Breathing Better NZ BB900 User manual

BB900 X-Large Air Purifier
BB900-2022/04

BB900 2022/04
Page 1
Remove all packaging from the unit
Open the filter locking cover.
1. Pull the lock levers to the inside as shown in figures 1 and 2
2. Pull the upper cover as shown in figure 3
3. Pull out the filter as shown in figure 4
4. Remove all packaging from the filter.
5. Replace the filter and cover

BB900 2022/04
Page 2

Page 3
Each press of the function button cycles through the below functions
BB900 2022/04

Page 4
Only use the filters supplied or provided by Breathing Better NZ in your Air
Purifier.
Your Air Purifier Filters are: BB900F X-Large Purifier Filter
Order your replacement filters online at www.breathingbetter.co.nz or email
us at [email protected]
The filter replacement light will turn red
when the filter needs to be replaced.
On average a filter will last about 1 year.
After replacing the filter, reset the filter replacement warning by pressing
and holding the filter replacement button for 5 seconds.
BB900 2022/04

1. Scan the QR Code below to download the Tuya Smart App.
2. Touch the on/off button on the machine, then touch the Wi-Fi button for 3-
5 seconds. When you hear a buzzer sound release the button. The wi-fi
button will flash.
3. Open the Tuya App and complete registration.
4. On the next page select Add device, then select Small Home Appliance,
and Air Purifier.
BB900 2022/04
Page 5

5. Enter your 2.4GHz Wi-Fi network name and password, confirm that the
Bluetooth on the unit is enabled and then select your unit in the following
screen
6. After successful connection, click on Done.
7. You can now use the app to control the unit.
BB900 2022/04
Page 6

Please check this table for before contacting us should your unit not be working as described.
Problem
Possible Cause
Try this…
The unit is not working
Power cord is not plugged in/there is
no electricity
Plug in the power supply / check
the power supply is working
Unit is not turned on Touch the ‘On/Off’ button
The purification effect is poor
Air inlet/outlet is blocked Clean the filter using s a soft
brush to remove particulates.
Wrong installation of the filter
direction
Reinstall the filter the correct
way.
The filter is too dirty Replace the filter
Air volume is small
Filter may be dirty Replace the filter
Packaging not removed Ensure all packaging is removed
Abnormal noise from unit
Ensure all packaging is removed and check for damage to the unit
Ensure the air inlet and outlet is not blocked by anything, and dean it if
needed.
While the negative ion function is on, "fizz” sound is normal.
If above corrective actions do not solve the problem, please contact
Breathing Better NZ. For safety, please do not disassemble the unit
and maintain by yourself to avoid damage.
Breathing Better NZ Limited
46 Galloway Road,
RD 1, Papakura 2580
New Zealand
021 02788465
[e-mail]
www.breathingbetter.co.nz
Page 7
BB900 2022/04

Page 8
BB900 2022/04

Page 9
BB900 2022/04

Thank you for purchasing your Air Purifier from Breathing Better NZ Limited.
Your 12-month Warranty for this unit was automatically registered when you
purchased it and starts 30 days from that date.
Read this warranty carefully and keep in a safe place.
1) For repairs to your unit, please contact us at [email protected]
and we will advise you of the nearest authorised repairer to contact.
2) This warranty does not cover damage caused by:
a. mistreatment of the unit. Examples are: Dropped unit, damage
caused by moisture.
b. natural disaster. Examples are Earthquake, Flooding, bush fire, and
other natural disasters.
c. using an unauthorised repairer.
d. incorrect use that is not following the operating instructions.
3) Damage to the Glass Control Panel is excluded from the warranty.
4) Damage caused outside the warranty period is not covered.
(Note: if any of the above are the cause of damage, please contact us
and we can refer you to your nearest repair. This will be at your cost)
5) Before returning your Air Purifier ensure there is no damage to the
exterior of the until, any included accessories, and the package overall.
For all warranty questions or claims, please contact us:
Breathing Better NZ Limited
46 Galloway Road,
RD 1, Papakura 2580
New Zealand
Ph: 021 02788465
Email: [e-mail]
Web: www.breathingbetter.co.nz
Page 10
BB900 2022/04
