Breez DELTA GBR50LED User manual

MODELS:
GBR
50
LED,
GBR80HLED,
GBR
80
LED,
GBR80MHLED
,
GBR100HLED
,
GBR
100
LED
INSTALLATION AND OPERATING INSTRUCTIONS
VENTILATION FAN /DIMMABLE LED LIGHT
READ AND SAVE THESE INSTRUCTIONS
GENERAL SAFETY INFORMATION
1. Make sure that the electric service suppl voltage is AC 120V,
60Hz.
2. Follow all local electrical and safet codes, as well as the Nation
Electrical Code (NEC) and the Occupation Safet and Health Act
(OSH Act).
3. Alwa s disconnect the power source before working on or near
the ventilating fan, motor or junction box.
4. Protect the power cord from sharp edges, oil, grease, hot
surfaces, chemicals or other objects.
5. Do not kink the power cord.
6. Do not install the unit where ducts are configured as shown in
Fig. A.
7. Provide suction parts with proper ventilation.
8. This unit is UL listed for use over a bathtub or shower when
installed in a GFCI protected branch circuit.
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR
INJURY TO PERSONS, OBSERVE THE FOLLOWING:
1. Use this unit onl in the manner intended b the manufacturer.
If ou have questions, contact the manufacturer.
2. Before servicing or cleaning unit, switch power off at service
panel and lock the service disconnecting means to prevent
power from being switched on accidentall . When the service
disconnecting means cannot be locked, securel fasten a
prominent warning device, such as a tag, to the service panel.
3. Installation work and electrical wiring must be done b qualified
person(s) in accordance with all applicable codes and standards,
including fire-rated construction.
4. Sufficient air is needed for proper combustion and exhausting of
gases through the flue (chimne ) of fuel burning equipment to
prevent back drafting. Follow the heating equipment
manufacturer’s guideline and safet standards such as those
published b the National Fire Protection Association (NFPA),
and the American Societ of Heating, Refrigerating and Air-
Conditioning Engineers (ASHRAE), and the local code authorities.
5. When cutting or drilling into wall or ceiling, do not damage
electrical wiring and other hidden utilities.
6. Ducted fans must alwa s be vented to the outdoors.
7. If this unit is to be installed over a tub or shower, it must be
marked as appropriate for the application and be connected to a
GFCI (Ground Fault Circuit Interrupter) --- protected branch
circuit.
8. Do not use this unit with an other solid-state control devices.
Solid-state control devices ma cause harmonic distortion,
which can cause a motor humming noise. (Avertissement: ne
convient pas à des régulateurs de vitesse à semi-conducteurs).
9. NEVER place a switch where it can be reached from a tub or
shower.
10. Not to be installed in a ceiling thermall insulated to a value
greater than R50. (This is required for installation in Canada
onl ).
Turning angle too large Duct shrink
Too many elbows Elbow near the body
Body
Fig. A
CAUTION
1. For General Ventilating Use Onl . Do Not Use To Exhaust
Hazardous Or Explosive Materials And Vapors.
2. Not for use in cooking areas. (Fig. B)
3. This product must properl connect to the grounding conductor
of the suppl circuit.
4. To reduce the risk of injur to persons, install the fan at least 8.2
feet (2.5m) above the floor.
45
Cooking area
45
Do not install above or
inside this area
Cooking
Equipment floor
Fig. B
Page 1.

MODELS:
GBR
50
LED,
GBR80HLED,
GBR
80
LED,
GBR80MHLED
,
GBR100HLED
,
GBR
100
LED
SUPPLIED ACCESSORIES
Part name Appearance Quantit
Grille 1
Fan 1
Housing 1
Duct Connector
(4’’)
1
Long Wood Screw
(ø4×25)
8
Machine Screw
(#8-32x5/16’’)
4
Suspension Bracket 4
INSTALLATIONS
Proper insulation around the fan to minimize building heat loss and
gain. 4’’ circular duct is recommended for installation. The ducting
from this fan to the outside of the building has a strong effect on
the air flow, noise and energ use of the fan. Use the shortest,
straightest duct routing possible for best performance, and avoid
installing the fan with smaller ducts than recommended. Insulation
around the ducts can reduce energ loss and inhibit mold growth.
Fans installed with existing ducts ma not achieve their rated air
flow.
Roof cap
(with built-in damper)
Seal gap
around
housing
Caulk termination
to duct
Fan housing
Short piece of flexible
duct helps alignment
and absorbs sound
Wall cap
(with built-in damper)
or
MOUNT
MOUNTMOUNT
MOUNT HOUSING
HOUSINGHOUSING
HOUSING WITH
WITHWITH
WITH FLANGE:
FLANGE:FLANGE:
FLANGE:
1. To bend the housing tabs out to 90 degree and make
housing tabs contact the bottom of the joist.
Joist
Tabs
2. The housing mounts with 4 long wood screw (Ø4×25).
Screw housing to joist through lowest holes in each
mounting flange, then through the other holes.
Joist
Long Wood Screw ( 4×25)
USING SUSPENSION BRACKETS
USING SUSPENSION BRACKETS USING SUSPENSION BRACKETS
USING SUSPENSION BRACKETS
3. Sliding suspension brackets available to allow for our
specific positioning of housing an where between joists
and span up to 24’’.
Suspension Bracket
4. Extend suspension brackets to the width of the joists. Make
sure the fan bod is level and perpendicular with the joist.
5. Secure suspension brackets to joists with long wood screw
(ø4×25).
6. Secure suspension brackets together with machine screw
(#8-32x5/16’’).
(#8-32x5/16”)
Joist
Joist
Page 2.

MODELS:
GBR
50
LED,
GBR80HLED,
GBR
80
LED,
GBR80MHLED
,
GBR100HLED
,
GBR
100
LED
DUCT CONNECTION
1. Insert the duct into the duct connector and tape all ductwork
connections to make them secure and air tight.
2. Install the duct with a gradient 1°~2° to the outside.
Inside Outside
Duct
Body
Gradient
1°~2°
Tape
Ceiling
Grille
Duct Connector
CONNECT WIRING
1. Follow all local electrical and safet codes, ANSI/NFPA70.
2. NEVER place a switch where it can be reached from a tub or
shower.
3. Connect wires as shown in wiring diagrams.
For Models: GBR50LED, GBR80LED, GBR80MHLED, GBR100LED
POWER SWITCH
LIGHT SWITCH
JUNCTION BOX SWITCH BOX
WHITE
BLACK
OFF
ON
WHITE
RED
GREEN
GRD
L
N
L
N
OFF
ON
ON/OFF SWITCH
(purchase separately) SWITCH BOX
120 VAC
LINE IN
WIRING
PLATE
BLACK
WHITEGROUND
(bare)
BLUE
LIGHT
SWITCH
POWER
SWITCH
For Models: GBR80HLED, GBR100HLED
HI
POWER SWITCH
MODE SWITCH
JUNCTION BOX SWITCH BOX
WHITE
BLACK
OFF
ON
BLUE
GREEN
GRD
L
N
L
N
ON
LIGHT SWITCH
RED
L
N
WHITE
WHITE
BLACK
ON/OFF SWITCH
(purchase separately) SWITCH BOX
120 VAC
LINE IN
WHITE
GROUND
(bare)
POWER
SWITCH
WIRING
PLATE
MODE
SWITCH
LIGHT
SWITCH
RED
BLUE
4. Using wire nuts (not provided), connect house power cable
to ventilating fan.
5. 14 AWG (2.1 mm
2
) is the smallest conductor that shall be
used for branch-circuit wiring.
GRILLE ATTACHMENT & TEST RUN
1. Insert the LED lighting connector into the power socket of
main bod as below shown.
2. Insert the motion plug connector into the housing. (for
GBR80MHLED onl )
3. Insert the mounting springs into the slots and mount the
grille to the fan unit.
Spring
Grille
Lighting Connector
Slots
4. When the power on, check for abnormal vibration or sound.
OPERATION
1. For Single Speed Models: GBR50LED, GBR80LED, GBR100LED
1-1. Turn on the power switch to operate ON or OFF, and LED
indicator is green.
2. For Humidit models: GBR80HLED, GBR80MHLED, GBR100HLED
Humidit tolerance is about ±10%. Long -time operation will
influence the detecting precision as dust accumulates. The
humidit switch ma need to be adjusted.
80 SERIES
0
50
CFM
50
80
70
60
%RH
0
60
CFM
50
80
70
60
%RH
100 SERIES
Low speed air volume
preset control
Humidity preset control
2-1. Humidit control mode: Turn the POWER switch on to
operate at humidit control mode - the LED indicator
will be blue. When the ambient humidit is higher than
the user-adjustable set-point, the fan will run at full
speed. When the ambient humidit is lower than the
set-point, the fan will continue to run at the full speed
until a 10-minute time dela has elapsed, and then will
automaticall change to the user -adjustable low speed
airflow.
Page 3.

MODELS:
GBR
50
LED,
GBR80HLED,
GBR
80
LED,
GBR80MHLED
,
GBR100HLED
,
GBR
100
LED
2-2. Full speed mode: Turn the MODE switch on to operate at
full speed mode - the LED indicator will be amber.
(for GBR80HLED and GBR100HLED onl )
2-3. When motion is detected, the fan will run at full speed
and the LED indicator will be amber. When motion is not
detected, the fan will continue to run at the full speed
until a 10-minute time dela has elapsed. (for
GBR80MHLED onl )
MAINTENANCE
WARNING:
Disconnect power source before working on unit. Routine
maintenance must be done ever ear.
CAUTION:
1. Never use gasoline, benzene, thinner or an other such
chemicals for cleaning the ventilating fan.
2. Do not allow water to enter motor.
3. Do not soak resin parts in water over 140°F (60°C).
CLEANING ：
1. Wash and clean grille. CAUTION: Do not let water into the lamp
base. (Use non-abrasive kitchen detergent, wipe dr with a new
cloth.)
2. Using a cloth dampened with non-abrasive kitchen
detergent, remove dust and dirt from ventilating fan. Wipe
dr with new cloth.
3. Replace grille.
SPECIFICATIONS – FAN
Model No. Voltage
(V)
Frequency
(Hz)
Weight
(lb.)
Power
Max.
(W)
Power
@ .1SP
(W)
Air Flow
@ .1SP
(W)
Remark
GBR5 LED
12 6
6. 8 4.4 5
Single
speed
GBR8 HLED,
GBR8 MHLED
6.1 13
11. 8
Full
speed
4.4 5
Low
speed
GBR8 LED 6. 13 11. 8
Single
speed
GBR1 HLED 6.3 14
13.6 1
Full
speed
4.8 6
Low
speed
GBR1 LED 6.2 14 13.6 1
Single
speed
Note: Design and specifications subject to change without notice.
SPECIFICATIONS – LED LIGHT
ITEM SPEC
VOLTAGE ( V ) 12
FREQUENCY ( Hz ) 6
POWER CONSUMPTION ( W ) 13
LUMINOUS FLUX ( Lumen ) 85
CORRELATED COLOR TEMPERATURE ( Kelvin ) 27
DIMMABLE YES
FCC QUALIFIED YES
ENERGY STAR QUALIFIED YES
ROHS QUALIFIED YES
SAFETY CERTIFICATIONS UL/cUL
DIMENSIONS
8
1/4
"
10
3/4
"
10
3/4
"
8"
4" Duct
10
3/4
"
10
3/4
" 8
1/4
"
5
3/4
"
7/8
"
WARRANTY
DELTA ELECTRONICS TH
REE YEAR LIMITED WAR
RANTY
Delta Electronics Inc. (“Delta Electronics”) warrants to the original
consumer purchaser in the USA and Canada that the Breez
ventilation fan products will be free from defects in material or
workmanship. This warranty is limited to three (3) years from the
original date of purchase.
Limitations and Exclusions
1. During the warranty period, a replacement for any defective
product will be supplied free of charge for installation by the
consumer. The warranty provided herein does not cover
charges for labor or other costs incurred in the
troubleshooting, repair, removal, and installation service.
2. All returns of defective parts or products must include the
product model number, and must be made through an
authorized Delta Electronics distributor. Authorized returns
must be shipped prepaid. Repaired or replacement products
will be shipped by Delta Electronics F.O.B. shipping point.
3. Delta Electronics shall not be liable for any indirect, incidental,
consequential, punitive, or special damages arising out of or in
connection with products use or performance, regardless of
the form of action whether in contract, tort (including
negligence), strict product liability or otherwise.
4. This warranty does not extend to fluorescent lamp starters and
tubes.
5. The warranty does not cover if user does not comply with
manufacture’s installation manual.
6. To qualify for warranty service, you must notify Delta
Electronics at the address or telephone number below.
7. Delta Electronics shall have no liability to the original owner-
user with respect to any defect caused by abuse, misuse,
neglect, improper transportation or storage, improper testing,
improper installation, improper operation, improper use,
improper maintenance, improper repair, improper alteration,
improper modification, tampering or accident of products or
parts thereof, or unusual deterioration or degradation of
products or parts thereof due to a physical environment
beyond the requirements of products’ specifications.
Address: 461 1 Fremont Boulevard, Fremont, CA 94538
US Toll Free Number: 1
-
888
-
979
-
9889
Page 4.
