Breville the Set & Serve LRC210 User manual

the Set & Serve™
Instruction Book - LRC210

2
IMPORTANT
SAFEGUARDS
READ ALL
INSTRUCTIONS BEFORE
USE AND SAVE FOR
FUTURE REFERENCE
•Carefully read all
instructions before
operating the rice cooker
for the first time and save
for future reference.
•Remove and safely discard
any packaging material
and promotional labels
before using the rice
cooker for the first time.
•To eliminate a choking
hazard for young children,
remove and safely discard
the protective cover fitted
to the power plug of this
rice cooker.
•Do not place the rice
cooker near the edge of
a bench or table during
operation. Ensure that the
surface is level, clean and
free of water and other
substances.
Contents
2Breville Recommends Safety First
8Components
9Functions
11 Rice Cooking Guide
13 Steaming Guide
14 Hints & Tips
17 Care & Cleaning
BREVILLE
RECOMMENDS
SAFETY FIRST
At Breville we are very safety
conscious. We design and
manufacture consumer
products with the safety of you,
our valued customer, foremost
in mind. In addition we ask
that you exercise a degree of
care when using any electrical
appliance and adhere to the
following precautions.

3
•Do not operate the rice
cooker on a sink drain
board.
•Always ensure the
rice cooker is properly
assembled before use.
Follow the instructions
provided in this book.
•Always operate the rice
cooker on a stable and
heat resistant surface.
•Do not place the cooker
directly on a heat sensitive
bench top, such as a stone
bench top, when cooking.
This type of bench top is
heat sensitive to uneven
heat and may crack if
heated locally. To cook
on a heat sensitive bench
top, place a chopping
board or heat proof mat
underneath the cooker.
•Never plug in or switch
on the rice cooker without
having the removable
cooking bowl placed
inside the rice cooker
housing.
•Use the removable cooking
bowl supplied with the rice
cooker. Do not use any
other bowl inside the rice
cooker housing.
•Do not use a damaged,
cracked or dented
removable cooking bowl.
If damaged, cracked or
dented, replace bowl before
using.
•Before placing the
removable cooking bowl
into the rice cooker base
ensure the base of cooking
bowl and base of rice
cooker is dry by wiping
with a dry soft cloth.
•Do not place food or liquid
in the rice cooker housing.
Only the removable
cooking bowl is designed
to contain food or liquid.
•Do not place the removable
cooking bowl, when hot,
on any surface that may be
affected by heat.
•Never operate the rice
cooker without food and
liquid in the removable
cooking bowl.

4
•Ensure the removable
cooking bowl is correctly
positioned in the rice
cooker base before you
commence cooking.
•When using this rice
cooker, ensure the lid
is properly positioned
before use.
•Do not operate the rice
cooker on an inclined
plane. Do not move while
the rice cooker is switched
on or during cooking.
•Care should be taken
when handling the rice
cooker after cooking,
ensuring the rice cooker
body and parts are not
touched as these may be
hot due to residual heat.
•The temperature of
accessible surfaces will be
high when the rice cooker
is operating and for some
time after use.
•Do not touch hot surfaces.
Use the cooker handle for
lifting and carrying the
rice cooker once the unit
is switch off.
•Do not touch hot surfaces,
use dry oven mitts to
remove the lid and/or
removable cooking bowl.
Lift and remove the lid
carefully and away from
yourself to avoid scalding
from escaping steam.
•Extreme caution must
be used when the rice
cooker contains hot food
and liquids. Improper use
may result in injury. Do
not move the rice cooker
during cooking.
•Do not allow water from
the lid to drip into the rice
cooker housing, only into
the removable cooking
bowl.
•Position the rice cooker
so that the steam vent is
directed away from you.
Lift and remove the lid
carefully to avoid scalding
from escaping steam.
•To prevent scratching the
non-stick surface of the
removable cooking bowl,
always use wooden or
plastic utensils.

5
•Always have the glass
lid placed correctly into
position on the rice cooker
throughout operation,
unless stated in the recipe
to have it removed.
•The glass lid has been
specially treated to
make it stronger, more
durable and safer than
ordinary glass, however
it is not unbreakable. If
struck extremely hard,
it may break or weaken,
and could at a later time
shatter into many small
pieces without apparent
cause.
•Do not leave the rice
cooker unattended when
in use.
•Do not place your face or
any other body part over
the rice cooker whilst
in use as the steam can
cause serious burns.
•Do not place anything,
other than the supplied lid
on top of rice cooker when
assembled, when in use
and when stored.
•Do not use chemicals, steel
wool, metal scouring pad
or abrasive cleaners to
clean the outside of the rice
cooker housing or cooking
bowl as these can damaged
the housing or the coating
of the cooking bowl.
•Do not immerse rice
cooker housing/base,
power cord or plug in water
or any other liquid.
•The rice cooker is not
intended to be operated by
means of an external timer
or separate remote control
system.
•Always ensure that the
power is off and the power
plug is removed from
the power outlet before
attempting to move the
rice cooker before cleaning
and storing.
•Keep the rice cooker
clean. Follow the cleaning
instructions provided in
the book.

6
IMPORTANT
SAFEGUARDS
FOR ALL
ELECTRICAL
APPLIANCES
•Fully unwind the power
cord before use.
•Connect only to a 230V
or 240V power outlet.
•Do not let the power cord
hang over the edge of
a bench or table, touch
hot surfaces or become
knotted.
•To protect against electric
shock, do not immerse
the power cord, power
plug or appliance in water
or any other liquid or
allow moisture to come
in contact with the part,
unless it is recommended
in the cleaning
instructions.
•The appliance is not
intended for use by
persons (including
children) with reduced
physical, sensory or
mental capabilities,
or lack of experience
and knowledge, unless
they have been given
supervision or instruction
concerning use of the
appliance by a person
responsible for their safety.
•Children should be
supervised to ensure that
they do not play with the
appliance.
•It is recommended to
regularly inspect the
appliance. To avoid a
hazard, do not use the
appliance if power cord,
power plug or appliance
becomes damaged in any
way. Return the entire
appliance to the nearest
authorised Breville service
centre for examination and
/ or repair.
•Any maintenance other
than cleaning should be
performed at an authorised
Breville Service Centre.
•This appliance is for
household use only. Do
not use this appliance for
anything other than its

7
intended use. Do not
use in moving vehicles
or boats. Do not use
outdoors. Misuse may
cause injury.
•The installation of
a residual current
device (safety switch)
is recommended to
provide additional safety
protection when using
electrical appliances.
It is advisable that a
safety switch with a rated
residual operating current
not exceeding 30mA be
installed in the electrical
circuit supplying the
appliance. See your
electrician for professional
advice.
•Always turn the appliance
to the OFF position,
switch off at the power
outlet and unplug at the
power outlet when the
appliance is not in use.
•Before cleaning, always
turn the appliance to the
OFF position, switch off at
the power outlet, unplug
at the power outlet and
remove the power cord,
if detachable, from the
appliance and allow all
parts to cool.
•Do not place this
appliance on or near a
heat source, such as hot
plate, oven or heaters.
•Position the appliance at
a minimum distance of
20cm away from walls,
curtains and other heat or
steam sensitive materials
and provide adequate
space above and on all
sides for air circulation.
FOR HOUSEHOLD USE ONLY
SAVE THESE INSTRUCTIONS

8
A. Cook ‘n’ Look toughened glass lid
With steam vent
B. Non-stick removable cooking bowl
With level indicator
C. Large 8 cup capacity
Cooks up to 16 cups of cooked rice at
a time
D. COOK and WARM lights
Red COOK light indicates that the rice cooker
is on the COOK setting. Amber WARM light
indicates that the rice cooker has automatically
switched to keep WARM
E
A
B
C
D
E. Selector control
F. Set & Serve measuring cup and
serving spoon
G. Non-stick steaming tray
Ideal for vegetables, seafood and poultry
H. Removable power cord (not shown)
FG
Components

9
Functions
BEFORE FIRST USE
Remove all promotional labels and any
packaging materials from the rice cooker.
Wash the removable cooking bowl, steaming
tray, measuring cup, serving spoon and glass
lid in hot soapy water, rinse and dry thoroughly.
HOW TO COOK RICE
1. Use the measuring cup provided to measure
required quantity of rice (refer to cooking
tables on page 11). Always measure level
cups, not heaped (Fig 1).
Fig. 1
NOTE
1 level Set & Serve measuring cup = 150 grams
uncooked rice
1 level Set & Serve cup uncooked rice = 2 Set &
Serve cups cooked rice (approx.)
The maximum quantity of uncooked white rice
to be cooked = 8 Set & Serve cups
The minimum quantity of uncooked white rice
to be cooked = 2 Set & Serve cups
CAUTION
When using the rice cooker, avoid any spillage
of water on the cooker as this may cause
damage to the rice cooker.
2. Place measured rice into a separate bowl
and wash by rinsing under cold water, to
remove any excess starch. The rice is ready
for cooking when the water runs clear.
3. Ensure the exterior of the removable cooking
bowl is clean and dry before placing it in the
outer housing, this will ensure proper contact
with the inner cooking surface (Fig 2).
Fig. 2
CAUTION
Always operate the rice cooker on a stable and
heat resistant surface.
4. Add washed rice to the removable cooking
bowl, ensuring rice is spread evenly across
the bottom of the bowl and not heaped to
one side (Fig 3).
Fig. 3
5. Add water using the following ratios:
White Rice
= 1 Set & Serve measuring cup water
: 1 Set & Serve measuring cup rice
Brown Rice
= 1½ Set & Serve measuring cups water
: 1 Set & Serve measuring cup rice
(Refer to table on page 11 for more
information)
6. Place glass lid into position on the cooking
bowl. The lid should sit level on the rim of
the bowl.

10
CAUTION
Never operate the rice cooker without food and
liquid in the removable cooking bowl.
CAUTION
Position the rice cooker so that the steam vent
is directed away from you. Lift and remove the
lid carefully to avoid scalding from escaping
steam.
CAUTION
Do not place your face or any other body part
over the rice cooker whilst in use as the steam
can cause serious burns.
7. Plug power cord into a 230V or 240V
power outlet and then switch the power on
at power outlet. The amber WARM light
will illuminate.
8. To commence cooking, press the selector
control. The red COOK light will illuminate.
9. When cooking is complete, the rice cooker
will automatically switch to the WARM
setting. The amber WARM light
will illuminate.
10. Open lid and fluff the rice with serving
spoon. Replace lid and allow rice to stand
for 10-15 minutes before serving. This
allows any excess moisture to be absorbed,
resulting in fluffier rice.
CAUTION
Do not touch hot surfaces; use dry oven mitts
to remove the lid and removable cooking bowl.
Lift and remove the lid carefully and away
from yourself to avoid scalding from escaping
steam.
NOTE
Rice can be kept in the automatic keep warm
setting for up to 5 hours.
Do not remove the glass lid until ready to serve
(except when fluffing the rice after cooking is
complete or as suggested in the recipes).
To stop the WARM setting, switch off at the
power outlet and then unplug power cord.
IMPORTANT
Always place liquid into removable cooking
bowl, or be ready to add oil, butter or
margarine, before depressing the selector
control to the COOK setting. Do not operate
with an empty cooking bowl.
Never try to force the selector control to stay
in the COOK setting after it has automatically
switched to the keep warm setting.
Do not interfere with automatic selector
control during operation.
To prevent scratching non-stick surface of
the removable cooking bowl or steaming tray,
always use wooden, silicon or plastic utensils.

11
Rice Cooking
Guide
The Set & Serve measuring cup provided
with your Breville Rice Cooker is used in the
following tables.
NOTE
The Set & Serve measuring cup is not a
standard metric measuring cup.
1 Set & Serve measuring cup is equal to 150g of
uncooked rice and 180ml of water.
1 Australian standard metric measuring cup is
equal to 200g of uncooked rice.
If your Set & Serve measuring cup is lost or
misplaced, use another cup but maintain
the same cooking ratios and ensure you do
not exceed the 8 cup maximum line in the
removable cooking bowl:
White rice = 1 cup water to 1 cup rice
Brown rice = 1½ cups water to 1 cup rice.
TIPS
Add a little extra water for fluffier rice and a
little less water for firmer rice.
Washed rice will have some extra water
adhering after rinsing. This extra water will
extend the cooking time slightly. Reduce the
measured amount of water to compensate, if
required.
Some rice varieties may require more water for
cooking, such as wild rice blends, Arborio rice
or short grain rice. Follow the directions on the
packet or use the brown rice cooking table.
Due to the additional water needed to cook
brown rice, some starchy water bubbles
may rise to the lid while cooking. For best
results, wash brown rice before cooking and
allow to stand on the WARM setting for 20
minutes after cooking to absorb the remaining
moisture.
WHITE RICE
CUPS UNCOOKED
WHITE RICE
CUPS COLD
TAP WATER
CUPS COOKED
RICE (APPROX)
COOKING TIME
(APPROX)
2 cups 2 cups 4 cups 10–15 minutes
4 cups 4 cups 8 cups 15–20 minutes
6 cups 6 cups 12 cups 20–25 minutes
8 cups 8 cups 16 cups 25–30 minutes
BROWN RICE
CUPS UNCOOKED
BROWN RICE
CUPS COLD
TAP WATER
CUPS COOKED
RICE (APPROX)
COOKING TIME
(APPROX)
2 cups 3 cups 4 cups 20–30 minutes
4 cups 6 cups 8 cups 35–40 minutes
5 cups 7½ cups 10 cups 45–50 minutes

12
RICE VARIATIONS
• Savoury Rice: Prepare rice in the rice cooker
as specified, substituting all the water with
the same quantity of chicken, beef, fish, or
vegetable stock.
• Sweet Rice: Prepare rice in the rice cooker
as specified substituting half the water
with apple juice, orange juice or pineapple
juice. Cooking rice with milk or cream is
not recommended as it will burn onto the
bottom of removable cooking bowl.
• Saffron Rice: Add ¼ teaspoon of saffron
powder or 2 saffron threads to every 2 cups
of water. Use white rice cooking tables.
Mix well.
• Arborio Rice: Arborio rice is short
round-grained pearly rice often used for
Italian risotto cooking. Use brown rice
cooking tables.
• Jasmine Rice: Jasmine rice is fragrant long
grain rice. Use white rice cooking tables.
• Basmati Rice: Basmati rice is an aromatic
long grain rice. Use white rice cooking
tables.
• Wild Rice: It is not recommended to cook
wild rice alone in the rice cooker as it
requires a substantial amount of water. It
is possible to cook wild rice as a blend with
white or brown rice.

13
Steaming Guide
Steamed foods retain most of their nutritional
value when cooked in the rice cooker.
Foods may be steamed by placing food in
the steaming tray over stock or water and
covering with the glass lid. Keep the glass lid
on while steaming food unless the recipe or
chart specifically states to remove the lid. By
removing the lid unnecessarily, steam is lost
and the cooking time will be extended.
1. Measure 3 Set & Serve measuring cups or
more of water or stock into the removable
cooking bowl. Use up to a maximum of 6
Set & Serve cups of water.
2. Place food to be steamed directly onto the
steaming tray and insert into the removable
cooking bowl. (Refer to the Steaming Charts
on the following pages for approximate
cooking times).
3. Place removable cooking bowl with
steaming tray into the outer housing and
cover with glass lid.
4. Plug power cord into a 230V or 240V
power outlet and then switch on. The amber
WARM light will illuminate.
5. Push the selector control down to begin
cooking. The red COOK light will
illuminate. Food needs to be monitored
when steaming, as the rice cooker will not
automatically switch to WARM when the
food is cooked.
6. When steaming is complete, remove
the food from the rice cooker. If further
steaming is required, ensure that there is
sufficient liquid in the removable cooking
bowl. If more liquid is required, add hot
water or stock and continue cooking.
7. Turn the rice cooker off at the power outlet
and unplug power cord. Allow to cool before
cleaning.
NOTE
Do not let the removable cooking
bowl boil dry during steaming. Hot liquid can
be added during the steaming process.
CAUTION
Always lift and remove the lid carefully,
angling it away from yourself to avoid scalding
from escaping steam.
The following steaming tables are based on
using 3 Set & Serve measuring cups of water or
stock. This will take approximately 8 minutes
to reach boiling point.

14
STEAMING VEGETABLES
• Smaller pieces will steam faster than larger
pieces.
• Try to keep vegetables to a uniform size to
ensure even cooking.
• Fresh or frozen vegetables may be steamed.
• If steaming frozen vegetables, do not thaw
before cooking.
• The size and shape of vegetables, as well
as personal taste, may call for adjustments
to the cooking time. If softer vegetables are
required, allow extra cooking time.
• Do not allow water or stock to reach the
steaming tray, otherwise the steaming will
not be effective.
VEGETABLES PREPARATION & TIPS QUANTITY COOKING TIME
(APPROX)
Asparagus trim, leave as spears 2 bunches 10–12 minutes
Beans top and tail, leave whole 150g 13–15 minutes
Beetroot small-medium trim, do not break skin 300g 20–25 minutes
Broccoli cut into florets 250g 10–12 minutes
Brussel Sprouts cut a cross in the base 250g 17–19 minutes
Cabbage large pieces 500g 10–12 minutes
Carrots cut into strips 3 medium 14–16 minutes
Cauliflower cut into florets 375g 17–19 minutes
Corn whole corn cobs 2 small cobs 17–19 minutes
Snow peas topped and tailed 250g 8–12 minutes
Peas fresh, peeled
frozen
250g
250g
10–14 minutes
8–12 minutes
Potatoes new, whole 6 (100g each) 35–40 minutes
Sweet Potato Kumera cut into pieces 300g 25–30 minutes
Pumpkin cut into pieces 300g 18–23 minutes
Spinach (English) leaves and stems cleaned ½ bunch 8–12 minutes
Squash (baby) topped and tailed 350g 10–12 minutes
Turnips peeled, sliced & cut to 50g pieces 350g 15–17 minutes
Zucchini sliced 350g 10–14 minutes

15
STEAMING FISH AND SEAFOOD
• Season fish with fresh herbs, onions, lemon etc. before cooking.
• Ensure fish fillets are in a single layer and do not overlap.
• Fish is cooked when it flakes easily with a fork and is opaque in colour.
TYPE SUGGESTIONS AND TIPS COOKING TIME (APPROX)
Fish – fillets
– whole
– cutlets
Steam until opaque and easy to flake. A cutlet is cooked
when the centre bone is able to be easily removed. 10–12 minutes
20–25 minutes
10–12 minutes
Lobster – tails Remove underside of shell 18–20 minutes
Mussels – in shell Steam until just opened 12–14 minutes
Clams and Pipis Steam until just opened 8–10 minutes
Prawns – in shell Steam until pink 8–10 minutes
Scallops Steam until opaque 8–10 minutes
Oysters – unopened Steam until the top shell starts to open. If the top shell
does not completely open, it will need to be opened with
a knife.
12–14 minutes
STEAMING POULTRY
• Select similar sized pieces of poultry for even cooking.
• For even cooking results arrange poultry in a single layer.
• Remove visible fat and skin.
• To obtain a browned appearance, sear the chicken before steaming.
• Check if poultry is cooked by piercing the thickest part. The poultry is cooked when the juices
run clear.
TYPE SUGGESTIONS AND TIPS COOKING TIME (APPROX)
Breast fillet Place skin side up (200g) 23–27 minutes
Drumstick Place thickest part to outside of the steaming tray 30–35 minutes
Thigh fillet Place thickest part to outside of the steaming tray 20–25 minutes

16
STEAMING DUMPLINGS
• Fresh or frozen dumplings and savoury buns can be steamed.
• Place small pieces of baking paper, cabbage or lettuce leaves, or spray the steaming tray with oil
under the dumplings to avoid sticking while cooking.
TYPE SUGGESTIONS AND TIPS COOKING TIME (APPROX)
BBQ pork or chicken buns Cook from frozen 12–16 minutes
Dumplings – frozen Separate before cooking 15–20 minutes
Dumplings – fresh 10–15 minutes

17
Care & Cleaning
Switch the rice cooker off at the power outlet
and then unplug power cord. Allow all parts
to cool before removing the power cord and
removable cooking bowl from the housing.
Wash removable cooking bowl, steaming tray,
measuring cup, serving spoon and glass lid in
hot, soapy water, rinse and dry thoroughly.
Breville does not recommend that any parts of
your rice cooker are washed in a dishwasher as
harsh detergents and hot water temperatures
may stain or distort the removable cooking
bowl and accessories.
The outer housing can be wiped over with a
damp cloth and then dried thoroughly.
If rice has cooked onto the inside of the
removable cooking bowl, place the bowl on a
flat surface and fill with hot, soapy water. Leave
to stand for approximately 10 minutes before
cleaning.
CAUTION
Do not use chemicals, steel wool, metal
scouring pad or abrasive cleaners to clean the
outside of the rice cooker housing or cooking
bowl as these can damage the housing or the
coating of the removable cooking bowl.
CAUTION
To prevent damage to the rice cooker do not
uses alkaline cleaning agents when cleaning.
Use a soft cloth and mild detergent.
WARNING
Do not immerse the outer housing or power
cord in water or any other liquid as this may
cause electrocution.
STORAGE
Ensure that the rice cooker is switched off and
unplug from the power point before moving.
Ensure that the rice cooker is completely cool,
clean and dry before storing.
Store the rice cooker with the removable
cooking bowl in the housing and the glass lid
on the bowl. Do not store anything on top of
the rice cooker.

18
Notes

19

Web: www.breville.co.nzWeb: www.breville.com.au
Breville is a registered trademark of Breville Pty. Ltd. A.B.N. 98 000 092 928.
Copyright Breville Pty. Ltd. 2017.
Due to continued product improvement, the products illustrated/photographed
in this brochure may vary slightly from the actual product.
LRC210–A17
Australian Customers
Mail: Locked Bag 2000
Botany NSW 1455
AUSTRALIA
Phone: [phone]
Fax: [phone]
Email: Customer Service:
[e-mail]
New Zealand Customers
Mail: Private Bag 94411
Botany Manukau 2163
Auckland NEW ZEALAND
Phone: [phone]
Fax: [phone]
Email: Customer Service:
[e-mail]
Breville Customer Service Centre
