Use & Care Manual
Professional/Custom Panel
Built-In Refrigerator/Freezer

3
Warnings
WARNING
To reduce the risk of fire, electric shock, or injury when using
your unit, follow these basic precautions:
• Read all instructions before using the unit.
• Never allow children to operate, play with, or crawl inside
the unit.
• Never clean unit parts with flammable fluids. The fumes can
create a fire hazard or explosion.
• Always turn the power on/off switch (located behind the air
grille on top right side) to the OFF position before
attempting to change light bulbs, clean, or service the unit.
FOR YOUR SAFETY
DO NOT STORE OR USE GASOLINE OR OTHER
FLAMMABLE VAPORS AND LIQUIDS IN THE VICINITY OF
THIS OR ANY OTHER APPLIANCE. THE FUMES CAN
CREATE A FIRE HAZARD OR EXPLOSION.
WARNING
ELECTRICAL SHOCK HAZARD
Plug into a grounded 3-prong outlet.
If a 2-prong wall receptacle is encountered,
contact a qualified electrician.
Do not remove ground prong.
Unit must be grounded at all times.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death, fire, or
electrical shock.
Your safety is important to us. This use and care manual
contains safety symbols and statements. Please pay special
attention to these symbols and follow any instructions given.
This symbol alerts you to hazards such as fire,
electrical shock or other injuries.
Congratulations and welcome to the elite world of Brigade
ownership. We hope you will enjoy and appreciate the care
and attention we have put into every detail of your new,
state-of-the-art refrigerator.
Your appliance is designed to offer years of reliable service.
This Use and Care Guide will provide you with the information
you need to become familiar with your refrigerator’s care and
operation.
Your complete satisfaction is our ultimate goal. If you have any
questions or comments about this product, please contact the
dealer from whom you purchased it, or contact our Consumer
Support Center at 1-888-845-4641.
We appreciate your choice of a Brigade refrigerator and hope
that you will again select our products for your other major
appliance needs.
For more information about the complete and growing
selection of products, contact your dealer or visit us online at
www.brigade.ca
Congratulations
2

Warnings
4 5
WARNING
To avoid serious illness or death, do not use unit where water
is unsafe or of unknown quality without adequate disinfection
before or after use of filter.
WARNING
To avoid electrical shock which can cause severe personal
injury or death, turn power disconnect switch to OFF before
cleaning. After cleaning, return power disconnect switch to
ON position.
WARNING
ELECTRICAL SHOCK HAZARD
Disconnect power or turn power
disconnect switch to OFF position before
removing top grille. Failure to do so can
result in death or electrical shock.
WARNING
BURN HAZARD
Do not touch condenser coils near
defrost pan.
Doing so can result in burns.
DANGER
RISK OF CHILD ENTRAPMENT
Before You Throw Away Your Old Refrigerator or Freezer:
• Take off the doors.
• Leave the shelves in place so that children may not easily
climb inside.
IMPORTANT: Child entrapment and suffocation are not
problems of the past. Junked or abandoned refrigerators are
still dangerous... even if they will sit for “just a few days.”
Table of Contents
Getting Started
Important Safety Instructions ______________________ 6
Proper Disposal (of old refrigerator) ________________ 7
Features __________________________________________ 8
Product Controls
Settings and Functions ____________________________ 14
Operation
Refrigerator (all units) _____________________________ 18
Freezer (all units) __________________________________ 22
Automatic Ice Maker ______________________________ 23
Automatic Dispenser ______________________________ 25
Installing Water Filter ______________________________ 26
Replacing Water Filter _____________________________ 27
Food Storage Guide _______________________________ 28
Product Care
Cleaning and Maintenance ________________________30
Troubleshooting ___________________________________ 39
Service Information ________________________________ 42
Warranty __________________________________________ 43

7
Proper Disposal (of old refrigerator)
Important Safety Instructions
6
• Install and level your refrigerator on a floor that will hold its
weight, plus food weight (approximately 1200 pounds
[540kg]) and in an area suitable for its size and use.
• Do not install a refrigeration unit near a heat source, nor in a
location where the surrounding temperature will fall below
60° F (16° C).
• Do not allow your refrigerator to be exposed to the weather
or outdoor elements.
• Connect your refrigerator only to the appropriate kind of
electrical outlet, with the correct power supply and
grounding. (Refer to the Electrical Requirements section
of the Installation Instructions.)
• Use the refrigerator only for the uses described in this
manual.
• Properly maintain the refrigerator.
• Be sure the refrigerator is not used by anyone unable to
operate it properly.
Getting Started
DANGER
RISK OF CHILD ENTRAPMENT
Before You Throw Away Your Old Refrigerator or Freezer:
• Take off the doors.
• Leave the shelves in place so that children may not easily
climb inside.
IMPORTANT:
Now that you have a new refrigerator, it is extremely important
that you dispose of your old appliance in a way that minimizes
the possibility that children will find it. There have been many
cases in years past of children crawling inside junked and
abandoned refrigerators and becoming trapped or suffocated.
Contact your municipal waste disposal authority to find out the
best and safest way to dispose of your old refrigerator.
Getting Started

98
Getting Started
Getting Started
General Features
• ProChill™ Temperature Management System
The variable speed DC Overdrive™ Compressor is
one of the quietest, most technologically advanced
compressors available. Electronic controls with
digital temperature readouts, maintain
temperatures and the multi-channel airflow system
and Odor Eliminator™ Evaporator remove odors
and excess humidity.
• Plasmacluster™* Ion Air Purifier
(all models except all freezer)
The Plasmacluster™ Ion Air Purifier uses ions to
eliminate airborne bacteria and mold spores,
remove odors and enhance food preservation.
Because of the unique technology, the
Plasmacluster™ will continue to keep the
refrigerator bateria and mold free without ever
having to be replaced.
• Adjustable Cold Zone™Drawer
(all models except all freezer)
Equipped with a separate temperature control, the
Adjustable Cold Zone™ Drawer can be set for
either produce or long-term fresh meat storage.
• Adjustable Humidity Zone™Drawer(s)
(all models except all freezer)
Equipped with an adjustable humidity control, the
Adjustable Humidity Zone™ Drawer(s) can be set
on the high setting for leafy greens or the low
setting for fruits and vegetables with skins.
• Super Clog-Resistant™Condenser
The pin and tube design of the condenser coil
prevents dust and other airborne particles from
clogging the condenser. Under normal operation,
the condenser is maintenance-free.
• Tru-Flush™Design
Keeps items in back within easy reach and allows
refrigerator to fit flush into 24” deep installation
cutout (Professional Integrated, Designer and
Custom Panel models).
*Plasmacluster is a trademark of Sharp Corporation.
30” W. Model Shown
1. Variable Speed DC Overdrive™ Compressor and Super Clog-Resistant™
condenser
2. Electronic Controls with digital temperature readouts
3. Wire Shelves (6)
4. Non-Adjusting Freezer Shelf (1)
5. Patented Modular
Storage System
• Gliding Ice Drawer
with 2 Ice Bins
• Gliding Freezer
Baskets (2)
6. Adjustable Door Bins
(Patent Pending)
30” W. Models–
Full-Width Bins (3)
36” W. Models–
Full-Width Bin (1)
Half-Width Bins (4)
7. Lights
12
7
3
4
6
5
Features (built-in all freezer)
