Briggs & Stratton SIMPLIPHI SPHI-B-4.9 User manual

|
1
|
REV202206240956
© 2022 Briggs & Stratton. All rights reserved.
Installation Manual
SimpliPHI™ 4.9 Battery
4.9
kWh

|
2
|
REV202207071617
SimpliPHI Your Energy
Security and Independence
and gain control of your own power.
SimpliPHI helps you manage your power as a personal resource. Anytime.
Anywhere. SimpliPHI energy storage optimizes integration of any power
generation source – solar, wind, generator – on or off grid, and protects your
home and mission-critical business functions from power outages and
intermittency. SimpliPHI storage technology reduces operating temperature
constraints, the risk of thermal runaway, and eliminates toxic coolants. Safer
lithium ferrous phosphate (LFP) chemistry that does not contain cobalt, the rare
earth metal that drives thermal runaway.
SimpliPHI’s battery technology utilizes the industry’s most environmentally
benign chemistry (LFP) combined with proprietary architecture and power
electronics (BMS) to create a portfolio of high performance, scalable and enduring
energy storage solutions that provide power security, resilience and daily cycling
for savings on your utility bill.
SimpliPhi Power offers proprietary, commercially available energy storage and management systems that are safer,
low-toxicity, reliable, durable, efficient, highly scalable, and economical over the lifetime of the SimpliPHI ESS.

|
3
|
REV202207071617
Table of Contents
Safety Information ................................................................................................................................................4
Important Safety Instructions................................................................................................................................................ 4
Warranty Statement................................................................................................................................................................... 5
1.0 – Introduction ........................................................................................................................................................................ 6
1.1 – Online Resources ..................................................................................................................................................................................6
1.2 – Technical Support .................................................................................................................................................................................6
1.3 – Product Overview.................................................................................................................................................................................6
1.3.1 – Battery Management System (BMS)......................................................................................................................................6
1.3.2 – Built-In Breaker..................................................................................................................................................................................7
1.3.3 –Networking Communication Cables & Plugs ....................................................................................................................8
1.4 – Specifications...................................................................................................................................................................... 8
2.0 –Safety ...............................................................................................................................................................9
2.1 – General Safety Instructions ........................................................................................................................................ 9
2.2 – Response to Emergency Situations...................................................................................................................... 10
3.0 – Pre-Installation......................................................................................................................................... 10
3.1 – SimpliPHI Battery Performance............................................................................................................................. 10
3.2 – SimpliPHI Battery System Sizing ........................................................................................................................... 11
3.2.1 – Sizing for All Systems .................................................................................................................................................................. 11
3.2.2 – Additional Sizing Considerations for AC Coupled Systems................................................................................... 11
4.0 – Installation ................................................................................................................................................. 12
4.1 – Installation Options...................................................................................................................................................... 12
4.2 – Environmental Considerations............................................................................................................................... 12
4.2.1 – Charging & Discharging at Temperatures Below Freezing and Above 70° C ............................................. 12
4.2.2 – Explosive Gas Precautions....................................................................................................................................................... 13
4.2.3 – Anti-Corrosion Protection....................................................................................................................................................... 13
4.3 – Mounting Hardware .................................................................................................................................................... 13
4.4 – Dimensions and Weight............................................................................................................................................. 13
4.5 – SimpliPHI Battery Connection Terminals......................................................................................................... 14
4.5.1 – Batteries with Threaded Studs.............................................................................................................................................. 14
4.5.2 – Torque Batteries with Threaded Studs............................................................................................................................. 14
4.6 – Electrical Wiring............................................................................................................................................................. 15
4.6.1 – Increasing Storage Capacity via Parallel Wiring .......................................................................................................... 15
4.6.2 –Wiring Batteries with Threaded Studs using Battery Cables ................................................................................ 15
4.6.3 – Parallel Wiring Batteries with Threaded Studs using Interconnecting 4/0 Cables.................................. 18
4.7 – Communications Wiring............................................................................................................................................ 19
4.8 – Conduit Box Installation (Outdoor Installations).......................................................................................... 20
4.9 – Battery System Commissioning............................................................................................................................. 21
4.10 – Battery Bank Expansion.......................................................................................................................................... 23
5.0 – Programming ............................................................................................................................................ 23
5.1 – Operating Parameters per Warranty.................................................................................................................. 23
6.0 – Troubleshooting ...................................................................................................................................... 24
Appendix A – SimpliPHI Battery Safety & Green Attributes, Certifications................................ 26

|
4
|
REV202207071617
Safety Information
Important Safety Instructions
SAVE THESE INSTRUCTIONS –This manual contains important instructions that must be read, understood
and obeyed during installation of ESS and/or accessories.
WARNING! LOSS OF LIFE. THIS PRODUCT IS NOT INTENDED TO BE USED IN A
CRITICAL LIFE SUPPORT APPLICATION. FAILURE TO ADHERE TO THIS WARNING
COULD RESULT IN DEATH OR SERIOUS INJURY
DANGER! INDICATES A HAZARDOUS SITUATION WHICH WILL RESULT IN DEATH OR
SERIOUS INJURY. THESE CONDITIONS WILL RESULT IN THE TERMS OF THE WARRANTY
BEING VIOLATED.
WARNING! WARNINGS IDENTIFY CONDITIONS OR PRACTICES THAT COULD RESULT
IN PERSONAL INJURY AND SEVERE DAMAGE TO THE SYSTEM. THESE CONDITIONS
WILL RESULT IN THE TERMS OF THE WARRANTY BEING VIOLATED.
CAUTION! CAUTIONS IDENTIFY CONDITIONS OR PRACTICES THAT COULD RESULT IN
DAMAGE TO THE UNIT OR OTHER EQUIPMENT CONNECTED. THESE CONDITIONS CAN
RESULT IN THE TERMS OF THE WARRANTY BEING VIOLATED.
WARNING! INDICATES AN ELECTRIC SHOCK HAZARD.
CAUTION:
THIS MANUAL IS SPECIFIC TO THE SIMPLIPHI BATTERIES THAT FEATURE
INTERNAL COMMUNICATIONS WITHIN THE BMS. DO NOT FOLLOW THESE
GUIDELINES IF YOU ARE USING THE STANDARD PHI PRODUCT LINE. PLEASE
CONSULT THE INSTALLATION MANUAL SPECIFIC FOR YOUR BATTERIES FOUND
HERE: SIMPLIPHI PHI BATTERY INSTALLATION MANUAL LINK
CAUTION! BEFORE INSTALLING AND USING BATTERIES, READ ALL INSTRUCTION
MANUAL AND CAUTIONARY MARKINGS ON THE BATTERY AND ALL APPROPRIATE
SECTIONS OF THIS GUIDE.

|
5
|
REV202207071617
CAUTION: THESE 3 THINGS WILL VIOLATE THE TERMS OF THE WARRANTY &
DAMAGE THE BATTERIES. READ IN FULL PRIOR TO BATTERY INSTALLATION
Warranty Statement
The following abbreviated guidelines do NOT encompass all SimpliPHI Battery Warranty details. Failure to
adhere to the Warranty and Installation Manual requirements will Violate the terms of the Warranty. Read the
battery’s complete Warranty prior to installation and register the battery according to the form found at the
bottom of the same web page address: https://simpliphipower.com/wp-
content/uploads/documentation/SimpliPHI-series/warranty.pdf
Before using the battery, please read all instructions and cautionary markings on the unit and this manual.
Store the manual where it can be accessed easily.
This manual is for qualified personnel. The tasks described in this manual may be performed by qualified
personnel only.
CAUTION: The following will result in damage to your PHI batteries and will Violate the terms of the Warranty:
1. Incorrect battery wiring and/or installation
a. Verify polarity at all connections with a standard voltmeter if applicable (1) before energizing the
system and (2), before switching the built-in circuit breaker to the “ON” position. Reverse polarity at
the SimpliPHI Battery terminals will Violate the terms of the Warranty and may permanently damage
the SimpliPHI Batteries.
b. SimpliPHI Batteries must be fully charged before commissioning (i.e. before connecting loads). Failure
to do so will damage the SimpliPHI batteries and Violate the terms of the Warranty.
c. Lugs, washers and lug nuts must be installed according to the Installation Manual. Failure to do so will
damage the SimpliPHI Batteries and Violate the terms of the Warranty.
2. Pairing the battery with incompatible equipment. Use of accessories not recommended or sold by the
manufacturer may result in a risk of fire, electric shock, or injury to persons and will Violate the terms of the
Warranty.
a. Contact SimpliPhi Technical Support at [phone] x 1 regarding the compatibility of any
equipment not explicitly listed in the ‘SimpliPHI Integration Guides’ section of the Product
Documentation web page (https://simpliphipower.com/product-documentation/).
b. Refer to the SimpliPhi-Approved Chargers list (Appendix B of this document) for all compatible
external / plug-in battery chargers. Use only a SimpliPhi-approved LFP battery charger if ancillary
charging is required before installation, testing or troubleshooting. Failure to use a SimpliPhi-approved
LFP battery charger will damage the SimpliPHI Battery and Violate the terms of the Warranty.
3. Incorrect inverter and/or charge controller settings. Operating the SimpliPHI Battery in conjunction with
equipment not programmed to the SimpliPHI Battery’s settings will Violate the terms of the Warranty.
a. Refer to the ‘SimpliPHI Integration Guides’ section of the Product Documentation web page
(https://simpliphipower.com/product-documentation/) for all inverter and charge controller settings.
b. Although each SimpliPHI Battery contains an internal Battery Management System (BMS) with
circuitry that protects the SimpliPHI Battery cells from over-charge, over-discharge and extreme load
amperage, the SimpliPHI Battery must always be installed with appropriate inverter and/or charge
controller settings and power electronics to protect the SimpliPHI Battery from open solar
photovoltaic (PV) voltage and other high voltage charging sources.
c. Failure to protect the SimpliPHI batteries from voltages higher than the battery voltage rating (48-56
VDC) will destroy the SimpliPHI batteries, cause electrical fires and Violate the terms of the Warranty.

|
6
|
REV202207071617
The SimpliPHI Battery Warranty does NOT cover product damage caused by mishandling or improper use per
the Installation Manual, Integration Guides and Warranty, exposure to corrosive liquids or solvents, impacts
from falling objects or from being dropped, or attempts to repair the battery by any party other than SimpliPhi.
The complete list of Warranty Exclusions is included in the SimpliPHI Battery Warranty document:
https://simpliphipower.com/wp-content/uploads/documentation/SimpliPHI-series/warranty.pdf
1.0 – Introduction
1.1 – Online Resources
The Product Documentation section of SimpliPhi’s web site (https://simpliphipower.com/product-
documentation/) includes Specification Sheets, Warranties, Installation & Operator’s Manuals, and Integration
Guides for all SimpliPhi’s current and legacy products.
SimpliPhi’s YouTube channel (https://www.youtube.com/channel/UCcuCaLT_G3Hhumteh-pI5yg/videos) has
instructional videos showing various steps of the battery installation process in detail.
1.2 – Technical Support
SimpliPHI ESS Technical Support (805-640-6700 x 1, [e-mail]) is available to take any questions
regarding this manual or general installation questions. For assistance with battery system commissioning,
Briggs & Stratton asks that a commissioning call be scheduled ahead of time with Technical Support.
We encourage you or your installer to contact ESS Tech Support with any questions. We are committed to
working with you and your installation team to achieve a safe, reliable storage system that will provide years of
maintenance-free service that is covered by our Warranty terms & conditions.
1.3 – Product Overview
The SimpliPHI deep-cycle Lithium Ferro Phosphate (LFP) Battery is optimized with proprietary cell
architecture, power electronics, Battery Management System (BMS) with communications, manufacturing
materials and processes. This assures the highest grade and quality, longest cycle-life, greatest efficiency and
freedom from material impurities, toxicity and hazardous risk. The SimpliPHI Battery is modular, lightweight
and scalable. It provides power security and seamless integration of renewable and traditional sources of
energy in conjunction with or independent of the grid.
1.3.1 – Battery Management System (BMS)
Each SimpliPHI Battery contains circuitry that protects the LFP cells from damaging conditions
(overcharge, over-discharge, extreme load amperage, etc.). If pre-programmed BMS values are
exceeded, the protective circuitry will shut down the flow of electricity to/from the SimpliPHI Battery.
In some cases, the BMS will automatically resume the flow of electricity to/from the SimpliPHI Battery
when the battery is no longer in damaging conditions. In other cases, the SimpliPHI Battery’s self-
protection mechanism will result in the battery’s breaker tripping and requiring a manual re-set (refer
to Section 6.0 - Troubleshooting of this Manual for manual re-set instructions).
Regardless, once SimpliPHI Battery operation resumes and the connected inverter is back on,
SimpliPhi recommends checking that the inverter’s settings are still correct. Often, inverter system
settings will be saved within the inverter memory storage and will not need to be reset. However, refer
to SimpliPhi’s SimpliPHI Integration Guides for inverter and/or charge controller settings to verify the
set-point values. (https://simpliphipower.com/product-documentation/).

|
7
|
REV202207071617
CAUTION: Although each SimpliPHI Battery contains an internal communication based BMS
with circuitry that protects the SimpliPHI Battery cells from over-charge, over-discharge and
extreme load amperage, the SimpliPHI Batteries must always be installed with appropriate
inverter and/or charge controller settings to protect the SimpliPHI Battery from open PV
voltage and other high voltage charging sources. Exposure to higher voltage than the
SimpliPHI battery rating (48-56 VDC) will Violate the terms of the Warranty and may damage
the SimpliPHI batteries.
1.3.2 – Built-In Breaker
SimpliPHI batteries are outfitted with a hydraulic/magnetic circuit breaker. This breaker increases
safety during shipping and installations and allows the battery to effectively be turned “OFF” or “ON.”
The breaker works in conjunction with the battery’s built-in BMS and creates additional safety,
efficiency and functionality in the overall power storage system.
Figure 1.0 – SimpliPHI 4.9 Circuit Breaker
NOTE:Circuit breakers, disconnects and fuses should be employed throughout several points of a power
storage and generation installation to effectively isolate and protect all components of the system to safeguard
against faults, short circuits, polarity reversals or a failure of any component in the overall system. Fuses,
breakers, wiring ratings and values should be determined by established electrical codes and standards and
evaluated by certified electricians, installers, and regional code authorities.
Detail A ON
OFF

|
8
|
REV202207071617
1.3.3 –Networking Communication Cables & Plugs
Each SimpliPHI battery comes with a 4’ CAT5 cable and a terminator plug for networking
communication set-up (explained in greater detail in Section 4.7 – Communications Wiring).
1.4 – Specifications
Please review the tables below for SimpliPHI 4.9 battery specifications.
Table 1.0 - SimpliPHI 4.9 Performance Specifications
DC Voltage - Nominal 51.2 VDC
DC Operating Voltage
Range 48 VDC to 56 VDC
Amp-Hours 97 Ah
Rated Capacity 4.9 kWh DC at 100% DoD
3.9 kWh DC @ 80% DoD
MAX Surge Discharge
Rate
(10 minutes)
100 Amps DC
(5.1 kW DC)
MAX Continuous
Discharge & Charge Rate
48.5 Amps DC
(2.5 kW DC)
DC Voltage Range148 to 56 VDC
Depth of Discharge1up to 100%
Operating Efficiency 96%
Self-Discharge Rate < 1% per month (when off)
Memory Effect None
Cycle Life 10,000+ cycles (@ 80%
DoD)
Warranty Period 10 Years
Notes:
1Max operating ranges. Refer to Warranty for
recommended conditions.
Table 1.1 - SimpliPHI 4.9 Mechanical Specifications
Dimensions (W x H x D)
23 x 28.5 x 8.5 in.
(30” H w/terminals) / 3.2 ft3
(584 x 724 x 216 cm / 0.1 m3)
Weight 160 lbs. (73 kg)
Terminal Size 3/8” (10mm) threaded studs
Minimum Battery Cable
Size 4/0 (battery to battery)
2/0 (battery to inverter)
Table 1.2 - SimpliPHI 4.9 Installation Specifications
Maximum Battery
Quantity per System
72 batteries
(358.56 total kWh @ 100% DoD)
Comms Compatible
Inverters
SimpliPhi 6kW, Sol-Ark, SMA Sunny
Island
Mounting Wall Mount
Table 1.3 - SimpliPHI 4.9 Environmental Specifications
Charging Temperature 32° to 120° F (0° to 49° C)
Operating Temperature -4° to 140° F (-20° to 60° C)
Storage Temperature 6 months: 14° to 77° F (-10° to 25° C)
3 months: -4° to 113° F (-20° to 45° C)
Enclosure IP 65 with terminal covers

|
9
|
REV202207071617
Table 1.4- SimpliPHI BMS Specifications
SimpliPHI 4.9™ Internal BMS
Programmed Absorb Voltage
56 VDC
Programmed Float Voltage
54 VDC
Over-Voltage Fault Trip2
60 VDC
Low-Voltage Fault Trip2
45 VDC
Programmed Discharge & Charge Rate
per Battery2
48.5 Amps DC
(2.5 kW DC)
Charging Low Temperature Fault Trip2
32° F (0° C)
Discharging Low Temperature Fault Trip3
-4° F (-20° C)
High Temperature Fault Trip3
158° F (70° C)
Maximum Quantity of Networked Batteries
72
Networking Cable
CAT5 or greater
Networking Port
RJ45
Notes:
2These SimpliPHI BMS Fault Trip conditions result in the need for the BMS to be re-set manually (refer to
Section 6.0 - Troubleshooting of this Manual)
3These SimpliPHI BMS Fault Trip conditions result in automatic BMS reconnection when fault conditions are no
longer detected. There is no need to re-set the BMS manually in these instances.
Specifications are typical/nominal. (Subject to change without notice, refer to most recent edition of Installation
Manual and Firmware version information on our website.)
.
2.0 –Safety
For safety reasons, read all instructions and cautionary markings on the SimpliPHI Batteries, and all
appropriate sections of this manual. Failure to follow instructions provided in the Installation Manual,
Integration Guides and/or Warranty will Violate the terms of the Warranty and damage the batteries.
2.1 – General Safety Instructions
•Do not operate if the SimpliPHI Battery has been damaged in any way during shipping or on-site.
•To reduce the chance of short-circuits, always use insulated tools when installing or working with
SimpliPHI batteries or other electrical equipment.
•Remove personal metal items such as rings, bracelets, necklaces, and watches when working with
SimpliPHI batteries and electrical equipment. Wear insulated gloves and rubber shoes.
•SimpliPHI Batteries pose some risk of shock or sparking during the installation and initial wiring and
connection process. This is consistent with all other battery-based storage formats. To minimize the
risk of shock or sparks during the installation and commissioning of the system, make sure the built-in
breaker is in the “OFF” position.

|
10
|
REV202207071617
•To avoid a risk of fire and electric shock, make sure that existing system wiring is in good condition and
that the wire is not undersized. Do not operate the SimpliPHI Battery in conjunction with damaged or
substandard wiring or balance of system equipment.
These safety precautions are in addition to the Warnings previously outlined on page 4 of this Manual.
2.2 – Response to Emergency Situations
As with any battery, if the SimpliPHI Battery’s cells are severely damaged due to physical abuse, reverse
polarity, high voltage, unmitigated current or other electrical phenomenon incurred outside of Warranted
installation specifications, it can cause electrolyte leakage and other failures. The electrolyte can be ignited by
an open external flame. However, unlike other lithium-ion batteries with cobalt oxides (e.g. LCO, NCM and
NCA), the SimpliPHI LFP Batteries’ electrolyte and other material components generate a limited amount of
heat and do not go into a state of thermal runaway with fire propagation. The SimpliPhi UL 1973 Battery
Certification verifies “No Thermal Runaway” (see MSDS for chemical analyses). Additional fire safety testing
was conducted through UL 9540A protocols which has demonstrated that SimpliPHI batteries do NOT go into
unmitigated thermal runaway, fire propagation or deflagration when installed in properly operating systems
per this manual.
While SimpliPHI Batteries do not go into thermal runaway with fire propagation, the following protocol should
be followed in the event that the SimpliPHI Batteries are subjected to electrical fire caused by other system
components or failures:
•Ensure that the system is no longer energized, either from the solar array or the grid (main
disconnect).
•Separate any external cables from batteries if present (cut if necessary) using insulated tools.
•Wear a respirator or dust mask to avoid inhaling soot/dust.
•Wear insulating and abrasion-resistant gloves (if permeable, over nitrile or similar gloves).
•Move battery debris into non-conductive bins capable of handling the weight.
•Dispose as regulations require.
CAUTION: While water is an acceptable and effective extinguishing agent for the SimpliPHI
Battery model, the Balance of System equipment used in conjunction with the SimpliPHI
Batteries may require specialized extinguishers such as FM-200 or CO2 suppression systems.
3.0 – Pre-Installation
3.1 – SimpliPHI Battery Performance
SimpliPHI Batteries do not need to be de-rated unless running continuously at more than 90% capacity. To
achieve the greatest cycle life of 10,000 cycles, it is recommended that the SimpliPHI Batteries are operated at
80% maximum Depth of Discharge.
Due to the SimpliPHI Battery’s internal self-protection mechanisms, the battery will not charge when internal
battery temperatures are below 32° F (0° C), will not discharge when internal temperatures are below -4° F (-
20° C), and will not charge or discharge when internal temperatures exceed 158° F (70° C).
All SimpliPHI Batteries are balanced during final production and testing stages. Following proper wiring
guidelines and fully charging the SimpliPHI batteries prior to applying loads ensures that a system will not
require any manual balancing processes.
