Briggs & Stratton NAX 100C User manual

NAX 100C

2
A
B
C
D

3
CHAIN SAW
NAX 100C

4
Fig. 2 Fig. 3
Fig. 4 Fig. 5
CONSTRUCTION OF CHAIN SAW AND PREVIEW DRAWINGS
Fig. 1

5
Fig. 8 Fig. 10
Fig. 9
Fig. 6 Fig. 7

6
Fig. 11 Fig. 12
Fig. 14 Fig. 15
Fig. 13

7
Fig. 16 Fig. 17
Fig. 20 Fig. 21
Fig. 18 Fig. 19

8
Fig. 22 Fig. 23
Fig. 24 Fig. 25
Fig. 26 Fig. 27

9
Fig. 29
Fig. 28

10
Fig. 30

11
Original operation manual, edition 1/2020 Translation of the original operation manual from polish language
This manual should be treated as an integral part of the device. It should be stored in the place provided for it so that it is easily
accessible. Remember to pass on the operation manual to a new owner or user if the device is resold or transferred to another
person.
TABLE OF CONTENTS
Markings on the machine and warning pictograms 2
Chain saw construction and overview drawings 4
Table of contents 11
Technical data 12
Description of graphic pages and pictograms 13
Safety rules for machines and devices with internal combustion engine 13
General safety regulations 13
Detailed safety regulations 15
Safety and producer’s liability 18
Residual risk 18
Usage 18
Additional information for the user 18
Preparing for work 18
Construction of a chainsaw 19
Starting the saw 21
Operation 22
Maintenance 22
Transport 24
Storage 25
Review and diagnosis of problems 26
Device assembly diagrams 27
Warranty and service 27
Declaration of Conformity 28
Warranty conditions 30
Warranty card 31

12
TECHNICAL DATA
CIRCULAR COMBUSTION SAW
Type, model
NAX 100C
Engine
TT-1E34F series BS
Fuel mix
40: 1 (4 l of gasoline for every 100 ml of two-stroke oil)
Fuel tank capacity
230 cm3
Mix oil (recommended)
Briggs & Stratton for two-stroke engines
Oil for lubricating the chain
NAX
Oil tank capacity for chain lubrication
160 cm3
Engine capacity
25.4 cc
Machine rated power
0.75 kW –8500 rpm
Maximum torque
1.0 Nm - 6500 rpm
Spark plug
TORCH L8RTF
Maximum engine speed with cutting attachment
10500 rpm
Maximum engine idle speed
3300 ± 500 rpm
Gearwheel
6T X 3/8’’
Chain scale
3/8’’
Chain thickness
1.3 mm
Number of chain links
40 pieces,
Guide length
10’’ (25 cm)
Maximum chain feed speed
~ 19 m/s
Sound pressure level
LpA= 93.4 dB(A) K =3 dB
The value of vibrations transmitted by the machine and acting
on the operator's upper limbs
front handle a front_hv, eq 7.128 m/s2
rear handle a rear_hv, eq 6.895 m/s2
K= 1.5 m/s2
Guaranteed sound power level LWA
117 dB(A)
Equipment mass
3.5 kg
Year of manufacture
2020
THE DEVICE INCLUDES:
petrol chain saw (power supply unit, guide bar guard, guide bar, chain, butt),
screws, nuts, necessary wrenches,
operation manual, EC declaration of conformity, warranty conditions, warranty card.

13
DESCRIPTION OF GRAPHIC PAGES AND PICTOGRAMS
Pictograms page 2.A
1. Attention! Danger. Exercise special caution.
2. Important! Read the instructions and follow the warnings.
3. Risk of fire or explosion. Gasoline is highly flammable.
4. Keep out of the reach of children.
5. It is prohibited to work in the rain.
6. Note: Exhaust gases are harmful to health. There is a danger of poisoning or suffocation. Do not use the device indoors.
7. Note: A hot surface can cause burns.
8. Wear protective gloves!
9. Keep safe distance.
10. Note: Disconnect the high-voltage pipe from the spark plug before maintenance and / or repair.
11. Never operate the saw only with one hand.
12. Hold the saw with both hands.
13. Danger of kickback. Be careful
14. Use only a gas / oil mixture as fuel.
15. Do not dispose of used equipment. It is the user's responsibility to hand over used equipment to a designated collection point for
waste recycling.
16. Wear safety glasses and ear protection.
OTHER MARKINGS ON THE MACHINE
1. Name plate (page 2.B)
2. Guaranteed sound power level (page 2.C)
3. Warnings and other labels (page 2. D)
SAFETY RULES FOR MACHINES AND DEVICES WITH COMBUSTION ENGINE
WARNING!
Read this manual thoroughly. Familiarize yourself with the safety regulations and with the control systems and the principles
of proper use of the device.
Failure to observe the following warnings and safety instructions may result in electric shock, fire and / or serious injury.
Retain this operation manual for reference.
This equipment is not intended for use by persons (including children) with reduced physical, sensory or mental capacity or
without experience or knowledge of the equipment, unless supervised or in accordance with instructions for use given by
persons responsible for their safety.
Do not allow the device to be used by children, adolescents up to 16 years of age and people not acquainted with the
device's operation manual.
GENERAL SAFETY REGULATIONS
WORKING AREA SAFETY
Ensure good lighting and order in the workplace. Cluttered and dark areas contribute to accidents.
Keep children and observers away from places where devices with an internal combustion engine are used. Distractions can
cause lose of control of the device. Garden equipment should be left away from unauthorized persons.
The operator or user is responsible for accidents or hazards occurring to other people or the environment.

14
SAFETY DURING WORKING WITH FUEL
The internal combustion engine is designed to run on gasoline or a fuel mixture (see type of fuel in the device's technical
data).
Gasoline should be stored only in specially prepared containers (canisters).
Store gasoline away from factors that could cause a fire, e.g. bonfires, open flames, where there is electric sparking,
elevated temperature, welding sparks or other heat sources that can cause fuel to ignite.
The fuel tank should only be filled outdoors.
It is extremely dangerous to smoke cigarettes or use open flames when the machine is running or when filling the fuel tank.
Always turn the engine off and cool before filling the tank with fuel.
Do not fill the tank above the lower edge of the filler neck, gasoline has a high thermal expansion.
If you spill fuel, immediately wipe up spilled gasoline with a dry cloth.
When filling the fuel tank, be careful not to spill fuel on clothing. Gasoline-soaked clothing can catch fire and should be
changed immediately.
After filling the tank with fuel, tighten the cap tightly and before starting the engine, move the fuel canister to a place at least
3 m away from the place where the filling was carried out.
Before starting the engine, check the tightness of the entire fuel system, especially the fuel tank, fuel lines, connectors, filler
cap and carburetor area. Do not start the engine if you detect a leaking fuel system as it may cause a fire.
The device should not be operated in explosive atmospheres, which form flammable liquids, gases or dust. The internal
combustion engine may create sparks which may ignite the dust or fumes.
Do not use the device if you have trouble turning it off. Any device that cannot be turned off is dangerous and must be
repaired.
Do not store the device with filled fuel tank indoors. Gasoline vapors are flammable and dangerous to health.
CAUTION!
Avoid breathing gasoline vapors and exhaust fumes. Gasoline, gasoline vapors and exhaust fumes can cause poisoning.
Do not operate the saw in closed or poorly ventilated rooms. In case of headache, nausea, hearing or vision impairment, stop
work immediately.
PERSONAL SAFETY
 Be foresightful, watch what you do, and use common sense when working with the equipment. Do not use the equipment
when you are tired or under the influence of drugs, alcohol or medication. A moment of inattention during work can cause
serious personal injury.
 Protective equipment should be used. Always wear safety glasses. Wearing protective equipment such as a dust mask, non-
slip shoes, helmet or hearing protectors under the right conditions will reduce personal injury.
 Before starting the equipment, remove all objects and keys. Leaving the key in the rotating working part of the machine can
cause personal injury.
 Do not lean too far. You should always stand firm and balance. This will allow better control in unpredictable situations.
 Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing and gloves away from moving parts. Loose
clothes, jewelry or long hair can be caught in moving parts.
 When working, hold the tool by the additional handles if the tool is equipped with them. Losing control of the tool carries the
risk of injury.
 Do not use the device if you have trouble turning it off. Any device that cannot be turned off is dangerous and must be
repaired.
CAUTION! Despite the use of a safe structure by design, the use of protective measures and additional protective
measures, there is always a residual risk of injury during work.
USE AND CARE FOR EQUIPMENT
 Do not overload the tool. Use a tool with the power appropriate for the work. Properly selected equipment will enable better
and safer work under the load for which it was designed.

15
 Store the unused equipment out of the reach of children. Do not allow people not familiar with the tool or this manual to use
the equipment. Internal combustion tools and equipment are dangerous in the hands of untrained users.
 Internal combustion tools must be maintained. Check alignment or jamming of moving parts, cracked parts and all other
factors that may affect the operation of the device. If damage is found, the equipment must be repaired before use. Many
accidents are caused by improper repair and / or maintenance of the equipment.
 Before using the device, replace all defective, worn and damaged parts. Replace with new warning signs on the device if
they become illegible or damaged.
 Warning decals and spare parts can be ordered from NAX service and authorized dealers.
 An internal combustion tool, equipment, working tools etc. should be used in accordance with these instructions, taking into
account the conditions and the type of work to be performed. Using the device in a manner not intended for it may be
dangerous.
OPERATION AND EXPLOITATION OF TOOLS EQUIPPED WITH A BATTERY
 Before inserting batteries into the tool, make sure that its on / off switch is in the "off" position. Inserting the batteries into the
device when the on / off switch is in the "on" position can cause serious injury.
 Use only the charger recommended by the manufacturer. Using a charger to charge other types of batteries may cause a
fire.
 Never use batteries other than those recommended by the manufacturer. Use of other batteries may result in serious injury
or fire.
 When the device is not in use, remove the battery. The battery should be kept away from metal objects such as paper clips,
coins, nails, screws, etc., which may short-circuit the battery terminals. Shorting the battery terminals together may cause
burns or a fire.
 Under extreme conditions, liquid may escape from the battery. You must avoid contact with it. If it accidentally it comes into
contact with liquid - rinse immediately with water. If liquid gets in your eyes, contact your doctor immediately. Liquids leaking
from the battery may cause irritation or burns.
 It is forbidden to use chargers and power supplies outside the rooms and in rooms with high humidity such as bathrooms or
basements.
CAUTION! Chargers and power supplies for battery devices are intended for indoor use in a dry environment.
Danger of electric shock and / or damage to the device.
REPAIR
 Before carrying out any adjustment, part replacement or storage, the spark plug wire must be removed. Such preventive
safety measures reduce the risk of accidental starting.
 Repair should be performed by a qualified person using only original spare parts. This will ensure further safe operation of
the device. It is recommended to have any service performed by an authorized NAX service center.
CAUTION! Danger of suffocation when children play with the packaging. The packaging, especially the foil bag, should be stored out
of the reach of children.
DETAILED SAFETY REGULATIONS FOR PETROL CHAINSAW
WARNING!
Observe all safety instructions, operation manual, descriptions and data supplied with the device. Failure to follow the
instructions below may pose a risk of serious injury.
Use a soft, dry cloth to clean the chain saw. Never use any detergent or alcohol.
Use personal protective equipment: safety glasses or goggles, protective gloves, protective footwear and protective clothing.
Wear ear protectors. Exposure to noise over a long period of time may result in hearing loss.
Regularly clean the equipment's ventilation slots. The engine blower draws dust into the housing, and large accumulation of
metal dust can cause electrical hazards.
You can only use the chain saw in good technical condition, perform the necessary actions if necessary or contact the
service center. It is recommended to use the services of an authorized NAX service.
Before starting, check if:
The device is assembled in accordance with the operating instructions;
The cutting tool is in good technical condition; regularly check chain attachment, damage and wear;

16
Safety devices (e.g. cutting unit cover, housing, handle, engine switch) are in good technical condition and work
properly;
Before adjustment, cleaning, maintenance, switch off the engine.
Do not use the device when other people, especially children or pets, are nearby.
Do not start a damaged chain saw.
Do not move the device with the engine running.
Turn the chain saw off when:
-you leave the equipment unattended,
-before adjustment,
-before checking, cleaning or repairing the device,
-after hitting with a foreign object,
-before you clean,
-in the event of abnormal vibrations.
PREPARATION
 Always wear solid footwear and long pants when working with the equipment, do not operate the device with bare feet or in
sandals.
 Check carefully the area where you will be working and remove all stones, branches, wires and other foreign objects
protruding from the ground that you might trip over during your work.
 In high grass, you may not notice obstacles (e.g. stumps, roots), so before starting work with the device, mark all obstacles
hidden in the grass that cannot be removed.
 Before use and after falling or other impacts, inspect the saw to identify any significant damage that may affect safety.
REMEMBER! Do not leave the chain saw uncontrolled. Never leave the chain saw turned on, as unintentional use may result, which
may result in accidents.
USEAGE
 Work only in daylight or in good artificial light.
 Do not work during rain, especially during a storm and in high humidity.
 Do not work in strong winds or other weather conditions that will cause the device to use a dangerous situation.
 It is important to have correct posture during work. In order not to bother excessively, frequent change of work position is
recommended.
 Stop work every 15 minutes - rest is necessary. Tiredness and distraction can contribute to an accident.
 Keep your feet steady and keep balance during work.
 When working on a slope, make sure your legs are standing firmly.
 Do not work too long because of the possibility of tingling or numbness in the fingers and hands. If such symptoms occur,
stop working.
 Attention! The device causes vibrations of the limbs during operation. The value of vibration acceleration is provided in the
table with rated data. Prolonged exposure of hands to vibration for several months or years, can cause the white toe
disease, i.e. a decrease in limb temperature caused by ischemia. Symptoms such as tingling, numbness, hypersensitivity to
cold should not be underestimated, see a doctor.
 Do not use the device with damaged covers or housings or without any protection.
 Start the saw engine as per the instructions.
 Check the chain saw brake for proper operation from time to time, as a malfunctioning brake may not disconnect the cutting
chain movement in an emergency.
 Refuel after switching off the engine and after it has cooled down, as there is a risk of spillage and ignition from hot parts of
the chain saw.
 Do not touch the chain saw with exposed body parts to avoid any possible burns.
 When working, hold the chain saw with both hands on the handles provided.
 Always adjust before cutting the chain brake lever by pulling it toward you. During operation, the safety brake is also a hand
guard.
 Move the chain saw away from the material to be cut only when the saw chain is running.
 When cutting processed sawn timber or thin limbs, use a special support (goat). It is not allowed to cut several boards at the
same time (stacked on top of each other) or materials held by a leg or held by another person.

17
 When cutting through, always use the buttress as a fulcrum. Holding the chainsaw by the main handle, guide it with the
auxiliary handle.
 If it is not possible to cut the material at once, pull the saw back slightly, move the buttress and continue cutting by slightly
raising the main handle of the saw.
 When cutting horizontally, position yourself so as to keep as vertical a position as possible.
 Use extreme caution if the chain is jammed. Then the so-called recoil directed towards the operator.
 To avoid dangerous situations, try to cut with the bottom of the guide where possible. In this case, any recoil would be
directed away from the operator's body.
 Be careful when cutting splitting wood, because cut pieces of wood can be thrown away in any direction with the risk of
injury.
 Pay particular attention to branches that are under tension, never cut branches hanging down from below.
 An uncontrolled fall of a felled branch or the whole tree may cause injury, while standing always stand on the side of the line
of the predicted fall direction of the tree to be felled.
 Remember that the direction of the cuts should in principle be opposite to the main direction of felling the tree. Before
cutting, determine the direction of the fall of the tree, for greater safety, tying a rope to be able to direct the falling trunk in the
right direction.
 A working chain saw tends to rotate when the top of the chain guide touches the workpiece. In this case, the chainsaw may
move uncontrollably towards the operator with the risk of injury.
 Be particularly careful at the end of cutting wood, because the saw without resistance in the form of cut material falls by the
force of inertia, which can cause injury.
 Do not use the chain saw above shoulder height or standing on a tree, ladder, scaffolding, stump, etc.
CAUTION! Despite the use of a safe structure by design, the use of protective measures and additional protective
measures, there is always a residual risk of injury during work.
Maintenance and storage
WARNING!
 Before attempting any repair or maintenance, make sure the chain saw engine has stopped and is cold. Disconnect the high
voltage cable from the spark plug to prevent accidental starting of the engine.
 Remember that there may be fuel in the machine's tank. Safety rules for handling fuel are described in this manual in the
section "Safety in handling fuel".
 Keep all nuts, bolts and screws in good condition to make sure that the device will work safely.
 After finishing work, clean the device of grass, dust and dirt
CAUTION! Always make sure that the device is turned off before performing any inspection or maintenance.
Use a fine brush, tuft, or cloth to clean the housing of the dust, you can clean the saw with compressed air.
Cleaning with a damp cloth is allowed, however, provided that the device is dried immediately after this operation. Metal parts must be
protected with oil.
Regularly clean the ventilation holes with compressed dry air. Do not insert sharp objects into the ventilation openings.
After finishing work, please:
 Wipe the ventilation holes and leave them free of dirt.
 Wipe the chain saw with a dry cloth.
CAUTION! Never use aggressive or corrosive cleaning detergents as they may damage the plastic parts of the device. It is
unacceptable to clean the saw with a water jet, water may damage the electric parts of the saw.
Cleaning agents and solvents such as gasoline, carbon tetrachloride, chlorinated cleaning solvents, ammonia and household
detergents that contain ammonia can damage plastic components.
CAUTION! The chain saw must be stored in a well-ventilated room in a dry, dust-free place. Only a functional device should
be stored; rectify faults before storage.
In the event of an accident, stop / turn off the machine immediately and call for help (if required).
In the event of a fault, stop / turn off the machine and contact an authorized service center to avoid the fault.

18
SAFETY AND PRODUCER'S LIABILITY
Any use of the chain saw, other than described in this manual is considered improper and the manufacturer is not liable for any
damage or damages resulting from such a procedure.
Proper use also includes respecting the operating, maintenance, storage and repair conditions established by the manufacturer.
To prevent accidents, all safety precautions and hazard avoidance must be followed. Any changes in the construction of the device
made by the user may affect the safety of use of the machine and release the manufacturer from liability for damage or injuries.
RESIDUAL RISK
Despite the fact that the machine manufacturer bears responsibility for its construction eliminating danger, certain elements of risk
during operation are unavoidable. The residual risk arises from the erroneous behavior of the machine's operator. The greatest danger
occurs when performing the following prohibited activities:
 use of the device by children,
 use of the machine for other purposes than described in the Operation Manual,
 when other people, especially children or animals are nearby,
 use of the device by people not acquainted with the operation's manual,
 using the device without proper, protecting operating clothing and footwear protecting foot,
 using the device with damaged guards or the casing and without properly installed safety devices, e.g. shield guards etc.
When observing the instructions in the operating manual, the residual hazards of using the machine may be eliminated. There is a risk
in case of failure to comply with the above recommendations.
USAGE
The device is intended only for work in the home garden in accordance with the description and safety rules contained in these
operation manual. It can be used for cutting trees, cutting branches, preparing firewood and for other applications that require pruning.
Other applications may be dangerous to users and may cause damage to the equipment.
The device should not be used to:
 cutting materials other than wood and wood-based materials,
 as a lever for lifting, moving or dividing objects.
ADDITIONAL INFORMATION FOR THE USER
Performing maintenance and adjustment work before or after the season can be a problem even for advanced users. The NAX
company would like to offer you a service consisting in preparing the machine for storage and / or work. The scope of this service may
include: candle replacement, cleaning, maintenance, oil change, filter replacement and lubrication of moving parts, knife sharpening
and balancing, as well as other work related to the adjustment and maintenance of equipment. This will ensure long-term and reliable
operation and safety of the device.
PREPARING FOR WORK
The saw is supplied by the manufacturer in a cardboard packaging in a partially disassembled state. After reading the operating
instructions and assembly drawings, assembling the chain saw should not be too difficult. All necessary components for assembly are
included in the packaging.
WARNING! The chain has very sharp edges. Use thick protective gloves for safety.
 Stay away from the saw chain as it will start to rotate when the engine starts.
 The handles should be dry, clean and free from oil or the fuel mixture.

19
 Use extreme caution when cutting small branches and trees, as thin material can get stuck in the saw chain and hit the
operator or throw him off balance.
 When cutting stressed boughs, be careful not to be hit when the stress in the wood fibers is reduced.
 Check the tree for dry branches that may fall during felling operations.
 Always stop the engine before putting the saw down.
CONSTRUCTION OF PETROL SAW
Illustrative drawings can be found on page 4, Fig. 1
1. Speed brake lever.
2. Auxiliary handle
3. Starter handle with cable
4. Air filter cover
5. Choke control
6. Gas control lever lock
7. Main handle
8. Gas control handle
9. Switch
10. Fuel-filler cap
11. Oil filler cap
12. Guide lubrication points
13. Chain
14. Guide
15. Buttress
16. Muffler
17. Suction pump
18. Ear hanger
INSTALLING THE GUIDE
To mount the guide:
Remove the drive transmission cover 1 (Fig. 2) by unscrewing the nuts 2 (Fig. 2).
Mount the buttress 2 (Fig. 3) using the screws supplied.
Put the guide on the pins shown in the picture 1 (Fig. 3).
FITTING THE CHAIN
To put the chain on the guide bar:
Bring close the guide bar 3 (Fig. 4) to the drive wheel 1 (Fig. 4).
Install the chain 2 (Fig. 4) remembering the chain's operation direction. The direction is indicated by arrows on the guide bar,
on the chain and the machine body.
CAUTION! When installing the chain, remember to put it correctly on the drive wheel and then on the guide bar.
INSTALLING THE TRANSMISSION GUARD
To attach the cover:
Check that the emergency brake is applied, otherwise it will not be put on
Remember that the chain tensioning point 1 (Fig. 5) was on the pin in the cover.
TENSIONING THE CHAIN
Before starting work, stretch the chain. To do this, use the chain tensioning screw.
To tighten the chain, loosen the drive case housing nuts 2 (Fig. 6) check that the chain is in the guide groove of the guide bar and
use a screwdriver to turn the adjustment screw 1 (Fig. 7) until the chain is properly tensioned. A correctly tensioned chain can be lifted
in the middle of the guide bar to a height of about 3-4 mm. Correctly tighten the guide fastening nuts.
CAUTION! When working with a chainsaw, the cutting chain lengthens as a result of heating. Check and adjust the tension frequently,
as a loose chain can easily fall off the rail or wear quickly and damage the bar.

20
SYMBOLS ON THE DEVICE
Symbols are placed on the device for safe operation and maintenance.
Use these guidelines to be careful not to make a mistake.
Designations of the symbols. (Fig. 8)
1. Hole for refilling the fuel mixture. Place: fuel tank housing Fig. 1, point 10.
2. Hole for topping up oil to the chain. Place: fuel tank housing Fig. 1, point 11.
3. Switch tip. When the engine switch is moved towards "O" (STOP), the engine goes out.
Place: the rear part of the device on the left Fig. 1, point 9.
4. Choke tip. When the choke lever is pulled out, choke is activated.
5. Note on the amount of oil to lubricate the chain:
"MIN" direction - reducing oil quantity
"MAX" direction - increasing the amount of oil. Place: the bottom of the saw.
6. Carburetor adjustment indicator:
"H" indicator position
Position of indicator "L"
Idle adjustment screw position "T"
7. Chain brake:
Left arrow - brake released
Right arrow - brake turned on
FILLING THE FUEL TANK
Fill the fuel tank before the first start-up.
When filling with fuel, observe the following rules:
the engine cannot operate,
the engine cannot be hot,
Do not allow fuel to spill.
Mix the filtered 95 octane unleaded gasoline with good quality engine oil - synthetic or semi-synthetic, designed for air-cooled 2-stroke
engines well, and fill the fuel tank. We recommend Briggs & Stratton two stroke oil. To refuel the saw tank:
unscrew the fuel filler cap 10 (Fig. 1),
pour previously prepared fuel mixture (max 230 ml),
screw the fuel filler cap 10 (Fig. 1).
CAUTION! Most engine problems are caused, directly or indirectly, by the low quality of fuel used in the device. The use of
Mixol oil and its derivatives as well as oil for 4-stroke engines is prohibited.
Recommended mix ratio: 40: 1
Table for a 40: 1 mix
The amount of gasoline in liters
1
2
3
4
5
The amount of oil in ml
25
50
75
100
125
CAUTION! It is forbidden to use other suggestions of the mixture under the threat of loss of warranty.
CHAIN LUBRILAC
The new chainsaw has an empty oil tank, so fill the tank with oil before using it for the first time. To do this:
unscrew the fuel filler cap 11 (Fig. 1),
pour max. 160 ml (be careful not to get any dirt inside the tank when filling it),
screw the fuel filler cap 11 (Fig. 1).
For chain lubrication, it is best to use a guide and chain preparation or a special NAX chain lubricant.
