Briggs & Stratton SnapperPRO S800X Series User manual

This manual is available in Spanish. For a copy, contact your Snapper Pro dealer or www.snapperpro.com.
Este manual está disponible en Español. Para obtener una copia, póngase en contacto con
su distribuidor Snapper Pro o www.snapperpro.com.
BRIGGS & STRATTON POWER PRODUCTS GROUP, LLC
5375 NORTH MAIN STREET
MUNNSVILLE, NY 13409
800 933 6175
5102673
Rev H
Tractor
Model Number Description
5900659 S800XY30D
Mower Deck
5900656 S800X/61
5900875 S800X/72
Operator’s Manual
S800X Series
Zero-Turn Riding Mower

Thank you for purchasing this quality-built Snapper
Pro product. We’re pleased that you’ve placed your
confidence in the Snapper Pro brand. When operated
and maintained according to the instructions in this
manual, your Snapper Pro product will provide many
years of dependable service.
This manual contains safety information to make
you aware of the hazards and risks associated with
this machine and how to avoid them. This machine
is designed and intended to be used and maintained
according to the manual and operated by trained
professionals for finish cutting of established lawns and
is not intended for any other purpose. It is important that
you read and understand these instructions thoroughly
before attempting to start or operate this equipment.
Save these original instructions for future reference.
The images in this document are representative, and
are meant to compliment the instructional copy they
accompany. Your unit may vary from the images
displayed. LEFT and RIGHT are as seen from the
operator’s position.
The Illustrated Parts List for this machine can be
downloaded from snapperpro.com. Please provide model
and serial number when ordering replacement parts.
Briggs & Stratton Power Products Group, LLC.
Copyright © 2015 Briggs & Stratton Corporation
Milwaukee, WI, USA. All rights reserved.
SNAPPER PRO is a trademark of Briggs & Stratton
Corporation, LLC. Milwaukee, WI, USA.
Contact Information:
Briggs & Stratton Power Products Group, LLC.
5375 N. Main St.
Munnsville, NY 13409-4003
[phone]
www.SnapperPro.com
WARNING
Battery posts, terminals, and related accessories
contain lead and lead compounds – chemicals
known to the State of California to cause cancer and
reproductive harm. Wash hands after handling.
WARNING
The engine exhaust from this product contains
chemicals known to the State of California to cause
cancer, birth defects, or other reproductive harm.
Product Reference Data:
PRODUCT REFERENCE DATA
Unit Model Number Unit SERIAL Number
Mower Deck Model Number Mower Deck SERIAL Number
Dealer Name Date Purchased
ENGINE REFERENCE DATA
Engine Make Engine Model
Engine Type/Spec Engine Code/Serial Number
See Features and Controls for the location of
Identification Numbers

1
Table of Contents
Operator Safety ...........................................................2
Safety Rules and Information ..................................2
Safety Decals........................................................11
Safety Interlock System.........................................12
Safety Icons ..........................................................13
Features & Controls................................................. 13
Identification Numbers ..........................................13
Control Functions - Tractor ...................................14
Control Functions - Instrument Control Panel .......15
Operation .................................................................. 16
General .................................................................16
Checks Before Starting .........................................17
Seat Adjustment....................................................17
Check Tire Pressures............................................18
Mowing Height Adjustment ...................................18
Priming the Fuel System .......................................19
Check Engine Coolant ..........................................20
Change Engine Coolant ........................................20
Clean Radiator & Screens.....................................20
Starting The Engine...............................................21
Stopping The Mower.............................................21
Safety Interlock & Mower Deck
Positioning Instructions .........................................21
Zero-Turn Driving Practice ....................................22
Mowing..................................................................24
Mowing Recommendations...................................24
Mowing Methods...................................................25
Pushing the Rider by Hand ...................................26
Raise and Lower the Roll Bar................................27
Attachment Removal and Installation
Procedure..............................................................28
Regular Maintenance............................................... 30
Maintenance Schedule .........................................30
Checking/Adding Fuel...........................................31
Fuel Filter ..............................................................32
Check / Add Engine Oil Level ...............................33
Change Engine Oil & Filter....................................33
Service Air Filter....................................................33
Engine Maintenance .............................................33
Lubrication ............................................................34
Servicing the Mower Blades..................................36
Check Hydraulic Oil Level.....................................38
Change Hydraulic Oil Filter ...................................38
Ground Speed Control Lever Adjustment .............39
Speed Balancing Adjustment................................39
Neutral Adjustment................................................40
Return-to-Neutral Adjustment ...............................41
Parking Brake Adjustment.....................................41
Deck Lift Rod Timing Adjustment..........................42
Deck Leveling Adjustment.....................................43
PTO Clutch Belt Replacement ..............................44
Hydraulic Pump Drive Belt Replacement ..............45
Mower Belt Replacement......................................46
Gearbox Maintenance...........................................47
Fuse Locations......................................................48
Fault Diagnosis Lamps..........................................49
Cleaning the Battery and Cables...........................50
Removing the Battery............................................50
Re-installing the Battery ........................................50
Battery Service......................................................51
Storage..................................................................53
Starting After Long Term Storage .........................53
Troubleshooting....................................................... 54
Troubleshooting the Rider.....................................54
Troubleshooting the Mower...................................55
Troubleshooting Common Cutting Problems ........56
Specifications........................................................... 57
Slope Identification Guide....................................... 58
NOTE: In this manual, “left” and “right” are referred to as
seen from the operating position.

2
Operator Safety
Operating Safety
Congratulations on purchasing a superior-quality piece of
lawn and garden equipment. Our products are designed and
manufactured to meet or exceed all industry standards for safety.
Do not operate this machine unless you have been trained.
Reading and understanding this operator’s manual is a way to
train yourself.
Power equipment is only as safe as the operator. If it is misused,
or not properly maintained, it can be dangerous! Remember, you
are responsible for your safety and that of those around you.
Use common sense, and think through what you are doing. If
you are not sure that the task you are about to perform can be
safely done with the equipment you have chosen, ask a
professional: contact your local authorized dealer.
Read the Manual
The operator’s manual contains important safety
information you need to be aware of BEFORE you
operate your unit as well as DURING operation.
Safe operating techniques, an explanation of the
product’s features and controls, and maintenance
information is included to help you get the most out of
your equipment investment.
Be sure to completely read the Safety Rules and
Information found on the following pages. Also
completely read the Operation section.
Children
Tragic accidents can occur with children. Do
not allow them anywhere near the area of
operation. Children are often attracted to the
unit and mowing activity. Never assume that
children will remain where you last saw them.
If there is a risk that children may enter the
area where you are mowing, have another
responsible adult watch them.

3
Operator Safety
Slope Operation
Operation on slopes can be dangerous. Using the unit on a slope
that is too steep where you do not have adequate wheel traction
(and control) can cause sliding, loss of steering, control, and
possible rollover. You should not operate on a slope greater than
a 5.4 foot rise over a 20 foot length (15 degrees).
Always mow across slopes, not up and down (to maintain traction
on the wheels) and avoid sudden turns or rapid speed changes.
Reduce speed and use extreme caution on ALL slopes.
Also, note that the surface condition you are on can greatly impact
your ability to safely operate this machine. Operating on wet or
slippery slopes can cause sliding and loss of steering and control.
Do not operate on slopes that are slippery, wet, or have soft soil
conditions.
If you feel unsure about operating the unit on a slope, don’t do it.
It’s not worth the risk.
Thrown Objects
This unit has spinning mower blades. These blades can pick up and
throw debris that could seriously injure a bystander. Be sure to clean
up the area to be mowed and remove objects that could be thrown by
the blade BEFORE you start mowing.
Do not operate this unit without the entire grass catcher or discharge
guard (deflector) in place.
Also, do not allow anyone in the area while the unit is running! If
someone does enter the area, shut the unit off immediately until they
leave.
Moving Parts
This equipment has many moving parts that can injure
you or someone else. However, if you stay in the
operator zone (stay seated in the seat), and follow the
safety rules in this operator’s manual, the unit is safe to
operate.
The mower deck has spinning mower blades that can
amputate hands and feet. Do not allow anyone near the
unit while it is running! Keep safety devices (guards,
shields, and switches) in place and working.
To help you, the operator, use this equipment safely, it
is equipped with an operator-present safety system. Do
NOT attempt to alter or bypass the system. See your
dealer immediately if the system does not pass all the
safety interlock system tests found in this manual.

4
Roll Bar Use
Keep the roll bar in the raised position and fasten the
seat belt. There is no roll over protection when the
roll bar is down! Do not jump off if the mower tips (it
is safer to be secured by the seat belt with the roll bar
raised.)
Lower the roll bar only when necessary (such as to
temporarily clear a low overhanging obstacle) and
NEVER remove it. Do NOT use the seat belt when
the roll bar is down. Raise the roll bar as soon as
clearance permits.
Retaining Walls, Drop-
offs, and Water
Retaining walls and drop-offs around steps and
water are a common hazard. Give yourself a
minimum of two mower widths of clearance
around these hazards and hand-trim with a
walk behind mower or string trimmer. Wheels
dropping over retaining walls, edges, ditches,
embankments, or into water can cause rollovers,
which may result in serious injury, death, or
drowning.
Overhead Obstacles
Check for overhead clearances before driving
under any objects. Do not allow the roll bar to
contact low overhanging obstacles such as tree
branches and guide wires.
Operator Safety

5
Operator Safety
Enclosed Areas
Only operate this unit outdoors and
away from unventilated areas such as
inside garages or enclosed trailers.
The engine emits poisonous carbon
monoxide gas and prolonged exposure
in an enclosed area can result in
serious injury or death.
Fuel and Maintenance
Always disengage all drives, shutoff the engine, and
remove the key before doing any cleaning, refueling, or
servicing.
Gasoline and its vapors are extremely flammable. Do not
smoke while operating or refueling. Do not add fuel while
engine is hot or running. Allow engine to cool for at least
3 minutes prior to adding fuel.
Do not add fuel indoors, in an enclosed trailer, garage,
or any other enclosed area that is not well ventilated.
Gasoline spills should be cleaned up promptly and before
operation begins.
Gasoline should be stored only in sealed containers
approved for fuel.
Proper maintenance is critical to the safety and
performance of your unit. Keep the unit free of
grass, leaves, and excess oil. Be sure to perform the
maintenance procedures listed in this manual, especially
periodically testing the safety system.

6
2. Mow only in the daylight or with good artificial
light, keeping away from holes and hidden
hazards.
3. Be sure all drives are in neutral and parking brake
is engaged before starting engine. Only start
engine from the operator’s position. Use seat
belts if provided.
4. Be sure of your footing while using pedestrian
controlled equipment, especially when backing up.
Walk, don’t run. Reduced footing could cause
slipping.
5. Slow down and use extra care on hillsides. Be
sure to travel in the recommended direction on
hillsides. Turf conditions can affect the machines
stability. Use caution when operating near drop-
offs.
6. Do not mow in reverse unless absolutely
necessary. Always look down and behind before
and while traveling in reverse.
7. Be aware of the mower discharge direction and do
not point it at anyone. Do not operate the mower
without either the entire grass catcher or the
deflector in place.
8. Slow down and use caution when making turns
and when changing directions on slopes.
9. Never raise deck with the blades running.
10. Never leave a running unit unattended. Always
disengage the PTO, set parking brake, stop
engine, and remove keys before dismounting.
Keep hands and feet away from the cutting units.
11. Turn off the PTO switch to disengage the blades
when not mowing.
12. Never operate with guards not securely in place.
Be sure all interlocks are attached, adjusted
properly and functioning properly.
13. Never operate with the discharge deflector raised,
removed or altered, unless using a grass catcher.
14. Do not change the engine governor setting or
overspeed the engine.
15. Stop on level ground, lower implements,
disengage drives, engage parking brake, shut off
engine before leaving the operator’s position for
any reason including emptying the grass catchers
or unclogging the chute.
16. Stop equipment and inspect blades after striking
objects or abnormal vibration occurs. Make
necessary repairs before resuming operations.
17. Keep hands and feet away from the cutting units.
18. Look behind and down before backing up to be
sure of a clear path.
19. Never carry passengers and keep pets and
bystanders away.
20. Do not operate the unit while under the influence
of alcohol or drugs.
21. Slow down and use caution when making turns
and crossing roads and sidewalks. Stop blades if
not mowing.
22. Use care when loading or unloading the machine
into a trailer or truck.
TRAINING
1. Read, understand, and follow all instructions in
the manual and on the unit before starting. If the
operator(s) or mechanic(s) can not read English
it is the owner’s responsibility to explain this
material to them.
2. Become familiar with the safe operation of the
equipment, operator controls, and safety signs.
3. All operators and mechanics should be trained.
The owner is responsible for training the users.
4. Only allow responsible adults, who are familiar
with the instructions, to operate the unit.
5. Never let children or untrained people operate
or service the equipment. Local regulations may
restrict the age of the operator.
6. The owner/user can prevent and is responsible
for accidents or injuries occurring to themselves,
other people or property.
7. Data indicates that operators, age 60 years and
above, are involved in a large percentage of riding
mower-related injuries. These operators should
evaluate their ability to operate the riding mower
safely enough to protect themselves and others
from serious injury.
PREPARATION
1. Evaluate the terrain to determine what
accessories and attachments are needed to
properly and safely perform the job. Use only
accessories and attachments approved by the
manufacturer.
2. Wear appropriate clothing including safety shoes,
safety glasses and ear protection. Long hair,
loose clothing or jewelry may get tangled in
moving parts.
3. Inspect the area where the equipment is to be
used and remove all objects such as rocks, toys
and wire, which can be thrown by the machine.
4. Use extra care when handling gasoline and
other fuels. They are flammable and vapors are
explosive.
a) Use only an approved container.
b) Never remove fuel cap or add fuel with the
engine running. Allow engine to cool before
refueling. Do not smoke.
c) Never refuel or drain the machine indoors.
5. Check that operator’s presence controls, safety
switches and shields are attached and functioning
properly. Do not operate unless they are
functioning properly.
OPERATION
1. Never run an engine in an enclosed area.
Read these safety rules and follow them closely. Failure to obey these rules could result in loss
of control of unit, severe personal injury or death to you, or bystanders, or damage to property or
equipment. This mowing deck is capable of amputating hands and feet and throwing objects.
The triangle in text signifies important cautions or warnings which must be followed.
Operator Safety

7
Operator Safety
23. Use care when approaching blind corners, shrubs,
trees or other objects that may obscure vision.
24. To reduce fire hazard, keep unit free of grass,
leaves & excess oil. Do not stop or park over dry
leaves, grass or combustible materials.
25. OSHA regulations may require the use of hearing
protection when exposed to sound levels greater
than 85 dBA for an 8 hour time period.
SLOPE OPERATION
Slopes are a major factor related to loss-of-control and
tip-over accidents, which can result in severe injury or
death. All slopes require extra caution. If you cannot
back up the slope or if you feel uneasy on it, do not
drive on it.
Do
1. Mow across slopes, not up and down.
2. Remove obstacles such as rocks, tree limbs, etc.
3. Watch for holes, ruts, or bumps. Uneven terrain
could overturn the unit. Tall grass can hide
obstacles.
4. Use slow speed. Choose a slow speed so that
you will not have to stop or change speed while
on the slope.
5. Use extra care with grass catchers or other
attachments. These can change the stability of
the unit.
6. Keep all movement on the slopes slow and
gradual. Do not make sudden changes in speed
or direction.
7. See your authorized dealer for recommendations
of available weights to improve stability.
Do Not
1. Avoid starting, stopping, or turning on a slope.
If tires lose traction (i.e. machine stops forward
motion on a slope), disengage the blade(s) (PTO)
and drive slow off the slope.
2. Do not turn on slopes unless necessary, and then,
turn slowly and gradually uphill, if possible. Never
mow down slopes.
3. Do not mow near drop-offs, ditches, or
embankments. The operator could lose footing or
balance or mower could suddenly turn over if a
wheel is over the edge of a cliff or ditch, or if an
edge caves in.
4. Do not mow on wet grass. Reduced footing or
traction could cause sliding.
5. Do not try to stabilize the unit by putting your foot
on the ground. (ride-on units)
6. Do not mow excessively steep slopes.
7. Do not use grass catcher on steep slopes.
8. Do not mow slopes if you cannot back up them.
TOWED EQUIPMENT (RIDE-ON UNITS)
1. Tow only with a machine that has a hitch designed
for towing. Do not attach towed equipment except
at the hitch point.
2. Follow the manufacturer’s recommendations
for weight limit for towed equipment and
towing on slopes. See attaching a trailer under
OPERATION.
3. Never allow children or others in or on towed
equipment.
4. On slopes, the weight of the towed equipment
may cause loss of traction and loss of control.
5. Travel slowly and allow extra distance to stop.
6. Do not shift to neutral and coast down hill.
CHILDREN
Tragic accidents can occur if the operator is not alert to
the presence of children. Children are often attracted
to the unit and the mowing activity. Never assume that
children will remain where you last saw them.
1. Keep children out of the mowing area and under
the watchful care of another responsible adult.
2. Be alert and turn unit off if children enter the area.
3. Before and during reverse operation, look behind
and down for small children.
4. Never carry children, even with the blade(s) off.
They may fall off and be seriously injured or
interfere with safe unit operation. Children who
have been given rides in the past may suddenly
appear in the mowing area for another ride and be
run over or backed over by the machine.
5. Never allow children to operate the unit.
6. Use extra care when approaching blind corners,
shrubs, trees, or other objects that may obscure
vision.
CAUTION
This machine produces sound levels
in excess of 85 dBA at the operator’s
ear and can cause hearing loss
though extended periods of exposure.
Wear hearing protection when operating this
machine.
WARNING
Do not use this machine on slopes greater than
15°.*
Select slow ground speed before driving onto
slope. Use extra caution when operating on
slopes with rear-mounted grass catchers.
Mow across the face of slopes, not up and
down, use caution when changing directions
and DO NOT START OR STOP ON SLOPE.
*This limit was determined per CEN Standard EN 836:1997, Section
5.2.2 and is based on the EN 836 Stability Test procedure described in
Section 4.2.4.2. The 15 degree “limit of stability” is equal to 50% of the
angle at which machine lift-off occurred in static tests. Actual dynamic
stability may vary depending on operating conditions.
WARNING
It is a violation of California Public Resource
Code, Section 4442, to use or operate the
engine on any forest-covered, brush-covered
or grass-covered land unless the exhaust
system is equipped with a spark arrester,
as defined in Section 4442, maintained in
effective working order. Other states or federal
jurisdictions may have similar laws. Contact
an Authorized Service Dealer to obtain a spark
arrester designed for the exhaust system
installed on this engine.

8
Operator Safety
EMISSIONS
1. Engine exhaust from this product contains
chemicals known, in certain quantities, to cause
cancer, birth defects, or other reproductive harm.
2. Look for the relevant Emissions Durability Period
and Air Index information on the engine emissions
label.
IGNITION SYSTEM (GASOLINE MODELS)
1. This spark ignition system complies with Canadian
ICES-002.
SERVICE AND MAINTENANCE
To avoid personal injury or property damage, use
extreme care in handling gasoline. Gasoline is
extremely flammable and the vapors are explosive.
Safe Handling of Gasoline
1. Extinguish all cigarettes, cigars, pipes, and other
sources of ignition.
2. Use only approved gasoline containers.
3. Never remove the gas cap or add fuel with the
engine running. Allow the engine to cool before
refueling.
4. Never fuel the machine indoors.
5. Never store the machine or fuel container where
there is an open flame, spark, or pilot light such
as near a water heater or other appliance.
6. Never fill containers inside a vehicle or on a
truck bed with a plastic bed liner. Always place
containers on the ground away from your vehicle
before filling.
7. Remove gas-powered equipment from the truck
or trailer and refuel it on the ground. If this is not
possible, then refuel such equipment on a trailer
with a portable container, rather than from a
gasoline dispenser nozzle.
8. Keep nozzle in contact with the rim of the fuel tank
or container opening at all times until fueling is
complete. Do not use a nozzle lock-open device.
9. If fuel is spilled on clothing, change clothing
immediately.
10. Never over-fill the fuel tank. Replace gas cap and
tighten securely.
11. Use extra care in handling gasoline and other
fuels. They are flammable and vapors are
explosive.
12. If fuel is spilled, do not attempt to start the engine
but move the machine away from the area of
spillage and avoid creating any source of ignition
until fuel vapors have dissipated.
13. Replace all fuel tank caps and fuel container caps
securely.
Maintenance and Storage
1. Always observe safe refueling and fuel
handling practices when refueling the unit after
transportation or storage.
2. Always follow the engine manual instructions for
storage preparations before storing the unit for
both short and long term periods.
3. Always follow the engine manual instructions for
proper start-up procedures when returning the unit
to service.
4. Never store the machine or fuel container inside
where there is an open flame, such as in a water
heater. Allow unit to cool before storing.
5. Shut off fuel while storing or transporting. Do not
store fuel near flames or drain indoors.
6. Keep all hardware, especially blade attachment
bolts, tight and keep all parts in good working
condition. Replace all worn or damaged decals.
7. Never tamper with safety devices. Check their
proper operation regularly.
8. Disengage drives, lower implement, set parking
brake, stop engine and remove key or disconnect
spark plug wire. Wait for all movement to stop
before adjusting, cleaning or repairing.
9. Clean grass and debris from cutting units, drives,
mufflers, and engine to prevent fires. Clean up oil
or fuel spillage.
10. Let engine cool before storing and do not store
near flame.
11. Stop and inspect the equipment if you strike an
object. Repair, if necessary, before restarting.
12. Park machine on level ground. Never allow
untrained personnel to service machine.
13. Use jack stands to support components when
required.
14. Carefully release pressure from components with
stored energy.
15. Disconnect battery or remove spark plug wire
before making any repairs. Disconnect the
negative terminal first and the positive last.
Reconnect positive first and negative last.
16. Use care when checking blades. Wrap the
blade(s) or wear gloves, and use caution when
servicing them. Only replace blades. Never
straighten or weld them.
17. Keep hands and feet away from moving parts.
If possible, do not make adjustments with the
engine running.
18. Charge batteries in an open well ventilated area,
away from spark and flames. Unplug charger
before connecting or disconnecting from battery.
Wear protective clothes and use insulated tools.
19. Grass catcher components are subject to wear,
damage, and deterioration, which could expose
moving parts or allow objects to be thrown.
Frequently check components and replace
with manufacturer’s recommended parts, when
necessary.
20. Check brake operation frequently. Adjust and
service as required.
21. Use only factory authorized replacement parts
when making repairs.
22. Always comply with factory specifications on all
settings and adjustments.
23. Only authorized service locations should be
utilized for major service and repair requirements.
24. Never attempt to make major repairs on this unit
unless you have been properly trained. Improper
service procedures can result in hazardous
operation, equipment damage and voiding of
manufacturer’s warranty.
25. Units with hydraulic pumps, hoses, or motors:
WARNING: Hydraulic fluid escaping under
pressure may have sufficient force to penetrate
skin and cause serious injury. If foreign fluid is
injected into the skin it must be surgically removed
within a few hours by a doctor familiar with this
form of injury or gangrene may result. Keep body
and hands away from pin holes or nozzles that
eject hydraulic fluid under high pressure. Use
paper or cardboard, and not hands, to search for

9
Operator Safety
ROLL BAR INSTRUCTIONS
For models equipped with factory-installed Roll Over
Protection System (ROPS).
OPERATIONAL WARNINGS
• Always use the seat belt when the roll bar is in the
raised position.
• Never use the seat belt when the roll bar is in the
down position.
• Remember there is no roll over protection when
the roll bar is in the down position so it is very
important to always keep the roll bar in the raised
position whenever possible.
• Lower the roll bar to the down position only when
it is absolutely necessary.
• Check for overhead clearances before driving
under any objects. Do not allow roll bar to contact
low overhanging obstacles such as tree branches
and guide wires.
• Never remove the roll bar from the vehicle.
• Do not exceed the machine weight rating of the
roll bar.
• Read and follow all of the instructions shown
below regarding the inspection and maintenance
of the roll bar structure and the seat belt.
INSPECTION OF THE ROLL BAR PROTECTIVE
STRUCTURE
A ROLL BAR, like any other safety device, needs to
be periodically inspected to verify that the integrity of
the device has not been compromised through normal
machine use, misuse, age degradation, modifications,
or a roll over.
WARNING
In order to avoid serious injury or death from
roll over, it is important to follow the warnings
listed below.
WARNING
Failure to properly inspect and maintain the
ROLL BAR protective structure can cause
serious injury or death.
To maintain operator roll over protection and roll bar
effectiveness:
• If a ROLL BAR becomes damaged for any reason,
such as a collision, roll over or impact, the ROLL
BAR must be replaced. Small undetectable
cracks can reduce the effectiveness of the ROLL
BAR. Never weld, straighten, or repair the ROLL
BAR.
• Never alter the ROLL BAR by welding anything to
it or by drilling additional holes.
• BEFORE FIRST TIME USE - Inspect the ROLL
BAR structure and mounting hardware for:
1) Check to make sure the machine GVW (Gross
Vehicle Weight), including attachments,
restrained payload, fuel and operator, is not
in excess of the maximum weight specified on
the ROLL BAR label.
2) Make sure there isn’t any missing, damaged,
or loose mounting hardware.
3) Make sure the ROLL BAR has been correctly
and completely installed.
• EVERY 100 HOURS - Inspect the ROLL BAR
structure and mounting hardware for:
1) Any cracks in the structure (structural members
and/or welds).
2) Significant corrosion on any part of the ROLL
BAR structure or hardware.
3) Missing, damaged, or loose mounting
hardware
4) Mounting hardware that is of a grade lesser
than specified.
5) Machine GVW (Gross Vehicle Weight),
including attachments, restrained payload,
fuel and operator, in excess of the maximum
weight specified on the ROLL BAR label.
6) Any modifications that have been made, such
as unauthorized welds and holes.
7) Any permanent deformation or twisting of the
ROLL BAR structure.
8) That the ROLL BAR label is still in place and is
readable.
9) That the ROLL BAR on-product warning labels
are still on the ROLL BAR and are readable.
• If there is any doubt as to the condition of the
ROLL BAR, remove the machine from service and
contact your dealer for assistance.
leaks. Make sure all hydraulic fluid connections
are tight and all hydraulic hoses and lines are in
good condition before applying pressure to the
system. If leaks occur, have the unit serviced
immediately by your authorized dealer.
26. WARNING: Stored energy device. Improper
release of springs can result in serious personal
injury. Springs should be removed by an
authorized technician.
27. Models equipped with an engine radiator:
WARNING: Stored energy device. To prevent
serious bodily injury from hot coolant or steam
blow-out, never attempt to remove the radiator
cap while the engine is running. Stop the engine
and wait until it is cool. Even then, use extreme
care when removing the cap.

10
INSPECT BUCKLE
& LATCH
INSPECT WEBBING
Operator Safety
WARNING
Failure to properly inspect and maintain the
seat belt can cause serious injury or death.
INSPECTION AND MAINTENANCE OF
THE ROLL BAR SEAT BELT
• The seat belt like the ROLL BAR, needs to
be periodically inspected to verify that the
integrity has not been compromised through
normal machine use, misuse, age degradation,
modifications, or a roll over. If the seat belt does
not pass all of the following tests, it should be
replaced.
• BEFORE EACH USE – Conduct the following
inspections/maintenance of the seat belt and
retraction mechanism:
1) Check for dirt or debris in the retraction
mechanism. If dirt or debris is found, it should
be removed.
2) Check to make sure the retraction mechanism
retracts easily and completely.
3) Check for damage to any part of the seat belt
such as nicks, cuts, loose stitching, or fraying.
4) Check that the buckle and latch operate
properly and that the latch plate is not
excessively worn, deformed, or the buckle is
damaged or cracked. The seat belt should
latch and release easily.

11
Operator Safety
Safety Decals
Before operating your unit, read the safety decals. The
cautions and warnings are for your safety. To avoid a
personal injury or damage to the unit, understand and follow
all safety decals.
DANGER
Amputation and thrown objects hazard
Keep hands and feet
away from deck.
Do not operate mower
unless discharge chute
or entire grass catcher
is in its proper place.
7101665
15° Max.
A
BC
DE
F
A
C
B
F
D
E*
C
E*
B
G
G
H
WARNING
If any safety decals become worn or damaged, and cannot
be read, order replacement decals from your local dealer.
* This decal is located behind the ROPS on the frame of
the unit.
H
H

12 www.SnapperPro.com
Operator Safety
Safety Alert Symbol & Signal Words
The alert symbol ( ) is used to identity safety information
about hazards that can result in personal injury. A signal
word (DANGER, WARNING, or CAUTION) is used with the
alert symbol to indicate the likelihood and the potential
severity of the injury. In addition, a hazard icon may be
used to represent the type of hazard. An explanation of
hazard levels and icons are as follows:
DANGER
This indicates a hazard which, if not avoided, will result in
serious injury or death.
WARNING
This indicates a hazard which, if not avoided, could result
in serious injury or death.
CAUTION
This indicates a hazard which, if not avoided, might result
in serious injury or death.
NOTICE
This message presented without the alert symbol indicates
a situation where the unit or property could be damaged.
Safety Interlock System
This unit is equipped with safety interlock switches. These
safety systems are present for your safety, do not attempt
to bypass safety switches, and never tamper with safety
devices. Check their operation regularly.
Operational SAFETY Checks
Test 1 — Engine should NOT crank if:
• PTO switch is engaged, OR
• Parking brake is not engaged, OR
• Ground speed control levers are not in the NEUTRAL
position, OR
Test 2 — Engine SHOULD crank if:
• PTO switch is NOT engaged, AND
• Parking brake is engaged, AND
• Ground speed control levers are locked in the NEUTRAL
position, AND
Test 3 — Engine should SHUT OFF if:
• Operator rises off the seat with the PTO engaged, OR
• Operator rises off the seat with the parking brake
disengaged.
• Operator moves the ground speed control levers out of
their NEUTRAL positions before disengaging the parking
brake.
• Operator moves the ground speed control levers out of
the NEUTRAL position be positioning the mower deck in
the operating position.
Test 4 — PTO SHOULD shut off if:
• Operator raises the deck from the operating position
with the PTO engaged.
Test 5 — PTO should NOT engage if:
• Operator engages the PTO before the mower deck is in
the operating position.
Test 6 — Blade Brake Check
Mower blades and mower drive belt should come to a
complete stop within seven (7) seconds after electric PTO
switch is turned off (or operator raises from the seat). If
mower drive belt does not stop within seven (7) seconds,
see your dealer.
NOTE: Once the engine has stopped, the PTO switch must
be turned off, parking brake must be engaged, the ground
speed control levers must be locked in the NEUTRAL
position, after the operator returns to the seat to start the
engine.
WARNING
If the unit does not pass a safety test, do NOT operate
it. See your authorized dealer. Under no circumstance
should you attempt to defeat the purpose of the safety
interlock system.

13
Features and Controls
Features and Controls
Identification Numbers
When contacting your authorized dealer for replacement
parts, service, or information you MUST have these
numbers.
Record your model / serial number and engine serial
numbers on the space provided on the inside front cover for
easy access. These numbers can be found in the locations
shown.
NOTE: For location of engine identification numbers, refer to
engine owner’s manual.
Mower Deck
Identification
Tag
Tractor
Identification
Tag
S
S
AMPLE
AMPLE
Safety Icons
A B C D
E F G H
I J K L
M
Q
N O P
Callout Description
A Alert
B Read the Manual
C Amputation - Rotating Parts
D Pinch Point
E Fire Hazard
F Amputation - Hand in Blade
G Amputation - Foot in Blade
H Thrown Objects
I Maximum Slope Angle for Safe Operation
J Overhead Obstacles
K Rollover Hazard
L Tipover
M Keep ROPS in Raised Position
N Keep Children Away
O Slippery Slopes
P Dropoffs
Q Hot Surface

14 www.SnapperPro.com
Features and Controls
Cutting Height Adjustment Pin
With the actuator fully extended move the cutting height
adjustment pin to the desired cutting height. Retract the
actuator until it makes contact with the cutting height
adjustment pin to set the cutting height.
Control Functions
The information below briefly describes the function of individual controls. Starting, stopping, driving, and mowing require
the combined use of several controls applied in specific sequences. To learn what combination and sequence of controls to
use for various tasks see the OPERATION section.
Features and Controls
Tractor
See Instrument
Control Panel
Ground Speed Control Levers
These levers control the ground speed of the rider. The
left lever controls the left drive wheel and the right lever
controls the right drive wheel.
Moving a lever forward increases the FORWARD speed
of the associated wheel, and pulling back on and lever
increases the REVERSE speed.
Note: The further a lever is moved away from the neutral
position the faster the drive wheel will turn.
See Zero-Turn Driving Practice section for steering
instructions.
Seat Adjustment Lever
The seat can be adjusted forward and back.
Serial Number 2014648787 & Below: Move the lever
away from the seat, position the seat as desired, and
release the lever to lock the seat in position.
Serial Number 2014648788 & Above: Move the lever to
the left, position the seat as desired, and release the lever
to lock the seat in position.
Operating Position Indicator Lamp
The operating position indicator lamp will flash when the
mower deck is not properly positioned in the operating
position. When the mower deck is properly positioned the
operating position indicator lamp will stop flashing and
shut off. See Positioning the Mower Deck for Operation
for instructions on properly positioning the mower deck.
A. Serial Number 2014648787 & Below
B. Serial Number 2014648788 & Above
AB

15
Features and Controls
Mower Deck Lift Actuator Switch
Pulling back on the switch will lower the mower deck.
Pushing forward on the switch will raise the deck. The
ground speed controls levers MUST be in the NEUTRAL
positon to raise or lower the mower deck.
Driving the Mower: The mower deck MUST either be
positioned in the Operating position or the Service position
BEFORE you move the ground speed control levers out of
the NEUTRAL position.
Operating the Mower: The mower deck MUST be
positioned in the Operating position BEFORE engaging the
PTO clutch.
See Positioning the Mower Deck for Service and
Positioning the Mower Deck for Operation for the proper
positioning of the mower deck.
PTO (Power Take Off) Switch
The PTO switch engages and disengages the mower.
Pull UP on the switch to engage, and push DOWN to
disengage.
IMPORTANT NOTE: If you attempt to position the mower
deck for service with the PTO switch engaged, the
PTO will shut off and remain shut off until the deck is
properly positioned for operation and the PTO switch is
disengaged and then re-engaged.
Throttle Control
The throttle controls the engine speed. Move the throttle
control forward toward the FAST position to increase
the engine speed and back towards the SLOW position
to decrease the engine speed. Always operate at FULL
throttle when mowing.
FAST Speeds up the engine speed.
SLOW Slows down the engine speed.
Parking Brake
Pull the parking brake handle up to engage the parking
brake. Push the parking brake handle down to disengage
the parking brake. NOTE: To start the unit the parking
brake must be engaged.
DISENGAGE Releases the parking brake.
ENGAGE Locks the parking brake
Instrument Control Panel
Retractable Seat Belt
The seat belt is used to secure the operator to the seat.
The seat belt should ALWAYS be worn when the Roll Bar
is in the raised position. The seat belt should NEVER be
worn when the Roll Bar is in the down position.
Deck Attachment Lever
The deck attachment lever is used to assist in the process
of removing and installing the mower deck to the tractor.
See the Attachment Removal and Installation section.
Hour Meter
The hour meter measures the number of hours the PTO
has been engaged. The hour glass will flash when the
hour meter is recording the passage of time. The hour
meter has a self-contained power source so that total
hours are always visible.
Ignition Switch
The ignition switch starts and stops the engine, it has three
positions:
OFF Stops the engine and shuts off the electrical
system.
RUN /
HEAT
Turning the key to this position prior to
starting the engine heats the glow plugs.
After the engine starts the engine returns to
this position and allows the engine to run
and powers the electrical system.
START Cranks the engine for starting
Note: Never leave the ignition switch in the RUN position
with the engine stopped-this drains the battery.

16 www.SnapperPro.com
Features & Controls
Operation
General Operating Safety
Before first time operation:
• Be sure to read all information in the Safety and
Operation sections before attempting to operate this
unit.
• Become familiar with all of the controls and how to stop
the unit.
• Drive in an open area without mowing to become
accustomed to the unit.
WARNING
Do NOT load this zero-turn rider on a trailer or truck using
two separate ramps. Only use a single ramp that is at
least one foot wider than the width of the rear wheels of
this rider. This rider has a zero turning radius and the rear
wheels could fall off the ramps, or the rider could tip over
injuring the operator or bystanders.
WARNING
• Never allow passengers to ride on the unit.
• Before leaving the operator’s position for any reason,
engage the parking brake, disengage the PTO, stop the
engine and remove the key.
• To reduce fire hazard, keep the engine, tractor and
mower free of grass, leaves and excess grease. Do
NOT stop or park tractor over dry leaves, grass or
combustible materials.
• Gasoline is highly flammable and must be handled with
care. Never fill the tank when the engine is still hot from
recent operation. Do NOT allow open flame, smoking or
matches in the area. Avoid over-filling and wipe up any
spills.
WARNING
Operating on steep slopes can be
dangerous.
• Never operate on slopes greater than 15°.
• Select slow ground speed before driving onto a slope.
Use extra caution when operating on slopes with a rear-
mounted grass catcher.
• Mow across the face of slopes, not up and down, use
caution when changing directions and DO NOT START
OR STOP ON A SLOPE.
Glow Plug Indicator
Lamp that indicates that the glow plugs are heating. Hold
the ignition key in the “RUN” position until indicator lamp
turns off, then turn key to start.
Voltage Gauge
Gauge measures the output voltage of the engine charging
system.
Oil Pressure Indicator
Lamp that indicates a low oil pressure condition.
Water Temperature Gauge
Gauge measures the engine coolant temperature.

17
Operation
Figure 1. Pre-start Checks
A. Engine Oil Dipstick
B. Fuel Tank Cap
C. Hydraulic Oil Fill
A
Seat Adjustment (Suspension Seat)
Serial Number 2014648787 & Below:
In addition to the forward and backward seat adjustment,
models equipped with a suspension seat can be adjusted for
lumbar support, suspension and back angle.
Forward and Backward Adjustment:
Move the forward / backward seat adjustment lever (A,
Figure 2a) away from the seat, position the seat as desired,
and release the lever to lock the seat into position.
Lumbar Adjustment:
Turn the lumbar adjustment knob (B) until the desired
amount of lumbar is achieved.
Back Angle Adjustment:
Turn the back angle adjustment knob (C) until the desired
amount of back angle is achieved.
Suspension Adjustment:
Turn the suspension adjustment knob (D) until the display
scale has a reading that matches the weight of the operator.
A
B
C
Figure 2a. Suspension Seat Adjustment
A. Forward / Backward Seat Adjustment Lever
B. Lumbar Adjustment Knob
C. Back Angle Adjustment Knob
D. Suspension Adjustment Knob
D
Checks Before Starting
• Check that crankcase is filled to full mark on the engine
oil dipstick (A, Figure 1). See the engine Operator’s
Manual for instructions and oil recommendations.
• Fill the fuel tank (B) with fresh fuel. Refer to engine
manual for fuel recommendations.
• Make sure all nuts, bolts, screws and pins are in place
and tight.
• Check the tire pressures. See Check Tire Pressures.
• Check the hydraulic oil tank (C) and make sure that the
oil level is up to the FULL COLD mark.
• Adjust the height of the mower deck to the desired
position. See Mowing Height Adjustment.
• Adjust the seat position, and make certain you can reach
all controls from the operator’s position. See Seat
Adjustment (Suspension Seat).
• Make sure that the fuel valves are in the ON position.
• Check the radiator fluid level. See Check Engine Coolant
Level.
C
B

18 www.SnapperPro.com
18
Operation
Figure 3. Checking Tire Pressure
Check Tire Pressures
Tire pressure should be checked periodically, and
maintained at the levels shown in the chart. Note that these
pressures may differ slightly from the “Max Inflation”
stamped on the side-wall of the tires. The pressures shown
provide proper traction, improve cut quality, and extend tire
life.
Mowing Height Adjustment
The cutting height adjustment pin (A, Figure 4) controls
the mower cutting height. The cutting height is adjustable
between 1-1/2” (3,37 cm) and 5” (12,7 cm) in 1/4” (0,64
cm) increments.
1. Turn the ignition key (C) to the RUN position.
2. Press the mower deck lift actuator switch (B) foward
(away from the operator) to remove the pressure from
the deck height adjustment pin.
3. Place the deck height adjustment pin in the desired
location.
4. Press the mower deck lift actuator switch backwards
(towards the operator) until contact is made with the
deck height adjustment pin. Continue to retract the
actuator until the operating position indicator lamp (D)
stops flashing and shuts off.
NOTE: The actuator MUST be positioned correctly before
attempting to move the ground speed control levers out of
their NEUTRAL positions. If the actuator is not positioned
as described in the above step the mower’s safety
interlock system will cause the engine to shut off.
Figure 4. Mowing Height Adjustment
A. Cutting Height Adjustment Pin
B. Actuator Deck Height Toggle Switch
C. Ignition Switch Key
D. Operating Position Indicator Lamp
A
C
B
D
Tire Pressure
psi bar
Deck Caster
Tire
25 1,03
Drive Tires 10 0,69
Tractor Caster
Tires
25 1,03
Seat Adjustment
S/N: 2014648788 & Above:
The seat can be adjusted forward and back. Move the seat
adjustment lever (A, Figure 2b) to the left, position the
seat as desired, and release the lever to lock the seat into
position.
Figure 2b. Seat Adjustment
A. Seat Adjustment Lever
A
