BrightSign WS103 User manual

1
HO523 WIFI INSTALLATION
Follow the steps below to install the WS103 WiFi/Bluetooth module on the HO523.
Step 1
Remove the screws from each side of the HO523 (four screws total).
Step 2
Using your thumbs, slide the top casing towards the back. Then, remove it
completely.

2
Step 3
Insert the WS103 module into the M.2 connector at an angle of approximately 20
degrees.
Step 4
Secure the WS103 using the screw included with the module.

3
Step 5
Remove the rubber cap from the antenna port near the WS103 module (i.e. the port
on the left side of the front panel).
Step 6
Insert the threaded antenna connector into the antenna port.

4
Step 7
Secure the threaded antenna connector using the washer and nut included with the
module.
Step 8
Tuck the excess antenna cable into the space between the circuit board and the
bottom casing.

5
Step 9
Replace the top casing on the player, making sure it locks fully into place.
Step 10
Reinsert and secure the screws on each side of the HO523.

6
Step 11
Attach the antenna to the threaded antenna connector.
