Brightwell Quantura Q10 User manual

Quick Start Guide for Q10 & Q10+ English
M00015
-
EN
-
22/03/17
-
V1.1
Quantura Q10 & Q10+
Dishwash Dosing System
Safety Notes
IMPORTANT:
Please read the following precautions
carefully before using this equipment.
This appliance can be used by children age from 8
years and above and persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the
appliance in a safe way and understand the
hazards involved. Children shall not play with the
appliance. Cleaning and user maintanence shall
not be made by children without supervision.
If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualified persons in order to avoid hazard.
Before Installation
Ensure you have checked all parts required are
present and inspect for any damage before
installation. In the unlikely event your items are
faulty, DO NOT install faulty or damaged parts as
this unsafe and will void any warranty. Please
return to your distributor in the original delivery
condition including any packaging. This unit is
ONLY to be installed by a suitably qualified person
complying with local regulations.
Quantura
Q10 & Q10+
Peristaltic
tubing
× 1
(Silicone 5mm OR
Norprene 3mm)
Ceramic weight
and foot filter
× 1
Rinse
or
Detergent
Injector
× 1
Polyethylene
Tubing
3000mm × 1
Fixings Pack:
Screws × 2
Wall plugs ×2
Installation
Mounting and connection
Step 1: Using the wall plugs and screws
specified for this unit, fix the mounting
bracket to the wall. There is an embedded
spirit level to aid with this part of the
installation.
Step 2: Mount the unit to the wall by
hooking it onto the wall bracket. As you push
the unit down you should hear a click sound.
Step 3: Ensure there is no power to the
unit Remove front cover by turning thumb
screw anti-clockwise and pulling the front
cover towards you as shown.
Step 4: Insert one end of the tube ensuring
that it is slotted into the body of the
enclosure as shown.
Step 5: Now by manually rotating the pump
head, feed the tube into the unit as shown.
TIP use some HT5 Silicone grease on the
outer of the tube to help ease the tube in and
prevent any snagging.
Step 6: Now insert the other end of the
tube ensuring that it is slotted into the body
of the enclosure as shown.
IMPORTANT INFORMATION: Brightwell
Dispensers Ltd (manufacturer) accepts no
responsibility and/or damages caused to
either the product or premises if the
installation process is not complied with in
full.
.
Connecting Chemicals
Step 1:
Ensure there is no
power to the unit, connect the
suction tube from the detergent
or rinse container to (A). Now
connect the delivery tube from
(B) to the injection point.
Installation connection
Should the supply cord be damaged, it should be replaced by the
manufacturer or its service agent or a similarly qualified person in
order to avoid a hazard.
SPEED
T
IMED
Rinse Rake
Solenoid
Valve
Wash Cycle
Run Lamp
Coil of Wash
Contactor
Cam Timer
Power Supply
Should the supply cord be damaged, it should be replaced by the
manufacturer or its service agent or a similarly qualified person in
order to avoid a hazard.
This unit contains high voltage
circuits that may expose you to the
danger of electric shock.
Means for disconnection must be
incorporated in accordance with the
wiring rules.
Do
not
open the enclosure without
isolating the signal and supply
sources. Ensure that these sources
have been isolated for at least 5
minutes before entering the enclosure.
Do
not
power the unit outside of the
values stated on the rating label.
Do
not
use damaged or frayed cables.
Do
not
dismantle or modify this
equipment.
Never
insert fingers into mechanisms
without turning the power supply off
first.
Do
not
mount the unit to unstable,
irregular or non-vertical surfaces.
Do
not
place heavy objects on top of
the unit.
Do
not
attempt to place items (such as
screwdrivers) into the moving parts of
the pump head.
Always
ensure that care is taken when
handling chemicals.
Do
not
discard of the manual, this
must be retained.
This unit must be installed by suitably qualified
personnel in accordance with local regulations,
or in the absence of local regulations, installed
in accordance with the applicable requirements
in the National Electrical Code, NFPA 70,
Canadian Electrical Code (CEC), Part 1, CSA
C22.1, and Standard for Ventilation Control
and Fire Protection of Commercial Cooking
Operations, NFPA 96.
Detergent
Rinse Aid Dosing
A
B

Quick Start Guide for Q10 & Q10+ English
M00015
-
EN
-
22/03/17
-
V1.1
Operation
-
Speed and Timed
Probe Installation (Q10+ only)
Operation
-
Probe Mode
(Q10+ only)
Selecting between Timed
and Speed Mode
Remove the dust cover with a
screw driver. Use the screwdriver to
flick the switch Left for Timed and
Right for Speed mode. See below
for operational programing.
Prior to Installation: Please note that the probe is to
be mounted at a minimum distance of no less than
100mm away from the tank injector (chemical injection
point).
Probe Mode
is automatically activated when a probe is connected. There is no
requirement to make a switch selection.
Speed
Step 1: Potentiometer A– Used
to adjust the Pump Speed (0-
100%). Continuous Operation is
enabled with potentiometer A set to
zero. Note: the ON period will be
fixed at 0.5 seconds.
Step 2:
Potentiometer B– Used
to adjust the Cyclic OFF period (0-3
seconds). Note: the ON period will
be fixed at 0.5 seconds.
1. Turn dial A to its minimum setting (anti-clockwise) and dial B to its
maximum (clockwise).
2. Add the required amount of product into the wash tank.
3. Adjust dial A until the motor starts to run.
4. Back off dial A until the pump stops again. (The unit is now calibrated
for your required chemical concentration).
5. Finally turn dial B to your required alarm position (the mid position is
recommended).
Service Intervals
1. Pump Tube Servicing: It is recommended the pump tubes are
inspected for performance once every 3 months and lubricated with
silicone grease to pro long tube life.
2. Pump Calibration: As a guide once every 3 months it is recommended
the flow produced is checked to ensure consistent flow over the life of
the tube. To do this run the pump for minute and capture the flow
produced. Compare this figure with the run time of the pump to ensure
the correct dosage is produced.
3. Pump Tube replacement: As a guide it is recommended the tube is
replaced for a new piece once every 6 months, or as needed.
Timed
Step 1: Potentiometer B– Top up
charge will operate when power is
applied. Adjust Top Up run time
using B (1-60 secs).
Step 2: Potentiometer A– The
initial charge will operate if power
remains for over 15 secs after the
completion of the Top Up charge.
Adjust Initial charge run time using
Potentiometer A (1-90 seconds).
WEEE Directive
Please remember to respect the local regulations:
hand in the non-working electrical equipment’s to
an appropriate waste disposal centre. The packaging
material is recyclable. Dispose of the packaging in
an environmentally friendly manner and make it
available for the recyclable material collection-service.
Flowrate – 100ml/min (3.38
fl.oz/min)
NOTE: Flowrates measured with
water, Suction length of 2 metres
Dust Cover
A
B
B
A
Pot
A
Pot
B
Useful
Information
The pump has a maximum run time of 3 minutes per
event. The pump cannot be programed to run longer than
this per event.
