Britec WASHERBASE Installation guide

A
B


ASSEMBLING INSTRUCTIONS

M8x40 Bolt - Qty. 8
M8 Adjustable Foot - Qty. 4
A
A
A
A
B
B
B



Start the assembly by
locating the side frames
and screwing the feet into
the bottom of them.

You will now choose which
height to set your stand to.
For the taller height you
will use the top 4 holes on
the side frames.
For the lower height you
will use the lower holes.
Make sure you only use
the top OR bottom holes.
You cannot mix and
match.
The illustrations show the
stand assembled in teh
lower position.

Once the stand is fully assembled,
make sure all of the bolts are
tightened properly. Use the allen
key provided to go through and
tighten each one.
Notice that on the lower setup
there is a raised lip on each side of
the frame.
The available drawer is compatible
with this stand in both its
congurations.
Note:When the clothes dryer is operating on a spin cycle, the dryer stand may experience a small vibration. The Dryer Stand is stable and designed to sustain such
movements, so please do not be concerned if this occurs
Caution:Ensure your clothes dryer with wet clothes does not exceed the maximum weight load of 75 kilograms.
Support:For any enquiries regarding this product, please contact us as [e-mail]

Your stand is now ready to use.
Position it in place and then set the
washing or drying machine on top.

Hold the stands top
panel in line with the
holes and screw the
bolt on through the
outside of the frame.

Bolt the two sides onto the back frame using the bolts provided.
The bolts will go through the lowest 2 holes on the side frames.
B
AM8x40 Bolt - 4
AM8x40 Bolt - 4
Adjustable Foot - 4
