britech FT User manual

17 Pullman Court, Toronto, ON M1X 1E4 • Tel: [phone] • Fax: [phone] • [e-mail] • www.britech.ca
© 2018, Britech Corp. Disclaimer of liability: Any information given here is understood as a guideline without any legal obligation. Technical data subject to alteration without notice. 10/2018
Description
Snow or ice dams that have built up on a roof can cause water damage to the interior of homes as well as damage to gutters and downspouts.
The BRITECH FT/ST self-regulating heating cable designed for installation on roofs and gutters prevents ice dam formation and maintains flow
paths for melted snow and ice to drain from the roof. Maintaining flow paths prevents standing water on the roof and icicle formations.
The BRITECH FT/ST system is easy to design and to install following the provided installation instructions and utilizing the required accessory
kits. The heating cable can be cut to length at the job site and installed directly on the roof or in gutters or downspouts simplifying the
installation process and reducing waste.
1
BRITECH FT/ST Heating Cable System
Roof, Gutter & Drain Installation Manual
Self-Regulating Cables
heating cables & controls
1. GENERAL INFORMATION
Installation Temperatures
• Minimum installation temperature: -55 °C
• Minimum switched on temperature: -40 °C
Operating Temperatures
• Max. operating temperature switched off
max. 85 °C (1000 hours cumulative)
• Max. operating temperature switched on
max. 65 °C
WARNINGS
This heat tracing system must be installed
correctly to ensure proper operation and
to prevent shock and fire. Read these important
warnings and carefully follow all the installation
instructions.
• To comply with Britech (Bartec) requirements, agency certifications
and the Canadian Electrical Code and to protect against the risk
of fire, ground-fault equipment protection must be used on each
heating cable circuit.
• Approvals and performances are based on the use of Britech
specified parts only. Do not substitute parts.
• Electricians trained for installation of trace heating shall install
the trace heating cable. They shall also ensure orderly condition,
operation and monitoring of the operating equipment as well as
the implementation of maintenance and repair works.
For Technical Assistance:
For product selection, design assistance and
technical questions please contact Britech at
1-877-335-7790
Made in Germany
Ground Fault Protection:
A ground fault protection device must be used with
this heating device. 30mA GFEP protection required.
Contact Britech for selection of GFIs and controls.
Installation Instructions Cold-applied kit 05-0091-0128 Heating circuit FT-ST 27-1680-****
Approval
Certifi cation
CAN/CSA-C22.2 No. 130-03
1862457; Class: 2878-01, 2878-81
Class: 2872-01, 2872-81
Class I, Div. 2, Groups A, B, C, D
Class II, Div. 2 Groups E, F, G
Class III
Technical data
Rated voltage
120 V, 240 V
Rated current
max. 30 A
Related power rating
max. 33 W/m (10 W/ft) at 10 °C (50 °F)
Protection class
NEMAX 4X
Max. permissible process temperature
+65 °C (+149 °F)
with heating system switched on
+85 °C (+185 °F)
with heating system switched off
Min. ambient temperature
-55 °C (-67 °F)
Min. installation temperature
-30 °C (-22 °F)
3/6
Put silicone glue h into the end cap g and put
this onto the exposed insulating sleeve.
Push the end cap over the end of the heating
tape until some of the glue oozes out.
Remove the metal jacket, starting from the end
of the heating tape. Take care not to damage the
internal insulation.
10
Cut through the heating tape with a straight cut.
Remove 5 mm (0.2 inch.) of the outer protective
sleeve on the heating tape.
9 11
Note regarding gluing
The silicone should ooze out a bit when the silicone
hose is pushed onto the heating tape. When laying
the heating tape in the junction box, make sure the
silicone hose lies directly against the cable gland
sealing. This prevents overheating.
After gluing, inspect the heating circuit visually.
There may not be any fault, such as e.g. cracks,
peeling, cuts etc. Leave the glued area to set for 20
min. The fi nal strength is reached after 24 hours.
Installation Instructions Cold-applied kit 05-0091-0128 Heating circuit FT-ST 27-1680-****
4/6
Approvals FT/ST Cable Construction Power Connection Kit
For power connection of the system please
refer to the Power Connection and Splice Kit
manuals for complete instructions.
BRI-PEK-FT Power Connection & End Seal Kit
BRI-PEK-ST Power Connection & End Seal Kit
BRI-TSP-1 T-Splice & End Seal Kit
Braided Jacket

17 Pullman Court, Toronto, ON M1X 1E4 • Tel: [phone] • Fax: [phone] • [e-mail] • www.britech.ca
© 2018, Britech Corp. Disclaimer of liability: Any information given here is understood as a guideline without any legal obligation. Technical data subject to alteration without notice. 10/2018
BRITECH FT/ST Heating Cable System
Roof, Gutter & Drain Installation Manual
Self-Regulating Cables
heating cables & controls
2
2. SYSTEM COMPONENTS
Heating Cables
Catalogue No. : Description Heating Cable Allowance Qty Required
BRI-PEK-FT Power Connection & End Seal Kit 2 ft 1 per power connection/end seal
BRI-PEK-ST Power Connection & End Seal Kit 2 ft 1 per power connection/end seal
BRI-TSP-1 T-Splice Kit & End Seal Kit 2 ft 1 per t-splice/end seal
Connection Kits
Catalogue No. : Description Trigger Mechanism
BRI-A19-4X20 Weatherproof thermostat Ambient temperature
ASE DS-8C Automatic snow/rain sensor Precipitation & Ambient temperature
ASE CDP-2 Remote control/display panel Manual override
Controls
Catalogue No. : Description Target Area
BT-50 Roof clip Roof
BRISS-75 Stainless steel cable clip strip Flat roof, gutter
Mounting Accessories
* Note: Adhesives/sticky pads or hardware required to fasten mounting clips to roof or gutter are not included, to be supplied by installer.
FT - 120V FT - 208V (Adjusted from 240V) FT - 240V
FT110-1810P-120V (3W/ft) FT210-1810P-208V (2.5W/ft) FT210-1810P-240V (3W/ft)
FT115-1810P-120V (5W/ft) FT215-1810P-208V (4W/ft) FT215-1810P-240V (5W/ft)
FT120-1810P-120V (6W/ft) FT220-1810P-208V (5W/ft) FT220-1810P-240V (6W/ft)
FT125-1810P-120V (8W/ft) FT225-1810P-208V (6.5W/ft) FT225-1810P-240V (8W/ft)
FT133-1810P-120V (10W/ft) FT233-1810P-208V (9W/ft) FT233-1810P-240V (10W/ft)
ST - 120V ST - 208V (Adjusted from 240V) ST - 240V
ST110-1410P-120V (3W/ft) ST210-1410P-208V (2.5W/ft) ST210-1410P-240V (3W/ft)
ST115-1410P-120V (5W/ft) ST215-1410P-208V (4W/ft) ST215-1410P-240V (5W/ft)
ST120-1410P-120V (6W/ft) ST220-1410P-208V (5W/ft) ST220-1410P-240V (6W/ft)
ST125-1410P-120V (8W/ft) ST225-1410P-208V (6.5W/ft) ST225-1410P-240V (8W/ft)
ST130-1410P-120V (9W/ft) ST230-1410P-208V (8W/ft) ST230-1410P-240V (9W/ft)
Catalogue number: FT/ST X XX Supply voltage: 1-120V, 2-208-240V
Heat output at 10°C, watts/m

17 Pullman Court, Toronto, ON M1X 1E4 • Tel: [phone] • Fax: [phone] • [e-mail] • www.britech.ca
© 2018, Britech Corp. Disclaimer of liability: Any information given here is understood as a guideline without any legal obligation. Technical data subject to alteration without notice. 10/2018
BRITECH FT/ST Heating Cable System
Roof, Gutter & Drain Installation Manual
Self-Regulating Cables
heating cables & controls
3
3. INSTALLATION
Determine the total cable length
Before any installation begins, determine the required cable length. The amount of cable required to maintain a clear path for melted snow and
ice to drain shall be based on size and shape of the roof system that need protection. Plan the cable layout and use the following tables to
calculate the total cable length required.
Figure 1 – Illustration of roof
Figure 1 – Illustration of roof

17 Pullman Court, Toronto, ON M1X 1E4 • Tel: [phone] • Fax: [phone] • [e-mail] • www.britech.ca
© 2018, Britech Corp. Disclaimer of liability: Any information given here is understood as a guideline without any legal obligation. Technical data subject to alteration without notice. 10/2018
BRITECH FT/ST Heating Cable System
Roof, Gutter & Drain Installation Manual
Self-Regulating Cables
heating cables & controls
4
Determine the number of circuits
The circuit length for a given over current protection device shall not exceed the maximum length specified in the following charts. If the total
heating cable length exceeds the maximum circuit length for the expected start-up temperature, more than one circuit will be required.
Minimum number of circuits = Total cable length
Maximum recommended circuit length
Ground-fault protection on each heating cable branch circuit is required by the Canadian Electrical Code to minimize the danger of fire from
sustained electrical arcing if the heating cable is damaged or improperly installed.
MAXIMUM CIRCUIT LENGTH CHART FOR FT (FREEZE TRACE) CABLES
FT Maximum Circuit Length ft (m) : Based on Circuit Breaker Size (Equipment Protection Type C)
208 V 240 V
[°F] [°C] 15 A 20 A 30 A 15 A 20 A 30 A 15 A 20 A 30 A
50 10 312 ft (95 m) 312 ft (95 m) 312 ft (95 m) 591 ft (180 m) 591 ft (180 m) 591 ft (180 m) 673 ft (205 m) 673 ft (205 m) 673 ft (205 m)
32 0 279 ft (85 m) 312 ft (95 m) 312 ft (95 m) 476 ft (145 m) 541 ft (165 m) 591 ft (180 m) 525 ft (160 m) 656 ft (200 m) 640 ft (195 m)
5 -15 226 ft (69 m) 295 ft (90 m) 312 ft (95 m) 410 ft (125 m) 525 ft (160 m) 558 ft (170 m) 456 ft (139 m) 610 ft (186 m) 640 ft (195 m)
-22 -30 190 ft (58 m) 246 ft (75 m) 312 ft (95 m) 354 ft (108 m) 443 ft (135 m) 541 ft (165 m) 394 ft (120 m) 492 ft (150 m) 640 ft (195 m)
50 10 220 ft (67 m) 262 ft (80 m) 262 ft (80 m) 410 ft (125 m) 476 ft (145 m) 476 ft (145 m) 476 ft (145 m) 531 ft (162 m) 531 ft (162 m)
32 0 180 ft (55 m) 230 ft (70 m) 262 ft (80 m) 328 ft (100 m) 410 ft (125 m) 476 ft (145 m) 377 ft (115 m) 443 ft (135 m) 531 ft (162 m)
5 -15 148 ft (45 m) 197 ft (60 m) 262 ft (80 m) 262 ft (80 m) 374 ft (114 m) 427 ft (130 m) 305 ft (93 m) 410 ft (125 m) 531 ft (162 m)
-22 -30 128 ft (39 m) 161 ft (49 m) 262 ft (80 m) 213 ft (65 m) 312 ft (95 m) 404 ft (123 m) 253 ft (77 m) 348 ft (106 m) 525 ft (160 m)
50 10 190 ft (58 m) 230 ft (70 m) 230 ft (70 m) 328 ft (100 m) 394 ft (120 m) 394 ft (120 m) 381 ft (116 m) 459 ft (140 m) 459 ft (140 m)
32 0 164 ft (50 m) 177 ft (54 m) 230 ft (70 m 256 ft (78 m) 312 ft (95 m) 394 ft (120 m) 269 ft (82 m) 344 ft (105 m) 459 ft (140 m)
5 -15 121 ft (37 m) 151 ft (46 m) 230 ft (70 m) 203 ft (62 m) 262 ft (80 m) 361 ft (110 m) 236 ft (72 m) 305 ft (93 m) 459 ft (140 m)
-22 -30 98 ft (30 m) 125 ft (38 m) 200 ft (61 m) 157 ft (48 m) 213 ft (65 m) 312 ft (95 m) 180 ft (55 m) 253 ft (77 m) 361 ft (110 m)
50 10 141 ft (43 m) 190 ft (58 m) 207 ft (63 m) 262 ft (80 m) 312 ft (95 m) 344 ft (105 m) 289 ft (88 m) 384 ft (117 m) 413 ft (126 m)
32 0 118 ft (36 m) 164 ft (50 m) 190 ft (58 m) 236 ft (72 m) 256 ft (78 m) 328 ft (100 m) 230 ft (70 m) 279 ft (85 m) 413 ft (126 m)
5 -15 98 ft (30 m) 125 ft (38 m) 180 ft (55 m) 164 ft (50 m) 217 ft (66 m) 302 ft (92 m) 190 ft (58 m) 246 ft (75 m) 384 ft (117 m)
-22 -30 85 ft (26 m) 102 ft (31 m) 174 ft (53 m) 131 ft (40 m) 180 ft (55 m) 262 ft (80 m) 148 ft (45 m) 210 ft (64 m) 328 ft (100 m)
50 10 108 ft (33 m) 148 ft (45 m) 177 ft (54 m) 197 ft (60 m) 246 ft (75 m) 295 ft (90 m) 230 ft (70 m) 295 ft (90 m) 354 ft (108 m)
32 0 95 ft (29 m) 125 ft (38 m) 164 ft (50 m) 164 ft (50 m) 203 ft (62 m) 262 ft (80 m) 180 ft (55 m) 246 ft (75 m) 344 ft (105 m)
5 -15 82 ft (25 m) 105 ft (32 m) 148 ft (45 m) 148 ft (45 m) 180 ft (55 m) 226 ft (69 m) 161 ft (49 m) 210 ft (64 m) 312 ft (95 m)
-22 -30 69 ft (21 m) 85 ft (26 m) 141 ft (43 m) 125 ft (38 m) 148 ft (45 m) 190 ft (58 m) 141 ft (43 m) 171 ft (52 m) 269 ft (82 m)
Start-up Temp 120 V
FTX10
FTX15FTX20
FTX25
FTX33
Cable
Type

17 Pullman Court, Toronto, ON M1X 1E4 • Tel: [phone] • Fax: [phone] • [e-mail] • www.britech.ca
© 2018, Britech Corp. Disclaimer of liability: Any information given here is understood as a guideline without any legal obligation. Technical data subject to alteration without notice. 10/2018
BRITECH FT/ST Heating Cable System
Roof, Gutter & Drain Installation Manual
Self-Regulating Cables
heating cables & controls
5
Locating the heating cable on the roof
On the edge of the roof, route the heating cable in a triangle pattern (see Figure 2). Loop the heating cable on the overhang area of the roof
and extend the loop into the gutter to maintain a drainage path. The spacing of the loops should be 1-2 feet. Use roof clips to hold the heating
cable onto the roof at the top and bottom of the triangles.
For valleys, route the cable a minimum of 3 feet up and down the valley. Lengthen as appropriate for high roofs.
Construction of an ice/snow fence above the tracing system is recommended to prevent damage from ice or snow slides.
MAXIMUM CIRCUIT LENGTH CHART FOR ST (SMART TRACE) CABLES
ST Maximum Circuit Length ft (m) : Based on Circuit Breaker Size (Equipment Protection Type C)
208 V 240 V
[°F] [°C] 10 A 15 A 10 A 15 A 10 A 15 A
50 10 161 ft (49 m) 253 ft (77 m) 328 ft (100 m) 427 ft (130 m) 387 ft (118 m) 505 ft (154 m)
32 0 151 ft (46 m) 236 ft (72 m) 279 ft (85 m) 394 ft (120 m) 328 ft (100 m) 466 ft (142 m)
5 -15 148 ft (45 m) 223 ft (68 m) 246 ft (75 m) 377 ft (115 m) 295 ft (90 m) 446 ft (136 m)
-22 -30 128 ft (39 m) 194 ft (59 m) 217 ft (66 m) 328 ft (100 m) 253 ft (77 m) 387 ft (118 m)
50 10 141 ft (43 m) 190 ft (58 m) 292 ft (89 m) 377 ft (115 m) 341 ft (104 m) 456 ft (139 m)
32 0 131 ft (40 m) 171 ft (52 m) 236 ft (72 m) 289 ft (88 m) 269 ft (82 m) 377 ft (115 m)
5 -15 115 ft (35 m) 148 ft (45 m) 194 ft (59 m) 246 ft (75 m) 226 ft (69 m) 292 ft (89 m)
-22 -30 92 ft (28 m) 128 ft (39 m) 157 ft (48 m) 213 ft (65 m) 184 ft (56 m) 256 ft (78 m)
50 10 108 ft (33 m) 151 ft (46 m) 230 ft (70 m) 312 ft (95 m) 259 ft (79 m) 361 ft (110 m)
32 0 95 ft (29 m) 131 ft (40 m) 171 ft (52 m) 246 ft (75 m) 197 ft (60 m) 295 ft (90 m)
5 -15 82 ft (25 m) 118 ft (36 m) 144 ft (44 m) 207 ft (63 m) 161 ft (49 m) 233 ft (71 m)
-22 -30 66 ft (20 m) 95 ft (29 m) 118 ft (36 m) 164 ft (50 m) 131 ft (40 m) 190 ft (58 m)
50 10 82 ft (25 m) 115 ft (35 m) 174 ft (53 m) 236 ft (72 m) 197 ft (60 m) 272 ft (83 m)
32 0 72 ft (22 m) 105 ft (32 m) 138 ft (42 m) 180 ft (55 m) 157 ft (48 m) 223 ft (68 m)
5 -15 66 ft (20 m) 92 ft (28 m) 115 ft (35 m) 157 ft (48 m) 128 ft (39 m) 184 ft (56 m)
-22 -30 49 ft (15 m) 79 ft (24 m) 89 ft (27 m) 135 ft (41 m) 98 ft (30 m) 154 ft (47 m)
50 10 62 ft (19 m) - 131 ft (40 m) - 148 ft (45 m) -
32 0 49 ft (15 m) - 98 ft (30 m) - 112 ft (34 m) -
5 -15 39 ft (12 m) - 69 ft (21 m) - 79 ft (24 m) -
-22 -30 26 ft (8 m) - 46 ft (14 m) - 52 ft (16 m) -
Start-up Temp 120 V
STX10
STX15STX20
STX25
STX30
Cable
Type

17 Pullman Court, Toronto, ON M1X 1E4 • Tel: [phone] • Fax: [phone] • [e-mail] • www.britech.ca
© 2018, Britech Corp. Disclaimer of liability: Any information given here is understood as a guideline without any legal obligation. Technical data subject to alteration without notice. 10/2018
BRITECH FT/ST Heating Cable System
Roof, Gutter & Drain Installation Manual
Self-Regulating Cables
heating cables & controls
6
Locate the heating cable in gutters and downspouts
If a gutter is present, all gutters below heated areas of the roof must have a heating cable run through to allow for the drainage of melted snow
or ice. Run the heating cable in and along the gutter (See Figure 3). It is not necessary to attach the cable to the gutter bottom. Double runs of
heating cable are recommended for gutters more than 6 in wide. Use roof clips to provide equal spacing between each length of cable.
When running the heating cable into, or out of the gutter, use a roof clip to prevent abrasion of the cable.
If a downspout is present along the route of the gutter, drop the cable down to the bottom of drain and back up; continue the
cable along the gutter. The cable should extend below the frost line if the downspout is tied into a drainage system. End terminations should
not be located at the lowest point of downspouts. Where the gutter joins the drainpipe and at sensitive transition zones, use roof clips to
prevent abrasion of the cable.
Power connection and splices
Please refer to Britech’s Power Connection and Splice Kit manuals for instructions.
BRI-PEK-FT Power connection & End seal kit
BRI-PEK-ST Power connection & End seal kit
BRI-TSP-1 T-Splice and End seal kit

17 Pullman Court, Toronto, ON M1X 1E4 • Tel: [phone] • Fax: [phone] • [e-mail] • www.britech.ca
© 2018, Britech Corp. Disclaimer of liability: Any information given here is understood as a guideline without any legal obligation. Technical data subject to alteration without notice. 10/2018
BRITECH FT/ST Heating Cable System
Roof, Gutter & Drain Installation Manual
Self-Regulating Cables
heating cables & controls
7
4. OPERATION AND MAINTENANCE
WARNINGS
All applicable safety instructions must be observed prior to the
implementation of any maintenance or failure rectification works.
De-energise all power circuits before servicing.
System start-up
The power connection kit contains two caution labels “electrically heated”. These must be visibly located. One must be at the circuit breaker
panel, the other on or next to the control device for the cable unit.
When the heating cable installation is complete, visually inspect for mechanical damage and test the entire circuit for insulation resistance
prior to applying power. Apply a test voltage of at least 2500 VDC between the heating cable bus wires and the grounding braid. The minimum
acceptable reading is 20 MΩ. Record the value.
Power the system with the appropriate voltage. The voltage rating of the heating cable must be suitable for the service being used. A deviation
from the nominal operating voltage will change the heating power.
Periodic inspection and maintenance
A system inspection with visual and electrical checks is needed before each winter season:
• Visually inspect the heating cable to make sure physical damage has not occurred.
• Inspect junction boxes for water or evidence of previous water ingress.
• If moisture is present, restore the box to dry condition and eliminate the cause of ingress.
• Clear all gutters and/or downspouts of leaves and any other debris.
• Check monitoring and ground-fault devices for functionality.
• Measure insulation resistance of each heater circuit.
Roof and gutter repair and maintenance
If maintenance is needed on the roof, gutter, downspouts or other areas close to the heating cable:
• Disconnect power to all heating cable circuits.
• Protect the heating cable from damage during the repair.
• Visually inspect for heating cable damage and test insulation resistance after any repairs or maintenance.
• Reconnect power to all heating cable circuits.
Damaged products
Remove damaged cables and replace the entire section. Defective cable or component must be replaced immediately to avoid moisture
migration into the good section of the cable. Replace all gaskets used for the heat trace connections after every disassembly.

17 Pullman Court, Toronto, ON M1X 1E4 • Tel: [phone] • Fax: [phone] • [e-mail] • www.britech.ca
© 2018, Britech Corp. Disclaimer of liability: Any information given here is understood as a guideline without any legal obligation. Technical data subject to alteration without notice. 10/2018
CONTROL CARD
Self-Regulating Heating Cable System
TEST
Test Voltage
of Cable
(M OHMS)
Insulation
Resistance
(M OHMS)
Prior to applying
power to system
After applying
power to system
Installation
Notes
Address of Installation:
Date of Installation:
Name of Qualied Electrician:
Signature of Qualied Electrician:
IMPORTANT: The system warranty is not valid without evidence that the system resistance has been tested. Control Card
must be completed and given to the property or homeowner upon completion of installation and required testing.
For assistance with your heating cable product please contact Britech by calling 1-877-335-7790 or email [email protected]
Product Name:
Model #:
Supplier/Purchased from:
CONTROL CARD
Watts: Volts:
APPLICATION: pipe tracing roof, gutter and drains other:
LOCATION :
(MM/DD/YY)
8
heating cables & controls

WARRANTY INFORMATION
Policy Summary / Terms & Conditions
17 Pullman Court, Toronto, ON M1X 1E4 • Tel: [phone] • Fax: [phone] • [e-mail] • www.britech.ca
© 2018, Britech Corp. Disclaimer of liability: Any information given here is understood as a guideline without any legal obligation. Technical data are subject to alteration without notice. 10/2018
WARRANTY TERMS
9
heating cables & controls
WARRANTY POLICY
All products sold in Canada by Britech Corp. carry the
original manufacturers warranties. Britech’s policy is to
exchange any non-performing product with a similar product
or product of equal value during its warranty period as
outlined in the terms below. Full product warranties can be
obtained from the manufacturer online and/or by request.
Britech will administer and promptly process all warranties
in accordance with the manufacturer’s specic warranty
policies and procedures.
Britech will provide technical assistance to assist the end
user or installer in the best method of operation,
application and installation.
Custom heating cables carry a twenty (20) year warranty.
Warranty on custom TXLP cables is provided by Nexans
(refer to their warranty statement summary).
For more information regarding warranty terms or for
assistance with your heating cable product please contact
Britech Corp. at 1-877-335-7790
Warranty Terms for Heating Cables,
Mats & Custom Cable Units:
BRITECH Terms of Limited Warranty (Summary):
This guarantee applies to the following Britech label
products: TECH-MAT™, SNOW-MAT™, SNOW-MELT™
and BRI-THIN™ Cables: (20) twenty year warranty /
THERMA-ROOF™and THERMA-PIPE™ (5) ve years
Britech warrants to the original purchaser only, that
the product is to be free of any defects in material or
workmanship during the rst twenty (20) or ve (5) years
after the date of purchase under proper and normal use of
the system. This guarantee is a material warranty only and
does not cover any labor or other installation cost. The
warranty does not cover installations made by unauthorized
persons or faults caused by incorrect design by others,
misuse, damage caused by others, damage in transit,
incorrect installation and any other subsequent damage
that may occur. Repair and/or replacement will be fully
chargeable if damage is result of any of the above reasons.
Britech is under no circumstances liable for any incidental,
special, or consequential damages or losses including
without limitation the loss or prot arising from any cause
whatsoever. To obtain a replacement under this warranty,
please send a description of the defect, proof of purchase,
and the damaged product, shipping paid to Britech at the
address noted below. The warranty is void if there is any
payment default and if data is not lled-in on the control
card. www.britech.ca
NEXANS Terms of Limited Warranty (Summary):
Nexans Norway warrants the products manufactured by it
to be free from defects in material and workmanship from
the date the warranty form attached to the product is
correctly and completely lled in and for a period of twenty
(20) years thereafter, or a period of twenty-one (21) years
after the production date, whichever period ends rst,
under proper and normal use and service. Nexans Norway’s
responsibility does not include defects caused by material
obtained by the buyer or by constructions specied by it.
Nexans Norway further warrants that the products will have
passed those performance tests, if any, called for in the
applicable specications.
The buyer must give Nexans Norway written notice of any
defect within thirty (30) days following the discovery of the
defect, and in no event later than two (2) weeks after the
expiry of the warranty period.
www.nexans.com
Warranty Terms for Controls,
Thermostats & Sensors:
ASE / Automated Systems Engineering
Terms of Limited Warranty (Summary):
ASE Products are warranted against defects in workmanship
and materials for two (2) years from date of sale. This
warranty does not apply to damage resulting from accident,
misuse, or alteration nor where connected voltage is more
than 5% above the congured operating voltage, nor to
equipment improperly installed or wired or maintained in
violation of the Owner’s Manual. No other written or oral
warranty applies. No employee, agent, dealer or other
person is authorized to give any warranties on behalf of ASE.
The customer shall be responsible for all costs incurred in
the removal or reinstallation and shipping of the product for
repairs. Within the limitations of this warranty, inoperative
units should be returned, freight prepaid, to ASE, and we
will repair or replace, at our option, at no charge to you with
return freight paid by ASE. It is agreed that such repair or
replacement is the exclusive remedy available from ASE
and that ASE IS NOT RESPONSIBLE FOR DAMAGES OF
ANY KIND, INCLUDING INCIDENTAL AND CONSEQUENTIAL
DAMAGE. www.goase.com
BRITECH / HONEYWELL
Terms of Limited Warranty (Summary):
Honeywell warrants it’s products, excluding battery,
to be free from defects in the workmanship or materials,
under normal use and service, for a period of three (3)
years from the date of manufacture. If at any time during the
warranty period the product is determined to be defective
or malfunctions, Honeywell shall repair or replace it (at
Honeywell’s option) through Britech.
If product is defective, return it to the following address:
Britech Corp., 17 Pullman Court, Toronto, Ontario M1X 1E4
Toll Free: 1-877-335-7790 • Email: [email protected]
This warranty does not cover removal or reinstallation costs.
This warranty shall not apply if it is shown by Honeywell
that the defect or malfunction was caused by damage which
occurred while the product was in the possession of a
consumer. Honeywell’s sole responsibility shall be to repair
or replace the product within the terms stated above.
www.honeywell.com
JOHNSON CONTROLS
Terms of Limited Warranty (Summary):
The Company warrants all products manufactured by it to
be free from defects in workmanship or materials under
normal use and service. If any part of the product herein
described, and sold by the Company proves to be defective
in workmanship or material, and if such part is within
three (3) years from date of sale, returned to the Company
transportation charges prepaid and if the same is found by
the Company to be defective in workmanship or material,
credit based on current prices will be allowed. The date of
sale must be established by a receipt showing the purchase
date, seller and product sold. If the date of sale cannot be
determined, the warranty shall extend for three (3) years
from the date of manufacture. www.jci.com
NEXTRON Terms of Limited Warranty (Summary):
The manufacturer warrants each control that it manufactures
to be free from defective material or workmanship for a
period of 12 months from date of purchase. Under this
warranty, the obligation of the manufacturer is limited to
repairing or replacing the defective control at its option,
when returned to the manufacturer’s factory with shipping
charges prepaid. If failure has been caused by misuse,
incorrect application or alteration of the control, this
warranty will be void. UNLESS SPECIFICALLY PROVIDED
FOR IN WRITING IN THIS WARRANTY, EACH CONTROL IS
PROVIDED WITHOUT ANY WARRANTY OF ANY KIND EITHER
EXPRESSED OR IMPLIED. The user shall be made aware
that if the equipment is used in a manner not specied by
the manufacturer, the protection provided by the equipment
may be impaired. www.nextron.ca
Warranty Terms for BRI-GFI
Ground Fault Interrupter:
BRITECH Terms of Limited Warranty (Summary):
Britech warrants the BRI-GFI (Ground Fault Interrupter)
is manufactured to be free from defective material or
workmanship for a period of 12 months from date of
purchase. Under this warranty, the obligation of Britech
is limited to repairing or replacing the defective control
at its option, when returned to the manufacturer’s factory
with shipping charges prepaid. If failure has been caused
by misuse, incorrect application or alteration of the
control, this warranty will be void. BRITECH IS UNDER NO
CIRCUMSTANCES RESPONSIBLE FOR DAMAGES OF ANY
KIND, INCLUDING INCIDENTAL AND CONSEQUENTIAL
DAMAGES. This guarantee is a material warranty for
components only and does not cover any labor. To obtain a
replacement under this warranty, please send a description
of the defect, proof of purchase, and the damaged product,
shipping paid to Britech at the address noted herein.
Warranty Terms for Self-Regulating
& Constant Wattage Cables:
BRITECH Terms of Limited Warranty (Summary):
This guarantee applies to Britech Self-Reg. and Constant
Watt. Cables: FT/PT/PSB/WINTER-MELT™ (5) ve years;
ST/AHT (2) two years
Britech warrants to the original purchaser only, that
the product is to be free of any defects in material or
workmanship (during warranty term as noted above) after
the date of purchase under proper and normal use of the
system. This guarantee is a material warranty only and does
not cover any labor or other installation cost. The warranty
does not cover installations made by unauthorized persons
or faults caused by incorrect design by others, misuse,
damage caused by others, damage in transit, incorrect
installation and any other subsequent damage that may
occur. Repair and/or replacement will be fully chargeable if
damage is result of any of the above reasons.
Britech is under no circumstances liable for any incidental,
special, or consequential damages or losses including
without limitation the loss or prot arising from any cause
whatsoever. To obtain a replacement under this warranty,
please send a description of the defect, proof of purchase,
and the damaged product, shipping paid to Britech at the
address noted herein. The warranty is void if there is any
payment default and if data is not lled-in on the control
card. www.britech.ca
