Briteq LD-SPLIT IP68 - INSTALLATION V1.0 User manual

Version: 1.0
LD-SPLIT IP68
ENGLISH
InstallationManual

85
129
40
91
109
115
Installation
A
B
C
D
E
Specification
The LD-SPLIT IP68 should be placed on a non-flammable
flat surface in any orientation and fixed by the two
screws.Therearetwomountingholesinthehousing.
Dimension: 129 x 91 x 40 mm
Weight: 0.15kg
Junction box for outdoor applications
IP 68

1. Unscrew all the screws (A), open the
right cover (B) and remove the gasket (C).
2. Connect wires to the PCB board (D) through
the water-proof input glands (E) as shown below.
3. Install the gasket (C) and the cover (B) back
firmly.
Brown
White + Brown
Green
White + Blue
Blue
White + Green
Orange
White + Orange
Brown
White + Brown
Green
White + Green
Blue
White + Blue
Orange
White + Orange
Please connect the units with lights as below:
LD-POWER
1 2 3
LD-POWER input
1

Brown
White + Brown
Green
White + Blue
Blue
White + Green
Orange
White + Orange
Brown
White + Brown
Green
White + Green
Blue
White + Blue
Orange
White + Orange
LED
2
3Out or Led Fixture
Brown
White + Brown
Green
White + Blue
Blue
White + Green
Orange
White + Orange
Brown
White + Brown
Green
White + Green
Blue
White + Blue
Orange
White + Orang
