Broadata 4890-SP-D-4S User manual

4890-SP-D-4S
DVISPLITTER
BCI reserves the right to make changes to the products described herein without
prior notice or consent. No liability is assumed as a result of their use or
application. All rights reserved.
©2010 Broadata Communications, Inc.

BCI4890-SP-D-4SUser’s Manual
DVISplitter
Broadata Technical Support, [email protected] 3
SAFETY INSTRUCTIONS AND
COMPLIANCE DECLARATIONS
PLEASEOBSERVETHEFOLLOWINGSAFETY
PRECAUTIONSASOUR PRODUCTSCONTAIN
CLASS I LASER PRODUCTS
WARNING
Do not disconnect the fiber optic connector while the unit is powered
up. Exposure to laser radiation is possible when the laser fiber optic
connector is disconnected while the unit is powered up.
Although the fiber optic connectors in this product emit only Class 1
energythatisbelowthe levels considered to be hazardous, oneshould
neverstaredirectlyintoafiberopticconnectororanunconnectedfiber
end unless one can be certain that no exposure to laser energy could
occur.
CAUTION
This manual is intended for use by trained service personnel. The use
of controls, making adjustments, or performing operations other than
those specified may result in hazardous radiation exposure.
Thefollowinglabelorequivalentislocatedonthesurfaceoflaserproducts.
Thislabelindicatesthat the product is classified as a CLASS 1 LASER
PRODUCT.
SURGEPROTECTION DEVICERECOMMENDED
This product contains sensitive electrical components that may be
damaged by electrical spikes, surges, electric shock, lightning strikes,
etc. Use of surge protection systems is highly recommended in order
to protect and extend the life of your equipment.
CLASS 1 LASER PRODUCT

BCI4890-SP-D-4SUser’s Manual
DVISplitter
Broadata Technical Support, [phone]
4
TABLE OF CONTENTS
1.0 PRODUCT DESCRIPTION .............................................5
2.0 OPERATION CONTROLS AND FUNCTIONS ...............5
3.0 CONNECTION AND INSTALLATION..............................6
4.0 SPECIFICATIONS............................................................7
5.0 SERVICE PROCEDURE .................................................8
5.1 REPLACEMENT POLICY ...............................................8
5.2 RETURN AND REPAIR SERVICE ...................................8
6.0 LIMITED WARRANTY ......................................................9

BCI4890-SP-D-4SUser’s Manual
DVISplitter
Broadata Technical Support, [email protected] 5
1.0 PRODUCT DESCRIPTION
BCI’s 4890-SP-D-4S is a high performance HDCP compliant DVI
distribution amplifier. It allows same DVI or HDMI signal source to split
uptofouridenticalandbuffereddisplaysformulti-viewingpurposes.The
4890-SP-D-4S has a built-in EDID and HDCP bypass that ensures
eachoutputcanbe displayed. HDMI sourceanddisplayare compatible
by using the HDMI to DVI adaptor cable. It supports a wide range of
PCandHDTVresolutionsfromVGAtoUXGAand480p to 1080p. This
4890-SP-D-4S can be cascaded up to 3 layers. Each of the buffered
output can run up to 15 meters.
2.0 OPERATION CONTROLS AND FUNCTIONS
Front Panel
1. DVI input: Connect to the DVI or HDMI output of your source
equipment such as DVD player or PC graphic card.
2. DVI output 1: Connect to the digital input of your first display.
3. Sync LED: The LED will illuminate when the source signal is
connected.
4. Powerinput:Plug the supplied5VDCpowersupply into theunit
and the LED will illuminate when connected.

BCI4890-SP-D-4SUser’s Manual
DVISplitter
Broadata Technical Support, [phone]
6
Rear Panel
1. DVI output 2/3/4: Connect these ports to the digital input of
each output display.
3.0 CONNECTION AND INSTALLATION

BCI4890-SP-D-4SUser’s Manual
DVISplitter
Broadata Technical Support, [email protected] 7
4.0 SPECIFICATIONS
FrequencyBandwidth 1.5Gbps (single link)
Input/Output 1-in/4-outDVIfemale port
PowerConsumption 6W max.
Power 5VDCUniversalPowerSupply
Physical
Dimension (H x W x D) 1.49” x 4.02” x 5.55”
OperatingTemperature 0 to +40oC
Humidity 30to80% RH, non-condensing

BCI4890-SP-D-4SUser’s Manual
DVISplitter
Broadata Technical Support, [phone]
8
5.0 SERVICE PROCEDURE
5.1 Replacement Policy
Standard products found defective on arrival (DOA) will be
replaced,basedonavailability,within 24 to 48hoursanywhere
in the U.S. Please call Customer Service at 800-214-0222 for
information.
5.2 Return/Repair Service
The BCI 4890-SP-D-4S System contains no user serviceable
components.Ifyouhaveaproblemwithyourunit,pleasecontact
theCustomer ServiceDepartment. Tofacilitateourreturn/repair
processing please contact Broadata Communications, Inc. to
obtain a Return MaterialAuthorization (RMA). Please include
thefollowinginformation:
• Productmodelnumber
• SerialNumber
• Completedescriptionofproblem
• Hardwareinstallationdescription
BroadataCommunications,Inc.
2545 West 237th Street, Suite K
Torrance,CA 90505
1-800-214-0222
[phone]
[phone](Facsimile)
e-mail:[email protected]
Website:www.broadatacom.com

BCI4890-SP-D-4SUser’s Manual
DVISplitter
Broadata Technical Support, [email protected] 9
6.0 LIMITED WARRANTY
BroadataCommunications,Inc.(BCI) warrants, for aperiodofone year
from date of shipment, each product sold shall be free from defects in
materialandworkmanship. BCIwillcorrect, either by repair, oratBCI’s
election, by replacement, any said products that in our sole discretion
prove to be defective and are returned to the manufacturing location
within30days aftersuchdefect isascertained. Allwarranties arelimited
todefects arising under normal use and do not include malfunctions or
failureresulting frommisuse,abuse,neglect,alterations, electricalpower
problems,usagenotinaccordancewithproductinstructions,improper
installation,ordamagedetermined by BCI to have been caused by the
Buyer or repair made by a third party. Limited warranties granted on
products are to the initial customer end-user and are not transferable.
OURLIABILITYUNDERTHISWARRANTYSHALLINANYCASEBE
LIMITEDTOTHE INVOICEVALUEOFTHEPRODUCTSOLDANDBCI
SHALL NOT BE LIABLE TO ANYONE FOR CONSEQUENTIAL OR
INCIDENTALDAMAGESARISINGFROMTHEUSEOFITSPRODUCTS
OR THE SALE THEREOF. We make NO WARRANTY AS TO THE
MERCHANTABILITYOFANYGOODS, ORTHATTHEYARE FITFOR
ANY PARTICULAR PURPOSE OR ENDAPPLICATION NOR DO WE
MAKE ANY WARRANTY, EXPRESSED OR IMPLIED OTHER THAN
AS STATEDABOVE.

BroadataCommunications,Inc.
2545 West 237th Street, Suite K
Torrance, CA 90505
1-800-214-0222
[phone]
[phone] (Facsimile)
e-mail:[email protected]
Website: www.broadatacom.com
60000-4890-SP-D-4S
