INTRODUCTION
INTRODUCTION
Thank you for your purchase of a Broadcast Tools® NTP Server Sentinel® GPS-
based time server (referred to as the NTP Server Sentinel® throughout this manual).
We’re confident that this product will give you many years of dependable service.
This manual is intended to give you all the information needed to install and oper-
ate the Broadcast Tools® NTP Server Sentinel®.
SAFETY INFORMATION
Only qualified technical personnel should install the NTP Server Sentinel®. Any
attempt to install this device by a person who is not technically qualified could result
in a hazardous condition to the installer or other personnel or damage to the NTP
Server Sentinel® or other equipment. Please ensure that proper safety precautions
have been taken before installing this device. If you are unfamiliar with this type of
equipment, please contact a properly qualified engineer to handle the installation
and setup of the NTP Server Sentinel®.
Broadcast Tools, Inc., is unable to support NON-Broadcast Tools software, hardware or
NON-Broadcast Tools computer/hardware/software problems. If you experience these
problems, please research your hardware/software instruction manuals or contact the man-
ufacturers technical support department.
WHO TO CONTACT FOR HELP
If you have any questions regarding your product or you need assistance, please con-
tact your distributor from whom you purchased this equipment.
If you would like more information about Broadcast Tools® products, you may
reach us at:
Broadcast Tools, Inc.
131 State Street
Sedro-Woolley, WA 98284-1503 USA
Voice: 360.854.9559
Fax: 866.783.1742
Internet Home Page: www.broadcasttools.com
E-mail: [email protected]
THANK YOU FOR CHOOSING
BROADCAST TOOLS® BRAND PRODUCTS!
CAUTION!
Broadcast Tools®
Products, as with any
electronic device, can
fail without warning.
Do not use this product
in applications where a
life threatening condition
could result due to failure.
NOTE:
This manual should be
read thoroughly before
installation and operation.
WEBSITE:
Visit our web site for
product updates and
additional information.
NTP Server Sentinel®Installation and Operation Manual
OVERVIEW
Product Overview
The NTP Server Sentinel® is a standalone "ready-to-run" GPS referenced NTP
time server offering a complete solution for synchronizing the time across TCP/IP
LANs using NTP. The NTP Server Sentinel® combines a GPS receiver with an embed-
ded web based controller and is configured and managed via a web browser. The mon-
itor and control web page displays date, time, locked satellite signal strength with mul-
tiple display features. The NTP Server Sentinel® can handle multiple requests per sec-
ond, making it the choice for providing accurate time information. The concept is as
simple as plugging the controller into the network, attaching the GPS receiver, config-
uring the unit and allowing any client to request “highly accurate” time.
Additional features include; three separate GPS time referenced outputs. The
first is a DPDT relay, which operates at 12:00, 22:00, 42:00, 54:30 each hour and is
user programmable in each of four storage locations for any minute and second each
hour. The second output is an active high driver with a 100 ms pulse each second,
while the third output provides an active high driver in the ESE TC89 or TC90 serial
time code format. Indicator LED's are provided to display; power, 1PPS activity, seri-
al time code activity and time sync relay operation. The NTP Server Sentinel® is sup-
plied with a Garmin GPS18 receiver, which tracks up to 12 satellites. The GPS-18 can
be positioned up to 100 feet away from the controller, using standard CAT5 cable. The
controller may be desk mounted or up to three units may be mounted on our RA-1, 1-
RU rack shelf. The controller is supplied with a domestic DC power supply.
Features/Benefits
• Ready-to-operate Stratum 1 NTP Time Server.
• Support for NTP and SNTP compatible clients.
• Configured across network via web browser.
• Upgradeable flash memory.
• RJ-45 Ethernet interfaces 10/100 base-T.
• Web based display for Time and Satellite Status.
• Standard CAT5 GPS receiver cable length up to 100 feet.
• TC 89 or TC90 serial time code output.
• 1-pulse-per-second output.
• User-programmable time sync relay.
• Email logging and error reporting
• Secure proprietary operating system for enhanced security
• One year warranty
Applications:
Standalone "ready-to-run" GPS referenced NTP time server.
TC89 or TC90 serial time code source.
Time sync closures for legacy systems.
Inspection
Please examine your NTP Server Sentinel® carefully for any damage that may have
been sustained during shipping. If any damage is noted, please notify the shipper
immediately and retain the packaging for inspection by the shipper. The package
should contain the NTP Server Sentinel®, a Garmin GPS18 LVC GPS receiver, this
manual and/or CD, 7 foot BLUE straight-through CAT 5 cable, 7 foot GRAY
crossover CAT 5 cable, and the 7.5 to 9.0 VDC wall transformer. Manuals may also
be downloaded from our web site.
NTP Server Sentinel®Installation and Operation Manual
INSTALLATION
Installation
The NTP Server Sentinel® interfaces to external equipment through removable
euroblock screw terminals. The terminals accommodate wire sizes from 16 - 28
AWG solid or stranded wire. Before installing a wire, remove the euroblock screw
terminal plug and turn each capture screw fully counterclockwise. Strip each con-
ductor to a length of 0.25” and insert the conductor fully into the terminal. Turn the
capture screw fully clockwise to secure the conductor.
Surge Protection
The NTP Server Sentinel® has built-in resistance to voltage changes; we recom-
mend that you use a power surge protector or line conditioner on the incoming AC
line. Lightning strikes and/or other high voltage surges may damage your NTP
Server Sentinel® and connected equipment if it is not properly protected. For light-
ning protection devices, check out www.polyphaser.com and www.itwlinx.com.
UPS Standby Power System
We recommend that you connect your NTP Server Sentinel® to a UPS system. A
UPS helps minimize the risk to the NTP Server Sentinel® and provides power dur-
ing a power outage.
DC POWER connector
This is the connector used to power the unit. Never use any type of power supply
other than the specified power supply.
“CHS GND” Chassis Ground
This is the chassis ground terminal. The station ground should be connected to the
chassis ground terminal using a 20 to 24-gauge wire.
“LAN/NET” network RJ45 connector
Connect one end of the supplied CAT5 (straight or crossover) cable to the desired
ETHERNET (WAN/LAN) or PC port.
“DEF” Defaults button
Hold down this button while powering the device up to reset the unit to defaults.
“1PPS” / “GND” One Pulse Per Second Output
The 1 PPS logic output provides an active high 100ms pulse per second. This out-
put may be used to drive clock systems.
“STC” / “GND” Serial Time Code Output
STC (Serial Time Code) active high driver logic output. Output format (ESE TC90
or TC89) and frequency (30 hz or 60hz) configurable from web interface. Also avail-
able on the BNC connector labeled “STC.”
CAUTION!
Installation of the NTP
Server Sentinel® in high
RF environments should
be performed with care.
The station ground
should be connected to
the designated chassis
ground terminal using a
20 to 24-gauge wire.
WEBSITE:
Visit our web site for
product updates and
additional information.
NTP Server Sentinel®Installation and Operation Manual
INSTALLATION
“TS-K1A / TS-K1B” Time Sync Relay
DPDT relay connections for use with devices that require contact closures for time
sync. Closures are configured from the web interface.
“GPS RCVR” RJ45 connector
Connect the supplied Garmin GPS18 LVC GPS receiver. The receiver must be
mounted in an area that has a clear, unobstructed view of the sky. If the attached 10-
foot cable isn’t an adequate length, you may attach an additional 100 feet of CAT 5
cable. The receiver is equipped with a metric M3 x 4mm threaded magnetic base,
use this to secure the receiver to a user provided mounting bracket. The receiver
may also be secured with a small strip of Velcro. Do not allow the receiver to sit in
water.
GPS Receiver RJ-45 pin-out:
Pin 1 = No connection
Pin 2 = Ground
Pin 3 = Ground
Pin 4 = GPS Receiver, receive data.
Pin 5 = GPS Receiver transmit data.
Pin 6 = GPS Receiver 1 PPS output.
Pin 7 = No connection
Pin 8 = Regulated +5 Vdc used to power the Garmin GPS-18 receiver
(100 ma max).
Front Panel Status Indicators
• Power: Lit when powered up.
• 1PPS: Blinks once per second when receiving valid GPS time data.
• STC: Flashes when serial time code output is enabled and active.
• TS-K1: Indicates time sync relay activity.
Please refer to the appendix for connector layouts.
NTP Server Sentinel®Installation and Operation Manual
OPERATION
Web Setup/Operation
Ethernet “Quick Start” guide
CAUTION! If you are not familiar with Ethernet enabled equipment, it may be use-
ful to contact your IT department, network administrator or network consultant for
help. Assigning an IP address already in use by another device may cause problems
with your network! Instructions for changing the IP address of the computer that
will be used for the configuration of this product are given here. Note that these
instructions are specifically for computers with the Windows XP operating system.
For setup using other operating systems, refer to the appropriate OS user’s manual.
Step 1:
Open the control panel by clicking on the start menu, click on settings, then click on
Control Panel. (Note that the control panel shown is in “Classic View”. If control
panel is in “Category View” select the “Classic View” option before proceeding.)
CAUTION!
NEVER DOWNLOAD
FIRMWARE UPDATES
OR CHANGES TO
THE XPORT WEB-
SERVER UNLESS
INSTRUCTED TO DO
SO BY BROADCAST
TOOLS®. DOING SO
DELETES ALL SOFT-
WARE AND VOIDS
ALL WARRANTIES
FROM BROADCAST
TOOLS, INC
NOTE:
We recommend using
the following browsers:
Firefox, Safari and/or
Chrome.
WEBSITE:
Visit our web site for
product updates and
additional information.
8
NTP Server Sentinel®Installation and Operation Manual
OPERATION
Step 2:
Double click on the icon labeled Network Connections. The following menu will
pop up.
Step 3:
Right click on the icon labeled Local Area Connection. Another menu will appear.
Select the option at the bottom of the menu labeled Properties. The Local Area
Connection Properties window will appear.
NTP Server Sentinel®Installation and Operation Manual
OPERATION
Step 4:
On the Local Area Connection Properties page, double click on Internet Protocol
(TCP/IP) to display properties.
Step 5:
Before making any changes to the network settings, write down the current settings
(or screen capture the page and print) so that they can be restored once the unit is
configured. Next, select the radio button labeled “Use the following IP address” and
type in the IP address 192.168.1.60. Type in the subnet mask of 255.255.255.0.
Leave the default gateway field blank. Click OK to apply the new settings.
WEBSITE:
Visit our web site for
product updates and
additional information.
NTP Server Sentinel®Installation and Operation Manual
OPERATION
Opening the LOGIN Web Page
1. Connect the supplied GRAY colored XOVER cable between the PC’s Ethernet
port and the products NETWORK RJ45’s jack.
2. Connect the supplied DC power supply to the product’s power jack labeled
Power. Verify that the green POWER LED and left “LINK” LED above the
“NET” Network RJ-45 are illuminated
3. Open the product’s login page by typing the following URL into the browser:
http://192.168.1.55 A username and password is required to change any param-
eter and are case sensitive.
Factory “Login” defaults: username: admin (lower case)
password: 1234
4. Once you are logged in, follow this manual for setup and/or operational infor-
mation.
NTP Server Sentinel®Installation and Operation Manual
OPERATION
WEBSITE:
Visit our web site for
product updates and
additional information.
“Login” Web Page
The Login screen displays the username and password entry points, Site ID, and
time/date.
After you have successfully logged in, the Monitor/Control page will be displayed.
Depending on your access level, you may or may not be able to control or modify
the product’s configuration.
NTP Server Sentinel®Installation and Operation Manual
OPERATION
“Monitor/Control” Web Page
The Monitor/Control page provides an overview of the current status of the NTP
server, and the GPS receiver. Allow at least 10 minutes for the receiver to get an ini-
tial location fix and acquire the required satellites for time sync.
Queued Logs: Displays the available number of queued logs.
PRN: Unique identification numbers used for GPS satellites.
SNR: Signal to noise ratio value. A higher number equals a higher signal
strength.
Elv: Calculated elevation of satellite (in degrees) relative to current GPS
fix location.
Az: Calculated azimuth of the satellite (in degrees) relative to current
GPS fix location.
GPS Status: Indicates current acquisition status of GPS receiver.
NTP Server: Indicates whether or not the NTP server service is enabled.
TCxx State: Shows current serial time code output format and status.
Latitude/Longitude: GPS fix location in (d)ddmm.mmm format.
Satellites In View: Number of GPS Satellites in view according to the current time and
GPS fix location.
Satellites Tracked: To select other pages (if authorized), make your selection under the
left hand Navigation column.
NOTE:
The user defined Site ID,
Time, Date and Queued
Logs are always dis-
played. Only “admin”
level access can edit
some of these items.
NTP Server Sentinel®Installation and Operation Manual
OPERATION
“User Setup” Web Page
Eight Usernames and Passwords may be configured for up to three access levels.
1. “admin” allows complete product configuration access and control.
2. “Monitor/Control” allows the following access:
About, Monitor/Control, Show log, Help, and Logout.
3. “Monitor Only” allows the following access:
About, Monitor only, Help, and Logout.
Values on this page can only be defined by users with “admin” access level, which
is the factory default.
The Site ID is displayed for the user convenience and can be changed on the
Email/Network Setup page.
NOTE:
After any item has been
changed, you MUST
press the “Save
Settings” button for
your changes to be
saved.
WEBSITE:
Visit our web site for
product updates and
additional information.
NTP Server Sentinel®Installation and Operation Manual
OPERATION
“Device Setup” Web Page
Email Addresses: Email messages can be sent when GPS lock is acquiring,
disconnected, or valid lock. Up to eight email address
assigned to using the checkboxes labeled 1-8.
Log GPS State Change: This enables the email logging of GPS lock status. See the
“Email/Network setup” page for email and logging settings.
Enable GPS Alarm:
TC Enabled: Enables or disables serial time code output.
TC Format: Allows you to set time code output to desired format. Either
TC89 or TC90.
TC Frequency: Sets serial time code operating frequency.
Relay Closure: This is used to control the units DPDT relay (TS-K1, TS-
K2) for external time sync applications. Up to four closures
per hour can be configured. Each closure can be pro-
grammed for any minute and any second of each hour.
Closures are configured at 12:00, 22:00, 42:00, and 58:30
by default. The closure duration can be between 100ms and
900ms in 100ms increments, the default is 500ms.
NOTE:
After any item has been
changed, you MUST
press the “Save
Settings” button for
your changes to be
saved.
NTP Server Sentinel®Installation and Operation Manual
OPERATION
“Email/Network Setup” Web Page
NTP Server Sentinel®Installation and Operation Manual
OPERATION
Restoring Network Factory Defaults
The NTP Server Sentinel® factory defaults may be restored by depressing the
recessed “DEF” push button on the back on the device for five seconds while pow-
ering up the unit.
“Email/Network Setup” Web Page – Device Network Settings
Device Address: Enter a static IP address here. Default: 192.168.1.55
Device Netmask: Enter the Netmask here: Default: 255.255.255.0
Gateway Address: Enter the Gateway IP here: Default: 192.168.1.1
DNS Server IP Address: Enter your DNS address here. Default: 192.168.1.1
HTTP Port: Normally Port 80 Default: 80
“Email/Network Setup” Web Page – SMTP Settings
SMTP Server Address: The user can enter either an IP address in the
xxx.xxx.xxx.xxx format or a URI in the form:
smtp.comcast.net. In order to resolve the URI, a work-
ing DNS server must be present or its IP address
entered into the system.
SMTP Port: Normally Port 25 Default: 25
SMTP Return Address: Enter your return email address here. If an email can-
not be delivered, a message stating why will be sent to
this address.
NOTE: The user must enter the following items before an email can be successful-
ly sent: SMTP Server Address, SMTP Port, SMTP Return Address, SMTP Host ID,
SMTP username and SMTP password must be supplied if authentication is turned on
and the Recipient Address 1. The test email is sent to email recipient address 1.
The user should press the “Save Settings” button after entering the SMTP informa-
tion before attempting an email test. If authentication fails, the email is not sent,
please ensure that the username and password is correct.
SMTP Host ID: Enter something here to identify the device.
SMTP Authentication: When checked, Base64 SMTP authentication is used.
SSL/TLS authentication is not supported.
WEBSITE:
Visit our web site for
product updates and
additional information.
NTP Server Sentinel®Installation and Operation Manual
OPERATION
“Email/Network Setup” Web Page
SMTP Username: Enter user name here.
SMTP Password: Enter password here.
“Email/Network Setup” Web Page – Email Logging Settings
Logging Email Address: IP address for the “Logging” email recipient
(may be different from the 8 “Alarm”
Recipient Addresses. Logging emails and
Daily emails are sent to this address.
Logging Email Snapshot Interval: The period in hours that a snapshot is taken of
the system when logging is enabled. An email
is not sent on this interval.
Logging Email Update Interval: The period in hours that the collected snap-
shots are emailed. This email may contain
multiple snapshots if the Snapshot Interval is
less than the Update Interval. Each snapshot
will be identified by the date and time.
“Email/Network Setup” Web Page – Email Alarm Settings
Email Alarms: Choose Immediate and/or Daily. If Immediate
is selected, then an email will be sent out as
soon as an alarm is generated. If Daily is
selected, then each alarm is queued and the
queued alarms are sent in accordance with the
Daily Alarm Email Time. The number of
queued alarms at any given time is displayed
on the Monitor/Control page.
Daily Alarm Email Time: The time that queued alarms are sent. Queued
alarms are sent to the Logging Email Address
only.
Recipient Address: Email addresses for up to 8 addresses. These
addresses correlate to the 8 email addresses
selectable on each I/O Setup page.
NTP Server Sentinel®Installation and Operation Manual
OPERATION
“Email/Network Setup” Web Page – SNMP Manager Settings
SNMP Manager IP Address: This is the IP address of the SNMP manager. The sys-
tem only accepts SNMP requests from this IP address,
and will send traps to this IP address only.
SNMP Manager Trap Port: Port number that SNMP trap messages will be sent.
SNMP Read Community: This is the community name for Read-Only access.
SNMP Write Community: This is the community name for Read-Write access.
SNMP Enable Traps: When checked, trap messages will be sent. When
Unchecked, no trap messages will be sent.
NOTE: A cold-start trap will be sent when the unit boots up if the SNMP Enable
Traps is checked, otherwise trap messages are sent when a device enters or exits an
alarm condition, depending on whether or not alarms are enabled.
“Email/Network Setup” Web Page – Other Settings
Site ID: This is the Site Identifier that will be sent in each
email an displayed on the web pages.
Monitor Refresh Time (Sec): Monitor/Control page refresh interval. Shorter times
may increase network traffic.
Time Zone Offset from UTC: Must be set for correct time on web interface.
Default: -8
Enable Event Logging: Enabling these checkboxes will generate an alarm, but
will not send an email. If the system is configured for
Daily Alarm emails, then that Daily Alarm email will
contain the Event Logging items as well.
Login: Whenever someone logs into the system, the user-
name and date/time will be logged.
Email: Whenever an email is sent, the type of email and
date/time will be logged.
Reboot: Whenever the device boots, the date/time will be
logged.
Alarms Cleared: Whenever the Daily Logs or Normal Alarms are
cleared, the type of log cleared and date/time will be
stored. When Daily Logs are sent, the Daily Logs are
also cleared; this will cause an event log as well.
WEBSITE:
Visit our web site for
product updates and
additional information.
NTP Server Sentinel®Installation and Operation Manual
OPERATION
“Email/Network Setup” Web Page – Controls
Save Settings: After pressing the “Save Settings” button, the device
will reboot (If you changed the IP address, you must
navigate your web browser to the new IP address (if
the HTTP port was changed from port 80, be sure to
add the new port number after the IP:
xxx.xxx.xxx.xxx:port #). If you didn’t change the IP
address, then the web page will return to the login
screen after the device reboots.
Reboot Device: When you press the “Reboot Device” button, the
device resets, you must navigate your web browser to
the new IP address.
Send Test Email: Press this button to send a test email to recipient #1.
When the email has completed, an alert box will pop-
up indicating the status of the email and an error con-
dition if the email was not sent correctly. If an email
was not sent correctly, please review your SMTP set-
tings and correct as necessary.
Reload Defaults: When you press the “Reload Defaults” button, the
device resets to factory default settings, you must nav-
igate your web browser to the new IP address (if the
HTTP port was changed from port 80, be sure to add
the new port number after the IP:
xxx.xxx.xxx.xxx:port #).
Clear Daily Logs: When you press the “Clear Daily Logs” button, the
daily logs stored in memory will be cleared. Keep in
mind that if the Alarms Cleared Event is enabled, this
event will post after the logs are cleared.
Send Daily Logs: When you press the “Send Daily Logs” button, the
system will send the daily logs email and then clear
those logs as ifthe correct time has expired.
NOTE:
After you are done mak-
ing changes to the
Email/Network Setup
page, you MUST press
the “Save Settings” but-
ton to save your
changes.
NTP Server Sentinel®Installation and Operation Manual
OPERATION
NOTE:
Adobe “Flash” must be
installed and operating
properly on your PC for
the “Alarm Sound” to
work when enabled.
“Show Alarms” Web Page
This page displays a log of current and past events/alarms.
With the “admin” access level, the user may control all functions.
With the “Monitor/Control” access level, the user may view the “Show Log”,
enable/disable PC speaker sound and silence alarms but they cannot Clear Alarms.
Table of contents
Other Broadcast Tools Server manuals
