Brocade Communications Systems VDX 6720 Quick user guide

53-1002084-01
7 December, 2010
®
Brocade VDX6720/6730
Hardware Reference Manual

Copyright © 2010 Brocade Communications Systems, Inc. All Rights Reserved.
Brocade, the B-wing symbol, BigIron, DCFM, DCX, Fabric OS, FastIron, IronView, NetIron, SAN Health, ServerIron, TurboIron and
Wingspan are registered trademarks, and Brocade Assurance, Brocade NET Health, Brocade One, Extraordinary Networks,
MyBrocade, and VCS are trademarks of Brocade Communications Systems, Inc., in the United States and/or in other countries.
All other brands, products, or service names are or may be trademarks or service marks of, and are used to identify, products or
services of their respective owners.
Notice: This document is for informational purposes only and does not set forth any warranty, expressed or implied, concerning
any equipment, equipment feature, or service offered or to be offered by Brocade. Brocade reserves the right to make changes to
this document at any time, without notice, and assumes no responsibility for its use. This informational document describes
features that may not be currently available. Contact a Brocade sales office for information on feature and product availability.
Export of technical data contained in this document may require an export license from the United States government.
Brocade Communications Systems, Incorporated
Document History
Corporate and Latin American Headquarters
Brocade Communications Systems, Inc.
130 Holger Way
San Jose, CA 95134
Tel: [phone]
Fax: [phone]
E-mail: inf[email protected]
Asia-Pacific Headquarters
Brocade Communications Systems China HK, Ltd.
No. 1 Guanghua Road
Chao Yang District
Units 2718 and 2818
Beijing 100020, China
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
European Headquarters
Brocade Communications Switzerland Sàrl
Centre Swissair
Tour B - 4ème étage
29, Route de l'Aéroport
Case Postale 105
CH-1215 Genève 15
Switzerland
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]
Asia-Pacific Headquarters
Brocade Communications Systems Co., Ltd. (Shenzhen WFOE)
Citic Plaza
No. 233 Tian He Road North
Unit 1308 – 13th Floor
Guangzhou, China
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
Document Title Publication Number Summary of Changes Date
Brocade VDX 6720/6730 Hardware Reference
Manual
53-1002084-01 New document December 2010

Brocade VDX 6720/6730 Hardware Reference Manual iii
53-1002084-01
Contents
About This Document
In this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
How this document is organized . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Supported hardware and software . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Document conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii
Text formatting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii
Command syntax conventions . . . . . . . . . . . . . . . . . . . . . . . . . . viii
Notes, cautions, and warnings . . . . . . . . . . . . . . . . . . . . . . . . . . viii
Key terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix
Notice to the reader . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix
Additional information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix
Brocade resources. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x
Other industry resources. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x
Getting technical help. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x
Document feedback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
Chapter 1 Brocade VDX 6720/6730 Introduction
In this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Brocade VDX 6720/6730 overview . . . . . . . . .. . . . . . . . . . . . . . . . . . 1
Platform components and capabilities. . . . . . . . . . . . . . . . . . . . . 1
VDX 6720/6730-24 features. . . . . . . . . . . . . . .. . . . . . . . . . . . . . 2
VDX 6720/6730-60 features. . . . . . . . . . . ... . . . . . . . . . . . . . . . 2
Software features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Views of the Brocade VDX 6720/6730-24 switch . . .. . . . . . . . . . . . . 3
Views of the Brocade VDX 6720/6730-60 switch. . .. . . . . . . . . . . . . 4
Chapter 2 Brocade VDX 6720/6730 Installation
In this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Items included with the Brocade VDX 6720/6730 switches . . . . . . 7
Installation and safety considerations. . . . . . . . . . . . . . . . . . . . . . . . . 7
Electrical considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Environmental considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Cabinet considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Recommendations for cable management . . . . . . . . . . . . . . . . . 8
Items required for installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Standalone installation for a Brocade VDX 6720/6730. . . . . . . . . . 9

iv Brocade VDX 6720/6730 Hardware Reference Manual
53-1002084-01
Rack installation for a Brocade VDX 6720/6730 . . . . . . . . . . . . . . 10
Providing power to the switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Verifying operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Chapter 3 Brocade VDX 6720/6730 Configuration
In this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Configuration modes for the Brocade VDX 6720/6730 . . . . . . . . . 11
Creating a serial connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Assigning permanent passwords . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Changing the default account passwords . . . . . . . . . . . . . . . . .12
Setting the switch IP address. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Using DHCP to set the IP address. . . . . . . . . . . . . . . . . . . . . . . . 13
Setting a static IP address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Setting stateless IPv6 autoconfiguration . . . . . . . . . . . . . . . . . . 14
Enabling and disabling Brocade VCS mode . . . . . . . . . . . . . . . . . . . 14
Enabling VCS mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Disabling VCS mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Setting the date and time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Understanding time zones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Understanding time synchronization . . . . . . . . . . . . . . . . . . . . . 16
Synchronizing local time using NTP . . . . . . . . . . . . . . . . . . . . . . 16
Setting the clock (date and time) . . . . . . . . . . . . . . . . . . . . . . . . 17
Setting time zones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Connecting network devices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Connecting to Ethernet or fast Ethernet hubs . . . . . . . . . . . . . . 18
Connecting to workstations, servers, or routers . . . . . . . . . . . . 18
Connecting a network device to a fiber port . . . . . . . . . . . . . . .18
Testing connectivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Creating Brocade inter-switch link trunks . . . . . . . . . . . . . . . . . . . . . 18
Chapter 4 Brocade VDX 6720/6730 Operation
In this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Powering on the Brocade VDX 6720/6730 . . . . . . . . . . . . . . . . . . 19
Powering off the Brocade VDX 6720/6730 . . . . . . . . . . . . . . . 19
LED activity interpretation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Brocade VDX 6720/6730 LEDs . . . . . . . . . . . . . . . . . . . . . . . . . 19
LED locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
LED patterns. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
POST and boot specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
POST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Boot. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Interpreting POST results . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Brocade VDX 6720/6730 Hardware Reference Manual v
53-1002084-01
Brocade VDX 6720/6730 maintenance . . . . . . . . . . . . . . . . . . . . .25
Installing an SFP or SFP+ transceiver . . . . . . . . . . . . . . . . . . . . 25
Diagnostic tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Brocade VDX 6720/6730 management . . . . . . . . . . . . . . . . . . . . . 27
Chapter 5 FRU Removal and Replacement Procedures
In this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Before beginning the installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Replacing a combined power supply and fan assembly in
a VDX 6720/6730-24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Time required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Items required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Replacing the power supply and fan assembly . . . . . . . . . . . . .32
Replacing a power supply FRU in a VDX 6720/6730-60 . . . . . . . . 33
Determining the need to replace a power supply . . . . . . . . . . .34
Time required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Items required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Replacing a power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Replacing a fan assembly in the VDX 6720/6730-60 . . . . . . . . . .36
Determining the need to replace a fan assembly . . . . . . . . . . . 37
Time required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Items required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Replacing a Brocade VDX 6720/6730-60 fan assembly . . . . . 37
Appendix A Brocade VDX 6720/6730 Specifications
In this appendix. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Weight and physical dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Facility requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Power supply specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Environmental requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
General specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Data transmission ranges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Memory specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Regulatory compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
FCC warning (US only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Germany . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
KCC statement (Republic of Korea) . . . . . . . . . . . . . . . . . . . . . .43
VCCI statement (Japan) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Power cords (Japan Denan). . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
BSMI statement (Taiwan) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
CE statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Canadian requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Laser compliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
RTC battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
Electrical safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

vi Brocade VDX 6720/6730 Hardware Reference Manual
53-1002084-01
Regulatory certifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Environmental regulation compliance . . . . . . . . . . . . . . . . . . . . . . . .46
China RoHS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Environmental protection use period (EPUP) disclaimer. . . . . .46
TS/HS dual language sheet . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Index

Brocade VDX 6720/6730 Hardware Reference Manual vii
53-1002084-01
About This Document
In this chapter
•How this document is organized . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
•Supported hardware and software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
•Document conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii
•Notice to the reader . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix
•Additional information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix
•Getting technical help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x
•Document feedback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
How this document is organized
This document is organized to help you find the information that you want as quickly and easily as
possible.
The document contains the following components:
•Chapter 1, “Brocade VDX 6720/6730 Introduction” provides an overview of the Brocade VDX 6720
/6730 switch.
•Chapter 2, “Brocade VDX 6720/6730 Installation” provides the information needed to install the
switch into your network.
•Chapter 3, “Brocade VDX 6720/6730 Configuration” lays out the tasks and commands necessary to
get the switch up and running.
•Chapter 4, “Brocade VDX 6720/6730 Operation” discusses the day-to-day operational procedures for
using the switch.
•Chapter 5, “FRU Removal and Replacement Procedures” provides procedures for removing
and replacing the field-replaceable units (FRUs), including the fan assemblies and power
supplies.
•Appendix A, “Brocade VDX 6720/6730 Specifications” provides tables of physical, environmental,
and general specifications.
Supported hardware and software
This document is specific to the Brocade VDX 6720/6730-24 and the Brocade VDX 6720/6730-60 under
Network OS v2.0.0.

viii Brocade VDX 6720/6730 Hardware Reference Manual
53-1002084-01
Document conventions
This section describes text formatting conventions and important notice formats used in this
document.
Text formatting
The narrative-text formatting conventions that are used are as follows:
bold text Identifies command names
Identifies the names of user-manipulated GUI elements
Identifies keywords and operands
Identifies text to enter at the GUI or CLI
italic text Provides emphasis
Identifies variables
Identifies paths and Internet addresses
Identifies document titles
code text Identifies CLI output
Identifies command syntax examples
For readability, command names in the narrative portions of this guide are presented in mixed
lettercase: for example, show media. In actual examples, command lettercase is often all
lowercase. Otherwise, this manual specifically notes those cases in which a command is case
sensitive.
Command syntax conventions
Command syntax in this manual follows these conventions:
Notes, cautions, and warnings
The following notices and statements are used in this manual. They are listed below in order of
increasing severity of potential hazards.
command Commands are printed in bold.
--option, option Command options are printed in bold.
-argument, arg Arguments.
[ ] Optional element.
variable Variables are printed in italics. In the help pages, values are underlined or
enclosed in angled brackets < >.
... Repeat the previous element, for example “member[;member...]”
value Fixed values following arguments are printed in plain font. For example,
--show WWN
| Boolean. Elements are exclusive. Example: --show -mode egress | ingress

Brocade VDX 6720/6730 Hardware Reference Manual ix
53-1002084-01
NOTE
A note provides a tip, guidance or advice, emphasizes important information, or provides a reference
to related information.
ATTENTION
An Attention statement indicates potential damage to hardware or data.
CAUTION
A Caution statement alerts you to situations that can be potentially hazardous to you.
DANGER
A Danger statement indicates conditions or situations that can be potentially lethal or extremely
hazardous to you. Safety labels are also attached directly to products to warn of these conditions
or situations.
Key terms
For definitions specific to Brocade and Fibre Channel, see the Brocade Glossary.
For definitions of SAN-specific terms, visit the Storage Networking Industry Association online
dictionary at:
http://www.snia.org/education/dictionary
Notice to the reader
This document may contain references to the trademarks of the following corporations. These
trademarks are the properties of their respective companies and corporations.
Additional information
This section lists additional Brocade and industry-specific documentation that you might find
helpful.
Corporation Referenced Trademarks and Products
Microsoft Corporation Windows, Windows NT, Internet Explorer
Sun Microsystems, Inc. Sun, Solaris
Netscape Communications Corporation Netscape
Red Hat, Inc. Red Hat, Red Hat Network, Maximum RPM, Linux Undercover
Velcro Industries B.V. Velcro

xBrocade VDX 6720/6730 Hardware Reference Manual
53-1002084-01
Brocade resources
To get up-to-the-minute information, go to http://my.brocade.com to register at no cost for a user ID
and password.
For practical discussions about SAN design, implementation, and maintenance, you can obtain
Building SANs with Brocade Fabric Switches through:
http://www.amazon.com
White papers, online demos, and data sheets are available through the Brocade Web site at:
http://www.brocade.com/products-solutions/products/index.page
For additional Brocade documentation, visit the Brocade Web site:
http://www.brocade.com
Release notes are available on the MyBrocade web site and are also bundled with the Network OS
firmware.
Other industry resources
For additional resource information, visit the Technical Committee T11 Web site. This Web site
provides interface standards for high-performance and mass storage applications for Fibre
Channel, storage management, and other applications:
http://www.t11.org
For information about the Fibre Channel industry, visit the Fibre Channel Industry Association Web
site:
http://www.fibrechannel.org
Getting technical help
Contact your switch support supplier for hardware, firmware, and software support, including
product repairs and part ordering. To expedite your call, have the following information available:
1. General Information
•Switch model
•Switch operating system version
•Error numbers and messages received
•Support save output
•Detailed description of the problem, including the switch or fabric behavior immediately
following the problem, and specific questions
•Description of any troubleshooting steps already performed and the results
•Serial console and Telnet session logs
•syslog message logs
2. Switch Serial Number

Brocade VDX 6720/6730 Hardware Reference Manual xi
53-1002084-01
The switch serial number and corresponding bar code are provided on the serial number label,
as illustrated below.:
The serial number label is located as follows:
•Brocade VDX 6720/6730 — On the switch ID pull-out tab located on the bottom of the port side
of the switch
Document feedback
Quality is our first concern at Brocade and we have made every effort to ensure the accuracy and
completeness of this document. However, if you find an error or an omission, or you think that a
topic needs further development, we want to hear from you. Forward your feedback to:
[e-mail]
Provide the title and version number of the document and as much detail as possible about your
comment, including the topic heading and page number and your suggestions for improvement.
*FT00X0054E9*
FT00X0054E9

xii Brocade VDX 6720/6730 Hardware Reference Manual
53-1002084-01

Brocade VDX 6720/6730 Hardware Reference Manual 1
53-1002084-01
Chapter
1
Brocade VDX 6720/6730 Introduction
In this chapter
•Brocade VDX 6720/6730 overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
•Views of the Brocade VDX 6720/6730-24 switch . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
•Views of the Brocade VDX 6720/6730-60 switch . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Brocade VDX 6720/6730 overview
The Brocade VDX 6720/6730 switches are a pair of 10 GbE line-rate, low latency, lossless Data Center
Bridging (DCB) switches: the VDX 6720/6730-24 (a 24-port, single height switch) and the VDX 6720-60
(a 60-port double height switch). The Brocade VDX 6720/6730 switches run on the Brocade Network
Operating System (Network OS) v2.0.0. For details about Network OS, refer to the Brocade Network
OS Administrator’s Guide.
A key feature of the Brocade VDX 6720/6730 switches is Brocade VCS™ technology, which includes
virtual cluster switching, a new set of technologies that allows users to create flatter, virtualized,
and converged data center networks. VCS fabrics are scalable, permitting users to expand at their
own pace, and simplified to allow users to manage the fabric as a single entity. VCS-based Ethernet
fabrics are convergence-capable, enabling Fibre Channel over Ethernet (FCoE) storage.
The Brocade VDX 6720/6730 switches offer Ports on Demand (POD) licensing as well. “Base” models of
the switches contain 16 ports (for the VDX 6720-24) or 40 ports (for the VDX 6720-60). Additional
ports can be licensed via POD. One POD license on the VDX 6720-24 allows the additional 8 ports
to be activated. For the VDX 6720-60, two POD licenses (for 10 ports each) can be purchased.
Platform components and capabilities
The Brocade VDX 6720/6730 switches offer the following common features and capabilities:
•A system motherboard that features a Reduced Instruction Set Computer (RISC) CPU running
at 1.3 GHz with integrated peripherals
•An RJ45 10/100/1000 Ethernet out-of-band management port
•An RJ45 10/100/1000 Ethernet port for RLO
•An RJ45-fronted serial (RS-232) port for terminal access
•A USB port for firmware upgrades and system log downloads
•Support for long-range and short-range SFP+ transceivers
•Support for optical cables and active twin axial (twinax) copper cables
•Support for inter-switch link (ISL) trunking
•A rack-mount design using existing rail kits (fixed and mid-mount or Telco rail kits) on a 19-inch
EIA rack, also suitable for reduced-depth racks

2Brocade VDX 6720/6730 Hardware Reference Manual
53-1002084-01
Brocade VDX 6720 overview
1
•Extensive diagnostics and system-monitoring capabilities for enhanced high Reliability,
Availability, and Serviceability (RAS)
•Optimized airflow - a choice of front-to-back or back-to-front flow
•A real-time clock (RTC) with battery
•SEEPROM for switch identification
•Voltage monitoring
•Fan monitoring
•Three temperature sensors
•I2C interface to monitor and control environmental aspects
•Supports both regular transceiver plus cable arrangements or direct-attach cables (copper or
optical fiber)
VDX 6720/6730-24 features
•1U form factor enclosure
•24 10GbE SFP+ ports (also configurable to 1 GbE)
•One forwarding ASIC
•600 nanosecond (ns) port-to-port latency
•15-inch depth
•Dual, hot-swappable 250W AC power supplies with three integrated cooling fans each
VDX 6720/6730-60 features
•2U form factor enclosure
•60 10GbE SFP+ ports (also configurable to 1 GbE)
•Nine forwarding ASICs arranged in a 3/6, core/edge configuration
•600ns port-to-port latency, 1.8μs across port groups
•17-inch depth
•Dual, redundant, hot-swappable 500W AC power supplies
•Triple, hot-swappable cooling fans
Software features
The Brocade VDX 6720/6730 switches support the following features. For more details on these
features, refer to the Brocade Network OS Administrator’s Guide.
Layer 2/Layer 3 security features
•VLANs
•Spanning Tree Protocol(STP, RSTP, MSTP) PVST+/PVRST+
•Support Unicast and multicast capabilities, IGMP snooping
•Layer 2 multi-path based on Transparent Interconnection of Lots of Links (TRILL)
•Layer 2 access control lists (ACLs)

Brocade VDX 6720/6730 Hardware Reference Manual 3
53-1002084-01
Views of the Brocade VDX 6720-24 switch 1
•Switch Port Analyzer (SPAN), also known as port mirroring
Virtualization
•Automatic Migration of Port Profiles (AMPP)
•Support for VLAN, QoS, security, and FCoE port profiles
Convergence/FCoE
•Pause Frames(Tx and Rx)
•DCB features such as Priority Flow Control (PFC) and Enhanced Transmission Selection (ETS)
•End-to-end, multi-hop FCoE
Link aggregration
•802.3ad LACP support
•Virtual Link Aggregation Group (vLAG) – LAG that spans multiple physical switches
QoS
•802.1p marking
•Eight hardware queues per port
•Scheduling: Strict priority (SP), Shaped Deficit Weighted Round-Robin (SDWRR)
Management
•IPv4 or IPv6 management
•CLI management utilities available on Network OS 2.0.0
•Out-of-band management (VCS mode)
•sFlow
•TRILL Operations, Administration, and Management (OAM)
Licensing
•VCS licensing: available multi-node license up to 10 nodes
•Ports on Demand (POD):
-Single POD of 8 ports on VDX 6720/6730-24
-Two sets of 10-port PODs on VDX 6720/6730-60
•FCoE licensing
Views of the Brocade VDX 6720/6730-24 switch
The port side of the Brocade VDX 6720-24 switch includes the system LEDs, management ports
and LEDs, USB port, and Gigabit Ethernet (GbE) ports and the corresponding port status LEDs.

4Brocade VDX 6720/6730 Hardware Reference Manual
53-1002084-01
Views of the Brocade VDX 6720-60 switch
1
Figure 1 shows the port side of the Brocade VDX 6720 -24.
FIGURE 1 Port side view of the Brocade VDX 6720-24
Figure 2 shows the non-port side of the Brocade VDX 6720-24, which contains the combined power
supply and fan assemblies.
FIGURE 2 Non-port side view of the Brocade VDX 6720-24
Views of the Brocade VDX 6720-60 switch
The port side of the Brocade VDX 6720-24 switch includes the system LEDs, management ports
and LEDs, USB port, and Gigabit Ethernet (GbE) ports and the corresponding port status LEDs.
1 Switch ID pull-out tab 5 Ethernet management port (RJ45)
2 System power LED 6 RLO management port (RJ45)
3SystemstatusLED 7USBport
4 Serial console port (RJ45) 8 GbE ports 1 through 24 with status
LEDs above
1 Power supply and fan assemby #2 5 Handle
2 Power cord receptacle 6 Airflow label
3 Power supply and fan status LED 7 Captive screw
4 On/off switch 8 Power supply and fan assembly #1
35 7
1
2
468
237
15
48
6

Brocade VDX 6720 Hardware Reference Manual 5
53-1002084-01
Views of the Brocade VDX 6720-60 switch 1
Figure 3 shows the port side of the Brocade VDX 6720 -60.
FIGURE 3 Port side view of the Brocade VDX 6720-60
Figure 4 shows the non-port side of the Brocade VDX 6720-60, which contains the power supplies
and cooling fan assemblies.
FIGURE 4 Non-port side view of the Brocade VDX 6720-60
1 Switch ID pull-out tab 5 Ethernet management port (RJ45)
2 Serial console port (RJ45) 6 RLO management port (RJ45)
3SystempowerLED 7USBport
4 System status LED 8 GbE ports 1 through 60 with status
LEDs above and below
1 Power supply status LED 8 Fan assembly #1
2 Power supply #2 9 Power supply #1
3 Power cord receptacle 10 Fan captive screw
4 Power supply airflow label 11 Fan assembly airflow label
5 Fan assembly #3 12 Fan status LED
6 Fan handle 13 Power supply captive screws
7 Fan assembly #2
4
3 2 1
5678
12 5 78 9
63 4
13 10 1112

6Brocade VDX 6720/6730 Hardware Reference Manual
53-1002084-01
Views of the Brocade VDX 6720-60 switch
1

Brocade VDX 6720/6730 Hardware Reference Manual 7
53-1002084-01
Chapter
2
Brocade VDX 6720/6730 Installation
In this chapter
•Items included with the Brocade VDX 6720/6730 switches . . . . . . . . . . . . 7
•Installation and safety considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
•Standalone installation for a Brocade VDX 6720/6730 . . . . . . . . . . . . . . . . 9
•Rack installation for a Brocade VDX 6720/6730 . . . . . . . . . . . . . . . . . . . . 10
•Providing power to the switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
•Verifying operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Items included with the Brocade VDX 6720/6730 switches
The following items are included with the standard shipment of a fully-configured Brocade VDX
6720. When you open the Brocade VDX 6720 packaging, verify that the items are included in the
package and that no damage has occurred during shipping.
•The Brocade VDX 6720 switch, either the 24-port or 60-port version
•One accessory kit, containing the following items:
-Serial cable with an RJ45 connector
-6 ft. power cords
-Rubber feet, required for setting up the switch as a standalone unit
-Brocade Family Documentation CD
-Brocade VDX 6720/6730 QuickStart Guide
Installation and safety considerations
You can install a Brocade VDX 6720 switch in the following ways:
•As a standalone unit on a flat surface.
•In an EIA cabinet using a fixed-rail rack mount kit. The optional fixed-rail rack mount kit can be
ordered from your switch retailer.
•In an Telco rack using an flush mount rack kit. The optional flush mount rack kit for switches
can be ordered from your switch retailer.
•In the Idataplex IBM 17-inch depth rack (requires an Idataplex rack mount kit).
Electrical considerations
To install and operate the switch successfully, ensure compliance with the following requirements:

8Brocade VDX 6720/6730 Hardware Reference Manual
53-1002084-01
Installation and safety considerations
2
•The primary outlet is correctly wired, protected by a circuit breaker, and grounded in
accordance with local electrical codes.
•The supply circuit, line fusing, and wire size are adequate, as specified by the electrical rating
on the switch nameplate.
•The power supply standards are met. Refer to Table 10 on page 40, for more information.
Environmental considerations
For successful installation and operation of the switch, ensure that the following environmental
requirements are met:
•Because the Brocade VDX 6720/6730 switches can be ordered with fans that either move air front to
back or back to front, be sure to orient your switch with the airflow pattern of any other devices
in the rack.
•All equipment in the rack should force air in the same direction to avoid intake of exhaust air.
•A maximum of 102 cubic meters/hour (60 cubic feet/minute) and a minimum of 74.8 cubic
meters/hour (44 cubic feet/minute) of airflow is available to the air intake vents.
•The ambient air temperature does not exceed 40°C (104°F) while the switch is operating.
Cabinet considerations
For successful installation and operation of the switch in a cabinet, ensure the following cabinet
requirements are met:
•The cabinet must be a standard EIA cabinet.
•The cabinet space is one rack unit or two rack units high depending on the platform ordered
(1U for VDX 6720-24 or 2U for VDX 6720-60); 4.45 cm (1.75 in.) or 8.90 cm (3.50 in.) high and
48.3 cm (19 in.) wide.
•The equipment in the cabinet is grounded through a reliable branch circuit connection and
maintains ground at all times. Do not rely on a secondary connection to a branch circuit, such
as a power strip.
•Airflow and temperature requirements are met on an ongoing basis, particularly if the switch is
installed in a closed or multicabinet assembly.
•The additional weight of the switch does not exceed the cabinet’s weight limits or unbalance
the cabinet in any way.
•The cabinet is secured to ensure stability in case of unexpected movement, such as an
earthquake.
Recommendations for cable management
The minimum bend radius for a 50 micron cable is 5.1 cm (2 in.) under full tensile load and 3.0 cm
(1.2 in.) with no tensile load.
Cables can be organized and managed in a variety of ways; for example, use cable channels on the
sides of the cabinet or patch panels to reduce the potential for tangling the cables. The following
list provides some recommendations for cable management:
