SIDE BURNER OWNER’SMANUAL
MODEL DPSBSS
(NATURAL OR PROPANE)
RETAIN OWNER’SMANUAL FOR FUTURE REFERENCE.
B100027-0-0202
FOR USE WITH BROILMASTER®PREMIUM GAS GRILLS

Page 2 DPSBSS
THIS GAS APPLIANCE IS DESIGNED FOR OUTDOOR USE ONLY
WARNING
REFERENCE THIS MANUAL FOR PROPER INSTALLATION AND MAINTENANCE INSTRUCTIONS. IMPROPER
INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE OR MAINTENANCE CAN CAUSE PERSONAL INJURY OR
PROPERTY DAMAGE. FOR ASSISTANCE OR ADDITIONAL INFORMATION CONSULT AQUALIFIED INSTALLER,
SERVICE AGENCY OR THE GAS SUPPLIER.
CAUTION: FOR YOUR SAFETY
IF YOU SMELL GAS: 1. SHUT OFF GAS TO THE APPLIANCE.
2. EXTINGUISH ANY OPEN FLAME.
3. OPEN THE GRILL LID.
4. IFODOR CONTINUES, IMMEDIATELY CALL YOUR GAS SUPPLIER OR
FIRE DEPARTMENT.
5. DONOT TOUCH ELECTRICAL SWITCHES.
CAUTION: FOR YOUR SAFETY
1. DONOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS AND LIQUIDS IN THE VICINITY OF
THIS OR ANY OTHER APPLIANCE.
2. ANLP CYLINDER NOT CONNECTED FOR USE SHALL NOT BE STORED IN THE VICINITY OF THIS OR ANY
OTHER APPLIANCE.
CAUTION:
PARTS MAY HAVE SHARP EDGES. WEAR LEATHER WORK GLOVES AND HANDLE PARTS CAREFULLY DURING
THE UNPACKING, ASSEMBLY AND THE INSTALLATION.
WARNING
BROILMASTER SIDE BURNERS EQUIPPED FOR PROPANE GAS MUST ONLY USE PROPANE CYLINDERS
EQUIPPED WITH AN OVERFILL PROTECTION DEVICE (OPD). USE ONLY AREPUTABLE PROPANE DEALER
WHEN EXCHANGING OR FILLING CYLINDERS. ANOVERFILLED OR IMPROPERLY FILLED PROPANE CYLINDER
CAN BE DANGEROUS.
IMPORTANT
THIS MANUAL SHOULD BE READ THOROUGHLY BY THE PERSON INSTALLING THE SIDE BURNER AND ALL
PERSONS WHO WILL USE AND MAINTAIN THE SIDE BURNER. THE INSTALLER SHOULD BE SURE THE MANUAL
IS LEFT IN THE POSSESSION OF THE USER. THE USER SHOULD RETAIN THIS MANUAL FOR FUTURE REFERENCE
WHEN USING OR CLEANING THE SIDE BURNER AND TO PROPERLY IDENTIFY ANY REPAIR PARTS THAT MAY
BE REQUIRED.

Page 3DPSBSS
TABLE OF CONTENTS
C22
PartsDiagram...............................................................................................................................4
Parts List ......................................................................................................................................5
Side Burner Assembly...............................................................................................................6-7
Propane Gas Connection........................................................................................................
8-10
Natural Gas Connection........................................................................................................ 11-12
Operation and Maintenance.......................................................................................................13
Gas Leaks...............................................................................................................................
13
Operation...................................................................................................................................13
Notes........................................................................................................................................14-15
CONGRATULATIONS!
You have chosen the finest side burner for your outdoor cooking pleasure. Please take time
to read this entire manual before assembling your premium Broilmaster® gas side burner.
Your Broilmaster®Side Burner is identified by model number, serial number, and gas
type. This information is provided on a product identification label located on the Side
Burner. The grill’s model number, serial number, and gas type must also be provided
whencontactingyour Broilmaster®dealer. Foryourconvenience, complete this section
forfuturereferencewhencontactingyourdealer.
Grill Information
ModelNo. Dealer
SerialNo. Dealer Phone No.
GasType: Propane Natural Date of Purchase
Side Burner Information
ModelNo. DPSBSS Dealer
SerialNo. Dealer Phone No.
GasType: Propane Natural Date of Purchase

Page 4 DPSBSS
PARTS DIAGRAM
SIDE BURNER EXPLODED VIEW

Page 5DPSBSS
4
All repair part orders should be placed through your local Broilmaster®dealer. To locate a dealer in your
area, contact Broilmaster Customer Service at 800-851-3153 •WWW.broilmaster.com. To ensure prompt and
accurate service, please provide the following information when placing a repair part order: Model number
of your Side Burner, Part Name, Part Number, and Quantity of parts needed.
PARTS LIST
Key
No. Part Name Qty. Part Number
1 Bumper 2 B100103
2 10 X 3/8 Screw 2 B053779
3 Cooking Grid 1 B070100
4 Control Panel Label 1 B072698
5 Ignitor Ground Wire 2 B072684
6 Valve 1 B070483
7 Valve Knob 1 B070084
8 Electronic Ignitor 1 B072218
9 10-24 X 3/8 Screw 2 B100130
10 Tie-Down Bracket 1 B070081
11 Ignitor Ground Lug 1 B069747
12 9/32 Flat Washer 1 B100136
13 10-24 Wing Nut 1 B100125
14 Handle 1 B059229
15 Side Burner Lid 1 B076984
16 Side Burner Body 1 B076985
17 1/4-20 X 3/4 Phillips Truss Screw 1 B072217
18 Orifice (LP) No. 89 1 B100226
18 Orifice (NAT) No. 173 1 B073270
19 Burner Complete (Includes 18, 25, 26, 27) 1 B100278
20 Tee Fitting 1 B070323
21 Mounting Plate 1 B070142
22 Side Burner S/S Flex Line 10" 1 B070487
23 Side Burner S/S Flex Line 34" 1 B070289
24 Manifold Tube 1 B070108
25 Burner Cap 1 B070584
26 Ring (LP Only) (Not SHown) 1 B073953
27 Burner (Not Shown) 1 B100227
28 Handle Shelf Bracket 1 B073100

Page 6 DPSBSS
Igniter Assembly
Attachone end ofthe igniter wire(5) totheopen terminal
on the back of the electronic igniter.
Install AAAlkaline battery
SIDE BURNER ASSEMBLY
Instructions
All Broilmaster®side burners require some assembly
and installation. Certain instructions may not apply
toyourmodelofside burner. Thisside burner requires
the same gas type (natural or liquid propane) as your
Broilmaster®gas grill. Your side burner is factory
equipped for LP gas. Natural gas conversion
instructions are located in the Natural Gas section of
this manual.
Please locate and follow in listed order only the
instructions for assembly and installation of the
correctgastype. Skip anysectionsthat do notpertain
to the side burner model you have purchased.
PreAssembly
Every assembly and installation instruction includes
detailed illustrations to aid in assembly.
Comparethematerialsfound in theshippingcontainer
tothe partslist provided. Everyefforthas beenmade
to ensure the correct parts have been provided. In
the event of an error, please contact your local
Broilmaster®dealer regarding the replacement of
missing parts.
The following items are needed for the assembly of
your side burner:
Phillips screwdriver
Two adjustable wrenches
Soapy water solution (to test for leaks)
Grill Pull Handle
Attach the pull handle to the right side of the grill as
illustrated in Figure 1. Place two bolts into holes in
pull handle and through holes on right sides of grill
bottom. Fasten each bolt with a washer, lock washer
and nut.
Positioning Side Burner
Slide side burner right side up onto right grill pull handle.
Attach with one 1/4-20 x 3/4 screw (17). FIGURE 3.
FIGURE 3
FIGURE 2
-
+
Burner (21)
Electronic
Igniter (8)
AA Alkaline
Battery
Igniter Wire (5)
17
FIGURE 1

Page 7DPSBSS
Mounting Side Burner
Insert the notched end of the tie-down bracket
(10)into theslotonthe mountingplate(21). Push
the other end of the tie-down bracket onto the
screw. Fasten with an igniter ground lug (11), a
washer (12) and wing nut (13). FIGURE 4.
SIDE BURNER ASSEMBLY
Lid Handle
Attach the lid handle (14) to the side burner lid
(15) using two phillips head self-tapping screws
(2). FIGURE 6.
Attachthe igniter groundwire (5)onto the igniter
ground lug (11) terminal. FIGURE 5.
Tie-Down
Bracket (10)
Mounting
Plate (23)
13
12
11
FIGURE 4
FIGURE 5
Igniter
Ground Wire (5)
11
Cooking Grid
Position the cooking grid (3) over the burner as
shown by FIGURE 7.
Lid (15)
Handle (14)
FIGURE 6
FIGURE 7
Cooking Grid (3)

Page 8 DPSBSS
Gas Type
Your Broilmaster®sideburnerisfactory equipped
for LP gas. Natural gas conversion instructions
are located in the Natural Gas section of this
manual. Never use liquid propane gas with a grill
designedfornaturalgas,ornaturalgas with a grill
designed for liquid propane gas. The type gas
required for your grill can be determined from its
product identification label. Questions regarding
differenttypesofgasesshouldbedirectedtoyour
gassupplier.
PROPANE GAS CONNECTION
Side Burner Location
Yourgrillandsideburner have been designed for
outdoor use ONLY.
This side burner mounts on the right side of a
Broilmaster®gas grill and cannot be used with
another grill or for any other purpose.
You should never install or operate your grill and
side burner in any building, garage, or other
enclosedarea.
For your safety, the grill and side burner
shouldnot be installedor operatedunderany
combustible materials, such as carports,
covered porches, awnings, or overhangs.
Neverinstallor use yourgrilland sideburner
in or on any recreational vehicle or boat.
A minimum clearance of sixteen (16") inches is
required from all sides of the side burner to any
combustible material. Refer to the grill’s Owner’s
Manual for specific grill clearances.
Examples of combustible materials are patio
furniture, fences, or the wall of your home.
The area surrounding the grill and side burner
should be clear to ensure proper ventilation. Do
notobstructthe flow of combustion andventilation
air in any way. The ventilation openings on the
propanecylinderenclosuremustalsoremainfree
and clear of debris.
Portable grills with side burners should be level
andpositionedaway from directwindpriortoeach
use.
CAUTION: THE INSTALLATION AND OPERATION OF
THIS GRILL AND SIDE BURNER AT CLEARANCES LESS
THAN SPECIFIED BELOW MAY CAUSE AFIRE, PROPERTY
DAMAGE,OR PERSONAL INJURY.
WARNING: DONOT INSTALL OR OPERATE THIS
GRILL AND SIDE BURNER WHERE GASOLINE OR OTHER
FLAMMABLE MATERIALS ARE USED OR STORED. FAILURE
TO COMPLY WITH THIS WARNING COULD RESULT IN
EXPLOSION OR FIRE CAUSING PROPERTY DAMAGE OR
PERSONAL INJURY.
CAUTION: DONOT USE APROPANE GAS CYLINDER
WHICH HAS ACAPACITY GREATER THAN TWENTY (20)
POUNDS WITH THIS GRILL AND SIDE BURNER.
Cylinder Requirements
Your Broilmaster®Premium Gas Grill requires a
standardtwenty(20)poundpropanegascylinder.
The propane gas cylinder used must be:
1. constructed and marked in accordance with the
specifications for LP gas cylinder of the U.S.
Department of Transportation (D.O.T.) or the
National Standard of Canada, CAN/CSA-B339,
Cylinders,Spheres, andTubes forTransportation
of Dangerous Goods; and Commission as
applicable.
2. providedwitha listedoverfillingprotection device
(OPD).
3. provided with a listed safety device having direct
access with the vapor space of the cylinder and
the cylinder supply system must be arranged
for vapor removal.
4. provided with a shutoff valve terminating in a
valve outlet as specified in the Standard for
Compressed Gas Cylinder Outlet and Inlet
Connections, ANSICGA-V-1.
5. provided with a plug to effectively seal off the
cylinder outlet when the cylinder is being stored
or transported.
6. provided with a collar to protect the cylinder
valve.

Page 9DPSBSS
Propane Cylinder Safety
Liquid propane gas has a long history of safe use
when the safety precautions provided in this
manualarefollowed.
FAILURE TO FOLLOW THESE SAFETY PRECAUTIONS
COULD RESULT IN AFIRE OR EXPLOSION CAUSING
PROPERTY DAMAGE OR PERSONAL INJURY.
Propanegascylindersshouldalwaysbehandled,
stored, and transported with extreme caution in a
secured upright position.
Never attempt to use or repair a propane gas
cylinder that has been damaged. Never attempt
touse orrepairacylinder witha faultyor damaged
valve outlet. A cylinder that has been dropped,
dented,or otherwise damaged must bereplaced.
A propane gas cylinder should never be
transported in the passenger area of a vehicle.
Keep cylinders out of direct sunlight and never
apply any other source of direct heat to them.
When refilling your cylinder, always insist on a
reputable,qualifiedgasdealer. Yourpropanegas
cylinder is filled by weight, and should never
exceed eighty (80%) percent of its weight limit. If
the cylinder is not completely empty, the gas
dealer must make necessary adjustments to
ensure it is not overfilled. Never use an overfilled
Propane gas cylinder.
Your grill must be stored outdoors in a well
ventilated area if the cylinder is attached to it.
Disconnected cylinders must have a threaded
valveplug tightly installed and mustnot bestored
in any building, garage, or other area.
Flammable materials (gasoline, grill covers, etc.)
must not be stored in the cylinder enclosure.
Cylinder Storage
CAUTION: NEVER USE LIQUID PROPANE GAS IN AGRILL
DESIGNED FOR NATURAL GAS, OR NATURAL GAS IN A
GRILL DESIGNED FOR LIQUID PROPANE GAS. QUESTIONS
REGARDING DIFFERENT TYPES OF GASES SHOULD BE
DIRECTED TO YOUR LOCAL GAS COMPANY.
Always store propane cylinders in a secured
upright position, out of the reach of children.
Installation must conform to local codes or, in the
absenceoflocal codes, with the NationalFuelGas
Code, ANSI Z223.1. In Canada, installation shall
beinaccordancewithCAN/CGA-B149.2Propane
Installation Code, or CAN/CGA-B149.1 Natural
Gas Installation Code, and local codes where
applicable. Consult your local gas company or
Propane gas dealer for code regulations and
recommended procedures.
Always use the pressure regulator and hose
assembly supplied with your propane gas grill.
WARNING: BROILMASTER®GAS GRILLS AND SIDE
BURNERS REQUIRE LIQUID PROPANE CYLINDERS
EQUIPPED WITH AN OVERFILL PROTECTION DEVICE
(OPD). ANOVERFILLED OR IMPROPERLY FILLED
PROPANE CYLINDER CAN BE DANGEROUS.
Connection Requirements
Note: Notall valve andcylinder combinationsare
compatible. Check warning tag on valve and
cylinder as well as external fitting threads.
All Broilmaster®pressure regulators and hose
assembliesrequirepropanecylinderswithaType
1 connection device as illustrated by Figure 8.
FIGURE 8
PROPANE GAS CONNECTION

Page 10 DPSBSS
Installing "Tee" Connector
Thepressureregulator has an outlet pressure of not
morethaneleven(11")incheswatercolumn. Itmust
be connected to the propane gas cylinder’s female
valve outlet before the grill and side burner can be
operated.
CAUTION: OPERATION OF APROPANE GAS GRILL AND
SIDE BURNER WITHOUT THE PRESSURE REGULATOR AND
HOSE ASSEMBLY WILL CAUSE GAS LEAKS WHICH COULD
LEAD TO FIRE OR EXPLOSION, RESULTING IN PROPERTY
DAMAGE OR PERSONAL INJURY.
The pressure regulator’s fitting must remain clean
and free of nicks and scratches. A dirty, nicked or
scratched fitting can cause a gas leak, resulting in
an explosion or fire. Use only genuine Broilmaster®
replacementpartsunlessotherwise specified by the
manufacturer.
Pressure Regulator and
Hose Assembly
If your grill is equipped with a factory installed gas
"tee" behind the grill’s control panel, please skip to
the next section.
Turn OFF the gas valve at the propane cylinder.
Disconnect the regulator and hose assembly from
the cylinder. Disconnect hose from the gas valve
located under the grill’s control panel. FIGURE 9.
Attach one end of the 10" S/S flex line (22) to the
end of the grill’s gas valve. Attach the other end of
the S/S flex line to the brass "tee" (20). FIGURE 10.
NOTE: GRILLS MANUFACTURED PRIOR TO 1999 MAY REQUIRE
THE ALTERNATE "TEE" CONNECTOR.
Installing “Tee”Connector
(Continued)
Attachtheregulatorand hose assembly to the brass
tee" (20). Reconnect the assembly to the cylinder.
Use two adjustable wrenches to hold and tighten
the joint between the hose and "tee". FIGURE 12.
PROPANE GAS CONNECTION
Connecting to Propane Gas
Attach one end of the 34" S/S flex line (23) to the
endof thesideburnervalve (6). Attachtheremaining
end of the hose to the "tee" (20) and use two
wrenches to tighten the S/S flex line connections.
One wrench should be used to turn the S/S flex line
connector while the "tee" or valve is held with the
second wrench. FIGURE 11.
FIGURE 12
20
FIGURE 10
Grill Gas Valve "Tee"(20)
10" S/S flex line (22)
FIGURE 9
Grill Gas Valve
Hose Assembly
FIGURE 11
34" S/S flex line (23)
"Tee"(20) 6
For old Broilmaster grill, this alternate tee fitting kit
must be ordered.

Page 11DPSBSS
Gas Type
YourBroilmaster®side burner is factory equipped
for LP gas and must be converted for use with
Natural gas grills. Never use liquid propane gas
withagrilldesignedfornaturalgas, or natural gas
with a grill designed for liquid propane gas. The
type gas required for your grill can be determined
from its product identification label. Questions
regarding different types of gases should be
directed to your gas company.
NATURAL GAS CONNECTION
CAUTION: NEVER USE LIQUID PROPANE GAS IN AGRILL
DESIGNED FOR NATURAL GAS, OR NATURAL GAS IN A
GRILL DESIGNED FOR LIQUID PROPANE GAS. QUESTIONS
REGARDING DIFFERENT TYPES OF GASES SHOULD BE
DIRECTED TO YOUR LOCAL GAS COMPANY.
Side Burner Location
Yourgrillandsideburner have been designed for
outdoor use ONLY.
This side burner mounts on the right side of a
Broilmaster®gas grill and cannot be used with
another grill or for any other purpose.
You should never install or operate your grill and
side burner in any building, garage, or other
enclosedarea.
For your safety, the grill and side burner should
notbe installedoroperated underanycombustible
materials, such as carports, covered porches,
awnings, or overhangs.
Never install or use your grill and side burner in
or on any recreational vehicle or boat.
A minimum clearance of sixteen (16") inches is
required from all sides of the side burner to any
combustible material. Refer to the grill’s Owner’s
Manual for specific grill clearances.
Examples of combustible materials are patio
furniture, fences, or the wall of your home.
The area surrounding the grill and side burner
should be clear to ensure proper ventilation. Do
notobstructthe flow of combustion andventilation
air in any way. The ventilation openings on the
propanecylinderenclosuremustalsoremainfree
and clear of debris.
Portable grills with side burners should be level
andpositionedaway from directwindpriortoeach
use.
CAUTION: THE INSTALLATION AND OPERATION OF
THIS GRILL AND SIDE BURNER AT CLEARANCES LESS
THAN SPECIFIED BELOW MAY CAUSE AFIRE, PROPERTY
DAMAGE,OR PERSONAL INJURY.
WARNING: DONOT INSTALL OR OPERATE THIS
GRILL AND SIDE BURNER WHERE GASOLINE OR OTHER
FLAMMABLE MATERIALS ARE USED OR STORED. FAILURE
TO COMPLY WITH THIS WARNING COULD RESULT IN
EXPLOSION OR FIRE CAUSING PROPERTY DAMAGE OR
PERSONAL INJURY.
173
DENOTES
(NAT) BRASS
ORIFICE
89
DENOTES (LP)
BRASS ORIFICE
BRASS
ORIFICE
SHUTTER
SCREW
SIDE
BURNER
SHUTTER
RING
BURNER
TOP
173
89
1. Remove shutter screw. Important: Do not
discard this screw; it will be reinstalled.
2. Remove shutter ring. The shutter ring is not
used for Natural gas, but retain for future use
if LP conversion is desired.
3. Use a 7 mm nut driver or socket wrench to
remove the LP orifice and replace it with the
Natural gas orifice supplied.
4. Replace the shutter screw.
5. Turnset screw in centerof valvestem1/2turn
counterclockwise.
6. Apply soapy solution to test for leaks around
the set screw. If a leak is found, turn screw
clockwise until bubbles cease.
IMPORTANT: PLACE CONVERSION LABEL INSIDE LID
ADJACENT TO SERIAL NUMBER LABEL.

Page 12 DPSBSS
Attach one end of the 10" S/S flex line (22) to the
end of the grill’s gas valve.
Attach the other end of the S/S flex line to the
brass “tee”(20). FIGURE 14.
NATURAL GAS CONNECTION
The grill’s natural gas supply line valve installed
by your gas company must be turned to OFF.
IMPORTANT: THE GAS SUPPLY LINE MUST HAVE A
SHUTOFF VALVE INSIDE THE WALL. CONTACT YOUR
LOCAL GAS COMPANY FOR DIRECTIONS.
Disconnect the copper gas supply line from the
gas valve located under the grill’s control panel.
FIGURE 13.
Attach one end of the 34" S/S flex line (23) to the
end of the side burner valve (6).
Attach the remaining end of the S/S flex line to
the end of the “tee”(20) connector. FIGURE 15.
FIGURE 13
Grill Gas Valve
Gas Supply Line
Attach the copper gas supply line to the brass
“tee”(20). Usetwoadjustablewrenchestotighten
the joint. FIGURE 16.
“Tee”(20)
Connection Requirements
Installation must conform to local codes or, in the
absenceof localcodes,withthe NationalFuelGas
Code, ANSI Z223.1. In Canada, installation shall
beinaccordance withCAN/CGA-B149.2Propane
Installation Code, or CAN/CGA-B149.1 Natural
Gas Installation Code, and local codes where
applicable. Contact your local gas company for
coderegulations,recommendedprocedures,and
the installation of your grill’s gas supply line.
Broilmaster®gas grills and side burners are not
equipped with pressure regulators. Your gas grill
operates at a manifold pressure of seven (7")
inches water column.
Connect cartmounted natural gas grillsto apre-
installedgassupplylineusing the twelve (12') foot
flexible hose and quick disconnect kit supplied or
specified by the manufacturer.
CAUTION: THE GRILL AND ITS INDIVIDUAL SHUTOFF
VALVE MUST BE DISCONNECTED FROM THE GAS SUPPLY
PIPING SYSTEM DURING ANY SYSTEM PRESSURE TESTING
AT TEST PRESSURES IN EXCESS OF 1/2 PSIG.
CAUTION: THE GRILL MUST BE ISOLATED FROM THE
GAS SUPPLY PIPING SYSTEM BY CLOSING ITS INDIVIDUAL
MANUAL SHUTOFF VALVE DURING ANY PRESSURE
TESTING OF THE GAS SUPPLY PIPING SYSTEM AT TEST
PRESSURES EQUAL TO OR LESS THAN 1/2 PSIG.
Connection Instructions
FIGURE 16
“Tee”(20) Gas Supply Line
FIGURE 14
Grill Gas Valve
7" S/S flex line (22)
FIGURE 15
34" S/S flex line (23)
20 6

Page 13DPSBSS
CAUTION: DONOT USE AN OPEN FLAME TO CHECK
FOR LEAKS. CHECKING FOR LEAKS WITH AN OPEN
FLAME MAY LEAD TO AFIRE OR EXPLOSION, RESULTING
IN PROPERTY DAMAGE OR PERSONAL INJURY.
Checking for Gas Leaks
Check for gas leaks each time you connect your
Broilmaster®gasgrillandsideburnerto a propane
gas cylinder, when a connected cylinder has not
been used recently, or when the grill and side
burner are initially used.
Using Matches
CAUTION: IFABURNER FAILS TO LIGHT AFTER 5
SECONDS, TURN THE BURNER OFF FOR 5 MINUTES, TO
ALLOW THE GAS TO CLEAR, THEN TRY AGAIN.
WARNING: NEVER OPERATE THE SIDE BURNER WITH
THE LID CLOSED.
To check for gas leaks:
1. Usingdish washing detergentandwater,make
a soapy solution.
2. Turn OFF the knob on both the grill and side
burner’scontrol panel.
3. Turn ONthegasat thesupply.
Ahissingsound
indicates a leak.
Turn OFF the gas and repair
all leaks.
4. If no hissing occurs, apply the soapy solution
to all gas connections.
5. Look for bubbles.
Bubbles indicate a leak.
6. If there are bubbles, turn OFF the gas and
repair all leaks.
7. Turn the gas ON and repeat the above
procedure until all leaks are repaired.
Operating Instructions
OPERATION AND MAINTENANCE
Operating Instructions
Using the Igniter
1. Open the side burner lid.
2. Push and turn the burner control knob
counterclockwise to MAX.
3. Pushandholdigniterbuttonuntilburnerlights.
(Approximately 5 seconds).
1. Open the side burner lid.
2. Light and place a long wooden match next to
the burner ports under the cooking grid.
3. Push and turn the burner control knob
counterclockwise to MAX.
Low Flame Adjustment
Thelowflamesettingissetatthefactory. Toadjust
the flame height at the lowest setting:
A. Light the side burner
B. Turn the valve knob to MIN.
C. Remove the knob and locate the screw in the
center of the valve stem.
D. Use a small screwdriver to adjust the flame:
Clockwise - Lower Flame
Counterclockwise - Higher Flame
Do not unseat the adjustment screw. If the screw
isunseateda gas leak willoccuratthevalvestem.
NOTE: IFTHE FLAME IS ADJUSTED TOO LOW,ASTRONG
WIND COULD BLOW IT OUT. THE FLAME MAXIMUM HEIGHT
(A)SHOULD BE APPROXIMATELY 1/2INCH AT THE MINIMUM
SETTING. FIGURE 17.
FIGURE 17
Care and Cleaning
CAUTION: TOPREVENT INJURY DO NOT CLEAN SIDE
BURNER WHILE HOT.
For baked on residue use a brass (NOT STEEL)
brush on the cooking grid.
Cleanthe exterior regularly with asolution ofmild
detergentand hot water.
Stainless steel surfaces can be easily cleaned
with a stainless steel cleaner found at your
1/2
BURNER

Page 14 DPSBSS
NOTES

Page 15DPSBSS
NOTES

Page 16 DPSBSS
RETAIN OWNER’SMANUAL FOR FUTURE REFERENCE.
FORM B100027-2-0202
BROILMASTER®
A Division of Empire Comfort Systems, Inc.
918 Freeburg Ave.
Belleville, Illinois 62220
Phone: [phone]
