Brute Elite BNTH1000 Owner's manual

Installation and Operation Instructions Document 1266A
H2360900A
WARNING
If the information in this manual is not
followed exactly, a re or explosion may
result causing property damage, personal
injury or loss of life.
Do not store or use gasoline or other
ammable vapors and liquids in the vicinity
of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from a
nearby phone. Follow the gas supplier’s
instructions.
• If you cannot reach your gas supplier, call
the re department.
Installation and service must be performed
by a qualied installer, service agency, or gas
supplier.
FOR YOUR SAFETY: This product must be installed and serviced by a professional service technician,
qualied in hot water boiler and heater installation and maintenance. Improper installation and/or operation
could create carbon monoxide gas in ue gases which could cause serious injury, property damage, or
death. Improper installation and/or operation will void the warranty.
AVERTISSEMENT
Assurez-vous de bien suivres les instructions
données dans cette notice pour réduire au
minimum le risque d’incendie ou d’explosion ou
pour éviter tout dommage matériel, toute blessure
ou la mort.
Ne pas entreposer ni utiliser d’essence ni d’autres
vapeurs ou liquides inammables dans le
voisinage de cet appareil ou de tout autre appareil.
QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ:
• Ne pas tenter d’allumer d’appareils.
• Ne touchez à aucun interrupteur. Ne pas vous
servir des téléphones dansle bâtiment où vous
vous trouvez.
• Appelez immédiatement votre fournisseur de
gaz depuis un voisin. Suivez les instructions du
fournisseur.
• Si vous ne pouvez rejoindre le fournisseur de
gaz, appelez le sservice des incendies.
L’installation et l’entretien doivent être assurés par
un installateur ou un service d’entretien qualié ou
par le fournisseur de gaz.
Installation and
Operation Instructions for
Modulating Boiler Water Heater
Model BNTH1000 Model BNTV1000
1,000 MBTU/h 1,000 MBTU/h
Model BNTH1700 Model BNTV1700
1,700 MBTU/h 1,700 MBTU/h
Brute Elite LC
238-50567-00B REV 7/14

Bradford White Corp.

Brute Elite Boilers and Water Heaters
Section 1 - General Information ........................................1
1.1 Introduction......................................................1
1.2 About the Brute Elite Control System..............1
1.3 Safety Notes .....................................................3
1.4 ModelIdentication .........................................3
1.5 Warranty...........................................................3
1.6 Unit Overview..................................................4
1.7 Dimensions.......................................................5
1.8 Unpacking ........................................................5
Section 2 - Locating the Unit.............................................7
2.1 Locating the Unit..............................................7
2.2 Locating Unit for Correct Vent Distance
from Outside Wall or Roof Termination...........7
Section 3 - Venting and Combustion Air ...........................8
3.1 Combustion Air ................................................8
3.1.1 Combustion Air From Room............................8
3.1.2 Ducted Combustion Air....................................9
3.2 Venting ...........................................................10
3.2.1 Common Venting............................................10
3.2.2 Condensate Drain Trap...................................10
3.2.3 Venting Requirements Unique to Canada ......11
3.3 Locating the Vent and Combustion Air
Terminals........................................................13
3.3.1 Side Wall Vent Terminal.................................13
3.3.2 Side Wall Combustion Air Terminal ..............14
3.3.3 Vertical Vent Terminal....................................14
3.3.4 Vertical Combustion Air Terminal..................14
3.3.5 Installations in the Commonwealth of
Massachusetts.................................................14
3.4 Common Vent Test .........................................15
3.5 Outdoor Installation........................................15
Section 4 - Gas Supply and Piping ..................................16
4.1 Gas Supply and Piping...................................16
Section 5 - Pump Requirements.......................................18
5.1 Brute Elite Boiler Flow and Head
Requirements..................................................18
5.2 Brute Elite Water Heater Flow and Head
Requirements..................................................18
Section 6 – Water Connections........................................19
Section 6A - NTH Units...................................................19
6A.1 NTH System Piping: Hot Supply
Connections....................................................19
6A.2 NTH Cold Water Make-Up............................19
6A.3 NTH Freeze Protection...................................19
6A.4 NTH Suggested Piping Schematics................20
Section 6B - NTV Units...................................................26
6B.1 NTV Water Quality ........................................26
6B.2 NTV Piping Requirements.............................26
6B.3 NTV Cold Water Make-Up ............................27
6B.4 NTV Freeze Protection...................................27
6B.5 NTV Suggested Piping Schematics................27
6B.6 NTV Suggested Pumps ..................................28
Section 7 - Electrical Connections...................................29
7.1 Main Power ....................................................29
7.2 Pump Connections..........................................29
7.3 24 VAC Transformer with Integral
Circuit Breaker...............................................31
7.4 Signal Connections.........................................31
7.5 Optional Field Connections............................31
7.6 Ladder and Wiring Diagrams.........................31
Section 8 – Using the Controls
on the Brute Elite..........................................36
8.1 Controls and Indicators on the Front
of the Unit.......................................................36
8.2 Using the Operator Interface..........................36
8.3 While Operating – Checking Lead/Lag
Operating Information....................................38
8.4 Checking Lead/Lag Master............................39
8.5 While Operating - Checking Individual
Parameters......................................................39
8.6 Checking Individual Details...........................40
8.7 ConguringParametersonIndividual
Controllers......................................................40
8.8 VericationProcessforSafety-Related
Parameters......................................................42
Table of Contents
i

Bradford White Corp.
Section9–SetupandConguration ...............................44
9.1 Review of Lead/Lag Control System.............44
9.1.1 About Lead/Lag Operation.............................44
9.1.2 Lead/Lag Modulation Cycle...........................45
9.1.3 NTH Lead/Lag with Indirect
Domestic Hot Water.......................................46
9.2 Connection Terminals.....................................46
9.3 BruteEliteSystemCongurations.................48
9.4 Installation Jobs..............................................55
A Note for Systems Using Common
Venting ...........................................................55
B Naming the Controllers..................................55
C Make One Control the Lead/Lag
Master.............................................................56
D Disable the Lead/Lag Master Function
on the Lead/Lag Slaves ..................................57
E Set up the Modbus Control Addressing..........58
F Set the Flap Valve IDs....................................59
G Disconnect Unused Operator
Interfaces........................................................63
H Connect the Modbus Wiring...........................63
I Set the Parameters Used by the
Lead/Lag System............................................64
About the “Time of Day” Function................68
J Install the System Sensor and Adjust
the Setpoint.....................................................68
K Set the Lead/Lag Outdoor Reset and
Warm Weather Shutdown...............................68
About “Outdoor Reset”..................................69
L Building Automation or Multiple Boiler
Control Thermostat Demand.........................70
M Building Automation or Multiple Boiler
4-20mA Setpoint Control ..............................70
N Building Automation or Multiple Boiler
4-20mA Modulation Control..........................71
O Combustion Setup Procedure.........................71
P Setting the Date and Time on the
System Display...............................................76
9.5 Setup for Domestic Hot Water on a
Lead/Lag System............................................77
Setup Type 1 ...................................................77
Setup Type 2 ...................................................78
Setup Type 3 ...................................................79
9.6 Gateway Connections to a
Building Automation System .........................80
9.7 Setup for HighAltitude Operation -
NT 1700 Only.................................................80
9.8 Installer Parameters........................................81
Section 10 - Operating Instructions .................................88
10.1 Filling the Boiler System................................88
10.2 Initial Operation .............................................89
10.2.1 Initial Burner Operation .................................89
10.2.2 Combustion Setup Procedure.........................89
10.3 Shutting Down the Brute Elite .......................89
10.4 Restarting the Brute Elite...............................89
Section 11 – Maintenance................................................90
11.1 System Maintenance.......................................90
11.2 Maintenance Notes.........................................90
11.2.1 Burner.............................................................90
11.2.2 Modulating Gas Valve/ Venturi......................90
11.2.3 Controllers......................................................91
11.2.4 Ignitor Assembly ............................................91
11.2.5 Flame Sensor..................................................91
11.2.6 Transformer with Integral
Circuit Breaker...............................................91
11.2.7 Blower............................................................92
11.2.8 Heat Exchanger Coils.....................................92
11.2.9 Gas Pressure Switches (optional)...................92
11.2.10 Natural/Propane Gas Conversion.................93
Section 12 – Troubleshooting ..........................................94
12.1 Potential Setup and Synchronization
Problems.........................................................94
12.1.1 Controller Synchronization ............................94
12.1.2 Flap Valve Status Checks...............................95
12.2 About Lockouts, Holds, and Alerts................95
12.2.1 Responding to a Lockout, Hold,
or Alert............................................................95
12.2.2 Viewing the Lockout and Alert
Histories .........................................................96
12.3 Troubleshooting Table....................................98
12.4 Diagnostic Tests and Input/Output
Indicators......................................................113
12.5 Lead/Lag Slave Diagnostics.........................114
12.6 Statistics .......................................................114
12.7 Analysis........................................................114
12.8 Control Snapshot..........................................115
12.9 Operating Sequence......................................115
Section 13 – Replacement Parts.....................................118
13.1 General Information.....................................118
13.2 Parts List.......................................................118
13.3 Parts Illustrations..........................................124
ii

Page 1
Brute Elite Boilers and Water Heaters
Section 1
GENERAL INFORMATION
1.1 Introduction
This manual includes information which will help
you to install, operate, and maintain the Brute Elite
1000 and 1700 systems. Please read this manual
completely before proceeding with the installation.
If you have any questions regarding this equipment,
please consult the Bradford White factory, or a local
factory representative. Many operating problems are
caused by improper installation.
WARNING
Brute Elite’s must be installed in accordance
with the procedures detailed in this manual,
or the Bradford White Corporation warranty
will be voided. The installation must conform
to the requirements of the local jurisdiction
having authority, and, in the United States,
to the latest edition of the National Fuel Gas
Code, ANSI Z223.1/NFPA54. In Canada, the
installation must conform to the latest edition
of CSA B149.1 Natural Gas and Propane Gas
Installation Code, and/or local codes. Where
required by the authority having jurisdiction, the
installation of Brute Elite boilers must conform to
the Standard for Controls and Safety Devices for
Automatically Fired Boilers, ANSI/ASME CSD-1.
Any modications to the boiler, its gas controls,
or wiring may void the warranty. If eld conditions
require modications, consult the factory
representative before initiating such modications.
Pressure and
temperature
gauge
Touch Screen Display
(behind the plastic cover
which slides downward)
Power switch

Page 2 Bradford White Corp.
1.2 About the Brute Elite Control
System
This unit includes an advanced control system
which can perform many functions. This is part of
the reason why the Brute Elite 1000 or 1700 can
deliver such outstanding performance. There are
several “branches” in the control software, and many
different display screens. For clarity, throughout
this manual we have made a special effort to show
you how to reach each of the important setup and
operating functions. We have done this in two ways:
• In many cases, we have shown you the actual
screen display you will see while performing a
function.
• Sometimes, instead of showing the screens, we
have just listed the series of choices you should
make in order to reach the section you want.
The arrangement of the control software is actually
quite logical, and after you have worked with it a bit,
you will not have any problems “nding your way
around.” We just want to give you some help with
the rst part of the process, when you are “getting
used to” the control system.
Later in this manual, we will detail information on
the setup and operating procedures. There are a
couple of concepts you will need to understand right
from the start.
• Each boiler has two controllers and two
burners, as shown in Fig. 1. A single Operator
Interface is used to communicate with both
controllers.
Primary
burner
Primary
controller
Gas
valve
Gas
valve
Secondary
controller Secondary
burner
Operator
interface
Boiler 1
Fig. 1 – Control Arrangement in a Single-Boiler
Installation
Each controller and burner work together. Each
boiler includes two of these controller/burner
combinations.
Notice the different terms we are using here.
The term boiler refers to the whole unit – the
complete Brute Elite 1000 or 1700. Each
boiler includes two separate controller/burner
pairs.
• Brute Elite 1000 and 1700 units are always set
up for “Lead/Lag” operation. The term “Lead/
Lag” means that, as the heating load increases,
the control system brings additional burners on
automatically.
On a multiple-boiler installation, each of the
individual boilers is still set up as shown in Fig.
1 above. The controller/burner pairs on all of the
boilers are arranged in a “daisy chain.” Up to four
boilers, with up to eight controller/burner pairs, can
be connected in this way. See Fig. 2.
Fig. 2 – Lead/Lag Arrangement in a Multiple-
Boiler Installation
In a multiple-boiler installation, just one of the
operator interfaces is active. It can communicate
with all of the controller/burner pairs in the system,
so it displays information from all of the burners. A
single system sensor provides the control input for
the system.
Actually, even a Brute Elite 1000 or 1700 unit set
up as a single boiler still uses Lead/Lag operation.
If the heating load becomes too great for the rst
burner, the control system automatically starts the
Press here to
see current
Lead/ Lag
performance
Press here
for individual
controller/
burner pairs
Press here
for Lead/ Lag
setup
Press here for
system setup
Operator
interface
Boiler 1
Slave 4
Boiler 2
Slave 3
Slave 2
Lead Lag
Master and
Slave 1 Slave 6
Boiler 3
Slave 5
Slave 8
Boiler 4
Slave 7
Addr
1Addr 2Addr 3Addr 4Addr 5Addr 6Addr 7Addr 8

Page 3
Brute Elite Boilers and Water Heaters
second burner.
To work with this control system, you will need
to understand the difference between two kinds of
control functions:
• Some of the functions control all of the
controller/burner pairs, working together as
part of the Lead/Lag system. As an example,
the setpoint for a whole multiple-boiler system
is set by a single value: “Central Heat Lead/
Lag Setpoint.” By changing this one value,
you change the setpoint used by the whole
system. The action of all of the controller/
burner pairs will refer back to that single value.
On the Operator Interface, from the Home
screen you can reach all of the Lead/Lag
functions by pressing the View Lead Lag
button. See Fig. 3.
• Other functions apply only to each separate
controller/burner pair. As an example, each
controller/burner has a name, and this can be
changed.
The Home screen on the Operator Interface
will show icons for each of the controller/
burner pairs connected to the system. To
reach one of the functions for an individual
controller/burner, press the icon for that
controller/burner. On the following screen,
press the Congure button. This will take
you to all of the conguration options for that
individual controller/burner.
Fig. 3 – Going to Lead/Lag and Individual
Functions
Note – For individual functions, if you want to make
a change on all of the controller/burner pairs in the
system, you will have to go to each controller/burner
separately and repeat the change for each of them.
If there are eight controller/burners in the system,
and you want to make the same change on all of
them, go to each of the eight controller/burner pairs
separately.
As we go through the explanations in this manual,
we will point out whether a control function affects
the whole Lead/Lag system, or just an individual
controller/burner pair.
This has been just a quick introduction, but this
manual includes two longer sections that will help
you to work with the control system:
• Section 8 – “Using the Controls on the Brute
Elite.”
This is an introduction to the Operator
Interface. It explains how to “get along” with
the interface: how to move through the various
screens, enter and change values, and so on.
• Section 9 – “Setup and Conguration”
The rst part of this section includes a more
complete explanation of the Lead/Lag system.
The rest of the section includes detailed setup
instructions.
If you are not familiar with the control system, the
installation and setup process will go much more
smoothly if you read through these three sections
before beginning work.
1.3 Safety Notes
WARNING
Fire or Explosion Hazard
Improper conguration can cause fuel buildup and
explosion. Improper user operation may result in
property loss, severe physical injury, or death.
Any changes to safety-related conguration
parameters must only be done by experienced and/or
licensed burner/boiler operators and mechanics.
If any odor of gas is detected, or if the gas burner
does not appear to be functioning in a normal
manner, close the main gas shutoff valve. Do not
shut off the power switch. Contact your heating
contractor, gas company, or factory representative.
The Brute Elite is protected against over-
pressurization. A pressure relief valve is included
with each Brute Elite.
The inlet gas pressure to the appliance must not
exceed 13” W.C. (3.2 kPa).
All installations must be made in accordance with
1) American National Standard Z223.1/NFPA54-
Latest Edition “National Fuel Gas Code” or 2) CSA
B149.1 “Natural Gas and Propane Installation Code”

Page 4 Bradford White Corp.
and with the requirement of the local utility or other
authorities having jurisdiction. Such applicable
requirements take precedence over the general
instructions contained herein.
WARNING
Carbon Monoxide Hazard
Improper adjustment of the burners may lead to poor
combustion quality, increasing the amount of carbon
monoxide produced. Excessive carbon monoxide
levels may lead to personal injury or death.
WARNING
Electrical Shock Hazard
Electrical shock can cause severe injury, death or
property damage. Disconnect the power supply
before beginning installation or changing the
wiring to prevent electrical shock or damage to the
equipment. It may be necessary to turn off more than
one power supply disconnect.
All electrical wiring is to be done in accordance with
local codes, or in the absence of local codes, with:
1) The National Electrical CodeANSI/NFPA No.
70 - latest Edition, or 2) CSA STD. C22.1 “Canadian
Electrical Code - Part 1.” This appliance must be
electrically grounded in accordance with these
codes.
1.4 ModelIdentication
Consult the rating plate on the unit. The following
information describes the model number structure.
(1-3) Model Series Designation
B N T = Brute Elite
(4) Usage
H = Hydronic
V = Volume Water
(5-8) Size
1 0 0 0 = 1,000,000 BTU/hr input
1 7 0 0 = 1,700,000 BTU/hr input
(9) Fuel
N = Natural Gas
P = LP Gas
(10) Options Code
J = CSD1 Version
X = Standard Unit
(11) Pump Options
X = No pump (conguration available for all sizes)
(12) Revision
1 = First version
1.5 Unit Overview
See Figure 4.
1.6 Warranty
Bradford White appliances are covered by a
limited warranty.
All warranty claims must be made to an authorized
Bradford White wholesale rep / distributor. To nd
information about the wholesalers in your area,
please go to www.bradfordwhite.com. and
click on ‘Wholesalers’.
Claims must include the serial number and model
(this information can be found on the rating plate),
installation date, and name of the installer. Shipping
costs are not included in the warranty coverage.
Some accessory items may be shipped in separate
packages. Verify receipt of all packages listed on
the packing slip. Inspect everything for damage
immediately upon delivery, and advise the carrier of
any shortages or damage. Any such claims should be
led with the carrier. The carrier, not the shipper,
is responsible for shortages and damage to the
shipment whether visible or concealed.
Model Nomenclature
SERIES
B N T USAGE
H - HYDRONIC
V - VOLUME
WATER
SIZE
MBTU/h
1 0 0 0
1 7 0 0
FUEL
N - NATURAL
P - PROPANE
OPTIONS CODE
J- CSD1
X - STANDARD
PUMP OPTIONS
X - NO PUMP REVISION 1 - FIRST
1 2 3 4 5 6 7 8 9 10 11 12
1
B N T

Page 5
Brute Elite Boilers and Water Heaters
1.6 Unit Overview
Pressure and
temperature
gauge
Blower 1
(under bezel)
Automatic
gas valves
Manual
gas valve
Blower 2
Touch Screen
Display
Protective Cover
(slides downward) Power switch Ducted air inlet
Electrical box
PRV and
ow switch
Outlet
temperature
sensors
Inlet
temperature
sensors
Condensate
trap
Leveling feet
Model 1000

Page 6 Bradford White Corp.
Model 1700
Pressure and
temperature
gauge
Blower 1
(behind bezel)
Automatic
gas valves
Manual
gas valve
(on back)
Blower 2
Touch Screen
Protective Cover
(slides downward) Power switch Ducted air inlet Electrical box
PRV and
ow switch
Outlet
temperature
sensors
Inlet
temperature
sensors
Condensate
trap
Leveling feet
