Bryant 561G User manual

NOTE: Read the entire instruction manual before starting the
installation.
OWNER’S INFORMATION
User information for the operation and maintenance of your new
residential air conditioner.
A NOTE ABOUT SAFETY
Any time you see this symbol in manuals, instructions and on
the unit, be aware of the potential for personal injury. There are
three levels of precaution:
DANGER identifies the most serious hazards which will result in
severe personal injury or death.
WARNING signifies hazards that could result in personal injury
or death.
CAUTION is used to identify unsafe practices which would result
in minor personal injury or product and property damage.
WARNING: PERSONAL INJURY, DEATH
AND/OR PROPERTY DAMAGE HAZARD
Failure to follow this warning could result in personal
injury, death or property damage.
Improper installation, adjustment, alteration, service,
maintenance, or use can cause explosion, fire, electrical
shock, or other conditions which may cause personal
injury or property damage. Consult a qualified installer,
service agency, or your distributor or branch for informa-
tion or assistance. The qualified installer or service
agency must use factory-authorized kits or accessories
when modifying this product.
WARNING: PERSONAL INJURY, DEATH, OR
PROPERTY DAMAGE HAZARD
Failure to follow this warning could result in personal
injury, death, or property damage.
Read and follow all instructions and warnings, including
labels shipped with or attached to unit before operating
your new air conditioner.
IMPORTANT FACTS
To better protect your investment and to eliminate unnecessary
service calls, familiarize yourself with the following facts:
Your air conditioning system should never be operated without a
clean air filter properly installed. Plan to inspect the filter
periodically. A clogged air filter will increase operating costs and
shorten the life of the unit.
Supply-air and return-air registers should not be blocked. Drapes,
furniture, and toys are some of the items commonly found
obstructing grilles. Restricted airflow lessens the unit’s efficiency
and life span.
The outdoor unit must have unrestricted airflow. Do not cover the
unit, lean anything against it, or stand upon it. Do not allow grass
clippings, leaves, or other debris to accumulate around or on top of
the unit. Maintain a 12-in. minimum clearance between the
outdoor unit and tall grass, vines, shrubs, etc.
Your multipurpose indoor thermostat is the control center for your
air conditioning system. You should familiarize yourself with its
proper operation. Attempting to control the system by other
means—for instance, switching the electrical supply power ON
and OFF—may cause damage to the unit.
Thermostat “jiggling” causes rapid-cycling, which is potentially
damaging to the compressor. Do not move the temperature selector
on the thermostat for any reason for at least 5 minutes after the
compressor has shut off.
You may find that you can maintain greater personal comfort by
running the fan continuously. “Air pockets” can form due to the
structure of the house, placement of registers, etc. These air
pockets may be too cool or warm for you liking. Continuous fan
operation minimizes any temperature differences. Also, systems
equipped with electronic air cleaners and/or humidifiers offer the
added benefits of having the air continuously cleaned year-round,
and humidified during the winter season.
Your air conditioner will remove humidity from your home during
the cooling season. After a few minutes of operation, you should
be able to see water trickle from the condensate drain of the
cooling coil. Check this occasionally to be sure the drain system is
not clogged. Of course, don’t expect to see much drainage if you
live in a very dry environment.
REGULAR DEALER MAINTENANCE
In addition to the routine maintenance that you perform, your
home comfort system should be inspected regularly by a properly
trained service technician. The inspection (preferably each year,
but at least every other year) should include the following:
· Routine inspection of air filter(s). Replacement or cleaning as
required.
· Inspection and cleaning of the blower wheel, housing, and
motor.
· Inspection and, if required, cleaning of indoor and outdoor
coils.
· Inspection of the indoor coil drain pan, plus the primary and
secondary drain lines. If supplied, the auxiliary drain pan and
line should be inspected at this time. Service should include
cleaning if required.
· A check of all electrical wiring and connections.
· A check for secure physical connections of individual compo-
nents within units.
· Operational check of the air conditioning system to determine
actual working condition. Necessary repair and/or adjustment
should be performed at this time.
Your servicing dealer may offer an economical service contract
that covers seasonal inspections. Ask for further details.
Owner’s Manual
SPLIT SYSTEM AIR CONDITIONERS
Cancels: OM01-22 OM01-77
3-06
561G
—1—

WARNING: ELECTRICAL SHOCK, FIRE, EX-
PLOSION, PERSONAL INJURY HAZARD
Improper installation, adjustment, alteration, service,
maintenance, or use can cause explosion, fire, electrical
shock, or other conditions which may cause personal
injury or property damage.
Consult a qualified installer, service agency, or your
distributor or branch for information or assistance. The
qualified installer or agency must use factory-authorized
kits or accessories when modifying this product.
WARNING: ELECTRICAL SHOCK, UNIT OP-
ERATION AND SAFETY HAZARD
Failure to follow this warning could result in personal
injury, death and or property damage.
Read and follow all instructions and warnings, including
labels shipped with or attached to unit, before operating
your new air conditioner.
OUTDOOR COIL—SEA COAST
If your unit is located near the ocean, special maintenance is
required. Ocean mist/breeze carries salt, which is corrosive to most
metals. Although your new unit is made out of galvanized metal
and is protected by top-grade paint, you should take the precaution
of additional maintenance which consists of periodically washing
the unit. By washing all exposed surfaces and coil, you will be
adding additional life to your unit. Please consult your installing
contractor for proper intervals/procedures for your geographic area
or service contract.
© 2006 Bryant Heating & Cooling Systems 7310 W. Morris St. Indianapolis, IN 46231 —2— Printed in U.S.A. Catalog No. OM01-77
