Bryant CM5A User manual

Form No. PDS CM5A.24.2
CM5A/CM5B COILS
KMABA BLOWERS
For Manufactured Homes
4THE CM5A/CM5B INDOOR COIL
To complete your cooling or heating system, the model CM5A
or CM5B Coil is installed inside your Evcon/Coleman, Nor-
dyne/Miller/Intertherm or AirPro gas or electric downflow fur-
nace. Both coils are uncased, and designed for installation
within the manufactured home furnace casing or inside a fac-
tory-installed plenum. These indoor coils are designed to be
used in conjunction with blower kits and other accessories.
The CM5A and CM5B coils are designed for quick and easy in-
stallation by a qualified service technician.
The CM5A comes with factory-installed mechanical connec-
tions. The CM5B comes with factory-installed sweat connec-
tions. Both coils utilize a Check-Flo-Rater® piston for refrig-
erant flow control. Both coils can be used in cooling-only
applications or as part of a heat pump system.
When heating in conjunction with a heat pump, the outdoor
heat pump unit recovers heat from the outdoor air, and trans-
mits it to the CM5A or the CM5B indoor coil for distribution to
the living space.The CM5A and CM5B coils are not activated
when heating in conjunction with a furnace without a heat
pump in the system.
Built-in drainage assembly ensures leak-free condensate re-
moval. Periodic cleaning of filter and drainage sections is rec-
ommended to avoid possible sediment blockage.The A-shape
design of the coil provides maximum cooling-heating transfer
surface and ease of handling at installation.Four coil sizes are
available from 024 though 048, covering a wide range of cool-
ing-heating capacities to meet varying manufactured home re-
quirements.
THE KMABA BLOWER
KMABA Blower Kits and Accessories are designed and built to
meet the needs of the manufactured housing market.The kits
are used to upgrade Nordyne and Evcon gas and electric fur-
naces (see note). For cooling and heat pump duty, kits avail-
able include blowers for up to 4 tons of air conditioning, control
boxes, insulation kits, filter kits, and evaporator coil shelves.
Blower kits for gas furnaces are shipped without controls.Order
the control box from accessory usage chart.Blower kits for elec-
tric furnaces are shipped with or without controls. See acces-
sory usage chart for details. All control box kits are designed to
operate with a minimum 4-wire thermostat.
Quick connect wire harnesses are shipped with the appro-
priate blower kit or control box for ease of installation. Sheet
metal adapter plates also are included with the blower kits that
are needed to adapt the blower with the furnace.
NOTE: Intertherm, Miller, Coleman, and AirPro brands.

—2—
CM5A DIMENSIONS
A96627
NOTE: Series designation is the 14th position of unit model number.
CM5A SPECIFICATIONS
UNIT SIZE SERIES UNIT DIMENSIONS (In.) NUMBER OF ROWS SHIPPINGWEIGHT
(Lb)ABC
024 A 14 5/8 3 30
036 A 16 3/4 3 32
042 A 18 3/4 3 35
048 A 18 3/4 4 37
UNIT SIZE-SERIES 024-A 036-A 042-A 048-A
Operating Weight (Lb) 21 23 26 28
REFRIGERANT
Control Check-Flo-Rater® Piston
COIL
Type Uncased A-Type with Aluminum Fins
Rows-Fins/In. 3–15 3–15 3–15 4–13
Face Area (Sq Ft) 3.11 3.56 4.00 3.56
Nominal CFM 800 1200 1200 1200
CONNECTIONS
Type Mechanical
Vapor (In. ID) 5/8 3/4
Liquid (In. ID) 3/8
OPTIONAL EQUIPMENT
TXV (Hard Shutoff) KSATX0801HSO KSATX0901HSO
FRONT RIGHT SIDE
"A"
7⁄8″ OD DRAIN
3⁄8″ DIA
LIQUID
FITTING "B" DIA
VAPOR
FITTING
"C" ROWS
19 1⁄4″
16″
7⁄8″18″

—3—
CM5B DIMENSIONS
A96628
NOTE: Series designation is the 14th position of unit model number.
CM5B SPECIFICATIONS
UNIT SIZE SERIES UNIT DIMENSIONS (In.) NUMBER OF ROWS SHIPPINGWEIGHT
(Lb)ABC
024 A 14 5/8 3 30
036 A 16 3/4 3 32
042 A 18 7/8 3 35
048 A 18 7/8 4 37
UNIT SIZE-SERIES 024-A 036-A 042-A 048-A
Operating Weight (Lb) 21 23 26 28
REFRIGERANT
Control Check-Flo-Rater® Piston
COIL
Type Uncased A-Type with Aluminum Fins
Rows—Fins/In. 3–15 3–15 3–15 4–13
Face Area (Sq Ft) 3.11 3.56 4.00 3.56
Nominal CFM 800 1200 1200 1200
CONNECTIONS
Type Sweat
Vapor (In. ID) 5/8 3/4 7/8
Liquid (In. ID) 3/8
OPTIONAL EQUIPMENT
TXV (Hard Shutoff) KSATX0801HSO KSATX0901HSO
FRONT RIGHT SIDE
"A"
7⁄8″ OD DRAIN
3⁄8″ DIA
LIQUID
FITTING "B" DIA
VAPOR
FITTING
"C" ROWS
19 1⁄4″
16″
7⁄8″18″

—4—
A97119
KMABA SPECIFICATIONS
NOTE: Refer to Accessory Usage chart for exact kit application.
N/A—Not applicable
BLOWER MODEL ABCD
KMABA01013TG
17-3/4 15-1/4
7-3/8 9-5/8
KMABA02014TG 7-1/2 10
KMABA03013TE 7-3/8 9-5/8
KMABA04014TE 7-1/2 10
KMABA05013TE 7-3/8 9-5/8
KMABA06014TE 7-1/2 10
BLOWER MODEL 01013TG 02014TG 03013TE 04014TE 05013TE 06014TE
Shipping Weight (Lb) 30 38 33 39 35 41
ELECTRICAL
Volts—Phase 115/1 115/1 208–230/1 208–230/1 208–230/1 208–230/1
Operating Voltage Range 104–127 104–127 187–253 187–253 187–253 187–253
Full Load Amps 7.20 9.00 3.00 4.30 3.00 4.30
BLOWER MOTOR
Motor Hp (PSC) 1/2 1/2 1/2 3/4 1/2 3/4
RPM—Speeds 1075/3
Blower Type Direct Drive
BLOWER WHEEL
Diameter (In.) 10-1/2 11-1/2 10-1/2 11-1/2 10-1/2 11-1/2
Width (In.) 8
Air Discharge Downflow
Maximum Cooling Capacity 3 Ton 4 Ton 3 Ton 4 Ton 3 Ton 4 Ton
ACCESSORIES
Control Box Kit KMACC02014WG KMACC0401E14 KMACC0601FE4
Filter Kit N/A KMAFK0101NFK
Insulation Kit N/A KMAIK0101E1I N/A
Coil Shelf Kit N/A KMACR0101CRI
B
A
C
D

—5—
PERFORMANCE DATA
GROSS COOLING CAPACITIES (MBH)
BF — Bypass Factor
CFM — Cubic Ft per Minute
EWB — Entering Wet Bulb ( ° F)
SHG — Gross Sensible Capacity 1000 Btuh
TCG — Gross Cooling Capacity 1000 Btuh
NOTES:
1. Contact manufacturer for cooling capacities at conditions other than
shown in table.
2. Formulas:
Leaving db = entering db —
Leaving wb = wb corresponding to enthalpy of air leaving coil (h
lwb
)
h
lwb
= h
ewb
—
where h
ewb
= enthalpy of air entering coil.
INDOOR
COIL AIR SATURATED TEMPERATURE LEAVING EVAPORATOR (
° F)
30 35 40 45 50
CFM EWB (
° F) TCG SHG BF TCG SHG BF TCG SHG BF TCG SHG BF TCG SHG BF
CM5A/CM5B024
600 72 50.4 24.2 0.00 45.8 21.8 0.00 40.9 19.4 0.00 35.3 16.9 0.09 28.8 14.3 0.06 67 41.5 24.8 0.08 37.0 22.4 0.06 32.0 19.9 0.05 26.2 17.3 0.05 19.9 14.7 0.06
62 33.7 25.4 0.05 29.1 22.9 0.05 24.1 20.4 0.06 18.5 17.5 0.08 14.8 14.8 0.19
800 72 61.9 29.4 0.00 56.7 26.8 0.00 50.8 24.1 0.00 44.0 21.1 0.11 36.0 17.9 0.08 67 51.6 30.9 0.10 46.2 28.1 0.08 39.9 25.1 0.07 32.7 22.0 0.07 24.9 18.7 0.08
62 42.1 32.1 0.07 36.4 29.1 0.07 30.1 26.0 0.08 23.2 22.4 0.11 19.0 19.0 0.22
1000 72 71.5 33.8 0.00 65.4 30.9 0.00 58.6 27.8 0.00 51.1 24.7 0.12 42.2 21.2 0.10 67 59.7 36.0 0.12 53.7 33.0 0.10 46.7 29.8 0.09 38.4 26.2 0.09 29.2 22.3 0.10
62 49.2 38.1 0.09 42.7 34.7 0.09 35.4 31.1 0.10 27.6 26.9 0.13 22.9 22.9 0.25
CM5A/CM5B036
1000 72 74.8 35.4 0.00 68.7 32.5 0.00 61.7 29.3 0.00 54.0 26.1 0.11 44.8 22.5 0.09 67 62.6 37.7 0.10 56.4 34.7 0.09 49.2 31.4 0.08 40.8 27.7 0.07 31.3 23.7 0.09
62 51.3 39.7 0.08 44.7 36.3 0.08 37.5 32.7 0.09 29.1 28.3 0.12 23.9 23.9 0.24
1200 72 83.4 39.4 0.00 76.9 36.3 0.00 69.2 33.0 0.19 60.4 29.4 0.12 50.5 25.6 0.10 67 70.1 42.6 0.11 63.1 39.3 0.10 55.3 35.7 0.09 46.2 31.8 0.09 35.7 27.4 0.10
62 57.6 45.4 0.09 50.5 41.8 0.09 42.5 37.8 0.10 33.4 32.8 0.14 27.8 27.8 0.26
1400 72 90.6 42.8 0.00 83.6 39.7 0.00 75.5 36.2 0.17 65.9 32.4 0.13 55.4 28.4 0.12 67 76.3 46.9 0.12 68.9 43.5 0.11 60.3 39.6 0.11 50.8 35.6 0.10 39.6 30.9 0.12
62 62.9 50.5 0.10 55.4 46.7 0.11 46.9 42.5 0.12 37.4 37.1 0.16 31.5 31.5 0.29
CM5A/CM5B042
1000 72 77.4 36.7 0.00 71.5 33.8 0.00 64.7 30.7 0.00 56.8 27.4 0.11 47.8 23.8 0.08 67 65.2 39.2 0.09 59.0 36.1 0.08 51.6 32.7 0.07 43.3 29.0 0.06 33.6 25.0 0.07
62 54.2 41.6 0.07 47.4 38.1 0.07 39.9 34.4 0.07 31.2 29.9 0.09 25.5 25.5 0.21
1200 72 85.9 40.6 0.00 79.8 37.7 0.00 72.1 34.4 0.20 63.3 30.7 0.11 53.6 27.0 0.10 67 72.8 44.2 0.10 65.5 40.7 0.09 57.9 37.2 0.09 48.9 33.3 0.08 38.2 28.8 0.09
62 60.4 47.2 0.08 53.3 43.7 0.08 45.1 39.6 0.09 35.7 34.7 0.11 29.7 29.7 0.23
1400 72 93.1 44.0 0.00 86.6 41.1 0.00 78.5 37.6 0.16 69.1 33.9 0.12 58.5 29.8 0.11 67 79.0 48.5 0.11 71.5 45.0 0.10 63.1 41.2 0.10 53.6 37.2 0.09 42.3 32.5 0.10
62 65.7 52.4 0.09 58.1 48.7 0.10 49.6 44.4 0.10 39.9 39.2 0.13 33.6 33.6 0.25
CM5A/CM5B048
1200 72 86.4 40.9 0.00 79.2 37.4 0.00 71.2 33.8 0.00 62.0 29.9 0.11 51.3 25.7 0.09 67 72.3 43.5 0.11 64.9 39.8 0.09 56.5 35.8 0.08 46.7 31.5 0.07 36.0 27.1 0.09
62 59.6 45.8 0.08 51.5 41.6 0.08 42.7 37.2 0.09 34.2 32.8 0.11 28.6 28.6 0.20
1400 72 94.5 44.6 0.00 86.8 40.9 0.00 77.8 37.0 0.00 68.0 33.0 0.14 56.6 28.5 0.12 67 79.1 47.8 0.13 71.2 44.0 0.12 62.1 39.8 0.11 51.6 35.2 0.10 39.8 30.3 0.11
62 65.1 50.6 0.10 56.9 46.5 0.10 47.4 41.8 0.11 38.3 37.2 0.12 32.4 32.4 0.22
1600 72 101.0 47.6 0.00 93.1 43.9 0.00 83.7 39.9 0.00 73.1 35.6 0.16 61.2 31.0 0.14 67 84.9 51.6 0.15 76.3 47.5 0.14 67.0 43.3 0.13 55.9 38.6 0.12 43.2 33.4 0.13
62 70.0 55.1 0.12 61.5 50.9 0.12 51.5 46.0 0.13 42.4 41.6 0.14 36.0 36.0 0.25
sensible heat cap.
1.09 x CFM
total capacity (Btuh)
4.5 x CFM
3. Direct interpolation is permissible.Do not extrapolate.
4. SHC is based on 80 ° F db temperature of air entering coil.
Below 80 ° F db, subtract (Correction Factor x CFM)
from SHC.Above 80 ° F db, add (Correction Factor x CFM) to SHC
5. All data points are based on 10 ° F superheat leaving coil.
SHC CORRECTION FACTOR
Interpolation is permissible.
Correction Factor = 1.09 x (1 – BF) x (db – 80)
BYPASS
FACTOR
ENTERING AIR DRY-BULBTEMPERATURE (
° F)
79 78 77 76 75 Under 75
81 82 83 84 85 Over 85
Correction Factor
0.10
0.20
0.30
0.98
0.87
0.76
1.96
1.74
1.53
2.94
2.62
2.29
3.92
3.49
3.05
4.91
4.36
3.82 Use formula
shown below.

—6—
COIL STATIC PRESSURE DROP (IN.WC)
UNIT SIZE BULB AIR QUANTITY (CFM)
024 WET
DRY
600 700 800 900 1000
0.11
0.09 0.14 0.12 0.19 0.15 0.23 0.19 0.27 0.22
036 WET
DRY
1000 1100 1200 1300 1400
0.22
0.19 0.28 0.23 0.32 0.27 0.37 0.31 0.42 0.36
042 WET
DRY
1100 1200 1300 1400 1500
0.24
0.20 0.28 0.24 0.32 0.29 0.38 0.33 0.43 0.39
048 WET
DRY
1200 1300 1400 1500 1600
0.30
0.27 0.35 0.29 0.40 0.33 0.45 0.38 0.51 0.43

—7—
ACCESSORY USAGE
* Requires additional control box kit.
† Only required on high static 3-ton applications.
‡ Only required on 3-1/2-ton and 4-ton applications.
** Blower package comes with necessary control box.Additional control box kit not required.
†† Only required if using existing furnace blower.
X—Indicates recommended use of product.
ACCESSORY
KIT
NO.
USEDWITH
Evcon/Coleman/AirPro Nordyne/Miller/Intertherm
Gas Furnaces Electric Furnaces Gas Furnaces Electric Furnaces
DGRT—A
7900 DGRT—B DGAT
3400
3400A
3500A8— EB—B MGHA MGBA MGBB MGHB E1EB E1EH FEBA FEBB FEH2 FEHB
BLOWER PACKAGES
KMABA01013TG X* X† — — X — — X† ————
KMABA02014TG X* X‡ — — X X‡ X‡ X‡ ————
KMABA03013TE —————————X**——
KMABA04014TE —————————X**——
KMABA05013TE — — X** ———————X**X**
KMABA06014TE — — X** ———————X**X**
CONTROL BOXES
KMACC02014WG X — — — X X ——————
KMACC0401E14 —————————X††——
KMACC0601FE4 ——————————X††X††
FILTER KIT
KMAFK0101NFK ————————XXXX
INSULATION KITS
KMAIK0101E1I ————————X X——
COIL SHELF KIT
KMACR0101CRI — — X X ————————

—8—
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
UNIT MUST BE INSTALLED IN ACCORDANCE
WITH INSTALLATION INSTRUCTIONS
Cancels: PDS CM5A.24.1
© 1997 Bryant Heating and Cooling Systems, 7310 W. Morris St., Indianapolis, IN 46231 PRINTED IN U.S.A. Catalog No. 12CM-5A1 5-97
