Product Data
MODEL 225B
PREFERREDSERIES 15 HEAT PUMP
WITH PURONREFRIGERANT
1--1/2 TO 5 NOMINAL TONS
TM
the environmentally sound refrigerant
Bryant’s heat pumps with Puronrrefrigerant provide a collection
of features unmatched by any other family of equipment. The
225B has been designed utilizing Bryant’s Puron refrigerant. The
environmentally sound refrigerant allows consumers to make a
responsible decision in the protection of the earth’s ozone layer.
As an Energy StarrPartner, Bryant Heating & Cooling Systems
has determined that this product meets the Energy Starr
guidelines for energy efficiency. Refer to the combination ratings
in the Product Data for system combinations that meet Energy
Starrguidelines.
NOTE:Ratings contained in this document are subject to
change at any time. Always refer to the AHRI directory
(www.ahridirectory.org) for the most up--to--date ratings
information.
INDUSTRY LEADING
FEATURES / BENEFITS
Efficiency
S15.3 SEER/ 11.0 -- 13.0 EER/ 7.7 -- 9.0 HSPF
(Nominal)
SMicrotube Technologytrefrigeration system
SIndoor air quality accessories available
Sound
SSound level as low as 68 dBA
Comfort
SSystem supports Thermidistattor standard thermostat
controls
Reliability
SPuronrrefrigerant -- environmentally sound, won’t
deplete the ozone layer and low lifetime service cost.
SFront--seating service valves
SScroll compressor
SInternal pressure relief valve
SInternal thermal overload
SHigh pressure switch
SLoss of charge switch
SFilter drier
SBalanced refrigeration system for maximum reliability
Durability
DuraGuardtprotection package:
SSolid, durable sheet metal construction
SSteel louver coil guard
SBaked--on, complete coverage, powder paint
Applications
SLong--line -- up to 250 feet (76.20 m) total equivalent length,
up to 200 feet (60.96 m) condenser above evaporator, or up to
80 ft. (24.38 m) evaporator above condenser (See Longline
Guide for more information.)
SLow ambient (down to --20_F/--28.9_C) with accessory kit
2
MODEL NUMBER NOMENCLATURE
12 3 4 5 6 78 9 10 11 12 14
N N N A A/N N N N N A/N A/N N A
22 5 B N A 03 6 0 0 0 A
Product
Family
Tier SEER Major
Series
Voltage Variations Cooling Capacity Open Open Open Series
2=HP 2=
Legacy
Series
5=15 SEER B=Puron N=
208--- 230--- 1
or
208/230--- 1
A=Standard 0=Not
Defined
0=Not
Defined
0=Not
Defined
A = Origi-
nal Series
the environmentally sound refrigerant
REGISTERED
ISO 9001:2000
This product has been designed and
manufactured to meet Energy Starcriteria for
energy efficiency when matched with
appropriate coil components. However, proper
refrigerant charge and proper air flow are critical
to achieve rated capacity and efficiency.
Installation of this product should follow all
manufacturing refrigerant charging and air flow
instructions. Failure to confirm proper charge
and air flow may reduce energy efficiency and
shorten equipment life.
Use of the AHRI Certified
TM Mark indicates a
manufacturer’s
participation in the
program For verification
of certification for individual
products, go to
www.ahridirectory.org.
STANDARD FEATURES
Feature 018 024 030 036 042 048 060
Puron Refrigerant XXXXXXX
Maximum SEER Rating* 14.5 15.3 15.0 15.0 15.3 15.0 15.0
Scroll Compressor XXXXXXX
Louvered Coil Guard XXXXXXX
FieldInstalledFilterDrier XXXXXXX
Front Seating Service Valves XXXXXXX
Internal Pressure Relief Valve XXXXXXX
Internal Thermal Overload XXXXXXX
Long Line capability XXXXXXX
Low Ambient capability with Kit XXXXXXX
Suction Line Accumulator XXXXXXX
High Pressure Switch XXXXXXX
Loss of Charge Switch XXXXXXX
* Based on tested combination ratings
X=Standard
225B
3
PHYSICAL DATA
UNIT SIZE SERIES 018 --- A 024 --- A 030 --- A 036 --- A 042 --- A 048 --- A 060 --- A
Operating Weight lb (kg) 169 200 196 215 245 260 294
Shipping Weight lb (kg) 207 233 242 257 290 303 345
Compressor Type Scroll
REFRIGERANT R---410A
Control TXV (R ---410A Hard Shutoff)
Charge (lb) 5.6 7.6 7.0 7.4 8.9 9.6 12.5
COND FAN Propeller Type, Direct Drive
Air Discharge Vertical
Air Qty (CFM) 2233 3223 3223 3810 3810 4046 4046
Motor HP 1/12 1/12 1/12 1/5 1/5 1/4 1/4
Motor RPM 800 800 800 800 800 800 800
COND COIL
Face Area (Sq ft) 15.09 20.12 20.12 22.63 17.60 20.12 25.15
Fins per In. 20 20 20 20 20 20 20
Rows 1 1 1 1 2 2 2
Circuits 4 5 5 6 7 7 9
VALVECONNECT.(In.ID)
Vapor 5/8 5/8 3/4 3/4 7/8 7/8 7/8
Liquid 3/8
REFRIGERANT TUBES (In. OD)
Rated Vapor* 5/8 5/8 3/4 3/4 7/8 7/8 1 --- 1 / 8
Max Liquid Line 3/8”
*Units are rated with 25 ft (7.6 m) of lineset length. See Vapor Line Sizing and Cooling Capacity Loss table when using other sizes and lengths of lineset.
Note: See unit Installation Instruction for proper installation.
VAPOR LINE SIZING AND COOLING CAPACITY LOSS
Acceptable vapor line diameters provide adequate oil return to the compressor while avoiding excessive capacity loss. The suction line
diameters shown in the chart below are acceptable for HP systems with Puron refrigerant:
VAPOR LINE SIZING AND COOLING CAPACITY LOSSES -- PURONRREFRIGERANT
1-- STAGE HEAT PUMP APPLICATIONS
Unit
Nominal
Size (Btuh)
Maximum
Liquid Line
Diameters
(In. OD)
Vapor Line
Diameters
(In.) OD
Cooling Capacity Loss (%)
Total Equivalent Line Length ft. (m)
Standard
Application Long Line Application Requires Accessories
26 --- 50
(7.9--- 15.2)
51 --- 80
(15.5--- 24.4)
81 --- 100
(24.7--- 30.5)
101 --- 125
(30.8--- 38.1)
126 --- 150
(38.4--- 45.7)
151 --- 175
(46.0--- 50.3)
176 --- 200
(53.6--- 60.0)
201 --- 225
(61.3--- 68.6)
226 --- 250
(68.9--- 76.2)
18,000
1 --- S t a g e
HP with
Puron
3/8
1/2 1 2 3 4 6 7 8 9 10
5/8 0 0 1 1 1 2 2 3 3
24,000
1 --- S t a g e
HP with
Puron
3/8
5/8 0 1 1 2 3 3 4 4 5
3/4 0 0 0 0 1 1 1 1 1
30,000
1 --- S t a g e
HP with
Puron
3/8
5/8 1 2 3 3 4 5 6 7 8
3/4 0 0 1 1 1 2 2 2 3
7/8 0 0 0 0 1 1 1 1 1
36,000
1 --- S t a g e
HP with
Puron
3/8
5/8 1 2 4 5 6 7 9 10 11
3/4 0 0 1 1 2 2 3 3 4
7/8 0 0 0 0 1 1 1 1 2
42,000
1 --- S t a g e
HP with
Puron
3/8
3/4 0 1 2 2 3 4 4 5 6
7/8 0 0 1 1 1 2 2 2 3
48,000
1 --- S t a g e
HP with
Puron
3/8
3/4 0 1 2 3 4 5 5 6 7
7/8 0 0 1 1 2 2 2 3 3
60,000+
1 --- S t a g e
HP with
Puron
3/8
3/4 1 2 4 5 6 7 9 10 11
7/8 0 1 2 2 3 4 4 5 5
1 --- 1 / 8 0 0 0 1 1 1 1 1 1
Standard Length = 80 ft. (24.4 m) or less total equivalent length
Applications in this area are long line. Accessories are required as shown recommended on Long Line Application Guidelines
Applications in this area may have height restrictions that limit allowable total equivalent length, when outdoor unit is below indoor unit See Long Line Applica-
tion Guidelines
225B
4
REFRIGERANT PIPING LENGTH LIMITATIONS
Maximum Line Lengths:
The maximum allowable total equivalent length for heat pumps varies depending on the vertical separation. See the tables below for
allowable lengths depending on whether the outdoor unit is on the same level, above or below the outdoor unit.
MAXIMUM LINE LENGTHS FOR HEAT PUMP APPLICATIONS
MAXIMUM ACTUAL LENGTH
ft (m)
MAXIMUM EQUIVALENT LENGTH{
ft (m)
MAXIMUM VERTICAL
SEPARATION ft (m)
Units on equal level 200 (61) 250 (76.2) N/A
Outdoor unit ABOVE
indoor unit 200 (61) 250 (76.2) 200 (61)
Outdoor unit BELOW
indoor unit See Table ’Maximum Total Equivalent Length: Outdoor Unit BELOW Indoor Unit’
{Total equivalent length accounts for losses due to elbows or fitting. See the Long Line Guideline for details.
MAXIMUM TOTAL EQUIVALENT LENGTH{-- OUTDOOR UNIT BELOW INDOOR UNIT
Size
Liquid Line
Diameter
w/ TXV
HP with PuronrRefrigerant --- Maximum Total Equivalent Length{
Vertical Separation ft (m) Outdoor unit BELOW indoor unit;
0 --- 2 0
(0 --- 6.1)
21 --- 30
(6.4 --- 9.1)
31 --- 40
(9.4 --- 12.2)
41 --- 50
(12.5 --- 15.2)
51 --- 60
(15.5 --- 18.3)
61 --- 70
(18.6 --- 21.3)
71 --- 80
(21.6 --- 24.4)
18000
HP with
Puron
3/8 250* 250* 250* 250* 250* 250* 250*
24000
HP with
Puron
3/8 250* 250* 250* 250* 250* 250* 250*
30000
HP with
Puron
3/8 250* 250* 250* 250* 250* 250* 250*
36000
HP with
Puron
3/8 250* 250* 250* 250* 250* 250* 250*
42000
HP with
Puron
3/8 250* 250* 250* 250* 250* 250* 150
48000
HP with
Puron
3/8 250* 250* 250* 250* 230 160 --- ---
60000
HP with
Puron
3/8 250* 225* 190 150 110 --- --- --- ---
* Maximum actual length not to exceed 200 ft (61 m)
{Total equivalent length accounts for losses due to elbows or fitting. See the Long Line Guideline for details.
--- --- = o u t s i d e a c c e p t a b l e r a n g e
LONG LINE APPLICATIONS
An application is considered Long Line when the refrigerant level in the system requires the use of accessories to maintain acceptable
refrigerant management for systems reliability. Defining a system as long line depends on the liquid line diameter, actual length of the tubing,
and vertical separation between the indoor and outdoor units.
For Heat Pump systems, the chart below shows when an application is considered Long Line. Beyond these lengths, long line accessories
are required:
HP WITH PURONRREFRIGERANT LONG LINE DESCRIPTION FT (M)
BEYOND THESE LENGTHS, LONG LINE ACCESSORIES ARE REQUIRED
Liquid Line Size Units On Same Level Outdoor Below Indoor Outdoor Above Indoor
3/8 80 (24.4) 20 (6.1) vertical or 80 (24.4) total 80 (24.4)
Note: SeeLongLineGuidelinefordetails
225B
5
ACCESSORIES
ORDER
NUMBER DESCRIPTION 018 --- A 024--- A 030 --- A 036 --- A 042 --- A 048 --- A 060 --- A
KAACH1701AAA CRANKCASE HTR X X X
KAACH1401AAA CRANKCASE HTR X
KAACH1601AAA CRANKCASE HTR X
KAACH1201AAA CRANKCASE HTR X
Standard CRANKCASE HTR S
KSACY0101AAA CYCLE PROTECTOR X X X X X X X
KAAFT0101AAA FREEZE THERMOSTAT X X X X X X X
KSAHS1701AAA HARD START (CAP/RELAY) X X X X X X X
KHAIR0101AAA ISOLATION RELAY X X X X X X X
KSALA0301410 LOW AMBIENT PSW X X X X X X X
HC32GE229 MOTOR FAN BALL BEARING X X X
HC38GE228 MOTOR FAN BALL BEARING X X
HC40GE228 MOTOR FAN BALL BEARING X X
KSALA0601AAA MOTORMASTER 230V X X X X X X X
KHAOT0201SEC OUTDOOR THERMOSTAT X X X X X X X
KHAOT0301FST OUTDOOR THERMOSTAT X X X X X X X
KHASS0606MPK* HEAT PUMP SNOW RACK X X X X X X X
KHALS0401LLS SOLENOID VALVE X X X X X X X
KAACS0201PTC STARTASSISTPTC X X X X X X X
KSASF0101AAA SUPPORT FEET X X X X X X X
KAATD0101TDR TIME DELAY X X X X X X X
KSATX0201PUR TXV PURON HSO X X X
KSATX0301PUR TXV PURON HSO X X
KSATX0401PUR TXV PURON HSO X
KSATX0501PUR TXV PURON HSO X
x = Accessory S = Standard
* Order through RCD ---Totaline, part number KHASS0606MPK (qty 6).
ACCESSORY THERMOSTATS
THERMOSTAT / SUBBASE
PKG. DESCRIPTION
T 6 --- P R H 0 1 --- A Programmable Thermidistat
T 6 --- N R H 0 1 --- A Non---programmable Thermidistat
T6---PHP01 Preferred Series Programmable HP Stat
T 6 --- N H P 0 1 Preferred Series Non--- programmable HP Stat
T2---PHP01 Legacy Series Programmable HP Stat
T 2 --- N H P 0 1 Legacy Series Non---programmable HP Stat
T1---PHP01 Legacy RNC Series Programmable HP Stat
T 1 --- N H P 0 1 Legacy RNC Series Non---programmable HP Stat
TSTATXXSEN01---B* Outdoor Air Temperature Sensor
TSTATXXNBP01 Backplate for Non---Programmable Thermostat
TSTATXXPBP01 Backplate for Programmable Thermostat and ThermidistattControl
TSTATXXSBP01 Backplate for Standard Programmable Thermostat
TSTATXXBBP01 Backplate for Builder’s Thermostat
TSTATXXCNV10** Thermostat Conversion Kit (4 to 5 Wire) — 10 Pack
* Outdoor temperature sensor is an accessory for all Bryant electronic thermostats, except the non ---programmable air conditioner version and builder;s
thermostats. It allows the temperature at a remote location (outdoors) to be displayed on the thermostat. The outdoor air temperature sensor must be used
with the HybridHeatt(dual fuel) thermostat. The outdoor air temperature sensor is included with the Thermidistat Control and HybridHeatt(dual fuel)
thermostat.
** Thermostat conversion kit is a 24---vac accessory that can turn a 4---wire thermostat application into a 5---wire application. This kit can also be used to
replace a broken thermostat wire, or add an extra wire when needed.
225B
6
ACCESSORY USAGE GUIDELINE
Accessory
REQUIRED FOR LOW--- AMBIENT
COOLING APPLICATIONS
(Below 55F / 12.8C)
REQUIRED FOR
LONG LINE APPLICATIONS*
REQUIRED FOR
SEA COAST APPLICATIONS
(Within 2 miles / 3.22 km)
Accumulator Standard Standard Standard
Ball Bearing Fan Motor Ye s {No No
Compressor Start Assist Capacitor and
Relay Ye s Ye s No
Crankcase Heater Ye s Ye s No
Evaporator Freeze Thermostat Ye s No No
Hard Shutoff TXV Ye s Ye s Ye s
Isolation Relay Ye s No No
Liquid Line Solenoid Valve No See Long---Line Application Guideline No
Motor MasterControl or
Low Ambient Switch Ye s No No
Support Feet Recommended No Recommended
* For tubing line sets between 80 and 200 ft. (24.38 and 60.96 m) and/or 20 ft. (6.09 m) vertical differential, refer to Residential Piping and Longline Guideline.
{Additional requirement for Low---Ambient Controller (full modulation feature) MotorMasterrControl.
Accessory Description and Usage (Listed Alphabetically)
1. Ball--Bearing Fan Motor
A fan motor with ball bearings which permits speed reduction
while maintaining bearing lubrication.
Usage Guideline:
Required on all units when using MotorMasterr
2. Compressor Start Assist -- Capacitor and Relay
Start capacitor and relay gives a ”hard” boost to compressor
motor at each start up.
Usage Guideline:
Required for reciprocating compressors in the
following applications:
Long line
Low ambient cooling
Hard shut off expansion valve on indoor coil
Liquid line solenoid on indoor coil
Required for single--phase scroll compressors in the
following applications:
Long line
Low ambient cooling
Suggested for all compressors in areas with a history of
low voltage problems.
3. Compressor Start Assist — PTC Type
Solid state electrical device which gives a ”soft” boost to the
compressor at each start--up.
Usage Guideline:
Suggested in installations with marginal power supply.
4. Crankcase Heater
An electric resistance heater which mounts to the base of the
compressor to keep the lubricant warm during off cycles.
Improves compressor lubrication on restart and minimizes the
chance of liquid slugging.
Usage Guideline:
Required in low ambient cooling applications.
Required in long line applications.
Suggested in all commercial applications.
5. Evaporator Freeze Thermostat
An SPST temperature--actuated switch that stops unit operation
when evaporator reaches freeze--up conditions.
Usage Guideline:
Required when low ambient kit has been added.
6. Isolation Relay
An SPDT relay which switches the low--ambient controller out of
the outdoor fan motor circuit when the heat pump switches to
heating mode.
Usage Guideline:
Required in all heat pumps where low ambient kit has
been added.
7. Liquid--Line Solenoid Valve (LLS)
An electrically operated shutoff valve which stops and starts
refrigerant liquid flow in response to compressor operation. It is
to be installed at the outdoor unit to control refrigerant off cycle
migration in the heating mode.
Usage Guideline:
An LLS is required in all long line heat pump
applications to control refrigerant off cycle migration in
the heating mode. See Long Line Guideline.
8. Low--Ambient Pressure Switch Kit
A long life pressure switch which is mounted to outdoor unit
service valve. It is designed to cycle the outdoor fan motor in
order to maintain head pressure within normal operating limits.
The control will maintain working head pressure at low--ambient
temperatures down to 0_F (--17.8_C)when properly installed.
Usage Guideline:
A Low--Ambient Pressure Switch or MotorMasterr
Low--Ambient Controller must be used when cooling
operation is used at outdoor temperatures below 55_F
(12.8_C).
9. MotorMasterrLow--Ambient Controller
A fan--speed control device activated by a temperature sensor,
designed to control condenser fan motor speed in response to the
saturated, condensing temperature during operation in cooling
mode only. For outdoor temperatures down to --20_F (--28.9_C),
it maintains condensing temperature at 100_F10_F (37.8_C
6.5_C).
Usage Guideline:
A MotorMasterrLow Ambient Controller or
Low--Ambient Pressure Switch must be used when
cooling operation is used at outdoor temperatures
below 55_F (12.8_C).
Suggested for all commercial applications.
225B
7
Accessory Description and Usage (Listed Alphabetically) -- CONTINUED
10. Outdoor Air Temperature Sensor
Designed for use with Bryant Thermostats listed in this
publication. This device enables the thermostat to display the
outdoor temperature. This device also is required to enable
special thermostat features such as auxiliary heat lock out.
Usage Guideline:
Suggested for all Bryant thermostats listed in this
publication.
11. Outdoor Thermostat
An SPDT temperature--actuated switch which turns on
supplemental electric heaters when outdoor air temperature drops
below a user--selected set point.
Usage Guideline:
Electric supplemental heat applications in non--variable
speed indoor units when electric heat staging is desired.
12. Secondary Outdoor Thermostat
An SPDT temperature--actuated switch which turns on
third--stage of supplemental electric heaters when outdoor air
temperature drops below the second--stage set point.
Usage Guideline:
Outdoor thermostat applications where electric heater is
capable of three--stage operation.
13. Snow Stand
Coated wire rack which supports unit 18 in. (457.2 mm) above
mounting pad to allow for drainage from unit base.
Usage Guideline:
Suggested in the following applications:
Heat pump installations in heavy snowfall areas.
Heat pump installations in snow drift locations.
Heat pump installations in areas of prolonged
subfreezing temperatures.
All commercial installations.
14. Thermostatic Expansion Valve (TXV) Bi--Flow
A modulating flow--control valve which meters refrigerant liquid
flow rate into the evaporator in response to the superheat of the
refrigerant gas leaving the evaporator.
Usage Guideline:
Accessory required to meet AHRI rating and system
reliability, where indoor not equipped.
Required in all heat pump applications designed with
Puron refrigerant.
15. Time--Delay Relay
An SPST delay relay which briefly continues operation of indoor
blower motor to provide additional cooling after the compressor
cycles off.
Note: Most indoor unit controls include this feature. For those
that do not, use the guideline below.
Usage Guideline:
Accessory required to meet AHRI rating, where indoor
not equipped.
225B
8
ELECTRICAL DATA
UNIT
SIZE V/PH OPER VOLTS* COMPR FAN MCA
MIN
WIRE
SIZE{
MIN
WIRE
SIZE{
MAX
LENGTH
ft (m)††
MAX
LENGTH
ft (m)††
MAX
FUSE**
or CKT
BRK
AMPS
MAX MIN LRA RLA FLA 60C75C60° C 75° C
018 --- A
208/230/1 253 197
48.0 9.00 0.5 11.8 14 14 67 (20.4) 63 (19.2) 20
024 --- A 58.3 12.80 0.5 16.5 14 14 48 (14.6) 45 (13.7) 25
030 --- A 73.0 14.10 0.5 18.1 14 14 44 (13.4 41 (12.5) 30
036 --- A 79.0 16.70 1.2 22.1 12 12 57 (17.4) 54 (16.5) 35
042 --- A 109.0 21.10 1.2 27.6 10 10 72 (21.9) 69 (21.0) 40
048 --- A 117.0 21.80 1.2 28.5 10 10 70 (21.3) 67 (20.4) 40
060 --- A 134.0 26.40 1.2 34.2 810 91 (27.7) 56 (17.1) 50
* Permissible limits of the voltage range at which the unit will operate satisfactorily
{If wire is applied at ambient greater than 30_C, consult table 310---16 of the NEC (ANSI/NFPA 70). The ampacity of non ---metallic---sheathed cable (NM),
trade name ROMEX, shall be that of 60_C conditions, per the NEC (ANSI/NFPA 70) Article 336---26. If other than uncoated (no---plated), 60 or 75_C
insulation, copper wire (solid wire for 10 AWG or smaller, stranded wire for larger than 10 AWG) is used, consult applicable tables of the NEC (ANSI/NFPA
70).
}Length shown is as measured 1 way along wire path between unit and service panel for voltage drop not to exceed 2%.
* * T i m e --- D e l a y f u s e .
FLA --- F u l l L o a d A m p s
LRA --- L o c k e d R o t o r A m p s
M C A --- Minimum Circuit Amps
RLA --- RatedLoadAmps
NOTE: Control circuit is 24---V on all units and requires external power source. Copper wire must be used from service disconnect to unit.
All motors/compressors contain internal overload protection.
Complies with 2007 requirements of ASHRAE Standards 90.1
A--WEIGHTED SOUND POWER
U N I T S I Z E ---
VOLTAGE,
SERIES
STANDARD
RATING
(dBA)
TYPICAL OCTAVE BAND SPECTRUM (dBA, without tone adjustment)
125 250 500 1000 2000 4000 8000
018 --- A 72 50.5 60.0 65.0 67.5 64.5 61.5 53.5
024 --- A 68 49.5 58.5 61.5 62.0 61.0 58.5 51.5
030 --- A 69 50.5 58.5 61.5 64.0 61.5 58.5 51.5
036 --- A 70 54.5 57.5 63.0 66.0 64.0 61.0 54.0
042 --- A 72 56.5 64.5 66.5 66.5 64.5 61.0 54.5
048 --- A 72 58.5 63.0 65.5 67.0 63.5 60.0 52.0
060 --- A 73 58.5 62.5 65.0 67.0 64.0 61.0 56.5
NOTE: Tested in accordance with AHRI Standard 270---08 (not listed in AHRI).
CHARGING SUBCOOLING (TXV--TYPE EXPANSION DEVICE)
UNIT SIZE--- VOLTAGE, SERIES REQUIRED SUBCOOLING ° F (° C)
018 --- A 12 (6.7)
024 --- A 14 (7.8)
030 --- A 10 (5.6)
036 --- A 8 (4.4)
042 --- A 10 (5.6)
048 --- A 11 (6.1)
060 --- A 10 (5.6)
225B
9
DIMENSIONS -- ENGLISH
B
3 13/16"
K
11/8"
L
C31/2" 17/8"
N
P
M
E
F
G
A
208-230-1-60
230-1-60
208/230-3-60
460-3-60
UNIT SIZE MINIMUM
MOUNTING PAD
DIMENSIONS
- 26" X 26"
18 31 1/2" X 31 1/2"
24,30,36,42,48,60 35" X 35"
UNIT SERIES ELECTRICAL
CHARACTERISTICS ABCDEFGKLMNP
OPERATING
WEIGHT (lbs)SHIPPING
WEIGHT (lbs) SHIPPING
DIMENSIONS (L x W x H)
225B018 A X O O O 31 3/16" 28 15/16" 3 3/4" 5/8" 6 9/16" 24 11/16" 9 1/8" 2 13/16" 1/2" 16" 15" 14" 169 207 32 5/16" X 35 1/2" X 32 9/16"
225B024 A X O O O 35" 32 5/16" 3 3/4" 5/8" 6 9/16" 28 7/16" 9 1/8" 2 13/16" 1/2" 15 3/4" 16 3/4" 16 1/2" 200 233 36 1/8" X 39 1/4" X 35 15/16"
225B030 A X O O O 35" 32 5/16" 3 3/4" 3/4" 6 9/16" 28 7/16" 9 1/8" 2 13/16" 1/2" 16 1/4" 16" 15 1/2" 196 242 36 1/8" X 39 1/4" X 35 15/16"
225B036 A X O O O 35" 35 3/4" 3 3/4" 3/4" 6 9/16" 28 7/16" 9 1/8" 2 13/16" 1/2" 15 3/4" 16 3/4" 17" 215 257 36 1/8" X 39 1/4" X 39 3/8"
225B042 A X O O O 35" 28 15/16" 3 7/8" 7/8" 6 9/16" 28 7/16" 9 1/8" 2 15/16" 5/8" 17" 16 3/4" 14 3/4" 245 290 36 1/8" X 39 1/4" X 32 9/16"
225B048 A X O O O 35" 28 15/16" 3 7/8" 7/8" 6 9/16" 28 7/16" 9 1/8" 2 15/16" 5/8" 16 3/4" 16 1/4" 14" 260 303 36 1/8" X 39 1/4" X 32 9/16"
225B060 A X O O O 35" 39 1/8" 3 7/8" 7/8" 6 9/16" 28 7/16" 9 1/8" 2 15/16" 5/8" 17 1/4" 16 1/4" 18 1/4" 294 345 36 1/8" X 39 1/4" X 42 3/4"
AIR
DISCHARGE
AIR DISCHARGE
SQ. AIR IN
VAPOR LINE CONN.
D
3/8"
LIQUID LINE CONN.
AIR IN
AIR IN
AIR IN
3/8" TIEDOWN KNOCKOUTS
(2) PLACES
FIELD CONTROL
SUPPLY CONN.
7/8" HOLE
FIELD POWER SUPPLY CONN.
7/8" HOLE WITH
1 1/8" KNOCKOUT
X = YES
O=NO
NOTES:
1. ALLOW 30" CLEARANCE TO SERVICE SIDE OF UNIT,
48" ABOVE UNIT, 6" ON ONE SIDE, 12" ON REMAINING SIDE,
AND 24" BETWEEN UNITS FOR PROPER AIRFLOW.
2. MINIMUM OUTDOOR OPERATING AMBIENT IN COOLING
MODE IS 55 F, MAX. 125
3. SERIES DESIGNATION IS THE 14TH POSITION OF THE
UNIT MODEL NUMBER.
4. CENTER OF GRAVITY .
5. ALL DIMENSIONS ARE IN "INCHES" UNLESS NOTED.
225B
10
DIMENSIONS -- SI
B
96.8
K
28.6
L
C88.9 47.6
N
P
M
E
F
G
A
208-230-1-60
230-1-60
208/230-3-60
460-3-60
UNIT SIZE MINIMUM
MOUNTING PAD
DIMENSIONS
- 660.4 X 660.4
18 800.1 X 800.1
24,30,36,42,48,60 889.0 X 889.0
UNIT SERIES ELECTRICAL
CHARACTERISTICS ABCDEFGKLMNP
OPERATING
WEIGHT (Kgs)
SHIPPING
WEIGHT (Kgs) SHIPPING
DIMENSIONS (L x W x H)
225B018 A X O O O 792.5 734.8 95.6 15.9 166.1 626.3 231.3 70.9 12.8 406.4 381.0 355.6 76.7 93.9 821.2 X 901.2 X 826.8
225B024 A X O O O 889.0 821.2 95.6 15.9 166.1 722.8 231.3 70.9 12.8 400.1 425.5 419.1 90.8 105.7 917.7 X 997.7 X 913.2
225B030 A X O O O 889.0 821.2 95.6 19.1 166.1 722.8 231.3 70.9 12.8 412.8 406.4 393.7 88.9 109.8 917.7 X 997.7 X 913.2
225B036 A X O O O 889.0 907.5 95.6 19.1 166.1 722.8 231.3 70.9 12.8 400.1 425.5 431.8 97.5 116.6 917.7 X 997.7 X 999.5
225B042 A X O O O 889.0 734.8 97.9 22.2 166.1 722.8 231.3 74.5 16.3 431.8 425.5 374.7 111.1 131.5 917.7 X 997.7 X 826.8
225B048 A X O O O 889.0 734.8 97.9 22.2 166.1 722.8 231.3 74.5 16.3 425.5 412.8 355.6 117.9 137.4 917.7 X 997.7 X 826.8
225B060 A X O O O 889.0 993.9 97.9 22.2 166.1 722.8 231.3 74.5 16.3 438.2 412.8 463.6 113.4 156.5 917.7 X 997.7 X 1085.9
AIR DISCHARGE
SQ. AIR
DISCHARGE
AIR IN
VAPOR LINE CONN.
D
AIR IN
AIR IN
AIR IN
9.53 TIEDOWN KNOCKOUTS
(2) PLACES
FIELD CONTROL
SUPPLY CONN.
22.23 HOLE
FIELD POWER SUPPLY CONN.
22.23 HOLE WITH
28.58 KNOCKOUT
X = YES
O=NO
C, MAX. 52
225B
11
225B BALANCE POINT WORKSHEET
0.0
2.9
5.9
8.8
11.7
14.6
17.6
20.5
23.4
0
10
20
30
40
50
60
70
80
BUILDING HEAT LOSS, UNIT INTEGRATED HEATING CAPACITY, MBTUH
225BNA018
FX4DNF019
225BNA024
FX4DNF025
225BNA042
FX4DNF043
225BNA030
FX4DNF031
225BNA060
FX4DNF061
225BNA048
FX4DNF049
225BNA036
FX4DNF037
- 10 (-23) 0 (-17.78) 10 (-12.22) 20 (-6.67) 30 (-1.11) 40 (4.44) 50 (10) 60 (15.56) 70 (21.11) 80 (26.67)
OUTDOOR TEMPERATURE, ºF (ºC)
BASED ON INDOOR ENT. AIR AT 70 ºF (21.1)
AND AT RATED CFM
kW
225B
12
CLEARANCES
Clearances (various examples)
Wall
Wall
Wall
Wall
24”
Service
6”
(152.4 mm)
24”
(609.6)
Service
24”
(609.6)
Service
24”
(609.6)
Service
24”
(609.6)
Service
24”
(609.6)
24”
(609.6)
24”
(609.6)
12”
(304.8)
12”
(304.8)
12”
(304.8)
12”
(304.8)
6”
(152.4)
Note: Numbers in ( ) = mm
IMPORTANT: When installing multiple units in an alcove, roof well, or partially enclosed area, ensure there is adequate ventilation to prevent re--circulation of discharge air.
A07833
225B
13
COMBINATION RATINGS
AHRI
Ref. No.
Model
Number Coil Model Number Furnace
Model Number
Cooling
Capacity EER SEER
High Temp
HSPF
Low Temp
E
Capacity ECOP H
Capacity HCOP
3677484 225BNA018****A †FX4DNF019 17,800 12.6 15.3 17,400 3.88 8.6 10,600 2.56
3677410 225BNA018****A FE4ANF002+UI 17,700 12.5 15.5 17,400 3.82 8.2 10,400 2.54
3677414 225BNA018****A FF1ENP018 17,200 11.2 13.0 18,000 3.50 7.7 11,100 2.34
3677415 225BNA018****A FF1ENP019 17,500 12.0 14.5 17,600 3.74 8.0 10,700 2.48
3677416 225BNA018****A FF1ENP024 17,400 11.2 13.0 18,000 3.56 7.7 11,100 2.38
3677418 225BNA018****A FF1ENP025 17,800 12.5 15.0 17,600 3.84 8.2 10,600 2.54
3677441 225BNA018****A FV4BNF002 17,700 13.0 15.5 17,400 3.82 8.2 10,400 2.54
3677457 225BNA018****A FV4CNF002 17,700 13.0 15.5 17,400 3.82 8.2 10,400 2.54
3677469 225BNA018****A FX4CNF018 17,500 12.2 14.5 17,600 3.74 8.1 10,600 2.50
3677470 225BNA018****A FX4CNF024 17,700 12.5 15.0 17,600 3.80 8.2 10,600 2.54
3677485 225BNA018****A FX4DNF025 18,000 12.6 15.0 17,400 3.88 8.3 10,600 2.56
3677489 225BNA018****A FY4ANF018 17,200 11.2 13.0 18,000 3.52 7.7 11,100 2.36
3677490 225BNA018****A FY4ANF024 17,200 11.0 13.0 18,000 3.50 7.7 11,200 2.34
3676324 225BNA018****A CAP**1814A** 313*AV024045 17,400 12.0 14.5 17,400 3.66 7.9 10,500 2.48
3676323 225BNA018****A CAP**1814A** 315(A,J)AV036070 17,200 12.0 14.5 17,100 3.56 7.7 10,300 2.44
3676325 225BNA018****A CAP**1814A**+TDR 17,200 11.0 13.0 18,000 3.50 7.7 11,100 2.36
3676327 225BNA018****A CAP**2414A** 313*AV024045 17,600 12.5 15.0 17,600 3.82 8.2 10,600 2.54
3676326 225BNA018****A CAP**2414A** 315(A,J)AV036070 17,400 12.5 15.0 17,300 3.68 7.9 10,400 2.48
3676330 225BNA018****A CAP**2414A**+TDR 17,400 11.2 13.5 18,000 3.60 7.8 11,200 2.40
3676333 225BNA018****A CAP**2417A** 315(A,J)AV048090 17,400 12.5 15.0 17,300 3.70 8.0 10,400 2.50
3676335 225BNA018****A CAP**2417A** 353(A,B)AV036060 17,800 12.5 15.5 17,600 3.90 8.3 10,600 2.58
3676334 225BNA018****A CAP**2417A** 353AAV036040 18,000 13.0 15.5 17,600 3.98 8.5 10,700 2.62
3676332 225BNA018****A CAP**2417A** 355(A,C)AV042060 17,400 12.5 15.0 17,300 3.70 8.0 10,400 2.48
3676341 225BNA018****A CAP**2417A** 355BAV042060 17,400 12.5 15.0 17,300 3.70 8.0 10,400 2.48
3676343 225BNA018****A CAP**2417A**+TDR 17,400 11.2 13.5 18,000 3.60 7.8 11,200 2.40
3676535 225BNA018****A CNPF*2418A**+TDR 17,400 11.2 13.5 18,000 3.64 7.8 11,200 2.40
3676546 225BNA018****A CNPH*2417A** 313*AV024045 17,600 12.5 15.0 17,600 3.82 8.2 10,600 2.52
3676544 225BNA018****A CNPH*2417A** 315(A,J)AV036070 17,300 12.5 15.0 17,300 3.70 7.9 10,400 2.48
3676545 225BNA018****A CNPH*2417A** 315(A,J)AV048090 17,400 12.5 15.0 17,300 3.74 8.0 10,400 2.50
3676548 225BNA018****A CNPH*2417A** 353(A,B)AV036060 17,600 12.5 15.0 17,500 3.84 8.2 10,500 2.54
3676547 225BNA018****A CNPH*2417A** 353AAV036040 17,800 12.5 15.5 17,600 3.94 8.4 10,600 2.58
3676542 225BNA018****A CNPH*2417A** 355(A,C)AV042060 17,400 12.5 15.0 17,300 3.72 8.0 10,400 2.50
3676543 225BNA018****A CNPH*2417A** 355(A,C)AV042080 17,300 12.5 15.0 17,300 3.70 8.0 10,400 2.48
3676541 225BNA018****A CNPH*2417A** 355AAV042040 17,400 12.5 15.0 17,300 3.72 8.0 10,400 2.50
3676568 225BNA018****A CNPH*2417A** 355BAV042060 17,400 12.5 15.0 17,300 3.72 8.0 10,400 2.50
3676569 225BNA018****A CNPH*2417A** 355BAV042080 17,300 12.5 15.0 17,300 3.70 8.0 10,400 2.48
3676549 225BNA018****A CNPH*2417A** 359BAV036040 18,000 12.2 14.5 18,000 3.92 8.3 11,000 2.54
3676550 225BNA018****A CNPH*2417A** 359BAV036060 18,000 12.2 14.5 18,000 3.94 8.4 10,900 2.56
3676575 225BNA018****A CNPH*2417A**+TDR 17,400 11.2 13.5 18,000 3.64 7.8 11,200 2.40
3676858 225BNA018****A CNPV*1814A** 313*AV024045 17,400 12.0 14.5 17,400 3.72 7.9 10,500 2.48
3676857 225BNA018****A CNPV*1814A** 315(A,J)AV036070 17,200 12.0 14.5 17,100 3.66 7.7 10,400 2.46
3676859 225BNA018****A CNPV*1814A**+TDR 17,200 11.2 13.0 18,000 3.60 7.7 11,100 2.38
3676861 225BNA018****A CNPV*1917A** 315(A,J)AV048090 17,600 12.5 15.0 17,400 3.78 8.1 10,400 2.52
3676863 225BNA018****A CNPV*1917A** 353(A,B)AV036060 18,000 13.0 15.5 17,600 3.96 8.5 10,600 2.60
3676862 225BNA018****A CNPV*1917A** 353AAV036040 18,000 13.0 15.5 17,600 4.06 8.6 10,700 2.64
3676860 225BNA018****A CNPV*1917A** 355(A,C)AV042060 17,500 12.5 15.0 17,400 3.76 8.5 10,400 2.52
3676864 225BNA018****A CNPV*1917A** 355BAV042060 17,500 12.5 15.0 17,400 3.76 8.5 10,400 2.52
3676865 225BNA018****A CNPV*1917A**+TDR 17,600 11.2 13.0 18,000 3.66 7.9 11,200 2.40
3676867 225BNA018****A CNPV*2414A** 313*AV024045 17,600 12.5 15.0 17,600 3.82 8.2 10,600 2.52
3676866 225BNA018****A CNPV*2414A** 315(A,J)AV036070 17,400 12.5 15.0 17,300 3.70 7.9 10,400 2.48
3676870 225BNA018****A CNPV*2414A**+TDR 17,400 11.2 13.5 18,000 3.64 7.8 11,200 2.40
3676873 225BNA018****A CNPV*2417A** 315(A,J)AV048090 17,400 12.5 15.0 17,300 3.74 8.0 10,400 2.50
3676875 225BNA018****A CNPV*2417A** 353(A,B)AV036060 17,600 12.5 15.0 17,500 3.84 8.2 10,500 2.54
3676874 225BNA018****A CNPV*2417A** 353AAV036040 17,800 12.5 15.5 17,600 3.94 8.4 10,600 2.58
3676872 225BNA018****A CNPV*2417A** 355(A,C)AV042060 17,400 12.5 15.0 17,300 3.72 8.0 10,400 2.50
3676881 225BNA018****A CNPV*2417A** 355BAV042060 17,400 12.5 15.0 17,300 3.72 8.0 10,400 2.50
3676883 225BNA018****A CNPV*2417A**+TDR 17,400 11.2 13.5 18,000 3.64 7.8 11,200 2.40
3677125 225BNA018****A CSPH*2412A** 313*AV024045 17,600 12.5 15.0 17,600 3.80 8.1 10,600 2.52
3677123 225BNA018****A CSPH*2412A** 315(A,J)AV036070 17,400 12.5 15.0 17,300 3.70 7.9 10,400 2.48
3677124 225BNA018****A CSPH*2412A** 315(A,J)AV048090 17,400 12.5 15.0 17,300 3.72 8.0 10,500 2.50
3677127 225BNA018****A CSPH*2412A** 353(A,B)AV036060 17,600 12.5 15.0 17,300 3.76 8.1 10,400 2.52
3677126 225BNA018****A CSPH*2412A** 353AAV036040 17,800 12.5 15.5 17,600 3.88 8.3 10,600 2.56
3677121 225BNA018****A CSPH*2412A** 355(A,C)AV042060 17,400 12.5 15.0 17,300 3.72 8.0 10,500 2.50
3677122 225BNA018****A CSPH*2412A** 355(A,C)AV042080 17,500 12.5 15.0 17,300 3.70 8.0 10,400 2.48
3677120 225BNA018****A CSPH*2412A** 355AAV042040 17,500 12.5 15.0 17,300 3.72 8.0 10,500 2.50
3677147 225BNA018****A CSPH*2412A** 355BAV042060 17,400 12.5 15.0 17,300 3.72 8.0 10,500 2.50
3677148 225BNA018****A CSPH*2412A** 355BAV042080 17,500 12.5 15.0 17,300 3.70 8.0 10,400 2.48
3677128 225BNA018****A CSPH*2412A** 359BAV036040 18,000 12.2 14.5 18,000 3.92 8.3 11,000 2.54
3677129 225BNA018****A CSPH*2412A** 359BAV036060 18,000 12.2 14.5 18,000 3.92 8.4 10,900 2.54
3677154 225BNA018****A CSPH*2412A**+TDR 17,400 11.2 13.5 18,000 3.64 7.8 11,200 2.40
3677486 225BNA024****A †FX4DNF025 24,000 12.5 15.3 24,000 3.94 8.7 14,800 2.70
3677398 225BNA024****A FE4AN(B,F)003+UI 23,800 12.5 15.5 24,000 3.92 9.0 14,400 2.72
3677411 225BNA024****A FE4ANF002+UI 23,800 12.5 15.5 24,000 3.92 9.0 14,500 2.70
3677417 225BNA024****A FF1ENP024 23,400 11.0 13.0 24,000 3.64 8.1 15,300 2.52
3677419 225BNA024****A FF1ENP025 23,800 12.0 14.5 24,000 3.84 8.5 14,800 2.64
3677420 225BNA024****A FF1ENP030 23,400 11.0 13.5 24,000 3.64 8.2 15,200 2.52
3677422 225BNA024****A FF1ENP031 23,800 12.0 14.5 24,000 3.84 8.5 14,900 2.64
3677426 225BNA024****A FF1ENP037 23,800 12.0 15.0 24,000 3.92 8.7 14,900 2.68
See notes on pg. 28
225B
14
COMBINATION RATINGS CONTINUED
AHRI
Ref. No.
Model
Number Coil Model Number Furnace
Model Number
Cooling
Capacity EER SEER
High Temp
HSPF
Low Temp
E
Capacity ECOP H
Capacity HCOP
3677429 225BNA024****A FV4BN(B,F)003 23,800 12.5 15.5 24,000 3.92 9.0 14,400 2.72
3677442 225BNA024****A FV4BNF002 23,800 12.5 15.5 24,000 3.92 9.0 14,500 2.70
3677445 225BNA024****A FV4CN(B,F)003 23,800 12.5 15.5 24,000 3.92 9.0 14,400 2.72
3677458 225BNA024****A FV4CNF002 23,800 12.5 15.5 24,000 3.92 9.0 14,500 2.70
3677471 225BNA024****A FX4CNF024 23,800 12.0 15.0 24,000 3.82 8.5 14,700 2.64
3677472 225BNA024****A FX4CNF030 23,800 12.5 15.5 24,000 3.94 8.7 14,700 2.70
3677474 225BNA024****A FX4DN(B,F)031 24,000 12.2 15.0 24,000 3.94 8.7 14,900 2.70
3677491 225BNA024****A FY4ANF024 23,400 11.0 13.5 24,000 3.62 8.1 15,200 2.52
3677492 225BNA024****A FY4ANF030 23,800 11.5 13.5 24,000 3.72 8.3 15,200 2.56
3676329 225BNA024****A CAP**2414A** 313*AV024045 23,400 12.2 15.0 24,000 3.82 8.5 14,600 2.64
3676328 225BNA024****A CAP**2414A** 315(A,J)AV036070 23,400 12.5 15.0 24,000 3.76 8.3 14,200 2.60
3676331 225BNA024****A CAP**2414A**+TDR 23,400 11.2 13.5 24,000 3.70 8.3 15,300 2.54
3676337 225BNA024****A CAP**2417A** 315(A,J)AV048090 23,400 12.5 15.5 24,000 3.80 8.4 14,400 2.66
3676339 225BNA024****A CAP**2417A** 353(A,B)AV036060 23,400 12.5 15.5 24,000 3.98 8.8 14,600 2.72
3676340 225BNA024****A CAP**2417A** 353(A,B)AV036080 23,400 12.5 15.5 24,000 3.94 8.7 14,600 2.70
3676338 225BNA024****A CAP**2417A** 353AAV036040 23,400 12.5 15.5 24,000 3.96 8.7 14,600 2.72
3676336 225BNA024****A CAP**2417A** 355(A,C)AV042060 23,400 12.5 15.5 24,000 3.88 8.6 14,600 2.68
3676342 225BNA024****A CAP**2417A** 355BAV042060 23,400 12.5 15.5 24,000 3.88 8.6 14,600 2.68
3676344 225BNA024****A CAP**2417A**+TDR 23,400 11.2 13.5 24,000 3.70 8.3 15,300 2.54
3676346 225BNA024****A CAP**3014A** 313*AV024045 23,400 12.5 15.0 24,000 3.86 8.6 14,700 2.68
3676345 225BNA024****A CAP**3014A** 315(A,J)AV036070 23,400 12.5 15.0 24,000 3.78 8.4 14,500 2.64
3676348 225BNA024****A CAP**3014A**+TDR 23,400 11.2 13.5 24,000 3.72 8.3 15,300 2.56
3676351 225BNA024****A CAP**3017A** 315(A,J)AV048090 23,400 12.5 15.5 24,000 3.84 8.5 14,400 2.68
3676353 225BNA024****A CAP**3017A** 353(A,B)AV036060 23,400 12.5 15.5 24,000 4.02 9.0 14,700 2.76
3676354 225BNA024****A CAP**3017A** 353(A,B)AV036080 23,400 12.5 15.5 24,000 3.98 9.0 14,600 2.74
3676352 225BNA024****A CAP**3017A** 353AAV036040 23,400 12.5 15.5 24,000 4.02 9.0 14,700 2.76
3676350 225BNA024****A CAP**3017A** 355(A,C)AV042060 23,400 12.5 15.5 24,000 3.92 9.0 14,600 2.72
3676362 225BNA024****A CAP**3017A** 355BAV042060 23,400 12.5 15.5 24,000 3.92 9.0 14,600 2.72
3676364 225BNA024****A CAP**3017A**+TDR 23,400 11.2 13.5 24,000 3.72 8.3 15,300 2.56
3676389 225BNA024****A CAP**3619A** 359BAV036040 24,000 12.5 15.0 24,000 3.92 8.7 14,800 2.68
3676390 225BNA024****A CAP**3619A** 359BAV036060 24,000 12.5 15.0 24,000 3.98 8.8 14,900 2.72
3676536 225BNA024****A CNPF*2418A**+TDR 23,400 11.2 13.5 24,000 3.78 8.3 15,300 2.56
3676562 225BNA024****A CNPH*2417A** 313*AV024045 23,400 12.0 15.0 24,000 3.86 8.5 14,600 2.64
3676557 225BNA024****A CNPH*2417A** 315(A,J)AV036070 23,400 12.5 15.0 24,000 3.82 8.3 14,500 2.64
3676558 225BNA024****A CNPH*2417A** 315(A,J)AV048090 23,400 12.5 15.0 24,000 3.86 8.4 14,500 2.66
3676559 225BNA024****A CNPH*2417A** 315(A,J)AV060110 23,400 12.5 15.0 24,000 3.86 8.5 14,500 2.64
3676560 225BNA024****A CNPH*2417A** 315(A,J)AV066135 23,400 12.5 15.0 24,000 3.86 8.5 14,500 2.66
3676561 225BNA024****A CNPH*2417A** 315(A,J)AV066155 23,400 12.5 15.0 24,000 3.86 8.5 14,500 2.66
3676564 225BNA024****A CNPH*2417A** 353(A,B)AV036060 23,400 12.5 15.0 24,000 3.98 8.7 14,600 2.70
3676565 225BNA024****A CNPH*2417A** 353(A,B)AV036080 23,400 12.5 15.0 24,000 3.94 8.7 14,600 2.68
3676563 225BNA024****A CNPH*2417A** 353AAV036040 23,400 12.5 15.0 24,000 3.96 8.7 14,600 2.70
3676552 225BNA024****A CNPH*2417A** 355(A,C)AV042060 23,400 12.5 15.0 24,000 3.94 8.6 14,600 2.68
3676553 225BNA024****A CNPH*2417A** 355(A,C)AV042080 23,400 12.5 15.0 24,000 3.84 8.5 14,500 2.64
3676554 225BNA024****A CNPH*2417A** 355(A,C)AV060080 23,200 12.5 15.0 24,000 3.78 8.3 14,100 2.58
3676555 225BNA024****A CNPH*2417A** 355(A,C)AV060100 23,400 12.5 15.0 24,000 3.86 8.5 14,500 2.66
3676556 225BNA024****A CNPH*2417A** 355(A,C)AV060120 23,400 12.5 15.0 24,000 3.90 8.6 14,500 2.68
3676551 225BNA024****A CNPH*2417A** 355AAV042040 23,400 12.2 15.0 24,000 3.84 8.5 14,600 2.64
3676570 225BNA024****A CNPH*2417A** 355BAV042060 23,400 12.5 15.0 24,000 3.94 8.6 14,600 2.68
3676571 225BNA024****A CNPH*2417A** 355BAV042080 23,400 12.5 15.0 24,000 3.84 8.5 14,500 2.64
3676572 225BNA024****A CNPH*2417A** 355BAV060080 23,200 12.5 15.0 24,000 3.78 8.3 14,100 2.58
3676573 225BNA024****A CNPH*2417A** 355BAV060100 23,400 12.5 15.0 24,000 3.86 8.5 14,500 2.66
3676574 225BNA024****A CNPH*2417A** 355BAV060120 23,400 12.5 15.0 24,000 3.90 8.6 14,500 2.68
3676566 225BNA024****A CNPH*2417A** 359BAV036040 23,400 12.2 14.5 24,000 3.86 8.5 14,800 2.62
3676567 225BNA024****A CNPH*2417A** 359BAV036060 23,400 12.2 14.5 24,000 3.90 8.5 14,800 2.64
3676576 225BNA024****A CNPH*2417A**+TDR 23,400 11.2 13.5 24,000 3.78 8.3 15,300 2.56
3676588 225BNA024****A CNPH*3017A** 313*AV024045 23,400 12.5 15.0 24,000 3.90 8.5 14,700 2.68
3676583 225BNA024****A CNPH*3017A** 315(A,J)AV036070 23,400 12.5 15.0 24,000 3.80 8.4 14,500 2.66
3676584 225BNA024****A CNPH*3017A** 315(A,J)AV048090 23,400 12.5 15.5 24,000 3.84 8.5 14,400 2.68
3676585 225BNA024****A CNPH*3017A** 315(A,J)AV060110 23,400 12.5 15.5 24,000 3.84 8.5 14,500 2.68
3676586 225BNA024****A CNPH*3017A** 315(A,J)AV066135 23,400 12.5 15.5 24,000 3.84 8.5 14,500 2.68
3676587 225BNA024****A CNPH*3017A** 315(A,J)AV066155 23,400 12.5 15.5 24,000 3.86 8.5 14,500 2.68
3676590 225BNA024****A CNPH*3017A** 353(A,B)AV036060 23,400 12.5 15.5 24,000 4.02 9.0 14,700 2.76
3676591 225BNA024****A CNPH*3017A** 353(A,B)AV036080 23,400 12.5 15.5 24,000 3.98 9.0 14,600 2.74
3676589 225BNA024****A CNPH*3017A** 353AAV036040 23,400 12.5 15.5 24,000 4.02 9.0 14,700 2.76
3676578 225BNA024****A CNPH*3017A** 355(A,C)AV042060 23,400 12.5 15.5 24,000 3.92 9.0 14,600 2.72
3676579 225BNA024****A CNPH*3017A** 355(A,C)AV042080 23,400 12.5 15.5 24,000 3.82 8.5 14,400 2.66
3676580 225BNA024****A CNPH*3017A** 355(A,C)AV060080 23,400 12.5 15.0 24,000 3.76 8.3 14,100 2.60
3676581 225BNA024****A CNPH*3017A** 355(A,C)AV060100 23,400 12.5 15.5 24,000 3.84 8.5 14,400 2.68
3676582 225BNA024****A CNPH*3017A** 355(A,C)AV060120 23,400 12.5 15.5 24,000 3.88 8.6 14,500 2.70
3676577 225BNA024****A CNPH*3017A** 355AAV042040 23,400 12.5 15.0 24,000 3.82 8.5 14,500 2.66
3676613 225BNA024****A CNPH*3017A** 355BAV042060 23,400 12.5 15.5 24,000 3.92 9.0 14,600 2.72
3676614 225BNA024****A CNPH*3017A** 355BAV042080 23,400 12.5 15.5 24,000 3.82 8.5 14,400 2.66
3676615 225BNA024****A CNPH*3017A** 355BAV060080 23,400 12.5 15.0 24,000 3.76 8.3 14,100 2.60
3676616 225BNA024****A CNPH*3017A** 355BAV060100 23,400 12.5 15.5 24,000 3.84 8.5 14,400 2.68
3676617 225BNA024****A CNPH*3017A** 355BAV060120 23,400 12.5 15.5 24,000 3.88 8.6 14,500 2.70
3676592 225BNA024****A CNPH*3017A** 359BAV036040 23,600 12.2 14.5 24,000 3.88 8.5 14,800 2.68
3676593 225BNA024****A CNPH*3017A** 359BAV036060 23,600 12.2 14.5 24,000 3.94 8.5 14,900 2.70
3676623 225BNA024****A CNPH*3017A**+TDR 23,400 11.2 13.5 24,000 3.74 8.3 15,300 2.56
3676625 225BNA024****A CNPH*3117A** 359BAV036040 24,000 12.5 15.0 24,000 4.06 8.8 14,900 2.74
See notes on pg. 28
225B
15
COMBINATION RATINGS CONTINUED
AHRI
Ref. No.
Model
Number Coil Model Number Furnace
Model Number
Cooling
Capacity EER SEER
High Temp
HSPF
Low Temp
E
Capacity ECOP H
Capacity HCOP
3676626 225BNA024****A CNPH*3117A** 359BAV036060 24,000 12.5 15.0 24,000 4.16 8.8 15,000 2.76
3676869 225BNA024****A CNPV*2414A** 313*AV024045 23,400 12.2 15.0 24,000 3.86 8.5 14,600 2.64
3676868 225BNA024****A CNPV*2414A** 315(A,J)AV036070 23,400 12.5 15.0 24,000 3.82 8.3 14,500 2.64
3676871 225BNA024****A CNPV*2414A**+TDR 23,400 11.2 13.5 24,000 3.78 8.3 15,300 2.56
3676877 225BNA024****A CNPV*2417A** 315(A,J)AV048090 23,400 12.5 15.0 24,000 3.86 8.4 14,500 2.66
3676879 225BNA024****A CNPV*2417A** 353(A,B)AV036060 23,400 12.5 15.0 24,000 3.98 8.7 14,600 2.70
3676880 225BNA024****A CNPV*2417A** 353(A,B)AV036080 23,400 12.5 15.0 24,000 3.94 8.7 14,600 2.68
3676878 225BNA024****A CNPV*2417A** 353AAV036040 23,400 12.5 15.0 24,000 3.96 8.7 14,600 2.70
3676876 225BNA024****A CNPV*2417A** 355(A,C)AV042060 23,400 12.5 15.0 24,000 3.94 8.6 14,600 2.68
3676882 225BNA024****A CNPV*2417A** 355BAV042060 23,400 12.5 15.0 24,000 3.94 8.6 14,600 2.68
3676884 225BNA024****A CNPV*2417A**+TDR 23,400 11.2 13.5 24,000 3.78 8.3 15,300 2.56
3676886 225BNA024****A CNPV*3014A** 313*AV024045 23,400 12.5 15.0 24,000 3.84 8.5 14,700 2.66
3676885 225BNA024****A CNPV*3014A** 315(A,J)AV036070 23,400 12.5 15.0 24,000 3.80 8.4 14,500 2.66
3676888 225BNA024****A CNPV*3014A**+TDR 23,400 11.2 13.5 24,000 3.74 8.3 15,300 2.56
3676891 225BNA024****A CNPV*3017A** 315(A,J)AV048090 23,400 12.5 15.5 24,000 3.84 8.5 14,400 2.68
3676893 225BNA024****A CNPV*3017A** 353(A,B)AV036060 23,400 12.5 15.5 24,000 4.02 9.0 14,700 2.76
3676894 225BNA024****A CNPV*3017A** 353(A,B)AV036080 23,400 12.5 15.5 24,000 3.98 9.0 14,600 2.74
3676892 225BNA024****A CNPV*3017A** 353AAV036040 23,400 12.5 15.5 24,000 4.02 9.0 14,700 2.76
3676890 225BNA024****A CNPV*3017A** 355(A,C)AV042060 23,400 12.5 15.5 24,000 3.92 9.0 14,600 2.72
3676902 225BNA024****A CNPV*3017A** 355BAV042060 23,400 12.5 15.5 24,000 3.92 9.0 14,600 2.72
3676904 225BNA024****A CNPV*3017A**+TDR 23,400 11.2 13.5 24,000 3.74 8.3 15,300 2.56
3676908 225BNA024****A CNPV*3117A** 315(A,J)AV048090 23,400 12.5 15.5 24,000 4.02 8.8 14,500 2.74
3676910 225BNA024****A CNPV*3117A** 353(A,B)AV036060 23,400 13.0 15.5 24,000 4.24 9.0 14,800 2.82
3676911 225BNA024****A CNPV*3117A** 353(A,B)AV036080 23,400 13.0 15.5 24,000 4.18 9.0 14,700 2.80
3676909 225BNA024****A CNPV*3117A** 353AAV036040 23,400 13.0 15.5 24,000 4.22 9.0 14,800 2.82
3676907 225BNA024****A CNPV*3117A** 355(A,C)AV042060 23,400 13.0 16.0 24,000 4.10 9.0 14,700 2.78
3676919 225BNA024****A CNPV*3117A** 355BAV042060 23,400 13.0 16.0 24,000 4.10 9.0 14,700 2.78
3676906 225BNA024****A CNPV*3117A** 23,400 11.5 14.0 24,000 3.90 8.6 15,400 2.62
3677141 225BNA024****A CSPH*2412A** 313*AV024045 23,400 12.2 15.0 24,000 3.84 8.5 14,600 2.66
3677136 225BNA024****A CSPH*2412A** 315(A,J)AV036070 23,400 12.5 15.0 24,000 3.82 8.4 14,500 2.64
3677137 225BNA024****A CSPH*2412A** 315(A,J)AV048090 23,400 12.5 15.5 24,000 3.86 8.4 14,500 2.66
3677138 225BNA024****A CSPH*2412A** 315(A,J)AV060110 23,400 12.5 15.0 24,000 3.84 8.5 14,600 2.66
3677139 225BNA024****A CSPH*2412A** 315(A,J)AV066135 23,400 12.5 15.0 24,000 3.84 8.5 14,600 2.66
3677140 225BNA024****A CSPH*2412A** 315(A,J)AV066155 23,400 12.5 15.0 24,000 3.86 8.5 14,600 2.66
3677143 225BNA024****A CSPH*2412A** 353(A,B)AV036060 23,400 12.5 15.5 24,000 3.96 8.7 14,700 2.70
3677144 225BNA024****A CSPH*2412A** 353(A,B)AV036080 23,400 12.5 15.5 24,000 3.92 8.6 14,600 2.70
3677142 225BNA024****A CSPH*2412A** 353AAV036040 23,400 12.5 15.5 24,000 3.94 8.7 14,600 2.70
3677131 225BNA024****A CSPH*2412A** 355(A,C)AV042060 23,400 12.5 15.0 24,000 3.94 8.6 14,700 2.70
3677132 225BNA024****A CSPH*2412A** 355(A,C)AV042080 23,400 12.5 15.0 24,000 3.82 8.5 14,500 2.64
3677133 225BNA024****A CSPH*2412A** 355(A,C)AV060080 23,400 12.5 15.0 24,000 3.76 8.3 14,200 2.60
3677134 225BNA024****A CSPH*2412A** 355(A,C)AV060100 23,400 12.5 15.0 24,000 3.84 8.5 14,500 2.66
3677135 225BNA024****A CSPH*2412A** 355(A,C)AV060120 23,400 12.5 15.0 24,000 3.90 8.6 14,600 2.68
3677130 225BNA024****A CSPH*2412A** 355AAV042040 23,400 12.5 15.0 24,000 3.84 8.5 14,600 2.66
3677149 225BNA024****A CSPH*2412A** 355BAV042060 23,400 12.5 15.0 24,000 3.94 8.6 14,700 2.70
3677150 225BNA024****A CSPH*2412A** 355BAV042080 23,400 12.5 15.0 24,000 3.82 8.5 14,500 2.64
3677151 225BNA024****A CSPH*2412A** 355BAV060080 23,400 12.5 15.0 24,000 3.76 8.3 14,200 2.60
3677152 225BNA024****A CSPH*2412A** 355BAV060100 23,400 12.5 15.0 24,000 3.84 8.5 14,500 2.66
3677153 225BNA024****A CSPH*2412A** 355BAV060120 23,400 12.5 15.0 24,000 3.90 8.6 14,600 2.68
3677145 225BNA024****A CSPH*2412A** 359BAV036040 23,400 12.2 14.5 24,000 3.84 8.5 14,800 2.64
3677146 225BNA024****A CSPH*2412A** 359BAV036060 23,400 12.2 14.5 24,000 3.88 8.5 14,900 2.66
3677155 225BNA024****A CSPH*2412A**+TDR 23,400 11.2 13.5 24,000 3.78 8.3 15,300 2.58
3677167 225BNA024****A CSPH*3012A** 313*AV024045 23,400 12.5 15.0 24,000 3.88 8.5 14,700 2.68
3677162 225BNA024****A CSPH*3012A** 315(A,J)AV036070 23,400 12.5 15.0 24,000 3.80 8.4 14,500 2.66
3677163 225BNA024****A CSPH*3012A** 315(A,J)AV048090 23,400 12.5 15.5 24,000 3.84 8.5 14,500 2.68
3677164 225BNA024****A CSPH*3012A** 315(A,J)AV060110 23,400 12.5 15.5 24,000 3.84 8.5 14,500 2.66
3677165 225BNA024****A CSPH*3012A** 315(A,J)AV066135 23,400 12.5 15.5 24,000 3.84 8.5 14,500 2.68
3677166 225BNA024****A CSPH*3012A** 315(A,J)AV066155 23,400 12.5 15.5 24,000 3.84 8.5 14,500 2.68
3677169 225BNA024****A CSPH*3012A** 353(A,B)AV036060 23,400 12.5 15.5 24,000 4.00 9.0 14,700 2.74
3677170 225BNA024****A CSPH*3012A** 353(A,B)AV036080 23,400 12.5 15.5 24,000 3.96 9.0 14,600 2.72
3677168 225BNA024****A CSPH*3012A** 353AAV036040 23,400 12.5 15.5 24,000 3.98 9.0 14,700 2.74
3677157 225BNA024****A CSPH*3012A** 355(A,C)AV042060 23,400 12.5 15.5 24,000 3.92 9.0 14,600 2.70
3677158 225BNA024****A CSPH*3012A** 355(A,C)AV042080 23,400 12.5 15.5 24,000 3.80 8.4 14,500 2.66
3677159 225BNA024****A CSPH*3012A** 355(A,C)AV060080 23,400 12.5 15.0 24,000 3.74 8.3 14,100 2.60
3677160 225BNA024****A CSPH*3012A** 355(A,C)AV060100 23,400 12.5 15.5 24,000 3.82 8.5 14,500 2.66
3677161 225BNA024****A CSPH*3012A** 355(A,C)AV060120 23,400 12.5 15.5 24,000 3.88 8.6 14,500 2.70
3677156 225BNA024****A CSPH*3012A** 355AAV042040 23,400 12.5 15.0 24,000 3.82 8.5 14,500 2.66
3677192 225BNA024****A CSPH*3012A** 355BAV042060 23,400 12.5 15.5 24,000 3.92 9.0 14,600 2.70
3677193 225BNA024****A CSPH*3012A** 355BAV042080 23,400 12.5 15.5 24,000 3.80 8.4 14,500 2.66
3677194 225BNA024****A CSPH*3012A** 355BAV060080 23,400 12.5 15.0 24,000 3.74 8.3 14,100 2.60
3677195 225BNA024****A CSPH*3012A** 355BAV060100 23,400 12.5 15.5 24,000 3.82 8.5 14,500 2.66
3677196 225BNA024****A CSPH*3012A** 355BAV060120 23,400 12.5 15.5 24,000 3.88 8.6 14,500 2.70
3677171 225BNA024****A CSPH*3012A** 359BAV036040 23,600 12.2 14.5 24,000 3.86 8.5 14,800 2.66
3677172 225BNA024****A CSPH*3012A** 359BAV036060 23,600 12.2 14.5 24,000 3.92 8.5 14,900 2.68
3677202 225BNA024****A CSPH*3012A**+TDR 23,400 11.2 13.5 24,000 3.76 8.3 15,300 2.58
3677475 225BNA030****A †FX4DN(B,F)031 28,400 12.5 15.3 28,400 3.98 8.7 17,000 2.66
3677399 225BNA030****A FE4AN(B,F)003+UI 28,200 12.5 15.5 28,000 3.92 8.3 16,600 2.66
3677402 225BNA030****A FE4AN(B,F)005+UI 28,800 13.0 15.5 28,000 4.14 8.7 16,700 2.74
3677412 225BNA030****A FE4ANF002+UI 28,000 12.5 15.0 28,200 3.90 8.3 16,700 2.62
See notes on pg. 28
225B
16
COMBINATION RATINGS CONTINUED
AHRI
Ref. No.
Model
Number Coil Model Number Furnace
Model Number
Cooling
Capacity EER SEER
High Temp
HSPF
Low Temp
E
Capacity ECOP H
Capacity HCOP
3677421 225BNA030****A FF1ENP030 27,400 11.2 13.0 29,000 3.68 7.9 17,400 2.48
3677423 225BNA030****A FF1ENP031 28,000 12.0 14.5 28,600 3.86 8.2 17,000 2.60
3677424 225BNA030****A FF1ENP036 28,000 11.2 13.5 29,000 3.72 8.0 17,500 2.50
3677427 225BNA030****A FF1ENP037 28,200 12.0 14.0 28,800 3.86 8.2 17,200 2.58
3677430 225BNA030****A FV4BN(B,F)003 28,200 12.5 15.5 28,000 3.92 8.3 16,600 2.66
3677433 225BNA030****A FV4BN(B,F)005 28,800 13.0 15.5 28,000 4.14 8.7 16,700 2.74
3677443 225BNA030****A FV4BNF002 28,000 12.5 15.0 28,200 3.90 8.3 16,700 2.62
3677446 225BNA030****A FV4CN(B,F)003 28,200 12.5 15.5 28,000 3.92 8.3 16,600 2.64
3677449 225BNA030****A FV4CN(B,F)005 28,800 13.0 15.5 28,000 4.14 8.7 16,700 2.74
3677459 225BNA030****A FV4CNF002 28,000 12.5 15.0 28,200 3.90 8.3 16,700 2.62
3677461 225BNA030****A FX4CN(B,F)036 28,200 12.0 14.0 28,800 3.88 8.3 17,200 2.58
3677473 225BNA030****A FX4CNF030 28,000 12.0 14.5 28,600 3.90 8.3 17,000 2.60
3677476 225BNA030****A FX4DN(B,F)037 29,000 12.5 15.0 28,800 4.12 8.7 17,100 2.70
3677493 225BNA030****A FY4ANF030 27,600 11.2 13.0 29,000 3.72 8.0 17,500 2.48
3677494 225BNA030****A FY4ANF036 27,800 11.2 13.0 29,200 3.70 8.0 17,700 2.48
3676347 225BNA030****A CAP**3014A** 315(A,J)AV036070 27,600 12.0 14.5 28,200 3.78 8.1 16,700 2.58
3676349 225BNA030****A CAP**3014A**+TDR 27,800 11.2 13.0 29,200 3.72 8.0 17,600 2.50
3676357 225BNA030****A CAP**3017A** 313*AV048070 27,800 12.0 14.5 28,400 3.82 8.2 16,900 2.60
3676356 225BNA030****A CAP**3017A** 315(A,J)AV048090 27,800 12.5 15.0 28,000 3.82 8.2 16,600 2.60
3676359 225BNA030****A CAP**3017A** 353(A,B)AV036060 28,000 12.5 15.0 28,400 3.92 8.3 16,800 2.64
3676360 225BNA030****A CAP**3017A** 353(A,B)AV036080 28,000 12.5 15.0 28,200 3.90 8.3 16,800 2.64
3676361 225BNA030****A CAP**3017A** 353(A,B)AV048080 28,000 12.5 15.0 28,400 3.94 8.4 17,000 2.64
3676358 225BNA030****A CAP**3017A** 353AAV036040 28,000 12.5 15.0 28,200 3.92 8.3 16,800 2.64
3676355 225BNA030****A CAP**3017A** 355(A,C)AV042060 27,800 12.5 15.0 28,200 3.86 8.2 16,700 2.62
3676363 225BNA030****A CAP**3017A** 355BAV042060 27,800 12.5 15.0 28,200 3.86 8.2 16,700 2.62
3676365 225BNA030****A CAP**3017A**+TDR 27,800 11.2 13.0 29,200 3.72 8.0 17,600 2.50
3676366 225BNA030****A CAP**3614A** 315(A,J)AV036070 27,800 12.0 14.5 28,200 3.80 8.1 16,700 2.58
3676369 225BNA030****A CAP**3614A**+TDR 27,800 11.2 13.0 29,200 3.74 8.0 17,600 2.50
3676373 225BNA030****A CAP**3617A** 313*AV048070 28,000 12.0 14.5 28,400 3.86 8.2 16,900 2.60
3676372 225BNA030****A CAP**3617A** 315(A,J)AV048090 27,800 12.5 15.0 28,000 3.86 8.2 16,600 2.62
3676375 225BNA030****A CAP**3617A** 353(A,B)AV036060 28,000 12.5 15.0 28,400 3.96 8.5 16,900 2.66
3676376 225BNA030****A CAP**3617A** 353(A,B)AV036080 28,000 12.5 15.0 28,400 3.94 8.5 16,800 2.64
3676377 225BNA030****A CAP**3617A** 353(A,B)AV048080 28,000 12.5 15.0 28,600 3.96 8.5 17,000 2.66
3676374 225BNA030****A CAP**3617A** 353AAV036040 28,000 12.5 15.0 28,400 3.96 8.5 16,800 2.66
3676371 225BNA030****A CAP**3617A** 355(A,C)AV042060 27,800 12.5 15.0 28,200 3.88 8.5 16,700 2.62
3676385 225BNA030****A CAP**3617A** 355BAV042060 27,800 12.5 15.0 28,200 3.88 8.5 16,700 2.62
3676387 225BNA030****A CAP**3617A**+TDR 27,800 11.2 13.0 29,200 3.74 8.0 17,600 2.50
3676391 225BNA030****A CAP**3619A** 359BAV036040 27,800 12.0 14.0 28,600 3.80 8.1 17,100 2.56
3676392 225BNA030****A CAP**3619A** 359BAV036060 27,800 12.0 14.5 28,600 3.86 8.2 17,100 2.60
3676395 225BNA030****A CAP**3619A**+TDR 27,800 11.2 13.0 29,200 3.74 8.0 17,600 2.50
3676401 225BNA030****A CAP**3621A** 313*AV048090 28,000 12.5 15.0 28,400 3.94 8.4 16,900 2.66
3676400 225BNA030****A CAP**3621A** 315(A,J)AV060110 27,800 12.5 15.0 28,000 3.88 8.3 16,600 2.64
3676397 225BNA030****A CAP**3621A** 355(A,C)AV042080 27,800 12.5 15.0 28,000 3.82 8.1 16,600 2.60
3676398 225BNA030****A CAP**3621A** 355(A,C)AV060080 27,800 12.5 15.0 28,000 3.84 8.2 16,600 2.62
3676399 225BNA030****A CAP**3621A** 355(A,C)AV060100 27,600 12.5 15.0 28,000 3.80 8.1 16,500 2.60
3676409 225BNA030****A CAP**3621A** 355BAV042080 27,800 12.5 15.0 28,000 3.82 8.1 16,600 2.60
3676410 225BNA030****A CAP**3621A** 355BAV060080 27,800 12.5 15.0 28,000 3.84 8.2 16,600 2.62
3676411 225BNA030****A CAP**3621A** 355BAV060100 27,600 12.5 15.0 28,000 3.80 8.1 16,500 2.60
3676415 225BNA030****A CAP**3621A**+TDR 27,800 11.2 13.0 29,200 3.74 8.0 17,600 2.50
3676537 225BNA030****A CNPF*3618A**+TDR 27,800 11.2 13.0 29,200 3.72 8.0 17,600 2.50
3676605 225BNA030****A CNPH*3017A** 313*AV048070 27,800 12.0 14.5 28,400 3.82 8.2 16,900 2.58
3676606 225BNA030****A CNPH*3017A** 313*AV048090 27,800 12.0 14.5 28,400 3.86 8.2 16,800 2.62
3676600 225BNA030****A CNPH*3017A** 315(A,J)AV036070 27,800 12.0 14.5 28,200 3.80 8.1 16,700 2.58
3676601 225BNA030****A CNPH*3017A** 315(A,J)AV048090 27,800 12.5 15.0 28,000 3.84 8.2 16,600 2.60
3676602 225BNA030****A CNPH*3017A** 315(A,J)AV060110 27,800 12.5 15.0 28,200 3.84 8.2 16,700 2.62
3676603 225BNA030****A CNPH*3017A** 315(A,J)AV066135 27,800 12.5 15.0 28,000 3.84 8.2 16,600 2.62
3676604 225BNA030****A CNPH*3017A** 315(A,J)AV066155 27,800 12.5 15.0 28,000 3.86 8.2 16,600 2.62
3676608 225BNA030****A CNPH*3017A** 353(A,B)AV036060 28,000 12.5 15.0 28,400 3.92 8.3 16,800 2.64
3676609 225BNA030****A CNPH*3017A** 353(A,B)AV036080 28,000 12.5 15.0 28,200 3.90 8.3 16,800 2.64
3676610 225BNA030****A CNPH*3017A** 353(A,B)AV048080 28,000 12.2 15.0 28,400 3.92 8.4 17,000 2.64
3676607 225BNA030****A CNPH*3017A** 353AAV036040 28,000 12.5 15.0 28,200 3.90 8.3 16,800 2.64
3676595 225BNA030****A CNPH*3017A** 355(A,C)AV042060 27,800 12.5 15.0 28,200 3.86 8.2 16,700 2.62
3676596 225BNA030****A CNPH*3017A** 355(A,C)AV042080 27,600 12.0 14.5 28,000 3.78 8.1 16,600 2.58
3676597 225BNA030****A CNPH*3017A** 355(A,C)AV060080 27,800 12.0 14.5 28,200 3.82 8.1 16,700 2.60
3676598 225BNA030****A CNPH*3017A** 355(A,C)AV060100 27,600 12.0 14.5 28,000 3.76 8.0 16,600 2.58
3676599 225BNA030****A CNPH*3017A** 355(A,C)AV060120 27,800 12.5 15.0 28,000 3.84 8.2 16,600 2.62
3676594 225BNA030****A CNPH*3017A** 355AAV042040 27,600 12.0 14.5 28,200 3.80 8.1 16,700 2.58
3676618 225BNA030****A CNPH*3017A** 355BAV042060 27,800 12.5 15.0 28,200 3.86 8.2 16,700 2.62
3676619 225BNA030****A CNPH*3017A** 355BAV042080 27,600 12.0 14.5 28,000 3.78 8.1 16,600 2.58
3676620 225BNA030****A CNPH*3017A** 355BAV060080 27,800 12.0 14.5 28,200 3.82 8.1 16,700 2.60
3676621 225BNA030****A CNPH*3017A** 355BAV060100 27,600 12.0 14.5 28,000 3.76 8.0 16,600 2.58
3676622 225BNA030****A CNPH*3017A** 355BAV060120 27,800 12.5 15.0 28,000 3.84 8.2 16,600 2.62
3676611 225BNA030****A CNPH*3017A** 359BAV036040 27,800 11.5 14.0 28,600 3.76 8.1 17,000 2.54
3676612 225BNA030****A CNPH*3017A** 359BAV036060 28,000 12.0 14.5 28,600 3.82 8.2 17,100 2.58
3676624 225BNA030****A CNPH*3017A**+TDR 27,800 11.2 13.0 29,200 3.72 8.0 17,600 2.50
3676627 225BNA030****A CNPH*3117A** 359BAV036040 28,400 12.2 14.5 28,800 3.94 8.4 17,200 2.62
3676628 225BNA030****A CNPH*3117A** 359BAV036060 28,600 12.2 14.5 29,000 4.00 8.5 17,200 2.64
3676640 225BNA030****A CNPH*3617A** 313*AV048070 27,800 12.0 14.5 28,400 3.82 8.2 16,900 2.58
3676641 225BNA030****A CNPH*3617A** 313*AV048090 28,000 12.0 14.5 28,400 3.86 8.2 16,800 2.62
See notes on pg. 28
225B
17
COMBINATION RATINGS CONTINUED
AHRI
Ref. No.
Model
Number Coil Model Number Furnace
Model Number
Cooling
Capacity EER SEER
High Temp
HSPF
Low Temp
E
Capacity ECOP H
Capacity HCOP
3676635 225BNA030****A CNPH*3617A** 315(A,J)AV036070 27,800 12.0 14.5 28,200 3.80 8.1 16,700 2.58
3676636 225BNA030****A CNPH*3617A** 315(A,J)AV048090 27,800 12.5 15.0 28,000 3.84 8.2 16,600 2.60
3676637 225BNA030****A CNPH*3617A** 315(A,J)AV060110 27,800 12.5 15.0 28,000 3.84 8.2 16,700 2.62
3676638 225BNA030****A CNPH*3617A** 315(A,J)AV066135 27,800 12.5 15.0 28,000 3.84 8.2 16,600 2.62
3676639 225BNA030****A CNPH*3617A** 315(A,J)AV066155 27,800 12.5 15.0 28,000 3.86 8.2 16,600 2.62
3676643 225BNA030****A CNPH*3617A** 353(A,B)AV036060 28,000 12.5 15.0 28,400 3.92 8.5 16,800 2.64
3676644 225BNA030****A CNPH*3617A** 353(A,B)AV036080 28,000 12.5 15.0 28,200 3.90 8.5 16,800 2.64
3676645 225BNA030****A CNPH*3617A** 353(A,B)AV048080 28,000 12.2 15.0 28,600 3.92 8.5 17,000 2.64
3676642 225BNA030****A CNPH*3617A** 353AAV036040 28,000 12.5 15.0 28,200 3.90 8.5 16,800 2.64
3676630 225BNA030****A CNPH*3617A** 355(A,C)AV042060 27,800 12.5 15.0 28,200 3.86 8.5 16,700 2.62
3676631 225BNA030****A CNPH*3617A** 355(A,C)AV042080 27,600 12.0 14.5 28,000 3.78 8.1 16,600 2.58
3676632 225BNA030****A CNPH*3617A** 355(A,C)AV060080 27,800 12.0 14.5 28,000 3.82 8.1 16,700 2.60
3676633 225BNA030****A CNPH*3617A** 355(A,C)AV060100 27,600 12.0 14.5 28,000 3.76 8.0 16,600 2.58
3676634 225BNA030****A CNPH*3617A** 355(A,C)AV060120 27,800 12.5 15.0 28,000 3.84 8.2 16,600 2.62
3676629 225BNA030****A CNPH*3617A** 355AAV042040 27,600 12.0 14.5 28,200 3.80 8.1 16,700 2.58
3676672 225BNA030****A CNPH*3617A** 355BAV042060 27,800 12.5 15.0 28,200 3.86 8.5 16,700 2.62
3676673 225BNA030****A CNPH*3617A** 355BAV042080 27,600 12.0 14.5 28,000 3.78 8.1 16,600 2.58
3676674 225BNA030****A CNPH*3617A** 355BAV060080 27,800 12.0 14.5 28,000 3.82 8.1 16,700 2.60
3676675 225BNA030****A CNPH*3617A** 355BAV060100 27,600 12.0 14.5 28,000 3.76 8.0 16,600 2.58
3676676 225BNA030****A CNPH*3617A** 355BAV060120 27,800 12.5 15.0 28,000 3.84 8.2 16,600 2.62
3676646 225BNA030****A CNPH*3617A** 359BAV036040 27,800 11.5 14.0 28,600 3.76 8.1 17,000 2.54
3676647 225BNA030****A CNPH*3617A** 359BAV036060 28,000 12.0 14.5 28,600 3.82 8.2 17,100 2.58
3676682 225BNA030****A CNPH*3617A**+TDR 27,800 11.2 13.0 29,200 3.72 8.0 17,600 2.50
3676887 225BNA030****A CNPV*3014A** 315(A,J)AV036070 27,600 12.0 14.5 28,200 3.78 8.1 16,800 2.58
3676889 225BNA030****A CNPV*3014A**+TDR 27,800 11.2 13.0 29,200 3.72 8.0 17,600 2.50
3676897 225BNA030****A CNPV*3017A** 313*AV048070 27,800 12.0 14.5 28,400 3.82 8.2 16,900 2.58
3676896 225BNA030****A CNPV*3017A** 315(A,J)AV048090 27,800 12.5 15.0 28,000 3.84 8.2 16,600 2.60
3676899 225BNA030****A CNPV*3017A** 353(A,B)AV036060 28,000 12.5 15.0 28,400 3.92 8.3 16,800 2.64
3676900 225BNA030****A CNPV*3017A** 353(A,B)AV036080 28,000 12.5 15.0 28,200 3.90 8.3 16,800 2.64
3676901 225BNA030****A CNPV*3017A** 353(A,B)AV048080 28,000 12.2 15.0 28,400 3.92 8.4 17,000 2.64
3676898 225BNA030****A CNPV*3017A** 353AAV036040 28,000 12.5 15.0 28,200 3.90 8.3 16,800 2.64
3676895 225BNA030****A CNPV*3017A** 355(A,C)AV042060 27,800 12.5 15.0 28,200 3.86 8.2 16,700 2.62
3676903 225BNA030****A CNPV*3017A** 355BAV042060 27,800 12.5 15.0 28,200 3.86 8.2 16,700 2.62
3676905 225BNA030****A CNPV*3017A**+TDR 27,800 11.2 13.0 29,200 3.72 8.0 17,600 2.50
3676914 225BNA030****A CNPV*3117A** 313*AV048070 28,600 12.5 15.0 28,800 4.00 8.5 17,100 2.66
3676913 225BNA030****A CNPV*3117A** 315(A,J)AV048090 28,400 12.5 15.5 28,400 4.00 8.5 16,700 2.68
3676916 225BNA030****A CNPV*3117A** 353(A,B)AV036060 28,800 12.5 15.0 28,800 4.12 8.7 17,000 2.70
3676917 225BNA030****A CNPV*3117A** 353(A,B)AV036080 28,800 12.5 15.5 28,600 4.08 8.6 16,900 2.70
3676918 225BNA030****A CNPV*3117A** 353(A,B)AV048080 29,000 12.5 15.0 28,800 4.14 8.7 17,100 2.70
3676915 225BNA030****A CNPV*3117A** 353AAV036040 28,800 12.5 15.5 28,600 4.12 8.7 16,900 2.72
3676912 225BNA030****A CNPV*3117A** 355(A,C)AV042060 28,600 12.5 15.0 28,400 4.04 8.5 16,800 2.68
3676920 225BNA030****A CNPV*3117A** 355BAV042060 28,600 12.5 15.0 28,400 4.04 8.5 16,800 2.68
3676921 225BNA030****A CNPV*3117A**+TDR 28,600 11.5 13.5 29,400 3.90 8.3 17,800 2.56
3676925 225BNA030****A CNPV*3617A** 313*AV048070 27,800 12.0 14.5 28,400 3.82 8.2 16,900 2.58
3676924 225BNA030****A CNPV*3617A** 315(A,J)AV048090 27,800 12.5 15.0 28,000 3.84 8.2 16,600 2.60
3676927 225BNA030****A CNPV*3617A** 353(A,B)AV036060 28,000 12.5 15.0 28,400 3.92 8.5 16,800 2.64
3676928 225BNA030****A CNPV*3617A** 353(A,B)AV036080 28,000 12.5 15.0 28,200 3.90 8.5 16,800 2.64
3676929 225BNA030****A CNPV*3617A** 353(A,B)AV048080 28,000 12.2 15.0 28,600 3.92 8.5 17,000 2.64
3676926 225BNA030****A CNPV*3617A** 353AAV036040 28,000 12.5 15.0 28,200 3.90 8.5 16,800 2.64
3676923 225BNA030****A CNPV*3617A** 355(A,C)AV042060 27,800 12.5 15.0 28,200 3.86 8.5 16,700 2.62
3676937 225BNA030****A CNPV*3617A** 355BAV042060 27,800 12.5 15.0 28,200 3.86 8.5 16,700 2.62
3676939 225BNA030****A CNPV*3617A**+TDR 27,800 11.2 13.0 29,200 3.72 8.0 17,600 2.50
3676945 225BNA030****A CNPV*3621A** 313*AV048090 28,000 12.0 14.5 28,400 3.86 8.2 16,800 2.62
3676944 225BNA030****A CNPV*3621A** 315(A,J)AV060110 27,800 12.5 15.0 28,000 3.84 8.2 16,700 2.62
3676941 225BNA030****A CNPV*3621A** 355(A,C)AV042080 27,600 12.0 14.5 28,000 3.78 8.1 16,600 2.58
3676942 225BNA030****A CNPV*3621A** 355(A,C)AV060080 27,800 12.2 15.0 28,000 3.82 8.1 16,700 2.60
3676943 225BNA030****A CNPV*3621A** 355(A,C)AV060100 27,600 12.0 14.5 28,000 3.76 8.0 16,600 2.58
3676953 225BNA030****A CNPV*3621A** 355BAV042080 27,600 12.0 14.5 28,000 3.78 8.1 16,600 2.58
3676954 225BNA030****A CNPV*3621A** 355BAV060080 27,800 12.2 15.0 28,000 3.82 8.1 16,700 2.60
3676955 225BNA030****A CNPV*3621A** 355BAV060100 27,600 12.0 14.5 28,000 3.76 8.0 16,600 2.58
3676959 225BNA030****A CNPV*3621A**+TDR 27,800 11.2 13.0 29,200 3.72 8.0 17,600 2.50
3676963 225BNA030****A CNPV*3717A** 313*AV048070 29,000 12.5 15.0 28,800 4.12 8.7 17,200 2.68
3676962 225BNA030****A CNPV*3717A** 315(A,J)AV048090 28,800 12.5 15.5 28,400 4.12 8.6 16,800 2.70
3676965 225BNA030****A CNPV*3717A** 353(A,B)AV036060 28,800 12.5 15.5 28,600 4.24 8.9 17,100 2.74
3676966 225BNA030****A CNPV*3717A** 353(A,B)AV036080 29,200 12.5 15.5 28,600 4.20 8.8 17,000 2.74
3676967 225BNA030****A CNPV*3717A** 353(A,B)AV048080 29,400 12.5 15.5 28,800 4.24 8.9 17,200 2.74
3676964 225BNA030****A CNPV*3717A** 353AAV036040 28,800 13.0 15.5 28,600 4.22 8.9 17,000 2.74
3676961 225BNA030****A CNPV*3717A** 355(A,C)AV042060 28,800 12.5 15.5 28,600 4.16 8.7 16,900 2.72
3676975 225BNA030****A CNPV*3717A** 355BAV042060 28,800 12.5 15.5 28,600 4.16 8.7 16,900 2.72
3676977 225BNA030****A CNPV*3717A**+TDR 28,800 11.5 13.5 29,400 3.96 8.4 17,900 2.58
3677184 225BNA030****A CSPH*3012A** 313*AV048070 27,800 12.0 14.5 28,400 3.82 8.1 16,900 2.58
3677185 225BNA030****A CSPH*3012A** 313*AV048090 27,800 12.0 14.5 28,200 3.84 8.2 16,800 2.60
3677179 225BNA030****A CSPH*3012A** 315(A,J)AV036070 27,800 12.0 14.5 28,200 3.82 8.1 16,800 2.58
3677180 225BNA030****A CSPH*3012A** 315(A,J)AV048090 27,800 12.5 15.0 28,200 3.84 8.2 16,700 2.60
3677181 225BNA030****A CSPH*3012A** 315(A,J)AV060110 27,800 12.5 15.0 28,200 3.84 8.2 16,700 2.60
3677182 225BNA030****A CSPH*3012A** 315(A,J)AV066135 27,800 12.5 15.0 28,000 3.86 8.2 16,700 2.62
3677183 225BNA030****A CSPH*3012A** 315(A,J)AV066155 27,800 12.5 15.0 28,200 3.86 8.2 16,700 2.62
3677187 225BNA030****A CSPH*3012A** 353(A,B)AV036060 28,000 12.5 15.0 28,400 3.90 8.3 16,900 2.64
3677188 225BNA030****A CSPH*3012A** 353(A,B)AV036080 28,000 12.5 15.0 28,200 3.88 8.3 16,800 2.62
See notes on pg. 28
225B
18
COMBINATION RATINGS CONTINUED
AHRI
Ref. No.
Model
Number Coil Model Number Furnace
Model Number
Cooling
Capacity EER SEER
High Temp
HSPF
Low Temp
E
Capacity ECOP H
Capacity HCOP
3677189 225BNA030****A CSPH*3012A** 353(A,B)AV048080 28,000 12.0 14.5 28,400 3.92 8.3 17,000 2.64
3677186 225BNA030****A CSPH*3012A** 353AAV036040 28,000 12.5 15.0 28,200 3.90 8.3 16,800 2.64
3677174 225BNA030****A CSPH*3012A** 355(A,C)AV042060 27,800 12.5 15.0 28,200 3.88 8.2 16,800 2.62
3677175 225BNA030****A CSPH*3012A** 355(A,C)AV042080 27,600 12.0 14.5 28,200 3.78 8.1 16,700 2.58
3677176 225BNA030****A CSPH*3012A** 355(A,C)AV060080 27,800 12.0 14.5 28,200 3.82 8.1 16,700 2.60
3677177 225BNA030****A CSPH*3012A** 355(A,C)AV060100 27,600 12.0 14.5 28,000 3.76 8.0 16,600 2.58
3677178 225BNA030****A CSPH*3012A** 355(A,C)AV060120 27,800 12.5 15.0 28,000 3.86 8.2 16,700 2.62
3677173 225BNA030****A CSPH*3012A** 355AAV042040 27,600 12.0 14.5 28,200 3.80 8.1 16,800 2.58
3677197 225BNA030****A CSPH*3012A** 355BAV042060 27,800 12.5 15.0 28,200 3.88 8.2 16,800 2.62
3677198 225BNA030****A CSPH*3012A** 355BAV042080 27,600 12.0 14.5 28,200 3.78 8.1 16,700 2.58
3677199 225BNA030****A CSPH*3012A** 355BAV060080 27,800 12.0 14.5 28,200 3.82 8.1 16,700 2.60
3677200 225BNA030****A CSPH*3012A** 355BAV060100 27,600 12.0 14.5 28,000 3.76 8.0 16,600 2.58
3677201 225BNA030****A CSPH*3012A** 355BAV060120 27,800 12.5 15.0 28,000 3.86 8.2 16,700 2.62
3677190 225BNA030****A CSPH*3012A** 359BAV036040 27,800 11.5 14.0 28,600 3.76 8.1 17,000 2.54
3677191 225BNA030****A CSPH*3012A** 359BAV036060 28,000 12.0 14.5 28,600 3.80 8.1 17,100 2.56
3677203 225BNA030****A CSPH*3012A**+TDR 27,800 11.2 13.0 29,200 3.74 8.0 17,700 2.52
3677215 225BNA030****A CSPH*3612A** 313*AV048070 28,000 12.0 14.5 28,600 3.96 8.3 17,000 2.64
3677216 225BNA030****A CSPH*3612A** 313*AV048090 28,000 12.5 15.0 28,600 4.02 8.3 17,000 2.68
3677210 225BNA030****A CSPH*3612A** 315(A,J)AV036070 27,800 12.0 14.5 28,400 3.92 8.2 16,800 2.64
3677211 225BNA030****A CSPH*3612A** 315(A,J)AV048090 27,800 12.5 15.0 28,200 3.96 8.3 16,700 2.66
3677212 225BNA030****A CSPH*3612A** 315(A,J)AV060110 27,800 12.5 15.0 28,000 3.98 8.3 16,800 2.66
3677213 225BNA030****A CSPH*3612A** 315(A,J)AV066135 27,800 12.5 15.0 28,200 3.98 8.3 16,700 2.66
3677214 225BNA030****A CSPH*3612A** 315(A,J)AV066155 27,800 12.5 15.0 28,200 3.98 8.3 16,700 2.68
3677218 225BNA030****A CSPH*3612A** 353(A,B)AV036060 28,000 12.5 15.0 28,600 4.06 8.5 17,000 2.70
3677219 225BNA030****A CSPH*3612A** 353(A,B)AV036080 28,000 12.5 15.0 28,600 4.04 8.5 16,900 2.68
3677220 225BNA030****A CSPH*3612A** 353(A,B)AV048080 28,000 12.5 15.0 28,800 4.08 8.5 17,100 2.70
3677217 225BNA030****A CSPH*3612A** 353AAV036040 28,000 12.5 15.0 28,600 4.06 8.5 16,900 2.70
3677205 225BNA030****A CSPH*3612A** 355(A,C)AV042060 27,800 12.5 15.0 28,400 4.00 8.5 16,800 2.68
3677206 225BNA030****A CSPH*3612A** 355(A,C)AV042080 27,800 12.5 15.0 28,200 3.90 8.2 16,700 2.62
3677207 225BNA030****A CSPH*3612A** 355(A,C)AV060080 27,800 12.5 15.0 28,000 3.94 8.3 16,800 2.64
3677208 225BNA030****A CSPH*3612A** 355(A,C)AV060100 27,800 12.5 15.0 28,200 3.88 8.2 16,700 2.62
3677209 225BNA030****A CSPH*3612A** 355(A,C)AV060120 27,800 12.5 15.0 28,200 3.98 8.3 16,700 2.66
3677204 225BNA030****A CSPH*3612A** 355AAV042040 27,800 12.0 14.5 28,400 3.92 8.2 16,800 2.64
3677247 225BNA030****A CSPH*3612A** 355BAV042060 27,800 12.5 15.0 28,400 4.00 8.5 16,800 2.68
3677248 225BNA030****A CSPH*3612A** 355BAV042080 27,800 12.5 15.0 28,200 3.90 8.2 16,700 2.62
3677249 225BNA030****A CSPH*3612A** 355BAV060080 27,800 12.5 15.0 28,000 3.94 8.3 16,800 2.64
3677250 225BNA030****A CSPH*3612A** 355BAV060100 27,800 12.5 15.0 28,200 3.88 8.2 16,700 2.62
3677251 225BNA030****A CSPH*3612A** 355BAV060120 27,800 12.5 15.0 28,200 3.98 8.3 16,700 2.66
3677221 225BNA030****A CSPH*3612A** 359BAV036040 27,800 12.0 14.5 28,600 3.90 8.1 17,100 2.60
3677222 225BNA030****A CSPH*3612A** 359BAV036060 28,000 12.0 14.5 28,600 3.96 8.2 17,200 2.62
3677257 225BNA030****A CSPH*3612A**+TDR 27,800 11.2 13.0 29,200 3.86 8.0 17,800 2.54
3677477 225BNA036****A †FX4DN(B,F)037 34,800 12.5 15.0 35,200 3.88 8.7 22,000 2.64
3677400 225BNA036****A FE4AN(B,F)003+UI 33,800 12.0 14.5 34,200 3.70 8.2 21,200 2.56
3677403 225BNA036****A FE4AN(B,F)005+UI 35,000 12.5 15.0 34,600 3.92 8.6 21,600 2.66
3677406 225BNA036****A FE4ANB006+UI 35,400 13.0 15.5 34,400 4.02 8.7 21,600 2.72
3677413 225BNA036****A FE4ANF002+UI 33,600 12.0 14.0 34,600 3.68 8.1 21,600 2.52
3677425 225BNA036****A FF1ENP036 33,600 11.0 13.0 35,600 3.52 7.8 22,600 2.44
3677428 225BNA036****A FF1ENP037 33,600 11.2 13.0 35,400 3.58 7.9 22,400 2.48
3677431 225BNA036****A FV4BN(B,F)003 33,800 12.0 14.5 34,200 3.70 8.2 21,200 2.56
3677434 225BNA036****A FV4BN(B,F)005 35,000 12.5 15.0 34,600 3.92 8.6 21,600 2.66
3677437 225BNA036****A FV4BNB006 35,400 13.0 15.5 34,400 4.02 8.8 21,600 2.72
3677444 225BNA036****A FV4BNF002 33,600 12.0 14.0 34,600 3.68 8.1 21,600 2.52
3677447 225BNA036****A FV4CN(B,F)003 33,800 12.0 14.5 34,200 3.70 8.2 21,200 2.56
3677450 225BNA036****A FV4CN(B,F)005 35,000 12.5 15.0 34,600 3.92 8.6 21,600 2.66
3677453 225BNA036****A FV4CNB006 35,400 13.0 15.5 34,400 4.02 8.8 21,600 2.72
3677460 225BNA036****A FV4CNF002 33,600 12.0 14.0 34,600 3.68 8.1 21,600 2.52
3677462 225BNA036****A FX4CN(B,F)036 34,000 12.0 14.0 35,000 3.72 8.2 22,000 2.56
3677463 225BNA036****A FX4CN(B,F)042 34,600 12.0 14.0 35,400 3.78 8.3 22,200 2.58
3677478 225BNA036****A FX4DN(B,F)043 34,800 12.5 15.0 34,000 3.88 8.5 22,000 2.64
3677495 225BNA036****A FY4ANF036 33,600 11.0 13.0 35,600 3.54 7.8 22,600 2.44
3677496 225BNA036****A FY4ANF042 34,200 11.0 13.0 35,800 3.62 8.0 22,800 2.48
3676368 225BNA036****A CAP**3614A** 313*AV024045 33,200 11.0 13.5 34,800 3.52 7.8 22,000 2.46
3676367 225BNA036****A CAP**3614A** 315(A,J)AV036070 33,200 11.5 14.0 34,400 3.56 7.9 21,600 2.50
3676370 225BNA036****A CAP**3614A**+TDR 33,200 11.0 13.0 35,200 3.52 7.8 22,400 2.44
3676380 225BNA036****A CAP**3617A** 313*AV048070 33,400 11.5 14.0 34,600 3.60 7.9 21,800 2.50
3676379 225BNA036****A CAP**3617A** 315(A,J)AV048090 33,400 12.0 14.5 34,200 3.62 8.0 21,400 2.54
3676382 225BNA036****A CAP**3617A** 353(A,B)AV036060 33,600 12.0 14.0 34,600 3.68 8.1 21,600 2.56
3676383 225BNA036****A CAP**3617A** 353(A,B)AV036080 33,600 12.0 14.5 34,400 3.66 8.1 21,600 2.54
3676384 225BNA036****A CAP**3617A** 353(A,B)AV048080 33,600 12.0 14.0 34,600 3.68 8.1 21,600 2.56
3676381 225BNA036****A CAP**3617A** 353AAV036040 33,600 12.0 14.5 34,400 3.68 8.1 21,600 2.56
3676378 225BNA036****A CAP**3617A** 355(A,C)AV042060 33,600 12.0 14.0 34,400 3.64 8.0 21,600 2.54
3676386 225BNA036****A CAP**3617A** 355BAV042060 33,600 12.0 14.0 34,400 3.64 8.0 21,600 2.54
3676388 225BNA036****A CAP**3617A**+TDR 33,600 11.0 13.0 35,600 3.58 7.9 22,600 2.46
3676393 225BNA036****A CAP**3619A** 359BAV036040 33,200 11.0 13.5 35,000 3.52 7.8 22,000 2.46
3676394 225BNA036****A CAP**3619A** 359BAV036060 33,400 11.5 13.5 35,000 3.60 7.9 22,000 2.50
3676396 225BNA036****A CAP**3619A**+TDR 33,600 11.0 13.0 35,600 3.58 7.9 22,600 2.46
3676406 225BNA036****A CAP**3621A** 313*AV048090 33,800 12.0 14.5 34,400 3.72 8.2 21,600 2.58
3676407 225BNA036****A CAP**3621A** 313*AV060110 34,000 12.0 14.5 34,600 3.74 8.2 21,600 2.60
See notes on pg. 28
225B
19
COMBINATION RATINGS CONTINUED
AHRI
Ref. No.
Model
Number Coil Model Number Furnace
Model Number
Cooling
Capacity EER SEER
High Temp
HSPF
Low Temp
E
Capacity ECOP H
Capacity HCOP
3676405 225BNA036****A CAP**3621A** 315(A,J)AV060110 33,600 12.0 14.5 34,200 3.66 8.0 21,400 2.54
3676408 225BNA036****A CAP**3621A** 353(A,B)AV060100 33,600 12.0 14.5 34,200 3.70 8.1 21,400 2.58
3676402 225BNA036****A CAP**3621A** 355(A,C)AV042080 33,400 12.0 14.0 34,400 3.62 8.0 21,600 2.52
3676403 225BNA036****A CAP**3621A** 355(A,C)AV060080 33,400 12.0 14.5 34,200 3.62 8.0 21,400 2.52
3676404 225BNA036****A CAP**3621A** 355(A,C)AV060100 33,600 12.0 14.5 34,400 3.66 8.0 21,400 2.54
3676412 225BNA036****A CAP**3621A** 355BAV042080 33,400 12.0 14.0 34,400 3.62 8.0 21,600 2.52
3676413 225BNA036****A CAP**3621A** 355BAV060080 33,400 12.0 14.5 34,200 3.62 8.0 21,400 2.52
3676414 225BNA036****A CAP**3621A** 355BAV060100 33,600 12.0 14.5 34,400 3.66 8.0 21,400 2.54
3676416 225BNA036****A CAP**3621A**+TDR 33,600 11.0 13.0 35,600 3.58 7.9 22,600 2.46
3676421 225BNA036****A CAP**4221A** 313*AV048090 34,000 12.0 14.5 34,600 3.76 8.2 21,600 2.60
3676422 225BNA036****A CAP**4221A** 313*AV060110 34,200 12.0 14.5 34,600 3.78 8.3 21,600 2.62
3676420 225BNA036****A CAP**4221A** 315(A,J)AV060110 33,800 12.0 14.5 34,400 3.70 8.1 21,400 2.56
3676423 225BNA036****A CAP**4221A** 353(A,B)AV060100 34,000 12.0 14.5 34,400 3.74 8.2 21,400 2.60
3676417 225BNA036****A CAP**4221A** 355(A,C)AV042080 33,600 12.0 14.0 34,600 3.66 8.1 21,600 2.54
3676418 225BNA036****A CAP**4221A** 355(A,C)AV060080 33,600 12.0 14.5 34,400 3.66 8.1 21,400 2.54
3676419 225BNA036****A CAP**4221A** 355(A,C)AV060100 33,800 12.0 14.5 34,400 3.70 8.1 21,600 2.56
3676431 225BNA036****A CAP**4221A** 355BAV042080 33,600 12.0 14.0 34,600 3.66 8.1 21,600 2.54
3676432 225BNA036****A CAP**4221A** 355BAV060080 33,600 12.0 14.5 34,400 3.66 8.1 21,400 2.54
3676433 225BNA036****A CAP**4221A** 355BAV060100 33,800 12.0 14.5 34,400 3.70 8.1 21,600 2.56
3676437 225BNA036****A CAP**4221A**+TDR 33,800 11.0 13.0 35,600 3.62 8.0 22,600 2.48
3676441 225BNA036****A CAP**4224A** 315(A,J)AV066135 33,800 12.0 14.5 34,200 3.70 8.2 21,400 2.58
3676442 225BNA036****A CAP**4224A** 315(A,J)AV066155 33,800 12.5 15.0 34,200 3.74 8.2 21,200 2.60
3676440 225BNA036****A CAP**4224A** 355(A,C)AV060120 33,800 12.0 14.5 34,200 3.70 8.1 21,400 2.58
3676439 225BNA036****A CAP**4224A** 355AAV042040 33,600 12.0 14.0 34,400 3.64 8.0 21,600 2.52
3676451 225BNA036****A CAP**4224A** 355BAV060120 33,800 12.0 14.5 34,200 3.70 8.1 21,400 2.58
3676443 225BNA036****A CAP**4224A** 359BAV060100 34,200 12.0 14.5 34,800 3.78 8.3 21,800 2.60
3676453 225BNA036****A CAP**4224A**+TDR 33,800 11.0 13.0 35,600 3.62 8.0 22,600 2.48
3676538 225BNA036****A CNPF*3618A**+TDR 33,600 11.0 13.0 35,600 3.56 7.9 22,600 2.46
3676659 225BNA036****A CNPH*3617A** 313*AV024045 33,200 11.2 13.5 34,800 3.52 7.8 22,000 2.46
3676660 225BNA036****A CNPH*3617A** 313*AV048070 33,200 11.5 13.5 34,600 3.56 7.8 21,600 2.48
3676661 225BNA036****A CNPH*3617A** 313*AV048090 33,400 12.0 14.5 34,400 3.64 8.0 21,400 2.54
3676662 225BNA036****A CNPH*3617A** 313*AV060110 33,600 12.0 14.5 34,400 3.66 8.1 21,400 2.56
3676654 225BNA036****A CNPH*3617A** 315(A,J)AV036070 33,200 11.5 14.0 34,400 3.56 7.9 21,600 2.50
3676655 225BNA036****A CNPH*3617A** 315(A,J)AV048090 33,400 12.0 14.0 34,200 3.60 7.9 21,400 2.52
3676656 225BNA036****A CNPH*3617A** 315(A,J)AV060110 33,400 12.0 14.0 34,200 3.62 8.0 21,400 2.52
3676657 225BNA036****A CNPH*3617A** 315(A,J)AV066135 33,400 12.0 14.5 34,200 3.62 8.0 21,400 2.52
3676658 225BNA036****A CNPH*3617A** 315(A,J)AV066155 33,400 12.0 14.5 34,200 3.64 8.0 21,400 2.54
3676664 225BNA036****A CNPH*3617A** 353(A,B)AV036060 33,600 12.0 14.0 34,400 3.64 8.0 21,600 2.54
3676665 225BNA036****A CNPH*3617A** 353(A,B)AV036080 33,400 12.0 14.0 34,400 3.62 8.0 21,400 2.52
3676666 225BNA036****A CNPH*3617A** 353(A,B)AV048080 33,400 12.0 14.0 34,400 3.64 8.0 21,600 2.54
3676667 225BNA036****A CNPH*3617A** 353(A,B)AV060100 33,400 12.0 14.5 34,200 3.62 8.0 21,200 2.54
3676663 225BNA036****A CNPH*3617A** 353AAV036040 33,400 12.0 14.0 34,400 3.64 8.0 21,400 2.54
3676649 225BNA036****A CNPH*3617A** 355(A,C)AV042060 33,400 12.0 14.0 34,400 3.62 8.0 21,600 2.52
3676650 225BNA036****A CNPH*3617A** 355(A,C)AV042080 33,200 11.5 14.0 34,400 3.58 7.9 21,600 2.50
3676651 225BNA036****A CNPH*3617A** 355(A,C)AV060080 33,200 11.5 14.0 34,200 3.58 7.9 21,400 2.50
3676652 225BNA036****A CNPH*3617A** 355(A,C)AV060100 33,400 12.0 14.0 34,400 3.62 8.0 21,600 2.52
3676653 225BNA036****A CNPH*3617A** 355(A,C)AV060120 33,400 12.0 14.0 34,200 3.60 7.9 21,400 2.52
3676648 225BNA036****A CNPH*3617A** 355AAV042040 33,200 11.5 14.0 34,400 3.54 7.8 21,600 2.48
3676677 225BNA036****A CNPH*3617A** 355BAV042060 33,400 12.0 14.0 34,400 3.62 8.0 21,600 2.52
3676678 225BNA036****A CNPH*3617A** 355BAV042080 33,200 11.5 14.0 34,400 3.58 7.9 21,600 2.50
3676679 225BNA036****A CNPH*3617A** 355BAV060080 33,200 11.5 14.0 34,200 3.58 7.9 21,400 2.50
3676680 225BNA036****A CNPH*3617A** 355BAV060100 33,400 12.0 14.0 34,400 3.62 8.0 21,600 2.52
3676681 225BNA036****A CNPH*3617A** 355BAV060120 33,400 12.0 14.0 34,200 3.60 7.9 21,400 2.52
3676668 225BNA036****A CNPH*3617A** 359BAV036040 33,200 11.0 13.5 34,800 3.50 7.7 22,000 2.44
3676669 225BNA036****A CNPH*3617A** 359BAV036060 33,400 11.5 13.5 34,800 3.56 7.9 22,000 2.48
3676670 225BNA036****A CNPH*3617A** 359BAV060080 33,800 11.5 14.0 35,000 3.66 8.1 22,000 2.54
3676671 225BNA036****A CNPH*3617A** 359BAV060100 33,800 12.0 14.0 34,600 3.64 8.0 21,600 2.54
3676683 225BNA036****A CNPH*3617A**+TDR 33,600 11.0 13.0 35,600 3.56 7.9 22,600 2.46
3676695 225BNA036****A CNPH*4221A** 313*AV024045 33,600 11.2 13.5 35,000 3.60 7.9 22,200 2.50
3676696 225BNA036****A CNPH*4221A** 313*AV048070 33,600 11.5 14.0 34,800 3.64 8.0 21,800 2.52
3676697 225BNA036****A CNPH*4221A** 313*AV048090 34,000 12.0 14.5 34,600 3.74 8.2 21,600 2.58
3676698 225BNA036****A CNPH*4221A** 313*AV060110 34,000 12.0 14.5 34,600 3.76 8.3 21,600 2.60
3676690 225BNA036****A CNPH*4221A** 315(A,J)AV036070 33,600 12.0 14.0 34,600 3.64 8.0 21,600 2.52
3676691 225BNA036****A CNPH*4221A** 315(A,J)AV048090 33,600 12.0 14.5 34,400 3.68 8.1 21,400 2.56
3676692 225BNA036****A CNPH*4221A** 315(A,J)AV060110 33,800 12.0 14.5 34,400 3.70 8.1 21,600 2.56
3676693 225BNA036****A CNPH*4221A** 315(A,J)AV066135 33,800 12.0 14.5 34,200 3.70 8.1 21,400 2.56
3676694 225BNA036****A CNPH*4221A** 315(A,J)AV066155 33,800 12.0 14.5 34,200 3.72 8.2 21,400 2.58
3676700 225BNA036****A CNPH*4221A** 353(A,B)AV036060 34,000 12.0 14.5 34,600 3.74 8.2 21,800 2.58
3676701 225BNA036****A CNPH*4221A** 353(A,B)AV036080 34,000 12.0 14.5 34,600 3.72 8.2 21,600 2.58
3676702 225BNA036****A CNPH*4221A** 353(A,B)AV048080 34,000 12.0 14.5 34,600 3.72 8.2 21,800 2.58
3676703 225BNA036****A CNPH*4221A** 353(A,B)AV060100 33,800 12.0 14.5 34,400 3.72 8.2 21,400 2.58
3676699 225BNA036****A CNPH*4221A** 353AAV036040 34,000 12.0 14.5 34,600 3.74 8.2 21,600 2.58
3676685 225BNA036****A CNPH*4221A** 355(A,C)AV042060 33,800 12.0 14.5 34,600 3.70 8.1 21,600 2.56
3676686 225BNA036****A CNPH*4221A** 355(A,C)AV042080 33,600 12.0 14.0 34,600 3.66 8.0 21,600 2.54
3676687 225BNA036****A CNPH*4221A** 355(A,C)AV060080 33,600 12.0 14.0 34,400 3.66 8.0 21,600 2.54
3676688 225BNA036****A CNPH*4221A** 355(A,C)AV060100 33,800 12.0 14.5 34,400 3.70 8.1 21,600 2.56
3676689 225BNA036****A CNPH*4221A** 355(A,C)AV060120 33,800 12.0 14.5 34,200 3.68 8.1 21,400 2.56
3676684 225BNA036****A CNPH*4221A** 355AAV042040 33,600 11.5 14.0 34,400 3.62 8.0 21,600 2.52
3676731 225BNA036****A CNPH*4221A** 355BAV042060 33,800 12.0 14.5 34,600 3.70 8.1 21,600 2.56
See notes on pg. 28
225B
20
COMBINATION RATINGS CONTINUED
AHRI
Ref. No.
Model
Number Coil Model Number Furnace
Model Number
Cooling
Capacity EER SEER
High Temp
HSPF
Low Temp
E
Capacity ECOP H
Capacity HCOP
3676732 225BNA036****A CNPH*4221A** 355BAV042080 33,600 12.0 14.0 34,600 3.66 8.0 21,600 2.54
3676733 225BNA036****A CNPH*4221A** 355BAV060080 33,600 12.0 14.0 34,400 3.66 8.0 21,600 2.54
3676734 225BNA036****A CNPH*4221A** 355BAV060100 33,800 12.0 14.5 34,400 3.70 8.1 21,600 2.56
3676735 225BNA036****A CNPH*4221A** 355BAV060120 33,800 12.0 14.5 34,200 3.68 8.1 21,400 2.56
3676704 225BNA036****A CNPH*4221A** 359BAV036040 33,800 11.5 13.5 35,000 3.58 7.9 22,200 2.48
3676705 225BNA036****A CNPH*4221A** 359BAV036060 33,800 11.5 14.0 35,000 3.64 8.0 22,000 2.52
3676706 225BNA036****A CNPH*4221A** 359BAV060080 34,200 12.0 14.0 35,000 3.76 8.2 22,200 2.58
3676707 225BNA036****A CNPH*4221A** 359BAV060100 34,200 12.2 14.5 34,800 3.74 8.2 21,800 2.58
3676741 225BNA036****A CNPH*4221A**+TDR 33,800 11.0 13.0 35,600 3.62 8.0 22,800 2.48
3676743 225BNA036****A CNPH*4321A** 359BAV036040 34,200 11.5 14.0 35,400 3.76 8.2 22,400 2.56
3676744 225BNA036****A CNPH*4321A** 359BAV036060 34,200 12.0 14.5 35,400 3.86 8.4 22,400 2.60
3676745 225BNA036****A CNPH*4321A** 359BAV060080 34,200 12.2 14.5 35,400 3.98 8.6 22,400 2.68
3676746 225BNA036****A CNPH*4321A** 359BAV060100 34,200 12.5 15.0 35,200 3.96 8.6 22,200 2.68
3676932 225BNA036****A CNPV*3617A** 313*AV048070 33,200 11.5 13.5 34,600 3.56 7.8 21,600 2.48
3676931 225BNA036****A CNPV*3617A** 315(A,J)AV048090 33,400 12.0 14.0 34,200 3.60 7.9 21,400 2.52
3676934 225BNA036****A CNPV*3617A** 353(A,B)AV036060 33,600 12.0 14.0 34,400 3.64 8.0 21,600 2.54
3676935 225BNA036****A CNPV*3617A** 353(A,B)AV036080 33,400 12.0 14.0 34,400 3.62 8.0 21,400 2.52
3676936 225BNA036****A CNPV*3617A** 353(A,B)AV048080 33,400 12.0 14.0 34,400 3.64 8.0 21,600 2.54
3676933 225BNA036****A CNPV*3617A** 353AAV036040 33,400 12.0 14.0 34,400 3.64 8.0 21,400 2.54
3676930 225BNA036****A CNPV*3617A** 355(A,C)AV042060 33,400 12.0 14.0 34,400 3.62 8.0 21,600 2.52
3676938 225BNA036****A CNPV*3617A** 355BAV042060 33,400 12.0 14.0 34,400 3.62 8.0 21,600 2.52
3676940 225BNA036****A CNPV*3617A**+TDR 33,600 11.0 13.0 35,600 3.56 7.9 22,600 2.46
3676950 225BNA036****A CNPV*3621A** 313*AV048090 33,600 12.0 14.5 34,400 3.64 8.0 21,400 2.54
3676951 225BNA036****A CNPV*3621A** 313*AV060110 33,600 12.0 14.5 34,400 3.68 8.1 21,400 2.56
3676949 225BNA036****A CNPV*3621A** 315(A,J)AV060110 33,400 12.0 14.0 34,200 3.62 8.0 21,400 2.52
3676952 225BNA036****A CNPV*3621A** 353(A,B)AV060100 33,400 12.0 14.5 34,200 3.62 8.0 21,200 2.54
3676946 225BNA036****A CNPV*3621A** 355(A,C)AV042080 33,200 11.5 14.0 34,400 3.58 7.9 21,600 2.50
3676947 225BNA036****A CNPV*3621A** 355(A,C)AV060080 33,200 12.0 14.0 34,200 3.58 7.9 21,400 2.50
3676948 225BNA036****A CNPV*3621A** 355(A,C)AV060100 33,400 12.0 14.0 34,400 3.62 8.0 21,600 2.52
3676956 225BNA036****A CNPV*3621A** 355BAV042080 33,200 11.5 14.0 34,400 3.58 7.9 21,600 2.50
3676957 225BNA036****A CNPV*3621A** 355BAV060080 33,200 12.0 14.0 34,200 3.58 7.9 21,400 2.50
3676958 225BNA036****A CNPV*3621A** 355BAV060100 33,400 12.0 14.0 34,400 3.62 8.0 21,600 2.52
3676960 225BNA036****A CNPV*3621A**+TDR 33,600 11.0 13.0 35,600 3.56 7.9 22,600 2.46
3676970 225BNA036****A CNPV*3717A** 313*AV048070 34,600 12.0 14.5 35,200 3.82 8.4 22,200 2.60
3676969 225BNA036****A CNPV*3717A** 315(A,J)AV048090 34,600 12.5 15.0 34,800 3.86 8.4 21,600 2.64
3676972 225BNA036****A CNPV*3717A** 353(A,B)AV036060 35,000 12.5 15.0 35,200 3.92 8.6 22,000 2.66
3676973 225BNA036****A CNPV*3717A** 353(A,B)AV036080 34,800 12.5 15.0 35,000 3.90 8.5 21,800 2.66
3676974 225BNA036****A CNPV*3717A** 353(A,B)AV048080 35,000 12.5 15.0 35,200 3.92 8.5 22,000 2.66
3676971 225BNA036****A CNPV*3717A** 353AAV036040 35,000 12.5 15.0 35,000 3.92 8.5 22,000 2.66
3676968 225BNA036****A CNPV*3717A** 355(A,C)AV042060 34,800 12.5 15.0 35,000 3.88 8.5 22,000 2.64
3676976 225BNA036****A CNPV*3717A** 355BAV042060 34,800 12.5 15.0 35,000 3.88 8.5 22,000 2.64
3676978 225BNA036****A CNPV*3717A**+TDR 35,000 11.5 13.5 36,000 3.78 8.3 23,000 2.56
3676981 225BNA036****A CNPV*4217A** 313*AV048070 34,000 12.0 14.0 35,000 3.70 8.1 22,000 2.54
3676980 225BNA036****A CNPV*4217A** 315(A,J)AV048090 34,000 12.0 14.5 34,600 3.74 8.2 21,600 2.58
3676983 225BNA036****A CNPV*4217A** 353(A,B)AV036060 34,200 12.0 14.5 34,800 3.78 8.3 21,800 2.60
3676984 225BNA036****A CNPV*4217A** 353(A,B)AV036080 34,200 12.0 14.5 34,800 3.76 8.3 21,800 2.60
3676985 225BNA036****A CNPV*4217A** 353(A,B)AV048080 34,200 12.0 14.5 34,800 3.78 8.3 21,800 2.60
3676982 225BNA036****A CNPV*4217A** 353AAV036040 34,200 12.0 14.5 34,800 3.78 8.3 21,800 2.60
3676979 225BNA036****A CNPV*4217A** 355(A,C)AV042060 34,200 12.0 14.5 34,800 3.76 8.2 21,800 2.58
3676993 225BNA036****A CNPV*4217A** 355BAV042060 34,200 12.0 14.5 34,800 3.76 8.2 21,800 2.58
3676995 225BNA036****A CNPV*4217A**+TDR 34,000 11.0 13.0 35,800 3.68 8.1 22,800 2.50
3677001 225BNA036****A CNPV*4221A** 313*AV048090 34,000 12.0 14.5 34,600 3.74 8.2 21,600 2.58
3677002 225BNA036****A CNPV*4221A** 313*AV060110 34,000 12.0 14.5 34,600 3.76 8.3 21,600 2.60
3677000 225BNA036****A CNPV*4221A** 315(A,J)AV060110 33,800 12.0 14.5 34,400 3.70 8.1 21,600 2.56
3677003 225BNA036****A CNPV*4221A** 353(A,B)AV060100 33,800 12.0 14.5 34,400 3.72 8.2 21,400 2.58
3676997 225BNA036****A CNPV*4221A** 355(A,C)AV042080 33,600 12.0 14.0 34,600 3.66 8.0 21,600 2.54
3676998 225BNA036****A CNPV*4221A** 355(A,C)AV060080 33,600 12.0 14.0 34,400 3.66 8.0 21,600 2.54
3676999 225BNA036****A CNPV*4221A** 355(A,C)AV060100 33,800 12.0 14.5 34,400 3.70 8.1 21,600 2.56
3677011 225BNA036****A CNPV*4221A** 355BAV042080 33,600 12.0 14.0 34,600 3.66 8.0 21,600 2.54
3677012 225BNA036****A CNPV*4221A** 355BAV060080 33,600 12.0 14.0 34,400 3.66 8.0 21,600 2.54
3677013 225BNA036****A CNPV*4221A** 355BAV060100 33,800 12.0 14.5 34,400 3.70 8.1 21,600 2.56
3677017 225BNA036****A CNPV*4221A**+TDR 33,800 11.0 13.0 35,600 3.62 8.0 22,800 2.48
3677022 225BNA036****A CNPV*4324A** 315(A,J)AV066135 34,800 12.5 15.0 34,600 3.92 8.5 21,600 2.68
3677023 225BNA036****A CNPV*4324A** 315(A,J)AV066155 34,800 12.5 15.5 34,600 3.94 8.6 21,400 2.68
3677025 225BNA036****A CNPV*4324A** 355(A,C)AV042080 35,000 12.5 15.0 35,000 3.86 8.5 21,800 2.64
3677026 225BNA036****A CNPV*4324A** 355(A,C)AV060080 35,000 12.5 15.0 34,800 3.86 8.5 21,800 2.64
3677021 225BNA036****A CNPV*4324A** 355(A,C)AV060120 34,800 12.5 15.0 34,800 3.90 8.5 21,600 2.66
3677020 225BNA036****A CNPV*4324A** 355AAV042040 34,600 12.2 14.5 34,800 3.84 8.4 21,800 2.62
3677041 225BNA036****A CNPV*4324A** 355BAV042080 35,000 12.5 15.0 35,000 3.86 8.5 21,800 2.64
3677042 225BNA036****A CNPV*4324A** 355BAV060080 35,000 12.5 15.0 34,800 3.86 8.5 21,800 2.64
3677040 225BNA036****A CNPV*4324A** 355BAV060120 34,800 12.5 15.0 34,800 3.90 8.5 21,600 2.66
3677024 225BNA036****A CNPV*4324A** 359BAV060100
(DNFLWONLY) 35,400 12.5 15.0 35,400 3.98 8.7 22,200 2.68
3677019 225BNA036****A CNPV*4324A** 35,000 11.5 13.5 36,000 3.78 8.3 23,000 2.56
3677046 225BNA036****A CNPV*4821A** 355(A,C)AV042080 34,200 12.0 14.5 34,800 3.78 8.3 21,800 2.60
3677060 225BNA036****A CNPV*4821A** 355BAV042080 34,200 12.0 14.5 34,800 3.78 8.3 21,800 2.60
3677085 225BNA036****A CNPV*6024A** 355(A,C)AV042080 34,600 12.0 14.5 34,800 3.84 8.4 21,800 2.62
3677097 225BNA036****A CNPV*6024A** 355BAV042080 34,600 12.0 14.5 34,800 3.84 8.4 21,800 2.62
See notes on pg. 28
225B
This manual suits for next models
7
Table of contents
Other Bryant Heat Pump manuals
Bryant
Bryant TWO-SPEED PURON PLUS ELECTRIC HEAT PUMP 698B User manual
Bryant
Bryant 607E Series User manual
Bryant
Bryant Legacy 547K 04 Series User manual
Bryant
Bryant 213A Operation manual
Bryant
Bryant 585C048125 Manual
Bryant
Bryant Legacy 547K 14 User manual
Bryant
Bryant 607C024 User manual
Bryant
Bryant 285B EVOLUTION Quick start guide
Bryant
Bryant 637G Instructions and recipes
Bryant
Bryant LEGACY 604D Instruction Manual
Bryant
Bryant PREFERRED 677E C Series User manual
Bryant
Bryant Preferred Series User manual
Bryant
Bryant Puron Refrigerant Single Speed Guide
Bryant
Bryant 213A Operation manual
Bryant
Bryant 542D060 Manual
Bryant
Bryant PREFERRED 265A Operation manual
Bryant
Bryant 542D060 Manual
Bryant
Bryant Preferred 227T User manual
Bryant
Bryant EVOLUTION V 288BNV User manual
Bryant
Bryant 604D024 User manual
Popular Heat Pump manuals by other brands
Trane
Trane ComfortLink 4TWZ0024A1000A manual
LK Armatur
LK Armatur SmartSolar LK 202 instruction manual
Carrier
Carrier 38QN Installation, Start-Up and Service Instructions
Climer
Climer ECOFLEX TD EF04TD Installation and user manual
AERMEC
AERMEC WRK0300H installation manual
Panasonic
Panasonic Aquarea WH-SDC05H3E5-1 operating instructions
Nibe
Nibe FIGHTER 640P Installation and maintenance instructions
Beko
Beko BEKOMAT 3 E 25 Instructions for installation and operation
AQUARK
AQUARK BLACK SILENCE user manual
Bradford White
Bradford White RE2H65T 1NCWT Series quick guide
EAS Electric
EAS Electric E301WHF instruction manual
International comfort products
International comfort products R2H3 Series installation instructions
MICROWELL
MICROWELL HP COMMERCIAL iMAX60 Installation and user manual
Nibe
Nibe F1155 Series Installer manual
Johnson Controls Unitary Products
Johnson Controls Unitary Products 14.5 SEER SERIES User's information manual
Dimplex
Dimplex LI 11MS Technical data
Nulite
Nulite PB25Y/32 manual
Dettson
Dettson LPD09KCH18S owner's manual
