BUBBA burger CBC1210ARB User manual

OWNER’S MANUAL
Table of Contents
Important Safeguards ...........................................................Page 2
Expanded View & Hardware .......................................................... 3
Assembly Instructions............................................................... 4
Operating Instructions.............................................................. 7
Cleaning and Care ................................................................. 8
Limited Warranty ................................................................. 8
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP
FOR FUTURE REFERENCE.
If you are assembling this unit for someone else, give this manual to them to read and save for future
reference.
California Proposition 65: Combustion by-products produced when using this product contain chemicals
known to the State of California to cause cancer, birth defects, and other reproductive harm.
California Proposition 65: Wash your hands after handling this product.
Outdoor Charcoal Barbecue Grill
Model No. CBC1210ARB
.
.
If you have questions or need assistance during assembly,
please call 1-800-694-0013
CBC1210ARB-OM-E-F103
.
FOR YOUR SAFETY:
1. Do NOT store or use gasoline or other
flammable liquids or vapors in the
vicinity of this or any other appliance.
2. When cooking with oil/grease, do NOT
allow the oil/grease to exceed 350ºF
(176.5ºC). Do NOT store or use extra
cooking oil in the vicinity of this or any
other appliance.
.
FOR YOUR SAFETY:
For Outdoor Use Only
(outside any enclosure)
.
FOR YOUR SAFETY:
1. Improper installation, adjustment,
alteration, service or maintenance
can cause injury or property
damage.
2. Read the installation, operation, and
maintenance instructions thoroughly
before installing or servicing this
equipment.
3. Failure to follow these instructions
could result in fire or explosion,
which could cause property damage,
personal injury, or death.
4. This instruction manual contains
Important information necessary for
the proper assembly and safe use of
the appliance.
5. Read and follow all warnings and
instructions before assembling and
using the appliance.
6. Follow all warnings and instructions
when using the appliance.
7. Keep this manual for future
reference.
Never operate this appliance
unattended.

2
WThis grill is for outdoor use only, and should NOT be used in a building, garage or any other enclosed area.
WDo NOT operate, light or use this appliance within ten feet (3.05 m) of walls, structures or buildings.
WFor residential use only. This grill is NOT for commercial use.
WNever use charcoal that has been pre-treated with lighter fluid. Use only a high grade plain charcoal, charcoal/wood mixture, lump charcoal or cooking
wood. The conversion to or attempted use of any other fuel source in this charcoal grill is dangerous and will void your warranty.
WThis grill is NOT intended for and should never be used as a heater. TOXIC fumes can accumulate and cause asphyxiation.
WDo NOT use grill for indoor cooking. TOXIC carbon monoxide fumes can accumulate and cause asphyxiation.
WThis grill is safety certified for use in the United States and/or Canada only. Do NOT modify for use in any other location. Modification will result in a
safety hazard and will void your warranty.
WApartment dwellers: Check with management to learn the requirements and fire codes for using a charcoal grill in your apartment complex. If allowed,
use outside on the ground floor with a ten foot (3.05 m) clearance from any structure. Do NOT use on or under balconies.
WMinimum clearance from sides and back of unit to combustible construction is 36 inches (91.4 cm). Do NOT use this appliance under any type of
overhang or roof.
WDo NOT use gasoline, kerosene or alcohol for lighting.
WDo NOT use in an explosive atmosphere. Keep grill area clear and free from combustible materials, gasoline and other flammable vapors and liquids.
WDo NOT store or use gasoline or other flammable liquids or vapors within 25 feet (7.62 m) of this appliance.
WDo NOT block holes in sides or back of grill.
WInspect grill before each use.
WDo NOT alter grill in any manner. Any alteration will void your warranty.
WDo NOT build this model of grill in any built-in or slide-in construction. Ignoring this warning could cause a fire or an explosion that can damage
property and cause serious bodily injury or death.
WDo NOT use the grill unless it is COMPLETELY assembled and all parts are securely fastened and tightened.
WThis grill should be thoroughly cleaned and inspected on a regular basis.
WUse only RevoAce Inc. Limited factory-authorized parts. The use of any part that is not factory-authorized can be dangerous and will void your
warranty.
WDo NOT operate this appliance without reading “Operating Instructions” in this manual.
WTo avoid burns, do NOT touch metal parts of grill until they have completely cooled, unless you are wearing protective gear (pot holders, gloves, BBQ
mittens, etc.).
WNever touch grates (charcoal, cooking or warming), ashes or coals to see if they are hot.
WDo NOT use on wooden decks, wooden furniture or other combustible surfaces.
WThis grill is NOT to be used in or on boats or recreational vehicles.
WPosition grill so wind cannot carry ashes to combustible surfaces.
WDo NOT use in high winds.
WNever lean over the grill when lighting.
WDo NOT leave a lit grill unattended. Keep children and pets away from grill at all times.
WDo NOT attempt to move grill when in use. Allow the grill to cool before moving or storing.
WDo NOT leave grill unattended while preheating or burning off food residue.
WWhen cooking, fire extinguishing materials should be readily accessible. In the event of an oil/grease fire, do NOT attempt to extinguish with water.
Use type BC dry chemical fire extinguisher or smother with dirt, sand or baking soda.
WAlways open grill lid carefully and slowly as heat and steam trapped within grill can severely burn you.
WIf grill has not been cleaned, a grease fire can occur that may damage the product.
WDo NOT place empty cooking vessels on the appliance while in operation.
WUse caution when placing anything on the grill while the appliance is in operation.
WNever add lighting fluid to hot or warm coals as a flashback may occur causing serious injury or damage to property.
WAlways place your grill on a hard, non-combustible level surface. An asphalt or blacktop surface may not be acceptable for this purpose.
WDo NOT remove the ashes until they are completely and fully extinguished.
WLive hot briquettes and coals can create a fire hazard.
WAlways empty the bottom bowl and grill after each use.
WDo NOT place fuel (charcoal briquettes, wood or lump charcoal) directly into bottom of grill. Place fuel only on the charcoal pan/grid.
WDo NOT allow charcoal to rest on the walls of grill. Doing so will greatly reduce the life of the metal and finish of your grill.
WCheck to make sure the air vents are free of debris and ash before using the grill.
WExtinguished coals and ashes should be placed a safe distance from all structures and combustible materials.
WWith a garden hose, completely wet the surface beneath and around grill to extinguish any ashes, coals or embers that may have fallen during the
cooking or cleaning process.
WThe use of alcohol, prescription or non-prescription drugs may impair the consumer’s ability to properly assemble and/or safely operate this grill.
WAlways wear protective gloves when adding fuel (charcoal briquettes, wood or lump charcoal) to retain desired heat level.
WKeep all electrical cords away from a hot grill.
WAlways use a meat thermometer to ensure food is cooked to a safe temperature.
WNever cover entire cooking area with aluminum foil.
WUse protective gloves when assembling this product.
WDo NOT force parts together as this can result in personal injury or damage to the product.
WDo NOT touch ash receiver or ash receiver handle until grill has completely cooled, unless you are wearing protective gear.
WDo NOT touch air vent or air vent handle until grill has completely cooled, unless you are wearing protective gear.
WDeath, serious injury or damage to property may occur if the above is not followed exactly.
Important Safeguards
Warning

3
Expanded View
1Handle B0108-A01
2Lid Air Vent B0105-A01
3Lid C1210-010
4Warming Rack C1210-030
5Cooking Grid C1210-040
6Charcoal Grid C1210-050
7Top Hinge C1210-020
8Bottom Hinge C1210-060
9Bottom Bowl C1210-070
10 Lock C1210-080
11 Ash Tray C1210-100
12 Bottom Bowl Air Vent C1210-090
13 Air Vent Tool N2204-070
14 Leg Support Cup (4) C1210-110
15 Rear Leg (2) C1210-120
16 Front Leg (2) C1210-130
17 Bottom Grid C1210-150
18 Wheel (2) C1210-140
19 Brand Plate * B0109-BD0
* Pre-assembled
Parts List
AScrew M4x12 Nickel Plated Phillips Truss Head 2 pcs
BScrew M5x12 Nickel Plated Phillips Truss Head 2 pcs
CScrew M6x15 Nickel Plated Phillips Truss Head 6 pcs
DScrew M6x30 Nickel Plated Phillips Truss Head 4 pcs
ENut M8 Nickel Plated 2 pcs
FWing Nut M4 Nickel Plated 2 pcs
GWing Nut M5 Nickel Plated 2 pcs
HWing Nut M6 Nickel Plated 8 pcs
IWasher ø6 Zinc Plated 12 pcs
JWasher ø6 Heat Resistant 8 pcs
Tools Required for Assembly (Included)
#2 Phillips Head Screwdriver 1 pc
M8 Wrench 1 pc
Hardware
1
4
8
18
15
17
5
10 11
12
2
3
6
7
9
16
13
KLock Washer ø6 Zinc Plated 12 pcs
LPin ø6x148 Nickel Plated 1 pc
MCotter Pin ø1.4x30 Nickel Plated 1 pc
14
16
15
18
19

4
For assistance, call 1.800.694.0013 toll-free. Please have
your owner’s manual and model number available for
reference.
For Easiest Assembly:
1. Select an area where you will assemble this product. To
protect components, choose a smooth surface that’s free of
cracks or openings.
2. Spread out all parts.
3. Tighten all hardware connections by hand first. Then, before
completing each step, go back and fully tighten all hardware.
Be careful not to overtighten. That could damage surfaces or
strip threads.
4. For best results, complete each step in the order presented.
To complete assembly you will need:
• One bag of charcoal (not included)
Typical assembly is approximately 45 minutes.
Assembly Instructions
DO NOT RETURN TO PLACE OF PURCHASE.
1
Attach Top Hinge
4
Attach Handle
3
Attach Lid Air Vent
2
Gx 1
Jx 2
I
x 2
Hx 2
Kx 2
Cx 3
Bx 1
Hx 3
I
x 3
Jx 3
Kx 3
B
G

5
Attach Bottom Grid, Wheels, Legs, and Leg Cup Supports
6
Attach Lock and Bottom Hinge
7
Attach Bottom Bowl Air Vent
5
Attach Ash Tray
8
Dx 4
Cx 3
E
x 2
I
x 4
Kx 4
Note: Do not fully tighten screws until bottom shelf is attached.
Ax 2
Fx 2
Hx 3
I
x 3
Jx 3
Kx 3
Bx 1 Gx 1

6
10
Attach Lid
9
Mx 1
Lx 1
Insert Warming Rack
11
Insert Charcoal Grid and Cooking Grid
12
Lock Lid
Note: Lid must be locked before moving grill.
Unlock Lid
Note: Always unlock and open lid before lighting grill.

7
Adjust Bottom Bowl Air Vent
13
Note: Always use protective gloves when adjusting air vent.
.
Operating Instructions
Lighting Instructions
WCAUTION: Keep outdoor cooking appliance area clear and free from combustible materials,
gasoline and other flammable vapors and liquids.
WCAUTION: Check to make sure the air vents are free of debris and ash before using the grill.
WCAUTION: Attempting to light the grill with the lid closed may cause an explosion.
WCAUTION: When using a liquid starter, always check bottom bowl before lighting. Fluid can
collect in the bottom bowl and could ignite, resulting in a fire.
WCAUTION: Never add lighting fluid to hot or warm coals as flashback may occur, causing
serious injury or damage to property.
1. Open lid and vents.
2. Make sure bottom bowl is empty.
3. Remove cooking grid.
4. Arrange charcoal briquettes or other fuel on the bottom bowl to the “Fill Line” (Figure 1).
5. Light per instructions on fuel package.
6. Allow fuel time to ash into glowing coals before cooking.
First Use
1. Make sure all labels, packaging and protective films have been removed from the grill.
2. Remove manufacturing oils before cooking on this grill for the first time, by operating the grill for at least 15
minutes with the lid closed. This will “heat clean” the internal parts and dissipate odors.
.
Never use charcoal that has been pre-treated with
lighter fluid. Use only a high grade plain charcoal,
charcoal/wood mixture, lump charcoal or cooking
wood.
CAUTION
Turning Off
1. Allow charcoal to completely extinguish itself.
2. Dispose of the ashes in a proper location.
.
WARNING
WDo NOT use water to extinguish. This can be
dangerous and cause damage.
Controlling Flare-ups
WCAUTION: Do NOT use water on a grease fire. This can cause the grease to splatter and could
result in serious burns, bodily harm or other damage.
WCAUTION: Do NOT leave grill unattended while preheating or burning off food residue. If grill
has not been cleaned, a grease fire can occur that may damage the product.
Flare-ups are a part of cooking meats on a grill and add to the unique flavor of grilling.
Excessive flare-ups can over-cook your food and be dangerous.
Important: Excessive flare-ups result from the build-up of grease in the bottom of your grill.
If a grease fire occurs, close the lid until the grease burns out. Use caution when opening the lid as sudden flare-ups may
occur.
If excessive flare-ups occur, do NOT pour water onto the flames.
Minimize Flare-ups:
1. Trim excess fat from meats prior to cooking.
2. Cook high fat content meats indirectly.
3. Ensure that your grill is on a hard, level, non-combustible surface.
WARNING
When cooking, fire extinguishing materials should
be readily accessible. In the event of an oil/grease
fire, use a type BC dry chemical fire extinguisher
or smother with dirt, sand or baking soda. Do NOT
attempt to extinguish with water.
Figure 1

8
Cleaning and Care
.
1. This grill should be thoroughly cleaned and
inspected on a regular basis.
2. Abrasive cleaners will damage this product.
3. Never use oven cleaner to clean any part of
grill.
NOTICE
Before Each Use:
1. Keep the grill area free and clear from any combustible materials, gasoline, and other flammable vapors and liquids.
2. See below for proper cleaning instructions.
Cleaning Surfaces
1. Wait for grill to fully cool.
2. Wipe surfaces clean with a mild dishwashing detergent or baking soda mixed with water.
3. For stubborn stains, use a citrus-based degreaser and a nylon scrubbing brush.
4. Rinse clean with water.
5. Allow to air dry.
Before Storing
1. Wait for grill to fully cool.
2. Clean all surfaces.
3. If storing the grill indoors, cover the grill and store in a cool dry place.
4. If storing the grill outdoors, cover the grill with a grill cover for protection from the weather.
.
1. All cleaning and maintenance should be done
when grill is cool and with the ashes properly
disposed of.
2. Do NOT clean any grill part in a self-cleaning
oven. The extreme heat will damage the finish.
CAUTION
Limited Warranty
RevoAce Inc. Limited (“RA”) warrants to the original retail purchaser of this product, and to no other person, that if this product is assembled, maintained, and
operated in accordance with the printed instructions accompanying it, then for a period of one (1) year for all remaining parts from the date of purchase, all
parts in such product shall be free from defects in material and workmanship. RA may require reasonable proof of your date of purchase. Therefore, you should
retain your sales slip or invoice. This Limited Warranty shall be limited to the repair or replacement of parts, which prove defective under normal use and service
and which RA shall determine in its reasonable discretion upon examination to be defective. Before returning any parts, you should contact RA’s Customer Care
Department using the contact information listed below. If RA conforms, after examination, a defect covered by this Limited Warranty in any returned part, and if
RA approves the claim, RA will replace such defective part without charge. If you return defective parts, transportation charges must be prepaid by you. RA will
return replacement parts to the original retail purchaser, freight or postage prepaid. This Limited Warranty does not cover any failures or operating difficulties due
to accident, abuse, misuse, alteration, misapplication, improper installation or improper maintenance or service by you or any third party, or failure to perform
normal and routine maintenance on the product as set out in this owner’s manual. In addition, the Limited Warranty does not cover damage to the finish, such as
scratches, dents, discoloration, rust or other weather damage, after purchase.
This Limited Warranty is in lieu of all other express warranties. RA disclaims all warranties for products that are purchased from sellers other than authorized
retailers or distributors, including the warranty of merchantability or the warranty of fitness for a particular purpose. RA ALSO DISCLAIMS ANY AND ALL IMPLIED
WARRANTIES, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. RA SHALL HAVE
NO LIABILITY TO PURCHASER OR ANY THIRD PARTY FOR ANY SPECIAL, INDIRECT, PUNITIVE, INCIDENTAL, OR CONSEQUENTIAL DAMAGES. RA further disclaims
any implied or express warranty of, and assumes no responsibility for, defects in workmanship caused by third parties. This Limited Warranty gives the purchaser
specific legal rights; a purchaser may have other rights depending upon where he or she lives. Some jurisdictions do not allow the exclusion or limitation of
special, incidental or consequential damages, or limitations on how long a warranty lasts, so the above exclusion and limitations may not apply to everyone.
RA does not authorize any person or company to assume for it any other obligation or liability in connection with the sale, installation, use, removal, return, or
replacement of its equipment, and no such representations are binding on RA.
RevoAce Inc.
8F-1, NO.497, Jhongming S.RD.
West District, Taichung City, Taiwan
1.800.694.0013
