Buffalo AirStation WBR-B11 User manual

®
The AirStation 11Mbps Broadband Router Base
Station incorporates improved security with VPN support
and upgradeable firewall features.The built-in 4-port Ethernet
switch allows you to combine wired and wireless networks on
the same LAN. The 11Mbps Broadband Router also
supports up to 40Mbps wired throughput and will protect
your investment when faster broadband speeds become avail-
able (currently, standard wired throughput is 27Mbps). This
easy-to-use, affordable 11Mbps Broadband Router is the per-
fect solution for Home, SOHO and SMB use.
11Mbps Broadband Router Base Station
WBR-B11
◗ 11Mbps High-Speed Wireless Data rate
◗ Exclusive Intrusion Detector Firewall
◗ Wi-Fi™ Certified
◗ Fast 40Mbps wired throughput
◗ Supports up to 128-bit WEP
◗ External 2.4GHz Antenna Ready
◗ Supports up to 253 users/nodes
◗ Built-in HTTP admin-console enables users to
configure the AirStation through Web Browser
◗ Built-in DHCP Router and 4 port 10/100 switch
◗ Roaming support
◗ Improved VPN Features: IPSec and PPTP
pass through
◗ Allows WAN and MAC address modification
◗ Dynamic Packet Filtering on LAN and WAN side
◗ 24/7 Toll-Free Tech Support
◗ 2-Year Warranty
Buffalo’s Exclusive Intrusion Detector™
A powerful firewall that identifies and blocks
outside attacks into your network and alerts
you via pop-up window and email.
The Buffalo Anywhere Office allows users to safely
connect to private systems or home/office networks from
remote locations or hotspots through a Virtual Private
Network (VPN) using the updated TKIP Security method.
tel. [phone] www.buffalotech.com/wireless fax. [phone]
WBR-B11

Buffalo Technology (USA), Inc.,
along with our parent company
MELCO, Inc., are global leaders in
the design, development, and manu-
facturing of wireless networking
solutions for the SMB, SOHO and
home. Buffalo Technology’s prod-
ucts are Wi-Fi™ 802.11b certified
and provide a wide range of wire-
less LAN solutions focusing on
security and VPN features.
Standards Compliance
Frequency Range
Transmission Rate
Security
Access Mode
Antenna
External Antenna Connector
Output Power
Selectable Channels
Communication Protocol
Wireless LAN
802.11b (Wireless LAN Standard)
2,412 - 2,462MHz
1, 2, 5.5, 11Mbps
Intrusion Detector, 128/64-bit WEP, password, MAC address
registration, Privacy Separator, Dynamic Packet Filtering
Infrastructure Mode, WDS (bridge/repeater mode)
Diversity Method (Internal)
MC
15dBm (32mW)
11 Channels (3 non-overlapping)
Direct Sequence Spread Spectrum (DS-SS, Half-Duplex)
Interface
Transmission Rate
LAN Ports/Connector
Transmission Encoding Method
Access Method
WAN Port/Connector
Power Supply
Dimensions
Weight
Operating Environment
Wired LAN
IEEE802.3 (10 Base-T / 100 Base-TX)
10/100Mbps (auto Sense)
Four (4) 10/100 Base-T RJ-45 ports (Auto MDI/X)
10 Base-T Manchester coding; 100 Base-TX4B5B/MLT-3
CSMD/CD
One (1) RJ-45 port
100-240V AC 50/60Hz DC 3.3V, 2.5A
W3 x H6.75 x D6.1in. (76 x 171 x 155mm)
.80 lb. (363g)
0-40˚ C, 20-80% humidity (non-condensing)
Speed
11Mbps
2Mbps
1Mbps
Communication Range
Indoor
165 ft. (50m)
300 ft. (90m)
375 ft. (115m)
Outdoor
525 ft. (160m)
1310 ft. (400m)
1750 ft. (550m)
All distances are estimated.Wireless connections may be affected as physical conditions and circumstances vary.
AirStation 11Mbps Broadband Router Base Station
Technical Specifications
®
Wi-Fi™ is a trademark of the
Wireless Ethernet Compatibility Alliance, Inc.
© 2003 Buffalo Technology (USA), Inc. Buffalo Technology and the Buffalo Technology logo are registered trademarks belonging to Buffalo Technology (USA), Inc.
All other trademarks mentioned belong to their respective owners. Buffalo Technology is not responsible for typographical errors or omissions.
Product specifications and prices are subject to change without notice.
4030 W. Braker Lane #120
Austin,Texas 78759
Support Available for: Windows 98se, ME, 2000 and XP (Macintosh Compatible)
Package Contents: AirStation 11Mbps Broadband Router, Power Supply, CD driver
disk with Manual, LAN Cable, Quick Set-up Guide and Warranty card
Related Products: Airstation Flat PCMCIA Card, Airstation USB Adapter,Airstation
Ethernet Media Converter and AirStation 2.4GHz Antennas
