Buffalo AirStation WBR2-G54 User manual

User Manual
Wireless
Cable/DSL Router-G
WBR2-G54
www.buffalotech.com/wireless

2
Table of Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . 05
Installation / Setup . . . . . . . . . . . . . . . . . . . . . . 11
Antenna Installation. . . . . . . . . . . . . . . . . . . . . . 13
Standard Settings . . . . . . . . . . . . . . . . . . . . . . . 14
AOSS Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Advanced Setup . . . . . . . . . . . . . . . . . . . . . . . . 27
LAN Settings . . . . . . . . . . . . . . . . . . . . . . . . 27
Wireless Settings . . . . . . . . . . . . . . . . . . 27
Wireless LAN Security . . . . . . . . . . . . . . 29
LAN Port . . . . . . . . . . . . . . . . . . . . . . . . 32
DHCP Server . . . . . . . . . . . . . . . . . . . . . 33
Wireless MAC Filtering . . . . . . . . . . . . . 35
Wireless Bridge (WDS) . . . . . . . . . . . . . 38
WAN Settings . . . . . . . . . . . . . . . . . . . . . . . 40
WAN Port . . . . . . . . . . . . . . . . . . . . . . . . 40
WAN Network . . . . . . . . . . . . . . . . . . . . . 43

3
Table of Contents
Network Settings. . . . . . . . . . . . . . . . . . . . . 45
Routing Setup . . . . . . . . . . . . . . . . . . . . 45
Address Translation . . . . . . . . . . . . . . . . 47
Packet Filter . . . . . . . . . . . . . . . . . . . . . . 50
Intrusion Detector . . . . . . . . . . . . . . . . . 55
UPnP . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Management . . . . . . . . . . . . . . . . . . . . . . . . 58
System Information . . . . . . . . . . . . . . . . 58
Change Password . . . . . . . . . . . . . . . . . 59
Time Setup . . . . . . . . . . . . . . . . . . . . . . 60
Traffic Information . . . . . . . . . . . . . . . . . 61
Client Monitor . . . . . . . . . . . . . . . . . . . . 62
Ping Tool . . . . . . . . . . . . . . . . . . . . . . . . 63
Log Information . . . . . . . . . . . . . . . . . . . 64
Syslog Transfer . . . . . . . . . . . . . . . . . . . 65
Save/Restore Settings . . . . . . . . . . . . . . 66
Reboot/Reload Settings . . . . . . . . . . . . . 67
Firmware Updates . . . . . . . . . . . . . . . . . 68
AOSS . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

4
Table of Contents
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . 71
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . 76
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . .84
FCC Information . . . . . . . . . . . . . . . . . . . . . . . . 90
Warranty Information. . . . . . . . . . . . . . . . . . . . . 93
Contact Information . . . . . . . . . . . . . . . . . . . . . 94

5
AirStation Broadband Router Base Station (WBR2-G54)
Welcome to AirStation, the easy way to ultra fast wireless networking.
This manual, which describes the most common configurations, introduces you to the AirStation
Cable/DSL Router, and will help you connect to your network quickly.
The WBR2-G54 router, is a wireless 4-port router small/medium business (SMB) network device
that complies with the 2.4GHz IEEE 802.11g standard specification on wireless LANs. The WBR2-
G54 supports enhanced built-in NAT/SPI firewall functions and is used as a multi-functional router/
link between wired and wireless LAN computers.
Summary of the AirStation WBR2-G54 features:
• Wi-Fi™ (Wireless Fidelity) certified by the Wi-Fi Alliance as an 802.11b/g device. AirStation will
communicate with other IEEE 802.11b/g/Wi-Fi compliant wireless LAN products.
• Support for Wi-Fi Protected Access™ (WPA), 802.1x, TKIP, AES, and WEP.
• Automatic Transmit Rate Select mechanism transmits at speeds of 54, 36, 24, 11, 5.5, 2 and 1
Mbps.
• Supports Frame Bursting for enhanced performance.
• DHCP client/server function.
• Auto roaming, supports seamless roaming over multiple channels.
• VPN pass-through, for secure communications.
• Packet Filtering for eliminating unwanted communications.
Introduction

6
• SOHO/SMB routing and firewall functions provide a safer private networking environment, includ-
ing support for MS NetMeeting and MSN-Messenger.
• Additional SPI Firewall Functions - DMZ, intrusion detection and notification
• Syslog transmits some or all system activities to a central Syslog server.
• Extended range, with optional add-on antennas or WDS (Wireless Distribution System).
• Auto Media Dependent Interface/Crossover (MDI/X) port, allows connection by standard and
crossover CAT5 cables.
• Supports Universal Plug and Play (UPnP).
• Buffalo’s AOSS System for easy, secure wireless client configuration.
AirStation Wireless Network Features
• Enhanced security features:
- SPI Firewall and DMZ zone functions to prevent unknown intruders.
- Intrusion Detector Firewall (NAT) with a pop-up or email alert warning unwanted attacks.
- Dynamic packet filtering.
- WPA, 802.1x, TKIP, AES, and WEP.
- VPN (IPSec, PPTP and L2TP) pass-through
Introduction

7
- Packet monitoring and filtering by MAC address, IP address and port.
- PPPoE support
- WDS support
• Buffalo’s easy web interface configuration
• Broadband router static and dynamic routing methods between WAN and LAN based on updated
routing tables. An economical way to bridge multiple networks.
• Optional external antennas for boosting range and signal quality.
• Buffalo’s AOSS System for easy, secure wireless client configuration.
Home Networking 1
For the future home entertainment applications that carry hard drives for storing hundreds of titles,
IEEE 802.11g can transmit three channels of CD-quality voice to every room in the home simulta-
Figure 1.4
SOHO/SMB
Networking
Introduction

8
neously. Buffalo AirStation wireless access points enable sharing broadband by simply connecting
the AirStation to a DSL or CATV modem to:
• Share files and printers
• Access and share the Internet
• Share media files
SOHO/SMB Networking
With high-speed DSL or CATV connections readily available, many users can work effectively from
a home office, connected securely to a corporate network. Buffalo’s solutions are ideal for home
networks that require secure, high-speed access to the corporate LAN. Tools that play an integral
part in Buffalo’s solutions include VPN connectivity for secure access to corporate resources, which
enable the remote employee to handle information from clients or coworkers as if they were in the
Introduction

9
offi ce. Connect the Buffalo AirStation Broadband router
AP to a CATV or DSL modem in order to:
•Share broadband access
•Share fi les and printers
•Bridge between multiple networks and multiple com-
puter platforms
•Provide easy and secure access to home or company
networks from remote locations
System Requirements
• Broadband (High-Speed) Internet connection or exist-
Introduction
The LAN or Wired MAC address is
the default ESS-ID (SSID) of the
AirStation. The LAN MAC address
is clearly labeled on the back of the
AirStation.

10
ing Local area connection
• Any Wi-Fi (wireless) compatible computer with a Web Browser Internet Explorer or Netscape 4.5
or later. (Safari 1.0 is supported with Macintosh OS X.2)
AirStation WBR2-G54 Package Contents
The AirStation WBR2-G54 package consists of the following items.
1. WBR2-G54 Base Station
2. AC adapter and power cable
3. CAT5 LAN cable
4. Utility CD with Manual
5. Quick Setup Guides
6. Warranty Statement
Product Views
Power - Lit when the device is powered on.
Wireless - Lit when the wireless radio is on. Flashes when wireless traffic is present.
WAN - Lit when connection to Cable/DSL modem is present. Flashes when internet traffic is present.
Diag - Flashes red when performing diagnostic functions.
AOSS - Flashes when in AOSS mode.
Ethernet - 1, 2, 3, or 4 lit when ethernet clients are connected. Flashes when ethernet traffic is present.
Introduction

11
About the AirStation CD
The AirStation does not require any software to
be installed on your computer for configuration.
The AirStation CD contains client drivers for
Buffalo Wireless Adapters (i.e. Notebook Adapter
and Desktop PCI Adapter) and the AirStation
documentation.
Prior to copying or installing any software, please
read the Software License Agreement “license.txt”,
located in the root folder of the CD. By installing,
copying or using the AirStation software, you are
consenting to the terms of this agreement. If you
do not agree to all of the terms of the Software Li-
cense Agreement, do not download, copy or install
the AirStation software.
It is the policy of Buffalo Technology to improve
products as new technology, components, software and firmware become available.
Please consult the AirStation wireless website (http://www.buffalotech.com/wireless) to download
and install the latest firmware for your product.
Follow these simple steps to connect the AirStation to your Broadband Internet connection allowing
Installation / Setup

12
you to combine and share wired and wireless computers and printers with the high-speed internet
connection.
1. Power down the cable or DSL modem and the computer which will be used to configure the
AirStation router.
2. Plug the cable or DSL’s LAN Ethernet cable into the AirStation’s WAN port. Initially, you may
need to unplug this cable from your computer, hub or other router.
3. Plug the provided Ethernet cable into a LAN port on the AirStation and plug the other end into
your computer Ethernet adapter’s (NIC) port. If you plan to initially configure the AirStation via a
wireless connection, (not recommended), you may skip this step.
4. Power on your cable or DSL modem, wait one full minute, Power on the AirStation router, wait
another full minute and then power on the computer which will be used to configure the AirSta-
tion. If the red DIAG light on the AirStation is lit or flashing after several minutes of being pow-
ered on, please consult Buffalo Technical Support.
Installation / Setup

13
The WBR2-G54 has two internal antennas. One has a
vertical orientation while the other has a horizontal orienta-
tion. This setup is ideal because it allows for proper antenna
polarization with both desktop and notebook style wireless
adapter antennas.
However, it may be necessary to increase your range further
by installing an external, higher-gain antenna. External
antennas come in all shapes and sizes. Antennas also
come with different connectors. The WHR2-G54 has an ‘MC
Connector’ on it. Thus, the antenna must also have an MC
connector.
To install the antenna, slide the antenna connector door on
the back of the WBR2-G54 to the right. This will expose the
MC Connector. Attaching the antenna is simple, just insert
the antenna’s MC Connector into the WBR2-G54’s MC Con-
nector and firmly push it in until it snaps into place. Once
snapped, the antenna’s connector will swivel with ease. It is
important not to push the antenna connector in at an angle.
To remove the antenna, pull the antenna connector out. It is
important not to pull the antenna connector out at an angle.
Antenna Installation

14
Introduction
Confi guring the AirStation using a standard web browser requires basic wireless confi guration
knowledge. Setup includes manual wireless confi guration and basic administrative management.
Setup Preparation
Make note of the AirStation’s wired MAC
address (found on the back of the WBR2-
G54). It is also recommended you record
any other broadband ISP information
such as global IP address, subnet mask
address, default gateway address, DNS
server address and PPPoE parameters.
Setup Overview
Buffalo recommends using a wired
connection, meaning your computer is
physically connected to the AirStation with
a CAT5 straight cable plugged into one
of the four LAN ports This type of setup
will eliminate possible setup problems due to any issues with the wireless adapter on the computer
being used to confi gure the AirStation.
Setup Preparation
Initial
Settings
Login
Standard Settings

15
A Web browser version 4.5 or later can be used to configure the AirStation.
Advanced settings for security, filtering and other features will be explained in later sections.
Open the Setup Screen
• Connect the WBR2-G54 according to the wiring instructions in Section 2.
• The WBR2-G54 has a default LAN IP address of 192.168.11.1 and Subnet Mask of
255.255.255.0.
■ Note: The computer used to configure the AirStation should be set to obtain an IP address
automatically using a DHCP server. The Quick Setup Guide enclosed with the product contains
detailed instructions on how to configure your computer for initial configuration.
On the computer used to configure the AirStation, launch a Web Browser 4.5 or later.
- Enter 192.168.11.1 into the URL field.
- A window will open prompting you to enter a User ID and Password
Enter “root” as the User ID and leave the password field blank.
■ Note: These are the factory default settings
Standard Settings

16
Enter ISP information
• Click the appropriate button to select the type
of broadband access. (Users more experienced
in networking may choose to select the Ad-
vanced button and skip to Section 4.)
• For supplementary tools, use the tabs along
the top of the screen.
DSL Button
Select the appropriate connection method.
Automatic IP Assignment by ISP
- The DHCP server of the ISP assigns an IP ad-
dress automatically.
Initial
Settings
Screen
Initial DSL
button
Screen
Standard Settings

17
Enter IP Address Manually
- Enter the IP Address given by the ISP.
- Use ‘Enter IP Address Manually’ if the ISP
requires use of a static IP address.
PPPoE Connection
- Enter the PPPoE information provided by the
ISP.
Manual DSL
IP Settings
Screen
DSL PPPoE
Settings
Screen
Standard Settings

18
CATV (Cable) Button
Select the appropriate connection method.
Automatic IP Assignment by ISP
- Select ‘Automatic IP Assignment by ISP’ if
your ISP’s DHCP server assigns an IP address
automatically.
Enter IP Address Manually
- Select ‘Enter IP Address Manually’ if the ISP
requires use of a static IP address.
Initial CATV
Settings
Screen
Manual IP
Address
Settings
Standard Settings

19
The IP Address is Acquired
Au to mat i cal ly but DNS Server Address
is Entered Manually
- Select ‘IP address is acquired automatically
but DNS server address is entered manually’ if
the ISP’s DHCP server supplies an IP address
but not DNS server addresses.
Line Test
Tests the connection to the Internet.
Auto IP/
Manual DNS
Settings
Line
Test Tab
Standard Settings

20
Security
The Security Tab offers three Simple Security
Settings. Follow the in struc tions in each screen
to enter WEP keys, MAC Address Filtering and
the degree of fi rewall security for the AirStation.
Security Tab
Standard Settings
