Bull Outdoor RF40D User manual

Outdoor
I
Commercial Refrigerator
USER'S MANUAL
Model Number: RF40D
IMPORTANT: READ THIS USER'S MANUAL PRIOR TO CONNECTING POWER AND USE
Before the refrigerator is used, it must be
PROPERLY POSITIONED, LEVEL --
and installed as described in this manual.
READ-THis MANUAL ·cAREFOLL Y .
c@us
LISTED
PRODUCT CERTIFIED UNDER UL471
Ningbo Yingqi Metal Products, Zhejiang, China

TABLE OF CONTENT
IMPORTANT SAFEGUIDES ......................................................................... 1
PART LIST ····················································:·····················-··································· 2
INST ALLA
Tl ON INSTRUCTIONS ····························································
· 3
BEFORE USING YOUR UNIT
SETTING THE TEMPERATURE CONTROL
ELECTRICAL CONNECTION
FOOD STORAGE
.INSTALLING YOUR UNIT
CARE AND MAINTENANCE ········································································ 4
OPERATING YOUR UNIT
CLEANING YOUR UNIT
POWER FAILURE
VACATION TIME
MOVING YOUR UNIT
TROUBLE SHOOTING GUIDES ·································································· 5
TECHNICAL DATA AND WIRING DIAGRAM
................................. 6
PACKING LIST
......................................................... 7

IMPORTANT SAFEGUIDES
To reduce the risk or fire, electncal Shock or injury when using the refrigerator.
follow basic precaution. including the following:
Remove all packages before using this unit.
A DANGER&
•Plug into a grounded 3-prong outlet, do not remove grounding prong, do not use an adapter, and
do not use-an extension cord.
•It is recommended that a separate circuit. serving only your refrigerator be provided. Use
receptacles that camot be turned off by a switch or pull chain.
•Never clean refrigerator parts with flammable fluids These fumes can create a fire hazard or
explosion And do not store or use gasoline or ot11er flammable vapors and liquids in the vicinity of
t111s or any other appliance The fumes can create a fire hazard or explosion
•Before proceeding with cleaning and maintenance operations. make sure the power line of the
unit 1s disconnected.
•Do not connect or disconnect U1e elect1ic plug when your hands are wet
•Unplug the refrigerator or disconnect power bP.fore cleaning or servicing. Failure to do so can
result in electrical shock or death.
•Do not attempt to repair or replace any part of your refrigerator unless ii is specifically
recommended 1n ll1is manual All oU1er servicing should be referred to a qualified technician.
&WARNING&
FOLLOW WARNING CALL OUTS BELOW ONLY WHEN APPLICABLE TO YOUR MODEL
•Use two or more people to move and install refligerator Failure to do so can result in back or
other injury
•To ensure proper ventilation for your refrigerator, the front or the unit must be completely
unobstructed. Cl1oose a well-ventilated area wiU1 temperatures above 40
°
F (5.C) and below
105
°
F (40
°
C) . This unit must be installed in an area protected from the element.
•Tl1e refrigerator should not be located next to other sources or high heat.
•The refrigerator must be installed With all electrical connections in accordance With state and local
codes. A standard electrical supply (115 V AC only, 60 Hz), prope11y grounded in accordance
with the National Electrical Code and local codes and ordinances is required.
•Do not kink or pinch t11e power supply cord or refiigerator
•The ruse (or circuit breakel) size should be 15 amperes
•It Is
Important for the refrigerator to be level In order to work properly You may need to
make several adjustmerts to level it
•Never allow C11ildren to operate, play with or crawl inside the refrigerator
•Do not use solvent-based cleaning agents or abrasives on the irterior These cleaners may
damage or discolor the interior
•Do not use this apparatus for other than its.intended purpose
1

PART LIST
Thermostat Door Seal
Wire Rack--,--
Venting grille
2

4
'
INSTALLATION INSTRUCTIONS
Before Using Your Unit
•Remove the exterior and interior packing.
Check to be sure you have all of the parts per packing list.
•Before connecting the unit to the power source. let it stand upright for approximately 2 hours. This
will reduce the possibility of a malfunction in the cooling system from handling during
transportation.
•Clean the interior surface with lukewarm water using a soft cloth.
Setting the Temperature Control
•Your unit has only one control for regulating the temperature in the compartment. The temperature
control is located on the upper side of the compartment.
•The first time you tum the unit on. set the temperature control to "5"
•The range of the temperature control 1s from position "OFF" to •·5•. "1" is warmer and "5" is
.£2212!. Mer 24 to 48 hours, adjust the temperature control to the setting that best suits your
needs The setting of "3" should be appropriate for normal use.
•To tum the appliance off. tum the temperature control to "OFF"
•
•
.
.
•
•
•
►
.
•
•
•
Electrical Connection
Turning the temperature control to "OFF'' position stops the cooling cycle but does not shut off the
power to the unit.
If the unit is unplugged. has lost power or is turned off, you must wait 3 to 5 minutes before
restartina the unit If vou attemot to restart hefore this time delav. the unit will not start
Food Storage
Use plastic wrap to keep food and place evenly on wire rack or drawer .
Let hot food cool down before put into this refrigerator for energy saving .
Don't open door or drawer fr quently
Keep gap between foods inside refrigerator
Keep food dry before storage .
Installing Your Unit
Remove food from refrigerator when power is out.
Place your unit on a floor that is strong enough to support the unit when it is fully loaded. To level
your unit. adjust the leveling legs at the bottom of the unit.
Locate the unit away from direct sunlight and sources of heat (stove, heater, radiator, etc.). Direct
sunlight may affect the acrylic coating and heat sources may increase electrical consumption.
Extreme cold ambient temperatures may also cause the unit not to perform properly.
Plug the unit into an exclusive, property installed-grounded wall outlet. Do not under any
circumstances cut or remove the third (ground) prong from the power cord. Any questions
concerning power and/or grounding should be directed toward a certified electrician or an
authorized Products service center.
•After plugging the appliance into a wall outlet. allow the unit to cool down for 2-3 hours before
placing food in the refrigerator compartment.

OPERA TING YOUR UNIT
CARE AND MAINTENANCE
•Your unit has only one control for regulating the temperature in the compartment. The temperature
control is located on top side of the compartment.
•The first time you tum the unit on, set the temperature control to "5" ..
•The range of the temperature control is from position "OFF" to "5'. After 24 to 48 hours, adjust the
tempeiature control to the setting that best suits your needs. The setting of "3" should be
appropriate for home or office use.
•To turn the appliance
off,
turn the temperature control to "OFF"
NOTE:
Turning the temperature control to "OFF" position stops the cooling cycle but does not shut
off the
power to the unit.
If the unit is unplugged, has lost power, or is turned off,
you must wait 3 to 5 minutes before
restarting the unit. If you attempt to restart before this time delay, the unit will not start.
CAUTION:
Do not use boiling water because it may damage the plastic parts. In addition, never use a sharp or
metallic instrument to remove frost as it may damage the cooling system and will v_oid the warranty.
We recommend using a plastic scraper.
Cleaning Your Unit
•Turn the temperature control to "OFF", unplug the unit, and remove the food, shelf, and tray.
•Wash the inside surfaces with a warm water and baking soda solution. The solution should be
about 2 tablespoons of baking soda to a quart of water.
•Wash the shelf and tray with a mild detergent solution.
•The outside of the unit should be cleaned with mild detergent and warm water.
•Leave excess water out of the sponge or cloth before cleaning the area of the controls, or any
electrical parts.
•Wash the outside cabinet with warm water and mild liquid detergent. Rinse well and wipe dry with
a clean soft cloth.
CAUTION:
Failure to unplug the unit could result in electrical shock or personal injury.
Power Failure
Most power failures are corrected within a few hours and should not affect the temperature of your
unit if you minimize the number of times the door is opened. If the power is going to be off for a longer
period of time, you need to take the proper steps to protect your food.
Vacation Time
•Short vacations: Leave the unit operating during vacations of less than three weeks.
•Long vacations: If the appliance will not be used for several months, remove all food and unplug
the power cord. Clean and dry the interior thoroughly. To prevent odor and mold growth, leave
the door open slightly: blocking it open if necessary.
Moving Your Unit
•Remove all the food.
•Securely tape down all loose items inside your unit.
•Turn the leveling legs up to the base to avoid damage.
•Tape the door shut.
•Be sure the unit stays secure in the upright position during transportation Also protect the
outside of unit with a blanket, or similar item
4

l
\
TROUBLE SHOOTING GUIDE
You can solve many common unit problems easily, saving you the cost of a possible service call. Try
the suggestions below to see if you can solve the problem before calling the service.
PROBLEM POSSIBLE CAUSE
Unit does not operate. Not plugged in.
The circuit breaker tripped or a blown fuse.
The unit temperature control is set at "OFF"
position.
Turns on and off frequently. The ambient temperature is hotter than normal.
A large amount of food has been added to the
unit.
The door is opened too often.
The door is not closed completely.
The temperature control is not set correctly.
The door gasket does not seal properly.
Vibrations. Check to assure that the unit is level.
The unit seems to make too much noise. The rattling noise may come from the flow of the
-refrigerant, which is normal.
As each cycle ends, you may hear gurgling
sounds caused by the flow of refrigerant in your
unit.
Contraction and expansion of the inside walls
may cause popping and crackling noises.
The unit is not level.
The door will not close properly. The unit is not level.
The door was reversed and not properly installed.
The gasket is dirty or bent.
The shelves, bins, or baskets are out of oosition.
Energy Saving Tips
•Let
hot foods cool to room temperature before placing in the unit. Overloading the unit forces the
compressor to run longer.
•Be sure to wrap foods properly, and wipe containers dry before placing them in the unit. This cuts
down on frost build-up inside the unit.
•Unit storage bin should not be lined with aluminum foil, wax paper, or paper toweling. Liners
interfere with cold air circulation, making the unit less efficient.
•
Organize and label food to reduce door openings and extended searches. Remove as many
items as needed at one time, and close the
door as soon as possible.
•
Unit Safety Clearance
BACK �
200 mm
LEFT � 100 mm
RIGHT � 100mm
TOP
� 100 mm
5

\
Technical Data and Wiring Diagram
■Technical Data
Data el
Item
Voltage
V
Frequency
HZ
Current
A
Input Wattage
w
Comsumption
Kw. h/24/J
Volume
cuft
Dimensions (W X D X H) mm
Refrigerant
Refrigerant Charge
High Pressure
Low Pressure
Weight
Insulation
■Wiring Diagram
L
N
Light
pounds
psig
psig
KG
RF40D
110~
60
1.55
115
0.85
4. I
520�72*840
Rl34a
0.0883
218
88
45
PU
Compressor
Note: This wire diagram Is just for reference only. The wiring label on back of refrigerator will be accurate.
6

Packing List
.
NO. Description Quantity
1
Refrigerator
1
2
Wire Rack
3
3
Coke Shelf
1
4
Big Block Bar
1
5
Small Block Bar
2
6
User's Manual
1
7 Certification
1
7

Lll\1ITED WARRANTY
Bull Outdoor Products, Inc. warrants One Year to the original purchaser at the original site of delivery with
proof of purchase of each Outdoor Refrigerator that when subject lo nonnal residential use, it is free from
defects in workmanship and materials for the periods specified below. This wammty excludes products used
in rental or commercial applications. It does not apply to rust, co1TOsion, oxidation or discoloration, which
may occur due to moisture or overheating, unless the affected component becomes inoperable. It does not
cover labor or labor related charges. There will be shipping and handling charge for the delivery of
the
warranty prut(s).
Our obligation under this wru1·anty is limited to repair or replacement, at our option, of the product during
the warranty period. 111e extent of any liability of Bull Outdoor Products, Inc., under U1is warranty is limited
to repair or replacement. This warranty does not cover nonnal wear of pruts, damage resulting from any of
the following: negligent ·use or misuse of the product. use on improper power supply, use. contrary to
operating instructions, or alteration by any person other than our factory service center. The warranty period
is not extended by such repair or replacement
Warranty dahn procedure: If you require service or pruts for your Bull Products, please contact our
Warranty Service Center for factory direct assistance. Our hours of operation are 8AM lo 4 PM PST. Our
phone number is [phone] and our FAX number is [phone] or email to
[email protected]. Please direct all correspondence to: Bull Outdoor Products, Inc., Rialto, CA
92376 ATIN: Warranty Service Center
Product repair as provided under this warranty is your exclusive remedy. Bull Outdoor Products, Inc. shall
not be liable for any incidental or consequential damages for breach of any express or implied warranty on
its products. Except to the extent prohibited by applicable law, any implied wan-anty or me
rchantability or
fitness for a patticular pull)ose on this product to the duration of
the above warranty. Some states do not
allow the exclusion or limitation of incidental or consequential damages, or allow limitations on how long
an implied warranty lasts, so the above limitations or exclusions may not apply to you. This warranty gives
you specific legal rights, and you may have other rights, which vary from state to state.
Model Number ______________ Serial Number ____________ _
·
Date of
Purchased Purchased From ___ _
