Bullard EVABKPK2 User manual

EVABKPK2
(Ergonomic Backpack Harness)
www.bullard.com
WARNING
Please read all instructions and warnings before using. Keep this
user manual for reference. If you have questions regarding this
product contact Bullard Technical Services in your region. For
proper use, refer to an EVA or EVAHL user manual being used with
the EVA Ergonomic Backpack Harness to complete system assembly
and performance checks.
The EVA Ergonomic Backpack Harness is part of a system that
helps protect against certain airborne contaminants. Misuse
may result in sickness or death.
Description
The EVA Ergonomic Backpack Harness by Bullard® is designed
to distribute the weight of your EVA or EVAHL providing comfort and
maneuverability for extended periods of time. The EVA Ergonomic
Backpack Harness is an optional method of wearing with an EVA or
EVAHL. When used, it must be paired with an EVABELT1 or EVABELT2.
Users do have the option to omit the EVA Ergonomic Backpack
Harness and use only an EVABELT1 or EVABELT2.
NIOSH – Approval, Cautions, and Limitations
The EVA Ergonomic Backpack Harness is one component of a NIOSH
approved system. Refer to an EVA or EVAHL user manual or the
NIOSH approval label provided with the EVA or EVAHL for approved
configurations and applicable NIOSH Cautions and Limitations.
Assembly
EVA/EVAHL Blower Unit with Filter PAPRFC3
1.Lay EVABKPK2 on a flat
surface, unsnap the three
(3) buckles, and fold back
the white EVA holder
towards the top of the
EVA Ergonomic Backpack
Harness (Figure 1).
2. Place an assembled EVA/
EVAHL (with battery
and filter installed) and
EVABELT1 or EVABELT2
onto EVABKPK2 with EVA
facing up
(Figure 2).
NOTE:
If using PAPRFC3, the
filter must be installed
at this time.
3. Snap both buckles on either side
of the EVABKPK2 around the
EVABELT1 or EVABELT2
(Figure 3).
4. Bring the white EVA holder down
onto the PAPRFC3 filter and snap
the remaining buckle on the
white EVA holder to the bottom
of the EVABKPK2 (Figure 4).
5. Tighten the strap on the bottom of the
white EVA holder to securely retain EVA/
EVAHL to EVABKPK2 (Figure 5).
6. Don the EVA Ergonomic Backpack Harness
ensuring the shoulder straps are crossed
at the back, buckle the EVABELT1 or
EVABELT2, and adjust the shoulder straps
for a comfortable fit (Figure 6).
Fig. 1
Fig. 2
Fig. 3
Fig. 4
Fig. 5
Fig. 6

©2019 Bullard. All rights reserved.
60810012094A POST (0619)
ISO 9001
certified
EVA/EVAHL Blower Unit with Filter PAPRFC4 or PAPRFC5
1. Lay EVABKPK2 on a flat
surface, unsnap the
three (3) buckles, and
fold back the white EVA
holder towards the top
of the EVA Ergonomic
Backpack Harness
(Figure 7).
2. Place an assembled EVA/
EVAHL (with battery) and
EVABELT1 or EVABELT2
onto EVABKPK2 with EVA
facing up (Figure 8).
NOTE:
If using PAPRFC4 or
PAPRFC5, DO NOT
install the filter at this
time.
3. Snap both buckles
on either side of the
EVABKPK2 around the
EVABELT1 or EVABELT2 (Figure 9).
4. Bring the white EVA holder down
onto the EVA/EVAHL and snap
the remaining buckle on the
white EVA holder to the bottom
of the EVABKPK2 (Figure 10).
5. Screw the PAPRFC4 or
PAPRFC5 filter, going
through the white EVA
holder, onto the EVA/
EVAHL (Figure 11).
6. Tighten the strap on
the bottom of the white
EVA holder to securely
retain EVA/EVAHL to
EVABKPK2 (Figure 12).
7. Don the EVA Ergonomic
Backpack Harness
ensuring the shoulder
straps are crossed at
the back, buckle the
EVABELT1 or EVABELT2,
and adjust the shoulder
straps for a comfortable fit (Figure 13).
Adjusting the height and
comfort of the belt
You can adjust the height of the
belt on your waist to suit your
comfort. Just pull on the shoulder
straps to raise the belt position,
and adjust as needed (Figure 14).
