Bulldog security 200q User manual

1) Reversible Car Plate

2) Locking Stud and dust cap

3) Damper pivot bracket

4) Cam lever and 12mm safety

type adjusting bolt two lock nuts

5) Stabiliser spring arm

6) Angle bracket & slipper assembly

7) Tubular handle (detachable)

8) Saddle clamp c/w packer plates (2mm

& 6mm thck)

To Operate The Quick Release: To release pressure on the Ferodo friction discs fit the tubular handle (7) on to cam spigot (4) and lift cam to vertical

position. To apply pressure to the friction discs, simply press down until handle is horizontal, remove handle.

Fitting To The Car

1) Remove the towing ball.

2) Determine which side, and fit the reversible car plate (1) between the

towing ball and the car towing bracket (longer high tensile bolts may be necessary).

3) Lift the quick release cam (4) and insert damper pivot bracket (3) in to the slot in

the reversible car plate (1) and secure with locking stud(2). To clear the caravan ‘A’ frame pull the stabiliser towards you.

Fitting To The Caravan With A Fairing: When fitting the angle bracket (6) to an ‘A’ frame covered by a plastic fairing it is advisable to remove the

fairing and fit directly to the metal frame. Then replace the fairing over the angle bracket.

Fitting To The Caravan.

1) Load the car and caravan as normal and hitch up in line on a level surface. Please ensure the hitch is fully forward.

2) Push the stabiliser spring arm until it is parallel to the caravan ‘A’ frame.

3) Slide the angle bracket and slipper assembly (6) on to the spring arm leaving 4” (100mm) of spring protruding.

4) Holding the angle bracket vertical scribe marks down its edge on to the ‘A’ frame. Remove the bracket and pull aside the spring arm.

5a) Using Saddle Clamp Bracket Provided.

Alko Steel Chassis 40mm or 45mm wide and BPW Steel Chassis 46mm wide

also 1993 Swift Conqueror Alko Chassis.

i) Slide the saddle clamp bracket (8) over the chassis (tapped holes to the

front) and position between the vertical pencil marks.

IMPORTANT. On Swift Conqueror, or any other aluminium chassis, fit an

insulator between saddle clamp bracket and chassis e.g. Bulldog rubber strip

part No LC27.

ii) Engage angle bracket assembly (6) under spring and push to ‘A’ frame.

iii) Lock up quick release and lift spring arm at end between 1.5” to 2.5” (40 to

65mm). Note which row of holes in angle bracket line up with bottom holes in

saddle clamp bracket.

iv) Fit the angle bracket to the bottom set of holes with the two M8 x 75 long

bolts and lock nuts provided.

Alko 40mm wide chassis:- Fit 6mm packer plate between saddle

clamp and outer face of chassis.

Alko 45mm wide chassis:- Fit 2mm packer plate between saddle

clamp and outer face of chassis.

BPW 46mm wide chassis:- Omit packers.

v) Fit one serrated M8 washer and one plain washer over each of the two M8

x 16 set pins.

vi) Screw set pins through top two holes in angle bracket.

vii) Tighten the two long bolts and nuts and the two set pins evenly (do not

over tighten).

5b) Fitting To Chassis Where Drilling is possible.

(Refer to Caravan handbook).

Follow fitting to the caravan steps 1 to 4 then:

i) In the approximate position of the angle bracket on the ‘A’ frame draw

a horizontal centre line equal distance from the top and bottom flanges.

ii) Position the angle bracket vertical to the lines marked on the ‘A’ frame

and mark through any two holes on to the centre line. Remove the

bracket.

iii) Drill two 8.5mm holes.

iv) Slide angle bracket back on to spring arm and push to ‘A’ frame.

v) Lock up quick release and lift spring arm at end between 1.5” and 2.5” (40

to 65mm) and insert two M8 x 30 bolts through the appropriate holes and

bolt up with nuts and washers. Tighten evenly.

Vertical line

Packer Plate

(40 or 45mm

Chassis)

4”

(100mm)

1.5”

(40mm)

2.5”

(65mm)

Vertical line

1.5”

(40mm)

2.5”

(65mm)

4”

(100mm)

‘A’ Frame

These instructions must be passed onto the Stabiliser user.

200Q Stabiliser Fitting Instructions

Reading of 60lb (27kg)

Scales

Sideways force applied

Stabiliser spring

WARNING!

After fitting and prior to commencing your journey, please check tightness of the locking stud holding the Stabiliser into the car bracket. A secondary safety

and security feature of the Bulldog Stabiliser is the provision of a hole in the end of the damper pivot plate (3). This is to facilitate the use of a padlock (not

supplied).

When Boarding Ferries or Off Road on Uneven Ground.

It is advisable to remove stabiliser to avoid damage to the spring arm.

When Not In Use.

Remove locking stud. Apply grease in the thread car bracket and fit Red Cap. To remove cap just unscrew.

Adjustments.

1) Once fitted check that the springs are completely retained in the plastic slippers and do not catch any part of the caravan or trailer when the vehicle is on

full lock.

2) The stabiliser is factory set but may need adjustment after use.

3) To adjust the friction damper assembly you will require the following tools:

. A set of bathroom scales or suitable spring balance.

. Two open ended 19mm spanners.

Note. Adjustment is carried out with quick release locked i.e. pressure applied to friction discs.

IMPORTANT!

Please DO NOT use torque wrench as the torque needed on the 12mm adjusting bolt and nut (4) is very small.

4) Insert the damper pivot bracket (3) into the slot in the car plate (1) and secure with locking stud(2).

5) Apply the scales to the end of the spring arm and push. You are looking for a reading on the scales of approximately 60lbs (27kg).

It is emphasised that this is NOT a torque figure but the horizontal push/pull force at the end of the spring arm.

6) Adjustment is made by releasing the thin lock nut on the 12mm centre bolt and tightening up the special type lock nut until the appropriate reading is

obtained on the

scale. Finally, firmly lock up the special nut and thin lock nut together using the two spanners. Take care not to move the special nut on the bolt or you

may lose the

correct setting. Check tightness of the thin lock nut after 50 miles.

7) DO NOT USE ANY OTHER METHOD FOR CHECKING THE STABILISER.
