Bunn SA Instruction Manual

ILLUSTRATED PARTS CATALOG
Designs, materials, weights, specifications, and dimensions for equipment or replacement parts
are subject to change without notice.
S,SA
ST,STA
STF,STFA
BUNN-O-MATIC CORPORATION
POST OFFICE BOX 3227
SPRINGFIELD, ILLINOIS 62708-3227
PHONE: [phone] FAX: [phone]
www.bunnomatic.com
29252.0000 08/02 ©1998 Bunn-O-Matic Corporation
BUNN
®

229252 070102
BUNN-O-MATIC COMMERCIAL PRODUCT WARRANTY
Bunn-O-Matic Corp. (“BUNN”) warrants equipment manufactured by it as follows:
1) All equipment other than as specified below: 2 years parts and 1 year labor.
2) Electronic circuit and/or control boards: parts and labor for 3 years.
3) Compressors on refrigeration equipment: 5 years parts and 1 year labor.
4) Grinding burrs on coffee grinding equipment to grind coffee to meet original factory screen sieve analysis: parts
and labor for 3 years or 30,000 pounds of coffee, whichever comes first.
These warranty periods run from the date of installation BUNN warrants that the equipment manufactured by it will
be commercially free of defects in material and workmanship existing at the time of manufacture and appearing
within the applicable warranty period. This warranty does not apply to any equipment, component or part that was
not manufactured by BUNN or that, in BUNN’s judgment, has been affected by misuse, neglect, alteration, improper
installation or operation, improper maintenance or repair, damage or casualty. This warranty is conditioned on the
Buyer 1) giving BUNN prompt notice of any claim to be made under this warranty by telephone at [phone]
or by writing to Post Office Box 3227, Springfield, Illinois 62708-3227; 2) if requested by BUNN, shipping the
defective equipment prepaid to an authorized BUNN service location; and 3) receiving prior authorization from
BUNN that the defective equipment is under warranty.
THE FOREGOING WARRANTY IS EXCLUSIVE AND IS IN LIEU OF ANY OTHER WARRANTY, WRITTEN OR ORAL,
EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF EITHER
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. The agents, dealers or employees of BUNN are
not authorized to make modifications to this warranty or to make additional warranties that are binding on BUNN.
Accordingly, statements by such individuals, whether oral or written, do not constitute warranties and should not
be relied upon.
If BUNN determines in its sole discretion that the equipment does not conform to the warranty, BUNN, at its
exclusive option while the equipment is under warranty, shall either 1) provide at no charge replacement parts and/
or labor (during the applicable parts and labor warranty periods specified above) to repair the defective
components, provided that this repair is done by a BUNN Authorized Service Representative; or 2) shall replace
the equipment or refund the purchase price for the equipment.
THE BUYER’S REMEDY AGAINST BUNN FOR THE BREACH OF ANY OBLIGATION ARISING OUT OF THE SALE OF
THIS EQUIPMENT, WHETHER DERIVED FROM WARRANTY OR OTHERWISE, SHALL BE LIMITED, AT BUNN’S
SOLE OPTION AS SPECIFIED HEREIN, TO REPAIR, REPLACEMENT OR REFUND.
In no event shall BUNN be liable for any other damage or loss, including, but not limited to, lost profits, lost sales,
loss of use of equipment, claims of Buyer’s customers, cost of capital, cost of down time, cost of substitute
equipment, facilities or services, or any other special, incidental or consequential damages.

ELECTRICAL AND OPERATING CONTROLS (Models S and SA)................................................................................................. 21
ELECTRICAL AND OPERATING CONTROLS (Models SDB) ........................................................................................................ 25
ELECTRICAL AND OPERATING CONTROLS (Models ST, STA, STF, STFA) ................................................................................ 27
FAUCET AND TUBING ................................................................................................................................................................. 19
FUNNELS AND BASKET .............................................................................................................................................................. 35
HOUSING AND COVERS (Models S and SA) ................................................................................................................................ 5
HOUSING AND COVERS (Models SDB) ........................................................................................................................................ 7
HOUSING AND COVERS (Models ST, STA, STF, STFA) ................................................................................................................ 9
NUMERICAL INDEX .................................................................................................................................................................... 36
STRAINER/FLOW CONTROL....................................................................................................................................................... 17
TANK AND BASIN ....................................................................................................................................................................... 13
WARMER ASSEMBLIES ............................................................................................................................................................. 33
TABLE OF CONTENTS
3
The following Model designations are defined as indicated below. Models with faucet are available in either Right or Left side
versions.
Model S Pour Over (120V)
Model SA Pour Over (230V)
Model SDB Pour Over (100V) w/ One Top Warmer
Model ST Automatic (120V & 120/240V)
Model STW Automatic (120V & 120/240V) w/Wide Funnel (7.62")
Model STA Automatic (230V)
Model STB Automatic (200V)
Model STF Automatic w/Faucet (120V & 120/240V)
Model STFW Automatic w/Faucet (120V & 120/240V) w/Wide Funnel (7.62")
Model STFA Automatic w/Faucet (230V)
Model STFDB Automatic w/Faucet (200V)
Model ST and STF are available in 120V 15amp, 120V 20amp and 120/240V 20amp versions.
Model S is also available in a 120/240V version.
Model SP Same as Model S w/ Plastic Funnel
Model SPA Same as Model SA w/ Plastic Funnel
Model STP Same as Model ST w/ Plastic Funnel
Model STFP Same as Model STF w/ Plastic Funnel
NTW Models with No Top Warmer
29252 042301

4
BUNN
®HOUSING AND COVERS S
SA
P 1572
2
3
1
5
4
6
9
10
11
12
7
8
13
17 19 20
18
16
14
15
29252 022300

ITEM PART NO. QTY. DESCRIPTION
5
102770.0000 1 Lid Assy (Includes items 2 and 3)
200757.0000 1 Knob
01326.0000 1 Screw, Truss Head #10-32 x .25"
302722.0000 1 Lid, Pour In
429268.0000 1 Cover W/ Decals, Two Warmer Housing (Includes item 5)
02690.0000 1 Cover, Top (No Top Warmer)
01380.0000 4 Screw, Truss Head #8-32 x .50"
502763.0000 1 Decal, CAUTION-HOT SURFACE/POUR IN WATER ONLY
6 29255.0000 1 Housing W/ Decals, Main (Model S)(Includes items 7 and 8)
29256.0000 1 Housing w/Decals (120/240V)(No Faucet)(Includes item 8)
- - - - - - - - 1 Housing, Main (Model SA)(Contact BUNN-O-MATIC for availability)
700658.0000 1 Decal, Warning DECANTER/FUNNEL
802769.0000 1 Decal, CAUTION-HOT SURFACE
9 02750.0000 1 Plate, Backup (w/out ready light)
02626.0000 1 Plate, Backup (w/ready light)
10 02721.0000 1 End Cap, Front (w/out ready light)
02625.0000 1 End Cap, Front (w/ready light)
02301.0000 2 Screw, Phillips Pan Head #6-32 x .625"
11 02751.0000 1 Decal, BUNN S Series
12 02762.0000 1 Label, Switch (Two Upper Warmers)(w/out ready light)
02627.0000 1 Label, Switch (Two Upper Warmers)(w/ready light)
02821.0000 1 Label, Switch (No Top Warmer)
13 02734.0000 1 Plate, Bottom Base
02335.0001 4 Screw, Hex-Crimptite #8-32 x .375"
14 25137.0002 4 Foot
00970.0000 4 Nut, KEPS #8-32
15 03011.0000 1 Plug, Vent
16 00917.0000 4 Fastener, "J" Type #8-32
17 29270.0000 1 Panel W/ Decals, Back(Includes items 18. Also order item 19)
01311.0000 4 Screw, Truss Head #8-32 x .25"
18 00831.0000 1 Decal, Warning Electrical
19 10043.0000 1 Schematic, Electrical, 120V (Model S)
- - - - - - - - 1 Schematic, Electrical, 230V (Model SA)(Not Serviced)
- - - - - - - - 1 Schematic, Electrical, 120/240V (Model S)(Not Serviced)
20 00606.0000 1 Bushing
HOUSING AND COVERS
29252 042301

6
BUNN
®HOUSING AND COVERS SDB
P 1573
2
3
1
5
4
6
9
10
11
12
7
8
13
18
16
14
15
17 21 19 20
29252 022300

ITEM PART NO. QTY. DESCRIPTION
7
102770.0000 1 Lid Assy (Includes items 2 and 3)
200757.0000 1 Knob
01326.0000 1 Screw, Truss Head #10-32 x .25"
302722.0000 1 Lid, Pour In
429269.0000 1 Cover W/Decal, Top Housing, Pour In(One Upper Warmer)(Includes item 5)
01380.0000 4 Screw, Truss Head #6-32 x .50"
502763.0000 1 Decal, CAUTION-HOT SURFACE/POUR IN WATER ONLY
6-- - - - - - - 1 Housing, Main (Contact BUNN-O-MATIC for availability)
700658.0000 1 Decal, Warning DECANTER/FUNNEL
802769.0000 1 Decal, CAUTION-HOT SURFACE
902626.0000 1 Plate, Backup
10 02625.0000 1 End Cap, Front
02301.0000 2 Screw, Phillips Pan Head #6-32 x .625"
11 02751.0000 1 Decal, BUNN S Series
12 02958.0000 1 Label, Switch
13 02734.0000 1 Plate, Bottom Base
02335.0001 4 Screw, Hex-Crimptite #8-32 x .375"
14 25137.0002 4 Foot
00970.0000 4 Nut, KEPS #8-32
15 03011.0000 1 Plug, Vent
16 00917.0000 4 Fastener, "J" Type #8-32
17 29270.0000 1 Panel W/Decal (Includes item 18)
01311.0000 4 Screw, Truss Head #8-32 x .25"
18 00831.0000 1 Decal, Warning Electrical
19 - - - - - - - - 1 Schematic, Electrical, 100V (Model SDB)(Not Serviced)
20 00606.0000 1 Bushing
21 02732.0000 1 Cover, Back
01311.0000 2 Screw, Truss Head #8-32 x .25"
00917.0000 2 Fastener, "J" Type #8-32
HOUSING AND COVERS
29252 022300

8
BUNN
®HOUSING AND COVERS ST,STA
STF, STFA
P 1574
!CAUTIONWARMERSANDSURFACESAREHOT
TOP FRONT ON / LOWER START
TOP REAR
10043.0000D3/97©1988BUNN-O-MATICCORPORATION
WHI
BLU
LIMIT
THERMOSTAT
SW.&
THERMOSTAT
TANKHEATER
N
BLK
L1
BLK
WHI
P1
P3
P2
P1,P2,&P3AREPINSOF
APOLARIZEDTHREE-PIN
CONNECTOR.
GREEN
SCHEMATICWIRINGDIAGRAMS
"KEEPWARM"HEATER
50W
WHI
TOPREAR
WARMER
100W
WHI
WHI
BLKBLU/BLK
TOPFRONT
WARMER
100W
WHI
BLKBRN/BLK
LOWERWARMER
100W
WHI
WHIBLK
BLU/BLK
BRN/BLK
WHI
120VOLTSAC2WIRE
SINGLEPHASE
60HZ
1425W
WHI/VIO
!CAUTION
WARMERS AND SURFACES ARE HOT
1
2
3
4
5
7
8
9
10
11
12
24
13
6
18 20 21 22 23
19
17
25
15
14
16
29252 112200

ITEM PART NO. QTY. DESCRIPTION
9
HOUSING AND COVERS
102722.0000 1 Lid
01319.0000 1 Screw, Thumb #8-32 x .75"
229268.0001 1 Cover W/Decals, Two Top Warmer Housing (Includes items 3 & 4)
02811.1007 1 Cover, Housing (No Top Warmer)(Includes items 1 & 4)
01380.0000 4 Screw, Truss Head #6-32 x .50"
302765.0000 1 Decal, CAUTION-HOT SURFACE
400912.0000 1 Fastener, "J" Type #8-32
529256.0000 1 Housing W/Decals, (120V & 120/240V)(No Faucet)(Includes item 6)
29256.0001 1 Housing W/Decals, (120V & 120/240V)(Faucet Right)(Includes items 6 and 7)
29256.0002 1 Housing W/Decals, (120V & 120/240V)(Faucet Left)(Includes items 6 and 7)
- - - - - - - - 1 Housing (230V)(No Faucet)(Contact BUNN-O-MATIC for availability)
- - - - - - - - 1 Housing (230V)(Faucet Right)(Contact BUNN-O-MATIC for availability)
- - - - - - - - 1 Housing W/ 7.62" Wide Funnel (230V)(No Faucet)(Contact BUNN-O-MATIC for
availability)
- - - - - - - - 1 Housing W/ 7.62" Wide Funnel (230V)(Faucet Right)(Contact BUNN-O-MATIC for
availability)
602769.0000 1 Decal, CAUTION-HOT SURFACE
700882.0000 1 Decal, WARNING HOT WATER
802626.0000 1 Plate, Backup (4 Hole)
02750.0000 1 Plate, Backup (3 Hole)(No Top Warmer)
902625.0000 1 Cap, End (4 Hole)
02721.0000 1 Cap, End (3 Hole)(No Top Warmer)
02301.0000 2 Screw, Pan Head #6-32 x .625"
10 02751.0000 1 Decal, BUNN S Series
11 02627.0000 1 Label (Two Upper Warmers)
02820.0000 1 Label (No Top Warmer)
21239.0000 1 Label (Ready Light)
12 29270.0001 1 Panel W/Decals, Front (Includes item 13)
01311.0000 4 Screw, Truss Head #8-32 x .25"
13 00658.0000 1 Decal, CAUTION-DECANTER/FUNNEL
14 02734.0000 1 Plate, Bottom Base
02335.0001 4 Screw, Hex-Crimptite #8-32 x .375"
15 25137.0002 4 Foot
00970.0000 4 Nut, KEPS #8-32
16 03011.0000 1 Plug, Vent
17 00917.0000 8 Fastener, "J" Type #8-32
18 29270.0002 1 Panel W/Decals, Back (Includes items 19 & 21. Also order item 20)
01311.0000 4 Screw, Truss Head #8-32 x .25"
19 00831.0000 1 Decal, WARNING-ELECTRICAL
29252 052400
(Continued)

10
BUNN
®HOUSING AND COVERS ST,STA
STF, STFA
P 1574
!CAUTIONWARMERSANDSURFACESAREHOT
TOP FRONTON / LOWER START
TOP REAR
10043.0000D3/97©1988BUNN-O-MATICCORPORATION
WHI
BLU
LIMIT
THERMOSTAT
SW.&
THERMOSTAT
TANKHEATER
N
BLK
L1
BLK
WHI
P1
P3
P2
P1,P2,&P3AREPINSOF
APOLARIZEDTHREE-PIN
CONNECTOR.
GREEN
SCHEMATICWIRINGDIAGRAMS
"KEEPWARM"HEATER
50W
WHI
TOPREAR
WARMER
100W
WHI
WHI
BLKBLU/BLK
TOPFRONT
WARMER
100W
WHI
BLKBRN/BLK
LOWERWARMER
100W
WHI
WHIBLK
BLU/BLK
BRN/BLK
WHI
120VOLTSAC2WIRE
SINGLEPHASE
60HZ
1425W
WHI/VIO
!CAUTION
WARMERS AND SURFACES ARE HOT
1
2
3
4
5
7
8
9
10
11
12
24
13
6
18 20 21 22 23
19
17
25
15
14
16
29252 112200
(Continued)

ITEM PART NO. QTY. DESCRIPTION
11
20 10272.0000 1 Schematic (120V)(Model ST, STP)
- - - - - - - - 1 Schematic (240V)(Model STA, STPA)(Not available)
- - - - - - - - 1 Schematic (100V)(Model STB)(Not available)
10292.0000 1 Schematic (120, 240V)(Model STF, STFP)
10292.0002 1 Schematic (120 & 120/240V) (Model STF) (No Top Warmer)
- - - - - - - - 1 Schematic (230V)(Model STFA, STFPA)(Not available)
- - - - - - - - 1 Schematic (230V)(Model STFA)(No Top Warmer)(Not available)
- - - - - - - - 1 Schematic (200V)(Model STFDB)(Not available)
21 00656.0000 1 Decal, COMPLIANCE TO PLUMBING CODE
22 06060.1000 1 Decal, NOTICE-ELECTRICAL INSTALLATION (Not applicable to 15 amp units)
23 00606.0000 1 Bushing
24 32540.0000 1 Decal, Timer Batch Set (Models with Digital Timer)
25 33450.0000 1 Decal, Drain Notice (STFDB)
HOUSING AND COVERS
29252 112200

12
BUNN
®TANK AND BASIN S,SA,ST,STA
STF, STFA
29252 081402
P 1575
3
1
4
5
2
14
15
16
21
20
17
18
19
28
29
22
30
23
24
25
26
27
38 37 36 35 34 33 32 31
8
9
10
11
7
8
13
12
6

ITEM PART NO. QTY. DESCRIPTION
13
-02604.1001 1 Tank Assy, Mod. S (1425W, 120V)
02604.1003 1 Tank Assy, Mod. ST-15 (1425W, 120V)
02604.1004 1 Tank Assy, Mod. ST-20 (1800W, 120V)
02604.1005 1 Tank Assy, Mod. ST-35 (3500W, 120/240V)
02604.1006 1 Tank Assy, Mod. STF-15, Faucet Right (1425W, 120V)
02604.1009 1 Tank Assy, Mod. STF-15, Faucet Left (1425W, 120V)
02604.1007 1 Tank Assy, Mod. STF-20, Faucet Right (1800W, 120V)
02604.1010 1 Tank Assy, Mod. STF-20, Faucet Left (1800W, 120V)
02604.1008 1 Tank Assy, Mod. STF-35, Faucet Right (3500W, 120/240V)
02604.1011 1 Tank Assy, Mod. STF-35, Faucet Left (3500W, 120/240V)
- - - - - - - - 1 Tank Assy, Mod. SA (1850W, 230V)
- - - - - - - - 1 Tank Assy, Mod. SDB (1600W, 100V)
- - - - - - - - 1 Tank Assy, Mod. STA-35 (3500W, 230V)
- - - - - - - - 1 Tank Assy, Mod. STFA-35, Faucet Right (3500W, 230V)
- - - - - - - - 1 Tank Assy, Mod. STB (3500W, 200V)
- - - - - - - - 1 Tank Assy, Mod. STFDB, Faucet Right (3500W, 200V)
- - - - - - - - 1 Tank Assy, Mod. STFA-20, Faucet Right (1850W, 230V)
- - - - - - - - 1 Tank Assy, Mod. S (3500W, 120/240V)
102715.0000 1 Tank Lid (Brewers Without Faucets)
02829.0000 1 Tank Lid (Brewers With Faucets)
202747.0000 1 Gasket, Tank Lid
302775.0000 3 Bracket, Hold Down
00908.0000 3 Nut #8-32
402803.1000 1 Probe, Liquid Level (Brewers With Faucets)(Includes Hardware)
01501.0000 1 Washer
20203.0100 1 Lockwasher #8
00908.0000 1 Nut #8-32
502536.0000 1 Grommet (Brewers With Faucets)
NOTE: Items 6 thru 13 are for Model SDB with rear drain only)
6 02961.1000 1 Switch, Float (Includes items 7 and 8)
702651.0000 1 Support
803803.0000 1 Switch Assy (Includes items 9 thru 11)
903633.0000 1 Gasket
10 - - - - - - - - 3 Washer, Adjusting (DO NOT USE IN THIS APPLICATION)
11 03807.0000 1 Clip, Spring
12 07075.0000 1 Grommet
13 02954.0000 1 Ring, Retaining
14 02652.0000 1 Tube, Fill Basin
15 02713.0000 1 Cup, Syphon
16 02746.0000 1 Gasket
TANK AND BASIN
(Continued)
Includes items
1 thru 5 &
12 thru 27
Not Available.
Order Components
29252 042301
Includes items
1 thru 3,
12 thru 20 &
22 thru 27

14
BUNN
®
(Continued)
TANK AND BASIN S,SA,ST,STA
STF, STFA
P 1575
3
1
4
5
2
14
15
16
21
20
17
18
19
28
29
22
30
23
24
25
26
27
38 37 36 35 34 33 32 31
8
9
10
11
7
8
13
12
6
29252 081402

ITEM PART NO. QTY. DESCRIPTION
15
TANK AND BASIN
17 02745.0000 1 Nut, Brass .562-24"
18 00929.0001 1 Nut, Compression
19 02717.0000 1 Tube, Sprayhead (Includes item 18)
20 02719.0000 1 Tank /Fill Basin, Pour Over (No Faucet)
02667.0000 1 Tank /Fill Basin, Automatic (No Faucet)
02668.0001 1 Tank /Fill Basin, Automatic (Faucet Right)
02668.0002 1 Tank /Fill Basin, Automatic (Faucet Left)
02658.0000 1 Tank /Fill Basin, (Model SDB with rear drain)
02668.0003 1 Tank /Fill Basin, (Model STFDB with rear drain)
21 02659.0000 1 Tube, Tank To Faucet (Left and Right)
22 02653.1000 1 Tube, Fill Basin to Solenoid (Includes Connector)
00402.0001 1 Connector .25" FLR x .125" MPT
23 02755.1000 1 Tank Heater, 1425W 120V (Includes item 24)
02756.1000 1 Tank Heater, 1800W 120V (Includes item 24)
02805.1000 1 Tank Heater, 1850W 240V (Includes item 24)
05037.1000 1 Tank Heater, 3500W 240V (Includes item 24)
20940.1000 1 Tank Heater, 1600W 100V (Includes item 24)
20942.1000 1 Tank Heater, 3500W 200V (Includes item 24)
28660.1000 1 Tank Heater, 2000W 240V (Includes item 24)
24 00943.0000 2 Gasket, Tank Heater
25 00942.0000 2 Nut, Brass .50-20"
26 29329.1000 1 Thermostat, Limit
27 04260.0000 1 Blanket, Warmer 50W 120V
01927.0000 1 Blanket, Warmer 50W 220V
28 01075.0000 1 Nut, Hex .438-20"
29 01082.0000 1 Sprayhead
30 01592.0000 1 Bushing, Snap 1.0" Dia..
NOTE: Items 31 thru 38 are for Model SDB & STFDB with rear drain)
31 00929.0001 1 Nut, Compression
32 02955.0000 1 Tube, Drain
33 12757.0000 1 Nut, Brass .625-18"
34 01514.0000 1 Lockwasher .625"
35 12756.0000 1 Fitting, Bulkhead
36 32359.0000 1 Ferrule, .375" OD
37 02956.0000` 1 Valve, Shut-off
38 00976.0000 1 Cap Nut .375" FLR
29252 081402

16
BUNN
®STRAINER/FLOW CONTROL STF,
STFA
P 1576
BUNN
90 psig max operating pressure
Strainer/Flow Control # 22300.0500
(Repl. Flow Washer #20526.0500)
(Repl. Screen #23721.0000)
.500 gpm FLOW
BUNN
90 psig max operating pressure
Strainer/Flow Control # 22300.0500
(Repl. Flow Washer #20526.0500)
(Repl. Screen #23721.0000)
.500 gpm FLOW
12
11
1
2
3
5
6
8
7
9 10
4
5
6
14
15
13
14
16
20
23
22
21
19
18
17
29252 022300

ITEM PART NO. QTY. DESCRIPTION
17
STRAINER/FLOW CONTROL
102652.0000 1 Tube, Fill Basin
202653.1000 1 Tube, Fill Basin To Solenoid (Includes Connector)
00402.0001 1 Connector .25" FLR x .125" MPT
301085.0002 1 Solenoid, 120V 1" dia. coil (Includes items 5 thru 8)
01327.0000 2 Screw #10-32 x .375"
01502.0000 2 Lockwasher #10
428005.0000 1 Solenoid, 240V (Includes items 5 and 6)
21180.0000 1 Solenoid, 200V (Includes items 5 and 6)
02329.0000 2 Screw, Locking #10-32 x .375"
528480.0000 1 Coil 120V
28020.0000 1 Coil 240V
21181.0000 1 Coil 200V
601111.0002 1 Solenoid Valve Repair Kit 120V
28021.0000 1 Solenoid Valve Repair Kit 240V
01111.0000 1 Solenoid Valve Repair Kit 200V
728479.0000 1 Base Kit (Includes O-ring)
01079.0000 1 Base 200V
828481.0000 1 Guide Kit 120V (Includes Washer and O-ring)
902654.1000 1 Tube, Solenoid To Bulkhead (Includes Connector)
00402.0001 1 Connector .25" FLR x .125" MPT
10 04623.0001 1 Bracket, Solenoid Mounting 120V
28422.0000 1 Bracket, Solenoid Mounting 240V
01311.0000 2 Screw, Truss Head #8-32 x .25"
11 02611.0000 1 Bracket, Component Mounting
01311.0000 2 Screw, Truss Head #8-32 x .25"
12 00614.0000 1 Bushing
13 00459.0000 1 Fitting, Bulkhead .25" FLR
01532.0000 1 Lockwasher, Internal Tooth .438"
00463.0000 1 Nut, Brass .438-20"
14 00935.0000 1 Cap, Brass .25" FLR (For shipping purposes only)
15 00310.0000 1 Tube, Bulkhead To Strainer
16 22300.0222 1 Strainer/Flow Control Assy (.222 GPM)(Includes items 17 thru 23)
17 01154.0000 1 Flow Control Outlet
18 01155.0000 1 Gasket, Flow Control
19 - - - - - - - - 1 Washer, Flow Control
20 20526.1222 1 Washer/Gasket Assy (Includes items 18 and 19)
21 - - - - - - - - 1 Body (Order item 16)
22 23721.0000 1 Screen
23 22249.0000 1 Cap, End
29252 022300

18
BUNN
®FAUCET AND TUBING STF,
STFA
P 1577
1
2
3
5
6
7
8
9
10
11
4
29252 022300

ITEM PART NO. QTY. DESCRIPTION
19
FAUCET AND TUBING
102659.0000 1 Tube, Tank To Faucet (Right or Left)
227574.0000 1 Washer, Faucet Seal
302850.0000 1 Nut, Faucet Jam .50-20" UNF
402596.1000 1 Faucet Assy (Includes items 5 thru 11)
502601.0000 1 Handle, Red
602858.0000 1 Pin
702854.0000 1 Nut, Bonnet
802595.0000 1 Spring
913054.0000 1 Stem
10 02766.0000 1 Cup
11 - - - - - - - - 1 Body (Order item 4)
12 02594.0000 - Faucet Stem W/Pin (Includes items 6 and 9)
13 28706.0000 - Faucet Repair Kit (Includes items 5, 6 and 8 thru 10)
29252 022300

20
BUNN
®ELECTRICAL AND OPERATING CONTROLS S
SA
P 1578
BUNN
OFF
HI
MODEL S MODEL SA MODEL SA (NTW)
SERVICE REPLACEMENT
1 2 3 2
4 6 16
7
5
8
9
14 15 13 10 11 12
29252 022300
