Table Of Contents
3
Auto Grading Trimmer
1. Introduction
Congratulations on your purchase of your Burchland Manufacturing Trimmer.
Carefully examine the trimmer upon receipt. Report any damage immediately to the freight carrier and
register any claim.
Read and understand this manual before using the trimmer and follow all of the safety instructions. Keep this
manual with the trimmer at all times.
Information provided in this manual was current as of the issue date. Burchland Manufacturing, Inc. reserves
the right to make design changes without further notice or liability.
This manual explains the operation and routine maintenance of the AGT Auto Grading Trimmer.
Information furnished in this manual does not include all of the details of design, production, or variations of
the equipment. It does not cover all the possible contingencies, which may arise during operation, setup, or
maintenance. Should special issues arise, or further information be desired, please contact your Burchland
Manufacturing dealer.
The text contained in this manual is for current production models. Some instructions and maintenance
procedures may not apply to your specic unit.
Equipment modications from original design and specications are strictly prohibited. Modications or
overloading may compromise safe operation of the trimmer, subjecting users to serious injury or death and
may void any remaining warranty.
Burchland Manufacturing reserves the right to change, improve, modify or expand features of this equipment
at any time. Specications, models, or equipment are subject to change without notice, and without incurring
any obligations to change, improve or expand features of previously delivered equipment. Because of the
variations in optional equipment and continued design improvement, certain information contained within
this manual may not apply.
This operators manual does not replace, nor does its use release the owner/operator from observing all
safety codes or operating limitations as well as any applicable federal, state, provincial or local regulations.
The trimmer is designed to be used by experienced operators, trained in the safe operation of a skidsteer
and trained in the hazards related to using the trimmer and the safe use of the trimmer for the intended
purpose.
Serious injury or death of the operator or bystanders may be caused if the trimmer is misused. Misuse may
also cause damage to the skidsteer carrying the trimmer, or the trimmer itself.
Introduction
4Auto Grading Trimmer
Safety
2. Safety
Before setting up, operating or servicing the AGT trimmer, you must read, understand and follow the
instructions and safety warnings in this manual. Your machine may not be equipped with some of the optional
equipment described in this manual.
If you have any safety concerns or questions that are not covered by this manual, please contact your
Burchland Manufacturing dealer.
The safety information in this manual is denoted by the safety alert symbol: ^This symbol means
ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!
The level of risk is indicated by the following signal words:
^DANGER
Indicates a hazardous condition that will result in serious injury or death if not performed
appropriately.
^WARNING
Indicates a hazardous condition that could result in serious injury or death if not performed
appropriately.
^CAUTION
Indicates a hazardous condition that could result in serious injury if not performed
appropriately.
NOTICE
Indicates a situation that could result in damage to the machine or other property.
The following hazards are possible during the operation of the trimmer. All operators, maintenance and
service personal, or any one working with or near the trimmer must be familiar with all hazards.
^WARNING
Do not operate this trimmer until you read and understand this manual.
^WARNING
Do not operate, work on or around trimmer while under the influence of alcohol, prescription
or nonprescription medication,or if feeling ill.
5
Auto Grading Trimmer
Safety
^WARNING
Entanglement hazard.
Do not wear loose fitting clothing.
Loose fitting clothing and long hair can become entangled in moving or rotating parts.
Keep all personnel clear of moving parts when engine is running or about to be started.
Long hair must be tied back or netted.
Keep clear of moving components.
Never operate machine with open or missing guards or shields.
^WARNING
Pressurized fluids can penetrate the skin.
Hydraulic hoses can fail from age, damage and exposure.
Use body and face protection while searching for leaks. A tiny, almost invisible leak can
penetrate the skin, thereby requiring immediate medical attention.
Use wood or cardboard to detect hydraulic leaks, never use your hands.
^WARNING
Crush hazard.
A raised trimmer can fall, resulting in death or serious injury.
Never enter the area under a raised trimmer.
^WARNING
Moving parts can crush and dismember.
Do not operate without guards and shields in place.
Disconnect and lockout power source before adjusting or servicing.
Do not operate this trimmer until you read and understand this manual.
6Auto Grading Trimmer
^WARNING
Wear personal protective equipment appropriate for the job.
^WARNING
Cancer and reproductive harm
For more information go to www.P65Warnings.ca.gov.
Carefully read all safety messages in this manual and on equipment safety signs. Keep safety signs in good
condition and replace missing or damaged safety signs.
New equipment components and repair parts must include the current safety decal.
Learn how to properly operate equipment.
Never operate or work around this equipment without proper instruction, while fatigued or under the inuence
of alcohol, prescription or nonprescription medication, or if feeling ill.
Keep your equipment in proper working condition. Know the regulations and laws that apply to you and
your industry. This manual is not to replace any regulations or laws. Additional information may be found at:
www.asae.org or www.osha.gov. If you do not understand any part of this manual, contact your Burchland
Manufacturing dealer.
2.1.1 Replace Safety Signs
Replace missing or damaged safety signs. Safety signs are identied in this manual. Replacement safety
signs are available from your Burchland Manufacturing dealer.
2.1.2 Do Not Allow Riders
Never lift or carry anyone on the trimmer. Never use the trimmer as a work platform. Never allow riders on
the trimmer.
2.1.3 Hazards From Modifying Equipment
Do not make any alterations to the trimmer. Altering the trimmer may cause unsafe conditions and may void
the manufacturer’s warranty. Always use Burchland Manufacturing replacement parts.
The following maintenance and service hazards are additional to those found while operating the trimmer. All
operators, maintenance and service personal, or any one working with or near the trimmer must be familiar
with these hazards. If you do not understand any part of this manual, contact your Burchland Manufacturing
dealer.
After performing inspections, service or maintenance, reinstall all guards and verify all safety devices are
functional.
Safety
7
Auto Grading Trimmer
Safety
Wear personal protective equipment appropriate for the job.
Always use Burchland Manufacturing replacement parts. Not using Burchland Manufacturing parts may
cause harm to personnel and may void the warranty.
2.2.1 Lockout/Tagout
^WARNING
Entanglement and crush hazard.
Keep all personnel clear of all moving components.
Verify all guards are in place.
Follow lockout/tagout procedure before performing service, inspections or maintenance.
Before performing service or maintenance:
• If trimmer is connected to skid steer:
1. Park on a rm and level surface.
2. Lower trimmer to ground.
3. Set parking brake.
4. Stop engine and remove key.
5. Place a Do Not Operate tag on control panel.
• If trimmer is not connected to skid steer:
• Verify trimmer is on a rm and level surface.
8Auto Grading Trimmer
Safety decals are located on the machine to identify both operational and maintenance hazards. These
safety decals are placed according to the hazard in that area of the machine. Read and understand each
of the safety decals and the hazard it references. These safety messages are additional information to the
safety content already described in this section of the operators manual.
All safety decals must be legible at all times. Keep them clean by using soap and water, avoid using harsh
chemicals or pressure washing. If the safety decal is no longer legible, replace it with a new one. Contact
your Burchland Manufacturing dealer for new decals. The part number of the decal is located on the decal
and on the images of the safety decals that follow.
D
DD
D
D
G
G
G
G
G
G
E
E
A
C
FB
Safety
9
Auto Grading Trimmer
Decal A - 11187
Decal B - 7353642
Decal C - 11190
Decal D - 12740
Decal E - 7105980
Decal F - 7137319 Decal G - 6815993
Safety
10 Auto Grading Trimmer
Components
3. Components
A. Hydraulic Hoses
B. Handrail
C. Lift Cylinders
D. Auger Cover
E. Front Safety Flap
F. Sensors Box
G. Tilt Lock Turnbuckle Chains
H. Walkway Platform
I. Auger Hydraulic Motor
J. Hydraulic Pressure Gauge
K. Case Drain Pressure Gauge
L. Receiver Plate
M. Lifting/Tiedown Points
ML
J
M
M
K
M
I
C
C
M
G
B
A
D
E
F
M
GH
11
Auto Grading Trimmer
Attach And Detach
4. Attach And Detach
1. Verify the mount plate and receiver plate are free of any dirt or debris and that the locking mechanism
pins rotate freely. Lubricate locking mechanism if necessary.
2. Tilt skid steer mount plate (A) forward.
3. Position mount plate into the upper lip (B) of the receiver plate.
B
C
C
A
4. Raise skid steer loader arms slightly while tilting mount plate back at the same time. The trimmer should
be raised and the mount plate (A) tilted far enough back to clear the ground.
^WARNING
Crush hazard.
If locking mechanism pins are not fully seated, the trimmer could fall off of the skid steer,
crushing you or bystanders.
Locking mechanism pins must be fully seated through the trimmer receiver plate.
5. Engage the locking mechanism pins. Verify pins are fully seated through the receiver plate.
6. Tilt trimmer back slightly and stop skid steer engine.
7. Connect the turnbuckle chains (C) to the skid steer boom, both sides.
To set the turnbuckles, park the skid steer on a at, concrete surface. Lower the boom all the way down.
Adjust the length of the turnbuckles and/or chains, so the trimmer is relatively at or parallel with the ground
when the chains are tight.
Make sure all operators are aware of the chains. The turnbuckle chains limit the bucket tilt cylinders from
drifting during operation. If the skid steer boom does not have mounting points, contact your Burchland
Manufacturing dealer for turnbuckle mounting locations.
12 Auto Grading Trimmer
Attach And Detach
NOTICE
Avoid trying to overpower the turnbuckle chains with the skid steer bucket tilt cylinders.
This could result in damage to the skid steer or trimmer.
Once the chains are tight the operator should not adjust the bucket tilt forward.
^WARNING
Pressurized fluids can penetrate the skin.
Hydraulic hoses can fail from age, damage and exposure.
Use body and face protection while searching for leaks. A tiny, almost invisible leak can
penetrate the skin, thereby requiring immediate medical attention.
Use wood or cardboard to detect hydraulic leaks, never use your hands.
8. Connect hydraulic hoses and electrical connector. Conrm hydraulic connections are secure by pulling
on the hoses.
9. The trimmer is equipped with three hoses. You must connect the pressure, return and case drain hoses
from trimmer to skid steer hydraulic couplers. Skid steer hoses must be the same size as the trimmer
hoses. Using smaller diameter hoses will decrease hydraulic ow. Maximum allowable case pressure is
100 psi. Case drain is required.
NOTICE
Always make sure to hook up the third, smaller case drain line. Damage will occur to the
drive motor if the case drain line is not used.
1. Lower trimmer on to a at level surface.
2. Tilt trimmer back slightly and disconnect turnbuckle chains from skid steer.
3. Return trimmer to a level position on the at surface.
4. Stop skid steer engine and relieve hydraulic pressure.
5. Disconnect hydraulic hoses and electrical connector.
6. Disengage locking mechanism pins.
7. Tilt skid steer mount plate forward and back skid steer away from the trimmer.
13
Auto Grading Trimmer
5. Operation
Thoroughly inspect the trimmer before each operation.
Verify all safety signs are in place and clearly visible.
Visually inspect the trimmer before each start up. Check for loose or missing parts and any damage that may
have occurred during moving or shipping.
Review all skid steer pre-start instructions and verify that all recommended steps and procedures have been
followed.
^WARNING
Prevent death or serious injury.
Keep trimmer close to the ground. Operation with a raised trimmer may result in skid steer
rollover.
1. Verify hydraulics to trimmer are disengaged.
2. Raise trimmer slightly o the ground.
3. Travel at a reasonable and safe speed.
^WARNING
Prevent death or serious injury.
Keep shields and guards in place at all times. Do not operate without shields and guards.
Keep bystanders away.
1. Attach trimmer to skidsteer.
NOTICE
Avoid trying to overpower the turnbuckle chains with the skid steer bucket tilt cylinders.
This could result in damage to the skid steer or trimmer.
Once the chains are tight the operator should not adjust the bucket tilt forward.
Operation
14 Auto Grading Trimmer
Operation
2. Setup auto grading system See auto grading system suppliers information.
3. Set skid steer engine speed to low idle and engage hydraulics to trimmer. Engage hydraulic high ow
function if applicable.
4. Slowly increase engine speed to high idle. Monitor pressure gauge (A) during startup and operation.
When rst starting the rotor, hydraulic pressure on gauge (A) will jump from zero to maximum as the
rotor speed increases. It can take a few seconds for the rotor to reach operational speed. Do not attempt
to use the trimmer before operational speed is reached. As operational speed is reached, pressure will
drop to 500 - 1000 psi (35 - 69 bar). Maximum performance is with hydraulic pressure between 2000
- 3000 psi (138- 207 bar). If pressure increases during operation or rotor slows down, decrease travel
speed until rotor speed increases and hydraulic pressure returns to normal.
Hydraulic cylinder pressure on gauge (B) is between 200 - 600 psi (14 - 41 bar).
AB
5. Rotor will continue to spin freely when hydraulic power is disengaged. Allow rotor to stop before setting
trimmer on the ground or a hard surface.
15
Auto Grading Trimmer
Operation
Corner bracket (A, B) is designed to contain dirt when cutting next to a previously graded surface.
Set the bracket at highest position (A) when motor side of trimmer is cutting an ungraded surface.
Set the bracket at lowest position (B) when motor side of trimmer is cutting a previously graded surface.
A
B
To adjust corner bracket, loosen bolts (C), move bracket to desired position, and tighten bolts (C).
C
16 Auto Grading Trimmer
Maintenance
6. Maintenance
^WARNING
Prevent death or serious injury.
Do not perform service or maintenance on the trimmer until lockout/tagout safety
precautions have been implemented.
Make sure to follow your company’s lockout/tagout procedures.
Grease bearings with general purpose grease every eight operating hours and immediately after every
washing.
Clean grease ttings with a rag. Connect a grease gun to each tting and pump grease into the ttings until
grease begins to appear around bearing seals. Rotor has one grease tting (A) on right hand side. Drum has
one grease tting (B) on left and right hand side.
A
B
17
Auto Grading Trimmer
Maintenance
Replace rotor teeth (A) as needed. A tool is available to help remove teeth from their housing. Contact your
Burchland Manufacturing dealer for more information and replacement teeth.
A
6.3.1 Adjust Drum Scraper
Scraper (A) should be 1/8 in. (3.2 mm) (B) from the drum (C). If adjustment is required, loosen mounting
hardware (D) on both sides of trimmer and adjust scraper as needed. Tighten mounting hardware.
B
C
A
D
18 Auto Grading Trimmer
Maintenance
6.3.2 Scraper Cleanout
Debris can buildup on top of scraper. To remove debris, remove top bolt (A) on both sides.
Rotate scraper assembly (B) down and remove debris.
Pivot scraper assembly back into position, and reinstall mounting hardware (A).
B
A
B
Grader blade (A) should be 3/8 in. (9.5 mm) (B) higher than the rotor teeth (C) at their lowest point.
If adjustment is required, loosen mounting hardware (D), and adjust grader blade by adding shims (E).
Contact your Burchland Manufacturing dealer for additional shims.
Tighten mounting hardware.
.375
B
AC
E
D
19
Auto Grading Trimmer
Maintenance
^WARNING
Prevent death or serious injury.
Grader blade assembly weight is approximately 170 lbs (77 kg).
Plan a safe handling procedure before removing and installing grader blade assembly.
1. Remove mounting hardware (A).
A
A
A
2. Pull grader blade assembly out from under trimmer.
3. Remove bolts (B), washers and nuts. Remove grader blade (C) from mounting bracket (D).
B
D
C
4. Install replacement grader blade (C) to mounting bracket (D), install bolts (B), nuts and washers. Contact
your Burchland Manufacturing dealer for replacement grader blade.
5. Position grader blade assembly under trimmer.
6. Raise grader blade assembly and reinstall mounting hardware (A).
20 Auto Grading Trimmer
Troubleshooting
7. Troubleshooting
Problem Possible Cause Solution
Rotor does not spin. Rotor jammed. Remove material from rotor.
Low hydraulic oil level. Check hydraulic oil level in skid
steer. Add if necessary.
Low hydraulic oil ow. Check ow control on skid steer.
See your dealer.
Low hydraulic pressure. Check valve open. See your
dealer.
Rotor rotates slow or sluggish. Low hydraulic oil level. Check oil level in skid steer. Add if
necessary.
Hydraulic oil lter plugged. Replace skid steer hydraulic oil
lter.
Relief valve not set properly. Set relief pressure to motor
specication.
Low hydraulic oil ow. Check ow control on skid steer.
See your dealer.
Excessive vibration. Rotor teeth worn or missing. Replace worn, broken or missing
rotor teeth.
Debris lodged in rotor. Remove debris.
Table of contents
