Ryobi RLT26C User manual

STRING TRIMMER
OPERATOR’S MANUAL (Original Instructions)
RLT26C
Important! It is essential that you read the instructions in this manual before assembling,
maintaining and operating this machine.
Subject to technical modifications.

1
English (Original Instructions)
SYMBOLS
Important: Some of the following symbols may be used on your tool. Please study them and learn their meaning.
Proper interpretation of these symbols will allow you to operate the tool better and safer.
NAME EXPLANATION
Safety Alert Symbol Indicates danger, warning or caution. It means attention! Your
safety is involved.
Read Your Operator’s
Manual
Your manual contains special messages to bring attention to
potential safety concerns as well as operating and servicing
information. Please read all the information carefully to ensure
satisfaction and safe use.
Wear eye, hearing and
head protection
Wear eye, hearing and head protection when operating this
equipment.
Keep bystanders away Beware of thrown or flying objects. Keep all bystanders at least
15 m away.
No blade Do not use blade(s) on the product.
RPM Decal Rotational direction and maximum speed of the shaft for the
cutting attachment.
Boots Wear non-slip safety footwear when using this equipment.
Gloves Wear non-slip, heavy-duty gloves.
No Smoking Do not smoke when mixing fuel or filling fuel tank.
Petrol Use unleaded gasoline intended for motor vehicle use with an
octane rating of 91 ([R+M]/2) or higher.
Oil Use synthetic 2-stroke oil for air cooled engines.
Mix Petrol and Oil Mix the fuel mix thoroughly and also each time before refuelling.
Switch
On/Off Switch
I = ON to Run
O = OFF to Stop
Conforms to all regulatory standards in the country in the EU
where the product is purchased.

2
English (Original Instructions)
NAME EXPLANATION
Guaranteed sound power level is 108 dB.
Run position
Set the choke lever to “FULL” choke position.
Set the choke lever to “HALF” choke position.
Set the ignition switch to the “I” (ON) position.
Press the primer bulb 10 times.
Pull the starter grip to start.
Squeeze the throttle lock and throttle trigger to run.
Waiting time 10 seconds
To stop the engine, move the ignition switch to the “O” stop
position .
Keep hands away from blades.
EurAsian Conformity Mark
The following signal words and meanings are intended to explain the levels of risk associated with this product.
SYMBOL SIGNAL MEANING
DANGER Indicates an imminently hazardous situation, which, if not avoided, will
result in death or serious injury.
WARNING Indicates a potentially hazardous situation, which, if not avoided, could
result in death or serious injury.
CAUTION Indicates a potentially hazardous situation, which, if not avoided, may result
in minor or moderate injury.
CAUTION (Without safety alert symbol) Indicates a situation that may result in property
damage.

3
English (Original Instructions)
ŶDo not operate this unit when you are tired, ill, or under
the influence of alcohol, drugs, or medication.
ŶDo not operate in poor lighting.
ŶKeep firm footing and balance. Do not overreach.
Overreaching can result in loss of balance or exposure
to hot surfaces.
ŶKeep all parts of your body away from any moving part.
ŶDo not touch area around the muffler or cylinder of the
trimmer, these parts get hot from operation.
ŶAlways stop the engine and remove the spark plug
wire before making any adjustments or repairs except
for carburetor adjustments.
ŶInspect the unit before each use for loose fasteners, fuel
leaks, etc. Replace any damaged parts before use.
ŶIt has been reported that vibrations from hand-held
tools may contribute to a condition called Raynaud’s
Syndrome in certain individuals. Symptoms may
include tingling, numbness and blanching of the fingers,
usually apparent upon exposure to cold.
Hereditary factors, exposure to cold and dampness,
diet, smoking and work practices are all thought to
contribute to the development of these symptoms.
It is presently unknown what, if any, vibrations or extent
of exposure may contribute to the condition. There are
measures that can be taken by the operator to possibly
reduce the effects of vibration:
a) Keep your body warm in cold weather. When
operating the unit wear gloves to keep the hands
and wrists warm. It is reported that cold weather
is a major factor contributing to Raynaud’s
Syndrome.
b) After each period of operation, exercise to increase
blood circulation.
c) Take frequent work breaks. Limit the amount of
exposure per day.
If you experience any of the symptoms of this
condition, immediately discontinue use and see your
physician about these symptoms.
ŶKeep the tool well maintained, fasteners tightened and
worn parts replaced.
ŶMix and store fuel in a container approved for fuel.
ŶMix fuel outdoors where there are no sparks or flames.
Wipe up any fuel spillage. Move 9 m away from
refueling site before starting engine.
ŶStop the engine and allow to cool before refueling or
storing the unit.
ŶAllow the engine to cool; empty the fuel tank and
secure the unit from moving before transporting in a
vehicle. Secure the unit during transport to prevent
damage or injury.
Thank you for buying a Ryobi trimmer.
Your new trimmer has been engineered and manu-
factured to Ryobi’s high standard for dependability, ease
of operation, and operator safety. Properly cared for, it will
give you years of rugged, trouble-free performance.
INTENDED USE
This product is only intended for use outdoors in a well
ventilated area.
The product is intended for cutting long grass, weed, and
similar vegetation at or about ground level. The cutting
plane should be approximately parallel to the ground
surface. The product should not be used to cut or trim
hedges, bushes or other vegetation where the cutting
plane is not parallel to the ground surface.
WARNING
To reduce the risk of injury, the user must read
and understand the operator’s manual.
WARNING
Do not attempt to operate this trimmer until you
have read thoroughly and understood completely
all instructions, safety rules etc contained in
this manual. Failure to comply may result in
DFFLGHQWVLQYROYLQJ¿UHHOHFWULFVKRFNRUVHULRXV
personal injury. Save operator’s manual and
review frequently for continuing safe operation,
and instructing others who may use this tool.
READ ALL INSTRUCTIONS.
GENERAL SAFETY RULES
ŶSome regions have regulations that restrict the use of
the product. Check with your local authority for advice.
ŶDo not allow children or untrained individuals to use
this unit.
ŶNever start or run the engine in a closed or poorly
ventilated area; breathing exhaust fumes can kill.
ŶClear the work area before each use. Remove all
objects such as rocks, broken glass, nails, wire,
or string which can be thrown or become entangled in
the string head.
ŶWear full eye and hearing protection while operating
this unit.
ŶWear heavy long pants, boots, and gloves. Do not
wear loose fitting clothing, short pants, jewellery of any
kind, or use with bare feet.
ŶSecure long hair so it is above shoulder level to
prevent entanglement in any moving parts.
ŶKeep all bystanders, children, and pets at least 15 m
away.

4
English (Original Instructions)
ŶComply with local regulations in the use of the product.
WARNING
Injuries may be caused, or aggravated, by
prolonged use of a tool. When using any tool
for prolonged periods, ensure you take regular
breaks.
SPECIFIC SAFETY RULES FOR TRIMMER USE
ŶReplace string head if cracked, chipped, or damaged
in anyway. Be sure the string head is properly installed
and securely fastened. Failure to do so can cause
serious injury.
ŶMake sure all guards, straps, deflectors and handles
are properly and securely attached.
ŶUse only the manufacturer's replacement line in the
cutting head. Do not use any other cutting attachment.
Failure to do so can result in serious personal injury.
ŶNever operate unit without the safety guard in place
and in good condition.
ŶMaintain a firm grip on both handles while trimming.
Keep string head below waist level. Never cut with
the string head located over 76 cm or more above the
ground.
WARNING
Inspection after dropping or other impacts:
Thoroughly inspect the product and identify any
affections or damage with it. Any part that is
damaged should be properly repaired or replaced
by an authorized service centre
RESIDUAL RISKS
Even when the machine is used as prescribed, it is still
impossible to completely eliminate certain residual risk
factors. The following hazards may arise in use and
the operator should pay special attention to avoid the
following:
ŶInjury caused by vibration. Hold the tool by designated
handles and restrict working time and exposure.
ŶExposure to noise can cause hearing injury. Wear ear
protection and limit exposure.
ŶEye injury due to flying debris. Wear eye protection
at all times.
SPECIFICATION
Weight
- Without fuel and cutting attachment 4.4 kg
- Without fuel with string head 4.6 kg
Fuel tank volume 250 cm3or
(0.25L)
Cutting swath 432 mm
Engine displacement 26 cm3/ cc
Line diameter 2.4 mm
Maximum engine performance (in
accordance with ISO 8893) 0.65 kW
Maximum rotational frequency of the
spindle 12,000 min-1
Engine speed (rotational frequency) at
recommended max. spindle rotational
frequency
12,000 min-1
Engine speed (rotational frequency) at
idle
2,800-3,800
min-1
Fuel consumption ( in accordance with
ISO
8893) at max. engine performance
0.33 kg/h or
(0.45 L/h)
6SHFL¿F IXHO FRQVXPSWLRQ LQ
accordance with ISO 8893) at max.
engine performance
508 g/kW.h
or (0.7 L/
kW.h)
Vibration (in accordance with ISO 22867):
Front handle
- Idling 4.4 m/s2
- Racing 14.0 m/s2
- Equivalent vibration total value 10.4 m/s2
Rear handle
- Idling 5.7 m/s2
- Racing 8.7 m/s2
- Equivalent vibration total value 7.4 m/s2
Uncertainty K 1.5 m/s2
Noise emission (in accordance with ISO 22868)
A-weighted emission sound pressure
level at the operator position
- Idling 72.5 dB (A)
- Racing 99.0 dB (A)
- Equivalent A-weight emission sound
pressure level 96.0 dB (A)
A-weighted sound power level
- Idling 85.4 dB (A)

5
English (Original Instructions)
- Racing 106.3 dB (A)
- Equivalent A-weight sound power
level 106.3 dB (A)
Uncertainty K 2.5 dB
DESCRIPTION
3OHDVHUHIHUWRWKH¿JXUHVKHHW
1. Primer Bulb
2. Choke Lever
3. Fuel Cap
4. Starter Grip
5. Throttle Lock
6. On / Off Switch
7. Throttle Trigger
8. Rear Handle
9. Front handle
10. Shaft
11. Deflector
12. String Head
13. Cutting Line
14. Idle Speed Screw
15. Spool retainer
16. Bolt
17. Wing nuts
18. Flat washer
19. Wrench (not provided)
20. Paper tube
21. Hex nut
ASSEMBLY
Please refer to Fig. 2.
UNPACKING
This product requires assembly.
1. Carefully remove the tool and any accessories from
the box. Make sure that all items listed in the packing
list are included.
2. Inspect the tool carefully to make sure no breakage or
damage occurred during shipping.
3. Do not discard the packing material until you have
carefully inspected and satisfactorily operated the
tool.
4. If any parts are damaged or missing, do not operate
this tool until the parts are replaced. Failure to heed
this warning could result in serious personal injury.
PACKING LIST
ŶTrimmer
ŶFront handle assembly
ŶSafety guard assembly
ŶCutting head assembly
ŶOperator’s manual
WARNING
Do not attempt to modify this product or create
accessories not recommended for use with this
SURGXFW $Q\ VXFK DOWHUDWLRQ RU PRGL¿FDWLRQ LV
misuse and could result in a hazardous condition
leading to possible serious personal injury.
WARNING
To prevent accidental starting that could cause
serious personal injury, always disconnect the
engine spark plug wire from the spark plug when
assembling parts.
WARNING
Never attach or adjust any attachment while
power head is running. Failure to stop the engine
may cause serious personal injury.
WARNING
Be certain the knob is fully tightened before
operating equipment; check it periodically for
tightness during use to avoid serious injury.
ATTACHING THE FRONT HANDLE (FIG. 2A)
1. Remove the bolt, flat washer, and wing nut from the
front handle.
2. Mount the front handle in front of the foam part.
3. Replace the bolt, flat washer, and wing nut. Tighten
the wing nut.
ATTACHING THE DEFLECTOR (FIG. 2B)
1. Loosen the hex nut.
2. Insert the shaft into the deflector.
3. Tighten the hex nut.
INSTALLING THE STRING HEAD (FIG. 2C)
1. Remove the paper tube.
2. Place the middle of the line under the hook/notch
inside the spool.
3. Feed the ends of the line through the eyelets on the
side of the Pro-cut I fixed line head.
4. Pull the line outwards so it is tight and even on both
sides of the spool.
5. Install Pro-cut™ head assembly on drive shaft.
Secure with spool retainer.

6
English (Original Instructions)
OPERATION
FUEL AND REFUELING
HANDLING THE FUEL SAFELY
ŶAlways handle fuel with care, it is highly flammable.
ŶAlways refuel outdoors where there are no sparks and
flames. Do not inhale fuel vapors.
ŶDo not let petrol or oil come in contact with your skin.
ŶKeep petrol and oil away from the eyes. If petrol
or oil comes in contact with the eyes, wash them
immediately with clean water. If irritation is still present,
see a doctor immediately.
ŶClean up spilled petrol immediately.
MIXING THE FUEL (FIG. 3)
ŶThis product is powered by a 2-stroke engine and
requires pre-mixing petrol and 2-stroke oil. Pre-mix
unleaded petrol and 2-stroke engine oil in a clean
container approved for petrol.
ŶThis engine is certified to operate on unleaded petrol
intended for automotive use with an octane rating
of 91 ([R + M] / 2) or higher.
ŶDo not use any type of pre-mixed petrol / oil from fuel
service stations, this includes the pre-mixed petrol / oil
intended for use in mopeds, motorcycles, etc.
ŶUse synthetic 2-stroke oil only. Do not use automotive
oil or 2-stroke outboard oil.
ŶMix 2% synthetic 2-stroke oil into the petrol. This is
a 50:1 ratio.
ŶMix the fuel thoroughly and also each time before
fueling.
ŶMix in small quantities. Do not mix quantities larger
than usable in a 30 day period. Synthetic 2-stroke oil
containing a fuel stabilizer is recommended.
1 Litre + 20 ml =
2 Litres + 40 ml =
3 Litres + 60 ml =
4 Litres + 80 ml =
5 Litres + 100 ml =
=50:1 (2%)
FILLING THE TANK
ŶClean surface around fuel cap to prevent
contamination.
ŶLoosen fuel cap slowly to release pressure and to
keep fuel from escaping around the cap.
ŶCarefully pour fuel mixture into the tank. Avoid spillage.
ŶPrior to replacing the fuel cap, clean and inspect
the gasket.
ŶImmediately replace fuel cap and hand tighten.
Wipe up any fuel spillage. Move 9 m away from
refueling site before starting engine.
Note: It is normal for smoke to be emitted from a new
engine during and after first use.
WARNING
Always shut off engine before fueling. Never add
fuel to a machine with a running or hot engine.
Move at least 9 m from refueling site before
starting engine. Do not smoke!
STARTING AND STOPPING (FIG. 4)
WARNING
Never start or run the engine inside a closed or
poorly ventilated area; breathing exhaust fumes
can kill.
NOTE: Be sure to return the stop switch to the "I" (RUN)
position before trying to start unit.
To start a cold engine:
1. Press the primer bulb 10 times.
NOTE: After the 7th press, the fuel should be visible
in the primer bulb. If not, continue pressing until the
fuel is visible.
2. Set the choke lever to choke position.
3. Keeping the throttle trigger squeezed completely and
pull the starter grip until the engine attempts to start.
Do not pull the starter grip more than 4 times.
4. Set the choke lever to choke position.
5. Pull the starter grip until the engine starts. Do not pull
the starter grip more than 6 times.
NOTE: If the engine does not start, repeat the
procedure from step 2.
6. Allow the engine to run for 10 seconds, then set the
choke lever to position.
To start a warm engine:
1. Press the primer bulb 10 times.
2. Set the choke lever to position.
3. Squeeze the throttle trigger completely and pull the
starter grip until the engine starts.

7
English (Original Instructions)
To stop the engine:
Toggle the switch to the “o” (off) position.
OPERATING THE TRIMMER (FIG. 5)
Hold the trimmer with the right hand on the rear handle
DQG WKH OHIW KDQG RQ WKH IURQW KDQGOH .HHS D ¿UP JULS
with both hands while in operation. Trimmer should be
held at a comfortable position with the rear handle about
hip height.
Always operate trimmer at full throttle. Cut tall grass
from the top down. This will prevent grass from wrapping
around the shaft housing and string head which may cause
damage from overheating. If grass becomes wrapped
around the string head, stop the engine, disconnect the
spark plug wire, and remove the grass. Prolonged cutting
at partial throttle will result in oil dripping from the silencer.
CUTTING TIPS (FIG. 6)
When cutting make sure the cutter head is at a slight angle
as shown while still approximately parallel to the ground
surface. In tall grass cut from the top down to ensure the
moving parts do not get tangled with the long grass.
Move the head in steady strokes from right to left as you work
through the grass.
MAINTENANCE
WARNING
Use only original manufacturer's replacement
parts, accessories and attachments. Failure to do
so can cause possible injury, poor perfor-mance
and may void your warranty.
WARNING
The cutting attachment must not work in idle
mode. If this requirement is not satisfied, the
clutch has to be adjusted or the machine needs
an urgent maintenance by a qualified technician.
ŶYou may make adjustments and repairs described
here. For other repairs, have the trimmer serviced by
an authorised service agent.
ŶConsequences of improper maintenance may
include excess carbon deposits resulting in loss of
performance and discharge of black oily residue
dripping from the silencer.
ŶMake sure all guards, straps, deflectors and handles
are properly and securely attached to avoid the risk of
personal injury.
LINE REPLACEMENT (FIG. 9)
ŶEnsure the unit is in the off position
ŶUnlock the spool retainer as shown and remove the
spool.
ŶTake one 500 mm length of 2.4 mm thick monofilament
precut line.
ŶPlace the middle of the line under the hook/notch
inside the spool.
ŶFeed the ends of the line through the eyelets on the
side of the Pro-cut I fixed line head.
ŶPull the line outwards so it is tight and even on both
sides of the spool.
ŶInstall Pro-cut™ head assembly on drive shaft. Secure
with spool retainer.
CLEANING THE EXHAUST PORT AND SILENCER
Depending on the type of fuel used, the type and amount
of oil used, and/or your operating conditions, the exhaust
port and silencer may become blocked with carbon
deposits. If you notice a power loss with your petrol
SRZHUHG WRRO D TXDOL¿HG VHUYLFH WHFKQLFLDQ ZLOO QHHG WR
remove these deposits to restore performance.
CLEANING THE AIR FILTER (FIG. 7)
)RU SURSHU SHUIRUPDQFH DQG ORQJ OLIH NHHS WKH DLU ¿OWHU
clean.
ŶEnsure the unit is in the off position.
ŶRemove the air filter cover.
ŶRemove the air filter and clean it with warm soapy
water.
ŶRinse, and let the air filter dry completely.
ŶWork two drops of lubricant into the air filter.
ŶReplace the air filter (fits only one way).
ŶReplace the air filter cover.
NOTE:7KHDLU¿OWHU VKRXOG EHUHSODFHGDQQXDOO\IRUWKH
best performance.
FUEL CAP
WARNING
$ OHDNLQJ IXHO FDS LV D ¿UH KD]DUG DQG PXVW EH
replaced immediately.
7KH IXHO FDS FRQWDLQV D QRQVHUYLFH DEOH ¿OWHU DQG D
FKHFNYDOYH$FORJJHGIXHO¿OWHUZLOOFDXVH SRRU HQJLQH
performance. If performance improves when the fuel cap
LVORRVHQHGFKHFNYDOYHPD\EHIDXOW\RU¿OWHUFORJJHG
Replace fuel cap if required.
SPARK PLUG REPLACEMENT (FIG. 8)
This engine uses a Champion RCJ-6Y or equivalent
spark plug with 0.63 mm electrode gap. Use an exact
replacement and replace annually.

8
English (Original Instructions)
STORAGE (1 MONTH OR LONGER)
ŶDrain all fuel from tank into a container approved for
fuel. Run engine until it stops.
ŶClean all foreign material from the trimmer. Store it in
a well-ventilated place that is inaccessible to children.
Keep away from corrosive agents such as garden
chemicals and de-icing salts.
ŶAbide by all ISO and local regulations for the safe
storage and handling of fuel. Excess fuel should be
used up in other 2-stroke engine powered equipment.

9
English (Original Instructions)
TROUBLESHOOTING
IF THESE SOLUTIONS DO NOT SOLVE THE PROBLEM, CONTACT YOUR AUTHORISED SERVICE DEALER.
PROBLEM POSSIBLE CAUSE SOLUTION
Engine will not start. Power switch is off. Make sure Switch is in the ON or "I" position
No spark. The spark plug may be damaged, remove it and check
for dirt and cracks. Replace with a new spark plug.
No fuel.
Push primer bulb until bulb is full of fuel. If bulb does
QRW¿OOSULPDU\IXHOGHOLYHU\V\VWHPLVEORFNHG&RQWDFW
D VHUYLFLQJ GHDOHU ,I SULPHU EXOE ¿OOV HQJLQH PD\ EH
ÀRRGHGSURFHHGWRQH[WLWHP
(QJLQHLVÀRRGHG
Remove spark plug, turn unit so spark plug hole is
aimed at the ground. Set start lever to “ ” position
and pull starter cord 10 to 15 times. This will clear
excess fuel from engine. Remove any fuel which
splashed on the product. Clean and reinstall spark
plug. Clean up any spilled fuel and move at least 9m
away before restarting. Pull starter three times with
with start lever at “ ”. If engine does not start, set
start lever to “ ” position and repeat normal starting
procedure. If engine still fails to start, repeat procedure
with a new spark plug.
Starter rope is harder to pull
now than when it was new. Contact a servicing dealer.
Engine starts but will
not idle long enough to
engage throttle
Temperature can effect engine
idle time and rpm.
Flip start lever to RUN “ ” position and pull starter
until engine starts.
Engine does not stop
when switch is turned
off
Electrical connection is loose/
unplugged
Set the start lever to CHOKE “ ” to stop the engine.
Immediately stop using the product. Check electrical
connection on the bottom of the trimmer and make
sure it is properly connected. Contact servicing dealer
if the problem persists.
Engine starts but will
not accelerate.
Engine requires approximately
three minutes to warm up.
Allow engine to completely warm up. If engine does
not accelerate after three minutes, contact a servicing
dealer.
Engine starts but will
only run at high speed
at half choke.
Carburetor requires
adjustment. Contact a servicing dealer.
Engine does not reach
full speed and emits
excessive smoke.
1. Check oil fuel mixture.
2. Air filter is dirty.
3. Spark arrestor screen is
dirty.
1. Use fresh fuel and the correct 2-stroke oil mix.
2. Clean air filter. Refer to Cleaning the Air Filter
earlier in this manual.
3. Contact a servicing dealer.
Engine starts, runs,
and accelerates but will
not idle.
Idle speed screw on
carburetor requires
adjustment
Contact servicing dealer if the problem persists.

10
English (Original Instructions)
Grass wraps round
shaft housing and string
head.
1. Cutting tall grass at ground
level.
2. Operating trimmer at part
throttle.
1. Cut tall grass from the top down.
2. Operate trimmer at full throttle.
Oil drips from silencer.
1. Operating trimmer at part
throttle.
2. Check oil/fuel mixture.
3. Air filter dirty.
1. Operate trimmer at full throttle.
2. Use fresh fuel and the correct synthetic 2-stroke oil
mix.
3. Clean per instruction in Maintenance Section.
20141126v1

GUARANTEE
In addition to any statutory rights resulting from the purchase, this product is covered by a guarantee as stated below.
1. The guarantee period is 24 months for consumers and commences on the date when the product was purchased.
This date has to be documented by an invoice or other proof of purchase. The product is designed and dedicated to
consumer and private use only. So there is no guarantee provided in case of professional or commercial use.
2. There is, in some cases (i.e. promotion, range of tools), a possibility to extend the warranty period over the period
described above using the registration on the www.ryobitools.eu website. The eligibility of the tool is clearly displayed
in stores and/or on packaging. The end user needs to register his/her newly-acquired tools online within 8 days from
the date of purchase. The end user may register for the extended warranty in his country of residence if listed on
the online registration form where this option is valid. Furthermore, end users must give their consent to the storage
of the data which are required to enter online and they have to accept the terms and conditions. The registration
confirmation receipt, which is sent out by e-mail, and the original invoice showing the date of purchase will serve as
proof of the extended warranty. Your statutory rights remain unaffected.
3. The guarantee covers all defects of the product during the warranty period due to defaults in workmanship or material
at the purchase date. The guarantee is limited to repair and/or replacement and does not include any other obligations
including but not limited to incidental or consequential damages. The warranty is not valid if the product has been
misused, used contrary to the instruction manual, or being incorrectly connected. This guarantee does not apply to:
– any damage to the product that is the result of improper maintenance
– any product that has been altered or modified
– any product where original identification (trade mark, serial number) markings have been defaced, altered or
removed
– any damage caused by non-observance of the instruction manual
– any non CE product
– any product which has been attempted to be repaired by an non-qualified professional or without prior
authorization by Techtronic Industries
– any product connected to improper power supply (amps, voltage, frequency)
– any product used with inappropriate fuel mixture (fuel, oil, percentage of oil)
– any damage caused by external influences (chemical, physical, shocks) or foreign substances
– normal wear and tear of spare parts
– inappropriate use, overloading of the tool
– use of non-approved accessories or parts
– carburettor after 6 months, carburettor adjustments after 6 months
– components (parts and accessories) subject to natural wear and tear, including but not limited to bump knobs,
drive belts, clutch, blades of hedge trimmers or lawn mowers, harness, cable throttle, carbon brushes, power
cord, tines, felt washers, hitch pins, blower fans, blower and vacuum tubes, vacuum bag and straps, guide bars,
saw chains, hoses, connector fittings, spray nozzles, wheels, spray wands, inner reels, outer spools, cutting lines,
spark plugs, air filters, gas filters, mulching blades, etc.
4. For servicing, the product must be sent or presented to a RYOBI authorized service station listed for each country
in the following list of service station addresses. In some countries your local RYOBI dealer undertakes to send the
product to the RYOBI service organisation. When sending a product to a RYOBI service station, the product should
be safely packed without any dangerous contents such as petrol, marked with sender’s address and accompanied
by a short description of the fault.
5. A repair/replacement under this guarantee is free of charge. It does not constitute an extension or a new start of the
guarantee period. Exchanged parts or tools become our property. In some countries delivery charges or postage will
have to be paid by the sender.
6. This guarantee is valid in the European Community, Switzerland, Iceland, Norway, Liechtenstein, Turkey and Russia.
Outside these areas, please contact your authorized RYOBI dealer to determine if another warranty applies.

AUTHORISED SERVICE CENTRES
ACD PLANT LTD
145 Southbank Road
Coundon
Coventry, West Midlands
CV6 1FG
Phone: [phone]
Email: [email protected]
Web: www.acdplant.co.uk
CBS Power Tools Limited
Unit 4, V P Square
Storeys Bar Rd, Fengate
Peterborough, Cambridgeshire
PE1 5YS
Phone: [phone]
Email: [email protected]
Web: www.cbspowertools.com
C D Powertools
76 Old Road
Churwell Morley, Leeds
LS27 7TH
Phone: [phone]
Email: [email protected]
Web : www.cdpowertools.co.uk
C J Sinclair Limited
44 Victoria Road
St Peters
Broadstairs, Kent
CT10 2UG
Phone: [phone]
Email: [email protected]
Web: www.cjsinclairltd.co.uk
Powertech Ind Ltd
Unit 2C, Ellison Road
Norwood Ind, Killamarsh
Sheffield, South Yorkshire
S21 2JG
Phone: [phone]
Email: [email protected]
Web: www.powertech-industrial.co.uk
RYCKO Technical Services LTD
104 Green Lane
St Albans, Herts
AL3 6EX
Phone: [phone]
Email: [email protected]
Web: www.ryckotechnical.com
ToolTech Industrial Equipment
227 E Dunhill Road, Macosquin
Coleraine, Co Londonderry
BT514LQ
Phone: [phone]
Email: [email protected]
For an updated list of authorised service centres, visit http://uk.ryobitools.eu/header/service-and-support/service-agents.

DECLARATION OF CONFORMITY
Techtronic Industries GmbH
Max-Eyth-Straße 10, 71364 Winnenden, Germany
Herewith we declare that the product
String trimmer
Brand: Ryobi
Model number: RLT26C
Serial number range: 44438201000001 - 44438201999999
is in conformity with the following European Directives and harmonised standards
2006/42/EC, 2004/108/EC, 2000/14/EC, 2005/88/EC, 97/68/EC, 2002/88/EC, 2004/26/EC, 2010/26/EU
And furthermore, we declare that the following (parts/clauses of) European harmonised standards have been used
EN ISO 11806-1:2011, EN ISO 14982:2009, EN ISO 3744:2010
Measured sound power level: 106.1 dB(A)
Guaranteed sound power level: 108 dB(A)
Conformity assessment method to Annex V Directive 2000/14/EC amended by 2005/88/EC.
Floyd Jeffrey Nesom (BSME)
Senior Director of Engineering
Winnenden, Dec. 10, 2014
Authorised to compile the technical file:
Alexander Krug, Managing Director
Techtronic Industries GmbH
Max-Eyth-Straße 10, 71364 Winnenden, Germany

960499005-01
