Bush b-3363G User manual

Instruction manual
b-3363G Home Theatre

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in theTroubleshooting section of these instructions,
You’ll soon be enjoying your new Home Theatre.
It all begins here, with your instructions. Don’t worry,
there’s nothing too technical coming up. Just simple,
step-by-step guidance to get you up and running
quickly. Sound good? Then let’s get started.
Help and Guidance
We’re here to help you get the most from your soundbar. Should you require any
guidance, a simple solution can often be found online at:
www.argos-support.co.uk
If you still require further assistance, call one of our experts on 0345 604 0105.

3
or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 604 0105.
Contents
Other information
Wall mounting the soundbar 16
Technical specification 17
Care & maintenance 17
Product support
Troubleshooting 19
Help and assistance 20
Disposal 21
Guarantee 22
4
5
Safety information
Safety information 6
Getting to know your Home Theatre
Ready? Let’s begin 7
Accessories 7
Control panel and remote control 8
Making the connections 10
Connecting the sub woofer 11
Remote control (before use) 11
Installing the remote battery 11
Using your Soundbar
Using the stereoRCA inputs 14
Using the optical input 14
Using the line in 14
Pairing a bluetooth device 14
Controlling a paired device 14
Bluetooth notes 14
1
2
3

1Safety information

Safety information
Important - Please read these instructions fully before
installing or operating
Safety information 5
If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in theTroubleshooting section of these instructions,
Power source
•This symbol means that this unit is double
insulated. An earth connection is not
required.
•The appliance must be connected to
a 100-240 volt 50/60Hz AC supply by
means of a three pin socket.
•Unplug this apparatus during lightning
storms or when unused for long periods of
time - to prevent damage to this product.
•Opening or removing covers may expose
you to dangerous voltages or other
hazards.
•To prevent risk of fire or electric shock,
avoid overloading wall outlets, extension
cords, or integral convenience receptacles.
•Use suitable power sources - Plug the
product into a suitable power source, as
described in the operating instructions or
as marked on the product.
•The supply voltage should be the
same as that indicated in the technical
specifications and the appliance rating
plate.
•If the socket outlets in your home are not
suitable for the plug supplied with this
unit check with a qualified electrician for
replacement.
•In order to disconnect the apparatus from
the mains completely, switch o et
and remove the mains plug completely.
•Do not bend, stretch or pull the supply
cable in order to avoid electric shock.
•When installed, the power socket must be
within easy reach.
•Do not install the unit in a confined space.
Allow adequate ventilation to prevent heat
build-up.
•For indoor use only.
Heat build up
•During use the unit will heat up, this is not a
malfunction. If the unit is used continuously at
high volume levels, the unit temperature will
rise considerably. Do not touch the unit to avoid
potential burns.
Colour irregularity on TV screen
Colour irregularities may be seen on certain types of
TV.
•If such an irregularity is seen turn o V, then
turn on again after 15 to 30 minutes.
•If the colour irregularity is still seen place the
soundbar unit further away from the TV.
Moisture and water
•Do not use this apparatus near water or moisture.
•Do not use this product near a bathtub, washbowl,
kitchen sink, and laundry tub, in a wet basement,
near a swimming pool, or anywhere else that water
or moisture is present.
Heat sources and flames
•Batteries shall not be exposed to excessive
heat such as sun, fire or the like
•To prevent risk of fire or electric shock,
avoid overloading wall outlets, extension
cords, or integral convenience receptacles.
Servicing and repairs
•Refer all servicing to qualified service personnel
•Servicing is required when the apparatus has been
damaged in any way: such as liquid has been
spilled or objects have fallen into the apparatus; the
apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.

Getting to know your Home Theatre2

Getting to know your Home Theatre 7
If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in theTroubleshooting section of these instructions,
Getting to know your Home Theatre
You’ll be up and running in no time
Ready? Let’s begin...
Please read these instructions carefully. They contain
important information which will help you get the
best from your soundbar and ensure safe and correct
installation and operation.
If you require any further assistance, our technical
experts are happy to help. For full details, refer to
the product support section at the end of these
instructions.
Accessories
1. A soundbar
2. A external subwoofer
3. Remote control
4. CR2032 battery
5. RCA audio cable
6. Digital optical audio cable
7. 3.5mm audio cable
8. Mains adapter
9. Instruction manual
Soundbar
RCA audio cable
Subwoofer Remote control
Digital optical cable 3.5mm audio cable
CR2032 battery
Mains power adapter

Getting to know your Home Theatre
8
or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 604 0105.
Getting to know your Home Theatre
You’ll be up and running in no time
1. Stereo RCA Audio inputs
2. OPTICAL input
3. DC Power input
4. Subwoofer Output
5. Power and Source button: Press and hold 2 seconds to
Aux in, Line in or Optical in.
6. Volume + and - : Press to adjust the volume up or
down.
7. Pair: Press to begin pairing with an external Bluetooth
device.
8. 3.5mm LINE input
5
6
7
8
1 2 3 4

Getting to know your Home Theatre
You’ll be up and running in no time
Getting to know your Home Theatre 9
If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in theTroubleshooting section of these instructions,
Mute: Press to mute the volume
Power: Press to switch the unit on
Skip: In Bluetooth mode, press to
skip forward or back onetrack
Play/Pause: In Bluetooth mode,
press to play or pause a track
Pair: Press to switch to pairing
mode
Source: Press to switch between
Optical, Line In, AUX in, or
Bluetooth mode
Movie: Press to switch to the EQ
optimized for movie sound
Bass+/-: Press to adjust the bass
up or down
Volume+/-: Press to adjust the volume
up or down
Voice: Press to switch to the EQ
optimized for dialogue
Music: Press to switch to the EQ
optimized for music

10 Getting to know your Home Theatre
or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 604 0105.
Getting to know your Home Theatre
You’ll be up and running in no time
Making the connections
Follow the below connection guide to connect the soundbar to a TV with or without a digital output, a Bluray/
DVD player or an audio source such as an MP3 player.
Only one digital connection to a TV is required. Use the optical connection .
DO NOT power on the mains until all other connections are made.
aux audio output
Digital optical
audio output
MP3 player, Smart
phone or other audio
equipment
TV with aux output
or optical output
TV (non-digital connection)
DVD, Bluray player with
aux or optical output
3.5mm audio socket (such as
earphone output)
Mains power connection
DO NOT power on the mains until
all other connections are made
DC IN
24V 1.5A

Getting to know your Home Theatre
You’ll be up and running in no time
Getting to know your Home Theatre 11
If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in theTroubleshooting section of these instructions,
Connecting the sub woofer
Follow the below instructions to connect the wired
subwoofer to the soundbar.
1. Use the RCA audio cable from the subwoofer
to connect to the SUB OUT output on the
soundbar.
2. When audio is played through any source,
the speaker will automatically use the
connected subwoofer.
Remote control (before use)
Before use, pull the tab out from the b
1 2
3
12
3
ottom of the
remote control. This allows the terminals contact with
the pre-installed battery.
Installing the remote battery
As the battery becomes exhausted the operating
distance will shorten. When the remote no longer
operates the unit, replace the battery with a new
CR2032 lithium battery.
•Dispose of used batteries with regard to the
recycling regulations in your area.
•Do NOT short circuit batteries or throw them into
water, the general rubbish or in a fire. Weak batteries
can leak and damage the remote control. Replace
them in good time!
•Keep coin-sized button batteries out of sight and
out of the reach of children. Coin lithium batteries
can cause serious injury when swallowed.

Using your Home Theatre3

Using your Home Theatre
Let’s get started
Using your Home Theatre 13
or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 604 0105.
USING THE STEREO RCA INPUTS
When connecting two products using an RCA cable,
matches the colored ports with the same colored
connection. Before use, disconnects any cable
connected to the Line in.
1. Connect the RCA Cable to the AUX IN stereo
inputs located on the back of the unit, and to the
audio outputs on the television.
2. Press and hold 2 seconds the POWER / SOURCE
button on side panel or POWER button directly
on the remote control to switch on the unit.
3. Press the SOURCE button on your remote control
repeatedly to enter AUX mode or one touch the
POWER/SOURCE button on the unit repeatedly
to enter AUX mode, indicated by a white light.
4. Audio played through the television will now be
heard through the speakers.
Using the Optical Input
You will need: An audio source
with an Optical Audio Output and
a Digital Optical Audio cable
(included)
1. Connect the Digital Optical Audio cable to the
optical output on the audio source and to the
OPTICAL IN on the speaker bar.
2. Press and hold 2 seconds the POWER/SOURCE
button on side panel or POWER button directly
on the remote control to switch on the unit..
3. Press the SOURCE button on your remote control
repeatedly to switch to Optical Mode or one touch
POWER/SOURCE button on main unit repeatedly
to select the Optical mode. The mode indicator
LED will turn orange.
1. Plug one end of a 3.5mm audio input cable
(included) into the LINE IN on the unit. Before
use, disconnect and cables connected to the
Stereo RCA Inputs.
2. Plug the other end of the cable into the audio
output/headphone output on an MP3 player
or other audio source.
3. Press and hold 2 seconds the POWER/SOURCE
button on side panel or POWER button directly
on the remote control to switch on the unit.
4. Press the SOURCE button on your remote
control repeatedly to enter LINE in mode or one
touch the POWER/SOURCE button on the unit
repeatedly to enter Line in mode.
The mode indicator will turn green.
5. Audio played through the connected device will
now be heard through the speakers.
Using the LINE in
4. Using the native controls on your connected
device, make sure the audio settings are set to
PCM or Optical Audio and are turned On.
5. Audio from the connected audio source will now
be played through the speakers.

Using your Home Theatre
Let’s get started
Using your Home Theatre
14
If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in theTroubleshooting section of these instructions,
Pairing a bluetooth device
Before you can use the soundbar with your phone or
other bluetooth capable device you will need to pair
the device to the soundbar.
Pairing a Bluetooth Device for the First Time
1. Press and hold 2 seconds the POWER/SOURCE
button on the unit or the POWER button on the
remote control to switch on the unit.
2. Select and press the SOURCE button directly on
the remote control to enter Bluetooth mode or
press the POWER/SOURCE button repeatedly to
enter Bluetooth mode, indicated by a blue light.
3. Press the PAIR button on the remote control or
the unit directly. The pairing indicator will flash
quickly. When pairing, remain within 3 feet of
the unit.
4. Using the native controls on your Bluetooth
device, select the “b-3363G” in your Bluetooth
settings to pair.
5. When successfully paired and connected, a beep
will issue from the unit and the Pairing Indicator
will display a solid blue light. After initial pairing,
the unit will stay paired unless unpaired manually
by the user, or until it is erased due to a reset of
the device.
If your device should become unpaired or you
find it is unable to connect, repeat the above
steps.
Controlling a paired device
Once connected you can either use the controls on
the audio device to begin playback, skip tracks etc.
Or you can use the control buttons on the remote.
1. The PAIR button on the main unit (3) or on
the remote when pressed will begin playback
of the selected track on the audio device. Press
again to pause playback.
2. To skip to the next track press the button
on the remote.
3. To skip to the previous track press the
button on the remote.
4. Any further operations must be done from the
audio device.
The v ected by the volume level
on the audio source EG: Phone or laptop, so make
sure that is set to about 70-80% ( not too loud to
avoid distortion).
Bluetooth notes
•The operation range of bluetooth is approximately
10 meters (30 Feet). Any obstacles in the path
between devices may reduce this range.
•Only one Bluetooth device can be paired at a time.
•Not all Bluetooth devices are compatible.
Source Indicator Lights
STATUS INDICATOR
Power O Red Light
Optical Mode Orange light
Aux In Mode White Light
Line In Mode Green Light
Bluetooth Pairing Flashing Blue Light
Bluetooth Connected Blue Light

Other information 4

Other information
Helpful technical information
Other information16
If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in theTroubleshooting section of these instructions,
Wall mounting the soundbar
3.
•In order to avoid damage to the unit and personal
injury you should get a qualified person to drill the
fixing surface and fit the appropriate wall fixings.
•Take care not to allow the main unit to fall while
attempting to hook onto the wall mount brackets.
•Before mounting, check the wall strength, if it is not
clear then consult relevant qualified personnel.
•When drilling into walls, always check that there are
no hidden wires or pipes etc.
•Make sure the screws & wall plugs are suitable for
supporting the unit.
595mm
WALL
Accessories included
1.
2.
ScrewWall Fixing

Other information
Helpful technical information
Other information 17
or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 604 0105.
Technical specification
Amplifier
Power output 100W RMS
Frequency response 20Hz - 20KHz ± 3dB
Input sensitivity 1000mV
Main unit
Power supply INPUT: 100-240V ~ 50-60Hz
OUTPUT: 24V 2.5 A
Power consumption 60W
Standby power consumption ≤ 0.5W
Full range speaker drivers
Subwoofer
Impedance: 4 Ohm, 52mm (2”)
Frequency response: 180Hz ~ 20KHz
Impedance: 4 Ohm, 120mm(4.75”)
Frequency response: 35~180Hz
Dimensions Soundbar: 940 x 68 x 60mm
Sub woofer: 172 x 352 x 320mm
Mains cable length 1 metre
Remote control
Battery 1 x CR2032
Bluetooth
Bluetooth compatibility EDR, GFSK, π/4-DQPSK, 8DPSK
Bluetooth version 2.1
Care & maintenance
After using the soundbar
Set to Standby.
Switch the unit o at the mains and unplug it if you are
leaving it unattended for a long period (holidays etc).
Avoid leaving the battery fitted in the remote control if
you leave the unit unattended for long periods. It may
leak and damage the remote control.
Care & cleaning
All care and cleaning operations should be carried out
with the unit unplugged from the mains power.
Occasionally wipe the cabinet with a lint free duster.
Never clean the unit with liquids or solvents.

Product support5

Product support
Help is always at hand
Product support 19
If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in theTroubleshooting section of these instructions,
Troubleshooting
No power.
•Ensure the mains plug is connected to a power supply, and is switched ON.
•Make sure there is power to the mains socket.
No sound?
•Make sure if playing from the AUX input, the external source has the volume turned up and is outputting sound.
•Make sure the volume is turned up.
•If using the digital optical ensure the source DIGITAL output is set to PCM, LPCM, PCM 2Ch stereo or
PCM downmix.
•Bluetooth device not paired. Check ‘Pairing a bluetooth device’.
No response from the soundbar.
•Unplug the power cable for 1 minute then plug back in again.
Remote control does not work.
•Reduce the distance between the remote and main unit
•Check the batteries are installed correctly.
•Replace the batteries
•Aim the remote directly at the soundbar
•This unit is designed to enter STANDBY mode automatically after 20 MINUTES of inactivity. Press the STANDBY
button to wake the unit.

Product support
Help is always at hand
Product support
20
or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 604 0105.
Help and assistance
If you require any technical guidance or find that your soundbar is not operating as intended, a simple solution can
often be found in the Troubleshooting section of these instructions or online at
www.argos-support.co.uk
If you still require further assistance, call one of our experts on 0345 604 0105. To help give us give you a fast and
nt service please have the following information ready:
Model Ref.
Serial number
Date of purchase
Local call rates applies*
Lines open 8am-7pm Monday to Saturday and 10am-4pm Sunday.
providers costs may vary, see www.bt.com/pricing for details.
For Security and training purposes, telephone calls to and from customer service centres maybe recorded and monitored. Calls from
Republic of Ireland will attract international call charges.
You can find these on
the rating plate - a small
information panel (usually
a sticker or metal plate) on
the rear of your product
This will be shown on
your receipt
b-3363G
