INSTRUCTION MANUAL
MANUEL D'INSTRUCTIONS
MANUAL DE INSTRUCCIONES
BEDIENUNGSANLEITUNG
78-8830 76mm Reflector
78-8845 114mm Reflector
Lit.#: 98-0189/11-02
ENGLISH

2
Never Look Directly At The Sun
With Your Telescope
Permanent Damage To Your Eyes
May Occur
❂

3
Your Bushnell telescope can bring the wonders of the universe to your eye.
While this manual is intended to assist you in the set-up and basic use of this
instrument, it does not cover everything you might like to know about
astronomy. Although Northstar will give a respectable tour of the night sky,
it is recommended you get a very simple star chart and a flashlight with a red
bulb or red cellophane over the end. For objects other than stars and
constellations, a basic guide to astronomy is a must. Some recommended
sources appear on our website at www.bushnell.com. Also on our website
will be current events in the sky for suggested viewing. Some of the standbys
that you can see are:
The Moon—a wonderful view of our lunar neighbor can be enjoyed with any
magnification. Try viewing at different phases of the moon. Lunar highlands, lunar
maria (lowlands called "seas" for their dark coloration), craters, ridges and mountains
will astound you.
Saturn—even at the lowest power you should be able to see Saturn’s rings and
moons. This is one of the most satisfying objects in the sky to see simply because it
looks like it does in pictures. Imagine seeing what you’ve seen in textbooks or NASA
images from your backyard!
Jupiter—the largest planet in our solar system is spectacular. Most noted features are
its dark stripes or bands both above and below its equator. These are the north and
south equatorial belts. Also interesting are Jupiter’s four major moons. Pay close
attention to their positions from night to night. They appear to be lined up on either
side of Jupiter.
Mars—The Great Red Planet appears as a reddish-orange disk. Look at different
times of the year and try to catch a glimpse of the white polar ice caps.
Venus—just like the moon, Venus changes phases from month to month. At times
Venus appears brilliantly in the night sky, just as if you were looking at a distant
crescent moon.
Nebulae—The Great Orion Nebula is a very well known night sky object. This and
many others are brought to you by this telescope.
Star Clusters—View millions of stars densely packed in a cluster that resembles a ball.
Galaxies—One of the greatest and most interesting galaxies is our neighbor the
Andromeda Galaxy. Enjoy this and many others.
WHERE DO I START?

4
PARTS DIAGRAM 78-8830 76mm and 78-8845 114mm Reflectors
1. Red Dot Finderscope
2. 1.25" Format Eyepiece
3. Rack and Pinion Focusing Mechanism
4. Accessory Tray Brace
5. Quick-Release Tripod Leg Lever
6. Quick-Release Accessory Tray
7. Remote Computer Controller
8. Main Telescope Tube
9. Quick-Release Adjustable Aluminum Tripod
TELESCOPE PARTS DIAGRAM
1.
2. 3.
4.
5.
6.
7.
8.
9.

5
•Adjustable Aluminum Tripod Assembly
(Pre-assembled to Northstar Computerized Star Locator Base)
•Quick Release Accessory Tray
•Northstar Telescope with finger attachment nuts
•Red Dot Finderscope
•20mm 1.25" Diameter Eyepiece
•4mm 1.25" Diameter Eyepiece
•Barlow Lens
PARTS LIST
QUICK ASSEMBLY DIAGRAM 78-8830 76mm and 78-8845 114mm Reflectors
1.
2.

6
DETAILED ASSEMBLY
No tools are required for assembly of your telescope.
Remove all components from the carton and identify all components. It is a good idea to lay all the parts out in front of you
before assembly. Since your telescope is a precision optical system the parts require careful handling—particularly the onboard
computer, telescope, eyepieces, and various accessory lenses.
SET UP TRIPOD AND ACCESSORY TRAY
1. Stand Northstar Computerized Star Locator Assembly and attached tripod legs in the upright position. Spread tripod legs
to a comfortable distance.
2. Fold down the accessory tray braces and place the Quick Release Accessory Tray on top of braces.
(See Quick Assembly Diagram)
3. Turn accessory tray until it snaps into place.
4. Adjust tripod leg height to suit by opening tripod leg lever and extending tripod legs to desired height. Clamp Tripod
Leg lever closed when complete.
ATTACH TELESCOPE TUBE
1. Locate Main Telescope Tube.
2. Remove Telescope Tube Thumb Nuts from side of Telescope Tube. (See Quick Assembly Diagram)
3. Position Main Telescope Tube Attachment Bolts through Telescope Tube Bracket at the top of the Northstar
Computerized Star Locator Assembly. Make sure the telescope is pointing in the correct direction. (Logo on telescope
tube should be right-side up.)
4. Reattach Telescope Tube Thumb Nuts to Main Telescope Tube Attachment Bolts once Main Telescope Tube and Northstar
Computerized Star Locator Assembly are assembled together.
ATTACH FINAL TELESCOPE ACCESSORIES
1. Locate Red Dot Finderscope.
For Reflector Telescopes: Remove Finderscope attachment nuts from Main Telescope Tube. Place Finderscope
Assembly over Finderscope Attachment Bolts and reattach Finderscope thumb nuts to Finderscope Mount Bolts.
NOTE: The large end of the finderscope should face the open end of telescope tube.
2. Attach Low Power Eyepiece.
For Reflector Telescope Models: Insert lowest power eyepiece in the focusing mechanism by backing out eyepiece
set screw and inserting eyepiece fully.
3. Tighten all set screws to secure accessories.
4. Remove Objective Dust Cover exposing entire diameter of open end of telescope.
SELECTING AN EYEPIECE
You should always start viewing with the lowest power eyepiece, which in this case is the 20 mm lens. Note: the base power
of each eyepiece is determined by the focal length of the telescope objective lens. A formula can be used to determine the
power of each eyepiece: telescope OBJECTIVE lens focal length divided by EYEPIECE focal length = MAGNIFICATION (e.g.
Using the 20 mm lens, a sample calculation could look like this: 750 mm / 20 = 38x or 38 power. Telescope models will
vary in focal length.)
Included with this telescope is a Barlow lens. Barlow lenses are used to double or triple the power of your telescope. Place
your Barlow between the focusing tube and the eyepiece. Using the example above, your 3x Barlow lens would give you a
total power of 114x or 114 power. (38 x 3 = 114x or 114 power). The magnification calculation would look like this: 750
mm /20mm = 38 power. 38 power x 3=114 power.

7
MALIGNING FINDERSCOPE
Look through Main Telescope Tube and establish a well-defined target. (see Focusing Telescope section)
Remove plastic insulator from between Red Dot Finderscope battery and battery clip.
Turn Red Dot Finderscope on.
Looking through Red Dot Finderscope, turn adjustment wheels until the red dot is precisely centered on the same object already
centered in Main Telescope Tube’s field of view.
Now, objects located first with the Red Dot Finderscope will be centered in the field of view of the main telescope.
MFOCUSING TELESCOPE
1. After selecting the desired eyepiece, aim main telescope tube at a land-based target at least 200 yards away (e.g. a
telephone pole or building).
2. Fully extend Focusing Tube by turning Rack and Pinion Focusing Mechanism.
3. While looking through selected eyepiece (in this case the 20 mm), slowly retract Focusing Tube by turning Rack and
Pinion Focusing Mechanism until object comes into focus.
DETAILED ASSEMBLY (CONTINUED)
MATTACH REMOTE COMPUTER CONTROLLER AND BATTERY
1. Locate Remote Computer Controller and coil cord.
2. Locate Battery Door on Northstar Computerized Star Locator Base.
3. Remove Battery Door and insert one 9V battery.
4. Replace Battery Door.
5. Attach Remote Computer Controller with coil cord to Northstar Computerized Star Locator Base.
Never Look Directly At The Sun
With Your Telescope
Permanent Damage To Your Eyes
May Occur
❂

8
MENJOYING YOUR NEW TELESCOPE
1. First determine your targeted object. Any bright object in the night sky is a good starting point. One
of the favorite starting points in astronomy is the moon. This is an object sure to please any budding
astronomer or experienced veteran. When you have developed proficiency at this level, other objects
become good targets. Saturn, Mars, Jupiter, and Venus are good second steps to take.
2. The first thing you need to do after assembling the telescope as planned is center the desired object
in the finderscope’s cross hairs. Provided you did a reasonable job aligning the finderscope, a quick
look through the main telescope tube at low power should reveal the same image. With the lowest
power eyepiece (the one with the largest number printed on it) you should be able to focus the same
image that you saw through the finderscope. Avoid the temptation to move directly to the highest
power. The low power eyepiece will give you a wider field of view, and brighter image—thus making
it very easy to find your target object. At this point with a focused image in both scopes, you’ve
passed the first obstacle. If you don’t see an image after attempting to focus it in, you might consider
aligning your finderscope again. Once you pass this step, you’ll will enjoy the time spent ensuring a
good alignment. Every object you center in the finderscope will be easily found in the main telescope
tube, which is important for continuing your exploration of the night sky.
3. The low power eyepieces are perfect for viewing the full moon, planets, star clusters, nebulae, and
even constellations. These should build your foundation. However, for more detail, try bumping up
in magnification to higher power eyepieces on some of these objects. During calm and crisp nights,
the light/dark separation line on the moon (called the "Terminator") is marvelous at high power. You
can see mountains, ridges and craters jump out at you due to the highlights. Similarly, you can move
up to higher magnifications on the planets and nebulae. Star clusters and individual stars are best
viewed through the low power no matter what.
4. The recurring astronomical theater we call the night sky is an ever-changing billboard. In other words,
the same movie does not play all the time. Rather, the positions of the stars change not only hourly
as they seem to rise and set, but also throughout the year. As the earth orbits the sun our perspective
on the stars changes on a yearly cycle about that orbit. The reason the sky seems to move daily just
as the sun and the moon "move" across our sky is that the earth is rotating about its axis. As a result
you may notice that after a few minutes or a few seconds depending on what power you are viewing
at, the objects in your telescope will move. At higher magnifications especially, you will notice that
the moon or Jupiter will "race" right out of the field of view. To compensate, just move your telescope
to "track" it in the necessary path.

9
MHELPFUL HINTS
1. Your telescope is a very sensitive instrument. For best results and fewer vibrations set your
telescope up on a level location on the ground rather than your concrete driveway or your
wooden deck. This will provide a more stable foundation for viewing, especially if you’ve
drawn a crowd with your new telescope.
2. If possible view from a location that has relatively few lights. This will allow you to see
much fainter objects. You’d be surprised how much more you’ll see from your local lake
or park when compared to a backyard in the city.
3. Using your telescope out a window is NEVER recommended.
4. View objects that are high in the sky if possible. Waiting until the object rises well
above the horizon will provide a brighter and crisper image. Objects on the horizon
are viewed through several layers of earth’s atmosphere. Ever wonder why the moon
appears orange as it sets on the horizon? It’s because you are looking through a
considerable more amount of atmosphere than you would directly overhead. (Note:
If objects high in the sky are distorted or wavy, you are probably viewing on a very
humid night.) During nights of unstable atmosphere, viewing through a telescope
can be frustrating if not impossible. Astronomers refer to crisp, clear nights as nights
of "good seeing."

10
BUTTON FUNCTIONS
1. On/Off Button (On Northstar Base)
2. Back Button
3. Enter Button
4. Scroll Up Button
5. Scroll Down Button
6. LCD Display
7. “GO”Button
8. Motorized Movement Buttons (4)
9. Battery Door (On Northstar Base)
NORTHSTAR COMPUTER
INTERFACE DIAGRAM
The Liquid Crystal Display (LCD) is a two-line, sixteen character display. The LCD is illuminated for use during nighttime viewing
just like the buttons.
ALL BUTTONS ARE ILLUMINATED FOR NIGHTTIME USE.
On/Off Button: The On/Off Button will turn the Northstar Computerized Star Locator on and off. This button flashes or
strobes on and off during normal use. To turn the unit off, simply depress and hold the On/Off button for three seconds
and release. (Note: The Northstar Computerized Star Locator will automatically turn itself off after 10 minutes of inactivity.)
Back Button: This button functions to navigate to the previous level within the operating framework and/or back to the
previous level of input.
Enter Button: This button functions to select certain menu choices. By pressing the ENTER button Northstar will advance
to the selected level. When an object name or number is listed on the screen, the ENTER button can also be pressed to
display a scrolling text description of the object.
Scroll Up Button: This button functions to scroll up through various menus within Northstar. Anytime you encounter a
blinking text/number option, the scroll button will display the various choices within that menu. (Note: To select an option
that you have scrolled to, just press the ENTER button.)
Scroll Down Button: This button functions to scroll down through various menus within Northstar. Anytime you
encounter a blinking text/number option, the scroll button will display the various choices within that menu.
(Note: To select an option that you have scrolled to, just press the ENTER button.)
“GO” Button: The GO button will automatically center any object displayed on the LCD display. By pushing the “GO”
button, the telescope will automatically find and follow the selected object until another object is selected and the “GO”
button is pushed again.
Motorized Movement Buttons: These four multi-directional buttons will allow the user to override the tracking system
and move the telescope utilizing the motors manually to another desired location. The longer these buttons are depressed,
the faster the Northstar will move until it reaches its maximum speed.
LCD DISPLAY
2.
3. 4.
5.
6.
7.
8.

11
MMODE OVERVIEW OF PRODUCT
Explore: The Explore Mode of Northstar provides the ability to explore various astronomical objects
categorized by object type. These objects would fall under one or more of the following types of objects:
Deep Sky, Planets, Constellations, and Stars. Each of these subheadings would also have subcategories of
objects beneath their menu structure. (See Menu Tree for full list of menu functions and options.)
Sky Tour: The Sky Tour Mode of Northstar provides the ability to take a quick tour of the best and brightest objects
for any given month of the year. If the date has been input into the system, the Sky Tour Mode will automatically
default to that month. Objects can be chosen by using the scroll up or down arrows and pressing ENTER. To find
out more information about any given object press the ENTER button while that object is displayed to see the scrolling
text message.
Telescope: The Telescope Mode of Northstar provides real-time data on where the telescope is pointing.
Astronomical Coordinates for Right Ascension (RA) and Declination (DEC) as well as Altitude (ALT) and Azimuth (AZ)
are displayed simultaneously. In addition, in the lower right-hand corner will be the abbreviation for the current
constellation that the telescope is pointed at.
Identify: The Identify Mode of Northstar provides the ability to identify any object within your telescope field of view.
Subcategories for different classes of identifiable objects are included as well as an Identify Any option.
Align Earth: The Align Earth Mode of Northstar provides the ability to easily align your telescope utilizing common
information non-astronomers would readily know. By entering simple information such as time, date, city, etc. a first
time telescope user can explore the immense Northstar database of astronomical objects
within minutes.
Align Star: The Align Star Mode of Northstar provides the ability to align your telescope utilizing some astronomical
knowledge. By knowing where two stars are located in the sky, a novice user can circumvent the city, date, and time
input and quickly start utilizing the Northstar database to locate amazing astronomical objects.
Align Object: The Align Object Mode of Northstar provides the ability to refine your telescope alignment during the
middle of your observing session. This might come in very handy if the family dog has just bumped the telescope
out of alignment. By using this mode you can center the telescope on any known object and select align object to
quickly recalibrate the Northstar alignment allowing continued enjoyment for the duration
of the evening.

12
MMENU TREE
BUSHNELL NORTHSTAR COMPUTER MENU STRUCTURE
(For Step-By-Step Easy Use Refer to Quic Reference Guide)
WELCOME TO BUSHNELL NORTHSTAR LEVEL TUBE USE ALIGN MARKS PRESS ENTER WHEN LEVEL SELECT MODE
ALIGN EARTH
TIME 19:00 GMT DATE 25 DEC 2000
CITY
COUNTRY
CITY
POINT NORTH CENTER STAR 1 CENTER STAR 2 ALIGN COMPLETE THEN PRESS ENTER THEN PRESS ENTER THEN PRESS ENTER RATING *****
LATLON
EXPLORE
ANDROMEDA . VULPECULA MERCURY NAMED NAMED
CONSTELLATION VENUS VARIABLE MESSIER
MARS DOUBLE NCG
PLANET JUPITER CATALOG IC
SATURN GALAXY
STARS URANUS CLUSTER
NEPTUNE NEBULA
DEEP SKY PLUTO NS
MOON UGC
TELESCOPE RA 22:09 DEC+052 ESO
AZ 089 ALT 080 PEG
SKY TOUR JAN.DEC IDENTIFY ANY
STAR
ALIGN OBJECT DOUBLE
CLUSTER
ALIGN STAR CENTER STAR 1 CENTER STAR 2 ALIGN COMPLETE
THEN PRESS ENTER THEN PRESS ENTER RATING *****

13
MALIGNING NORTHSTAR FOR THE FIRST TIME
(NOTE: Make certain that the telescope is set up on a level surface.)
STEP 1: POINT NORTH
Point the telescope in the direction of North.
NOTE: THE USER SHOULD JUST ATTEMPT TO GET THE TELESCOPE POINTED RELATIVELY CLOSE TO NORTH. THE
ALIGNMENT WILL BE REFINED AS WE PROGRESS. HOWEVER, IF YOU CAN FIND THE BIG DIPPER AND USE THE
"POINTER STARS", FOLLOW THE ARROW ON THE DIAGRAM TO THE NORTH STAR. THE NORTH STAR LIES DIRECTLY
ABOVE DUE NORTH!
When you turn the telescope on, a scrolling message will appear:
BUSHNELL NORTHSTAR Vx.x
Following this message, the telescope will execute a diagnostic check and level the telescope tube in relation to the
telescope mount.
Then the default menu will appear:
SELECT MODE
ALIGN EARTH ][
This mode assumes that even if the telescope user is a first time user and does not know anything about astronomy
that they can be successful aligning the telescope in a few simple steps.
The ALIGN EARTH option is flashing.
Press ENTER to choose ALIGN EARTH option.
NOTE: ANY FLASHING ITEM ON THE DISPLAY IS A MENU CHOICE. OTHER CHOICES ARE AVAILABLE BY USING THE
SCROLL UP OR SCROLL DOWN BUTTONS.

14
MALIGNING NORTHSTAR FOR THE FIRST TIME (Continued)
STEP 2: SET THE TIME
By using the SCROLL UP and SCROLL DOWN buttons and the ENTER button, the time can easily be set as well as the time
zone. Each flashing option will need to be changed to read the appropriate number. Once the appropriate number is
displayed, accept the number by pressing ENTER. Then set the next flashing option until the time and time zone
are set.
STEP 3: SET THE DATE
Again by using the SCROLL UP and SCROLL DOWN buttons and the ENTER button, the date can easily be set. Each flashing
option will need to be changed to read the appropriate number or month. Once the appropriate number is displayed, accept
the number by pressing ENTER. Then set the next flashing option until the day, month and year
are set.
STEP 4: SET THE LOCATION
The next screen will display:
ALIGN EARTH
CITY ][
CITY will be flashing. By pressing the ENTER button, the display will change to:
COUNTRY
U.S.A.][
The country will be flashing.
Again by using the SCROLL UP and SCROLL DOWN buttons and the ENTER button, the COUNTRY can be chosen.
When the appropriate Country is found and the ENTER button is pushed, choose the city that you are closest to by pressing
ENTER when it is displayed.
NOTE: CHOOSE THE CITY CLOSEST TO YOUR VIEWING LOCATION. THIS IS NOT A CRITICAL STEP AND THE ALIGNMENT
WILL BE REFINED AUTOMATICALLY AS WE PROGRESS.
After four simple criteria that any consumer should know, the telescope now knows where over 20,000 astronomical objects
are in the night sky to a relative precision. With just two more steps, you will zero in on pinpoint accuracy.
Now the telescope will lead you through a simple two star alignment process. YOU DO NOT NEED TO KNOW WHERE ANY
STARS ARE. You just simply follow the directions.
A scrolling message indicates to CENTER STAR 1 THEN PRESS ENTER
Then the display will read:
CENTER STAR 1
{120 ]52 MIZAR
Push the “GO”button and the telescope will automatically move to the general vicinity of the first guide star--in this
case MIZAR
The guide stars will be the brightest stars found in that area of the sky. Northstar will automatically “zero out”the guide star
and the display will read:
CENTER STAR 1
0◊0 0◊0 MIZAR
Note as you move from greater than 10 degrees away from an object to under ten degrees, the display moves into tenths of
degrees with the arrows acting as decimal points (Example 8]5 8.5 degrees below the object).
After getting the star zeroed in, you need to do as the screen told you—CENTER STAR 1. In other words, the star might
appear in the lower left corner of your telescope’s eyepiece.
By looking through the eyepiece, center the star in the field of view by using the Motorized Movement Buttons or move
the telescope by hand and press ENTER.

15
MALIGNING NORTHSTAR FOR THE FIRST TIME (Continued)
The distance the object is from the center is related to how far outside of a city you might be located or how
accurately you aligned with north.
Repeat this process for STAR 2 and press ENTER.
After this step is completed, you will see a display that reads:
ALIGN COMPLETE
RATING *****
(Note: The more stars that appear on the second line of the display the better, up to 5)
After the two star alignment is complete, your Northstar now knows with pinpoint accuracy where
all 20,000+ objects are!!
After EARTH ALIGN, the display will then read:
SELECT MODE
EXPLORE ][
Select EXPLORE by pressing ENTER. SCROLL UP and DOWN to see what flashing menu choices you have.
Choose PLANET. These are the most interesting. Even if you are a first time telescope user, PLANET objects
can be very exciting.
Press ENTER when the display reads:
EXPLORE
PLANET
This will take you into a list of named PLANET objects. By using the SCROLL UP or SCROLL DOWN buttons, you can
explore several items in the object list.
PLANET
JUPITER ][
Press ENTER to choose the PLANET you wish to view. The display will then be:
PLANET
{120 ]52 JUPITER
NOTE: IF AN OBJECT IS BELOW THE HORIZON, THE DISPLAY WILL PERIODICALLY DISPLAY THE WORD "HORIZON".
SCROLL UP or SCROLL DOWN to see other PLANETS in the list. Notice the display shows you directions to each
object. But what if you are a first time user wanting to find out more about the object? Wouldn’t it be nice to know
what the object is before moving the telescope?
PRESS ENTER when:
PLANET
{120 ]52 JUPITER
any other PLANET item is displayed. You will see a scrolling message telling you the coordinates for the object, how
bright it is, how big it is, what its proper name is, what constellation it is in, and a brief description of what the object
is. For JUPITER it reads:
JUPITER fifth planet from sun.
Largest planet in solar system.
16 moons. Orbit is 11.86 years.
Diameter 143,000 km. Named for roman king of gods.
MUSING NORTHSTAR FOR THE FIRST TIME

16
MUSING NORTHSTAR FOR THE FIRST TIME (Continued)
Now imagine that you are a parent trying to impress your children (or vice versa). Ten minutes into your first
observing session you are already learning astronomical objects.
This is a great educational tool !!!!
To find the object, just press the “GO”button and that object will be right in the telescope’s eyepiece!
By pressing the BACK button, you move back to the previous level each time the button is pressed. Press the button
three times and you are back at the main level menu. The display will read:
SELECT MODE
EXPLORE ][
SCROLL UP or SCROLL DOWN to select
SELECT MODE
SKY TOUR ][.
Press ENTER.
This mode will take you through the best and brightest objects for each month. If you have done the ALIGN EARTH
alignment and entered the date, it will automatically take you to the current month. Don’t know what some of
these obscure objects and abbreviations mean? Just press the ENTER key for more information.
Press the BACK button until you get back to the main menu:
SELECT MODE
SKY TOUR ][.
SCROLL UP or SCROLL DOWN until the display reads:
SELECT MODE
IDENTIFY ][
PRESS ENTER
This mode will default to the level
IDENTIFY ANY
By selecting this option with the ENTER key, it will IDENTIFY the object that you are currently viewing OR the closest
object to where your telescope is currently pointed. You also have the options to choose other types of IDENTIFY
menus. These will IDENTIFY the closest CLUSTERS, NEBULAS, etc. to your current
telescope position.
To select the final mode press ENTER at the display:
SELECT MODE
TELESCOPE ][
The display reads something like:
RA18:53 DEC+38.7
AZ280 ALT+62 LYR
The TELESCOPE mode gives you dynamic real-time information on your telescope’s current position in terms of
astronomical coordinates. Play around with this mode by moving the telescope around. Notice the three letter
abbreviation in the lower right portion of the display. This dynamically displays the current CONSTELLATION that
the telescope is pointing at. These names are abbreviated in this mode. Definitions for the abbreviations will be in
the catalog index.

17
WARRANTY / REPAIR
TELESCOPE LIFETIME LIMITED WARRANTY*
Your Bushnell®telescope is warranted to be free of defects in materials and workmanship for the
lifetime of the original owner. The Lifetime Limited Warranty is an expression of our confidence
in the materials and mechanical workmanship of our products and is your assurance of a lifetime
of dependable service.
If your telescope contains electrical components, these components are warranted to be free of
defects in materials and workmanship for two years after the date of purchase.
In the event of a defect under this warranty, we will, at our option, repair or replace the product,
provided that you return the product postage prepaid. This warranty does not cover damages caused
by misuse, improper handling, installation, or maintenance provided by someone other than a
Bushnell Authorized Service Department.
Any return made under this warranty must be accompanied by the items listed below:
1) A check/money order in the amount of $15.00 to cover the cost of postage and handling
2) Name and address for product return
3) An explanation of the defect
4) Proof of Date Purchased
5) Product should be well packed in a sturdy outside shipping carton, to prevent damage
in transit, with return postage prepaid to the address listed below:
IN U.S.A. SEND TO: IN CANADA SEND TO:
Bushnell Performance Optics Bushnell Performance Optics
Attn.: Repairs Attn.: Repairs
8500 Marshall Drive 25A East Pearce Street, Unit 1
Lenexa, Kansas 66214 Richmond Hill, Ontario L4B 2M9
For products purchased outside the United States or Canada please contact your local dealer for
applicable warranty information. In Europe you may also contact Bushnell at: 33 141 44 94 80
Bushnell Performance Optics Service Centre
Columbusstraat 25
3165 AC Rotterdam
The Netherlands
This warranty gives you specific legal rights.
You may have other rights which vary from country to country.
©2002 Bushnell Corporation

18

19
MANUEL
D'INSTRUCTIONS
78-8830 76mm Reflectors
78-8845 114mm Reflectors
FRENCH

20
❂
Ne regar ez jamais irectement le soleil
ans le télescope.
Risque e lésions oculaires permanentes
