Bushnell SHIELD Series User manual

4 PERSON DOME TENT
8’ x 7’ x 54” (2.44m x 2.13m x 1.37m )

Customer Service HELPLINE 1-888-774-5840 www.bushnelltents.com
2
Model No. 30190
FEATURES TECHNOLOGY
&
WANT
MORE
?Visit www.bushnelltents.com for
additional information, product
videos, camping tips and more!
Special reflective coating on the underside of the rainfly
blocks the sun’s UV rays, keeping the tent darker and
noticeably cooler.
HEAT SHIELD TECHNOLOGY
WEATHER SHIELD
Internal and external pockets keep essential items
close at hand and off the ground. Store your flashlight
in its own easy access pocket, conveniently located
right outside the door.
ESSENTIAL GEAR ORGANIZERS
Large mesh windows allow for enhanced ventilation
and unobstructed views of the night sky. Privacy
panels on windows zip shut when needed.
PANORAMIC WINDOWS
Reflective tie-downs, zipper-pulls, and piping around
door enhance nighttime visibility.
ENHANCED NIGHTTIME VISIBILITY
Specially designed features defend you from the
toughest weather. Water repellent fabric and fully-
taped waterproof seams seal-off your tent from the
rain, while strong frame construction and heavy duty
tie-downs stand tough against the wind.
Simple 2-pole design allows
for easy setup and take down.
FAST SETUP AND TAKE DOWN

Customer Service HELPLINE 1-888-774-5840 www.bushnelltents.com
4
Model No. 30190
BEFORE YOU BEGIN:
• Before camping, unpack tent and ensure all parts are accounted for.
• Select a level site clear of rocks, branches, and other hard or sharp
objects to setup your tent.
• Always secure the tent using all stakes and tie-downs provided to
prevent property damage or personal injury.
• Keep tent clear of power lines!
• Do not set up your tent under trees because of potential lighting strikes
or falling tree limbs in inclement weather.
WANT
MORE
?See page 6 and 7 for frequently asked questions
and parts diagram. Visit www.bushnelltents.com
for additional camping tips and information!
1PREPARE FOR SETUP
1Remove all contents from bag.
2Lay tent fabric out flat.
SETUP TAKE DOWN
&
2INSERT POLES
3ATTACH POLES 4LINK POLES
5PREPARE RAINFLY 6PLACE RAINFLY
7ATTACH RAINFLY & FLOOR MAT 8SECURE TENT
TENT CONTENTS:
• Tent
• Rainfly
• Poles (3)
• Metal Stakes (12)
1Using the remaining small pole, set
both pole ends into webbing pockets in
the middle of the silver side of rainfly.
² Tie the pole to the rainfly with the ties
located at the center of the rainfly.
1Flip the rainfly right-side-up.
2 Drape the rainfly over tent, placing
the “B” logo above the door.
¹ Attach (4) rainfly buckles and hook-and-
loop tabs to secure the rainfly to the tent.
² Attach Floor Mat to loops at front of tent,
below door with (2) black hooks on the mat.
• Gear Loft
• Floor Mat
1Secure the tent by staking down the (4)
corners with included stakes.
2Stake out the (4) orange corner tie-
downs, and the (2) side vents.
1Connect the sections of each of the (3) poles.
² Insert the two large poles into sleeves. Poles
will create an “X” across the tent.
Link poles together at the top of the
tent where they intersect with black
hook.
1Insert the silver pins into the ends of
the poles at each corner of the tent.
2Secure tent fabric to poles using
black clips.
• Carry Bag

Customer Service HELPLINE 1-888-774-5840 www.bushnelltents.com
6
Model No. 30190
TAKE DOWN INSTRUCTIONS
Remove stakes from tie-downs, tent, rainfly and vents. Store in stake bag.
Detach hook-and-loop tabs and buckles that attach rainfly to tent. Remove
rainfly from tent and detach rainfly pole.
Detach floor mat.
Detach pole clips and remove four pole ends from silver pins.
Remove (2) main poles from pole sleeves.
Detach pole sections of all (3) poles and store in pole bag.
Fold tent lengthwise 2-3 times and roll tightly to remove excess air.
Fold and roll rainfly as well.
Store the tent, poles, rainfly, mat and stakes in the included carry bag.
1
2
3
4
5
6
7
8
WARRANTY CUSTOMER SERVICE
&
MAIN POLE
# 90409
FLOOR MAT
# 90413
ITEM NO. BSN-8754F
4 PERSON DOME TENT (8’ x 7’ x 54” / 2.44m x 2.13m x 1.37m) MODEL NO. 30190
FAQ / TROUBLESHOOTING
• Are replacement parts available? Yes, just call Customer Service at 1-888-774-5840 for
replacement parts. See next page.
• Is the tent freestanding? Are the stakes required? Yes, this tent is freestanding. The stakes
are to secure it to the ground and make the floor taut.
• How many people does this tent sleep? This tent is designed for four people in sleeping
bags on the ground. Two people would fit comfortably when using an air mattress.
• How do I clean my tent? Clean the tent with a soft sponge, a mild soap and tepid water. Be
sure to scrub gently and remove all soap. Let dry in sunlight, which also naturally cleans the tent.
• How many seasons is this tent? This is a three-season tent, recommended for use during
spring, summer and fall.
• Where does the gear loft go? It hangs on the ceiling inside the tent. There are four loops onto
which the gear loft attaches.
• Why is there water on the inside of my tent walls in the morning? Condensation can
be caused inside the tent by breath, perspiration or wet items. This is not leakage and can be
minimized by removing wet items and providing good ventilation. This is something that happens
in all tents, under the right circumstances.
INTERNAL GEAR LOFT
# 90414
NOT PICTURED:
FLY POLE # 90410
CARRY BAG # 90412
RAINFLY # 90411
STAKES #90442
TIE-DOWN # 90443
1 YEAR LIMITED WARRANTY
Bohemian Travel Gear Limited warrants for a period of 12
months from the original date of purchase, this product
against any defects in materials or workmanship. At
its discretion, Bohemian Travel Gear may provide
replacement parts to original purchaser. Original receipt
or proof of purchase as well as proof of defect is
required. Bohemian Travel Gear will not be responsible
for shipping costs incurred outside the continental USA.
Warranty is valid for the original purchaser 12 months
from the date of purchase and is not transferable. This
Warranty Does Not Cover any product purchased
through non authorized dealers and/or online auction
sites. This 12 Month Limited Warranty does NOT cover
normal wear and tear, abuse or misuse of this product
including damage from inclement weather conditions,
such as wind, rain, or hail. In case of inclement weather
remove all valuables and persons and seek appropriate
shelter. Under no circumstances will Bohemian Travel
Gear Limited be liable or responsible for any incidental
or consequential damages.
This product is designed and intended for Recreational
use only. Prolonged exposure to UV rays will cause
any fabric to fade and deteriorate and is NOT covered
by this 12 Month Limited Warranty. All replacement
products or parts will assume the remaining warranty
of the original product. This warranty gives you specific
legal rights. You may also have other rights which vary
from state to state.
NOTICE: DO NOT RETURN PRODUCT TO RETAIL STORE.
CUSTOMER SERVICE HELPLINE
Questions? Comments? Call us toll free at 1-888-774-5840 for warranty service, repair parts, or product questions.
Mon-Fri, 8:00 a.m. – 5:00 p.m., Central time. Use the below diagram for part number identification.
9

Bohemian Travel Gear Limited
Plot # 30-32, Sector 3, Karnaphuli EPZ, Chittagong 4204,
Bangladesh
Made in Bangladesh • Printed in Bangladesh
WARNINGS AND CAUTIONS
WARNING: KEEP ALL FLAME AND HEAT SOURCES
AWAY FROM THIS TENT FABRIC. This tent is made of flame-
resistant fabric which meets CPAI-84 specifications. IT IS NOT
FIRE-PROOF. The fabric will burn if left in continuous contact
with any flame source. The application of any foreign substance
to the product fabric may render the flame-resistant properties
ineffective.
DO NOT use fuel burning devices inside or near tent materials.
DO NOT permit children to light matches, operate burning
appliances, or handle any flame sources in or near the tent
• Do not smoke, use matches, candles or open flames of any
kind in or near the tent.
• Do not refuel lanterns, stoves or heaters inside tent.
• Do not cook inside tent.
• Do not store flammable liquids inside tent.
IMPORTANT: THE ORIGINAL FIRE RETARDANT AND WATER
REPELLENT PROTECTIVE COATINGS MAY BE COMPROMISED
IF SPRAYS OR OTHER CHEMICAL TREATMENTS ARE USED
ON THE TENT. FABRIC HAS BEEN FACTORY TREATED.
IT IS HIGHLY WATER-REPELLENT; HOWEVER IT IS NOT
WATERPROOF. ALL TENTS CAN EXPERIENCE SEAM
LEAKAGE DURING WET WEATHER. IF YOU WANT ADDITIONAL
MOISTURE PROTECTION TRY A SEAM SEALING COMPOUND
ONLY; STRICTLY FOLLOWING THE MANUFACTURER’S
DIRECTIONS. IT IS RECOMMENDED THAT YOU SEAL THE
TENT DURING THE INITIAL SETUP AS WELL AS PRIOR TO
EACH CAMPING SEASON. SEAM SEALER COMPOUNDS CAN
BE PURCHASED AT YOUR LOCAL CAMPING PRODUCTS
OUTLET. FOR MISSING PARTS CALL 1-888-774-5840.
NOTICE: DO NOT RETURN PRODUCT TO RETAIL STORE.
