1
CHAINSAW
CS4610 / CS5410
OPERATOR’S MANUAL
All manuals and user guides at all-guides.com
all-guides.com
2
SAFETY FIRST
Instructions contained in warnings
within this manual marked with a symbol
concern critical points which must be
taken into consideration to prevent
possible serious bodily injury, and for
this reason you are requested to read
all instructions carefully and follow them
without fail.
The rst time user shall have practical
instructions in the use of the chain saw
and the protective equipment from an
experienced operator and that the initial
practice should be cutting logs on a saw
horse or cradle.
If any malfunctions happen, please
consult with the Bushranger™dealer in
your area.
CONTENTS
NOTES ON TYPES OF
WARNINGS IN THE MANUAL
WARNING
This mark indicates instructions which
must be followed in order to prevent
accidents which could lead to serious
bodily injury or death.
IMPORTANT
This mark indicates instructions
which must be followed, or may lead
to mechanical failure, breakdown, or
damage.
NOTE
This mark indicates hints of directions
useful in the use of the product.
PARTS LOCATION.....................................................................................................................
WARNING LABELS ON THE MACHINE...................................................................................
SYMBOLS ON THE MACHINE..................................................................................................
SAFETY PRECAUTIONS...........................................................................................................
INSTALLING GUIDE BAR AND SAW CHAIN...........................................................................
FUEL AND CHAIN OIL...............................................................................................................
OPERATING ENGINE...............................................................................................................
SAWING.....................................................................................................................................
MAINTENANCE OF ENGINE....................................................................................................
MAINTENANCE OF CHAIN AND GUIDE BAR.........................................................................
TROUBLESHOOTING GUIDE...................................................................................................
ATTACHED TOOLS PARTS.......................................................................................................
SPECIFICATIONS......................................................................................................................
WARRANTY...............................................................................................................................
3
4
5
7
8
8
9
11
12
13
14
14
15
16
1
2
3
4
5
6
7
8
9
10
11
12
13
All manuals and user guides at all-guides.com
3
1. Front guard
2. Starter knob
3. Air cleaner cover
4. Choke knob
5. Throttle interlock
6. Right handle
7. Throttle lever
8. Engine switch
9. Fuel tank
10. Oil tank
11. Left handle
12. Saw chain
13. Guide Bar
3
4
5
7
8
8
9
11
12
13
14
14
15
16
1
2
3
4
5
6
7
8
9
10
11
12
13
All manuals and user guides at all-guides.com
4
1. Carefully read the
operator’s manual before
operating this machine.
2. Wear head, eye and ear
protection.
3. Use the chain saw with
two hands; one handed
operation of the saw
can be dangerous.
4. Warning!
Kickback it’s dangerous.
5. Warning!
The words WARNING calls
attentions to an act or a
condition which can lead to
serious personal injury or
death.
6. Chain brake operation.
7. Do not expose to rain! Do
not operate the machine on
wet ground.
8. Circle and slash symbol
means whatever shown is
prohibited.
(1)Carefully read owner’s
manual before operating
this machine.
(2)Wear head ,eye and ear
protection.
(3)Use the chain saw with
two hands; one handed
operation of the saw
can be dangerous.
(4)Warning ! kickback it’s
dangerous
(5)Warning
The words WARNING calls
attentions to an act or a
condition which can lead
to serious personal injury
or death.
(6) Chain brake operation.
(7) Do not expose to rain!
Do not operate the
machine on wet ground.
(8)Circle and slash symbol
means whatever shown
is prohibited.
For safe operation and maintenance,
symbols are carved in relief on the
machine. According to these
indications, please be careful not to
take a mistake.
(a). The port to refuel the
“MIXGASOLINE”
Position: fuel tank cap
(b). The port to refuel the
“CHAIN OIL”
Position: oil cap
(c). The indication
regarding the switch.
Flipping the engine switch
to the “O”(STOP) direction,
the engine stops.
Position: rear-left of the
unit
(d). The indication regarding
the choke.
Pulling out the choke
knob, the choke closes.
Pushing in the choke knob,
the chock opens.
Position: rear-right of the
unit
(e). The indication regarding
the chain oil adjuster nut.
“MIN”direction-the oil
flow decrease
“MAX”direction-the oil
flow increase.
Position: starter case of the
unit.
(f). The position of H-needle
The position of L-needle
The position of idle
adjusting screw
Position: cylinder cover of
the unit
Engine Manual start.
Position: starter knob.
(1)Carefully read owner’s
manual before operating
this machine.
(2)Wear head ,eye and ear
protection.
(3)Use the chain saw with
two hands; one handed
operation of the saw
can be dangerous.
(4)Warning ! kickback it’s
dangerous
(5)Warning
The words WARNING calls
attentions to an act or a
condition which can lead
to serious personal injury
or death.
(6) Chain brake operation.
(7) Do not expose to rain!
Do not operate the
machine on wet ground.
(8)Circle and slash symbol
means whatever shown
is prohibited.
For safe operation and maintenance,
symbols are carved in relief on the
machine. According to these
indications, please be careful not to
take a mistake.
(a). The port to refuel the
“MIXGASOLINE”
Position: fuel tank cap
(b). The port to refuel the
“CHAIN OIL”
Position: oil cap
(c). The indication
regarding the switch.
Flipping the engine switch
to the “O”(STOP) direction,
the engine stops.
Position: rear-left of the
unit
(d). The indication regarding
the choke.
Pulling out the choke
knob, the choke closes.
Pushing in the choke knob,
the chock opens.
Position: rear-right of the
unit
(e). The indication regarding
the chain oil adjuster nut.
“MIN”direction-the oil
flow decrease
“MAX”direction-the oil
flow increase.
Position: starter case of the
unit.
(f). The position of H-needle
The position of L-needle
The position of idle
adjusting screw
Position: cylinder cover of
the unit
Engine Manual start.
Position: starter knob.
(1)Carefully read owner’s
manual before operating
this machine.
(2)Wear head ,eye and ear
protection.
(3)Use the chain saw with
two hands; one handed
operation of the saw
can be dangerous.
(4)Warning ! kickback it’s
dangerous
(5)Warning
The words WARNING calls
attentions to an act or a
condition which can lead
to serious personal injury
or death.
(6) Chain brake operation.
(7) Do not expose to rain!
Do not operate the
machine on wet ground.
(8)Circle and slash symbol
means whatever shown
is prohibited.
For safe operation and maintenance,
symbols are carved in relief on the
machine. According to these
indications, please be careful not to
take a mistake.
(a). The port to refuel the
“MIXGASOLINE”
Position: fuel tank cap
(b). The port to refuel the
“CHAIN OIL”
Position: oil cap
(c). The indication
regarding the switch.
Flipping the engine switch
to the “O”(STOP) direction,
the engine stops.
Position: rear-left of the
unit
(d). The indication regarding
the choke.
Pulling out the choke
knob, the choke closes.
Pushing in the choke knob,
the chock opens.
Position: rear-right of the
unit
(e). The indication regarding
the chain oil adjuster nut.
“MIN”direction-the oil
flow decrease
“MAX”direction-the oil
flow increase.
Position: starter case of the
unit.
(f). The position of H-needle
The position of L-needle
The position of idle
adjusting screw
Position: cylinder cover of
the unit
Engine Manual start.
Position: starter knob.
(1)Carefully read owner’s
manual before operating
this machine.
(2)Wear head ,eye and ear
protection.
(3)Use the chain saw with
two hands; one handed
operation of the saw
can be dangerous.
(4)Warning ! kickback it’s
dangerous
(5)Warning
The words WARNING calls
attentions to an act or a
condition which can lead
to serious personal injury
or death.
(6) Chain brake operation.
(7) Do not expose to rain!
Do not operate the
machine on wet ground.
(8)Circle and slash symbol
means whatever shown
is prohibited.
For safe operation and maintenance,
symbols are carved in relief on the
machine. According to these
indications, please be careful not to
take a mistake.
(a). The port to refuel the
“MIXGASOLINE”
Position: fuel tank cap
(b). The port to refuel the
“CHAIN OIL”
Position: oil cap
(c). The indication
regarding the switch.
Flipping the engine switch
to the “O”(STOP) direction,
the engine stops.
Position: rear-left of the
unit
(d). The indication regarding
the choke.
Pulling out the choke
knob, the choke closes.
Pushing in the choke knob,
the chock opens.
Position: rear-right of the
unit
(e). The indication regarding
the chain oil adjuster nut.
“MIN”direction-the oil
flow decrease
“MAX”direction-the oil
flow increase.
Position: starter case of the
unit.
(f). The position of H-needle
The position of L-needle
The position of idle
adjusting screw
Position: cylinder cover of
the unit
Engine Manual start.
Position: starter knob.
(1)Carefully read owner’s
manual before operating
this machine.
(2)Wear head ,eye and ear
protection.
(3)Use the chain saw with
two hands; one handed
operation of the saw
can be dangerous.
(4)Warning ! kickback it’s
dangerous
(5)Warning
The words WARNING calls
attentions to an act or a
condition which can lead
to serious personal injury
or death.
(6) Chain brake operation.
(7) Do not expose to rain!
Do not operate the
machine on wet ground.
(8)Circle and slash symbol
means whatever shown
is prohibited.
For safe operation and maintenance,
symbols are carved in relief on the
machine. According to these
indications, please be careful not to
take a mistake.
(a). The port to refuel the
“MIXGASOLINE”
Position: fuel tank cap
(b). The port to refuel the
“CHAIN OIL”
Position: oil cap
(c). The indication
regarding the switch.
Flipping the engine switch
to the “O”(STOP) direction,
the engine stops.
Position: rear-left of the
unit
(d). The indication regarding
the choke.
Pulling out the choke
knob, the choke closes.
Pushing in the choke knob,
the chock opens.
Position: rear-right of the
unit
(e). The indication regarding
the chain oil adjuster nut.
“MIN”direction-the oil
flow decrease
“MAX”direction-the oil
flow increase.
Position: starter case of the
unit.
(f). The position of H-needle
The position of L-needle
The position of idle
adjusting screw
Position: cylinder cover of
the unit
Engine Manual start.
Position: starter knob.
(1)Carefully read owner’s
manual before operating
this machine.
(2)Wear head ,eye and ear
protection.
(3)Use the chain saw with
two hands; one handed
operation of the saw
can be dangerous.
(4)Warning ! kickback it’s
dangerous
(5)Warning
The words WARNING calls
attentions to an act or a
condition which can lead
to serious personal injury
or death.
(6) Chain brake operation.
(7) Do not expose to rain!
Do not operate the
machine on wet ground.
(8)Circle and slash symbol
means whatever shown
is prohibited.
For safe operation and maintenance,
symbols are carved in relief on the
machine. According to these
indications, please be careful not to
take a mistake.
(a). The port to refuel the
“MIXGASOLINE”
Position: fuel tank cap
(b). The port to refuel the
“CHAIN OIL”
Position: oil cap
(c). The indication
regarding the switch.
Flipping the engine switch
to the “O”(STOP) direction,
the engine stops.
Position: rear-left of the
unit
(d). The indication regarding
the choke.
Pulling out the choke
knob, the choke closes.
Pushing in the choke knob,
the chock opens.
Position: rear-right of the
unit
(e). The indication regarding
the chain oil adjuster nut.
“MIN”direction-the oil
flow decrease
“MAX”direction-the oil
flow increase.
Position: starter case of the
unit.
(f). The position of H-needle
The position of L-needle
The position of idle
adjusting screw
Position: cylinder cover of
the unit
Engine Manual start.
Position: starter knob.
(1)Carefully read owner’s
manual before operating
this machine.
(2)Wear head ,eye and ear
protection.
(3)Use the chain saw with
two hands; one handed
operation of the saw
can be dangerous.
(4)Warning ! kickback it’s
dangerous
(5)Warning
The words WARNING calls
attentions to an act or a
condition which can lead
to serious personal injury
or death.
(6) Chain brake operation.
(7) Do not expose to rain!
Do not operate the
machine on wet ground.
(8)Circle and slash symbol
means whatever shown
is prohibited.
For safe operation and maintenance,
symbols are carved in relief on the
machine. According to these
indications, please be careful not to
take a mistake.
(a). The port to refuel the
“MIXGASOLINE”
Position: fuel tank cap
(b). The port to refuel the
“CHAIN OIL”
Position: oil cap
(c). The indication
regarding the switch.
Flipping the engine switch
to the “O”(STOP) direction,
the engine stops.
Position: rear-left of the
unit
(d). The indication regarding
the choke.
Pulling out the choke
knob, the choke closes.
Pushing in the choke knob,
the chock opens.
Position: rear-right of the
unit
(e). The indication regarding
the chain oil adjuster nut.
“MIN”direction-the oil
flow decrease
“MAX”direction-the oil
flow increase.
Position: starter case of the
unit.
(f). The position of H-needle
The position of L-needle
The position of idle
adjusting screw
Position: cylinder cover of
the unit
Engine Manual start.
Position: starter knob.
(1)Carefully read owner’s
manual before operating
this machine.
(2)Wear head ,eye and ear
protection.
(3)Use the chain saw with
two hands; one handed
operation of the saw
can be dangerous.
(4)Warning ! kickback it’s
dangerous
(5)Warning
The words WARNING calls
attentions to an act or a
condition which can lead
to serious personal injury
or death.
(6) Chain brake operation.
(7) Do not expose to rain!
Do not operate the
machine on wet ground.
(8)Circle and slash symbol
means whatever shown
is prohibited.
For safe operation and maintenance,
symbols are carved in relief on the
machine. According to these
indications, please be careful not to
take a mistake.
(a). The port to refuel the
“MIXGASOLINE”
Position: fuel tank cap
(b). The port to refuel the
“CHAIN OIL”
Position: oil cap
(c). The indication
regarding the switch.
Flipping the engine switch
to the “O”(STOP) direction,
the engine stops.
Position: rear-left of the
unit
(d). The indication regarding
the choke.
Pulling out the choke
knob, the choke closes.
Pushing in the choke knob,
the chock opens.
Position: rear-right of the
unit
(e). The indication regarding
the chain oil adjuster nut.
“MIN”direction-the oil
flow decrease
“MAX”direction-the oil
flow increase.
Position: starter case of the
unit.
(f). The position of H-needle
The position of L-needle
The position of idle
adjusting screw
Position: cylinder cover of
the unit
Engine Manual start.
Position: starter knob.
For safe operation and maintenance,
symbols are carved in relief on the
machine. According to these indications,
please be careful not to take a mistake.
a. The port to refuel the
“MIXGASOLINE”.
Position: fuel tank cap
b. The port to refuel the
“CHAIN OIL”.
Position: oil cap
c. The indication regarding the
switch. Flipping the engine
switch to the “O”(STOP)
direction, the engine stops.
Position: rear-left of the
unit.
d. The indication regarding the
choke. Pulling out the choke
knob, the choke closes.
Pushing in the choke knob,
the choke opens.
Position: rear-right of the
unit.
e. The indication regarding the
chain oil adjuster nut.
“MIN” direction-the oil
ow decrease “MAX”
direction-the oil ow
increase.
Position: starter case of the
unit.
f. The position of H-needle
The position of L-needle
The position of idle adjusting
screw
Position: cylinder cover
of the unit Engine Manual
start. Position: starter knob.
(1)
Carefully read owner’s
manual before operating
this machine.
(2)Wear head ,eye and ear
protection.
(3)Use the chain saw with
two hands; one handed
operation of the saw
can be dangerous.
(4)Warning ! kickback it’s
dangerous
(5)Warning
The words WARNING calls
attentions to an act or a
condition which can lead
to serious personal injury
or death.
(6) Chain brake operation.
(7) Do not expose to rain!
Do not operat
e the
machine on wet ground.
(8)
Circle and slash symbol
means whatever shown
is prohibited.
For safe operation and maintenance,
symbols are carved in relief on the
machine. According to these
indications, please be careful not to
take a mistake.
(a). The port to refuel the
“MIXGASOLINE”
Position: fuel tank cap
(b). The port to refuel the
“CHAIN OIL”
Position: oil cap
(c). The indication
regarding the switch.
Flipping the engine switch
to the “O”(STOP) direction,
the engine stops.
Position: rear-left of the
unit
(d). The indication regarding
the choke.
Pulling out the choke
knob, the choke closes.
Pushing in the choke knob,
the chock opens.
Position: rear-right of the
unit
(e). The indication regarding
the chain oil adjuster nut.
“MIN”direction-the oil
flow decrease
“MAX”direction-the oil
flow increase.
Position: starter case of the
unit.
(f). The position of H-needle
The position of L-needle
The position of idle
adjusting screw
Position: cylinder cover of
the unit
Engine Manual start.
Position: starter knob.
(1)
Carefully read owner’s
manual before operating
this machine.
(2)Wear head ,eye and ear
protection.
(3)Use the chain saw with
two hands; one handed
operation of the saw
can be dangerous.
(4)Warning ! kickback it’s
dangerous
(5)Warning
The words WARNING calls
attentions to an act or a
condition which can lead
to serious personal injury
or death.
(6) Chain brake operation.
(7) Do not expose to rain!
Do not operat
e the
machine on wet ground.
(8)
Circle and slash symbol
means whatever shown
is prohibited.
For safe operation and maintenance,
symbols are carved in relief on the
machine. According to these
indications, please be careful not to
take a mistake.
(a). The port to refuel the
“MIXGASOLINE”
Position: fuel tank cap
(b). The port to refuel the
“CHAIN OIL”
Position: oil cap
(c). The indication
regarding the switch.
Flipping the engine switch
to the “O”(STOP) direction,
the engine stops.
Position: rear-left of the
unit
(d). The indication regarding
the choke.
Pulling out the choke
knob, the choke closes.
Pushing in the choke knob,
the chock opens.
Position: rear-right of the
unit
(e). The indication regarding
the chain oil adjuster nut.
“MIN”direction-the oil
flow decrease
“MAX”direction-the oil
flow increase.
Position: starter case of the
unit.
(f). The position of H-needle
The position of L-needle
The position of idle
adjusting screw
Position: cylinder cover of
the unit
Engine Manual start.
Position: starter knob.
(1)
Carefully read owner’s
manual before operating
this machine.
(2)Wear head ,eye and ear
protection.
(3)Use the chain saw with
two hands; one handed
operation of the saw
can be dangerous.
(4)Warning ! kickback it’s
dangerous
(5)Warning
The words WARNING calls
attentions to an act or a
condition which can lead
to serious personal injury
or death.
(6) Chain brake operation.
(7) Do not expose to rain!
Do not operat
e the
machine on wet ground.
(8)
Circle and slash symbol
means whatever shown
is prohibited.
For safe operation and maintenance,
symbols are carved in relief on the
machine. According to these
indications, please be careful not to
take a mistake.
(a). The port to refuel the
“MIXGASOLINE”
Position: fuel tank cap
(b). The port to refuel the
“CHAIN OIL”
Position: oil cap
(c). The indication
regarding the switch.
Flipping the engine switch
to the “O”(STOP) direction,
the engine stops.
Position: rear-left of the
unit
(d). The indication regarding
the choke.
Pulling out the choke
knob, the choke closes.
Pushing in the choke knob,
the chock opens.
Position: rear-right of the
unit
(e). The indication regarding
the chain oil adjuster nut.
“MIN”direction-the oil
flow decrease
“MAX”direction-the oil
flow increase.
Position: starter case of the
unit.
(f). The position of H-needle
The position of L-needle
The position of idle
adjusting screw
Position: cylinder cover of
the unit
Engine Manual start.
Position: starter knob.
(1)
Carefully read owner’s
manual before operating
this machine.
(2)Wear head ,eye and ear
protection.
(3)Use the chain saw with
two hands; one handed
operation of the saw
can be dangerous.
(4)Warning ! kickback it’s
dangerous
(5)Warning
The words WARNING calls
attentions to an act or a
condition which can lead
to serious personal injury
or death.
(6) Chain brake operation.
(7) Do not expose to rain!
Do not operat
e the
machine on wet ground.
(8)
Circle and slash symbol
means whatever shown
is prohibited.
For safe operation and maintenance,
symbols are carved in relief on the
machine. According to these
indications, please be careful not to
take a mistake.
(a). The port to refuel the
“MIXGASOLINE”
Position: fuel tank cap
(b). The port to refuel the
“CHAIN OIL”
Position: oil cap
(c). The indication
regarding the switch.
Flipping the engine switch
to the “O”(STOP) direction,
the engine stops.
Position: rear-left of the
unit
(d). The indication regarding
the choke.
Pulling out the choke
knob, the choke closes.
Pushing in the choke knob,
the chock opens.
Position: rear-right of the
unit
(e). The indication regarding
the chain oil adjuster nut.
“MIN”direction-the oil
flow decrease
“MAX”direction-the oil
flow increase.
Position: starter case of the
unit.
(f). The position of H-needle
The position of L-needle
The position of idle
adjusting screw
Position: cylinder cover of
the unit
Engine Manual start.
Position: starter knob.
(1)
Carefully read owner’s
manual before operating
this machine.
(2)Wear head ,eye and ear
protection.
(3)Use the chain saw with
two hands; one handed
operation of the saw
can be dangerous.
(4)Warning ! kickback it’s
dangerous
(5)Warning
The words WARNING calls
attentions to an act or a
condition which can lead
to serious personal injury
or death.
(6) Chain brake operation.
(7) Do not expose to rain!
Do not operat
e the
machine on wet ground.
(8)
Circle and slash symbol
means whatever shown
is prohibited.
For safe operation and maintenance,
symbols are carved in relief on the
machine. According to these
indications, please be careful not to
take a mistake.
(a). The port to refuel the
“MIXGASOLINE”
Position: fuel tank cap
(b). The port to refuel the
“CHAIN OIL”
Position: oil cap
(c). The indication
regarding the switch.
Flipping the engine switch
to the “O”(STOP) direction,
the engine stops.
Position: rear-left of the
unit
(d). The indication regarding
the choke.
Pulling out the choke
knob, the choke closes.
Pushing in the choke knob,
the chock opens.
Position: rear-right of the
unit
(e). The indication regarding
the chain oil adjuster nut.
“MIN”direction-the oil
flow decrease
“MAX”direction-the oil
flow increase.
Position: starter case of the
unit.
(f). The position of H-needle
The position of L-needle
The position of idle
adjusting screw
Position: cylinder cover of
the unit
Engine Manual start.
Position: starter knob.
(1)
Carefully read owner’s
manual before operating
this machine.
(2)Wear head ,eye and ear
protection.
(3)Use the chain saw with
two hands; one handed
operation of the saw
can be dangerous.
(4)Warning ! kickback it’s
dangerous
(5)Warning
The words WARNING calls
attentions to an act or a
condition which can lead
to serious personal injury
or death.
(6) Chain brake operation.
(7) Do not expose to rain!
Do not operat
e the
machine on wet ground.
(8)
Circle and slash symbol
means whatever shown
is prohibited.
For safe operation and maintenance,
symbols are carved in relief on the
machine. According to these
indications, please be careful not to
take a mistake.
(a). The port to refuel the
“MIXGASOLINE”
Position: fuel tank cap
(b). The port to refuel the
“CHAIN OIL”
Position: oil cap
(c). The indication
regarding the switch.
Flipping the engine switch
to the “O”(STOP) direction,
the engine stops.
Position: rear-left of the
unit
(d). The indication regarding
the choke.
Pulling out the choke
knob, the choke closes.
Pushing in the choke knob,
the chock opens.
Position: rear-right of the
unit
(e). The indication regarding
the chain oil adjuster nut.
“MIN”direction-the oil
flow decrease
“MAX”direction-the oil
flow increase.
Position: starter case of the
unit.
(f). The position of H-needle
The position of L-needle
The position of idle
adjusting screw
Position: cylinder cover of
the unit
Engine Manual start.
Position: starter knob.
All manuals and user guides at all-guides.com
5
7. Be sure to keep this manual handy so that you
may refer to it later whenever any questions arise.
8. Always be sure to include this
manual when selling, lending, or
otherwise transferring the ownership
of this product.
9. Never allow children or anyone unable to fully
understand the directions given in this manual to
use this product.
WORKING GEAR AND CLOTHING
a. When using the product, you should wear
proper clothing and protective equipment as
follows.
WORK CLOTHES
1. Helmet.
2. Protection goggles or face protector.
3. Thick work gloves.
4. Non-slip-sole work boots.
5. Ear protectors.
EQUIPMENT YOU SHOULD CARRY WITH YOU
1. Attached tools and les.
2. Properly reserved fuel and chain oil.
3. Things to notify your working area
(Ropes, warning signs).
4. Whistle (for collaboration or
emergency).
5. Hatchet or saw (for removal of
obstacles).
6. Never use the product when wearing
sandals, or when barefoot.
WARNING CONSIDERING
HANDLING OF FUEL
a. The engine of this product is designed to run on a
mixed fuel which contains highly
ammable gasoline. Never store cans of fuel or rell
the fuel tank in any place where
there is a boiler, stove, wood
re, electrical sparks, welding
sparks, or any other source of
heat or re which might ignite the fuel.
b. Smoking while operating the product or relling
its fuel tank is extremely dangerous. Always be sure
to keep lit cigarettes away from the product at all
times.
■BEFORE USING THE MACHINE
a. Read this owner’s manual
carefully to understand how to
operate this unit properly.
b. You should never use the product
when under the influence of alcohol,
when suffering from exhaustion or
lack of sleep, when suffering from
drowsiness as a result of having
taken cold medicine, or at any other
time when a possibility exists that
your judgment might be impaired or
that you might not be able to operate
the machine properly and in a safe
manner.
c. Avoid running the engine indoors.
The exhaust gases contain harmful
carbon monoxide.
d. Never use the product under
circumstances like those described
below:
1. When the ground is slippery or
when other conditions exist which
might make it not possible to
maintain a steady posture.
2. At night, at times of heavy fog, or
at any other times when your field of
vision might be limited and it would
be difficult to gain a clear view of the
area.
3. During rain storms, during
lightning storms, at times of strong
or gale-force winds, or at any other
times when weather conditions
might make it unsafe to use this
product.
e. When using this product for the
first time, before beginning actual
work, learn to handling it from
skilled worker.
f. Lack of sleep, tiredness, or
physical exhaustion results in lower
attention spans, and this in turn
leads to accidents and injury. Limit
the amount of time of using the
machine continuously to
somewhere around 10 minutes pre
session, and take 10-20 minutes of
rest between work sessions. Also
try to keep the total amount of work
performed in a single day under 2
hours or less.
g. Be sure to keep this manual
handy so that you may refer to it
later whenever any questions arise.
h. Always be sure to include this
manual when selling, lending, or
otherwise transferring the
ownership of this product.
i. Never allow children or anyone
unable to fully understand the
directions given in this manual to
use this product.
■WORKING GEAR AND CLOTHING
a. When using the product, you
should wear proper clothing and
protective equipment as follows.
WORK CLOTHES
(1) Helmet
(2) Protection goggles or face
protector
(3) Thick work gloves
(4) Non-slip-sole work boots
(5) Ear protectors
b. And you should carry with you.
1. Attached tools and files.
2.Properly reserved fuel and chain
oil.
3.Things to notify your working area
(Rope,
warning signs)
4.Whistle (for collaboration or
emergency)
5.Hatchet or saw (for removal of
obstacles)
c. Never use the product when
wearing pants with
loose cuffs, when wearing sandals,
or when barefoot.
1. Read this owner’s manual
carefully to understand how
to operate this unit properly.
2. You should never use the
product when under the
inuence of alcohol, when
suffering from exhaustion or
lack of sleep, when suffering from
drowsiness as a result of having taken
cold medicine, or at any other time when
a possibility exists that your judgment
might be impaired or that you might not
be able to operate the machine properly
and in a safe manner.
3. Avoid running the engine
indoors. The exhaust gases
contain harmful carbon
monoxide.
4. Never use the product under
circumstances like those described below:
a. When the ground is slippery or when
other conditions exist which might make it
not possible to maintain a steady posture.
b. At night, at times of heavy fog, or at any
other times when your eld of vision might
be limited and it would be difcult to gain a
clear view of the area.
c. During rain storms, during lightning
storms, at times of strong or gale-force
winds, or at any other times when weather
conditions might make it unsafe to use this
product.
5. When using this product for the rst
time, before beginning actual work, learn to
handle the machine from a skilled worker.
6. Lack of sleep, tiredness, or physical
exhaustion results in lower attention spans,
and this in time can lead to accidents and
injury. Limit the amount of time using the
machine continuously to somewhere around
10 minutes per session, and take 10-20
minutes of rest between work sessions.
Also try to keep the total amount of work
performed in a single day under 2 hours or
less.
BEFORE USING THE MACHINE
■BEFORE USING THE MACHINE
a. Read this owner’s manual
carefully to understand how to
operate this unit properly.
b. You should never use the product
when under the influence of alcohol,
when suffering from exhaustion or
lack of sleep, when suffering from
drowsiness as a result of having
taken cold medicine, or at any other
time when a possibility exists that
your judgment might be impaired or
that you might not be able to operate
the machine properly and in a safe
manner.
c. Avoid running the engine indoors.
The exhaust gases contain harmful
carbon monoxide.
d. Never use the product under
circumstances like those described
below:
1. When the ground is slippery or
when other conditions exist which
might make it not possible to
maintain a steady posture.
2. At night, at times of heavy fog, or
at any other times when your field of
vision might be limited and it would
be difficult to gain a clear view of the
area.
3. During rain storms, during
lightning storms, at times of strong
or gale-force winds, or at any other
times when weather conditions
might make it unsafe to use this
product.
e. When using this product for the
first time, before beginning actual
work, learn to handling it from
skilled worker.
f. Lack of sleep, tiredness, or
physical exhaustion results in lower
attention spans, and this in turn
leads to accidents and injury. Limit
the amount of time of using the
machine continuously to
somewhere around 10 minutes pre
session, and take 10-20 minutes of
rest between work sessions. Also
try to keep the total amount of work
performed in a single day under 2
hours or less.
g. Be sure to keep this manual
handy so that you may refer to it
later whenever any questions arise.
h. Always be sure to include this
manual when selling, lending, or
otherwise transferring the
ownership of this product.
i. Never allow children or anyone
unable to fully understand the
directions given in this manual to
use this product.
■WORKING GEAR AND CLOTHING
a. When using the product, you
should wear proper clothing and
protective equipment as follows.
WORK CLOTHES
(1) Helmet
(2) Protection goggles or face
protector
(3) Thick work gloves
(4) Non-slip-sole work boots
(5) Ear protectors
b. And you should carry with you.
1. Attached tools and files.
2.Properly reserved fuel and chain
oil.
3.Things to notify your working area
(Rope,
warning signs)
4.Whistle (for collaboration or
emergency)
5.Hatchet or saw (for removal of
obstacles)
c. Never use the product when
wearing pants with
loose cuffs, when wearing sandals,
or when barefoot.
■BEFORE USING THE MACHINE
a. Read this owner’s manual
carefully to understand how to
operate this unit properly.
b. You should never use the product
when under the influence of alcohol,
when suffering from exhaustion or
lack of sleep, when suffering from
drowsiness as a result of having
taken cold medicine, or at any other
time when a possibility exists that
your judgment might be impaired or
that you might not be able to operate
the machine properly and in a safe
manner.
c. Avoid running the engine indoors.
The exhaust gases contain harmful
carbon monoxide.
d. Never use the product under
circumstances like those described
below:
1. When the ground is slippery or
when other conditions exist which
might make it not possible to
maintain a steady posture.
2. At night, at times of heavy fog, or
at any other times when your field of
vision might be limited and it would
be difficult to gain a clear view of the
area.
3. During rain storms, during
lightning storms, at times of strong
or gale-force winds, or at any other
times when weather conditions
might make it unsafe to use this
product.
e. When using this product for the
first time, before beginning actual
work, learn to handling it from
skilled worker.
f. Lack of sleep, tiredness, or
physical exhaustion results in lower
attention spans, and this in turn
leads to accidents and injury. Limit
the amount of time of using the
machine continuously to
somewhere around 10 minutes pre
session, and take 10-20 minutes of
rest between work sessions. Also
try to keep the total amount of work
performed in a single day under 2
hours or less.
g. Be sure to keep this manual
handy so that you may refer to it
later whenever any questions arise.
h. Always be sure to include this
manual when selling, lending, or
otherwise transferring the
ownership of this product.
i. Never allow children or anyone
unable to fully understand the
directions given in this manual to
use this product.
■WORKING GEAR AND CLOTHING
a. When using the product, you
should wear proper clothing and
protective equipment as follows.
WORK CLOTHES
(1) Helmet
(2) Protection goggles or face
protector
(3) Thick work gloves
(4) Non-slip-sole work boots
(5) Ear protectors
b. And you should carry with you.
1. Attached tools and files.
2.Properly reserved fuel and chain
oil.
3.Things to notify your working area
(Rope,
warning signs)
4.Whistle (for collaboration or
emergency)
5.Hatchet or saw (for removal of
obstacles)
c. Never use the product when
wearing pants with
loose cuffs, when wearing sandals,
or when barefoot.
■BEFORE USING THE MACHINE
a. Read this owner’s manual
carefully to understand how to
operate this unit properly.
b. You should never use the product
when under the influence of alcohol,
when suffering from exhaustion or
lack of sleep, when suffering from
drowsiness as a result of having
taken cold medicine, or at any other
time when a possibility exists that
your judgment might be impaired or
that you might not be able to operate
the machine properly and in a safe
manner.
c. Avoid running the engine indoors.
The exhaust gases contain harmful
carbon monoxide.
d. Never use the product under
circumstances like those described
below:
1. When the ground is slippery or
when other conditions exist which
might make it not possible to
maintain a steady posture.
2. At night, at times of heavy fog, or
at any other times when your field of
vision might be limited and it would
be difficult to gain a clear view of the
area.
3. During rain storms, during
lightning storms, at times of strong
or gale-force winds, or at any other
times when weather conditions
might make it unsafe to use this
product.
e. When using this product for the
first time, before beginning actual
work, learn to handling it from
skilled worker.
f. Lack of sleep, tiredness, or
physical exhaustion results in lower
attention spans, and this in turn
leads to accidents and injury. Limit
the amount of time of using the
machine continuously to
somewhere around 10 minutes pre
session, and take 10-20 minutes of
rest between work sessions. Also
try to keep the total amount of work
performed in a single day under 2
hours or less.
g. Be sure to keep this manual
handy so that you may refer to it
later whenever any questions arise.
h. Always be sure to include this
manual when selling, lending, or
otherwise transferring the
ownership of this product.
i. Never allow children or anyone
unable to fully understand the
directions given in this manual to
use this product.
■WORKING GEAR AND CLOTHING
a. When using the product, you
should wear proper clothing and
protective equipment as follows.
WORK CLOTHES
(1) Helmet
(2) Protection goggles or face
protector
(3) Thick work gloves
(4) Non-slip-sole work boots
(5) Ear protectors
b. And you should carry with you.
1. Attached tools and files.
2.Properly reserved fuel and chain
oil.
3.Things to notify your working area
(Rope,
warning signs)
4.Whistle (for collaboration or
emergency)
5.Hatchet or saw (for removal of
obstacles)
c. Never use the product when
wearing pants with
loose cuffs, when wearing sandals,
or when barefoot.
■BEFORE USING THE MACHINE
a. Read this owner’s manual
carefully to understand how to
operate this unit properly.
b. You should never use the product
when under the influence of alcohol,
when suffering from exhaustion or
lack of sleep, when suffering from
drowsiness as a result of having
taken cold medicine, or at any other
time when a possibility exists that
your judgment might be impaired or
that you might not be able to operate
the machine properly and in a safe
manner.
c. Avoid running the engine indoors.
The exhaust gases contain harmful
carbon monoxide.
d. Never use the product under
circumstances like those described
below:
1. When the ground is slippery or
when other conditions exist which
might make it not possible to
maintain a steady posture.
2. At night, at times of heavy fog, or
at any other times when your field of
vision might be limited and it would
be difficult to gain a clear view of the
area.
3. During rain storms, during
lightning storms, at times of strong
or gale-force winds, or at any other
times when weather conditions
might make it unsafe to use this
product.
e. When using this product for the
first time, before beginning actual
work, learn to handling it from
skilled worker.
f. Lack of sleep, tiredness, or
physical exhaustion results in lower
attention spans, and this in turn
leads to accidents and injury. Limit
the amount of time of using the
machine continuously to
somewhere around 10 minutes pre
session, and take 10-20 minutes of
rest between work sessions. Also
try to keep the total amount of work
performed in a single day under 2
hours or less.
g. Be sure to keep this manual
handy so that you may refer to it
later whenever any questions arise.
h. Always be sure to include this
manual when selling, lending, or
otherwise transferring the
ownership of this product.
i. Never allow children or anyone
unable to fully understand the
directions given in this manual to
use this product.
■WORKING GEAR AND CLOTHING
a. When using the product, you
should wear proper clothing and
protective equipment as follows.
WORK CLOTHES
(1) Helmet
(2) Protection goggles or face
protector
(3) Thick work gloves
(4) Non-slip-sole work boots
(5) Ear protectors
b. And you should carry with you.
1. Attached tools and files.
2.Properly reserved fuel and chain
oil.
3.Things to notify your working area
(Rope,
warning signs)
4.Whistle (for collaboration or
emergency)
5.Hatchet or saw (for removal of
obstacles)
c. Never use the product when
wearing pants with
loose cuffs, when wearing sandals,
or when barefoot.
■BEFORE USING THE MACHINE
a. Read this owner’s manual
carefully to understand how to
operate this unit properly.
b. You should never use the product
when under the influence of alcohol,
when suffering from exhaustion or
lack of sleep, when suffering from
drowsiness as a result of having
taken cold medicine, or at any other
time when a possibility exists that
your judgment might be impaired or
that you might not be able to operate
the machine properly and in a safe
manner.
c. Avoid running the engine indoors.
The exhaust gases contain harmful
carbon monoxide.
d. Never use the product under
circumstances like those described
below:
1. When the ground is slippery or
when other conditions exist which
might make it not possible to
maintain a steady posture.
2. At night, at times of heavy fog, or
at any other times when your field of
vision might be limited and it would
be difficult to gain a clear view of the
area.
3. During rain storms, during
lightning storms, at times of strong
or gale-force winds, or at any other
times when weather conditions
might make it unsafe to use this
product.
e. When using this product for the
first time, before beginning actual
work, learn to handling it from
skilled worker.
f. Lack of sleep, tiredness, or
physical exhaustion results in lower
attention spans, and this in turn
leads to accidents and injury. Limit
the amount of time of using the
machine continuously to
somewhere around 10 minutes pre
session, and take 10-20 minutes of
rest between work sessions. Also
try to keep the total amount of work
performed in a single day under 2
hours or less.
g. Be sure to keep this manual
handy so that you may refer to it
later whenever any questions arise.
h. Always be sure to include this
manual when selling, lending, or
otherwise transferring the
ownership of this product.
i. Never allow children or anyone
unable to fully understand the
directions given in this manual to
use this product.
■WORKING GEAR AND CLOTHING
a. When using the product, you
should wear proper clothing and
protective equipment as follows.
WORK CLOTHES
(1) Helmet
(2) Protection goggles or face
protector
(3) Thick work gloves
(4) Non-slip-sole work boots
(5) Ear protectors
b. And you should carry with you.
1. Attached tools and files.
2.Properly reserved fuel and chain
oil.
3.Things to notify your working area
(Rope,
warning signs)
4.Whistle (for collaboration or
emergency)
5.Hatchet or saw (for removal of
obstacles)
c. Never use the product when
wearing pants with
loose cuffs, when wearing sandals,
or when barefoot.
All manuals and user guides at all-guides.com
6
WARNING CONSIDERING
HANDLING OF FUEL (CONTINUED)
c. When relling the tank always turn off the
engine rst and take a careful look around to
make sure that there are no sparks or open
ames anywhere nearby before refuelling.
d. If any fuel spillage occurs during refuelling,
use a dry rag to wipe up spills before turning the
engine back on again.
e. After refuelling, screw the fuel cap back
tightly onto the fuel tank and then carry the
product to a spot 3m or more away from
where it was refuelled before turning on the
engine.
BEFORE STARTING ENGINE
• Check working place, the cutting object and
cutting direction. It there is obstacle, remove
it.
• Never start cutting until you have a clear
work area, secure footing and a planned
retreat path from the falling tree.
• Use caution and keep bystanders and
animals out of the working area whose
diameter is 2.5 times of the cutting object.
• Inspect the machine for worn, loose, or
damaged parts. Never operate the machine
that is damaged, improperly adjusted, or
is not completely and securely assembled.
Make sure that the saw chain stops moving
when the throttle control trigger is released.
WHEN STARTING THE ENGINE
• Always hold the machine rmly with both
hands when the engine is running.
• Use a rm grip with thumb and ngers
encircling the handles.
• Keep all parts of your body away from the
machine when the engine is running.
• Before starting the engine, make sure the
saw chain is not contacting anything.
OPERATION
• Keep the handles dry, clean and free of oil or
fuel mixture.
• Never touch the mufer, spark plug or other
metallic parts of the engine while the engine is
in operation or immediately after stopping the
engine. Doing so could result in serious burns
or electrical shock. Use extreme caution when
cutting small size brush and saplings because
slender material may catch the saw chain and
be whipped towards you or pull you
off balance.
• When cutting a limb that is under tension, be
alert for spring back so that you will not be
struck when the tension in the wood bres is
released.
• Check the tree for dead branches
that could fall during the felling
operation.
• Always shut of the engine before setting it
down.
KICKBACK SAFETY
PRECAUTIONS FOR CHAIN SAW
USERS
WARNING
Kickback may occur when the nose or tip of the
guide bar touches an object, or when the wood
closes in and pinches the saw chain in the cut.
Tip contact in some cases may cause a lightning-
fast reverse reaction, kicking the guide bar up
and back toward the operator. Pinching the saw
chain along the top of the guide bar may push the
guide bar rapidly back toward the operator. Either
of these reactions may cause you to lose control
of the saw, which could result in serious personal
injury.
Do not rely exclusively upon the safety devices
built into your saw. As a chain saw user, you
should take several steps to keep your cutting jobs
free from accident or injury.
1. With a basic understanding of kickback, you
can reduce or eliminate the element of
surprise. Sudden surprise contributes to accidents;
■
WARNING CONSIDERING
HANDLING OF FUEL
a. The engine of this product is
designed to run on a mixed fuel
which contains highly flammable
gasoline. Never store cans of fuel or
refill the fuel tank in any place where
there is a boiler, stove, wood fire,
electrical sparks, welding sparks, or
any other source of heat or fire
which might ignite the fuel.
b. Smoking while operating the
product or refilling its fuel tank is
extremely dangerous. Always be
sure to keep lit cigarettes away from
the product at all times.
c. When refilling the tank always
turn off the engine first and take a
careful look around to make sure
that there are no sparks or open
flames anywhere nearby before
refueling.
d. If any fuel spillage occurs during
refueling, use a dry rag to wipe up
spills before turning the engine back
on again.
e. After refueling, screw the fuel cap
back tightly onto the fuel tank and
then carry the product to a spot 3m
or more away from where it was
refueled before turning on the
engine.
■
BEFORE STARTING ENGINE
·
Check working place, the cutting
object and cutting direction. It there
is obstacle, remove it.
·
Never start cutting until you have a
clear work area, secure footing and
a planned retreat path from the
falling tree.
·
Use caution and keep bystanders
and animals out of the working area
whose diameter is 2.5 times of the
cutting object.
·Inspect the machine for worn,
loose, or damaged parts. Never
operate the machine that is
damaged, improperly adjusted, or
is not completely and securely
assembled. Make sure that the
saw chain stops moving when the
throttle control trigger is released.
■WHEN STARTING THE ENGINE
·Always hold the machine firmly
with both hands when the engine
is running.
·Use a firm grip with thumb and
fingers encircling the handles.
·Keep all parts of your body away
from the machine when the engine
is running.
Before starting the engine, make
sure the saw chain is not
contacting anything.
■OPERATION
·Keep the handles dry, clean and
free of oil or fuel mixture.
·Never touch the muffler, spark
plug or other metallic parts of the
engine while the engine is in
operation or immediately after
stopping the engine. Doing so
could result in serious burns or
electrical shock.
·Use extreme caution when
cutting small size brush and
saplings because slender material
may catch the saw chain and be
whipped toward you or pull you
off balance.
·When cutting a limb that is under
tension, be alert for spring back
so that you will not be struck
when the tension in the wood
fibers is released.
·Check the tree for dead branches
that could fall during the felling
operation.
·Always shut of the engine before
setting it down.
■
WARNING CONSIDERING
HANDLING OF FUEL
a. The engine of this product is
designed to run on a mixed fuel
which contains highly flammable
gasoline. Never store cans of fuel or
refill the fuel tank in any place where
there is a boiler, stove, wood fire,
electrical sparks, welding sparks, or
any other source of heat or fire
which might ignite the fuel.
b. Smoking while operating the
product or refilling its fuel tank is
extremely dangerous. Always be
sure to keep lit cigarettes away from
the product at all times.
c. When refilling the tank always
turn off the engine first and take a
careful look around to make sure
that there are no sparks or open
flames anywhere nearby before
refueling.
d. If any fuel spillage occurs during
refueling, use a dry rag to wipe up
spills before turning the engine back
on again.
e. After refueling, screw the fuel cap
back tightly onto the fuel tank and
then carry the product to a spot 3m
or more away from where it was
refueled before turning on the
engine.
■
BEFORE STARTING ENGINE
·
Check working place, the cutting
object and cutting direction. It there
is obstacle, remove it.
·
Never start cutting until you have a
clear work area, secure footing and
a planned retreat path from the
falling tree.
·
Use caution and keep bystanders
and animals out of the working area
whose diameter is 2.5 times of the
cutting object.
·
Inspect the machine for worn,
loose, or damaged parts. Never
operate the machine that is
damaged, improperly adjusted, or
is not completely and securely
assembled. Make sure that the
saw chain stops moving when the
throttle control trigger is released.
■
WHEN STARTING THE ENGINE
·
Always hold the machine firmly
with both hands when the engine
is running.
·
Use a firm grip with thumb and
fingers encircling the handles.
·
Keep all parts of your body away
from the machine when the engine
is running.
Before starting the engine, make
sure the saw chain is not
contacting anything.
■
OPERATION
·
Keep the handles dry, clean and
free of oil or fuel mixture.
·
Never touch the muffler, spark
plug or other metallic parts of the
engine while the engine is in
operation or immediately after
stopping the engine. Doing so
could result in serious burns or
electrical shock.
·
Use extreme caution when
cutting small size brush and
saplings because slender material
may catch the saw chain and be
whipped toward you or pull you
off balance.
·
When cutting a limb that is under
tension, be alert for spring back
so that you will not be struck
when the tension in the wood
fibers is released.
·
Check the tree for dead branches
that could fall during the felling
operation.
·
Always shut of the engine before
setting it down.
All manuals and user guides at all-guides.com
all-guides.com
7
KICKBACK SAFETY
PRECAUTIONS FOR CHAIN
SAW USERS (CONTINUED)
WARNING
2. Keep a good rm grip on the saw with both
hands, the right hand on the rear handle and
the left hand on the front handle, when the
engine is running. Use a rm grip with thumbs
and ngers encircling the chain saw handles.
A rm grip will help you reduce kickback and
maintain control of the saw;
3. Make certain that the area in which you are
cutting is free from obstructions. Do not let the
nose of the guide bar contact a log, branch, or
any other obstruction that could be hit while
you are operating the saw;
4. Cut at high engine speeds;
5. Do not overreach or cut above
shoulder height;
6. Follow the manufacturer’s sharpening and
maintenance instructions for the saw chain;
7. Only use replacement bars and chains
specied by the manufacturer or the equivalent.
MAINTENANCE
• In order to maintain your product in proper
working order, perform the maintenance and
checking operations described in the manual
at regular intervals.
• Always be sure to turn off the engine before
performing any maintenance or checking
procedures.
WARNING
• The metallic parts reach high temperatures
immediately after stopping the engine.
• Leave all maintenance other than
the items listed in the Owner’s
Manual to your competent
servicing dealer.
TRANSPORTATION
• Always carry the unit with the engine
stopped, the guide bar covered with the
protector to the rare, and mufer away from
your body.
MAINTENANCE
• In order to maintain your product in proper
working order, perform the maintenance and
checking operations described in the manual
at regular intervals.
• Always be sure to turn off the engine before
performing any maintenance or checking
procedures.
WARNING
• The metallic parts reach high temperatures
immediately after stopping the engine.
• Leave all maintenance other than the
items listed in the Owner’s Manual to your
competent servicing dealer.
TRANSPORTATION
• Always carry the unit with the engine
stopped, the guide bar covered with the
protector to the rare, and mufer away from
your body.
WARNING
Open the box and install the guide bar and the
saw chain on the power unit as follows:
The saw chain has very sharp edges. Use thick
protective gloves for safety.
1. Install the attached spike to the power unit.
(F1.1)
2. Install the paper gasket onto the guide plate.
(F1.2)
3. Gear the chain to the sprocket and, while
tting the saw chain around the guide bar,
mount the guide bar to the power unit. Adjust
the position of chain tension nut on the chain
cover to the lower hole of guide bar. (F1.3)
a. Tension nut.
b. Chain cover.
■KICKBACK SAFETY PRECAUTIONS
FOR CHAIN SAW USERS
WARNING
Kickback may occur when the nose or
tip of the guide bar touches an object, or
when the wood closes in and pinches
the saw chain in the cut. Tip contact in
some cases may cause a lightning-fast
reverse reaction, kicking the guide bar
up and back toward the operator.
Pinching the saw chain along the top of
the guide bar may push the guide bar
rapidly back toward the operator. Either
of these reactions may cause you to
lose control of the saw, which could
result in serious personal injury.
Do not rely exclusively upon the safety
devices built into your saw. As a chain
saw user, you should take several steps
to keep your cutting jobs free from
accident or injury.
（
1
）
With a basic understanding of
kickback, you can reduce or
eliminate the element of
surprise. Sudden surprise
contributes to accidents;
（
2
）
Keep a good firm grip on the
saw with both hands, the right
hand on the rear handle and
the left hand on the front
handle, when the engine is
running. Use a firm grip with
thumbs and fingers encircling
the chain saw handles. A firm
grip will help you reduce
kickback and maintain control
of the saw.
（
3
）
Make certain that the area in
which you are cutting is free
from obstructions. Do not let
the nose of the guide bar
contact a log, branch, or any
other obstruction that could be
hit while you are operating the
saw;
（
4
）
Cut at high engine speeds;
（
5
）
Do not overreach or cut above
shoulder height;
（6）Follow the manufacturer's
sharpening and maintenance
instructions for the saw chain;
（7）Only use replacement bars and
chains specified by the manufacturer
or the equivalent.
■MAINTENANCE
·In order to maintain your product in
proper working order, perform the
maintenance and checking operations
described in the manual at regular
intervals.
Always be sure to turn off the engine
·before performing any maintenance or
checking procedures.
WARNING
The metallic parts reach high
temperatures immediately after
stopping the engine.
·Leave all maintenance other than the
items listed in the Owner’s Manual to
your competent servicing dealer.
■TRANSPORTATION
·Always carry the unit with the engine
stopped, the guide bar covered with the
protector to the rare, and muffler away
from your body.
All manuals and user guides at all-guides.com
8
NOTE
Pay attention to the correct direction of the saw
chain. (F2)
4. Fit the chain cover to the power unit and
fasten the nuts to nger tightness.
5. While holding up the tip of the bar, adjust the
chain tension by turning the tension screw until
the tie straps just touch the bottom side of the
bar rail. (F3, F4)
6. Tighten the nuts securely with the bar tip
held up (12-15N.m). Then check the chain
for smooth rotation and proper tension while
moving it by hand. If necessary, readjust with
the chain cover loose.
7. Tighten the tension screw
a. Loosen.
b. Tighten.
c. Tension screw.
NOTE
A new chain will expand its length in the
beginning of use. Check and readjust the
tension frequently as a loose chain can easily
derail or cause rapid wear of itself and the guide
bar.
FUEL
Mix a regular grade gasoline and a quality-
proven 2 stroke oil for air cooled 2 cycle
engines.
Recommended mixing ratio:
Condition Gasoline: Oil
Up to 20 hours use 20:1
After 20 hours use 25:1
25 = 1 Mix Chart
Gasoline litres 1 2 3 4 5
2-cycle oil ml. 40 80 120 160 200
WARNING
Keep open ames away from the area where
fuel is handled or stored.
Mix and store fuel only in an approved gasoline
container.
NOTE
Most engine troubles are caused, directly or
indirectly, by the fuel used on the machine. Take
special care not to mix a motor oil for 4 cycle
engines.
CHAIN OIL
Use good quality bar and chain oil.
NOTE
Do not use wasted or regenerated oil that can
cause damage to the oil pump.
STARTING ENGINE
1. Fill fuel and chain oil tanks respectively, and
tighten the caps securely. (F7)
2. Put the switch to “I” position. (F8)
3. Pull the choke knob out to close choke. (F9)
4. Pull the starter handle several times until rst
ring sound is heard. Push the choke knob all
the way in to open the choke. Pull the starter
handle again until engine run. (F10)
5. Push the throttle lever and throttle inter lock
once and loosen it make the engine run at idle
speed.(F11)
6. To stop the engine, push the engine switch
to stop (o) position.
NOTE
When restarting immediately after stopping
the engine, leave the choke knob at the open
position.
7. While holding the saw unit securely on the
ground, pull the starter rope vigorously. (F12)
Open the box and install the guide bar
and the saw chain on the power unit as
follows:
The saw chain has very sharp edges. Use
thick protective gloves for safety.
1.Install the attached spike to the power
unit.(F1.1)
2.Install the paper gasket onto the guide
plate. (F1.2)
3.Gear the chain to the sprocket and,
while fitting the saw chain around the
guide bar, mount the guide bar to the
power unit. Adjust the position of chain
tension nut on the chain cover to the
lower hole of guide bar. (F1.3)
(1) Tension nut
(2) Chain cover
NOTE
Pay attention to the correct direction of
the saw chain. (F2)
(1) Moving Direction
4.Fit the chain cover to the power unit
and fasten the nuts to finger tightness.
5.While holding up the tip of the bar,
adjust the chain tension by turning the
tension screw until the tie straps just
touch the bottom side of the bar rail.
(F4)
6.Tighten the nuts securely with the bar
tip held up (12-15N.m). Then check the
chain for smooth rotation and proper
tension while moving it by hand. If
necessary, readjust with the chain cover
loose.
7.Tighten the tension screw
(1) Loosen
(2) Tighten
(3) Tension screw
NOTE
A new chain will expand its length in the
beginning of use. Check and readjust the
tension frequently as a loose chain can
easily derail or cause rapid wear of itself
and the guide bar.
■FUEL
Mix a regular grade gasoline (leaded or
unleaded, alcohol-free) and a
quality-proven motor oil for air cooled 2
cycle engines.
Motor oil: Recommended use JASO 2T FC
grade lubrants or above.
Recommended mixing ratio:
Condition Gasoline: Oil
Up to 20 hours use 20:1
After 20 hours use 25:1
25
：
1 Mix Chart
Gasoline liters 1 2 3 4 5
2-cycle oil ml. 40 80 120 160 200
Keep open flames away from the area
where fuel is handled or stored.
Mix and store fuel only in an approved
gasoline container.
NOTE
Most engine troubles are caused, directly or
indirectly, by the fuel used on the machine.
Take special care not to mix a motor oil for
4 cycle engines.
■CHAIN OIL
Use motor oil SAE 20 # in summer and SAE
#10 in winter.
NOTE
Do not use wasted or regenerated oil that
can cause damage to the oil pump.
f
Open the box and install the guide bar
and the saw chain on the power unit as
follows:
The saw chain has very sharp edges. Use
thick protective gloves for safety.
1.Install the attached spike to the power
unit.(F1.1)
2.Install the paper gasket onto the guide
plate. (F1.2)
3.Gear the chain to the sprocket and,
while fitting the saw chain around the
guide bar, mount the guide bar to the
power unit. Adjust the position of chain
tension nut on the chain cover to the
lower hole of guide bar. (F1.3)
(1) Tension nut
(2) Chain cover
NOTE
Pay attention to the correct direction of
the saw chain. (F2)
(1) Moving Direction
4.Fit the chain cover to the power unit
and fasten the nuts to finger tightness.
5.While holding up the tip of the bar,
adjust the chain tension by turning the
tension screw until the tie straps just
touch the bottom side of the bar rail.
(F4)
6.Tighten the nuts securely with the bar
tip held up (12-15N.m). Then check the
chain for smooth rotation and proper
tension while moving it by hand. If
necessary, readjust with the chain cover
loose.
7.Tighten the tension screw
(1) Loosen
(2) Tighten
(3) Tension screw
NOTE
A new chain will expand its length in the
beginning of use. Check and readjust the
tension frequently as a loose chain can
easily derail or cause rapid wear of itself
and the guide bar.
■FUEL
Mix a regular grade gasoline (leaded or
unleaded, alcohol-free) and a
quality-proven motor oil for air cooled 2
cycle engines.
Motor oil: Recommended use JASO 2T FC
grade lubrants or above.
Recommended mixing ratio:
Condition Gasoline: Oil
Up to 20 hours use 20:1
After 20 hours use 25:1
25
：
1 Mix Chart
Gasoline liters 1 2 3 4 5
2-cycle oil ml. 40 80 120 160 200
Keep open flames away from the area
where fuel is handled or stored.
Mix and store fuel only in an approved
gasoline container.
NOTE
Most engine troubles are caused, directly or
indirectly, by the fuel used on the machine.
Take special care not to mix a motor oil for
4 cycle engines.
■CHAIN OIL
Use motor oil SAE 20 # in summer and SAE
#10 in winter.
NOTE
Do not use wasted or regenerated oil that
can cause damage to the oil pump.
f
Open the box and install the guide bar
and the saw chain on the power unit as
follows:
The saw chain has very sharp edges. Use
thick protective gloves for safety.
1.Install the attached spike to the power
unit.(F1.1)
2.Install the paper gasket onto the guide
plate. (F1.2)
3.Gear the chain to the sprocket and,
while fitting the saw chain around the
guide bar, mount the guide bar to the
power unit. Adjust the position of chain
tension nut on the chain cover to the
lower hole of guide bar. (F1.3)
(1) Tension nut
(2) Chain cover
NOTE
Pay attention to the correct direction of
the saw chain. (F2)
(1) Moving Direction
4.Fit the chain cover to the power unit
and fasten the nuts to finger tightness.
5.While holding up the tip of the bar,
adjust the chain tension by turning the
tension screw until the tie straps just
touch the bottom side of the bar rail.
(F4)
6.Tighten the nuts securely with the bar
tip held up (12-15N.m). Then check the
chain for smooth rotation and proper
tension while moving it by hand. If
necessary, readjust with the chain cover
loose.
7.Tighten the tension screw
(1) Loosen
(2) Tighten
(3) Tension screw
NOTE
A new chain will expand its length in the
beginning of use. Check and readjust the
tension frequently as a loose chain can
easily derail or cause rapid wear of itself
and the guide bar.
■FUEL
Mix a regular grade gasoline (leaded or
unleaded, alcohol-free) and a
quality-proven motor oil for air cooled 2
cycle engines.
Motor oil: Recommended use JASO 2T FC
grade lubrants or above.
Recommended mixing ratio:
Condition Gasoline: Oil
Up to 20 hours use 20:1
After 20 hours use 25:1
25
：
1 Mix Chart
Gasoline liters 1 2 3 4 5
2-cycle oil ml. 40 80 120 160 200
Keep open flames away from the area
where fuel is handled or stored.
Mix and store fuel only in an approved
gasoline container.
NOTE
Most engine troubles are caused, directly or
indirectly, by the fuel used on the machine.
Take special care not to mix a motor oil for
4 cycle engines.
■CHAIN OIL
Use motor oil SAE 20 # in summer and SAE
#10 in winter.
NOTE
Do not use wasted or regenerated oil that
can cause damage to the oil pump.
f
F1.1
F1.2 F1.3
Open the box and install the guide bar
and the saw chain on the power unit as
follows:
The saw chain has very sharp edges. Use
thick protective gloves for safety.
1.Install the attached spike to the power
unit.(F1.1)
2.Install the paper gasket onto the guide
plate. (F1.2)
3.Gear the chain to the sprocket and,
while fitting the saw chain around the
guide bar, mount the guide bar to the
power unit. Adjust the position of chain
tension nut on the chain cover to the
lower hole of guide bar. (F1.3)
(1) Tension nut
(2) Chain cover
NOTE
Pay attention to the correct direction of
the saw chain. (F2)
(1) Moving Direction
4.Fit the chain cover to the power unit
and fasten the nuts to finger tightness.
5.While holding up the tip of the bar,
adjust the chain tension by turning the
tension screw until the tie straps just
touch the bottom side of the bar rail.
(F4)
6.Tighten the nuts securely with the bar
tip held up (12-15N.m). Then check the
chain for smooth rotation and proper
tension while moving it by hand. If
necessary, readjust with the chain cover
loose.
7.Tighten the tension screw
(1) Loosen
(2) Tighten
(3) Tension screw
NOTE
A new chain will expand its length in the
beginning of use. Check and readjust the
tension frequently as a loose chain can
easily derail or cause rapid wear of itself
and the guide bar.
■FUEL
Mix a regular grade gasoline (leaded or
unleaded, alcohol-free) and a
quality-proven motor oil for air cooled 2
cycle engines.
Motor oil: Recommended use JASO 2T FC
grade lubrants or above.
Recommended mixing ratio:
Condition Gasoline: Oil
Up to 20 hours use 20:1
After 20 hours use 25:1
25
：
1 Mix Chart
Gasoline liters 1 2 3 4 5
2-cycle oil ml. 40 80 120 160 200
Keep open flames away from the area
where fuel is handled or stored.
Mix and store fuel only in an approved
gasoline container.
NOTE
Most engine troubles are caused, directly or
indirectly, by the fuel used on the machine.
Take special care not to mix a motor oil for
4 cycle engines.
■CHAIN OIL
Use motor oil SAE 20 # in summer and SAE
#10 in winter.
NOTE
Do not use wasted or regenerated oil that
can cause damage to the oil pump.
f
Open the box and install the guide bar
and the saw chain on the power unit as
follows:
The saw chain has very sharp edges. Use
thick protective gloves for safety.
1.Install the attached spike to the power
unit.(F1.1)
2.Install the paper gasket onto the guide
plate. (F1.2)
3.Gear the chain to the sprocket and,
while fitting the saw chain around the
guide bar, mount the guide bar to the
power unit. Adjust the position of chain
tension nut on the chain cover to the
lower hole of guide bar. (F1.3)
(1) Tension nut
(2) Chain cover
NOTE
Pay attention to the correct direction of
the saw chain. (F2)
(1) Moving Direction
4.Fit the chain cover to the power unit
and fasten the nuts to finger tightness.
5.While holding up the tip of the bar,
adjust the chain tension by turning the
tension screw until the tie straps just
touch the bottom side of the bar rail.
(F4)
6.Tighten the nuts securely with the bar
tip held up (12-15N.m). Then check the
chain for smooth rotation and proper
tension while moving it by hand. If
necessary, readjust with the chain cover
loose.
7.Tighten the tension screw
(1) Loosen
(2) Tighten
(3) Tension screw
NOTE
A new chain will expand its length in the
beginning of use. Check and readjust the
tension frequently as a loose chain can
easily derail or cause rapid wear of itself
and the guide bar.
■FUEL
Mix a regular grade gasoline (leaded or
unleaded, alcohol-free) and a
quality-proven motor oil for air cooled 2
cycle engines.
Motor oil: Recommended use JASO 2T FC
grade lubrants or above.
Recommended mixing ratio:
Condition Gasoline: Oil
Up to 20 hours use 20:1
After 20 hours use 25:1
25
：
1 Mix Chart
Gasoline liters 1 2 3 4 5
2-cycle oil ml. 40 80 120 160 200
Keep open flames away from the area
where fuel is handled or stored.
Mix and store fuel only in an approved
gasoline container.
NOTE
Most engine troubles are caused, directly or
indirectly, by the fuel used on the machine.
Take special care not to mix a motor oil for
4 cycle engines.
■CHAIN OIL
Use motor oil SAE 20 # in summer and SAE
#10 in winter.
NOTE
Do not use wasted or regenerated oil that
can cause damage to the oil pump.
f
F2 F3
Open the box and install the guide bar
and the saw chain on the power unit as
follows:
The saw chain has very sharp edges. Use
thick protective gloves for safety.
1.Install the attached spike to the power
unit.(F1.1)
2.Install the paper gasket onto the guide
plate. (F1.2)
3.Gear the chain to the sprocket and,
while fitting the saw chain around the
guide bar, mount the guide bar to the
power unit. Adjust the position of chain
tension nut on the chain cover to the
lower hole of guide bar. (F1.3)
(1) Tension nut
(2) Chain cover
NOTE
Pay attention to the correct direction of
the saw chain. (F2)
(1) Moving Direction
4.Fit the chain cover to the power unit
and fasten the nuts to finger tightness.
5.While holding up the tip of the bar,
adjust the chain tension by turning the
tension screw until the tie straps just
touch the bottom side of the bar rail.
(F4)
6.Tighten the nuts securely with the bar
tip held up (12-15N.m). Then check the
chain for smooth rotation and proper
tension while moving it by hand. If
necessary, readjust with the chain cover
loose.
7.Tighten the tension screw
(1) Loosen
(2) Tighten
(3) Tension screw
NOTE
A new chain will expand its length in the
beginning of use. Check and readjust the
tension frequently as a loose chain can
easily derail or cause rapid wear of itself
and the guide bar.
■FUEL
Mix a regular grade gasoline (leaded or
unleaded, alcohol-free) and a
quality-proven motor oil for air cooled 2
cycle engines.
Motor oil: Recommended use JASO 2T FC
grade lubrants or above.
Recommended mixing ratio:
Condition Gasoline: Oil
Up to 20 hours use 20:1
After 20 hours use 25:1
25
：
1 Mix Chart
Gasoline liters 1 2 3 4 5
2-cycle oil ml. 40 80 120 160 200
Keep open flames away from the area
where fuel is handled or stored.
Mix and store fuel only in an approved
gasoline container.
NOTE
Most engine troubles are caused, directly or
indirectly, by the fuel used on the machine.
Take special care not to mix a motor oil for
4 cycle engines.
■CHAIN OIL
Use motor oil SAE 20 # in summer and SAE
#10 in winter.
NOTE
Do not use wasted or regenerated oil that
can cause damage to the oil pump.
f
F4
Open the box and install the guide bar
and the saw chain on the power unit as
follows:
The saw chain has very sharp edges. Use
thick protective gloves for safety.
1.Install the attached spike to the power
unit.(F1.1)
2.Install the paper gasket onto the guide
plate. (F1.2)
3.Gear the chain to the sprocket and,
while fitting the saw chain around the
guide bar, mount the guide bar to the
power unit. Adjust the position of chain
tension nut on the chain cover to the
lower hole of guide bar. (F1.3)
(1) Tension nut
(2) Chain cover
NOTE
Pay attention to the correct direction of
the saw chain. (F2)
(1) Moving Direction
4.Fit the chain cover to the power unit
and fasten the nuts to finger tightness.
5.While holding up the tip of the bar,
adjust the chain tension by turning the
tension screw until the tie straps just
touch the bottom side of the bar rail.
(F4)
6.Tighten the nuts securely with the bar
tip held up (12-15N.m). Then check the
chain for smooth rotation and proper
tension while moving it by hand. If
necessary, readjust with the chain cover
loose.
7.Tighten the tension screw
(1) Loosen
(2) Tighten
(3) Tension screw
NOTE
A new chain will expand its length in the
beginning of use. Check and readjust the
tension frequently as a loose chain can
easily derail or cause rapid wear of itself
and the guide bar.
■FUEL
Mix a regular grade gasoline (leaded or
unleaded, alcohol-free) and a
quality-proven motor oil for air cooled 2
cycle engines.
Motor oil: Recommended use JASO 2T FC
grade lubrants or above.
Recommended mixing ratio:
Condition Gasoline: Oil
Up to 20 hours use 20:1
After 20 hours use 25:1
25
：
1 Mix Chart
Gasoline liters 1 2 3 4 5
2-cycle oil ml. 40 80 120 160 200
Keep open flames away from the area
where fuel is handled or stored.
Mix and store fuel only in an approved
gasoline container.
NOTE
Most engine troubles are caused, directly or
indirectly, by the fuel used on the machine.
Take special care not to mix a motor oil for
4 cycle engines.
■CHAIN OIL
Use motor oil SAE 20 # in summer and SAE
#10 in winter.
NOTE
Do not use wasted or regenerated oil that
can cause damage to the oil pump.
f
Open the box and install the guide bar
and the saw chain on the power unit as
follows:
The saw chain has very sharp edges. Use
thick protective gloves for safety.
1.Install the attached spike to the power
unit.(F1.1)
2.Install the paper gasket onto the guide
plate. (F1.2)
3.Gear the chain to the sprocket and,
while fitting the saw chain around the
guide bar, mount the guide bar to the
power unit. Adjust the position of chain
tension nut on the chain cover to the
lower hole of guide bar. (F1.3)
(1) Tension nut
(2) Chain cover
NOTE
Pay attention to the correct direction of
the saw chain. (F2)
(1) Moving Direction
4.Fit the chain cover to the power unit
and fasten the nuts to finger tightness.
5.While holding up the tip of the bar,
adjust the chain tension by turning the
tension screw until the tie straps just
touch the bottom side of the bar rail.
(F4)
6.Tighten the nuts securely with the bar
tip held up (12-15N.m). Then check the
chain for smooth rotation and proper
tension while moving it by hand. If
necessary, readjust with the chain cover
loose.
7.Tighten the tension screw
(1) Loosen
(2) Tighten
(3) Tension screw
NOTE
A new chain will expand its length in the
beginning of use. Check and readjust the
tension frequently as a loose chain can
easily derail or cause rapid wear of itself
and the guide bar.
■FUEL
Mix a regular grade gasoline (leaded or
unleaded, alcohol-free) and a
quality-proven motor oil for air cooled 2
cycle engines.
Motor oil: Recommended use JASO 2T FC
grade lubrants or above.
Recommended mixing ratio:
Condition Gasoline: Oil
Up to 20 hours use 20:1
After 20 hours use 25:1
25：1 Mix Chart
Gasoline liters 1 2 3 4 5
2-cycle oil ml. 40 80 120 160 200
Keep open flames away from the area
where fuel is handled or stored.
Mix and store fuel only in an approved
gasoline container.
NOTE
Most engine troubles are caused, directly or
indirectly, by the fuel used on the machine.
Take special care not to mix a motor oil for
4 cycle engines.
■CHAIN OIL
Use motor oil SAE 20 # in summer and SAE
#10 in winter.
NOTE
Do not use wasted or regenerated oil that
can cause damage to the oil pump.
f
F5
F6
All manuals and user guides at all-guides.com
9
WARNING
Do not start the engine while hanging the chain
saw with a hand. The saw chain may touch your
body. It’s very dangerous.
8. When the engine has ignited rst, push in
the choke knob and pull the starter again to
start the engine.
9. Allow the engine to warm up with the throttle
lever pulled slightly.
WARNING
Keep clear of the saw chain as it will start
rotating upon starting of engine.
CHECKING OIL SUPPLY
After starting the engine, run the chain at
medium speed and see if chain oil is scattered
off as shown in the gure. (F13)
CHAIN OIL
The chain oil ow can be changed by inserting
a screwdriver in the hole on bottom of the clutch
side. Adjust according to your work conditions.
(F14)
ADJUSTER
The oil tank should become nearly empty by the
time fuel is used up. Be sure to rell the oil tank
every time when refuelling the unit.
ADJUSTING CARBURETTOR (F15)
The carburettor on your unit has been factory
adjusted, but may require ne turning due to
change in operating conditions.
Before adjusting the carburettor, make sure
that provided are clean air/fuel lters and fresh,
properly mixed fuel.
When adjusting, take the following steps:
NOTE
Be sure to adjust the carburettor with the bar
chain attached,
1. Stop engine and screw in both H and L
needles until they stop. Never force. Set them
back the initial number of turns as shown below.
H needle: 1±⅜
L needle: 13/4±¼
2. Start engine and allow it to warm up at half-
throttle.
3. Turn L needle slowly clockwise to nd a
position where idling speed is maximum, then
set the needle back a quarter (1/4) turn counter-
clockwise.
4. Turn idle adjusting screw (3) counter-
clockwise so that saw chain does not turn.
If idling speed is too slow, turn the screw
clockwise.
5. Make a test cut and adjust the H needle for
best cutting power, not for maximum speed.
1. L needle.
2. H needle.
3. Idle adjusting screw.
CARBURETTOR ANTI-FREEZE MECHANISM
Operating the chain saw in temperatures of
0-5°C at times of high humidity may result in ice
forming within the carburettor, and this in time
may cause the output power of the engine to
be reduced or for the engine to fail to operate
smoothly.
This product has accordingly been designed
with a ventilation hatch the back of the air
cleaner cover to allow warm air to be supplied
to the engine and to thereby prevent icing from
occurring. (For some other models, the hot air
intake can be adjusted by the wind cover)
Under normal circumstances the product should
be used in normal operating mode. However
when the possibility exists that icing may occur,
the unit should be set to operate in anti-freeze
mode before use.
■STARTING ENGINE
1.Fill fuel and chain oil tanks
respectively, and tighten the caps
securely. (F7)
2.Pull the chock knob out to close chock.
(F8)
3.Put the switch to “I” position. (F9)
4.Pull the starter handle several ties until
first firing sound is heard. push the
chock knob all the way in to open the
chock .pull the starter handle again until
engine run.(F9)
5. Push the throttle lever and throttle
inter lock once and loosen it make the
engine run at idle speed.(F11)
6.To stop the engine, push the engine
switch to stop(o)position.
(1) Chain oil
(2) Fuel
(3) Switch
(4) Throttle lever
(5) Throttle interlock
(6) Choke knob
NOTE
When restarting immediately after
stopping the engine, leave the choke
knob at the open position.
6.While holding the saw unit securely on
the ground, pull the starter rope
vigorously. (F12)
Do not start the engine while hanging the
chain saw with a hand. The saw chain
may touch your body. It’s very
dangerous.
7.When engine has ignited first, push in
the choke knob and pull the starter again
to start the engine.
8.Allow the engine to warm up with the
throttle lever pulled slightly.
Keep clear of the saw chain as I t will
start rotating upon starting of engine.
■CHECKING OIL SUPPLY
After starting the engine, run the chain
at medium speed and see if chain oil is
scattered off as shown in the figure.
(F13)
(1) Chain oil
The chain oil flow can be changed by
inserting a screwdriver in the hole on
bottom of the clutch side. Adjust
according to your work conditions.
(F14)
(1) Adjuster
NOTE
The oil tank should become nearly
empty by the time fuel is used up. Be
sure to refill the oil tank every time
when refueling the unit.
■ADJUSTING CARBURETOR (F15)
The carburetor on your unit has been
factory adjusted, but may require fine
turning due to change in operating
conditions.
Before adjusting the carburetor, make
sure that provided are clean air/fuel
filters and fresh, properly mixed fuel.
When adjusting, take the following
steps:
NOTE
Be sure to adjust the carburetor with
the bar chain attached
1.op engine and screw in both H and L
needles until they stop. Never force.
The set them back the initial number of
turns as shown below.
H needle: 1±⅜
L needle: 13/4±¼
2.Start engine and allow it to warm up
at half-throttle.
3.Turn L needle slowly clockwise to
find a
position where idling speed is
maximum, then set the needle back a
quarter (1/4) turn counterclockwise.
■STARTING ENGINE
1.Fill fuel and chain oil tanks
respectively, and tighten the caps
securely. (F7)
2.Pull the chock knob out to close chock.
(F8)
3.Put the switch to “I” position. (F9)
4.Pull the starter handle several ties until
first firing sound is heard. push the
chock knob all the way in to open the
chock .pull the starter handle again until
engine run.(F9)
5. Push the throttle lever and throttle
inter lock once and loosen it make the
engine run at idle speed.(F11)
6.To stop the engine, push the engine
switch to stop(o)position.
(1) Chain oil
(2) Fuel
(3) Switch
(4) Throttle lever
(5) Throttle interlock
(6) Choke knob
NOTE
When restarting immediately after
stopping the engine, leave the choke
knob at the open position.
6.While holding the saw unit securely on
the ground, pull the starter rope
vigorously. (F12)
Do not start the engine while hanging the
chain saw with a hand. The saw chain
may touch your body. It’s very
dangerous.
7.When engine has ignited first, push in
the choke knob and pull the starter again
to start the engine.
8.Allow the engine to warm up with the
throttle lever pulled slightly.
Keep clear of the saw chain as I t will
start rotating upon starting of engine.
■CHECKING OIL SUPPLY
After starting the engine, run the chain
at medium speed and see if chain oil is
scattered off as shown in the figure.
(F13)
(1) Chain oil
The chain oil flow can be changed by
inserting a screwdriver in the hole on
bottom of the clutch side. Adjust
according to your work conditions.
(F14)
(1) Adjuster
NOTE
The oil tank should become nearly
empty by the time fuel is used up. Be
sure to refill the oil tank every time
when refueling the unit.
■ADJUSTING CARBURETOR (F15)
The carburetor on your unit has been
factory adjusted, but may require fine
turning due to change in operating
conditions.
Before adjusting the carburetor, make
sure that provided are clean air/fuel
filters and fresh, properly mixed fuel.
When adjusting, take the following
steps:
NOTE
Be sure to adjust the carburetor with
the bar chain attached
1.op engine and screw in both H and L
needles until they stop. Never force.
The set them back the initial number of
turns as shown below.
H needle: 1±⅜
L needle: 13/4±¼
2.Start engine and allow it to warm up
at half-throttle.
3.Turn L needle slowly clockwise to
find a
position where idling speed is
maximum, then set the needle back a
quarter (1/4) turn counterclockwise.
■STARTING ENGINE
1.Fill fuel and chain oil tanks
respectively, and tighten the caps
securely. (F7)
2.Pull the chock knob out to close chock.
(F8)
3.Put the switch to “I” position. (F9)
4.Pull the starter handle several ties until
first firing sound is heard. push the
chock knob all the way in to open the
chock .pull the starter handle again until
engine run.(F9)
5. Push the throttle lever and throttle
inter lock once and loosen it make the
engine run at idle speed.(F11)
6.To stop the engine, push the engine
switch to stop(o)position.
(1) Chain oil
(2) Fuel
(3) Switch
(4) Throttle lever
(5) Throttle interlock
(6) Choke knob
NOTE
When restarting immediately after
stopping the engine, leave the choke
knob at the open position.
6.While holding the saw unit securely on
the ground, pull the starter rope
vigorously. (F12)
Do not start the engine while hanging the
chain saw with a hand. The saw chain
may touch your body. It’s very
dangerous.
7.When engine has ignited first, push in
the choke knob and pull the starter again
to start the engine.
8.Allow the engine to warm up with the
throttle lever pulled slightly.
Keep clear of the saw chain as I t will
start rotating upon starting of engine.
■CHECKING OIL SUPPLY
After starting the engine, run the chain
at medium speed and see if chain oil is
scattered off as shown in the figure.
(F13)
(1) Chain oil
The chain oil flow can be changed by
inserting a screwdriver in the hole on
bottom of the clutch side. Adjust
according to your work conditions.
(F14)
(1) Adjuster
NOTE
The oil tank should become nearly
empty by the time fuel is used up. Be
sure to refill the oil tank every time
when refueling the unit.
■ADJUSTING CARBURETOR (F15)
The carburetor on your unit has been
factory adjusted, but may require fine
turning due to change in operating
conditions.
Before adjusting the carburetor, make
sure that provided are clean air/fuel
filters and fresh, properly mixed fuel.
When adjusting, take the following
steps:
NOTE
Be sure to adjust the carburetor with
the bar chain attached
1.op engine and screw in both H and L
needles until they stop. Never force.
The set them back the initial number of
turns as shown below.
H needle: 1±⅜
L needle: 13/4±¼
2.Start engine and allow it to warm up
at half-throttle.
3.Turn L needle slowly clockwise to
find a
position where idling speed is
maximum, then set the needle back a
quarter (1/4) turn counterclockwise.
■STARTING ENGINE
1.Fill fuel and chain oil tanks
respectively, and tighten the caps
securely. (F7)
2.Pull the chock knob out to close chock.
(F8)
3.Put the switch to “I” position. (F9)
4.Pull the starter handle several ties until
first firing sound is heard. push the
chock knob all the way in to open the
chock .pull the starter handle again until
engine run.(F9)
5. Push the throttle lever and throttle
inter lock once and loosen it make the
engine run at idle speed.(F11)
6.To stop the engine, push the engine
switch to stop(o)position.
(1) Chain oil
(2) Fuel
(3) Switch
(4) Throttle lever
(5) Throttle interlock
(6) Choke knob
NOTE
When restarting immediately after
stopping the engine, leave the choke
knob at the open position.
6.While holding the saw unit securely on
the ground, pull the starter rope
vigorously. (F12)
Do not start the engine while hanging the
chain saw with a hand. The saw chain
may touch your body. It’s very
dangerous.
7.When engine has ignited first, push in
the choke knob and pull the starter again
to start the engine.
8.Allow the engine to warm up with the
throttle lever pulled slightly.
Keep clear of the saw chain as I t will
start rotating upon starting of engine.
■CHECKING OIL SUPPLY
After starting the engine, run the chain
at medium speed and see if chain oil is
scattered off as shown in the figure.
(F13)
(1) Chain oil
The chain oil flow can be changed by
inserting a screwdriver in the hole on
bottom of the clutch side. Adjust
according to your work conditions.
(F14)
(1) Adjuster
NOTE
The oil tank should become nearly
empty by the time fuel is used up. Be
sure to refill the oil tank every time
when refueling the unit.
■ADJUSTING CARBURETOR (F15)
The carburetor on your unit has been
factory adjusted, but may require fine
turning due to change in operating
conditions.
Before adjusting the carburetor, make
sure that provided are clean air/fuel
filters and fresh, properly mixed fuel.
When adjusting, take the following
steps:
NOTE
Be sure to adjust the carburetor with
the bar chain attached
1.op engine and screw in both H and L
needles until they stop. Never force.
The set them back the initial number of
turns as shown below.
H needle: 1±⅜
L needle: 13/4±¼
2.Start engine and allow it to warm up
at half-throttle.
3.Turn L needle slowly clockwise to
find a
position where idling speed is
maximum, then set the needle back a
quarter (1/4) turn counterclockwise.
■STARTING ENGINE
1.Fill fuel and chain oil tanks
respectively, and tighten the caps
securely. (F7)
2.Pull the chock knob out to close chock.
(F8)
3.Put the switch to “I” position. (F9)
4.Pull the starter handle several ties until
first firing sound is heard. push the
chock knob all the way in to open the
chock .pull the starter handle again until
engine run.(F9)
5. Push the throttle lever and throttle
inter lock once and loosen it make the
engine run at idle speed.(F11)
6.To stop the engine, push the engine
switch to stop(o)position.
(1) Chain oil
(2) Fuel
(3) Switch
(4) Throttle lever
(5) Throttle interlock
(6) Choke knob
NOTE
When restarting immediately after
stopping the engine, leave the choke
knob at the open position.
6.While holding the saw unit securely on
the ground, pull the starter rope
vigorously. (F12)
Do not start the engine while hanging the
chain saw with a hand. The saw chain
may touch your body. It’s very
dangerous.
7.When engine has ignited first, push in
the choke knob and pull the starter again
to start the engine.
8.Allow the engine to warm up with the
throttle lever pulled slightly.
Keep clear of the saw chain as I t will
start rotating upon starting of engine.
■CHECKING OIL SUPPLY
After starting the engine, run the chain
at medium speed and see if chain oil is
scattered off as shown in the figure.
(F13)
(1) Chain oil
The chain oil flow can be changed by
inserting a screwdriver in the hole on
bottom of the clutch side. Adjust
according to your work conditions.
(F14)
(1) Adjuster
NOTE
The oil tank should become nearly
empty by the time fuel is used up. Be
sure to refill the oil tank every time
when refueling the unit.
■ADJUSTING CARBURETOR (F15)
The carburetor on your unit has been
factory adjusted, but may require fine
turning due to change in operating
conditions.
Before adjusting the carburetor, make
sure that provided are clean air/fuel
filters and fresh, properly mixed fuel.
When adjusting, take the following
steps:
NOTE
Be sure to adjust the carburetor with
the bar chain attached
1.op engine and screw in both H and L
needles until they stop. Never force.
The set them back the initial number of
turns as shown below.
H needle: 1±⅜
L needle: 13/4±¼
2.Start engine and allow it to warm up
at half-throttle.
3.Turn L needle slowly clockwise to
find a
position where idling speed is
maximum, then set the needle back a
quarter (1/4) turn counterclockwise.
■STARTING ENGINE
1.Fill fuel and chain oil tanks
respectively, and tighten the caps
securely. (F7)
2.Pull the chock knob out to close chock.
(F8)
3.Put the switch to “I” position. (F9)
4.Pull the starter handle several ties until
first firing sound is heard. push the
chock knob all the way in to open the
chock .pull the starter handle again until
engine run.(F9)
5. Push the throttle lever and throttle
inter lock once and loosen it make the
engine run at idle speed.(F11)
6.To stop the engine, push the engine
switch to stop(o)position.
(1) Chain oil
(2) Fuel
(3) Switch
(4) Throttle lever
(5) Throttle interlock
(6) Choke knob
NOTE
When restarting immediately after
stopping the engine, leave the choke
knob at the open position.
6.While holding the saw unit securely on
the ground, pull the starter rope
vigorously. (F12)
Do not start the engine while hanging the
chain saw with a hand. The saw chain
may touch your body. It’s very
dangerous.
7.When engine has ignited first, push in
the choke knob and pull the starter again
to start the engine.
8.Allow the engine to warm up with the
throttle lever pulled slightly.
Keep clear of the saw chain as I t will
start rotating upon starting of engine.
■CHECKING OIL SUPPLY
After starting the engine, run the chain
at medium speed and see if chain oil is
scattered off as shown in the figure.
(F13)
(1) Chain oil
The chain oil flow can be changed by
inserting a screwdriver in the hole on
bottom of the clutch side. Adjust
according to your work conditions.
(F14)
(1) Adjuster
NOTE
The oil tank should become nearly
empty by the time fuel is used up. Be
sure to refill the oil tank every time
when refueling the unit.
■ADJUSTING CARBURETOR (F15)
The carburetor on your unit has been
factory adjusted, but may require fine
turning due to change in operating
conditions.
Before adjusting the carburetor, make
sure that provided are clean air/fuel
filters and fresh, properly mixed fuel.
When adjusting, take the following
steps:
NOTE
Be sure to adjust the carburetor with
the bar chain attached
1.op engine and screw in both H and L
needles until they stop. Never force.
The set them back the initial number of
turns as shown below.
H needle: 1±⅜
L needle: 13/4±¼
2.Start engine and allow it to warm up
at half-throttle.
3.Turn L needle slowly clockwise to
find a
position where idling speed is
maximum, then set the needle back a
quarter (1/4) turn counterclockwise.
■STARTING ENGINE
1.Fill fuel and chain oil tanks
respectively, and tighten the caps
securely. (F7)
2.Pull the chock knob out to close chock.
(F8)
3.Put the switch to “I” position. (F9)
4.Pull the starter handle several ties until
first firing sound is heard. push the
chock knob all the way in to open the
chock .pull the starter handle again until
engine run.(F9)
5. Push the throttle lever and throttle
inter lock once and loosen it make the
engine run at idle speed.(F11)
6.To stop the engine, push the engine
switch to stop(o)position.
(1) Chain oil
(2) Fuel
(3) Switch
(4) Throttle lever
(5) Throttle interlock
(6) Choke knob
NOTE
When restarting immediately after
stopping the engine, leave the choke
knob at the open position.
6.While holding the saw unit securely on
the ground, pull the starter rope
vigorously. (F12)
Do not start the engine while hanging the
chain saw with a hand. The saw chain
may touch your body. It’s very
dangerous.
7.When engine has ignited first, push in
the choke knob and pull the starter again
to start the engine.
8.Allow the engine to warm up with the
throttle lever pulled slightly.
Keep clear of the saw chain as I t will
start rotating upon starting of engine.
■CHECKING OIL SUPPLY
After starting the engine, run the chain
at medium speed and see if chain oil is
scattered off as shown in the figure.
(F13)
(1) Chain oil
The chain oil flow can be changed by
inserting a screwdriver in the hole on
bottom of the clutch side. Adjust
according to your work conditions.
(F14)
(1) Adjuster
NOTE
The oil tank should become nearly
empty by the time fuel is used up. Be
sure to refill the oil tank every time
when refueling the unit.
■ADJUSTING CARBURETOR (F15)
The carburetor on your unit has been
factory adjusted, but may require fine
turning due to change in operating
conditions.
Before adjusting the carburetor, make
sure that provided are clean air/fuel
filters and fresh, properly mixed fuel.
When adjusting, take the following
steps:
NOTE
Be sure to adjust the carburetor with
the bar chain attached
1.op engine and screw in both H and L
needles until they stop. Never force.
The set them back the initial number of
turns as shown below.
H needle: 1±⅜
L needle: 13/4±¼
2.Start engine and allow it to warm up
at half-throttle.
3.Turn L needle slowly clockwise to
find a
position where idling speed is
maximum, then set the needle back a
quarter (1/4) turn counterclockwise.
■STARTING ENGINE
1.Fill fuel and chain oil tanks
respectively, and tighten the caps
securely. (F7)
2.Pull the chock knob out to close chock.
(F8)
3.Put the switch to “I” position. (F9)
4.Pull the starter handle several ties until
first firing sound is heard. push the
chock knob all the way in to open the
chock .pull the starter handle again until
engine run.(F9)
5. Push the throttle lever and throttle
inter lock once and loosen it make the
engine run at idle speed.(F11)
6.To stop the engine, push the engine
switch to stop(o)position.
(1) Chain oil
(2) Fuel
(3) Switch
(4) Throttle lever
(5) Throttle interlock
(6) Choke knob
NOTE
When restarting immediately after
stopping the engine, leave the choke
knob at the open position.
6.While holding the saw unit securely on
the ground, pull the starter rope
vigorously. (F12)
Do not start the engine while hanging the
chain saw with a hand. The saw chain
may touch your body. It’s very
dangerous.
7.When engine has ignited first, push in
the choke knob and pull the starter again
to start the engine.
8.Allow the engine to warm up with the
throttle lever pulled slightly.
Keep clear of the saw chain as I t will
start rotating upon starting of engine.
■CHECKING OIL SUPPLY
After starting the engine, run the chain
at medium speed and see if chain oil is
scattered off as shown in the figure.
(F13)
(1) Chain oil
The chain oil flow can be changed by
inserting a screwdriver in the hole on
bottom of the clutch side. Adjust
according to your work conditions.
(F14)
(1) Adjuster
NOTE
The oil tank should become nearly
empty by the time fuel is used up. Be
sure to refill the oil tank every time
when refueling the unit.
■ADJUSTING CARBURETOR (F15)
The carburetor on your unit has been
factory adjusted, but may require fine
turning due to change in operating
conditions.
Before adjusting the carburetor, make
sure that provided are clean air/fuel
filters and fresh, properly mixed fuel.
When adjusting, take the following
steps:
NOTE
Be sure to adjust the carburetor with
the bar chain attached
1.op engine and screw in both H and L
needles until they stop. Never force.
The set them back the initial number of
turns as shown below.
H needle: 1±⅜
L needle: 13/4±¼
2.Start engine and allow it to warm up
at half-throttle.
3.Turn L needle slowly clockwise to
find a
position where idling speed is
maximum, then set the needle back a
quarter (1/4) turn counterclockwise.
■STARTING ENGINE
1.Fill fuel and chain oil tanks
respectively, and tighten the caps
securely. (F7)
2.Pull the chock knob out to close chock.
(F8)
3.Put the switch to “I” position. (F9)
4.Pull the starter handle several ties until
first firing sound is heard. push the
chock knob all the way in to open the
chock .pull the starter handle again until
engine run.(F9)
5. Push the throttle lever and throttle
inter lock once and loosen it make the
engine run at idle speed.(F11)
6.To stop the engine, push the engine
switch to stop(o)position.
(1) Chain oil
(2) Fuel
(3) Switch
(4) Throttle lever
(5) Throttle interlock
(6) Choke knob
NOTE
When restarting immediately after
stopping the engine, leave the choke
knob at the open position.
6.While holding the saw unit securely on
the ground, pull the starter rope
vigorously. (F12)
Do not start the engine while hanging the
chain saw with a hand. The saw chain
may touch your body. It’s very
dangerous.
7.When engine has ignited first, push in
the choke knob and pull the starter again
to start the engine.
8.Allow the engine to warm up with the
throttle lever pulled slightly.
Keep clear of the saw chain as I t will
start rotating upon starting of engine.
■CHECKING OIL SUPPLY
After starting the engine, run the chain
at medium speed and see if chain oil is
scattered off as shown in the figure.
(F13)
(1) Chain oil
The chain oil flow can be changed by
inserting a screwdriver in the hole on
bottom of the clutch side. Adjust
according to your work conditions.
(F14)
(1) Adjuster
NOTE
The oil tank should become nearly
empty by the time fuel is used up. Be
sure to refill the oil tank every time
when refueling the unit.
■ADJUSTING CARBURETOR (F15)
The carburetor on your unit has been
factory adjusted, but may require fine
turning due to change in operating
conditions.
Before adjusting the carburetor, make
sure that provided are clean air/fuel
filters and fresh, properly mixed fuel.
When adjusting, take the following
steps:
NOTE
Be sure to adjust the carburetor with
the bar chain attached
1.op engine and screw in both H and L
needles until they stop. Never force.
The set them back the initial number of
turns as shown below.
H needle: 1±⅜
L needle: 13/4±¼
2.Start engine and allow it to warm up
at half-throttle.
3.Turn L needle slowly clockwise to
find a
position where idling speed is
maximum, then set the needle back a
quarter (1/4) turn counterclockwise.
F7 F8 F9
F10 F11 F12
F13
F12
F14 F15
All manuals and user guides at all-guides.com
10
• It is not necessary to force the saw into the
cut. Apply only light pressure while running
the engine at full throttle.
• When the saw chain is caught in the cut, do
not attempt to pull it out by force, but use a
wedge or a lever to open the way.
GUARD AGAINST KICKBACK (F18)
• It is extremely important that the chain
brake be checked
for proper operation before
each use and that the chain
be sharp in order to maintain
the kickback safety level of
this saw. Removal of the
safety devices, inadequate
maintenance, or incorrect
replacement of the bar or chain
may increase the risk of serious personal
injury due to kickback.
FELLING A TREE (F17)
1. Decide the felling direction
considering the wind, lean of the
tree, location of heavy branches,
ease of job after felling
and other factors.
2. While clearing the area around the tree,
arrange a good foothold and retreat path.
3. Make a notch cut one-third of the way into the
tree on the felling side.
4. Make a felling cut from the opposite side of
the notch and at a level slightly higher than the
bottom of the notch.
WARNING
·
Before proceeding to your job, read
“SAFETY INSTRUCTION” and “SAFETY
PRECAUTIONS” sections. It is
recommended to first practice sawing easy
logs. This also helps you get accustomed to
your unit.
·
Always follow the safety regulations. The
chain saw must only be used for cutting
wood. It is forbidden to cut other types of
material. Vibrations and kickback vary with
different materials and the requirements of
the safety regulations would not be
respected. Do not use the chain saw as a
lever for lifting, moving or splitting objects.
Do not lock it over fixed stands. It is
forbidden to hitch tools or applications that
are not specified by the manufacturer.
·
It is not necessary to force the saw into the
cut. Apply only light pressure while running
the engine at full throttle.
·
When the saw chain is caught in the cut,
do not attempt to pull it out by force, but
use a wedge or a lever to open the way.
■GUARD AGAINST KICKBACK (F19)
·
It is extremely important that the chain
brake be checked for proper operation
before each use and that the chain be sharp
in order to maintain the kickback safety
level of this saw. Removal of the safety
devices, inadequate maintenance, or
incorrect replacement of the bar or chain
may increase the risk of serious personal
injury due to kickback.
■FELLING A TREE (F20)
1.Decide the felling direction considering
the wind, lean of the tree, location of heavy
branches, ease of job after felling and other
factors.
2.While clearing the area around the tree,
arrange a good foothold and retreat path.
3.Make a notch cut one-third of the way into
the tree on the felling side.
4.Make a felling cut from the opposite side
of the notch and at a level slightly higher
than the bottom of the notch.
Description of felling escape routes.keep all
bystanders or other workers away from the
danger zone.
When you fell a tree, be sure to warn your
neighboring workers of the danger.
(1) Notch cut
(2) Felling cut
(3) Felling direction
■
Bucking and Limbing
·
Always ensure your foothold. Do not stand
on the log.
·
Be alert to the rolling over of a cut log.
Especially when working on a slope, stand
on the uphill side of the log.
·
Follow the instructions in “For Safe
Operation” to avoid kickback of the saw.
Before starting work, check the direction of
bending force inside the log to be cut.
Always finish cutting from the opposite
side of bending direction to prevent the
guide bar from being caught in the cut.
WARNING
·
Before proceeding to your job, read
“SAFETY INSTRUCTION” and “SAFETY
PRECAUTIONS” sections. It is
recommended to first practice sawing easy
logs. This also helps you get accustomed to
your unit.
·
Always follow the safety regulations. The
chain saw must only be used for cutting
wood. It is forbidden to cut other types of
material. Vibrations and kickback vary with
different materials and the requirements of
the safety regulations would not be
respected. Do not use the chain saw as a
lever for lifting, moving or splitting objects.
Do not lock it over fixed stands. It is
forbidden to hitch tools or applications that
are not specified by the manufacturer.
·
It is not necessary to force the saw into the
cut. Apply only light pressure while running
the engine at full throttle.
·
When the saw chain is caught in the cut,
do not attempt to pull it out by force, but
use a wedge or a lever to open the way.
■GUARD AGAINST KICKBACK (F19)
·
It is extremely important that the chain
brake be checked for proper operation
before each use and that the chain be sharp
in order to maintain the kickback safety
level of this saw. Removal of the safety
devices, inadequate maintenance, or
incorrect replacement of the bar or chain
may increase the risk of serious personal
injury due to kickback.
■FELLING A TREE (F20)
1.Decide the felling direction considering
the wind, lean of the tree, location of heavy
branches, ease of job after felling and other
factors.
2.While clearing the area around the tree,
arrange a good foothold and retreat path.
3.Make a notch cut one-third of the way into
the tree on the felling side.
4.Make a felling cut from the opposite side
of the notch and at a level slightly higher
than the bottom of the notch.
Description of felling escape routes.keep all
bystanders or other workers away from the
danger zone.
When you fell a tree, be sure to warn your
neighboring workers of the danger.
(1) Notch cut
(2) Felling cut
(3) Felling direction
■
Bucking and Limbing
·
Always ensure your foothold. Do not stand
on the log.
·
Be alert to the rolling over of a cut log.
Especially when working on a slope, stand
on the uphill side of the log.
·
Follow the instructions in “For Safe
Operation” to avoid kickback of the saw.
Before starting work, check the direction of
bending force inside the log to be cut.
Always finish cutting from the opposite
side of bending direction to prevent the
guide bar from being caught in the cut.
CHAIN BRAKE (F16)
This brake can also be operated manually with
the front guard turned down to the guide bar.
To release brake, pull up the front guard toward
the front handle till “click” sound is heard.
a. Break (front guard).
b. Released.
CAUTION
Be sure to conrm brake operation on the daily
inspection. In case the brake is not effective,
do not operate the saw, take the chainsaw to
your local Bushranger™dealer for inspection
and repairing. The engine, if being kept rotated
at high speed with the brake engaged, heats
the clutch, causing trouble. When the brake
is operated while in operation, immediately
release your ngers from the throttle lever and
keep the engine idling.
STOPPING ENGINE
a. Release the throttle lever to allow the engine
idling for a few minutes.
Put the switch to the “O” (STOP) position. (F17)
b. Switch.
WARNING
• Before proceeding to your job, read
“SAFETY INSTRUCTIONS” and
“SAFETY PRECAUTIONS” sections. It is
recommended to rst practice sawing easy
logs. This also helps you get accustomed to
your chainsaw.
• Always follow the safety regulations. The
chain saw must only be used for cutting
wood. It is forbidden to cut other types of
material. Vibrations and kickback vary with
different materials and the requirements
of the safety regulations would not be
respected. Do not use the chain saw as a
lever for lifting, moving or splitting objects.
Do not lock it over xed stands. It is
forbidden to hitch tools or applications that
are not specied by the manufacturer.
4.Turn idle adjusting screw (T) counterclockwise so that saw
chain does not turn. If idling speed is too slow, turn the screw
clockwise.
5.Make a test cut and adjust the H needle for best cutting power,
not for maximum speed.
(1) L needle (2) H needle
(3) Idle adjusting screw
■CARBURETOR ANTI-FREEZE MECHANISM
Operating the chain saw in temperatures of 0-5°C at times of high
humidity may result in ice forming within the carburetor, and this
in turn may cause the output power of the engine to be reduced
or for the engine to fail to operate smoothly.
This product has accordingly been designed with a ventilation
hatch the back of the air cleaner cover to allow warm air to be
supplied to the engine and to thereby prevent icing from
occurring.(For some other models, the hot air intake can be
adjusted by ho wind cover)
Under normal circumstances the product should be used in
normal operating mode, i.e., in the to which it is set at the time of
shipment.
However when the possibility exists that icing may occur, the
unit should be set to operate in anti-freeze mode before use.
■HOW TO SWITCH BETWEEN OPERATING MODES
A.SWITCHING BY AIR FILTER COVER (F16A)
1. Flip the engine switch to turn off the
engine.
2. Remove the air cleaner cover from the
cylinder cover.
3. Reattach the screen right side left so as to
the anti-icing plate is on the right. Reinstall
the cover.
（
1
）
Air cleaner cover
（
2
）
Anti-icing plate
（
3
）
Screw
（
4
）
Normal operating mode
（
5
）
Anti-freeze mode
（
6
）
Screen
B.SWITCHING BY HOT WIND COVER (F16B)
1.Flip the engine switch to turn off the engine.
2.Remove the air cleaner cover from the cylinder
cover.
3.Revolve the hot wind cover to the Anti-freeze
mode.
4.Reinstall the cover.
(1)Air cleaner cover
(2)Hot wind cover
(3) Normal operating mode
(4) Anti-freeze mode
Continuing to use the product in anti-freeze
mode even when temperatures have risen
and returned to normal may result in the
engine failing to start properly or in the
engine failing to operate at its normal
speed, and for this reason you should
always be sure to return the unit to normal
operating mode if there is no dander of
icing occurring.
■CHAIN BRAKE(F17)
This brake can also be operated manually
with the front guard turned down to the
guide bar.
To release brake, pull up the front guard
toward the front handle till “click” sound is
heard.
(1)Break(front guard)
(2)Released
(3)Operated
【
CAUTION
】
Be sure to confirm brake operation on the
daily inspection.
In case the brake is not effective, ask our
dealer inspection and repairing. The engine,
if being kept rotated at high speed with the
brake engaged, heats the clutch, causing a
trouble. When the brake is operated while in
operation, immediately release your fingers
from the throttle lever and keep the engine
idling.
■STOPPING ENGINE
1.Release the throttle lever to allow the
engine idling for a few minutes.
Put the switch to the “O” (STOP) position.
(F18)
(1) Switch
4.Turn idle adjusting screw (T) counterclockwise so that saw
chain does not turn. If idling speed is too slow, turn the screw
clockwise.
5.Make a test cut and adjust the H needle for best cutting power,
not for maximum speed.
(1) L needle (2) H needle
(3) Idle adjusting screw
■CARBURETOR ANTI-FREEZE MECHANISM
Operating the chain saw in temperatures of 0-5°C at times of high
humidity may result in ice forming within the carburetor, and this
in turn may cause the output power of the engine to be reduced
or for the engine to fail to operate smoothly.
This product has accordingly been designed with a ventilation
hatch the back of the air cleaner cover to allow warm air to be
supplied to the engine and to thereby prevent icing from
occurring.(For some other models, the hot air intake can be
adjusted by ho wind cover)
Under normal circumstances the product should be used in
normal operating mode, i.e., in the to which it is set at the time of
shipment.
However when the possibility exists that icing may occur, the
unit should be set to operate in anti-freeze mode before use.
■HOW TO SWITCH BETWEEN OPERATING MODES
A.SWITCHING BY AIR FILTER COVER (F16A)
1. Flip the engine switch to turn off the
engine.
2. Remove the air cleaner cover from the
cylinder cover.
3. Reattach the screen right side left so as to
the anti-icing plate is on the right. Reinstall
the cover.
（
1
）
Air cleaner cover
（
2
）
Anti-icing plate
（
3
）
Screw
（
4
）
Normal operating mode
（
5
）
Anti-freeze mode
（
6
）
Screen
B.SWITCHING BY HOT WIND COVER (F16B)
1.Flip the engine switch to turn off the engine.
2.Remove the air cleaner cover from the cylinder
cover.
3.Revolve the hot wind cover to the Anti-freeze
mode.
4.Reinstall the cover.
(1)Air cleaner cover
(2)Hot wind cover
(3) Normal operating mode
(4) Anti-freeze mode
Continuing to use the product in anti-freeze
mode even when temperatures have risen
and returned to normal may result in the
engine failing to start properly or in the
engine failing to operate at its normal
speed, and for this reason you should
always be sure to return the unit to normal
operating mode if there is no dander of
icing occurring.
■CHAIN BRAKE(F17)
This brake can also be operated manually
with the front guard turned down to the
guide bar.
To release brake, pull up the front guard
toward the front handle till “click” sound is
heard.
(1)Break(front guard)
(2)Released
(3)Operated
【
CAUTION
】
Be sure to confirm brake operation on the
daily inspection.
In case the brake is not effective, ask our
dealer inspection and repairing. The engine,
if being kept rotated at high speed with the
brake engaged, heats the clutch, causing a
trouble. When the brake is operated while in
operation, immediately release your fingers
from the throttle lever and keep the engine
idling.
■STOPPING ENGINE
1.Release the throttle lever to allow the
engine idling for a few minutes.
Put the switch to the “O” (STOP) position.
(F18)
(1) Switch
4.Turn idle adjusting screw (T) counterclockwise so that saw
chain does not turn. If idling speed is too slow, turn the screw
clockwise.
5.Make a test cut and adjust the H needle for best cutting power,
not for maximum speed.
(1) L needle (2) H needle
(3) Idle adjusting screw
■CARBURETOR ANTI-FREEZE MECHANISM
Operating the chain saw in temperatures of 0-5°C at times of high
humidity may result in ice forming within the carburetor, and this
in turn may cause the output power of the engine to be reduced
or for the engine to fail to operate smoothly.
This product has accordingly been designed with a ventilation
hatch the back of the air cleaner cover to allow warm air to be
supplied to the engine and to thereby prevent icing from
occurring.(For some other models, the hot air intake can be
adjusted by ho wind cover)
Under normal circumstances the product should be used in
normal operating mode, i.e., in the to which it is set at the time of
shipment.
However when the possibility exists that icing may occur, the
unit should be set to operate in anti-freeze mode before use.
■HOW TO SWITCH BETWEEN OPERATING MODES
A.SWITCHING BY AIR FILTER COVER (F16A)
1. Flip the engine switch to turn off the
engine.
2. Remove the air cleaner cover from the
cylinder cover.
3. Reattach the screen right side left so as to
the anti-icing plate is on the right. Reinstall
the cover.
（
1
）
Air cleaner cover
（
2
）
Anti-icing plate
（
3
）
Screw
（
4
）
Normal operating mode
（
5
）
Anti-freeze mode
（
6
）
Screen
B.SWITCHING BY HOT WIND COVER (F16B)
1.Flip the engine switch to turn off the engine.
2.Remove the air cleaner cover from the cylinder
cover.
3.Revolve the hot wind cover to the Anti-freeze
mode.
4.Reinstall the cover.
(1)Air cleaner cover
(2)Hot wind cover
(3) Normal operating mode
(4) Anti-freeze mode
Continuing to use the product in anti-freeze
mode even when temperatures have risen
and returned to normal may result in the
engine failing to start properly or in the
engine failing to operate at its normal
speed, and for this reason you should
always be sure to return the unit to normal
operating mode if there is no dander of
icing occurring.
■CHAIN BRAKE(F17)
This brake can also be operated manually
with the front guard turned down to the
guide bar.
To release brake, pull up the front guard
toward the front handle till “click” sound is
heard.
(1)Break(front guard)
(2)Released
(3)Operated
【
CAUTION
】
Be sure to confirm brake operation on the
daily inspection.
In case the brake is not effective, ask our
dealer inspection and repairing. The engine,
if being kept rotated at high speed with the
brake engaged, heats the clutch, causing a
trouble. When the brake is operated while in
operation, immediately release your fingers
from the throttle lever and keep the engine
idling.
■STOPPING ENGINE
1.Release the throttle lever to allow the
engine idling for a few minutes.
Put the switch to the “O” (STOP) position.
(F18)
(1) Switch
F16
a. b.
F18
F17
All manuals and user guides at all-guides.com
11
WARNING
·
Before proceeding to your job, read
“SAFETY INSTRUCTION” and “SAFETY
PRECAUTIONS” sections. It is
recommended to first practice sawing easy
logs. This also helps you get accustomed to
your unit.
·
Always follow the safety regulations. The
chain saw must only be used for cutting
wood. It is forbidden to cut other types of
material. Vibrations and kickback vary with
different materials and the requirements of
the safety regulations would not be
respected. Do not use the chain saw as a
lever for lifting, moving or splitting objects.
Do not lock it over fixed stands. It is
forbidden to hitch tools or applications that
are not specified by the manufacturer.
·
It is not necessary to force the saw into the
cut. Apply only light pressure while running
the engine at full throttle.
·
When the saw chain is caught in the cut,
do not attempt to pull it out by force, but
use a wedge or a lever to open the way.
■GUARD AGAINST KICKBACK (F19)
·
It is extremely important that the chain
brake be checked for proper operation
before each use and that the chain be sharp
in order to maintain the kickback safety
level of this saw. Removal of the safety
devices, inadequate maintenance, or
incorrect replacement of the bar or chain
may increase the risk of serious personal
injury due to kickback.
■FELLING A TREE (F20)
1.Decide the felling direction considering
the wind, lean of the tree, location of heavy
branches, ease of job after felling and other
factors.
2.While clearing the area around the tree,
arrange a good foothold and retreat path.
3.Make a notch cut one-third of the way into
the tree on the felling side.
4.Make a felling cut from the opposite side
of the notch and at a level slightly higher
than the bottom of the notch.
Description of felling escape routes.keep all
bystanders or other workers away from the
danger zone.
When you fell a tree, be sure to warn your
neighboring workers of the danger.
(1) Notch cut
(2) Felling cut
(3) Felling direction
■
Bucking and Limbing
·
Always ensure your foothold. Do not stand
on the log.
·
Be alert to the rolling over of a cut log.
Especially when working on a slope, stand
on the uphill side of the log.
·
Follow the instructions in “For Safe
Operation” to avoid kickback of the saw.
Before starting work, check the direction of
bending force inside the log to be cut.
Always finish cutting from the opposite
side of bending direction to prevent the
guide bar from being caught in the cut.
WARNING
Description of felling escape routes. Keep all
bystanders or other workers away from the
danger zone.
When you fell a tree, be sure to warn your
neighbouring workers of the danger.
a. Notch cut.
b. Felling cut.
c. Felling direction.
BUCKING & LIMBING
WARNING
• Always ensure your foothold. Do not stand
on the log.
• Be alert to the rolling over of a cut log.
Especially when working on a slope, stand
on the uphill side of the log.
• Follow the instructions in “For Safe
Operation” to avoid kickback of the saw.
Before starting work, check the direction
of bending force inside the log to be cut.
Always nish cutting from the opposite side
of bending direction to prevent the guide bar
from being caught in the cut.
A Log lying on the ground (F20)
Saw down halfway, then roll the log over and
cut from the opposite side.
A Log hanging off the ground (F21)
In area A, saw up from the bottom one-third and
nish by sawing down from the top. In area B,
saw down from the top one-third and nish by
sawing up from the bottom.
Cutting Limb of Fallen Tree (F22)
First check to which side the limb is bent. Then
make the initial cut from the bent side and nish
by sawing from the opposite side.
WARNING
Be alert to the springing back of a cut limb.
Pruning of Standing Tree (F23)
Cut up from the bottom, nish down from the
top.
WARNING
Do not use an unstable foothold or ladder.
Do not overreach.
Do not cut above shoulder height.
Always use your both hands to grip the saw.
A Log lying on the ground (F21)
Saw down halfway, then roll the log over
and cut from the opposite side.
A Log hanging off the ground (F22)
In area A, saw up from the bottom one-third
and finish by sawing down from the top. In
area B, saw down from the top one-third
and finish by sawing up from the bottom.
Cutting Limb of Fallen Tree (F23)
First check to which side the limb is bent.
Then make the initial cut from the bent side
and finish by sawing from the opposite
side.
Be alert to the springing back of a cut limb.
Pruning of Standing Tree (F24)
Cut up from the bottom, finish down from
the top.
Do not use an unstable foothold or ladder.
Do not overreach.
Do not cut above shoulder height.
Always use your both hands to grip the
saw.
WARNING
Before cleaning, inspecting or repairing
your unit, make sure that engine has
stopped and is cool. Disconnect the spark
plug to prevent accidental starting.
MAINTENANCE AFTER EACH USE
1. Air filter
Dust on the cleaner surface can be
removed by tapping a corner of the cleaner
against a hard surface. To clean dirt in the
meshes, split the cleaner into halves and
brush in gasoline. When using compressed
air, blow from the inside. (F25)
To assemble the cleaner halves, press the
rim until it clicks.
NOTE
When installing the main filler, make sure
that the grooves on the filter edge are
correctly fit with the projections on the
cylinder cover.
2. Oiling port
Dismount the guide bar and check the
oiling port for clogging. (F26)
(1) Oiling port
3. Guide bar
When the guide bar is dismounted, remove
sawdust in the bar groove and the oiling
port. (F27)
Grease the nose sprocket from the feeding
port on the tip of the bar. (F28)
(1) Oiling port
(2) Grease port
(3) Sprocket
4.Others
Check for fuel leakage and loose fastenings
and damage to major parts, especially
handle joints and guide bar mounting.. If
any defects are found, make sure to have
them repaired before operation again.
A Log lying on the ground (F21)
Saw down halfway, then roll the log over
and cut from the opposite side.
A Log hanging off the ground (F22)
In area A, saw up from the bottom one-third
and finish by sawing down from the top. In
area B, saw down from the top one-third
and finish by sawing up from the bottom.
Cutting Limb of Fallen Tree (F23)
First check to which side the limb is bent.
Then make the initial cut from the bent side
and finish by sawing from the opposite
side.
Be alert to the springing back of a cut limb.
Pruning of Standing Tree (F24)
Cut up from the bottom, finish down from
the top.
Do not use an unstable foothold or ladder.
Do not overreach.
Do not cut above shoulder height.
Always use your both hands to grip the
saw.
WARNING
Before cleaning, inspecting or repairing
your unit, make sure that engine has
stopped and is cool. Disconnect the spark
plug to prevent accidental starting.
MAINTENANCE AFTER EACH USE
1. Air filter
Dust on the cleaner surface can be
removed by tapping a corner of the cleaner
against a hard surface. To clean dirt in the
meshes, split the cleaner into halves and
brush in gasoline. When using compressed
air, blow from the inside. (F25)
To assemble the cleaner halves, press the
rim until it clicks.
NOTE
When installing the main filler, make sure
that the grooves on the filter edge are
correctly fit with the projections on the
cylinder cover.
2. Oiling port
Dismount the guide bar and check the
oiling port for clogging. (F26)
(1) Oiling port
3. Guide bar
When the guide bar is dismounted, remove
sawdust in the bar groove and the oiling
port. (F27)
Grease the nose sprocket from the feeding
port on the tip of the bar. (F28)
(1) Oiling port
(2) Grease port
(3) Sprocket
4.Others
Check for fuel leakage and loose fastenings
and damage to major parts, especially
handle joints and guide bar mounting.. If
any defects are found, make sure to have
them repaired before operation again.
A Log lying on the ground (F21)
Saw down halfway, then roll the log over
and cut from the opposite side.
A Log hanging off the ground (F22)
In area A, saw up from the bottom one-third
and finish by sawing down from the top. In
area B, saw down from the top one-third
and finish by sawing up from the bottom.
Cutting Limb of Fallen Tree (F23)
First check to which side the limb is bent.
Then make the initial cut from the bent side
and finish by sawing from the opposite
side.
Be alert to the springing back of a cut limb.
Pruning of Standing Tree (F24)
Cut up from the bottom, finish down from
the top.
Do not use an unstable foothold or ladder.
Do not overreach.
Do not cut above shoulder height.
Always use your both hands to grip the
saw.
WARNING
Before cleaning, inspecting or repairing
your unit, make sure that engine has
stopped and is cool. Disconnect the spark
plug to prevent accidental starting.
MAINTENANCE AFTER EACH USE
1. Air filter
Dust on the cleaner surface can be
removed by tapping a corner of the cleaner
against a hard surface. To clean dirt in the
meshes, split the cleaner into halves and
brush in gasoline. When using compressed
air, blow from the inside. (F25)
To assemble the cleaner halves, press the
rim until it clicks.
NOTE
When installing the main filler, make sure
that the grooves on the filter edge are
correctly fit with the projections on the
cylinder cover.
2. Oiling port
Dismount the guide bar and check the
oiling port for clogging. (F26)
(1) Oiling port
3. Guide bar
When the guide bar is dismounted, remove
sawdust in the bar groove and the oiling
port. (F27)
Grease the nose sprocket from the feeding
port on the tip of the bar. (F28)
(1) Oiling port
(2) Grease port
(3) Sprocket
4.Others
Check for fuel leakage and loose fastenings
and damage to major parts, especially
handle joints and guide bar mounting.. If
any defects are found, make sure to have
them repaired before operation again.
A Log lying on the ground (F21)
Saw down halfway, then roll the log over
and cut from the opposite side.
A Log hanging off the ground (F22)
In area A, saw up from the bottom one-third
and finish by sawing down from the top. In
area B, saw down from the top one-third
and finish by sawing up from the bottom.
Cutting Limb of Fallen Tree (F23)
First check to which side the limb is bent.
Then make the initial cut from the bent side
and finish by sawing from the opposite
side.
Be alert to the springing back of a cut limb.
Pruning of Standing Tree (F24)
Cut up from the bottom, finish down from
the top.
Do not use an unstable foothold or ladder.
Do not overreach.
Do not cut above shoulder height.
Always use your both hands to grip the
saw.
WARNING
Before cleaning, inspecting or repairing
your unit, make sure that engine has
stopped and is cool. Disconnect the spark
plug to prevent accidental starting.
MAINTENANCE AFTER EACH USE
1. Air filter
Dust on the cleaner surface can be
removed by tapping a corner of the cleaner
against a hard surface. To clean dirt in the
meshes, split the cleaner into halves and
brush in gasoline. When using compressed
air, blow from the inside. (F25)
To assemble the cleaner halves, press the
rim until it clicks.
NOTE
When installing the main filler, make sure
that the grooves on the filter edge are
correctly fit with the projections on the
cylinder cover.
2. Oiling port
Dismount the guide bar and check the
oiling port for clogging. (F26)
(1) Oiling port
3. Guide bar
When the guide bar is dismounted, remove
sawdust in the bar groove and the oiling
port. (F27)
Grease the nose sprocket from the feeding
port on the tip of the bar. (F28)
(1) Oiling port
(2) Grease port
(3) Sprocket
4.Others
Check for fuel leakage and loose fastenings
and damage to major parts, especially
handle joints and guide bar mounting.. If
any defects are found, make sure to have
them repaired before operation again.
F20 F21
F22 F23
WARNING
Before cleaning, inspecting or repairing your
unit, make sure that engine has stopped and
is cool. Disconnect the spark plug to prevent
accidental starting.
MAINTENANCE AFTER EACH USE
1. Air lter.
Dust on the cleaner surface can be removed by
tapping a corner of the cleaner against a hard
surface. When using compressed air, blow from
the inside. (F24)
NOTE
When installing the main ller, make sure that
the grooves on the lter edge are correctly tted
with the projections on the cylinder cover.
2. Oiling port.
Dismount the guide bar and check the oiling
port for clogging. (F25)
a. Oiling port.
3. Guide bar.
When the guide bar is dismounted, remove
sawdust in the bar groove and the oiling port.
(F26)
Grease the nose sprocket from the feeding port
on the tip of the bar. (F27)
1. Oiling port.
2. Grease port.
3. Sprocket.
4. Others.
Check for fuel leakage and loose fastenings
and damage to major parts, especially handle
joints and guide bar mounting. If any defects are
found, make sure to have them repaired before
operation again.
All manuals and user guides at all-guides.com
all-guides.com
12
■
PERIODICAL SERVICE POINTS
1. Cylinder fins
Dust clogging between the cylinder
fins will cause overheating of the
engine. Periodically check and clean
the cylinder fins after removing the
air cleaner and the cylinder cover.
When installing the cylinder cover,
make sure that switch wires and
grommets are positioned correctly
in place. (F29)
NOTE
Be sure to block the air intake hole.
2. Fuel filter
(a) Using a wire hook, take out the
filter from the filler port. (F30)
(1) Fuel filter
(b) Disassemble the filter and wash
with gasoline, or replace with new
one if needed.
NOTE
After removing the filter, use a pinch
to hold the end of the suction pipe.
When assembling the filter, take
care not to allow filter fibers or dust
inside the suction pipe.
3.Oil tank
With a wire hook, take out the oil
filter through the filler port and clean
in gasoline. When putting the filter
back into the tank, make sure that it
comes to the front right corner. Also
clean off dirt in the tank. (F31)
Remove the recoil starter
，
then clean
the air inlet of oil breather
。
(2) Oil filter
4. Spark plug (F32)
Clean the electrodes with a wire
brush and reset the gap to 0.65 mm
as necessary.
5. Sprocket (F33)
Check for cracks and for excessive
wear interfering with the chain drive.
If the wearing is found obviously,
replace it with new one. Never fit a
new chain on a worn sprocket, or a
worn chain on a new sprocket.
6. Front and Rear dampers
Replace if adhered part is peeled or
crack is observed on the rubber
part.
A Log lying on the ground (F21)
Saw down halfway, then roll the log over
and cut from the opposite side.
A Log hanging off the ground (F22)
In area A, saw up from the bottom one-third
and finish by sawing down from the top. In
area B, saw down from the top one-third
and finish by sawing up from the bottom.
Cutting Limb of Fallen Tree (F23)
First check to which side the limb is bent.
Then make the initial cut from the bent side
and finish by sawing from the opposite
side.
Be alert to the springing back of a cut limb.
Pruning of Standing Tree (F24)
Cut up from the bottom, finish down from
the top.
Do not use an unstable foothold or ladder.
Do not overreach.
Do not cut above shoulder height.
Always use your both hands to grip the
saw.
WARNING
Before cleaning, inspecting or repairing
your unit, make sure that engine has
stopped and is cool. Disconnect the spark
plug to prevent accidental starting.
MAINTENANCE AFTER EACH USE
1. Air filter
Dust on the cleaner surface can be
removed by tapping a corner of the cleaner
against a hard surface. To clean dirt in the
meshes, split the cleaner into halves and
brush in gasoline. When using compressed
air, blow from the inside. (F25)
To assemble the cleaner halves, press the
rim until it clicks.
NOTE
When installing the main filler, make sure
that the grooves on the filter edge are
correctly fit with the projections on the
cylinder cover.
2. Oiling port
Dismount the guide bar and check the
oiling port for clogging. (F26)
(1) Oiling port
3. Guide bar
When the guide bar is dismounted, remove
sawdust in the bar groove and the oiling
port. (F27)
Grease the nose sprocket from the feeding
port on the tip of the bar. (F28)
(1) Oiling port
(2) Grease port
(3) Sprocket
4.Others
Check for fuel leakage and loose fastenings
and damage to major parts, especially
handle joints and guide bar mounting.. If
any defects are found, make sure to have
them repaired before operation again.
A Log lying on the ground (F21)
Saw down halfway, then roll the log over
and cut from the opposite side.
A Log hanging off the ground (F22)
In area A, saw up from the bottom one-third
and finish by sawing down from the top. In
area B, saw down from the top one-third
and finish by sawing up from the bottom.
Cutting Limb of Fallen Tree (F23)
First check to which side the limb is bent.
Then make the initial cut from the bent side
and finish by sawing from the opposite
side.
Be alert to the springing back of a cut limb.
Pruning of Standing Tree (F24)
Cut up from the bottom, finish down from
the top.
Do not use an unstable foothold or ladder.
Do not overreach.
Do not cut above shoulder height.
Always use your both hands to grip the
saw.
WARNING
Before cleaning, inspecting or repairing
your unit, make sure that engine has
stopped and is cool. Disconnect the spark
plug to prevent accidental starting.
MAINTENANCE AFTER EACH USE
1. Air filter
Dust on the cleaner surface can be
removed by tapping a corner of the cleaner
against a hard surface. To clean dirt in the
meshes, split the cleaner into halves and
brush in gasoline. When using compressed
air, blow from the inside. (F25)
To assemble the cleaner halves, press the
rim until it clicks.
NOTE
When installing the main filler, make sure
that the grooves on the filter edge are
correctly fit with the projections on the
cylinder cover.
2. Oiling port
Dismount the guide bar and check the
oiling port for clogging. (F26)
(1) Oiling port
3. Guide bar
When the guide bar is dismounted, remove
sawdust in the bar groove and the oiling
port. (F27)
Grease the nose sprocket from the feeding
port on the tip of the bar. (F28)
(1) Oiling port
(2) Grease port
(3) Sprocket
4.Others
Check for fuel leakage and loose fastenings
and damage to major parts, especially
handle joints and guide bar mounting.. If
any defects are found, make sure to have
them repaired before operation again.
A Log lying on the ground (F21)
Saw down halfway, then roll the log over
and cut from the opposite side.
A Log hanging off the ground (F22)
In area A, saw up from the bottom one-third
and finish by sawing down from the top. In
area B, saw down from the top one-third
and finish by sawing up from the bottom.
Cutting Limb of Fallen Tree (F23)
First check to which side the limb is bent.
Then make the initial cut from the bent side
and finish by sawing from the opposite
side.
Be alert to the springing back of a cut limb.
Pruning of Standing Tree (F24)
Cut up from the bottom, finish down from
the top.
Do not use an unstable foothold or ladder.
Do not overreach.
Do not cut above shoulder height.
Always use your both hands to grip the
saw.
WARNING
Before cleaning, inspecting or repairing
your unit, make sure that engine has
stopped and is cool. Disconnect the spark
plug to prevent accidental starting.
MAINTENANCE AFTER EACH USE
1. Air filter
Dust on the cleaner surface can be
removed by tapping a corner of the cleaner
against a hard surface. To clean dirt in the
meshes, split the cleaner into halves and
brush in gasoline. When using compressed
air, blow from the inside. (F25)
To assemble the cleaner halves, press the
rim until it clicks.
NOTE
When installing the main filler, make sure
that the grooves on the filter edge are
correctly fit with the projections on the
cylinder cover.
2. Oiling port
Dismount the guide bar and check the
oiling port for clogging. (F26)
(1) Oiling port
3. Guide bar
When the guide bar is dismounted, remove
sawdust in the bar groove and the oiling
port. (F27)
Grease the nose sprocket from the feeding
port on the tip of the bar. (F28)
(1) Oiling port
(2) Grease port
(3) Sprocket
4.Others
Check for fuel leakage and loose fastenings
and damage to major parts, especially
handle joints and guide bar mounting.. If
any defects are found, make sure to have
them repaired before operation again.
A Log lying on the ground (F21)
Saw down halfway, then roll the log over
and cut from the opposite side.
A Log hanging off the ground (F22)
In area A, saw up from the bottom one-third
and finish by sawing down from the top. In
area B, saw down from the top one-third
and finish by sawing up from the bottom.
Cutting Limb of Fallen Tree (F23)
First check to which side the limb is bent.
Then make the initial cut from the bent side
and finish by sawing from the opposite
side.
Be alert to the springing back of a cut limb.
Pruning of Standing Tree (F24)
Cut up from the bottom, finish down from
the top.
Do not use an unstable foothold or ladder.
Do not overreach.
Do not cut above shoulder height.
Always use your both hands to grip the
saw.
WARNING
Before cleaning, inspecting or repairing
your unit, make sure that engine has
stopped and is cool. Disconnect the spark
plug to prevent accidental starting.
MAINTENANCE AFTER EACH USE
1. Air filter
Dust on the cleaner surface can be
removed by tapping a corner of the cleaner
against a hard surface. To clean dirt in the
meshes, split the cleaner into halves and
brush in gasoline. When using compressed
air, blow from the inside. (F25)
To assemble the cleaner halves, press the
rim until it clicks.
NOTE
When installing the main filler, make sure
that the grooves on the filter edge are
correctly fit with the projections on the
cylinder cover.
2. Oiling port
Dismount the guide bar and check the
oiling port for clogging. (F26)
(1) Oiling port
3. Guide bar
When the guide bar is dismounted, remove
sawdust in the bar groove and the oiling
port. (F27)
Grease the nose sprocket from the feeding
port on the tip of the bar. (F28)
(1) Oiling port
(2) Grease port
(3) Sprocket
4.Others
Check for fuel leakage and loose fastenings
and damage to major parts, especially
handle joints and guide bar mounting.. If
any defects are found, make sure to have
them repaired before operation again.
F24 F25
F26 F27
5. Sprocket. (F32)
Check for cracks and for excessive wear
interfering with the chain drive. If the wearing is
found obviously, replace it with new one. Never
t a new chain on a worn sprocket, or a worn
chain on a new sprocket.
6. Front and Rear dampers.
Replace if adhered part is peeled or crack is
observed on the rubber part.
SAW CHAIN
WARNING
It is very important for smooth and safe
operation to keep the cutters always sharp.
Your cutters need to be sharpened when:
• Sawdust becomes powder-like.
• You need extra force to saw in.
• The cut way does not go straight.
• Vibration increases.
• Fuel consumption increases.
WARNING
Cutter setting standards: Be sure to wear safety
gloves. Before ling:
• Make sure the saw chain is held securely.
• Make sure the engine is stopped.
• Use a round le of proper size for your
chain.
Chain type: 20BP
File size: 3/16 in 4.76mm
Place your le on the cutter and push straight
forward. Keep the le position as illustrated.
(F33)
After every cutter has been set, check the
depth gauge and le it to the proper level as
illustrated. (F34)
■
PERIODICAL SERVICE POINTS
1. Cylinder fins
Dust clogging between the cylinder
fins will cause overheating of the
engine. Periodically check and clean
the cylinder fins after removing the
air cleaner and the cylinder cover.
When installing the cylinder cover,
make sure that switch wires and
grommets are positioned correctly
in place. (F29)
NOTE
Be sure to block the air intake hole.
2. Fuel filter
(a) Using a wire hook, take out the
filter from the filler port. (F30)
(1) Fuel filter
(b) Disassemble the filter and wash
with gasoline, or replace with new
one if needed.
NOTE
After removing the filter, use a pinch
to hold the end of the suction pipe.
When assembling the filter, take
care not to allow filter fibers or dust
inside the suction pipe.
3.Oil tank
With a wire hook, take out the oil
filter through the filler port and clean
in gasoline. When putting the filter
back into the tank, make sure that it
comes to the front right corner. Also
clean off dirt in the tank. (F31)
Remove the recoil starter
，
then clean
the air inlet of oil breather
。
(2) Oil filter
4. Spark plug (F32)
Clean the electrodes with a wire
brush and reset the gap to 0.65 mm
as necessary.
5. Sprocket (F33)
Check for cracks and for excessive
wear interfering with the chain drive.
If the wearing is found obviously,
replace it with new one. Never fit a
new chain on a worn sprocket, or a
worn chain on a new sprocket.
6. Front and Rear dampers
Replace if adhered part is peeled or
crack is observed on the rubber
part.
■
PERIODICAL SERVICE POINTS
1. Cylinder fins
Dust clogging between the cylinder
fins will cause overheating of the
engine. Periodically check and clean
the cylinder fins after removing the
air cleaner and the cylinder cover.
When installing the cylinder cover,
make sure that switch wires and
grommets are positioned correctly
in place. (F29)
NOTE
Be sure to block the air intake hole.
2. Fuel filter
(a) Using a wire hook, take out the
filter from the filler port. (F30)
(1) Fuel filter
(b) Disassemble the filter and wash
with gasoline, or replace with new
one if needed.
NOTE
After removing the filter, use a pinch
to hold the end of the suction pipe.
When assembling the filter, take
care not to allow filter fibers or dust
inside the suction pipe.
3.Oil tank
With a wire hook, take out the oil
filter through the filler port and clean
in gasoline. When putting the filter
back into the tank, make sure that it
comes to the front right corner. Also
clean off dirt in the tank. (F31)
Remove the recoil starter
，
then clean
the air inlet of oil breather
。
(2) Oil filter
4. Spark plug (F32)
Clean the electrodes with a wire
brush and reset the gap to 0.65 mm
as necessary.
5. Sprocket (F33)
Check for cracks and for excessive
wear interfering with the chain drive.
If the wearing is found obviously,
replace it with new one. Never fit a
new chain on a worn sprocket, or a
worn chain on a new sprocket.
6. Front and Rear dampers
Replace if adhered part is peeled or
crack is observed on the rubber
part.
■
PERIODICAL SERVICE POINTS
1. Cylinder fins
Dust clogging between the cylinder
fins will cause overheating of the
engine. Periodically check and clean
the cylinder fins after removing the
air cleaner and the cylinder cover.
When installing the cylinder cover,
make sure that switch wires and
grommets are positioned correctly
in place. (F29)
NOTE
Be sure to block the air intake hole.
2. Fuel filter
(a) Using a wire hook, take out the
filter from the filler port. (F30)
(1) Fuel filter
(b) Disassemble the filter and wash
with gasoline, or replace with new
one if needed.
NOTE
After removing the filter, use a pinch
to hold the end of the suction pipe.
When assembling the filter, take
care not to allow filter fibers or dust
inside the suction pipe.
3.Oil tank
With a wire hook, take out the oil
filter through the filler port and clean
in gasoline. When putting the filter
back into the tank, make sure that it
comes to the front right corner. Also
clean off dirt in the tank. (F31)
Remove the recoil starter
，
then clean
the air inlet of oil breather
。
(2) Oil filter
4. Spark plug (F32)
Clean the electrodes with a wire
brush and reset the gap to 0.65 mm
as necessary.
5. Sprocket (F33)
Check for cracks and for excessive
wear interfering with the chain drive.
If the wearing is found obviously,
replace it with new one. Never fit a
new chain on a worn sprocket, or a
worn chain on a new sprocket.
6. Front and Rear dampers
Replace if adhered part is peeled or
crack is observed on the rubber
part.
■
PERIODICAL SERVICE POINTS
1. Cylinder fins
Dust clogging between the cylinder
fins will cause overheating of the
engine. Periodically check and clean
the cylinder fins after removing the
air cleaner and the cylinder cover.
When installing the cylinder cover,
make sure that switch wires and
grommets are positioned correctly
in place. (F29)
NOTE
Be sure to block the air intake hole.
2. Fuel filter
(a) Using a wire hook, take out the
filter from the filler port. (F30)
(1) Fuel filter
(b) Disassemble the filter and wash
with gasoline, or replace with new
one if needed.
NOTE
After removing the filter, use a pinch
to hold the end of the suction pipe.
When assembling the filter, take
care not to allow filter fibers or dust
inside the suction pipe.
3.Oil tank
With a wire hook, take out the oil
filter through the filler port and clean
in gasoline. When putting the filter
back into the tank, make sure that it
comes to the front right corner. Also
clean off dirt in the tank. (F31)
Remove the recoil starter
，
then clean
the air inlet of oil breather
。
(2) Oil filter
4. Spark plug (F32)
Clean the electrodes with a wire
brush and reset the gap to 0.65 mm
as necessary.
5. Sprocket (F33)
Check for cracks and for excessive
wear interfering with the chain drive.
If the wearing is found obviously,
replace it with new one. Never fit a
new chain on a worn sprocket, or a
worn chain on a new sprocket.
6. Front and Rear dampers
Replace if adhered part is peeled or
crack is observed on the rubber
part.
F28 F29
F30 F31
F32
PERIODICAL SERVICE POINTS
1. Cylinder ns.
Dust clogging between the cylinder ns will
cause overheating of the engine. Periodically
check and clean the cylinder ns after removing
the air cleaner and the cylinder cover. When
installing the cylinder cover, make sure that
switch wires and grommets are positioned
correctly in place. (F28)
NOTE
Be sure to block the air intake hole.
2. Fuel lter.
a. Using a wire hook, take out the lter from the
ller port. (F29)
b. Fuel lter.
c. Disassemble the lter and wash with
gasoline, or replace with new one if needed.
NOTE
After removing the lter, use a pinch to hold the
end of the suction pipe.
When assembling the lter, take care not to
allow lter bres or dust inside the suction pipe.
3. Oil tank.
With a wire hook, take out the oil lter through
the ller port and clean in gasoline. When
putting the lter back into the tank, make sure
that it comes to the front right corner. Also clean
off dirt in the tank. (F30)
Remove the recoil starter, then clean the air
inlet of oil breather.
a. Oil lter
4. Spark plug. (F31)
Clean the electrodes with a wire brush and
reset the gap to 0.65 mm as necessary.
All manuals and user guides at all-guides.com
13
■SAW CHAIN
It is very important for smooth and safe
operation to keep the cutters always sharp.
Your cutters need to be sharpened when
：
·
Sawdust becomes powder-like.
·
You need extra force to saw in.
·
The cut way does not go straight.
·
Vibration increases.
·
Fuel consumption increases.
Cutter setting standards:
Be sure to wear safety gloves.
Before filing:
Make sure the saw chain is held securely.
Make sure the engine is stopped.
Use a round file of proper size for your
chain.
Chain type: 21BP
File size: 3/16 in
（
4.76mm
）
Place your file on the cutter and push
straight forward. Keep the file position as
illustrated. (F34)
After every cutter has been set, check the
depth gauge and file it to the proper level as
illustrated. (F35)
Be sure to round off the front edge to
reduce the chance of kickback or tie-strap
breakage.
(1) Appropriate gauge checker.
(2) Make the shoulder round
(3) Depth gauge standard
Make sure every cutter has the same length
and edge angles as illustrated (F36)
(4) Cutter length
(5) Filing angle
(6) Side plate angle
(7) Top plate cutting angle
■GUIDE BAR
·
Reverse the bar occasionally to prevent
partial wear.
·
The bar rail should always be a square.
Check for wear of the bar rail. Apply a ruler
to the bar and the outside of a cutter. If a
gap is observed between them, the rail is
normal. Otherwise, the bar rail is worn.
Such a bar needs to be corrected or
replaced. (F37)
(1) Ruler
(2) Gap
(3) No gap
(4) Chain tilts
■SAW CHAIN
It is very important for smooth and safe
operation to keep the cutters always sharp.
Your cutters need to be sharpened when
：
·
Sawdust becomes powder-like.
·
You need extra force to saw in.
·
The cut way does not go straight.
·
Vibration increases.
·
Fuel consumption increases.
Cutter setting standards:
Be sure to wear safety gloves.
Before filing:
Make sure the saw chain is held securely.
Make sure the engine is stopped.
Use a round file of proper size for your
chain.
Chain type: 21BP
File size: 3/16 in
（
4.76mm
）
Place your file on the cutter and push
straight forward. Keep the file position as
illustrated. (F34)
After every cutter has been set, check the
depth gauge and file it to the proper level as
illustrated. (F35)
Be sure to round off the front edge to
reduce the chance of kickback or tie-strap
breakage.
(1) Appropriate gauge checker.
(2) Make the shoulder round
(3) Depth gauge standard
Make sure every cutter has the same length
and edge angles as illustrated (F36)
(4) Cutter length
(5) Filing angle
(6) Side plate angle
(7) Top plate cutting angle
■GUIDE BAR
·
Reverse the bar occasionally to prevent
partial wear.
·
The bar rail should always be a square.
Check for wear of the bar rail. Apply a ruler
to the bar and the outside of a cutter. If a
gap is observed between them, the rail is
normal. Otherwise, the bar rail is worn.
Such a bar needs to be corrected or
replaced. (F37)
(1) Ruler
(2) Gap
(3) No gap
(4) Chain tilts
■SAW CHAIN
It is very important for smooth and safe
operation to keep the cutters always sharp.
Your cutters need to be sharpened when
：
·
Sawdust becomes powder-like.
·
You need extra force to saw in.
·
The cut way does not go straight.
·
Vibration increases.
·
Fuel consumption increases.
Cutter setting standards:
Be sure to wear safety gloves.
Before filing:
Make sure the saw chain is held securely.
Make sure the engine is stopped.
Use a round file of proper size for your
chain.
Chain type: 21BP
File size: 3/16 in
（
4.76mm
）
Place your file on the cutter and push
straight forward. Keep the file position as
illustrated. (F34)
After every cutter has been set, check the
depth gauge and file it to the proper level as
illustrated. (F35)
Be sure to round off the front edge to
reduce the chance of kickback or tie-strap
breakage.
(1) Appropriate gauge checker.
(2) Make the shoulder round
(3) Depth gauge standard
Make sure every cutter has the same length
and edge angles as illustrated (F36)
(4) Cutter length
(5) Filing angle
(6) Side plate angle
(7) Top plate cutting angle
■GUIDE BAR
·
Reverse the bar occasionally to prevent
partial wear.
·
The bar rail should always be a square.
Check for wear of the bar rail. Apply a ruler
to the bar and the outside of a cutter. If a
gap is observed between them, the rail is
normal. Otherwise, the bar rail is worn.
Such a bar needs to be corrected or
replaced. (F37)
(1) Ruler
(2) Gap
(3) No gap
(4) Chain tilts
■SAW CHAIN
It is very important for smooth and safe
operation to keep the cutters always sharp.
Your cutters need to be sharpened when
：
·
Sawdust becomes powder-like.
·
You need extra force to saw in.
·
The cut way does not go straight.
·
Vibration increases.
·
Fuel consumption increases.
Cutter setting standards:
Be sure to wear safety gloves.
Before filing:
Make sure the saw chain is held securely.
Make sure the engine is stopped.
Use a round file of proper size for your
chain.
Chain type: 21BP
File size: 3/16 in
（
4.76mm
）
Place your file on the cutter and push
straight forward. Keep the file position as
illustrated. (F34)
After every cutter has been set, check the
depth gauge and file it to the proper level as
illustrated. (F35)
Be sure to round off the front edge to
reduce the chance of kickback or tie-strap
breakage.
(1) Appropriate gauge checker.
(2) Make the shoulder round
(3) Depth gauge standard
Make sure every cutter has the same length
and edge angles as illustrated (F36)
(4) Cutter length
(5) Filing angle
(6) Side plate angle
(7) Top plate cutting angle
■GUIDE BAR
·
Reverse the bar occasionally to prevent
partial wear.
·
The bar rail should always be a square.
Check for wear of the bar rail. Apply a ruler
to the bar and the outside of a cutter. If a
gap is observed between them, the rail is
normal. Otherwise, the bar rail is worn.
Such a bar needs to be corrected or
replaced. (F37)
(1) Ruler
(2) Gap
(3) No gap
(4) Chain tilts
F33 F33 F34 F34
■SAW CHAIN
It is very important for smooth and safe
operation to keep the cutters always sharp.
Your cutters need to be sharpened when
：
·
Sawdust becomes powder-like.
·
You need extra force to saw in.
·
The cut way does not go straight.
·
Vibration increases.
·
Fuel consumption increases.
Cutter setting standards:
Be sure to wear safety gloves.
Before filing:
Make sure the saw chain is held securely.
Make sure the engine is stopped.
Use a round file of proper size for your
chain.
Chain type: 21BP
File size: 3/16 in
（
4.76mm
）
Place your file on the cutter and push
straight forward. Keep the file position as
illustrated. (F34)
After every cutter has been set, check the
depth gauge and file it to the proper level as
illustrated. (F35)
Be sure to round off the front edge to
reduce the chance of kickback or tie-strap
breakage.
(1) Appropriate gauge checker.
(2) Make the shoulder round
(3) Depth gauge standard
Make sure every cutter has the same length
and edge angles as illustrated (F36)
(4) Cutter length
(5) Filing angle
(6) Side plate angle
(7) Top plate cutting angle
■GUIDE BAR
·
Reverse the bar occasionally to prevent
partial wear.
·
The bar rail should always be a square.
Check for wear of the bar rail. Apply a ruler
to the bar and the outside of a cutter. If a
gap is observed between them, the rail is
normal. Otherwise, the bar rail is worn.
Such a bar needs to be corrected or
replaced. (F37)
(1) Ruler
(2) Gap
(3) No gap
(4) Chain tilts
■SAW CHAIN
It is very important for smooth and safe
operation to keep the cutters always sharp.
Your cutters need to be sharpened when
：
·
Sawdust becomes powder-like.
·
You need extra force to saw in.
·
The cut way does not go straight.
·
Vibration increases.
·
Fuel consumption increases.
Cutter setting standards:
Be sure to wear safety gloves.
Before filing:
Make sure the saw chain is held securely.
Make sure the engine is stopped.
Use a round file of proper size for your
chain.
Chain type: 21BP
File size: 3/16 in
（
4.76mm
）
Place your file on the cutter and push
straight forward. Keep the file position as
illustrated. (F34)
After every cutter has been set, check the
depth gauge and file it to the proper level as
illustrated. (F35)
Be sure to round off the front edge to
reduce the chance of kickback or tie-strap
breakage.
(1) Appropriate gauge checker.
(2) Make the shoulder round
(3) Depth gauge standard
Make sure every cutter has the same length
and edge angles as illustrated (F36)
(4) Cutter length
(5) Filing angle
(6) Side plate angle
(7) Top plate cutting angle
■GUIDE BAR
·
Reverse the bar occasionally to prevent
partial wear.
·
The bar rail should always be a square.
Check for wear of the bar rail. Apply a ruler
to the bar and the outside of a cutter. If a
gap is observed between them, the rail is
normal. Otherwise, the bar rail is worn.
Such a bar needs to be corrected or
replaced. (F37)
(1) Ruler
(2) Gap
(3) No gap
(4) Chain tilts
F35
■SAW CHAIN
It is very important for smooth and safe
operation to keep the cutters always sharp.
Your cutters need to be sharpened when
：
·
Sawdust becomes powder-like.
·
You need extra force to saw in.
·
The cut way does not go straight.
·
Vibration increases.
·
Fuel consumption increases.
Cutter setting standards:
Be sure to wear safety gloves.
Before filing:
Make sure the saw chain is held securely.
Make sure the engine is stopped.
Use a round file of proper size for your
chain.
Chain type: 21BP
File size: 3/16 in
（
4.76mm
）
Place your file on the cutter and push
straight forward. Keep the file position as
illustrated. (F34)
After every cutter has been set, check the
depth gauge and file it to the proper level as
illustrated. (F35)
Be sure to round off the front edge to
reduce the chance of kickback or tie-strap
breakage.
(1) Appropriate gauge checker.
(2) Make the shoulder round
(3) Depth gauge standard
Make sure every cutter has the same length
and edge angles as illustrated (F36)
(4) Cutter length
(5) Filing angle
(6) Side plate angle
(7) Top plate cutting angle
■GUIDE BAR
·
Reverse the bar occasionally to prevent
partial wear.
·
The bar rail should always be a square.
Check for wear of the bar rail. Apply a ruler
to the bar and the outside of a cutter. If a
gap is observed between them, the rail is
normal. Otherwise, the bar rail is worn.
Such a bar needs to be corrected or
replaced. (F37)
(1) Ruler
(2) Gap
(3) No gap
(4) Chain tilts
SAW CHAIN (CONTINUED)
WARNING
Be sure to round off the front edge to reduce the
chance of kickback or tie-strap breakage.
a. Appropriate gauge checker.
b. Make the shoulder round.
c. Depth gauge standard.
Make sure every cutter has the same length
and edge angles as illustrated. (F35)
d. Cutter length.
e. Filing angle.
f. Side plate angle.
g. Top plate cutting angle.
GUIDE BAR
• Reverse the bar occasionally to prevent
partial wear.
• The bar rail should always be a square.
Check for wear of the bar rail. Apply a ruler
to the bar and the outside of a cutter. If a
gap is observed between them, the rail is
normal. Otherwise, the bar rail is worn. Such
a bar needs to be corrected or replaced.
(F36)
a. Ruler.
b. Gap.
c. No gap.
d. Chain tilts.
CASE 1. STARTING FAILURE:
• Check water for fuel or substandard mixture
- Replace with proper fuel.
• Check for engine ooding
- Remove and dry the spark plug. Then pull
the starter again with no choke.
• Check the spark
- Replace with a new plug.
■SAW CHAIN
It is very important for smooth and safe
operation to keep the cutters always sharp.
Your cutters need to be sharpened when
：
·
Sawdust becomes powder-like.
·
You need extra force to saw in.
·
The cut way does not go straight.
·
Vibration increases.
·
Fuel consumption increases.
Cutter setting standards:
Be sure to wear safety gloves.
Before filing:
Make sure the saw chain is held securely.
Make sure the engine is stopped.
Use a round file of proper size for your
chain.
Chain type: 21BP
File size: 3/16 in
（
4.76mm
）
Place your file on the cutter and push
straight forward. Keep the file position as
illustrated. (F34)
After every cutter has been set, check the
depth gauge and file it to the proper level as
illustrated. (F35)
Be sure to round off the front edge to
reduce the chance of kickback or tie-strap
breakage.
(1) Appropriate gauge checker.
(2) Make the shoulder round
(3) Depth gauge standard
Make sure every cutter has the same length
and edge angles as illustrated (F36)
(4) Cutter length
(5) Filing angle
(6) Side plate angle
(7) Top plate cutting angle
■GUIDE BAR
·
Reverse the bar occasionally to prevent
partial wear.
·
The bar rail should always be a square.
Check for wear of the bar rail. Apply a ruler
to the bar and the outside of a cutter. If a
gap is observed between them, the rail is
normal. Otherwise, the bar rail is worn.
Such a bar needs to be corrected or
replaced. (F37)
(1) Ruler
(2) Gap
(3) No gap
(4) Chain tilts
F36
■SAW CHAIN
It is very important for smooth and safe
operation to keep the cutters always sharp.
Your cutters need to be sharpened when
：
·
Sawdust becomes powder-like.
·
You need extra force to saw in.
·
The cut way does not go straight.
·
Vibration increases.
·
Fuel consumption increases.
Cutter setting standards:
Be sure to wear safety gloves.
Before filing:
Make sure the saw chain is held securely.
Make sure the engine is stopped.
Use a round file of proper size for your
chain.
Chain type: 21BP
File size: 3/16 in
（
4.76mm
）
Place your file on the cutter and push
straight forward. Keep the file position as
illustrated. (F34)
After every cutter has been set, check the
depth gauge and file it to the proper level as
illustrated. (F35)
Be sure to round off the front edge to
reduce the chance of kickback or tie-strap
breakage.
(1) Appropriate gauge checker.
(2) Make the shoulder round
(3) Depth gauge standard
Make sure every cutter has the same length
and edge angles as illustrated (F36)
(4) Cutter length
(5) Filing angle
(6) Side plate angle
(7) Top plate cutting angle
■GUIDE BAR
·
Reverse the bar occasionally to prevent
partial wear.
·
The bar rail should always be a square.
Check for wear of the bar rail. Apply a ruler
to the bar and the outside of a cutter. If a
gap is observed between them, the rail is
normal. Otherwise, the bar rail is worn.
Such a bar needs to be corrected or
replaced. (F37)
(1) Ruler
(2) Gap
(3) No gap
(4) Chain tilts
CASE 2. LACK OF POWER / POOR
ACCELERATION / ROUGH IDLING:
• Check water for fuel or substandard mixture
- Replace with proper fuel.
• Check air lter and fuel lter for clogging
- Clean.
• Check carburettor inadequate adjustment
- Readjust speed needles.
CASE 3. OIL DOES NOT COME OUT
• Check water for fuel or substandard mixture
- Replace with proper fuel.
• Check oil passage and ports for clogging
- Clean.
When your unit seems to need further service,
please consult with your Bushranger™dealer in
your area.
1. Screwdriver.............................................
2. S3 hexagon ring spanner........................
3. S4 hexagon ring spanner........................
4. Guide bar cover.......................................
5. Guide bar.................................................
6. Saw chain................................................
7. Spiked bumper.........................................
8. Screw.......................................................
9. Owner’s manual.......................................
10. T25 wench...............................................
NOTE
Specications, descriptions and illustrative
material in this literature are as accurate as
known at the time of publication, but are subject
to change without notice.
Illustrations may include optional equipments
and accessories, and may not include all
standard equipment
1
1
1
1
1
1
1
2
1
1
All manuals and user guides at all-guides.com
14
13. SPECIFICATIONS
Model name 4600/4680 5200/5280 5800
External dimensions: L x Wx N mm 412x260x272 412x260x272 412x265x275
Dry weight: Saw without guide
bar and chain Empty tanks
kg 4.8 4.9 5.0
Fuel tank mL 520
Tank of chain lubrication oil mL 260
Fuel(mixture ratio) 25:1;FB2-cycle engine oil
Oil(chain) SAE20# in summer and SAE10# in winter
usable cutting lengths of standard
guide bar
mm/inch 400/16”,
450/18”
450/18”,
500/20”
500/20”,
550/22”
Type of guide bar Sprocket nose
Lubrication Adjustable automatic oil pump
Sprocket: Specified number of teeth 7
Saw chain Pitch
mm/inch
9.5/0.375 8.3/0.325
Gauge 1.3/0.050 1.5/0.058
MAXMIUM CHAIN SPEED m/s 21.2 24.4
ENGINE:
Type Air cooled 2-cycle single cylinder
Carburetor Diaphragma type (Walbro/ Zomax)
Magneto Flywheel magneto ,CDI Ignitor
starter Recoil starter
Maximum speed with cutting
attachment
r/min 12000
Speed at idling r/min 3300 ± 400
Engine displacement mL(cm³)45.6 49.8 54
Rated power Kw/r/min 1.8/8500 2.0/8500 2.2/8500
Fuel consumption:: maxi
mum engine
power
g/Kw.h 610
G
uaranteed sound power level
(ISO0297) LwAav
dB(A) 117 116
Chain brake:(IS0 6535)
Mean braking time at racing speed
S0.12
Vibrations: (IS0 7505) m/s² 9.1 10.8
Other devices: Front hand guard, rear hand guard, Throttle
trigger lockout, Chain catcher, Chain brake,
Anti-vibration device, Spiked bumper
Specifications, descriptions and illustrative material in this literature are as accurate
as know at the time of publication, but are subject to change without notice.
Illustrations may include optional equipment and accessories, and may not include
all standard equipment.
4610
412x260x272
5410
412x260x272
4.8 4.9
16” 18”
Diaphragma type (Walbro)
8.3/0.325
1.3/0.050
45.6 54
1.8/8500 2.2/8500
All manuals and user guides at all-guides.com
15
NOTES
1. Australian Consumer Law (REG. 90):
The benets to the consumer given by this warranty are in addition to other rights and remedies of the
consumer under a law in relation to the good or services to which this warranty relates.
Our goods come with guarantees that cannot be excluded under the Australia Consumer Law. You are
entitled to a replacement or refund for a major failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the good repaired or replaced if the goods fail to
be of acceptable quality and the failure does not amount to
major failure.
The text above applies notwithstanding anything else
expressed or implied to the contrary in this warranty document.
