busoaudio The producer2 User manual

Seite 1 von 6
assemblyinstructions producerline
The producer line is the most aordable
Buso Audio furniture system. Each module features a 6U rack
space with the possibility to lift the table surface at an angle
to place table-top devices on.
assembly
instructions
Buso Audio B.V.
Bongastate 46
8926 pk
Leeuwarden, Netherlands
[e-mail]
www.busoaudio.com
Phone: [phone]
The producer2

Seite 2 von 6
assemblyinstructions producerline
parts
overall view
6x 35mm wood screw
6x wooden dowel / side
2x 50mm allen screw / side
2x buttery screw
9x 35-40
binding screw
2x metal clamp,
4x 18mm wood screw / side
2x M6 90 MM screw
6x m6 50/70mm
+ wing-nut

Seite 3 von 6
assemblyinstructions producerline
mounting Step 1 - 3.1
Step 1
Step 3.1
Step 2
Step 3.2
6x wooden dowel
6x 35mm
wood screw
2x metal clamp,
4x 18mm wood screw
2x 50mm
allen screw / side

Seite 4 von 6
assemblyinstructions producerline
mounting Step 4 - 6
Step 4
Step 6
Step 5
6x m6 50mm + wing-nut

Seite 5 von 6
assemblyinstructions producerline
mounting Step 7 - 9
Step 7
Step 8 Step 9
2x 35-40 binding screw

Seite 6 von 6
assemblyinstructions producerline
mounting Step 10 -11
Step 11
Step 10
2x 35-40
binding screw
