Pause Adapter
Operator's Manual
PS7

2 2
Pause Adapter PS7
Edition: 02/2016 - Part No. 9008904
Copyright
This documentation as well as translation hereof are property of cab Produkttechnik
GmbH & Co. KG. The replication, conversion, duplication or divulgement of the
whole manual or parts of it for other intentions than its original intended purpose - in
particular the procurement of spare parts for products sold by cab – demand the
previous written authorization by cab.
Editor
Regarding questions or comments please contact cab Produkttechnik GmbH & Co.
KG.
Topicality
Due to the constant further development of our products discrepancies between
documentation and product can occur. Please check www.cab.de for the latest
update.
Terms and conditions
Deliveries and performances are effected under the “General conditions of sale of
cab.
Operator's Manual for the following products
Germany
cab Produkttechnik
GmbH & Co KG
Postfach 1904
D-76007 Karlsruhe
Wilhelm-Schickard-Str. 14
D-76131 Karlsruhe
Telefon [phone]
Telefax [phone]
www.cab.de
[email protected]
France
cab technologies s.a.r.l.
F-67350 Niedermodern
Téléphone [phone]
www.cab.de/fr
[email protected]
USA
cab Technology Inc.
Tyngsboro MA, 01879
Phone [phone]
www.cab.de/us
[email protected]
Asia
cab Technology Co., Ltd.
Junghe, Taipei, Taiwan
Phone [phone]
www.cab.de/tw
[email protected]
China
cab (Shanghai)Trading Co., Ltd.
Phone [phone]
www.cab.de/cn
[email protected]
Representatives in other countries on request

3Table of Contents
1 Introduction.........................................................................4
1.1 Instructions ......................................................................................4
1.2 Intended Use ...................................................................................4
2 Product Description............................................................5
3 Mounting..............................................................................5
4 Operation.............................................................................6
5 Peripheral Interface.............................................................7
5.1 Pin Assignment................................................................................7
5.2 Signals.............................................................................................8
5.3 Internal Circuit of the Inputs.............................................................9
5.4 Internal Circuit of the Outputs..........................................................9
6 EU Conformity Declaration ..............................................10

4 4
1.1 Instructions
Important information and instructions are designated as follows:
!
Attention!
Draws attention to potential risks of property damage or loss of
quality.
i
Note!
Advices to make work routine easier or on important steps to be
carried out.
Handling instructions
Reference to chapter, position, picture number or document.
Option (accessories, peripherals, extras).
Time Viewed in the display / monitor.
1.2 Intended Use
• The device is an option only for cab A+ label printer. Any other use or use
going beyond this shall be regarded as improper use. The manufacturer/
supplier shall not be liable for damage resulting from unauthorized use; the
user shall bear the risk alone.
• Perform only those actions described in this operating manual.
Work going beyond this may only be performed by trained personnel or
service technicians.
i
Note!
The complete documentation can also currently be found in the
Internet.
1 Introduction

52 Product Description
The pause adapter PS7 is congured for communication between an external
signal generator and a printer to pause a print job via an external signal.
After deactivation of the pause signal the print job will be continued.
The adapter is connected to the printer via the SUB-D 9 external interface of
the printer.
3 Mounting
i
Note!
Keep the original packaging for later transports.
1
2
3
2
4
5
Figure 1 Mounting the pause adapter
Switch off the printer.
Loosen screw (2).
Remove cover (1).
Push the guides of the pause adapter (3) under the control panel (4).
Press the pause adapter against the printer. Ensure that the SUB-D9
connector of the module will be connected to the peripheral interface (5) of
the printer.
Secure the pause adapter with screw (2).

6 64 Operation
!
Attention!
To use the pause adapter on the printer disable all special
modes like peeling-off and cutting.
Send a print job.
The labels of the print job will be printed one after the other.
Activate the signal XPSE.
After completion of the current label the print job will be paused.
Deactivate the signal XPSE.
The print job will be continued.
XPSE
XFEH
-
-
XEDG
XDNB
XEDST
GND
RXPSE
RXFEH
-
GND
-
RUEL
P24
Figure 2 External minimum circuit at the pause adapter PS7

75 Peripheral Interface
5.1 Pin Assignment
Pin 8
Pin 1
Pin 15
Pin 9
Figure 3 Peripheral interface PS7
Pin Signal Direction Standard Function
1 XPSE Input Pause
2 XFEH Output External error
3 - - Do not use !
4 - - Do not use !
5 XEDG Output No print job available
6 XDNB Output Printer not ready
7 XEDST Output Print has been started
8 GND Ground (0V)
9 RXPSE (Input) Pause (reverse line)
10 RXFEH (Input) External error (reverse line)
11 - - Do not use !
12 GND Ground (0V)
13 - - Do not use !
14 RUEL Output Reverse line (for all outputs)
15 24P (Output) Operating voltage +24V, Si T 100mA
Table 1 Pin-Belegung Peripherie-Schnittstelle

8 85 Peripheral Interface
5.2 Signals
Pin Signal Description Activation /
Active State
1 XPSE Pause
Interruption of the print job after the current label +24 V between
Pin 1 and Pin 9
2 XFEH External error
Error message from the external control.
The print job will be stopped, the display shows the
error message "External error".
Conrm the error correction by pressing the pause
key. If the error occurred during label printing, the
print of the label will be repeated.
By pressing the cancel key the print job will be
canceled and the printer will be reset to its initial
state.
+24 V between
Pin 2 and Pin 10
3 - Do not use!
4 - Do not use!
5 XEDG No print job available Contact between
Pin 5 and Pin 14 is
open
6 XDNB Printer not ready
An error occurred in the printer.
The print job will be stopped the error type (Out
of ribbon, out of paper, no label found...) will be
shown on the display.
After error correction press the feed key to
synchronize the paper feed.
Press the pause key to continue the print job.
Contact between
Pin 6 and Pin 14 is
open
7 XEDST Print has been started
The print start will be indicated with 20 ms pulse. Contact between
Pin 7 and Pin 14 is
open
8 GND Ground ( 0 V )
9 RPSE Pause (reverse line)
10 RXFEH External error (reverse line)
11 - Do not use!
12 GND Ground ( 0 V )
13 - Do not use!
14 RUEL Reverse line (for all outputs)

9
Pin Signal Description Activation /
Active State
15 P24 Operating voltage +24 V, Si T 100 mA
ATTENTION ! Output !!!
Do not connect any external voltage to Pin 15
Table 2 Signals of peripheral interface PS7
5.3 Internal Circuit of the Inputs
The inputs XPSE and XFEH are designed for an operating voltage of 24 V.
For each signal X(input) exists a separate reverse line RX(input) at the
connector.
For that the following signal pairs result:
Pin 1 - XSTART
Pin 9 - RXSTART
Pin 2 - XFEH
Pin10 - RXFEH
Figure 4 Internal circuit of the inputs
5.4 Internal Circuit of the Outputs
For the outputs solid-state relays are used. The outputs have the common
reference potential RUEL (Pin 14).
Switching the outputs is realized by opening or closing a contact between
RUEL and the respective output.
Umax = 42 V Imax = 100 mA
Pin 5 - XEDG
Pin 6 - XDNB
Pin 7 - XEDST
Pin 14- RUEL
Figure 5 Internal circuit of the outputs
5 Peripheral Interface

10 10
EU Conformity Declaration
We declare herewith that as a result of the manner in which the device designated
below was designed, the type of construction and the devices which, as a result have
been brought on to the general market comply with the relevant fundamental regula-
tions of the EU Rules for Safety and Health. In the event of any alteration which
has not been approved by us being made to any device as designated below, this
statement shall thereby be made invalid.
This declaration is valid only when the pause adapter is used together with printers of
the A+ series. Manufacturer: cab Karlsruhe
Description: Pause adapter
Device: PS7
Applied EU Regulations Applied Standards:
Directive 2014/30/EU relating to
electromagnetic compatibility • EN 55022:2010
• EN 55024:2010
• EN 61000-3-2:2006+A1:2009+A2:2009
• EN 61000-3-3:2008
Directive 2011/65/EU on the
restriction of the use of certain
hazardous substances in electrical
and electronic equipment
• EN 50581:2012
Signed for, and on behalf of, the
Manufacturer : Sömmerda, 02.02.2015
cab Produkttechnik Sömmerda
Gesellschaft für Computer-
und Automationsbausteine mbH
99610 Sömmerda Erwin Fascher
Managing Director
6 EU Conformity Declaration
