Cabletron Systems TRMM-4 User manual

TRMM-4
TOKEN RING
MANAGEMENT MODULE
USER’S GUIDE
BOOKTITLE2 OPTIONAL

QR-1
TRMM-4 QUICK REFERENCE
QR.1 SWITCHBLOCK SW1 SETTINGS
Switchblock SW1With Factory Default Settings
Switch Function (Default settings shown in bold )
1 Ring speed of FNB Ring 1 for all port switching MIMs.
On – 16 Mbps ; Off – 4 Mbps
2 Ring speed of FNB Ring 2 for all port switching MIMs.
On – 16 Mbps ; Off – 4 Mbps
3 Ring speed of FNB Ring 3 for all port switching MIMs.
On – 16 Mbps ; Off – 4 Mbps
4 Ring speed of FNB Ring 4 for all port switching MIMs.
On – 16 Mbps ; Off – 4 Mbps
5 Unused
6 Toggle to initiate a Forced Network Download.
7 Toggle to clear NVRAM.
8 Toggle to reset passwords to defaults.
FNB Ring 1
FNB Ring 4
FNB Ring 2
FNB Ring 3
Unused
Forced
Network Download
NVRAM
Clear
Reset
Passwords
on
SW1

TRMM-4 QUICK REFERENCE
QR-2
QR.2 LED STATUS DESCRIPTIONS
NOTE
The TRMM-4 does not control the ring speeds of single-ring
MIMs.
LED Status Meaning
CPU
OFF No power to module.
GREEN Testing and booting are nearly complete.
Blinking
GREEN Operational.
RED Module is resetting or has detected errors.
Blinking RED Module has failed self-tests.
LWRP
OFF The left connection is
not left wrapped.
AMBER Left connection has been wrapped.FNB Ring 1
interface has been isolated from all other MIMs.
16 Mb AMBER Interface ring speed is set to 16 Mbps.
OFF Interface ring speed is set to 4 Mbps
.
XMT
Flashing
GREEN Information transmission by theTRMM-4
.
Blinking RED Beaconing condition on the ring.
OFF Interface is inactive.
RED Interface is disabled.
RCV
Flashing
AMBER Network activity.
RED Interface disabled.
NSRT GREEN Interface is inserted into the ring and is
participating as a station on that ring.
OFF Interface is not inserted into any ring.

TRMM-4 QUICK REFERENCE
QR-3
QR.3 CPU - CENTRAL PROCESSOR UNIT
The CPU LED indicates the operational status of the TRMM-4’s
processor. During start-up, the
CPU LED indicates a variety of
operational states, as shown below in the table.
State(s) Meaning
OFF The module is not receiving power.
Briefly turns RED The module is resetting.
GREEN The module has passed its power check.
AMBER Performing diagnostic checks.
(It will stay here for a while.)
Cycles through AMBER,
OFF, GREEN, and OFF for a
while. Testing and booting period has begun.
Momentarily to RED, but
continues cycling.
The module has detected errors during
the start-up sequence, but has continued
the process.
If blinking RED,
(continuously) The module has failed self-tests.
GREEN Testing and booting are nearly complete.
Blinking GREEN The module is fully functional.
The CPU
LED stays BLINKING GREEN under
normal operation.

TRMM-4 QUICK REFERENCE
