Cadco CAPO-203 User manual

Model CAPO-203 - Countertop combination oven
provides steam/convection: roast, bake, cook & old
or any combination
u u
Standard Features
Model Color Electrical
Volts Watts Amps
Unit
Dimensions
S ip
Wt./lbs.
Carton
Dimensions
UPC#
CAPO-203 Brushed
Stainless
208-240 5,500 30 w:243/4, h:281/4 , l:30 120* w:271/2, h:261/4, l:32 654796-51275-1
For more information, please contact Cadco, Ltd, 145 Colebrook River Road, Winsted, CT 06098
Tel. [phone] u Fax [phone] u E-mail: [email protected] u Web site: www.cadco-ltd.com
Due to continual product improvement, specifications and design are subject to change without notice.
l Steam/convection: roast, bake, cook & old or
any combination
l 1.9 cubic feet cooking c amber (14-1/2 H x
15 W x 15 D)
l Handles 5 - 2/3 size steam pans** or 5 alf size
steam pans** or 5 - 1/4 size s eet pans (pans
not included) Pan spacing 2-3/4
(** based on 2-1/2 deep steam pans).
l Five s elves included
l Compact design maximizes available space
l Digital controls provide easy operation
l Programmable (Memory for 70 programs)
l Variable steam u Venturi drying system
l Heat settings from 175o - 500o F
l Even heat system u One fan u Probe
l 10 hour timer or continuous on
l Cool-touch, easy-clean safety door
l Insulated double wall construction
l All stainless exterior; easy to clean
l Water feed, drain lines, filter and pressure regulator
not included with product
l Water filter required - Call Cadco for current filter model
l Full one year on-site warranty covering parts and
labor plus two-year warranty on heating element;
90 day warranty on light bulbs & gasket
l Complete internet or phone technical support for
installation of water, electricity, drainage, controls
and general start-up
l After-market support system to insure that units
are properly serviced.
l Chef Support  on-line and via phone
l 208/240 volts /5,500watts/30 amps/single phase/
NEMA L6-30 plug/10 6 cord
l NSF, UL (through CSA standards)
l Unit must ship by truck, NOT UPS
l Freight class 85
Item # ____________________
Project________________________________________
Model # CAPO-203
Product Name: Countertop Combination Oven
5 Quarter Size S eet Pan Capacity
Specifications:
Countertop Combination Oven. 1.9
cubic feet cooking chamber has
capacity for up to 5 half or 2/3 size
steam table pans or 5 quarter size
sheet pans. Steam/convection: roast,
bake, cook & hold or any combination.
Digital controls for easy operation.
Programmable. Probe. Variable
steam Venturi drying system. 10 hour
timer or continuous on. All stainless
double wall insulated construction.
208-240 volts - Single phase / 5,500
watts / 30amps / NEMA L6-30 Plug
10 6 cord
OPTIONAL ACCESSORIES:
XR030: : Oven Stand for CAPO-203; 8 tiers for pans
WPR-2B: Water Pressure Regulator 2 BAR
Water Pump accessory avail. - contact Cadco for details
*does not include weight of shipping skid
9/18/2006 RV06
Cadco, Ltd. Countertop Coombination Oven - 5 quarter size s eet pan capacity Model # CAPO-203
NEMA
L6-30
Plug
Countertop Combination Oven
Our combination ovens are made to Cadco Ltd. specifications by UNOX S.p.A., Italy u NSF, UL through CSA Standards
Cadco Model CAPO-203 = UNOX Model XAV203
241/4 without legs

Cross corner
air flow -High speed,
automatic oscillating
reversible fan for even
cavity heating.
Top View
Side View
24-3/4
4
24-1/4
4
door open = 19-1/2
15
15
15
Combustible Wall
Clearance Required:
Sides: 2
Rear: 4 from back
Top: 3
25-3/4
2-1/2
l CAPO-203 is made to Cadco Ltd. specifications by UNOX S.p.A.
l NSF, UL t roug CSA Standards
(Cadco Model CAPO-303 = UNOX Model XAV303)
l CSA File No. 202281-0-000 (UNOX) / covers Classes 2831-83 (US)
and 2831-03 (Canada)
l NSF Listed (UNOX) to ANSI/NSF Standard 4
(Cooking
Area)
2-3/4
2-3/4
Steam: Water is injected directly into the baking
chamber, vaporized and changed into steam when
touching the hot heating element. Water should be
connected to the oven water inlet by a mechanical
filter and a cut-off valve. Water must have a hardness
between 0.5o-5oF in order to reduce formation of
limestone deposits inside the electro-valve and inside
the cooking chamber, and a pressure value between
0.5 - 2 bar (7.25 - 29 PSI.)
umidity
vent (opens
on top)
Cadco, Ltd.
NEMA L6-30
Plug
Front View
door closed = 30
Venturi system - pulls in
cool air and pushes out
damp air, creating a dry
environment.
(Cooking
Area)
2-3/4
2-3/4
Item # ____________________
Project________________________________________
Model # CAPO-203
Product Name: Countertop Combination Oven
5 Quarter Size S eet Pan Capacity
Cadco, Ltd. Countertop Coombination Oven - 5 quarter size s eet pan capacity Model # CAPO-203
28-1/4
27-1/2
14-1/2
Back View
6 1 diam. water drain
umidity vent = 1diam;
opens on top
106 cord
vents
NEMA L6-30
Plug
11to vent ctr.
10 to ctr.of water drain
water inlet - opens at
bottom; andles NH 3/4
garden ose fitting
(4-1/4 to ctr. of water inlet)
