Cadco Line Chef CAPO-603-6 User manual

Full Size Combination Oven w/ Stand
Models CAPO-603-6 and CAPO-603-7
Countertop combination ovens provide steam & convection:
roast, bake, cook & old or any combination
u u
Standard Features- Bot Models
Model Color Electrical
Volts Watts Amps
Unit
Dimensions
S ip
Wt./lbs.
Carton
Dimensions**
UPC#
CAPO-603-6 Brushed
Stainless
208-240 10,000 50
208-240 10,000 50
w:37 , h:60 , l:343/4 262* w:401/4 , h:331/2 , l:37 ** 654796-51675-9
For more information, please contact Cadco, Ltd, 145 Colebrook River Road, Winsted, CT 06098
Tel. [phone] u Fax [phone] u E-mail: [email protected] u Web site: www.cadco-ltd.com
Due to continual product improvement, specifications and design are subject to change without notice.
l Steam & convection: roast, bake, cook & old or
any combination
l 7.0 cu. ft. cooking chamber (22 H x 27-1/2 W x 20 D)
l Pan spacing: CAPO-603-6 = 3 ; CAPO 603-7 = 2-3/4
l Compact design maximizes available space
l Oven Stand included. 7 double tiers (adjustable width)
l Digital controls provide easy operation
l Programmable (Memory for 70 programs)
l Variable steam l Venturi drying system
l Heat settings from 175o - 500o F
l Even heat system l Two fans l Probe
l 10 hour timer or continuous on
l Cool-touch, easy-clean safety door
l Insulated double wall construction
l All stainless exterior; easy to clean
l Water feed, drain lines, filter and pressure regulator
not included with product
l Water filter required - Call Cadco for current filter model
l Full one year on-site warranty covering parts and
labor plus two-year warranty on heating element;
90 day warranty on light bulbs & gasket
l Complete internet or phone technical support for
installation of water, electricity, drainage, controls and
general start-up
l After-market support system to insure that units are
properly serviced.
l Chef Support  on-line and via phone
l 208/240 volts /10,000watts/50 amps/single phase/
NEMA 6-50 plug/ 8 cord
l NSF, UL (through CSA standards)
l Unit must ship by truck, NOT UPS
l Freight class 85
Item # ____________________
Project________________________________________
Model # CAPO-603 (603-6 AND 603-7 CONFIGURATIONS)
Product Name: Full Size Combination Oven
Up To 6 Full Size S eet Pan Capacity
Specifications:
Full Size Combination Oven. 7.0 cubic
feet cooking chamber.Steam/
convection: roast, bake, cook & hold
or any combination. Digital controls for
easy operation. Programmable. Probe.
Variable steam Venturi drying system.
10 hour timer or continuous on. All
stainless double wall insulated
construction. Stand included. 208-240
volts - Single phase /10,000 watts / 50
amps / NEMA 6-50 Plug / 8 cord
OPTIONAL ACCESSORIES:
WPR-2B: Water Pressure Regulator 2 BAR
GR1090AO: Shelf
for CAPO-603-6; GR1055AO: Shelf for CAPO-603-7
LSR-603-7: Lateral Side Rack/Shelf Supports for CAPO-603-7 (set)
(can use on CAPO-603-6 to hold 7 steam pans)
*does not include weight of shipping skid
8/28/2006 RV04
NEMA
6-50
Plug
* steam pan quantity based on 2-1/2 deep steam pans).
NOTE: THIS MODEL COMES IN TWO DIFFERENT
CONFIGURATIONS. They are identical except for the side
racks that support shelves or pans, the number of shelves
included, and the number/size of pans each model will
accomodate.
SPECIFY THE DESIRED MODEL WHEN ORDERING:
MODEL CAPO-603-6: l Six shelves included
l Handles 6 full size steam pans* or 6 full size sheet pans
(pans not included)
MODEL CAPO-603-7: (designed for maximizing steam pan
capacity)
l Handles up to 7 full size steam pans* or up to
6 alf size sheet pans** (pans not included) l Three
#GR1055AO shelves included ( **Six #GR1055AO shelves
needed to use 6 half size sheet pans in this model)
Cadco, Ltd. Full Size Coombination Oven - up to 6 full size s eet pan capacity Model # CAPO-603
w:37 , h:60 , l:343/4 262* w:401/4 , h:331/2 , l:37 ** 654796-51775-6
CAPO-603-6 CAPO-603-7
(pans not included)
CAPO-603-6: 6 shelves; capacity for
6 full size sheet pans or steam pans.
CAPO-603-7: capacity for 7 full size steam
pans or up to 6* alf size sheet pans (*3
#GR1055AO shelves included)
CAPO-603-7
**& Stand ctn: w: 38 1/4 x h:10 5/8 x l: 24 1/4

Cross cor ner
air flow - High speed,
automatic oscillating
reversible fan for even
cavity heating.
Steam: Water is injected
directly into the baking
chamber, vaporized and
changed into steam when
touching the hot heating
element. Water should be
connected to the oven water
inlet by a mechanical filter
Venturi system - pulls in
cool air and pushes out
damp air, creating a dry
environment.
Cadco, Ltd. Full Size Coombination Oven - up to 6 full size s eet pan capacity Model # CAPO-603
Item # ____________________
Project________________________________________
Model # CAPO-603 (603-6 AND 603-7 CONFIGURATIONS)
Product Name: Full Size Combination Oven
Up To 6 Full Size S eet Pan Capacity
27-1/2
20
(Cooking
Area)
NEMA 6-50
Plug
Top View
and a cut-off valve. Water must have a hardness between
0.5o-5oF in order to reduce formation of limestone deposits
inside the electro-valve and inside the cooking chamber, and
a pressure value between 0.5 - 2 bar (7.25 - 29 PSI.)
Back View
8 1 diam. water drain
umidity vent = 1diam;
opens on top
8 cord
vents
11to vent ctr.
16-1/2 to ctr.
of water drain
NEMA
6-50
Plug
37
60
Front View
31-3/4
CAPO-603-7:comes wit 3 s elves;
need 6 to andle 6 alf size s eet pans)
CAPO-603-6 comes wit 6 s elves;
will andle 6 full size s eet pans)
door closed = 34-3/4
door open = 32-1/2
20
30-3/8
2-1/2
3
umidity vent
(opens on top)
(Model 603-6
Cooking
Area)
3
3
32-1/4
22
3
3
Side Views
22
20
2-3/4
2-3/4
2-3/4
2-3/4
2-3/4
2-3/4
(Model 603-7
Cooking
Area)
Combustible Wall
Clearance Required:
Sides: 2
Rear: 4 from back
Top: 3
l CAPO-603 is made to Cadco Ltd. specifications by UNOX S.p.A.
l NSF, UL t roug CSA Standards
(Cadco Model CAPO-603 = UNOX Model XAV603)
l CSA File No. 202281-0-000 (UNOX) / covers Classes 2831-83 (US)
and 2831-03 (Canada)
l NSF Listed (UNOX) to ANSI/NSF Standard 4
28-1/4
water inlet - opens at
bottom; andles NH 3/4
garden ose fitting
(4-1/4 to ctr. of water inlet)
