Cadco Line Chef CAPO-803 User manual

Specifications:
Full Size Combination Oven. 10.8 cubic
feet cooking chamber has capacity fopr
up to 10 full size sheet pans. Steam/
convection roast, bake, cook & hold or
any combination. Digital controls for easy
operation. Programmable. Probe.
Variable steam Venturi drying system. 10
hour timer or continuous on. All stainless
double wall insulated construction. Stand
included. 230-240 volts - Three phase
/16,000 watts /No cord or plug - qualified
electrician must install.
OPTIONAL ACC SSORI S:
WPR-2B Water Pressure Regulator 2 BAR
u u
Standard Features
Due to continual product improvement, specifications and design are subject to change without notice.
l Steam & convection: roast, bake, cook & hold or
any combination
l 10.8 cubic feet cooking chamber (34 H x 27-1/2
W x 20 D)
l Ten shelves included l Pan spacing 3
l Handles 10 full size steam pans* or 10 full size sheet
pans (*steam pan quantity based on 2-1/2 deep pans)
l Oven Stand included. 4 double tiers (adjustable width)
l Digital controls provide easy operation
l Programmable (Memory for 70 programs)
l Variable steam l Venturi drying system
l Heat settings from 175o - 500o F
l Even heat system l Three fans l Probe
l 10 hour timer or continuous on
l Cool-touch, easy-clean safety door
l Insulated double wall construction
l All stainless exterior; easy to clean
l Water feed, drain lines, filter and pressure regulator
not included with product
l Water filter required - Call Cadco for current filter model
l Full one year on-site warranty covering parts and
labor plus two-year warranty on heating element;
90 day warranty on light bulbs & gasket
l Complete internet or phone technical support for
installation of water, electricity, drainage, controls and
general start-up
l After-market support system to insure that units are
properly serviced.
l Chef Support  on-line and via phone
l 230/240 volts /16 KW / 3 phase
l No cord or plug; qualified electrician must install.
l NSF, UL (through CSA standards)
l Unit must ship by truck, NOT UPS
l Freight class 85
Item # ____________________
Project________________________________________
Model # CAPO-803
Product Name: Full Size Combination Oven with Stand
Up To 10 Full Size Sheet Pan Capacity
9/8/2006 RV06
Model Color lectrical
Volts Watts Amps
Unit
Dimensions
Ship
Wt./lbs.
Carton
Dimensions
UPC#
CAPO-803 Brushed
Stainless
230-240 16,000 __ w 37, h 67-1/2, l 34-3/4 366* w 40, h 50, l 37 (oven) 654796-51375-8
For more information, please contact Cadco, Ltd, 145 Colebrook River Road, Winsted, CT 06098
Tel. [phone] u Fax [phone] u E-mail [email protected] u Web site www.cadco-ltd.com
*ship wt.does not include weight of shipping skid
*ships in 2 cartons
Full Size Combination Oven w/ Stand
w 38-1/4, h 10-5/8, l 24-1/4 (stand carton)
Our combination ovens are made to Cadco Ltd. specifications by UNOX S.p.A., Italy u NSF, UL through CSA Standards
Cadco Model CAPO-803 = UNOX Model XAV803
Model CAPO-803 - Combination oven provides steam & convection:
roast, bake, cook & hold or any combination
Cadco, Ltd. Full Size Coombination Oven - up to 10 full size sheet pan capacity Model # CAPO-803

Cross cor ner
air flow - High speed,
automatic oscillating
reversible fan for even
cavity heating.
Steam: Water is injected
directly into the baking
chamber, vaporized and
changed into steam when
touching the hot heating
element. Water should be
connected to the oven water
inlet by a mechanical filter
Venturi system - pulls in
cool air and pushes out
damp air, creating a dry
environment.
Cadco, Ltd. Full Size Coombination Oven - up to 10 full size sheet pan capacity Model # CAPO-803
27-1/2
20
(Cooking
Area)
Top View
and a cut-off valve. Water must have a hardness between
0.5o-5oF in order to reduce formation of limestone deposits
inside the electro-valve and inside the cooking chamber, and
a pressure value between 0.5 - 2 bar (7.25 - 29 PSI.)
Back View
4 1 diam. water inlet
humidity vent = 1diam;
opens on top
vents
11-1/2to vent ctr.
16-1/4 to ctr.
of water inlet
(10 shelves
included;
will handle
10 full size
sheet pans)
door closed = 34-3/4
door open = 32-1/2
20
30-5/8
2-1/2
3
humidity vent
(opens on top)
(Cooking
Area)
3
3
32-1/2
34
3
3
Side View
Combustible Wall
Clearance Required:
Sides: 2
Rear: 4 from back
Top: 3
l CAPO-803 is made to Cadco Ltd. specifications by UNOX S.p.A.
l NSF, UL through CSA Standards
(Cadco Model CAPO-803 = UNOX Model XAV803)
l CSA File No. 202281-0-000 (UNOX) / covers Classes 2831-83 (US)
and 2831-03 (Canada)
l NSF Listed (UNOX) to ANSI/NSF Standard 4
Item # ____________________
Project________________________________________
Model # CAPO-803
Product Name: Full Size Combination Oven with Stand
Up To 10 Full Size Sheet Pan Capacity
3
3
3
3
3
No Plug or Cord
provided;
oven must be installed
by qualified electrician.
37
Front View
47-1/2
20
67-1/2
