Cadillac 2004 DeVille User manual

2004
CUSTOMER CONVENIENCE/PERSONALIZATION GUIDE
3384 DeVille 9/3/03 6:47 PM Page 1

D E V I L L E
DRIVER INFORMATION
•Instrument Panel
(DeVille and DHS)
•Instrument Panel (DTS)
•Digital Cluster
•Analog Cluster (DHS/DTS)
AUDIO SYSTEMS
•Audio System Control
Designations and Functions
•Preset Stations
•Setting the Time
•Loading CD Changer
COMFORT/CONVENIENCE
•Tri-zone Climate Control System
•Driver Information Center
Controls
•Driver Memory Settings
•Heated Seats, Heated and
Cooled Seats
•Ultrasonic Rear Parking Assist
(URPA)
•Night Vision
PERSONALIZATION GUIDE
MAINTENANCE/OWNER
PRIVILEGES
TABLE OF CONTENTS
3384 DeVille 9/3/03 6:47 PM Page 2

Refer to your Owner Manual for further information.
2
1
20 19
3
18 17 16 1513 13
4 5 6 7 9 8
10
12
2
14 11
1 1 1
21
INSTRUMENT PANEL DeVille and DHS
1. Air Outlets
2. Driver Information Center
Controls
3. Digital Instrument Cluster
(available on DHS)
Analog Instrument Cluster (DHS)
4. Driver Information Center Display
5. Shift Lever
6. Hazard Warning Flasher
7. Electronic Climate Controls
8. Glove Box
9. Passenger-Side Air Bag
10. Audio System
11. Ashtray/Lighter
12. Steering Wheel Audio System
Controls
13. Cruise Control
14. Driver-Side Air Bag/Horn
15. Tilt Wheel Lever (DeVille)
Power Tilt/Telescope Wheel
Control (DHS)
16. Parking Brake Pedal
17. Hood Release
18. Steering Wheel Climate System
Controls or optional Phone
Controls
19. Turn Signal/Multifunction Lever
20. Lighting Controls
21. 12V Power Outlet
(On front of Passenger seat, near
umbrella tray)
Driver
Information
Audio Systems Comfort/
Convenience Personalization
Guide
Maintenance/
Owner Privileges
Driver
Information
3384 DeVille 9/3/03 6:47 PM Page 3

D E V I L L E
Driver
Information
1. Air Outlets
2. Driver Information Center Controls
3. Digital Instrument Cluster
4. Driver Information Center Display
5. Hazard Warning Flasher
6. Electronic Climate Controls
7. Audio System
8. Glove Box
9. Passenger-Side Air Bag
10. Ashtray/Lighter
11. Console Shift Lever
12. Steering Wheel Audio System
Controls
13. Driver-Side Air Bag/Horn
14. Cruise Control
15. Tilt Wheel Lever
(Power Tilt/Telescope Wheel Control
if equipped)
16. Parking Brake Pedal
17. Hood Release
18. Steering Wheel Climate System
Controls or optional Phone Controls
19. Turn Signal/Multifunctional Lever
20. Lighting Controls
21. 12V Power Outlet
(On front of Passenger seat, near
umbrella tray)
INSTRUMENT PANEL DTS
20 19 18 17 16 1514 13 10
12
14 11 21
2
13 4 5 6 7 9
82 1 1 1
3384 DeVille 9/3/03 6:47 PM Page 4

❏Reviewed with Customer (Please Check Box)
Refer to your Owner Manual for further information.
21 4 5 6 7 93 8
DIGITAL CLUSTER DeVille (available on DHS)
1. Odometer
2. Trip Odometer
3. Engine Coolant Temperature Gauge
4. PRND321 Indicator
5. Speedometer
6. High Beam Indicator Light
7. Turn Signal Indicator
8. Fuel Data Center
9. Traction Control System
Warning Light
10. Air Bag Ready Light
11. Brake System Warning Light
12. Seat Belt Reminder Light
13. Service Engine Soon Light
14. Antilock Brake System
Warning Light
15. Cruise Control Light
16. The Driver Information Center (DIC)
shows the status of many of your
vehicle’s systems; the DIC also
displays driver personalization
features and warning/status
messages
17. Charging System Light
18. Security Light
19. Oil Pressure Light
20. Engine Coolant Temperature
Warning Light
21. Exterior Lamps Indicator Light
20 19 18 17 16 15 14 13 101112 21
Driver
Information
Audio Systems Comfort/
Convenience Personalization
Guide
Maintenance/
Owner Privileges
3384 DeVille 9/3/03 6:47 PM Page 5

Driver
Information
D E V I L L E
ANALOG CLUSTER DHS/DTS
1. Engine Coolant Temperature
2. Tachometer
3. PRND321 Indicator
4. Digital Speed Display
5. Turn Signal Indicator
6. Speedometer
7. Fuel Gauge
8. Traction Control System Warning
Light
9. Air Bag Ready Light
10. Parking Brake Indicator Light
11. Safety Belt Reminder Light
12. Antilock Brake System
Warning Light
13. Service Engine Soon Light
14. Cruise Control Light
15. Odometer
16. The Driver Information Center (DIC)
shows the status of many of your
vehicle’s systems; the DIC also
displays driver personalization
features and warning/status
messages
17. High Beam Indicator Light Location
18. Trip Odometer
19. Charging System Light
20. Security Light
21. Oil Pressure Light
22. Engine Coolant Temperature
Warning Light
23. Fog Lamp Indicator Light
(if equipped)
24. Exterior Lamps Indicator Light
2
13456 7 8
17 16 15 14 13 9
10
1112
20 19 18 22 2124 23
3384 DeVille 9/3/03 6:47 PM Page 6

❏Reviewed with Customer (Please Check Box)
Refer to your Owner Manual for further information.
Driver
Information
Comfort/
Convenience Personalization
Guide
Maintenance/
Owner Privileges
Navigation/Radio System
AM/FM Stereo with Cassette and
Compact Disc Player
AM/FM Stereo with Cassette and
Compact Disc Player/RDS/DSP
(DHS & DTS if equipped)
AM/FM Stereo with Compact
Disc Player (Base System)
Audio Systems
Note: If your
vehicle is
equipped with the
Radio/Navigation
System, please
see your
NAVIGATION
SYSTEM
SUPPLEMENT for
operating
instructions.
Audio Systems
3384 DeVille 9/3/03 6:47 PM Page 7

D E V I L L E
Audio Systems
AUDIO SYSTEM CONTROL
DESIGNATIONS AND
FUNCTIONS
PWR – Press to turn system
ON or OFF.
VOL – Turn to control
volume.
RDS – Press to activate an
RDS function.
TA – Press to seek traffic
announcement.
MSG – Press to see
message when MSG is
displayed.
TUNE/SEEK – Press up
arrow to seek next station,
tape selection or disc track.
Press down arrow to seek
previous station, tape
selection or CD track.
SCAN – Press to scan
stations, tape selections or
CD tracks.
SOURCE – Press to select
tape or disc source.
BAND – Press to select
AM, FM or XM band.
– Press to eject tape
or disc.
SIDE – Press to play other
side of tape.
TONE – Up-level system:
Press and release to display
BALANCE, FADE, BASS,
TREBLE or MIDRANGE.
TONE ( ) – Base system:
Press TONE to select BASS,
TREBLE, or MIDRANGE.
Press speaker symbol to
select BALANCE or FADE.
- LEVEL + — Press to
select tone or speaker
level.
DSP – Press to turn DSP on
and continue to press and
release until desired
listening experience
appears in display. To turn
DSP off, press and hold
button until DSP OFF is
displayed.
1-6 – Base system: Press
to select discs loaded in
changer.
PTY – Press to select RDS
or XM listening category.
See Owner Manual for
complete instructions.
RDM – Press to listen to
CD tracks in random order.
DISC – Press to select next
disc if equipped with
changer.
RW (<< >>) – Press to
rewind tape or reverse
through track.
FF (<< >>) – Press to fast-
forward tape or advance
through track.
NEXT – Press to select next
tape selection or CD track.
PREV – Press to select
previous tape selection or
CD track.
3384 DeVille 9/3/03 6:47 PM Page 8

❏Reviewed with Customer (Please Check Box)
Refer to your Owner Manual for further information.
PRESET STATIONS
• Turn radio on.
• Select band.
• Tune to desired station.
• Press one of six-numbered buttons
for two seconds.
SETTING THE TIME
All radios:
• Press and hold HR button until
correct hour appears in display.
• Press and hold MN button until
correct minute appears in display.
• Display time when ignition is off
by pressing either HR or MN
button.
RDS radio only: To synchronize time
with RDS broadcast information:
• Press and hold HR and MN
buttons at same time until TIME
UPDATED is displayed. If time is
not available from station, NO
STATION TIME will be displayed.
LOADING CD CHANGER
• Slide the door of the changer
open. The magazine will eject only
when the door is completely open.
• Press the EJECT button to remove
the magazine. (The EJECT button is
on the upper left after the door is
opened. In this view, the button is
hidden by the closed door.)
• Load the trays into the magazine
from the bottom to the top,
placing the label side of the
CD up.
• To remove a tray, press the button
on the back of the magazine.
• Push the magazine into the
changer, following the direction of
the arrow marked on top of
the magazine.
Driver
Information
Audio Systems Comfort/
Convenience Personalization
Guide
Maintenance/
Owner Privileges
3384 DeVille 9/3/03 6:47 PM Page 9

FRONT CLIMATE CONTROL
SYSTEM
Your climate control system
can operate automatically or
manually. In the automatic
mode, the system
automatically controls the
temperature and fan speed.
1. Driver-Side Temperature
Knob
Press the knob to turn the
system on.
Turn the knob to increase
or decrease the
temperature.
2. Outside Temperature
Display
3. Auto
Press the AUTO button to
switch from manual to
automatic operation.
4. Passenger-Side
Temperature
Press the PASS TEMP
button to turn the system
on. Press the up or down
arrow to increase or
decrease the
temperature.
5. PASS OFF
Press button to deactivate
the dual zone system.
6. AC
Press this button to turn the
air conditioning on and off.
7. Recirculation
Press this button to limit
the amount of outside air
entering the vehicle.
8. Fan
During AUTO operation,
the fan is automatically
controlled. In the manual
mode, to increase or
decrease fan speed, press
the up or down arrow.
9. Mode
Press the button to
deliver air through the
floor, middle or
windshield outlets.
Settings include heater,
bi-level, upper and defog.
10. Rear Window
Defogger
Press this button to defog
the rear window and both
outside mirrors.
11. Defrost
Press this button to quickly
remove fog
or frost from the
windshield.
REAR CLIMATE CONTROL
1. Mode
Press this button to enter
MANUAL mode, and to
adjust airflow direction up
or down.
1. To enter AUTO mode,
press the button down
until the display indicates
AUTO.
2. Fan Speeds
Press this button to adjust
blower speed.
3. Temperature
Press the TEMP up or
down button to adjust the
temperature.
D E V I L L E
21 3671011 89 45
Comfort/Convenience
132 Display
Tri-zone Climate
Control System
