Cadillac 2002 Eldorado User manual

i
2002 Cadillac Eldorado
Owner’s Manual
Litho in U.S.A. E Copyright General Motors Corporation 06/11/01
Part Number 25729636 A First Edition All Rights Reserved

ii
GENERAL MOTORS, GM and the GM Emblem,
CADILLAC, the CADILLAC Crest & Wreath and
the name ELDORADO are registered trademarks of
General Motors Corporation.
This manual includes the latest information at the time it
was printed. We reserve the right to make changes after
that time without further notice. For vehicles first sold in
Canada, substitute the name “General Motors of Canada
Limited” for Cadillac Motor Car Division whenever it
appears in this manual.
Please keep this manual in your vehicle, so it will
be there if you ever need it when you’re on the road.
If you sell the vehicle, please leave this manual in it
so the new owner can use it.
We support voluntary
technician certification.
For Canadian Owners Who Prefer a
French Language Manual:
Aux propriétaires canadiens: Vous pouvez vous
procurer un exemplaire de ce guide en français chez
votre concessionaire ou au:
Helm, Incorporated
P.O. Box 07130
Detroit, MI 48207

iii
How to Use this Manual
Many people read their owner’s manual from beginning
to end when they first receive their new vehicle. If you
do this, it will help you learn about the features and
controls for your vehicle. In this manual, you’ll find
that pictures and words work together to explain
things quickly.
Safety Warnings and Symbols
You will find a number of safety cautions in this book.
We use a box and the word CAUTION to tell you
about things that could hurt you if you were to ignore
the warning.
CAUTION:
These mean there is something that could hurt
you or other people.
In the caution area, we tell you what the hazard is.
Then we tell you what to do to help avoid or reduce
the hazard. Please read these cautions. If you don’t,
you or others could be hurt.
You will also find a circle
with a slash through it in
this book. This safety
symbol means “Don’t,”
“Don’t do this” or “Don’t
let this happen.”

iv
Vehicle Damage Warnings
Also, in this book you will find these notices:
NOTICE:
These mean there is something that could damage
your vehicle.
In the notice area, we tell you about something that can
damage your vehicle. Many times, this damage would
not be covered by your warranty, and it could be costly.
But the notice will tell you what to do to help avoid
the damage.
When you read other manuals, you might see
CAUTION and NOTICE warnings in different
colors or in different words.
You’ll also see warning labels on your vehicle.
They use the same words, CAUTION or NOTICE.
Vehicle Symbols
Your vehicle may be equipped with components and
labels that use symbols instead of text. Symbols,
used on your vehicle, are shown along with the text
describing the operation or information relating to a
specific component, control, message, gage or indicator.
If you need help figuring out a specific name of a
component, gage or indicator reference the following
topics in the Index:
D “Engine Compartment Overview”
D “Instrument Panel”
D “Comfort Controls”
D “Audio Systems”
Also see “Warning Lights and Gages” in the Index.

v
These are some examples of vehicle symbols you may find on your vehicle:

1- 1-1
Section 1 Seats and Restraint Systems
Here you’ll find information about the seats in your vehicle and how to use your safety belts properly. You can also
learn about some things you should not do with air bags and safety belts.
1-2 Seats and Seat Controls
1-9 Safety Belts: They’re for Everyone
1-13 Here Are Questions Many People Ask
About Safety Belts -- and the Answers
1-14 How to Wear Safety Belts Properly
1-14 Driver Position
1-21 Safety Belt Use During Pregnancy
1-22 Right Front Passenger Position
1-22 Supplemental Inflatable
Restraint (SIR) System
1-28 Rear Seat Passengers
1-31 Center Passenger Position
1-32 Children
1-36 Restraint Systems for Children
1-48 Older Children
1-51 Safety Belt Extender
1-51 Checking Your Restraint Systems
1-51 Replacing Restraint System Parts
After a Crash

1-2
Seats and Seat Controls
This section tells you about the power seats -- how to
adjust them, and also about the reclining front seatbacks,
lumbar adjustments, head restraints, heated seats and
seatback latches.
Power Seats
The power seat controls are located on the outboard side
of the front seat cushions.
Thepowerseatcontrolscanbeadjustedthefollowingways:
D Move the front of the control up or down to adjust
the front portion of the cushion up or down.
D Move the rear of the control up or down to adjust the
rear portion of the cushion up or down.
D Lift up or push down the whole control to move the
entire seat up or down.
D To move the whole seat forward or rearward, slide
the control forward or rearward.

1-3
Power Lumbar Control (Option)
If your vehicle has this
option, the driver’s and
passenger’s controls are
located on the outboard
sides of the seat cushions.
The power lumbar support control can be adjusted the
following ways:
D To increase or decrease support, hold the control
forward or rearward.
D To move the lumbar up and down, hold the control
up or down.
Keep in mind that as your seating position changes,
as it may during long trips, so should the position of
your lumbar support. Adjust the seat as needed.
If you have the optional personalization package, the
power lumbar control can be programmed for memory
recall. For more information, see “Memory and
Personalization Features” and “Memory Seat and
Mirrors” in the Index.

1-4
Memory Seat and Mirrors (If Equipped)
If your vehicle has this
feature, the controls are
located on the driver’s
door armrest.
These buttons are used to program and recall memory
settingsforthedriver’sseatingandoutsiderearviewmirror
positions. Use the following steps to program each button:
1. Adjustthe driver’sseat(including lumbaradjustments)
and both outside mirrors to a comfortable position.
2. Press the SET button.
3. Within five seconds, press button 1. A single beep
will sound through the driver’s side front speaker to
let you know that the position has been stored.
A second mirror and seating position may be
programmed by repeating the above steps and pressing
button 2 instead of button 1. Each time button 1 or 2 is
pressed and released while the vehicle is in PARK (P),
the memory position will be recalled. Each time a
memory button is pressed, a single beep will sound.
You can also recall a seat and mirror position if your
vehicle is not in PARK (P). Press and hold either
the 1 or 2 button until seat and mirror movement is
complete. Releasing the buttons will stop adjustment.
If you use the button with the unlock symbol on the
remote keyless entry transmitter to enter the vehicle, the
preset driver’s seat and mirror positions will be recalled.
The numbers on the back of the transmitters, 1 or 2,
correspond to the numbers on the driver’s armrest.
If the remote keyless entry transmitter was not used to
enter the vehicle, the last used seat and mirror positions
will be recalled when a key is inserted in the ignition
and is turned to RUN. The vehicle must be previously
programmed to turn this feature on. See “Memory and
Personalization Features” in the Index.

1-5
To stop recall movement of the memory feature at
any time, press one of the power seat controls or
memory buttons.
The EXIT button can be programmed to allow easy exit
for up to two drivers. Adjust the seat to a comfortable
“exit” position and then press the SET button followed
by the EXIT button. While your vehicle is in PARK (P),
briefly press the EXIT button to recall your programmed
exit position.
Further programming for automatic seat and mirror
movement can be done using the Driver Information
Center (DIC). You can select or not select the following:
D Automatic seat and mirror movement when the
vehicle is unlocked with the remote keyless entry
transmitter, or
D automatic seat and mirror movement when a key
is placed in the ignition.
For programming information, see “Memory and
Personalization Features” in the Index.
Heated Front Seat (Option)
The switch for the heated
front seat is located in the
center console.
Move the switch to LO or HI to turn on the heating
elements in the seat. The LO setting warms the
seatback and cushion until the seat approximates body
temperature. The HI setting heats the seat to a slightly
higher temperature.
A light in the switch is on when the system is in use.
The heated seats can only be used when the ignition
is turned on.
To turn the heated front seat off, move the switch to
the center position.

1-6
Reclining Front Seatbacks
The reclining front
seatback control is
located on the outboard
side of each front seat.
Pressthe control forwardor rearward toadjust theseatback.
But don’t have a seatback reclined if your vehicle
is moving.

1-7
CAUTION:
Sitting in a reclined position when your vehicle is
in motion can be dangerous. Even if you buckle
up, your safety belts can’t do their job when
you’re reclined like this.
The shoulder belt can’t do its job. In a crash you
could go into it, receiving neck or other injuries.
The lap belt can’t do its job either. In a crash the
belt could go up over your abdomen. The belt
forces would be there, not at your pelvic bones.
This could cause serious internal injuries.
For proper protection when the vehicle is in
motion, have the seatback upright. Then sit
well back in the seat and wear your safety
belt properly.
Head Restraints
Slide the head restraint up or down so that the top of the
restraint is closest to the top of your head. This position
reduces the chance of a neck injury in a crash.
The head restraints tilt forward and rearward also.

1-8
Seatback Latches
CAUTION:
If the seatback isn’t locked, it could move forward
in a sudden stop or crash. That could cause injury
to the person sitting there. Always press rearward
on the seatback to be sure it is locked.
The front seatback folds forward to let people get into
the rear seat. The seatback will move back and forth
freely unless you come to a sudden stop, then it will lock
into place.
The seatback latches are located on the back side of
the front seats near the bottom of the outboard side
of the seat.
To fold the seatback
forward when it’s in the
locked position, lift the
latch and fold the seatback
at the same time.
The seatback may not fold without some help from you
if your vehicle is parked facing down a fairly steep hill.
In this case, push the seatback toward the rear as you lift
the latch. Then the seatback will fold forward. The latch
must be down for the seat to work properly.

1-9
Safety Belts: They’re for Everyone
This part of the manual tells you how to use safety belts
properly. It also tells you some things you should not do
with safety belts.
AnditexplainstheSupplementalInflatableRestraint(SIR),
or air bag system.
CAUTION:
Don’t let anyone ride where he or she can’t wear
a safety belt properly. If you are in a crash and
you’re not wearing a safety belt, your injuries
can be much worse. You can hit things inside the
vehicle or be ejected from it. You can be seriously
injured or killed. In the same crash, you might
not be if you are buckled up. Always fasten your
safety belt, and check that your passengers’ belts
are fastened properly too.
CAUTION:
It is extremely dangerous to ride in a cargo
area, inside or outside of a vehicle. In a collision,
people riding in these areas are more likely to
be seriously injured or killed. Do not allow
people to ride in any area of your vehicle that is
not equipped with seats and safety belts. Be sure
everyone in your vehicle is in a seat and using a
safety belt properly.
Your vehicle has a light
that comes on as a reminder
to buckle up. See “Safety
Belt Reminder Light” in
the Index.

1-10
In most states and Canadian provinces, the law says to
wear safety belts. Here’s why: They work.
You never know if you’ll be in a crash. If you do have
a crash, you don’t know if it will be a bad one.
A few crashes are mild, and some crashes can be so
serious that even buckled up a person wouldn’t survive.
But most crashes are in between. In many of them,
people who buckle up can survive and sometimes walk
away. Without belts they could have been badly hurt
or killed.
After more than 30 years of safety belts in vehicles,
the facts are clear. In most crashes buckling up does
matter ... a lot!
Why Safety Belts Work
When you ride in or on anything, you go as fast as it goes.
Takethesimplestvehicle.Supposeit’sjustaseatonwheels.

1-11
Put someone on it. Get it up to speed. Then stop the vehicle. The rider
doesn’t stop.

1-12
The person keeps going until stopped by something.
In a real vehicle, it could be the windshield ...
or the instrument panel ...

1-13
or the safety belts!
With safety belts, you slow down as the vehicle does.
You get more time to stop. You stop over more distance,
and your strongest bones take the forces. That’s why
safety belts make such good sense.
Here Are Questions Many People Ask
About Safety Belts -- and the Answers
Q: Won’t I be trapped in the vehicle after an
accident if I’m wearing a safety belt?
A: You could be -- whether you’re wearing a safety
belt or not. But you can unbuckle a safety belt,
even if you’re upside down. And your chance of
being conscious during and after an accident, so
you can unbuckle and get out, is much greater if
you are belted.
Q: If my vehicle has air bags, why should I have
to wear safety belts?
A: Air bags are in many vehicles today and will
be in most of them in the future. But they are
supplemental systems only; so they work with
safety belts -- not instead of them. Every air bag
system ever offered for sale has required the use of
safety belts. Even if you’re in a vehicle that has air
bags, you still have to buckle up to get the most
protection. That’s true not only in frontal collisions,
but especially in side and other collisions.

1-14
Q: If I’m a good driver, and I never drive far from
home, why should I wear safety belts?
A: You may be an excellent driver, but if you’re in
an accident -- even one that isn’t your fault -- you
and your passengers can be hurt. Being a good
driver doesn’t protect you from things beyond your
control, such as bad drivers.
Most accidents occur within 25 miles (40 km)
of home. And the greatest number of serious
injuries and deaths occur at speeds of less than
40 mph (65 km/h).
Safety belts are for everyone.
How to Wear Safety Belts Properly
Adults
This part is only for people of adult size.
Be aware that there are special things to know about
safety belts and children. And there are different
rules for smaller children and babies. If a child will be
riding in your vehicle, see the part of this manual called
“Children.” Follow those rules for everyone’s protection.
First, you’ll want to know which restraint systems your
vehicle has.
We’ll start with the driver position.
Driver Position
This part describes the driver’s restraint system.
Lap-Shoulder Belt
The driver has a lap-shoulder belt. Here’s how to
wear it properly.
1. Close and lock the door.
2. Adjust the seat so you can sit up straight.
To see how, see “Seats” in the Index.
