Cadillac 2005 DeVille Specification sheet

CUSTOMER CONVENIENCE/PERSONALIZATION GUIDE

D E V I L L E
DRIVER INFORMATION
•Instrument Panel
(DeVille and DHS)
•Instrument Panel (DTS)
•Digital Cluster
•Analog Cluster (DHS/DTS)
•Driver Information Center
Controls
AUDIO SYSTEMS
•Audio System Control
Designations and Functions
•Preset Stations
•Setting the Time
•Loading CD Changer
COMFORT/CONVENIENCE
•Tri-zone Climate Control System
•Rainsense™ Wipers (if equipped)
•OnStar®
•Driver Memory Settings
•Heated Seats, Heated and
Cooled Seats
•Ultrasonic Rear Parking Assist
(URPA)
•Night Vision
PERSONALIZATION GUIDE
MAINTENANCE/OWNER
PRIVILEGES
TABLE OF CONTENTS

Refer to your Owner Manual for further information.
2
1
20 19
3
18 17 16 1513 13
4 5 6 7 9 8
10
12
2
14 11
1 1 1
21
INSTRUMENT PANEL DeVille and DHS
1. Air Outlets
2. Driver Information Center
Controls
3. Digital Instrument Cluster
(available on DHS)
Analog Instrument Cluster (DHS)
4. Driver Information Center Display
5. Shift Lever
6. Hazard Warning Flasher Button
7. Electronic Climate Controls
8. Glove Box
9. Passenger-Side Air Bag
10. Audio System
11. Ashtray/Lighter
12. Steering Wheel Audio System
Controls
13. Cruise Control
14. Driver-Side Air Bag/Horn
15. Tilt Wheel Lever (DeVille)
Power Tilt/Telescope Wheel
Control (DHS)
16. Parking Brake Pedal
17. Hood Release
18. Steering Wheel Climate System
Controls or optional Phone
Controls
19. Turn Signal/Multifunction Lever
20. Lighting Controls
21. 12V Power Outlet
(On front of passenger seat, near
umbrella tray)
Driver
Information
Audio Systems Comfort/
Convenience Personalization
Guide
Maintenance/
Owner Privileges™
Driver
Information

D E V I L L E
Driver
Information
1. Air Outlets
2. Driver Information Center Controls
3. Digital Instrument Cluster
4. Driver Information Center Display
5. Hazard Warning Flasher Button
6. Electronic Climate Controls
7. Audio System
8. Glove Box
9. Passenger-Side Air Bag
10. Ashtray/Lighter
11. Console Shift Lever
12. Steering Wheel Audio System
Controls
13. Driver-Side Air Bag/Horn
14. Cruise Control
15. Tilt Wheel Lever
(Power Tilt/Telescope Wheel Control
if equipped)
16. Parking Brake Pedal
17. Hood Release
18. Steering Wheel Climate System
Controls or optional Phone Controls
19. Turn Signal/Multifunctional Lever
20. Lighting Controls
21. 12V Power Outlet
(On front of passenger seat, near
umbrella tray)
INSTRUMENT PANEL DTS
20 19 18 17 16 1514 13 10
12
14 11 21
2
1345679
8
21 1 1

❏Reviewed with Customer (Please Check Box)
Refer to your Owner Manual for further information.
21 4 5 6 7 9
3 8
DIGITAL CLUSTER DeVille (available on DHS)
1. Odometer
2. Trip Odometer
3. Engine Coolant Temperature Gauge
4. PRND321 Indicator
5. Speedometer
6. High Beam Indicator Light
7. Turn Signal Indicator
8. Fuel Data Center
9. Traction Control System
Warning Light
10. Air Bag Ready Light
11. Brake System Warning Light
12. Seat Belt Reminder Light
13. Service Engine Soon Light
14. Antilock Brake System
Warning Light
15. Cruise Control Light
16. The Driver Information Center (DIC)
shows the status of many of your
vehicle’s systems; the DIC also
displays driver personalization
features and warning/status
messages
17. Charging System Light
18. Security Light
19. Oil Pressure Light
20. Engine Coolant Temperature
Warning Light
21. Exterior Lamps Indicator Light
20 19 18 17 16 15 14 13 10
11
12
21
Driver
Information
Audio Systems Comfort/
Convenience Personalization
Guide
Maintenance/
Owner Privileges™

Driver
Information
D E V I L L E
ANALOG CLUSTER DHS/DTS
1. Engine Coolant Temperature
2. Tachometer
3. PRND321 Indicator
4. Digital Speed Display
5. Turn Signal Indicator
6. Speedometer
7. Fuel Gauge
8. Traction Control System Warning
Light
9. Air Bag Ready Light
10. Parking Brake Indicator Light
11. Safety Belt Reminder Light
12. Antilock Brake System
Warning Light
13. Service Engine Soon Light
14. Cruise Control Light
15. Odometer
16. The Driver Information Center (DIC)
shows the status of many of your
vehicle’s systems; the DIC also
displays driver personalization
features and warning/status
messages
17. High Beam Indicator Light
18. Trip Odometer
19. Charging System Light
20. Security Light
21. Oil Pressure Light
22. Engine Coolant Temperature
Warning Light
23. Fog Lamp Indicator Light
(if equipped)
24. Exterior Lamps Indicator Light
2
134567 8
17 16 15 14 13 9
10
11
12
20 19 18
22 2124 23

❏Reviewed with Customer (Please Check Box)
Refer to your Owner Manual for further information.
Driver
Information
Audio Systems Comfort/
Convenience Personalization
Guide
Maintenance/
Owner Privileges™
DRIVER INFORMATION
CENTER CONTROLS
1. ENG/MET
Press this button to display
instrument cluster and climate
control information in English or
Metric.
2. DSPL MODE
Turns digital/analog display feature
on or off (analog only). Turns all
but speedometer off on digital
model.
3. RESET TRIP A/B
There are two trip odometers
Press the A/B portion of the
button to select and view the trip
odometers.
Press the reset portion of the button
to reset the displayed trip odometer.
4. INFO
Press this button’s up or down
arrow to display information such
as battery volts, oil life, average
miles per gallon, and outside air
temperature.
5. INFO RESET
Press this button to reset average
fuel economy, fuel used, average
speed, timer, oil life left, and
transmission fluid life.
To Use the Timer Functions:
•Press the INFO button (4) until the
timer function is displayed.
•Press the ON/OFF button (6) to
begin timing. Press button again to
stop timing.
•Press INFO/RESET (5) to return to
zero.
•Press the INFO button (4) until
display is off to exit.
2
14
356

D E V I L L E
Navigation/Radio System
AM/FM Stereo with Cassette and
Compact Disc Player
AM/FM Stereo with Cassette and
Compact Disc Player/RDS/DSP
(DHS & DTS if equipped)
AM/FM Stereo with Compact
Disc Player (Base System)
Audio Systems
Note: If your
vehicle is
equipped with the
Radio/Navigation
System, please
see your
NAVIGATION
SYSTEM
SUPPLEMENT for
operating
instructions.

❏Reviewed with Customer (Please Check Box)
Refer to your Owner Manual for further information.
Driver
Information
Audio Systems Comfort/
Convenience Personalization
Guide
Maintenance/
Owner Privileges™
AUDIO SYSTEM CONTROL
DESIGNATIONS AND
FUNCTIONS
PWR – Press to turn system
on or off.
VOL – Turn to control
volume.
RDS – Press to activate an
RDS function.
TA – Press to seek traffic
announcement.
MSG – Press to see
message when MSG is
displayed.
TUNE/SEEK – Press up
arrow to seek next station,
tape selection or disc track.
Press down arrow to seek
previous station, tape
selection or CD track.
SCAN – Press to scan
stations, tape selections or
CD tracks.
SOURCE – Press to select
tape or disc source.
BAND – Press to select
AM, FM or XM band.
– Press to eject tape
or disc.
SIDE – Press to play other
side of tape.
TONE – Up-level system:
Press and release to display
BALANCE, FADE, BASS,
TREBLE or MIDRANGE.
TONE ( ) – Base system:
Press TONE to select BASS,
TREBLE, or MIDRANGE.
Press speaker symbol to
select BALANCE or FADE.
- LEVEL + — Press to
select tone or speaker
level.
DSP – Press to turn DSP on
and continue to press and
release until desired
listening experience
appears in display. To turn
DSP off, press and hold
button until DSP OFF is
displayed.
1-6 – Base system: Press
to select discs loaded in
changer.
PTY – Press to select RDS
or XM listening category.
See Owner Manual for
complete instructions.
RDM – Press to listen to
CD tracks in random order.
DISC – Press to select next
disc if equipped with
changer.
RW (<< >>) – Press to
rewind tape or reverse
through track.
FF (<< >>) – Press to fast-
forward tape or advance
through track.
NEXT – Press to select next
tape selection or CD track.
PREV – Press to select
previous tape selection or
CD track.

D E V I L L E
PRESET STATIONS
• Turn radio on.
• Select band.
• Tune to desired station.
• Press one of six numbered buttons
for two seconds.
SETTING THE TIME
All radios:
• Press and hold HR button until
correct hour appears in display.
• Press and hold MN button until
correct minute appears in display.
• Display time when ignition is off
by pressing either HR or MN
button.
RDS radio only: To synchronize time
with RDS broadcast information:
• Press and hold HR and MN
buttons at same time until TIME
UPDATED is displayed. If time is
not available from station, NO
STATION TIME will be displayed.
LOADING CD CHANGER
• Slide the door of the changer
open. The magazine will eject only
when the door is completely open.
• Press the EJECT button to remove
the magazine. (The EJECT button is
on the upper left after the door is
opened. In this view, the button is
hidden by the closed door.)
• Load the trays into the magazine
from the bottom to the top,
placing the label side of the
CD up.
• To remove a tray, press the button
on the back of the magazine.
• Push the magazine into the
changer, following the direction of
the arrow marked on top of
the magazine.
Audio Systems

❏Reviewed with Customer (Please Check Box)
Refer to your Owner Manual for further information.
Driver
Information
Audio Systems Comfort/
Convenience Personalization
Guide
Maintenance/
Owner Privileges™
FRONT CLIMATE CONTROL
SYSTEM
Your climate control system
can operate automatically or
manually. In the automatic
mode, the system
automatically controls the
temperature and fan speed.
1. Fan Speeds Driver-Side
Temperature Knob
Press the knob to turn the
system on.
Turn the knob to increase
or decrease the
temperature.
2. Outside Temperature
Display
3. Auto
Press the AUTO button to
switch from manual to
automatic operation.
4. Passenger-Side
Temperature
Press the PASS TEMP
button to turn the system
on. Press the up or down
arrow to increase or
decrease the
temperature.
5. PASS OFF
Press button to deactivate
the dual zone system.
6. AC
Press this button to turn the
air conditioning on and of f.
7. Recirculation
Press this button to limit
the amount of outside air
entering the vehicle.
8. Fan
During AUTO operation,
the fan is automatically
controlled. In the manual
mode, to increase or
decrease fan speed, press
the up or down arrow.
9. Mode
Press the button to
deliver air through the
floor, middle or
windshield outlets.
Settings include heater,
bi-level, upper and defog.
10. Rear Window
Defogger
Press this button to defog
the rear window and both
outside mirrors.
11. Defrost
Press this button to quickly
remove fog or frost from
the windshield.
REAR CLIMATE CONTROL
1. Mode
Press this button to enter
MANUAL mode, and to
adjust airflow direction up
or down.
1. To enter AUTO mode,
press the button down
until the display indicates
AUTO.
2. Fan Speeds
Press this button to adjust
blower speed.
3. Temperature
Press the TEMP up or
down arrow to adjust the
rear temperature.
2
13
67 10
11 8
9 45
Comfort/Convenience
132
Display
Tri-zone Climate
Control System

DRIVER MEMORY SETTINGS
(if equipped)
Three-Button Memory Systems
If your vehicle is equipped with the
three-button memory system, follow
these procedures to set the memory:
With the vehicle in Park (P) adjust the
driver’s seat including lumbar support
and recliner, outside rearview mirror
positions, climate control and audio
settings and (if equipped) power
tilt/telescoping steering wheel
position.
D E V I L L E
Comfort/Convenience
Note: Memory 1 or 2 is
dependent on the RKE
transmitter being used and the
key being in the ignition during
programming. See the back of
your RKE transmitter for the
corresponding memory number.
Note: Turn the Rainsense wipers
off to avoid wiper damage when
going through an automatic car
wash.
Rainsense™ Wipers (if equipped)
The Rainsense system monitors the
amount of moisture on the
windshield and automatically
operates the wipers as needed,
depending on driving conditions and
the sensitivity setting. The moisture
sensor is mounted on the interior
side of the windshield behind the
rearview mirror.
The Rainsense wipers operate in a
delay mode as well as a continuous
low or high speed as needed. If the
system is left on for long periods of
time, occasional wipes may occur
without any moisture on the
windshield to indicate the system is
active.
To activate the Rainsense wipers:
Turn the wiper band to one of the
five sensitivity levels indicated on the
wiper stalk. The position closest to
OFF is the lowest sensitivity level.
Each higher sensitivity level increases
the frequency of wipes. The system
can be overridden at any time by
manually turning the wiper band to
LO or HI speed.
When the Rainsense system is active,
the headlamps will turn on
automatically to increase your
vehicle’s visibility.
OnStar®(if equipped)
OnStar®is a hands-free
communications link between the
vehicle and the OnStar®Center. If
equipped with OnStar, one year of
the Directions & Connections service
plan will be provided. Refer to your
OnStar supplement for full details of
available services and how to access
them.

❏Reviewed with Customer (Please Check Box)
Refer to your Owner Manual for further information.
1. Press and hold Memory button 1
or 2, located on the driver’s door
panel, until a beep sounds.
Look at the back of your RKE
transmitter to determine which
Memory button you need to set.
Set EXIT Position
1. Recall driver position by briefly
pressing the appropriate Memory
button or RKE unlock button.
2. Adjust driver seat and power
tilt/telescoping steering wheel
(if equipped) to the desired exit
position.
3. Press and hold the EXIT button
until a beep sounds.
These settings can be recalled by
pressing the Memory 1 or 2 button
on the driver’s door, or by using the
Remote Keyless Entry (RKE)
transmitter. The vehicle memory
settings will correspond to the
number on the RKE: 1 or 2.
HEATED SEATS
HEATED AND COOLED SEATS
(if equipped)
Your vehicle may have heated or
heated and cooled seats. The buttons
are located on the driver and front
passenger door armrests.
The button with the heat lines
through just the seatback activates
the heated seatback.
The button with heat lines through
both the seatback and seat cushion
activates the heated seatback and
seat cushion.
The button with the snowflake above
the seat activates the cooled
seatback and seat cushion.
There are three temperature settings
for each of the above features.
A light bar on the controls will
display which setting is selected:
high, medium or low. The longest
bar shows the high range and the
shortest bar shows the low range.
When you press a button, the feature
will turn on the highest setting. Each
time you press the button, the
feature will decrease one
temperature setting.
To turn the feature off, continue
pressing the button until the display
lights turn off.
Note: There is a slight delay in
seat recall position to avoid
inadvertent activation. Holding
the button until the beep sounds
will reset the memory position.
Driver
Information
Audio Systems Comfort/
Convenience Personalization
Guide
Maintenance/
Owner Privileges™

D E V I L L E
ULTRASONIC REAR PARKING
ASSIST (URPA) (if equipped)
This feature uses ultrasonic sensors to
help determine how close an object
is to your rear bumper.
Both a variable audible chime and
three color-coded lights (located
inside your vehicle above the rear
window) convey your distance to an
object.
URPA activates automatically when
your vehicle is shifted into Reverse
(R) and your vehicle speed is less
than 3 mph (5 km/h).
Disable URPA
To disable URPA, press the URPA
on/off button located near the
climate control system and radio.
NIGHT VISION (if equipped)
This feature helps you see better at
night — beyond the headlamps —
by sensing heat given off by objects
in its field of view.
Warmer objects such as pedestrians,
animals and other moving vehicles
will appear white. Colder objects,
such as the sky, signs and parked
vehicles, will appear darker.
The controls are located on the
lower-left side of the instrument
panel. They can be used to adjust the
brightness and location of the image.
1. Operate Night Vision
Move the dimmer switch up to turn
Night Vision on. Continue upward to
increase brightness. Move the switch
down to decrease brightness.
To turn off the image, move the
dimmer switch to the OFF position.
2. Locate Image
Press the up arrow on the IMAGE
switch to raise the image. Press the
down arrow to lower the image.
Comfort/Convenience
1
2

❏Reviewed with Customer (Please Check Box)
Refer to your Owner Manual for further information.
Personalization Guide
To begin programming, press ( ) on the INFO button until Feature Programming appears in the DIC. Press the
ON/OFF button to enter feature programming. Press down ( ) on the INFO button to scroll through the menu.
To exit, press the INFO RESET button.
DIC readout on Instrument Cluster with OFF/ON status
DIC =Driver Information Center
RKE =Remote Keyless Entry
With the ignition key ON and the vehicle in Park (P), press the
memory button “1” or “2” on the driver’s door panel that
corresponds to the number on the back of your RKE. Note: Memory
1 or 2 operation is dependent on the RKE transmitter being used and
the key being in the ignition during programming. See the back of
your RKE transmitter for the corresponding memory number.
The following features and instructions are for vehicles equipped
with either Digital or Analog instrument clusters.
The back-lit buttons, which control the DIC, are
located immediately to the right of the instrument cluster (shown
right):
•INFO selects the next feature.
•INFO/RESET exits the programming.
•ON/OFF turns feature on or off.
DIC controls located to right of cluster
You can personalize many of DeVille’s features to your own needs.
Driver
Information
Audio Systems Comfort/
Convenience Personalization
Guide
Maintenance/
Owner Privileges™
>
>

Personalization Guide
Programmable Features
D E V I L L E
DRIVER/RKE1 DRIVER/RKE 2
ON OFF ON OFF
■■■■■■■■
Remote Recall. If you want the seat and mirror
settings activated when Unlock is pressed on the
RKE, press ON when Remote Recall Memory
appears in the DIC. To turn feature off, press OFF.
If you select ON, the DIC will advance to the Mirror
to Curb in Reverse feature.
■■■■■■■■
Key in Recall. If you want the seat and mirror
settings activated using the ignition key, press ON
when Key in Recall Memory appears in the DIC. To
turn feature off, press OFF.
■■■■■■■■
Auto Exit Seat. If you want the driver’s seat to
move to the exit position with the ignition key OFF
and door open, press INFO until Auto Exit Seat
appears in the DIC, then press ON/OFF to select.
Press the down arrow on INFO to continue.
■■■■■■■■
Auto Exit Steering Wheel. (DHS & DTS only) If you
want the steering wheel to move to the exit
position when the ignition key is off and the driver’s
door is opened, press ON when Auto Exit Strg
Wheel appears in the DIC. To turn feature off, press
OFF.
DRIVER/RKE1 DRIVER/RKE 2
ON OFF ON OFF
■■■■■■■■
Lights Flash at Unlock. If you want the parking
lamps to flash twice when Unlock is pressed on
the RKE, press ON when Lights Flash at Unlock
appears in the DIC. To turn feature off, press OFF.
■■■■■■■■
Lights Flash at Lock. If you want the parking lamps
to flash once when Lock is pressed on the RKE,
press ON when Lights Flash at Lock appears in the
DIC. To turn feature off, press OFF.
■■■■■■■■
Horn Sounds at Lock. If you want the horn to
sound once when Lock is pressed on the RKE,
press ON when Horn Sounds at Lock appears in the
DIC. To turn feature off, press OFF.
■■■■■■■■
Exterior Lighting. If you want the parking, tail,
backup, and high beam lamps illuminated for 20
seconds when Unlock is pressed on the RKE (or until
the door is opened or the ignition key is turned out of
the OFF position), press ON when Ext Lights at Unlock
appears in the DIC. To turn feature off, press OFF.
NOTE: Shaded areas are for vehicles equipped with the Memory Package.

❏Reviewed with Customer (Please Check Box)
DRIVER/RKE1 DRIVER/RKE 2
ON OFF ON OFF
■■■■■■■■
Doors Lock in Gear. If you want all the doors to
lock when the vehicle is shifted out of Park (P),
press ON when Doors Lock in Gear appears in the
DIC. To turn feature off, press OFF.
■■■■■■■■
Driver Unlock in Park. If you want the driver’s door
to unlock when the vehicle is shifted into Park (P),
press ON when Driver Unlock in Park appears in the
DIC. To turn feature off, press OFF.
■■■■■■■■
Driver Unlock Key Off. If you want the driver’s
door to unlock when the ignition key is turned OFF,
press ON when Driver Unlock Key Off appears in
the DIC. To turn feature off, press OFF.
■■■■■■■■
Doors Unlock in Park. If you want all the doors to
unlock when the vehicle is shifted into Park (P),
press ON when Doors Unlock in Park appears in the
DIC. To turn feature off, press OFF.
■■■■■■■■
Doors Unlock Key Off. If you want the doors to
unlock when the ignition key is turned OFF, press
ON when Doors Unlock Key Off appears in the DIC.
To turn feature off, press OFF.
DRIVER/RKE1 DRIVER/RKE 2
ON OFF ON OFF
■■■■■■■■
Mirror to Curb in Reverse. If you want the
passenger’s outside mirror to tilt downward
when the vehicle is shifted into Reverse (R),
press ON when Mirror to Curb in Rev appears
in the DIC. To turn feature off, press OFF.
■■■■■■■■
Tire Pressure Display (if equipped). Press
down arrow on the INFO button until the TIRE
PRESSURE DISPLAY prompt appears. To turn
this feature on, press ON/OFF until ON is
displayed in the DIC. To turn the feature off,
press ON/OFF until OFF is displayed.
CAUTION: Do not attempt programming the vehicle while
driving.
Driver
Information
Audio Systems Comfort/
Convenience Personalization
Guide
Maintenance/
Owner Privileges™
Refer to your Owner Manual for further information.

D E V I L L E
Maintenance
1. Coolant Fill
2. Power Steering Fluid Fill Location
3. Brake Master Cylinder
4. Air Filter
5. Transaxle Fluid Dipstick
6. Engine Oil Dipstick
7. Oil Fill Location
8. Windshield Washer Fluid Fill
9. Fuses/Relay Center
ENGINE COMPARTMENT
1
2
4
5
3
6
7
8
9

05DEVILLEGTK A
To make your ownership experience
as satisfying and rewarding as
possible, we are proud to provide
you with Cadillac’s exceptional
Owner Privileges, designed to
accommodate you anytime and
anywhere.
ROADSIDE SERVICE
1-800-882-1112
Roadside Service provides every
Cadillac owner with the advantage of
contacting a Cadillac advisor and,
when appropriate, a Cadillac-trained
dealer technician who can provide
on-site services:
• Towing Service
• Battery Jump-Starting
• Lockout Assistance
• Fuel Delivery
• Flat Tire Change
(covers change only)
TRIP INTERRUPTION: If your trip is
interrupted due to a component
failure covered under warranty,
incidental expenses may be
reimbursed, including hotel, meals
and rental car.
COURTESY TRANSPORTATION may
also be provided for warranted
repairs, including shuttle service for
same-day repairs and loaner
transportation for overnight repair.
Roadside Service is also available to
Cadillac customers beyond the
warranty period for a charge.
CUSTOMER ASSISTANCE
1-800-458-8006
In Canada, call 1-888-446-2000
Should you need to ask a question,
make a comment, or request
additional information, the Cadillac
Customer Assistance Center is staffed
around the clock with professionals
to serve you.
When you call Cadillac Roadside
Service or Customer Assistance,
when possible, please provide the
phone advisor with:
• Your telephone number
• Your location
• Your Cadillac’s location
•A description of the problem
• Vehicle Identification Number
• Year and model of your Cadillac
• Delivery date
• Current mileage
CADILLAC ONLINE
For more information about your
Cadillac, including access to the
Cadillac owner Center at My GMLink,
visit www.cadillac.com.
Certain restrictions, precautions and
safety procedures apply to your
vehicle. Please read your Owner
Manual for complete instructions. All
information contained herein is based
on information available at the time
of printing and is subject to change
without notice.
DeVille is a registered trademark of
Cadillac Motor Car Division and
General Motors Corporation.
Copyright 2004 by Cadillac Motor
Car Division. All rights reserved.
Owner PrivilegesTM
Driver
Information
Audio Systems Comfort/
Convenience Personalization
Guide
Maintenance/
Owner Privileges™
