2006 Cadillac STS Navigation System M

GENERAL MOTORS, GM, the GM Emblem, CADILLAC,
the CADILLAC Crest & Wreath, and the name STS are
registered trademarks of General Motors Corporation.
DTS and DTS Digital
Surround are registered
trademarks of Digital
Theater Systems, Inc.
The information in this manual supplements the owner
manual. This manual includes the latest information
available at the time it was printed. We reserve the right
to make changes in the product after that time without
notice. For vehicles first sold in Canada, substitute
the name General Motors of Canada Limited for Cadillac
Motor Car Division whenever it appears in this manual.
Keep this manual with the owner manual in the
vehicle, so it will be there if it is needed. If the vehicle is
sold, leave this manual in the vehicle.
Canadian Owners
For Canadian owners that would like to obtain a French
language manual, see “Canadian Owners” in the
Index of your vehicle’s owner manual.
Litho in U.S.A.
Part No. 10376370 A First Print
©
2005 General Motors Corporation. All Rights Reserved.
ii

Overview .........................................................1-2
Navigation System Overview ............................1-2 Getting Started ...............................................1-4 Cleaning the Display .....................................1-12
Section 1 Overview
1-1

Overview
Navigation System Overview
1-2

A. Audio Status Line
B. Audio Source Screen Button. See Navigation Audio
System on page 3-2 for more information.
C. North Up/Heading Up Symbol. See Symbols on
page 2-6 for more information.
D. No GPS Symbol. See Symbols on page 2-6 for more
information.
E. Navigation Menu Symbol. See Navigation Menu on
page 2-16 for more information.
F. Map Scales. See “Map Scales” under Maps on
page 2-4 for more information.
G. Guidance Window Symbol. See Symbols on
page 2-6 for more information.
H. Z(Map DVD Eject) Key. See “Hard Keys” under
Using the Navigation System on page 2-2 for more
information.
I. Map DVD Loading Slot.
J. M(CD/DVD Changer Loading) Key. See Six-Disc
CD/DVD Changer on page 3-11 for more information.
K. Z(CD/DVD Changer Eject) Key. See Six-Disc
CD/DVD Changer on page 3-11 for more information.
L. CD/DVD Changer Loading Slot.
M. On(Power/Volume) Knob. See “Hard Keys”
under Using the Navigation System on page 2-2 for
more information.
N. ¦m¥(Navigation Screen Tilt) Key (in/out).
See “Hard Keys” under Using the Navigation
System on page 2-2 for more information.
O. Clock. See “Clock” under Configure Menu on
page 2-52 for more information.
P. Memory Point Symbol. See Symbols on page 2-6 for
more information.
Q. POI Symbol (Point of Interest). See Symbols on
page 2-6 for more information.
R. BAND Key. See Navigation Audio System on
page 3-2 for more information.
S. AUX (Auxiliary) Key. See “Hard Keys” under Using
the Navigation System on page 2-2 for more
information.
1-3

T. ROUTE Key. See Destination on page 2-37 for more
information.
U. )(Map) Key. See “Hard Keys” under Using the
Navigation System on page 2-2 for more information.
V. w(Tune) Knob. See Navigation Audio System
on page 3-2 for more information.
W. SRCE (Source) Key. See Navigation Audio System
on page 3-2 for more information.
X. e(Audio) Key. See Navigation Audio System on
page 3-2 for more information.
Y. CONFIG Key. See Configure Menu on page 2-52 for
more information.
Z. k(Navigation Voice Prompt Repeat) Key. See
“Hard Keys” under Using the Navigation System on
page 2-2 for more information.
AA. ¦tu¥(Seek/Scan) Key. See Navigation
Audio System on page 3-2 for more information.
Getting Started
Before you begin to operate the navigation system, read
this manual thoroughly to become familiar with it and to
understand how the system works.
Keeping your mind on the drive is important for safe
driving. See “Defensive Driving” in the Index of your
vehicle’s owner manual for more information. Get familiar
with your vehicle’s navigation system so you can use it
with less effort and take full advantage of its features.
Your navigation system includes not only navigation,
but also audio functions. While your vehicle is parked:
•Familiarize yourself with all of its controls: hard keys
on the faceplate and touch-sensitive screen buttons.
•Familiarize yourself with its operation.
•Set up your audio by presetting your favorite stations,
setting the tone, and adjusting the speakers. Then,
when driving conditions permit, you can tune to your
favorite stations using the presets and steering wheel
controls (if equipped).
•Set up the navigation features that can only be
done before you begin driving, such as entering
an address or a preset destination.
1-4

Entering a destination or alphanumeric text requires
many steps, so you can only perform these operations
when the vehicle is in PARK (P). You will notice
that touch-sensitive screen buttons leading to the
alphanumeric keyboard are dimmed out while driving.
Other functions may also be locked out while driving and
they too will appear grayed out on the screen — but
all functions are available when parked. Some functions
can be performed while driving, as long as you can
do so without diverting too much of your attention from
your driving.
{CAUTION:
This system provides you with a far greater
access to audio stations and song listings.
Giving extended attention to entertainment
tasks while driving can cause a crash and you
or others can be injured or killed. Always keep
your eyes on the road and your mind on the
drive — avoid engaging in extended searching
while driving.
{CAUTION:
Looking at the moving map on the navigation
screen frequently or for too long while driving
can cause a crash and you or others can be
injured or killed. Keep your eyes and mind on
the road and avoid looking too long or too
often at the moving map on the navigation
screen. Use the voice guidance directions
whenever possible.
The navigation system allows you to do the following:
•Plan a route with provided turn-by-turn route
and map guidance with voice prompts.
•Select a destination using various methods
and choices.
•Receive broadcast announcements on traffic and
emergency alert communications.
The information in the system may not always be
complete. Road conditions such as prohibited turns,
detours, and construction zones, change frequently.
It is important to consider whether you can follow the
directions given by the system for the current conditions.
1-5

Each time you start your vehicle and turn on the
navigation system by touching the map hard key, you will
see this screen. You can touch I agree to proceed into the
system, or the globe symbol in the lower left corner of the
screen to change the language of the system. For more
information on changing the language, see
Personalization on page 5-2.
When getting started you may set the navigation system
to your preference using various options. To do so,
reference the following topics:
•To adjust screen appearance, see “Screen
Appearance” under Configure Menu on page 2-52.
•To adjust the clock and other time options, see
“Clock” under Configure Menu on page 2-52.
•To plan a route, see Destination on page 2-37.
•To adjust the volume of voice guidance prompts or
voice recognition, see “Navigation Set Up” under
Configure Menu on page 2-52.
1-6

Setting Radio Station Presets
To set preset radio stations, do the following:
1. Press the power/volume knob to turn the system on.
2. Press the BAND hard key.
3. Select the desired band (AM, FM1, FM2, XM1, or
XM2 (if equipped)).
4. Seek, scan, or tune to the desired stations using
the seek and scan hard key arrows or the
tuning knob.
5. Press and hold one of the six preset screen buttons,
at the bottom of the screen, until you hear a beep or
see the station displayed on the selected preset
button.
6. Repeat the steps for each preset.
See “Preset Stations” under Navigation Audio System
on page 3-2 for more information.
Setting the Time
To set the time, do the following:
1. Press the power/volume knob to turn the system on.
2. Press the CONFIG hard key.
3. Press the H(clock) screen button.
4. Select the 12hour or 24hour screen button to
display the time in standard or military time.
5. Select the AM or PM screen buttons.
6. Select the appropriate time zone screen button.
7. Select the Daylight Saving Time screen button,
if necessary.
8. Press and hold the hour and minute arrow buttons to
increase or to decrease the time or press the GPS
TIME screen button to reset radio time to GPS time.
The radio will use the GPS satellite to set the time. The
vehicle needs to be in an open area to receive the signal.
See “Clock” under Configure Menu on page 2-52 for
more information.
1-7

Setting the Region, Entering an
Address and Point of Interest, and
Storing a Home Destination and Preset
Destinations
Before entering an Address, Point of Interest, Home, or
Preset Destination, select the appropriate region that
contains the final destination. Your vehicle must be
stopped to perform this operation.
Setting the Region
To set the region, do the following:
1. Press the power/volume knob to turn the system on.
2. Insert the DVD map disc. See “Installing the Map
DVD” under Maps on page 2-4 for more information.
A notice may appear. Touch the I agree screen
button to proceed.
3. Press the ROUTE hard key.
4. Press the Region screen button.
5. Select the appropriate region numbered screen
button that contains your final destination.
The system will return to the DESTINATION ENTRY
screen. See “Region” under Destination on page 2-37
for more information.
Entering an Address
To set a destination by entering a street address, do the
following:
1. Press the power/volume knob to turn the system on.
2. Insert the DVD map disc. See “Installing the Map
DVD” under Maps on page 2-4 for more information.
A notice may appear. Touch the I agree screen
button to proceed.
3. Press the ROUTE hard key. Verify that the selected
Region is correct.
4. Press the CAddress screen button.
5. Enter the street name using the alpha keypad on
the screen.
Do not enter directional information or street type,
and use the space symbol screen button (U)
between street or city names. For example, the
street name N. Royal Oak Rd. should be entered as
royalUoak. Use the backspace (V) screen
button if an incorrect character has been entered.
6. Select the desired street name with the correct
designation (Dr., Ln., St., etc.) from the list.
7. If there is more than one city, the system will
display the list of cities that have a street with
that name. Select a city from the list.
1-8

8. Enter the house number using the numeric keypad
on the screen and touch the OK screen button.
A map screen will appear with the destination
marked.
9. Select the h(destination) symbol screen button.
10. Select the Guide screen button.
11. Once you begin driving you will hear an audio
prompt to “Proceed to the highlighted route.”
You are now in route guidance mode.
See “Address” under Destination on page 2-37 for more
information.
Entering a Point of Interest (POI)
To set a destination by entering a Point of Interest (POI),
do the following:
1. Press the power/volume knob to turn the system on.
2. Insert the DVD map disc. See “Installing the Map
DVD” under Maps on page 2-4 for more information.
A notice may appear. Touch the I agree screen
button to proceed.
3. Press the ROUTE hard key. Verify that the selected
Region is correct.
4. Press the i(POI) screen button.
5. Enter the specific title of the POI in the name space
(i.e. Washington Monument) using the alpha keypad
on the screen.
6. Select the POI from the list.
7. If there is more than one city, the system will
display the list of cities that have a street with
that name. Select a city from the list or select the
Input Name screen button to input the city name.
A map screen will appear with the destination
marked.
8. Select the h(destination) symbol screen button.
9. Select the Guide screen button.
10. Once you begin driving you will hear an audio
prompt to “Proceed to the highlighted route.”
You are now in route guidance mode.
Using the Category or City selections will aid the system
in finding your POI by limiting the search options. See
“Point of Interest (POI)” under Destination on page 2-37
for more information.
1-9

Storing a Home Destination
1. Press the power/volume knob to turn the system on.
2. Insert the DVD map disc. See “Installing the Map
DVD” under Maps on page 2-4 for more information.
A notice may appear. Touch the I agree screen
button to proceed.
3. Press the )(map) hard key.
4. Press the Menu screen button from the map screen.
5. Press the NMemory Points screen button.
6. Press the LHome screen button.
7. Press the Add screen button.
8. Press the Address screen button and enter all
address information.
9. Press the OK screen button.
The LHome icon will be highlighted on the
DESTINATION ENTRY screen. See “Using Your
Home or Preset Destinations” later in this section
for more information.
See “Memory Points” under Navigation Menu on
page 2-16 for more information.
Storing a Preset Destination
1. Press the power/volume knob to turn the system on.
2. Insert the DVD map disc. See “Installing the Map
DVD” under Maps on page 2-4 for more information.
A notice may appear. Touch the I agree screen
button to proceed.
3. Press the )(map) hard key.
4. Press the Menu screen button from the map screen.
5. Press the NMemory Points screen button.
6. Press the APreset Dests. screen button.
7. Press the Add screen button and select the
numbered preset row to store the destination as.
8. Press the Address screen button and enter all
address information.
9. Press the OK screen button.
The numbered preset destination will be highlighted
on the DESTINATION ENTRY screen. See “Using
Your Home or Preset Destinations” later in this
section for more information.
See “Memory Points” under Navigation Menu on
page 2-16 for more information.
1-10

Using Your Home or Preset
Destinations
These destinations are available for selection while
driving.
1. Press the power/volume knob to turn the system on.
2. Insert the DVD map disc. See “Installing the Map
DVD” under Maps on page 2-4 for more information.
A notice may appear. Touch the I agree screen
button to proceed.
3. Press the ROUTE hard key. Verify that the selected
Region is correct.
4. Select the L(Home symbol) or one of the available
preset destination symbols. A map screen will
appear with the destination marked.
5. Select the h(destination) symbol screen button.
6. Select the Guide screen button.
7. Once you begin driving you will hear an audio
prompt to “Proceed to the highlighted route.”
You are now in route guidance mode.
See “Preset Destination” or “Home” under
Destination on page 2-37 for more information.
Canceling Guidance
Guidance will be canceled once you arrive at your final
destination. To cancel guidance prior to arrival at the
final destination, do the following:
1. Press the )(map) hard key.
2. Press the Menu screen button from the map
screen.
3. Press the EChange Route screen button.
4. Press the Cancel Guidance screen button.
5. Press the Yes screen button to confirm cancellation.
1-11

Guidance Volume
To adjust the volume of voice guidance prompts, do the
following:
1. Press the CONFIG hard key.
2. Press the 3(navigation set up) screen button.
3. Press the >Volume screen button.
4. Select the desired volume or select Off. The system
will play back the new volume level.
See “Volume” under Configure Menu on page 2-57for
more information.
Cleaning the Display
If the panel or the display is stained, wipe it with a dry,
soft cloth, such as a silicon cloth.
Notice: If you use abrasive cleaners when cleaning
glass surfaces, you could scratch the glass. When
cleaning the glass, use only a soft cloth and do not
spray cleaner directly on the system.
Do not apply spray cleaner directly to the system,
the cleaner could affect the mechanical parts.
Do not wipe the panel with a hard cloth or use a volatile
liquid such as thinner or alcohol, it could scratch the
surface or erase the characters.
1-12

Features and Controls ......................................2-2
Using the Navigation System ...........................2-2
Maps ............................................................2-4
Symbols ........................................................2-6
Navigation Menu ...........................................2-16
Destination ..................................................2-37
Keyless Access System .................................2-55
OnStar
®
System ...........................................2-55
Configure Menu ............................................2-57
Global Positioning System (GPS) ....................2-67
Vehicle Positioning ........................................2-68
Problems with Route Guidance .......................2-69
If the System Needs Service ..........................2-70
Ordering Map DVDs ......................................2-70
Database Coverage Explanations ....................2-70
Section 2 Features and Controls
2-1

Features and Controls
Using the Navigation System
This section presents basic information you will need to
know to operate the navigation system.
Use the hard keys located on the navigation system
along with the available touch screen buttons on the
navigation screen to operate the system. See Navigation
System Overview on page 1-2 for more information.
Once the vehicle is moving, various functions will be
disabled to reduce driver distractions.
Hard Keys
The following hard keys are located on the navigation
system:
Z(Map DVD Eject): Press the eject key located
next to the map DVD loading slot to eject the map DVD.
The map DVD slot is the slot directly below the display
screen.
M(Load): Press the CD/DVD changer loading key to
go to the loading screen and begin loading DVDs or
CDs. See Six-Disc CD/DVD Changer on page 3-12 for
more information.
Z(CD/DVD Eject): Press the eject key next to the
CD/DVD changer loading slot to begin ejecting DVDs or
CDs. See Six-Disc CD/DVD Changer on page 3-12
for more information.
On(Power/Volume): Press the power/volume knob
to turn the audio system on and off. Turn the knob to
increase or decrease the volume to the audio system.
ymz(Tilt): Press the up arrow on the tilt key to tilt
the navigation screen forward. Press the down arrow
on the tilt key to tilt the screen rearward. There are three
tilt positions to choose from.
BAND: Press the BAND key to access the audio
source screen. The press the BAND key to toggle
among the bands available, FM, AM, XM (if equipped),
and WX (weather). See Navigation Audio System on
page 3-2.
2-2

SRCE (Source): Press the source key to switch
between the audio sources. Pressing this key will switch
between the radio and the CD/DVD player. See
Navigation Audio System on page 3-2.
AUX (Auxiliary): Press the AUX key to access screens
from which you will operate Bluetooth
®
, OnStar
®
,or
control video input. See Bluetooth
®
Phone on page 6-2,
OnStar
®
System on page 2-55, and Auxiliary Devices
on page 3-25 for more information.
e(Audio): Press the audio key to access the Audio
Adjust screen, to adjust bass, midrange, fade, balance,
and DSP (Digital Signal Processing) settings. See
Navigation Audio System on page 3-2.
ROUTE: Press the ROUTE key to access the
Destination Entry screen or the search area and begin
planning a destination. See Destination on page 2-37.
CONFIG (Configure): Press the CONFIG key to access
the SETTING Function screen. See Configure Menu
on page 2-57.
)(Map): Press the map key to access the map
screen.
k(Navigation Repeat): Press the navigation repeat
key to repeat the last voice guidance prompt, while
on a planned route.
y©¨z (Seek/Scan): Press the seek/scan arrows
to go to the next or previous radio station, or press
and hold to scan stations. See Navigation Audio System
on page 3-2.
w(Tune) Knob: Turn the tune knob to change
frequencies. See Navigation Audio System on page 3-2.
Alpha-Numeric Keypad
Letters of the alphabet, symbols, punctuation, and
numbers will be displayed on the navigation screen as
an alpha or numeric keypad. The alpha keypad will
be displayed when the system needs input of a city or
street name.
All characters are touch-sensitive screen buttons.
Touch a character to select it.
Sym. (Symbol): Touch this screen button to access
the numeric keypad, punctuation marks, and other
characters. There are two pages available. Use the
right and left arrow screen buttons to view the pages.
2-3

A - Z (Alphabet): Touch this screen button to display to
the alpha keypad.
Others: Touch this screen button to display special
characters. There are two pages of characters available.
Use the right and left arrow screen buttons to view the
pages.
U(Space): Touch this screen button to enter a
space between characters or the words of a name.
V(Back space): Touch this screen button if
an incorrect character has been selected.
To make name selections easier, the system will only
allow you to select a character which can follow the last
one entered. For example, if a Z is entered, a T will
not be available to select. The system will highlight the
available characters.
If a name is not available after input, it may need to be
inputted differently, the map DVD database may not
contain that information, or the correct search area has
not been selected. See Database Coverage
Explanations on page 2-70 for more information.
Touch-Sensitive Screen Buttons
Touch-sensitive screen buttons are located on the
screen. When a screen button has been selected, a beep
will sound. These buttons will be highlighted when a
feature is available. There are also some toggle screen
buttons that will be light blue when active and dark blue
when inactive.
Maps
This section includes basic information about the map
database.
Regional Maps
The maps are stored on a DVD. The 48 contiguous
United States and portions of Canada are contained on
one disc.
If a regional map does not contain a specific city, the
map DVD may not contain the city or it may be
misspelled.
Refer to the Navigation System Map Disc manual to view
a detailed explanation of map coverage and detailed city
lists in each region. This manual will be in the map DVD
case when the vehicle is delivered from the factory.
2-4

Installing the Map DVD
When your vehicle is delivered from the factory, the
dealer may have installed the map DVD. If the map DVD
was not installed, use the following directions to load
the map DVD:
Read the following steps completely before operating
this feature.
1. Turn the ignition on.
2. Load the map DVD into the slot, located just below
the navigation system screen, by inserting it
partially until the system pulls it in.
Once the map DVD is inserted correctly, you will have
the following two choices:
I agree: Touch this screen button to proceed to the
navigation system.
^(Language): Touch this screen button to change
the language of the navigation system, Driver
Information Center (DIC), Head-Up Display (HUD), etc.
See “Language” under Personalization on page 5-2
for more information.
Once a language has been selected, touch I agree to
enter the navigation system. The map will appear
showing your current vehicle position.
Setting the Search Area
See Destination on page 2-37 for information on
changing the search area.
Map Adjustments
You can adjust the scale of view on the map. As you
drive, the map will scroll automatically based on
the direction you are traveling.
Map Scales
To view a larger or smaller
scale of the map, touch
the map scale arrows.
Change the level of map detail by either zooming in or
zooming out using the arrow screen buttons or by
touching the scale on the bar. The system will adjust
the map accordingly. The scale of a map can range from
1/32 of a mile (50 m) to 128 miles (256 km).
2-5

Scrolling the Map
Touch anywhere on the
map screen twice and the
scroll symbol will appear.
Use this feature to
scroll across the map.
Hold your finger in any direction outside of the scroll
symbol and the map will continue to scroll in that
direction until you remove your finger from the map
screen.
If scrolling while your vehicle is in PARK (P), the system
will scroll initially at a slower rate. It will increase if
you continue touching the map screen.
If scrolling while your vehicle is in motion, you have one
scroll speed and a limited distance to scroll. Keep
touching the map screen to scroll for a longer distance.
If the scroll feature is used to scroll the map and
your vehicle icon becomes lost, press the map hard key
to return to the current vehicle location on the map.
When scrolling on the map, the system will display the
address of the scroll symbol location and the distance
from your vehicle’s current position to the scroll symbol
location.
Use the scroll feature on the map to set a destination.
See “Map” under Destination on page 2-37 for more
information.
Symbols
The following symbols are the most common symbols
that will appear on a map screen.
Your vehicle is shown as
this symbol. It indicates the
current position and
heading direction of your
vehicle on the map.
The destination symbol will
appear on the map after a
route has been planned
marking your final
destination.
2-6
