FMC-4SFP+
Dual- and Quad-channel
SFP/SFP+ FMC Adapter
Pin Assignments
All Rights Reserved
© CAEN ELS s.r.l.
Rev. 1.2 –October 2017
FMC –FPGA MEZZANINE CARD

FMC-4SFP+ - User’s Manual
2

FMC-4SFP+ - User’s Manual
3
For technical assistance please refer to the following contact:

FMC-4SFP+ - User’s Manual
4
Table Of Contents
1. INTRODUCTION................................................................................................9
1.1 FMC-SFP OVERVIEW.....................................................................................9
1.2 FMC CONNECTIONS......................................................................................10
1.2.1 ROW A .....................................................................................................10
1.2.1 ROW B .....................................................................................................11
1.2.1 ROW C .....................................................................................................11
1.2.1 ROW D.....................................................................................................12
1.2.1 ROW E .....................................................................................................13
1.2.1 ROW F .....................................................................................................13
1.2.1 ROW G.....................................................................................................13
1.2.1 ROW H.....................................................................................................15
1.2.1 ROW J......................................................................................................16
1.2.1 ROW K .....................................................................................................16
2. CLOCK GENERATION...................................................................................17
3. ORDERING OPTIONS.....................................................................................18
4. TECHNICAL SPECIFICATIONS ..................................................................19

FMC-4SFP+ - User’s Manual
5
Document Revisions
Document Revision
Date
Comment
1.0
November 5th, 2015
First Release
1.1
April 1st, 2016
Corrected VADJ range
1.2
October 27th, 2017
Format changed

FMC-4SFP+ - User’s Manual
6
Safety information - Warnings
CAEN ELS will repair or replace any product within the guarantee period if the
Guarantor declares that the product is defective due to workmanship or materials and
has not been caused by mishandling, negligence on behalf of the User, accident or any
abnormal conditions or operations.
Please read carefully the manual before operating any part of the instrument
WARNING
Do NOT open the boxes
CAEN ELS s.r.l. declines all responsibility for damages or injuries caused
by an improper use of the Modules due to negligence on behalf of the User. It is
strongly recommended to read thoroughly this User's Manual before any kind of
operation.
CAEN ELS s.r.l. reserves the right to change partially or entirely the contents of this
Manual at any time and without giving any notice.
Disposal of the Product
The product must never be dumped in the Municipal Waste. Please check your local
regulations for disposal of electronics products.

FMC-4SFP+ - User’s Manual
7
Read over the instruction manual carefully before using the instrument.
The following precautions should be strictly observed before using the device:
WARNING
•Do not use this product in any manner not
specified by the manufacturer. The protective
features of this product may be impaired if it is
used in a manner not specified in this manual.
•Do not use the device if it is damaged. Before you
use the device, inspect the instrument for possible
cracks or breaks before each use.
•Do not operate the device around explosives gas,
vapor or dust.
•Always use the device with the cables provided.
•Turn off the device before establishing any
connection.
•Do not operate the device with the cover removed
or loosened.
•Do not install substitute parts or perform any
unauthorized modification to the product.
•Return the product to the manufacturer for service
and repair to ensure that safety features are
maintained
CAUTION
•This instrument is designed for indoor use and in
area with low condensation.

FMC-4SFP+ - User’s Manual
8
The following table shows the general environmental requirements for a correct
operation of the instrument:
Environmental Conditions
Requirements
Operating Temperature
0°C to 50°C
Operating Humidity
30% to 85% RH (non-condensing)
Storage Temperature
-10°C to 60°C
Storage Humidity
5% to 90% RH (non-condensing)

FMC-4SFP+ - User’s Manual
9
1.Introduction
This chapter describes the general characteristics and main features of the
CAEN ELS FMC-SFP mezzanine cards.
1.1 FMC-SFP Overview
The CAEN ELS FMC-SFP is a standard FPGA Mezzanine Card (FMC) Low
Pin Count (LPC) daughter board that allows to communicate up to 4 high speed hot-
swappable SFP+ devices. The board is available in two different versions:
•FMC-4SFP+ version: with 4 fast SFP/SFP+ channels, without front panel;
•FMC-2SFP+ version: with 2 fast SFP/SFP+ channels, with standard FMC
bezel.
The board is electrically compliant to the FMC standard (ANSI/VITA 57.1). All
module pins are translated to the FMC carrier voltage VADJ that can be in the range
from 1.5V to 3.3V. With its low operation voltage it can be used on almost all carriers.
The module is compatible with LPC and HPC carrier boards.
The components are placed to be compatible also with carriers that have
components under the FMC module. The SFP+ cages are placed to fi all carriers without
front panel modifications.
The module mounts an oscillator chip that can be configured using the I2C-
controlled LVDS (Low Voltage Differential Signaling) interface. The start-up
frequency could be also decided using a DIP switch present on the board (Autonomous
Mode). The operating frequency range of the chis is from 10 MHz up to 280 MHz.

FMC-4SFP+ - User’s Manual
10
1.2 FMC connections
In the following sections are described all the FMC connection with the FMC-SFP board.
1.2.1 ROW A
All FMC ROW A GND pins are connected to ground and are not listed in the following table.
Pin #
Pin Name
Connectivity
IO Standard
Remark
A2
DP1_M2C_P
Module 2 RX (inner module)
module dependent, SFF-8418
FMC output
A3
DP1_M2C_N
Module 2 RX (inner module)
module dependent, SFF-8418
FMC output
A6
DP2_M2C_P
Module 4 RX (outer module)
module dependent, SFF-8418
FMC output (*)
A7
DP2_M2C_N
Module 4 RX (outer module)
module dependent, SFF-8418
FMC output (*)
A10
DP3_M2C_P
Module 1 RX (outer module)
module dependent, SFF-8418
FMC output (*)
A11
DP3_M2C_N
Module 1 RX (outer module)
module dependent, SFF-8418
FMC output (*)
A14
DP3_M2C_P
Not Connected
/
/
A15
DP3_M2C_N
Not Connected
/
/
A18
DP3_M2C_P
Not Connected
/
/
A19
DP3_M2C_N
Not Connected
/
/
A22
DP1_C2M_P
Module 2 TX (inner module)
module dependent, SFF-8418
FMC input
A23
DP1_C2M_N
Module 2 TX (inner module)
module dependent, SFF-8418
FMC input
A26
DP2_C2M_P
Module 4 TX (outer module)
module dependent, SFF-8418
FMC input (*)
A27
DP2_C2M_N
Module 4 TX (outer module)
module dependent, SFF-8418
FMC input (*)
A30
DP3_C2M_P
Module 1 TX (outer module)
module dependent, SFF-8418
FMC input (*)
A31
DP3_C2M_N
Module 1 TX (outer module)
module dependent, SFF-8418
FMC input (*)
A34
DP3_C2M_P
Not Connected
/
/
A35
DP3_C2M_N
Not Connected
/
/
A38
DP3_C2M_P
Not Connected
/
/
A39
DP3_C2M_N
Not Connected
/
/
Table 1: FMC Row A connections; (*) available only in 4-channel version

FMC-4SFP+ - User’s Manual
11
1.2.1 ROW B
All FMC ROW B GND pins are connected to ground and the other pins are left unconnected.
1.2.1 ROW C
All FMC ROW C GND pins are connected to ground and are not listed in the following table.
Pin #
Pin Name
Connectivity
IO Standard
Remark
C2
DP0_C2M_P
Module 3 TX (inner module)
module dependent, SFF-8418
FMC input
C3
DP0_C2M_N
Module 3 TX (inner module)
module dependent, SFF-8418
FMC input
C6
DP0_M2C_P
Module 3 RX (inner module)
module dependent, SFF-8418
FMC output
C7
DP0_M2C_N
Module 3 RX (inner module)
module dependent, SFF-8418
FMC output
C10
LA06_P
MODABS Module 4
LVCMOS (VADJ)
FMC output (*)
C11
LA06_N
MODABS Module 3
LVCMOS (VADJ)
FMC output (*)
C14
LA10_P
RS0 Module 4
LVCMOS (VADJ)
FMC input (*)
C15
LA10_N
RS0 Module 3
LVCMOS (VADJ)
FMC input (*)
C18
LA14_P
Reserved
LVCMOS (VADJ)
Do not use
C19
LA14_N
Reserved
LVCMOS (VADJ)
Do not use
C22
LA18_CC_P
Reserved
LVCMOS (VADJ)
Do not use
C23
LA18_CC_N
Reserved
LVCMOS (VADJ)
Do not use
C26
LA27_P
Not Connected
/
/
C27
LA27_N
Not Connected
/
/
C30
SCL_C
EEPROM SCL
LVCMOS (+3V3PAUX)
/
C31
SDA_C
EEPROM SDA
LVCMOS (+3V3PAUX)
/
C34
GA0
EEPROM GA0
LVCMOS (+3V3PAUX)
/
C35
+12V
Not Connected
/
/
C38
+12V
Not Connected
/
/
C39
+3V3
Board Power Supply
/
/
Table 2: FMC Row C connections; (*) available only in 4-channel version

FMC-4SFP+ - User’s Manual
12
1.2.1 ROW D
All FMC ROW D GND pins are connected to ground and are not listed in the following table.
Pin #
Pin Name
Connectivity
IO Standard
Remark
D1
PG_C2M
Connected to on-board logic
/
Do not use
D4
GBTCLK0_M2C_P
Si570 Oscillator Output
LVDS
Frequency according to dip switches
(see Chapter 2)
D5
GBTCLK0_M2C_N
Si570 Oscillator Output
LVDS
Frequency according to dip switches
(see Chapter 2)
D8
LA01_CC_P
Reserved
LVCMOS (VADJ)
Do not use
D9
LA01_CC_N
Reserved
LVCMOS (VADJ)
Do not use
D11
LA05_P
RXLOS Module 2
LVCMOS (VADJ)
FMC output
D12
LA05_N
RXLOS Module 1
LVCMOS (VADJ)
FMC output
D14
LA09_P
TXDISABLE Module 2
LVCMOS (VADJ)
FMC input
D15
LA09_N
TXDISABLE Module 1
LVCMOS (VADJ)
FMC input
D17
LA13_P
RS1 Module 2
LVCMOS (VADJ)
FMC input
D18
LA13_N
RS1 Module 1
LVCMOS (VADJ)
FMC input
D20
LA17_CC_P
Reserved
LVCMOS (VADJ)
Do not use
D21
LA17_CC_N
Reserved
LVCMOS (VADJ)
Do not use
D23
LA23_P
I2C SCL Module 4
LVCMOS (VADJ) open drain
I2C (*)
D24
LA23_N
I2C SDA Module 4
LVCMOS (VADJ) open drain
I2C (*)
D26
LA26_P
Not Connected
/
/
D27
LA26_N
Not Connected
/
/
D29
TCK
Connected to on-board logic
LVCMOS (3.3V)
Do not use
D30
TDI
Connected to on-board logic
LVCMOS (3.3V)
Do not use
D31
TDO
Connected to on-board logic
LVCMOS (3.3V)
Do not use
D32
+3V3AUX
EEPROM +3.3V AUX
/
/
D33
TMS
Connected to on-board logic
LVCMOS (3.3V)
Do not use
D34
TRST_L
Not Connected
/
/
D35
GA1
EEPROM GA1
LVCMOS (+3V3PAUX)
/

FMC-4SFP+ - User’s Manual
13
Pin #
Pin Name
Connectivity
IO Standard
Remark
D36
+3V3
Board Power Supply
/
/
D38
+3V3
Board Power Supply
/
/
D40
+3V3
Board Power Supply
/
/
Table 3: FMC Row D connections; (*) available only in 4-channel version
1.2.1 ROW E
All FMC ROW E GND pins are connected to ground and the other pins are left unconnected, except the PIN E39 (see the following table).
Pin #
Pin Name
Connectivity
IO Standard
Remark
E39
VADJ
IO Pins Power Supply
/
Not used in LPC carriers
Table 4: FMC Row E connection
1.2.1 ROW F
All FMC ROW F GND pins are connected to ground and the other pins are left unconnected, except the PIN F40 (see the following table).
Pin #
Pin Name
Connectivity
IO Standard
Remark
F40
VADJ
IO Pins Power Supply
/
Not used in LPC carriers
Table 5: FMC Row F connection
1.2.1 ROW G
All FMC ROW G GND pins are connected to ground and are not listed in the following table.
Pin #
Pin Name
Connectivity
IO Standard
Remark
G2
CLK0_C2M_P
Not Connected
/
/
G3
CLK0_C2M_N
Not Connected
/
/
G6
LA00_CC_P
Reserved
LVCMOS (VADJ)
Do not use
G7
LA00_CC_N
Reserved
LVCMOS (VADJ)
Do not use

FMC-4SFP+ - User’s Manual
14
Pin #
Pin Name
Connectivity
IO Standard
Remark
G9
LA03_P
TXFAULT Module 2
LVCMOS (VADJ)
FMC output
G10
LA03_N
TXFAULT Module 1
LVCMOS (VADJ)
FMC output
G12
LA08_P
TXDISABLE Module 4
LVCMOS (VADJ)
FMC input (*)
G13
LA08_N
TXDISABLE Module 3
LVCMOS (VADJ)
FMC input (*)
G15
LA12_P
RS1 Module 4
LVCMOS (VADJ)
FMC input (*)
G16
LA12_N
RS1 Module 3
LVCMOS (VADJ)
FMC input (*)
G18
LA16_P
Reserved
LVCMOS (VADJ)
Do not use
G19
LA16_N
Reserved
LVCMOS (VADJ)
Do not use
G21
LA20_P
Not Connected
/
/
G22
LA20_N
Not Connected
/
/
G24
LA22_P
I2C SCL Module 2
LVCMOS (VADJ) open drain
I2C
G25
LA22_N
I2C SDA Module 2
LVCMOS (VADJ) open drain
I2C
G27
LA25_P
Si570 Oscillator I2C SCL
LVCMOS (VADJ) open drain
Programmed after reset regarding DIP Sw.
G28
LA25_N
Si570 Oscillator I2C SDA
LVCMOS (VADJ) open drain
Programmed after reset regarding DIP Sw.
G30
LA29_P
Not Connected
/
/
G31
LA29_N
Not Connected
/
/
G33
LA31_P
Not Connected
/
/
G34
LA31_N
Not Connected
/
/
G36
LA33_P
Not Connected
/
/
G37
LA33_N
Not Connected
/
/
G39
VADJ
IO Pins Power Supply
/
/
Table 6: FMC Row G connections; (*) available only in 4-channel version

FMC-4SFP+ - User’s Manual
15
1.2.1 ROW H
All FMC ROW H GND pins are connected to ground and are not listed in the following table.
Pin #
Pin Name
Connectivity
IO Standard
Remark
H1
VREF_A_M2C
Not Connected
/
/
H2
PRSNT_M2C#
GND
/
/
H4
CLK0_M2C_P
Not Connected
/
/
H5
CLK0_M2C_N
Not Connected
/
/
H7
LA02_P
TXFAULT Module 4
LVCMOS (VADJ)
FMC output (*)
H8
LA02_N
TXFAULT Module 3
LVCMOS (VADJ)
FMC output (*)
H10
LA04_P
RXLOS Module 4
LVCMOS (VADJ)
FMC output (*)
H11
LA04_N
RXLOS Module 3
LVCMOS (VADJ)
FMC output (*)
H13
LA07_P
MODABS Module 2
LVCMOS (VADJ)
FMC output
H14
LA07_N
MODABS Module 1
LVCMOS (VADJ)
FMC output
H16
LA11_P
RS0 Module 2
LVCMOS (VADJ)
FMC input
H17
LA11_N
RS0 Module 1
LVCMOS (VADJ)
FMC input
H19
LA15_P
Reserved
LVCMOS (VADJ)
Do not use
H20
LA15_N
Reserved
LVCMOS (VADJ)
Do not use
H22
LA19_P
Reserved
LVCMOS (VADJ)
Do not use
H23
LA19_N
Reserved
LVCMOS (VADJ)
Do not use
H25
LA21_P
I2C SCL Module 1
LVCMOS (VADJ) open drain
I2C
H26
LA21_N
I2C SDA Module 1
LVCMOS (VADJ) open drain
I2C
H28
LA24_P
I2C SCL Module 3
LVCMOS (VADJ) open drain
I2C (*)
H29
LA24_N
I2C SDA Module 3
LVCMOS (VADJ) open drain
I2C (*)
H31
LA28_P
Not Connected
/
/
H32
LA28_N
Not Connected
/
/
H34
LA30_P
Not Connected
/
/
H35
LA30_N
Not Connected
/
/
H37
LA32_P
Not Connected
/
/
H38
LA32_N
Not Connected
/
/

FMC-4SFP+ - User’s Manual
16
Pin #
Pin Name
Connectivity
IO Standard
Remark
H40
VADJ
IO Pins Power Supply
/
/
Table 7: FMC Row H connections; (*) available only in 4-channel version
1.2.1 ROW J
All FMC ROW J GND pins are connected to ground and the other pins are left unconnected.
1.2.1 ROW K
All FMC ROW K GND pins are connected to ground and the other pins are left unconnected.

FMC-4SFP+ - User’s Manual
17
2.Clock Generation
The CAEN ELS FMC-SFP mounts also a Clock Generator Chip Silicon Labs
SI570 (570BBC000121DG), which allows to generate random low-jitter clock at any
frequency ranging from 10 MHz to 280 MHz.
At power-up of the board, the SI570 chip generates a frequency according to the
configuration of DIP Switches. In the following table are summarized the possible start-
up DIP switches configurations:
Switch #3
Switch #2
Switch #1
Clock Frequency
0
0
0
125.00 MHz
0
0
1
156.25 MHz
0
1
0
162.50 MHz
0
1
1
178.25 MHz
1
0
0
200.00 MHz
1
0
1
203.15 MHz
1
1
0
250.00 MHz
1
1
1
Do not use
Table 8: Start-up Clock Frequency
The Silicon Labs clock generation chip is accessible also using the I2C bus, so
it is possible to communicate directly with the chip to configure it and to generate the
desired clock frequency. The I2C interface is accessible using the pins: LA25_P (Si570
I2C SCL) and LA25_N (Si570 I2C SDA). For additional information regarding the
Si570 please refer to its datasheet.
The DIP Switch #4 determinates the mode of operation. When it is set to 1, all
pins have to be controlled by the Carrier Board. If there is not an interaction with the
board, then the FMC-SFP will not generate a clock. Otherwise, when this switch is set
to 1, the module is enabled and the communication with the Carrier Board is disabled.

FMC-4SFP+ - User’s Manual
18
3.Ordering Options
The FMC-SFP+ board is available in two main different versions, differing by the
number of SFP channels:
F
M
C
4
S
F
P
X
X
A
A
A
4
FMC-4SFP+: Quad-channel
SFP/SPF+ FMC Adapter
2
FMC-2SFP+: Dual-channel
SFP/SPF+ FMC Adapter
NOTE: fields/characters shaded in grey color are fixed.
Table 9: Ordering Options

FMC-4SFP+ - User’s Manual
19
4.Technical Specifications
Technical Specifications of the FMC-SFP+ boards are herein presented.
Technical Specifications
FMC-SFP+
Board Type
FPGA Mezzanine Card - FMC VITA 57.1
FMC Connector Type
LPC (HPC compliant)
Number of SFP+ Channels
2 on FMC-2SFP+
4 on FMC-4SFP+
VADJ Range
1.5 V –3.3 V
On-board Oscillator Range
10 MHz –280 MHz
On-board Oscillator
Configuration Protocol
I2C
Other Features
Link Status indication via front panel or
bottom-emitting LEDs
Autonomous Mode: Clock speed setting and
transmitter activation via DIP switches
Table 10: Technical Specifications
