Calculated Industries SCALE MASTER CLASSIC 6020 User manual

•Guide de
l’utilisateur
•Guía del
usuario
SCALE MASTER
®
CLASSIC v3.0
Model 6020

2 – Scale Master®Classic v3.0
Preliminary Information
Key Definitions/Functions . . . . . . . .3
Imperial/Metric Modes . . . . . . . . . . .4
Adjusting the Wheel . . . . . . . . . . . . . .5
Using the Scale Master Classic . . . . . .5
“Rolling” a Measurement . . . . . . . . . .5
Built-in Scales . . . . . . . . . . . . . . . . . . . .6
Full Reset/All Clear . . . . . . . . . . . . . .7
Changing Measurement Units . . . . .7
Using the Custom Scale/Ruler . . . . .7
Memory Function Keystrokes . . . . . .8
Programming Modes . . . . . . . . . . . . .8
Area and Volume . . . . . . . . . . . . . . . .10
Converting Between Scales . . . . . . .12
Locking Scale Settings . . . . . . . . . . .12
Using the Counter . . . . . . . . . . . . . . .13
Appendix . . . . . . . . . . . . . . . . . . . .13
Error/Auto-Range Function . . . . . .13
Interference . . . . . . . . . . . . . . . . . . . . .13
Automatic Shut-Off . . . . . . . . . . . . . .13
Battery Replacement . . . . . . . . . . . . .14
Turning the Clicker & Beep On/Off . . . .14
Specifications . . . . . . . . . . . . . . . . . . .14
Repair and Return . . . . . . . . . . . . . .15
Warranty . . . . . . . . . . . . . . . . . . . .16
Guide de l’utilisateur (Français) . . . .19
Guía del usuario (Español) . . . . . . . .31
TABLE OF CONTENTS

3 – User’s Guide
Key Definitions/Functions
[Off/On] – Power On/Off switch
Turns power On or Off. Turning power
Off does not clear scales or modes.
[Lock] – Lock switch
Locks the mode and scale so they can-
not inadvertently be changed.
[Subtract/Count] – Subtract/Count key
Toggles measuring mode between pos-
itive and negative direction. Increases
the Count value by one. Count function
is active in the count mode.
[Rcl] – Recall key
Recalls stored values. Press [Rcl] [Rcl]
to recall the last rolled value.
[Mode] – Mode key
Used to toggle between the following
scale modes (in sequence):
1) Architectural (ARCH);
2) Engineering I (ENG I);
3) Engineering II (ENG II);
4) Custom (CUSTOM);
5) Count (COUNT).
[Scale] – Scale key
Used to toggle between various scales
within each scale mode.
[M1+] – Memory Add key (Length)
Adds the displayed value to memory.
This key is used to store a length in order
to calculate an area.
(Cont’d)

4 – Scale Master®Classic v3.0
[M2x] – Memory Add key (Width)
Adds the displayed value to memory.
This key is used to store a width in order
to calculate an area. When a length and
width have been stored in [M1+] and
[M2x], pressing [Rcl] [M2x] displays the
stored width, the next press of [M2x]
displays the area calculated from the
stored length and width, and the next
press of [M2x] displays the calculated
volume if a height has been stored.
Please see pages 10-12 for storing and
calculating an Area and Volume.
[Reset]
Used to clear the display. When pressed
together with another key, clears the
value of that key.
Imperial/Metric Modes
The Scale Master Classic is set up to use
Imperial (English) dimensional units by
default. The Scale Master Classic can be set up
to use Metric scales by using the following
sequence:
1) Turn unit off via switch.
2) Press and hold [Subtract/Count] key.
3) Turn unit on via switch.
4) Release [Subtract/Count] key.
While in Metric mode, MET will remain lit
in the scale box.
Repeat the procedure above to switch back
to Imperial mode.
(Cont’d)

5 – User’s Guide
Adjusting the Wheel
To adjust the Celcon®polymer wheel, take
a small, flat-head jeweler’s screwdriver
and slightly rotate the screw near the wheel
tip. Rotating the screw between 1 ⁄4 to 1⁄ 3
turn should adjust the wheel between free
spinning (which is too loose) to skidding
(which is too tight).
“Rolling” a Measurement
To take a measurement with the Scale
Master Classic:
1) Switch the unit on. Press [Reset] to clear
the display.
2) Select your scale mode by pressing the
[Mode] key. Then press the [Scale] key
to select your scale.
3) Begin rolling. The display will register
your measurements.
To ensure accurate measurements, be
sure to hold the unit upright and start
and stop the SMC at the exact points
you are measuring.
4) Press the appropriate key if you want
to store this measurement (ex. [M1+]
to store as length, [M2x] to store as
width).
5) Press [Reset] to clear the display and
begin a new measurement.
USING THE SCALE MASTER®CLASSIC

6 – Scale Master®Classic v3.0
Built-In Scales
Imperial (English) Units
Architect Engineer I Engineer II
ARCH ENG I ENG II
1 foot= 1 inch= 1 inch=
1/32" 10.0' 300.0'
1/16" 20.0' 333.3'
3/32" 30.0' 400.0'
1/8" 40.0' 416.6'
3/16" 50.0' 500.0'
1/4" 60.0' 583.3'
3/8" 83.3' 600.0'
1/2" 100.0' 625.0'
3/4" 166.6' 666.6'
1/1 (1") 200.0' 750.0'
3/2 (1 1/2") 250.0' 1,000.0'
2/1 (2") 1,200.0'
3/1 (3") 2,000.0'
4/1 (4") 3,000.0'
Metric Units
Architect Engineer I Engineer II
ARCH ENG I ENG II
1:1 1:100.0 1:1,000
1:2 1:125.0 1:1,250
1:3 1:150.0 1:1,500
1:4 1:200.0 1:1,625

7 – User’s Guide
1:5 1:250.0 1:2,000
1:10 1:300.0 1:2,500
1:20 1:400.0 1:5,000
1:25 1:500.0 1:6,000
1:30 1:10k
1:40 1:12.5k
1:50 1:20k
1:75 1:25k
1:50k
Full Reset/All Clear
To perform a complete reset of the unit, press
[Reset] and [Subtract/Count] simultaneously.
Changing Measurement Units
Press and hold [Subtract/Count] and press
[Mode] to switch between units. You can
also convert values from Imperial Units
(English) to Meters within the Imperial
mode. However, you cannot convert
values from Metric to Imperial when in
Metric mode.
Using the Custom Scale/Ruler
The default value (after a full reset) for
Custom Scale is one-to-one (1 foot equals
1 foot). This lets you use your Scale Master
Classic as a rolling ruler (in Feet-Inches),
which is especially useful for measuring
irregular shapes.
(Cont’d)

8 – Scale Master®Classic v3.0
1) To reset your Custom Scale setting to
a one-to-one ratio, press [Reset] and
[Subtract/Count] simultaneously.
2) Then press the [Mode] key until the
“Custom” mode appears.
3) Begin rolling.
Memory Function Keystrokes
[Rcl] [M1+] or [Rcl] [M2x]
Displays the value stored in the memory
register.
[Reset] and [M1+] simultaneously
or
[Reset] and [M2x] simultaneously
Clears the value stored in the memory
register.
[Reset] and [Rcl] simultaneously
Clears values stored in memory registers
([M1+] and [M2x]).
Programming Modes
Custom Scale
You can program and store six Custom
Scales: three in Imperial (English) mode
and three in Metric mode.
You can set a custom scale two ways:
by “rolling in” a known distance or by
entering the exact distance.
(Cont’d)

9 – User’s Guide
Rolling or Entering a Custom Scale
1) Press [Mode] until “1: CUS 1”appears
in the scale box display.
2) Press [Subtract/Count] and [Scale]
simultaneously.“
ROLL” will appear in the
main display. If you are entering a
scale, skip to step 4.
3) Roll desired dimension. “ROLLING“ now
appears in the main display.
Note: For greater accuracy, you may want to roll
the known distance several times, then enter
the distance times the number of rolls (for
example, roll a distance 5 times and if the
distance is 3 feet, enter 15 feet).
4) Press [Scale]. The display will show
zeroes and the units of measurement
annunciator will begin flashing (FT-IN for
Imperial Mode, MM for Metric Mode).
5) If you do not want to change the units
of measure, skip to step 6. If you want
to change the units of measure, press
[M1+] until you reach the desired units.
6) Press [Scale] to begin setting the scale
distance. The left-most digit will
begin flashing. Press:
[M1+] to increment this digit,
[Subtract/Count] to decrement,
[Scale] to advance to next digit,
[Mode] to move back one digit.
7) Continue to press [Scale] until all dig-
its are set and the display returns to
zero. The scale is now stored.

10 – Scale Master®Classic v3.0
Area and Volume
Finding Area
1) Roll the first dimension and press
[M1+]. A small “M” will appear in the
scale box display and the main display
will be cleared.
2) Roll the second dimension and press
[M2x]. The main display will be cleared.
3) Press [Rcl] [M2x]. This displays the linear
value stored in this register. The second
press of [M2x] will calculate and display
the area, which is the value stored in
[M1+] times the value stored in [M2x].
Finding Volume
1) Roll the first dimension and press [M1+].
2) Roll the second dimension and press
[M2x].
3) Storing a height value (if you have pre-
viously set a height, skip to step 4):
a. To Roll and Store a Height:
i. Roll the third dimension and
press [Subtract/Count] and [M2x]
simultaneously. The display will
show the rolled value and the unit
of measure will begin flashing.
ii. If you do not want to change the
unit of measure, go to step iii. To
change the unit of measure, press
[M1+] until you reach the desired
unit.

11 – User’s Guide
iii.Press [Scale] to advance through
the flashing digits until the display
returns to zero. The height is now
stored.
b. To Enter and Store a Height:
i. If you are entering a height (instead
of rolling), press [Subtract/Count]
and [M2x] simultaneously. The unit
of measure will begin flashing.
ii. If you do not want to change the
unit of measure, go to step iii. To
change the unit of measure, press
[M1+] until you reach the desired
unit.
iii.Press [Scale] to begin setting the
digits. The left-most digit will
begin flashing.
Press:
[M1+] to increment this digit,
[Subtract/Count] to decrement,
[Scale] to advance to next digit,
[Mode] to move back one digit.
iv. Continue pressing [Scale] until all
digits are set and the display returns
to zero. The height is now stored.
Note: Once you set your height, you do not need
to enter it again unless you want to change it.
4) Press [Rcl] [M2x]. This displays the
linear value stored in this register.
Press [M2x] a second time to calculate
and display the area. Press the [M2x]
key again to find volume. Press [M2x]
a fourth time to display the stored
height value.

12 – Scale Master®Classic v3.0
Converting Between Scales
The Scale Master Classic can automatically
convert values between scales. For exam-
ple, 20 feet rolled in 1/16” scale will be
converted to 10 feet in 1/8” scale. You
may want to roll a value in one scale and
then add that exact value (unconverted)
in another scale.
1) Roll a value and press [M1+]. Press
[Scale] to change scales.
2) Roll another value and press [M1+].
3) Press [Rcl] [M1+] to recall the combined
total.
Locking Scale Settings
Your Scale Master Classic comes equipped
with a lock switch that prevents inadver-
tently changing drawing scales. When the
lock is activated, a lock symbol will be dis-
played in the LCD. While active, the Scale
and Mode cannot be revised (other than by
removal of the battery).
Using the Counter
You can use the [Subtract/Count] key to
count items such as electrical outlets,
drains, etc.
Press [Mode] until you find the Count
mode. Then press the [Subtract/Count] key
to count the items.
You can use the [M1+] and [M2+] memory
keys to store or accumulate the counts for
two different items. After you have a count
value, press [M1+] or [M2+] to store it.

13 – User’s Guide
Error/Auto-Range Function
Error Message – Press [Reset] to clear to any
errors.
Auto Range Function – When calculating large
numbers, your answer will be displayed in the
next largest measurement unit (ex: 10,000 M
will display instead of 10,000,000 MM ).
Interference
Exposure to direct light or close proximity to cell
phones and other electronic devices may cause
interference with the Scale Master device and
result in erroneous measurements.
Automatic Shut-Off
The unit will shut itself off if it is not used for
5 minutes. Press any key to restore power. All
registers/settings remain intact.
Battery Replacement
To replace the batteries:
(1) Remove battery door;
(2) Insert batteries positive side down.
Turning the Clicker & Beep On/Off
To toggle the clicker off or on, press [Reset] and
[Scale] simultaneously. This will also toggle the
Count beep off or on.
APPENDIX

14 – Scale Master®Classic v3.0
Specifications
POWER SOURCE:
Two 3-Volt CR-2430 lithium batteries.
Approximately 400 hours normal use.
DISPLAY METHOD:
LCD with zero suppression, commas and annunciators.
DISPLAY CAPACITY (Main Display):
9,999,999 (7 digits)
RESOLUTION/ACCURACY:
.025 Inch/99.75%
DIMENSIONS:
6.7 x 1.6 inch x 0.6 inch (170mm x 41mm x 15mm)

15 – User’s Guide
Warranty, Repair and Return
Information
RETURN GUIDELINES:
1. Please read the Warranty in this
User's Guide to determine if your
Calculated Industries product remains
under warranty before calling or
returning any device for evaluation or
repairs.
2. If your product won't turn on, check
the batteries as outlined in the User's
Guide.
3. If you need more assistance, please go
to the website listed below.
4. If you believe you need to return your
product, please call a Calculated
Industries representative between the
hours of 8:00am and 4:00pm Pacific
Time for additional information and a
Return Merchandise Authorization
(RMA).
Call Toll Free: 1-800-854-8075
Outside USA: 1-775-885-4900
www.calculated.com/warranty
Repair and Return

16 – Scale Master®Classic v3.0
Calculated Industries (“CI”) warrants this product against
defects in materials and workmanship for a period of one
(1) year from the date of original consumer purchase in
the U.S. If a defect exists during the warranty period, CI,
at its option, will either repair (using new or remanufac-
tured parts) or replace (with a new or remanufactured
calculator) the product at no charge.
THE WARRANTY WILL NOT APPLY TO THE PRODUCT IF
IT HAS BEEN DAMAGED BY MISUSE, ALTERATION,
ACCIDENT, IMPROPER HANDLING OR OPERATION, OR
IF UNAUTHORIZED REPAIRS ARE ATTEMPTED OR
MADE. SOME EXAMPLES OF DAMAGES NOT COVERED
BY WARRANTY INCLUDE, BUT ARE NOT LIMITED TO,
BATTERY LEAKAGE, BENDING,
A “BLACK INK SPOT”
OR
VISIBLE CRACKING OF THE LCD, WHICH ARE PRE-
SUMED TO BE DAMAGES RESULTING FROM MISUSE
OR ABUSE.
To obtain warranty service in the U.S., please go to the
website.
A repaired or replacement product assumes the
remaining warranty of the original product or 90 days,
whichever is longer.
Non-warranty repair covers service beyond the warranty
period or service requested due to damage resulting
from misuse or abuse.
Contact Calculated Industries to obtain current product
repair information and charges. Repairs are guaranteed
for 90 days.
To obtain warranty or non-warranty repair service for
goods purchased outside the U.S., contact the dealer
through which you initially purchased the product. If you
cannot reasonably have the product repaired in your
area, you may contact CI to obtain current product repair
information and charges, including freight and duties.
(CI’s address and web site are listed on page 43.)
Repair Service – Outside the U.S.A.
Non-Warranty Repair Service – U.S.A.
Warranty Repair Service — U.S.A.
Warranty

17 – User’s Guide
Software Copyrighted and licensed to
Calculated Industries by
Scale Master Technologies, LLC, 2007.
User’s Guide copyrighted by
Calculated Industries, 2007.
Scale Master®and Calculated Industries®are
registered trademarks of Calculated Industries, Inc.
ALL RIGHTS RESERVED.
Designed in the United States of America.
Printed in China.
CI MAKES NO WARRANTY OR REPRESENTATION, EITHER
EXPRESS OR IMPLIED, WITH RESPECT TO THE PRODUCT’S
QUALITY, PERFORMANCE, MERCHANTABILITY, OR FITNESS
FOR A PARTICULAR PURPOSE. AS A RESULT, THIS
PRODUCT, INCLUDING BUT NOT LIMITED TO, KEYSTROKE
PROCEDURES, MATHEMATICAL ACCURACY AND
PREPROGRAMMED MATERIAL, IS SOLD “AS IS,” AND YOU
THE PURCHASER ASSUME THE ENTIRE RISK AS TO ITS
QUALITY AND PERFORMANCE.
IN NO EVENT WILL CI BE LIABLE FOR DIRECT, INDIRECT,
SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES
RESULTING FROM ANY DEFECT IN THE PRODUCT OR ITS
DOCUMENTATION.
The warranty, disclaimer, and remedies set forth above are
exclusive and replace all others, oral or written, expressed
or implied. No CI dealer, agent, or employee is authorized
to make any modification, extension, or addition to this
warranty.
Some states do not allow the exclusion or limitation of
implied warranties or liability for incidental or consequential
damages, so the above limitation or exclusion may not apply
to you. This warranty gives you specific rights, and you may
also have other rights, which vary, from state to state.
Disclaimer

18 – Scale Master®Classic v3.0

19 – User’s Guide
SCALE MASTER®CLASSIC
OUTIL DE MESURE NUMÉRIQUE Á
ÉCHELLES MULTIPLES
Guide de l’utilisateur
Calculated Industries, Inc.
4840 Hytech Drive
Carson City, NV 89706 USA

20 – Scale Master®Classic v3.0
Description des touches et des fonctions
[Off/On] – Mise hors/sous tension
Met l’appareil hors ou sous tension. Le fait
de mettre l’appareil hors tension ne remet
pas les échelles ou les modes à zéro.
[Lock] – Touche de verrouillage
Verrouille le mode et l’échelle pour
empêcher toute modification par
inadvertance.
[Subtract/Count] – Touche de
soustraction/compte
Bascule le mode de mesure entre des
valeurs positives et négatives. Incrémente
de 1 la valeur du compte. La fonction de
compte est active en mode de compte.
[Rcl] – Touche de rappel
Rappelle les valeurs entrées en mémoire.
Appuyer sur [Rcl] [Rcl] pour faire afficher à
nouveau la dernière mesure roulée à l’écran.
[Mode] – Touche de mode
Est utilisée pour basculer entre les modes
d’échelle suivants (dans l’ordre) :
1) Architecture (ARCH);
2) Ingénierie I (ENG I);
3) Ingénierie II (ENG II);
4) Personnalisé (CUSTOM);
5) Compte (COUNT).
[Scale] – Touche d’échelle
Est utilisée pour basculer entre les dif-
férentes échelles de chaque mode d’échelle.
