Casio CFX-9970G User manual

CFX-9970G
GUIDELINES LAID DOWN BY FCC RULES FOR USE OF THE UNIT IN THE U.S.A. (not appli-
cable to other areas).
NOTICE
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protec-
tion against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC WARNING
Changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
Proper connectors must be used for connection to host computer and/or peripherals in order to
meet FCC emission limits.
Connector SB-62 Power Graphic Unit to Power Graphic Unit
Connector FA-122 Power Graphic Unit to PC for IBM/Macintosh Machine
Model Number: CFX-9970G
Trade Name: CASIO COMPUTER CO., LTD.
Responsible Party: CASIO, INC.
Address: 570 MT PLEASANT AVENUE,
DOVER, NEW JERSEY 07801
Telephone Number: 973-361-5400
This device complies with Part 15 of FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
Declaration of Conformity
SA9808-003101A Printed in Japan

i
BEFORE USING THE CALCULATOR
FOR THE FIRST TIME ONLY...
This calculator does not contain any main batteries when you purchase it. Be sure to
perform the following procedure to load batteries, reset the calculator, and adjust the color
contrast before trying to use the calculator for the first time.
1. Slide the back cover from the unit by pulling with your finger
at the point marked 1.
2. Load the four batteries that come with calculator.
• Make sure that the positive (+) and negative (–) ends of the
batteries are facing correctly.
3. Remove the insulating sheet at the location marked “BACK
UP” by pulling in the direction indicated by the arrow.
4. Replace the back cover, making sure that its tabs enter the
holes marked 2in the illustration.
5. Press m.
If the Main Menu shown to the right is not on the display,
press the P button on the back of the calculator to
perform memory reset.
PPP button
BACK UPBACK UP
MAINMAIN
PP
BACK UPBACK UP
MAINMAIN
PP
P
MAIMAI
1
P
MAIMAI
2

ii
6. Use the cursor keys (f, c, d, e) to select the SYS icon and press
wor simply presst
F
.
7. Use the cursor keys (c, f) to highlight
Color Contrast and then press wto display
the contrast adjustment screen.
8. Adjust the display color.
uTo adjust the color contrast
1. Use fand cto move the pointer to CONTRAST.
2. Press eto make the figures on the display darker, and dto make them
lighter.
uTo adjust the tint
1. Use fand cto move the pointer to the color you want to adjust (ORANGE,
BLUE, or GREEN).
2. Press eto add more green to the color, and dto add more orange.
9. To exit display color adjustment, press m.
REMOVING AND REPLACING
THE CALCULATOR'S COVER
To remove the cover
Grasp the top of the cover, and slide the
unit out from the bottom.
To replace the cover
Grasp the top of the cover, and slide the
unit in from the bottom.
Always slide the unit into the cover with
the unit's display end first. Never slide the
keyboard end of the unit into the cover.

ABOUT THE COLOR DISPLAY
The display uses three colors: orange, blue, and green, to make data easier to understand.
• Main Menu • Display Color Adjustment
• Graph Function Menu
• Graph Display (Example 1) • Graph Display (Example 2)
• Graph-To-Table Display • Dynamic Graph Display
• Table & Graph Numeric Table • Recursion Formula Convergence/
Divergence Graph Example
iii

• Statistical Regression Graph Example
• When you draw a graph or run a program, any comment text normally appears on the
display in blue. You can, however, change the color of comment text to orange or green.
Example: To draw a sine curve
1. Enter the GRAPH Mode and input the following.
3(TYPE)1(Y=)
(Specifies rectangular coordinates.)
svwf45
(Stores the expression.)
2. 4(COLR)
23456
• Press the function key that corresponds to the color you want to use for the graph:
1for blue, 2for orange, 3for green.
3. 2(Orng)
(Specifies the graph color.)
J6
4.6(DRAW)
(Draws the graph)
You can also draw multiple graphs of different color on the same screen, making each one
distinct and easy to view.
iv

KEYS
v
Note that pressing /displays the character "/" for division, not "÷".
Alpha Lock
Normally, once you press aand then a key to input an alphabetic character, the key-
board reverts to its primary functions immediately. If you press !and then a, the
keyboard locks in alpha input until you press aagain.

KEY TABLE
vi
Page Page Page Page Page Page
128
Page Page Page Page Page
132 113
47 46
2 47 46
154 144 120
383 4
2 27 28 3
46 46
46 46
45 45
45 45
21
20
36
36
36
36
39
36
45
36
47
36
49
49
47
36
45
45
22
49

Turning Power On And Off
Auto Power Off Function
Using Modes
Basic Calculations
Replay Features
Fraction Calculations
Exponents
Graph Functions
Dual Graph
Box Zoom
Dynamic Graph
Table Function
Quick-Start

Quick-Start
viii
Welcome to the world of color graphing calculators and the CASIO “CFX-9970G”.
Quick-Start is not a complete tutorial, but it takes you through many of the most com-
mon functions, from turning the power on, to specifying colors, and on to graphing complex
equations. When you’re done, you’ll have mastered the basic operation of the “CFX-
9970G” and will be ready to proceed with the rest of this user’s guide to learn the entire
spectrum of functions available.
Each step of the examples in Quick-Start is shown graphically to help you follow along
quickly and easily. When you need to enter the number 57, for example, we’ve indicated it
as follows:
Press fh
Whenever necessary, we’ve included samples of what your screen should look like.
If you find that your screen doesn’t match the sample, you can restart from the beginning
by pressing the “All Clear” button o.
TURNING POWER ON AND OFF
To turn power on, press o.
To turn power off, press !
o
OFF
.
AUTO POWER OFF FUNCTION
Note that the unit automatically turns power off if you do not perform any operation for
about six minutes (about 60 minutes when a calculation is stopped by an output command
(^)).
USING MODES
The “CFX-9970G” makes it easy to perform a wide range of calculations by simply
selecting the appropriate mode. Before getting into actual calculations and operation
examples, let’s take a look at how to navigate around the modes.
To select the RUN Mode
1. Press mto display the Main Menu.

Quick-Start
ix
2. Use defc to highlight RUN and then
press w.
This is the initial screen of the RUN mode, where you
can perform manual calculations, and run programs.
BASIC CALCULATIONS
With manual calculations, you input formulas from left to right, just as they are written on
paper. With formulas that include mixed arithmetic operators and parentheses, the calcula-
tor automatically applies true algebraic logic to calculate the result.
Example: 15 !3 + 61
1. Press oto clear the calculator.
2. Press bf*d+gbw.
Parentheses Calculations
Example: 15 !(3 + 61)
1. Press bf*(d
+gb)w.
Built-In Functions
The “CFX-9970G” includes a number of built-in scientific functions, including trigonomet-
ric and logarithmic functions.
Example: 25 !sin 45˚
Important!
Be sure that you specify Deg (degrees) as the angle unit before you try this
example.
