CALEFFI Altecnic SATK22 Series Manual

SATK22 & SATK32 HIU
programmer guide

SATKF2000 programmer user guide
1
Index
Page Topic
2 Introduction
2 Keys and symbols
3 Selecting the operating mode
3 Summer and winter operation
4 Setting the clock and temperature
5 Setting the clock
6 Setting the room DAY temperature
6 Setting the room NIGHT temperature
7 Setting the room HEATING FLOW temperature
7 Setting the room DOMESTIC HOT WATER temperature
8 Enabling/disabling DOMESTIC HOT WATER pre-heat
8 Manual operation
9 Automatic operation
9 Holiday mode

SATKF2000 programmer user guide
2
Introduction
This guide is intended to help the end user understand the features of the SATKF2000 programmer
and to assist them in making changes to the operate of the programmer and heat interface unit (HIU)
or confirm the operating parameters.
The installer of the system will have commissioned and set the programmer to typical operating
conditions, which can be altered to suit individual comfort requirements.
The HIU and programmer can be operated and the settings altered by using the buttons, observing
the changing symbols on the LED screen and following the instructions in this guide.
Keys and Symbols
Select operating mode
Set time and temperature
Weekly program
Alarm set
Select temperature
level (day/night)
Temperature display
Keys
Change displayed value (turn).
Select automatic/manual (press).
Confirm (press).

SATKF2000 programmer user guide
3
Selecting the Operating Mode
Summer and Winter Operation
The oper ating modes you can set are:
SELECTED
STATUS ID ICONS
OFF
SUMMER
WINTER
HEATING ONLY
Select the operating mode by
pressing key several times
Press Once - OFF: all request are disabled
USER
Press Twice - SUMMER: the heat
interface unit is enabled to produce
domestic hot water only
Press 3 Times - WINTER: the heat
interface unit is enabled to produce
both domestic hot water and spece
heating.

SATKF2000 programmer user guide
4
Setting the Clock and Temperature
USER
SELECTED
STATUS
ID ICONS
+
+
* These parameters may not be accessible
CLOCK
TEMPERATURE
DAY
TEMPERATURE
NIGHT
HEATING FLOW
TEMPERATURE
SELECTED
STATUS
ID ICONS
DOMESTIC HOT WATER
TEMPERATURE
COMFORT MODE
HEATING MAX RETURN*
KD OUTSIDE PROBE*
DHW MAX RETURN*
COMFORT MODE enables/disables the
domestic hot water pre-heating.
To set the clock and the temperature of
this remote programmer and of the
boiler press key several times
In place of the time, the quantity value is
displayed in the lower left corner. Its
identifying icon will be flashing. In order
to conclude the setting phase press key
several times until the identifying
icons are off

SATKF2000 programmer user guide
5
Setting the Clock
1. Press key : the hour will flash.
2. Turn button
value. to set the required
3. Press button
input value.
The hour will stop flashing and the
minutes will start flashing.
to confirm the
4. Turn button
to set the value.
5. Press button
The minutes stop flashing and
the day of the week will start
flashing
to confirm value. 7. Press button
The day of the week stops
flashing and the icon goes off.
8. Day 1 is Monday and day 3 shown
is Wednesday etc. each day can
have its own unique programme.
6. Turn button to set the value.
to confirm value.

SATKF2000 programmer user guide
6
Setting the Room DAY temperature (if thermostat enabled)
1. Press key
flashing. until icon starts
2. Turn button
want. to set the value you
.
Setting the Room NIGHT temperature (if thermostat enabled)
1. Press key
flashing. until icon starts
2. Turn button
want. to set the value you

SATKF2000 programmer user guide
7
Setting the HEATING flow temperature
Setting the DOMESTIC HOT WATER temperature
If the remote programmer has been
configured as modulating, this
parameter determines the max.
temperature value as computed by
the modulation algorithms.
1. Press key
flashing. until icon starts
2. Turn button
want. to set the value you
.
1. Press key
flashing. until icon starts
2. Turn button
want. to set the value you

SATKF2000 programmer user guide
8
COMFORT FUNCTION - Enabling / disabling DOMESTIC HOT WATER pre-heating
1. Press key
flashing. until icon starts
2. Turn button
disabled (OFF) or enable
according to the weekly domestic hot
water pre-heating program (PROG)
function.
to enable (ON),
Manual operation
1. Press button until icon appears.
The central digits on the display will
show the set temperature flashing.
2. Turn button to set the temperature
you want.
If the thermostat function is disabled, pressing key until icon appears results
in disablin
g
the time
p
ro
g
rammin
g
of the s
p
ace heatin
g
set on the
p
ro
g
rammer.
3. After 30 secs the central display will go
back to showing the current ambient
temperature.
4. The set temperature can be changed
again at any time by turning button .
5. The set temperature can be displayed
by pressing key .
6. The selected temperature will continue
until the next phase, when the
programmer switches off the space
heating or the night program commences.

SATKF2000 programmer user guide
9
Automatic operation
until the heating clock1. Press button
corona will be displayed.
2. Icon or will light up to show which
is the current set temperature
level.
If the thermostatic function is disabled,
pressing button until the heating
clock corona is displayed enables the
time programming of space heating set
on the programmer (for any external
thermostat connected to the heat
interface unit).
Holiday Mode
The programmer can be set to override other functions when the premises will be un-occupied eg.
during holidays.
This is important during winter when the DHW and Heating pipework could freeze causing flooding
and damage.
Holiday protection is in additional to the anti-freeze function.
Everyday during the holiday the space heating program will follow the set pattern for each day.
1. Press key
shown in the central display.
until “HOL” will be
2. Icon
which is the currect set temperature
level.
will light up to show
The space heating program will be
according to the set pattern of the holiday
day, no matter what the day of the week is.
or
If the thermostat function is disabled,
pressing button until the heating
clock corona is displayed enables
the holiday time programming of space
heating set on the device (for any
external thermostat connected to the
heat interface unit).
To turn off Holiday Mode follow the
Summer and Winter Operating procedure
on page 3.

SATKF2000 programmer user guide
10
Notes:

SATKF2000 programmer user guide
