Calibre HQView-400 Series User manual
©Calibre UK Limited Issue 1.41 08 August 2011, W: www.calibreuk.com
This manual explains how to operate your HQView-400 Series (HQView-4xx) image scaler. The
HQView-400 Series comes in three versions HQView-400S, HQView-410 and HQView-420.
HQView-4xx is designed to provide users with a powerful and flexible method of driving large
display devices, and multiple screen applications including flexible geometry correction
functions.
If you have any queries relating to this or any other product supplied by Calibre please visit our
web site www.calibreuk.com.
1274 730960, for the attention of our Technical Support Department.
COPYRIGHT
This document and the software described within it are copyrighted with all rights reserved. Under
copyright laws, neither the documentation nor the software may be copied, photocopied, reproduced,
translated, or reduced to electronic medium or machine readable form, in whole or in part, without prior
written consent of Calibre UK Ltd ("Calibre"). Failure to comply with this condition may result in
prosecution.
Calibre does not warrant that this product package will function properly in every hardware/software
environment.
Although Calibre has tested the hardware, firmware, software and reviewed the documentation,
CALIBRE MAKES NO WARRANTY OR REPRESENTATION, EITHER EXPRESS OR IMPLIED, WITH
RESPECT TO THIS HARDWARE, FIRMWARE, SOFTWARE OR DOCUMENTATION, THEIR
QUALITY, PERFORMANCE, MERCHANTABILITY, OR FITNESS FOR A PARTICULAR PURPOSE.
THIS SOFTWARE AND DOCUMENTATION ARE LICENSED 'AS IS', AND YOU, THE LICENSEE, BY
MAKING USE THEREOF, ARE ASSUMING THE ENTIRE RISK AS TO THEIR QUALITY AND
PERFORMANCE.
IN NO EVENT WILL CALIBRE BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OR INABILITY TO USE THE SOFTWARE
OR DOCUMENTATION, even if advised of the possibility of such damages. In particular, and without
prejudice to the generality of the foregoing, Calibre has no liability for any programs or data stored or
used with Calibre software, including costs of recovering such programs or data.
Calibre UK Ltd
Cornwall House, Cornwall Terrace
Bradford, West Yorkshire
BD8 7JS, England
Telephone +44 (0)1274 394125
Fax + 44 (0)1274 730960
Email techsupport@calibreuk.com
Web-site www.calibreuk.com
Copyright (c) 2011 All World-wide Rights Reserved
All trade marks acknowledged
Calibre operates a policy of continued product improvement, therefore specifications are subject to
change without notice as products are updated or revised.
E&OE.
©Calibre UK Limited Issue 1.41 08 August 2011, W: www.calibreuk.com
Contents
SAFETY WARNING: 1
INTRODUCTION 2
1.1. General Introduction 2
1.2. Packing List 3
HQVIEW-4XX SYSTEM DESCRIPTION 4
2.1. Product Overview 4
2.2. Product Specification 4
2.2.1. Power Supply Requirement 4
2.2.2. Video Inputs 4
2.2.3. Component Video Inputs 4
2.2.4. HDSDI Input 4
2.2.5. Computer (SVGA) Inputs VESA formats 5
2.2.6. HDMI & DVI Inputs 5
2.2.7. Audio Output 5
2.2.8. Display Output 5
HQVIEW-4XX CONTROL 6
3.1. Menu Tree 6
3.2. Introduction 12
3.3. Main Menu 13
3.4. Input 13
3.5. Output 14
3.5.1. Display Type 14
3.5.2. Output Mode 14
3.5.3. Location 14
3.5.4. Optimize for Display 14
3.5.5. Frame Rate 14
3.5.6. I/O Lock 15
3.5.7. Native Color Temp 15
3.5.8. Output Gamma 15
3.6. Colour 16
3.6.1. Black-Level Offset 16
3.6.2. Black-Level 16
3.6.3. Contrast 16
3.6.4. Saturation 16
3.6.5. Hue 16
3.6.6. RGB values 16
3.6.7. Colour Temp 16
3.6.8. RGB values 16
3.6.9. Input Gamma 17
3.7. Geometry 17
3.7.1. Horizontal/Vertical Position 17
3.7.2. Edge Control 17
3.7.3. Warp 17
3.7.4. Picture Format 17
3.7.5. Overscan 18
3.7.6. Pan Tilt Zoom 18
3.8. PiP 19
3.8.1. PiP Input 19
3.8.2. PiP Mode 19
3.8.3. PiP Size 19
3.8.4. PiP Position 19
3.9. Multiple Unit 20
3.9.1. Auto Zoom 20
3.9.2. Units Wide/Units High 20
3.9.3. Horizontal Pos/Vertical Pos 20
3.9.4. Blend Width 20
3.9.5. Blend Curve Type 21
3.10. Enhancement 22
©Calibre UK Limited Issue 1.41 08 August 2011, W: www.calibreuk.com
3.10.1. Sharpness 22
3.10.2. Detail 22
3.10.3. Video Filters 22
3.11. System 23
3.11.1. User 23
3.11.2. Names/Profiles 23
3.11.3. Input Config 23
3.11.4. Display Mode 24
3.11.5. Menu Settings 24
3.11.6. Network Settings 24
3.11.7. Factory Defaults 24
3.11.8. Operation Mode 24
REMOTE CONTROL WEB SERVER 25
4.1. Introduction 25
4.2. Installing the Software 25
4.3. Discovery Tool 25
4.4. Software Operation 26
FIRMWARE UPDATE 27
5.1. Introduction 27
5.2. Updating Firmware 27
ENVIRONMENTAL AND EMC 28
6.1. Recommended Operating Conditions 28
6.2. Storage 28
6.3. CE and FCC Compliance 28
©Calibre UK Limited Issue 1.41 08 August 2011, W: www.calibreuk.com
SAFETY WARNING:
1. THERE ARE NO USER SERVICEABLE PARTS WITHIN THE UNIT. REMOVAL OF THE TOP COVER
WILL EXPOSE DANGEROUS VOLTAGES. DO NOT OPERATE THE UNIT WITHOUT THE TOP COVER
INSTALLED.
2. ENSURE THAT ALL ELECTRICAL CONNECTIONS (INCLUDING THE MAINS PLUG AND ANY
EXTENSION LEADS) ARE PROPERLY MADE AND COMPLY WITH ELECTRICAL SAFETY
REGULATIONS.
3. ENSURE THAT THE INTEGRITY OF THE EQUIPMENT ISOLATION BARRIER IS MAINTAINED WHEN
CONNECTING TO OTHER EQUIPMENT. THIS MEANS THAT ONLY LOW VOLTAGE ISOLATED
CIRCUITS MAY BE CONNECTED TO THE SIGNAL INPUTS AND OUTPUTS. IF ANY DOUBT EXISTS
CONSULT QUALIFIED SERVICE PERSONNEL.
4. TO PREVENT SHOCK OR FIRE HAZARD DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR
MOISTURE. IF SUCH EXPOSURE OCCURS, REMOVE THE PLUG FROM THE MAINS OUTLET AND
HAVE THE EXPOSED UNIT CHECKED BY QUALIFIED SERVICE PERSONNEL.
5. DO NOT CONTINUE TO OPERATE THE EQUIPMENT IF YOU HAVE ANY DOUBT ABOUT IT
WORKING NORMALLY, OR IF IT IS DAMAGED IN ANY WAY. WITHDRAW THE MAINS PLUG FROM
THE MAINS OUTLET AND CONSULT QUALIFIED SERVICE PERSONNEL.
6. DO NOT REMOVE ANY FIXED COVERS UNLESS YOU ARE QUALIFIED TO DO SO AND EVEN THEN
WITHDRAW THE MAINS PLUG FROM THE MAINS OUTLET BEFORE YOU START.
7. THIS EQUIPMENT CONTAINS NO USER SERVICEABLE PARTS. REFER ALL SERVICING AND
MAINTENANCE TO QUALIFIED SERVICE PERSONNEL.
8. TO AVOID EXPLOSION, DO NOT OPERATE THIS EQUIPMENT IN AN EXPLOSIVE ATMOSPHERE
©Calibre UK Limited Issue 1.41 08 August 2011, W: www.calibreuk.com
INTRODUCTION
1.1.
General Introduction
HQView-4xx is a very flexible image scaler developed specifically for driving large screen displays and
multiple screen applications from video or graphics sources.
HQView-4xx features state of the art digital image processor which provides market leading HD& SD
per-pixel multiple Iow-angle motion-adaptive de-interlacing and automatic film pull-down correction for
3:2 and 2:2, significantly outperforming the capabilities of benchmark competitor products.
HQView-4xx features excellent image processing algorithms for the very best scaling, film and video
noise reduction and MPEG artefact reduction.
HQView-4xx uses a very flexible high performance video input front end including true component video
support in analog YPbPr and RGBS formats and HDSDI/SDI digital formats as well as composite
(CVBS) and YC/S-Video inputs. A very high performance video decoder is utilised with 4x oversampling
and 3D Y/C separation for outstanding video image clarity. HDMI and DVI video with HDCP encryption
is also supported, as are computer graphics inputs in SVGA analogue and HDMI/DVI digital formats.
The output format can be set to I/O Lock mode where it locks the output frame rate to the input frame
rate dynamically without frame rate conversion so as to reduce system latency, or it can be set to a fixed
output frame rate for driving basic screens which are not 50Hz-compatible. A Low latency mode with
non-motion adaptive reduced processing is available to further reduce latency.
Outputs are available in VGA analog and DVI digital formats which are useable simultaneously so that
one output can drive the screen while the other runs a local monitor. Note that if an HDCP encrypted
signal is connected to the HDMI or DVI input, the DVI output signal will be similarly HDCP encrypted and
the VGA analog output will be disabled.
HQView-4xxV2 supports Pan, Zoom and Tilt to select a part of the input image, fill the screen and pan
within it.
HQView-4xx can be operated with different firmware. At time of issuing this document three firmware
options are available. Each firmware provides different feature sets controlled through the OSD. Thus,
the OSD menu systems of the firmware options may deviate from each other. Special emphasize is
given in the discussion of the OSD menu system in the corresponding chapters.
In the basic configuration HQView-400S used for single display installations Picture in Picture
functionality is provided.
The next stage is the HQView-410 for multi screen or multi projector installations. Picture in Picture is
replaced by Auto Zoom and Edge Blend. Edge Blend allows to electronically reduce the brightness level
of certain image regions to match the brightness of overlapping areas. Auto Zoom automatically crops
and zooms the input video image to display the section of the total image on the corresponding projector
or screen. Embedded warp is provided allowing to adjust the image in a projection scenario to match a
rotated, tilted or curved screen.
HQView-420 adds free form warp capability for certain non-flat screens in a multi projector installation.
Warp maps created with the PC tool “Warp Generator” can be uploaded into HQView-420 and
processed accordingly.
HQView-400DC is a specialized version of HQView-400S targeted for the digital cinema market. It
includes embedded warp and defaults to settings which are more appropriate to drive cinema
projectors.
System control is via an OSD controlled by keys on the front panel or through the inbuilt TCP/IP web
server.
©Calibre UK Limited Issue 1.41 08 August 2011, W: www.calibreuk.com
1.2.
Packing List
HQView-4xx is supplied with the following:
1) This manual
2) 3 pin plug IEC mains cable
3) DVI-D output cable
4) CD
©Calibre UK Limited Issue 1.41 08 August 2011, W: www.calibreuk.com
HQVIEW-4XX SYSTEM DESCRIPTION
2.1.
Product Overview
HQView-4xx is designed to accept the following input signals:
Composite video via BNC
Composite video via RCA
S-Video via 4-way miniDIN
YPbPr or RGBS SD/ED/HD component video via 3/4xBNC
HDSDI/SDI (Serial Digital Interface) via BNC
VGA analog (computer interface) via 15HDD
DVI (Digital Visual Interface) via DVI-I (only the digital part is implemented on this connector)
HDMI via HDMI connector
2.2.
Product Specification
This section provides technical details for all possible inputs. Please note that not all possible input
options may be applicable to certain output modes.
2.2.1.
Power Supply Requirement
100V-264VAC 50/60Hz connected via a standard IEC connector located on the rear panel.
2.2.2.
Video Inputs
Composite via BNC and RCA connector, S-Video via 4-way mini DIN socket
Signal formats Composite (CVBS), S-Video (Y/C),
StandardsNTSC, PAL, SECAM
Composite (CVBS) input level 1V p-p nominal inc. sync
Luminance (Y) input level 1V p-p nominal inc. sync
Chrominance (C) input level 0.6V p-p nominal
Input Impedance (all inputs) 75 Ohms
2.2.3.
Component Video Inputs
Via 3 or 4 BNC connectors
YPbPr, YPbPrS, RGB and RGBS component video, menu selectable.
Signal formats 484i (480i) and 576i (SD), 480p, 576p (ED), 720p, 1080i at 50, 59.94 and 60Hz and
1080p at 24, 25, 29.97 and 30Hz.
Please note this input does not support Computer SVGA signals which should be connected via the
Computer SVGA input
2.2.4.
HDSDI Input
Format: SD-SDI and HD-SDI YCbCr 4:2:2 serial digital component video
Input impedance: 75 ohms.
SMPTE 292M and SMPTE 259M-C compliant, accepts 484i, 576i, 720, 1080i and 1080p single link
formats at 270Mb or 1.485Gb rates.
©Calibre UK Limited Issue 1.41 08 August 2011, W: www.calibreuk.com
2.2.5.
Computer (SVGA) Inputs VESA formats
Signal formats: DOS, VGA –WUXGA up to 165MHz pixel clock
RGB video level 0.7V - 1.0V
RGB input impedance 75 Ohms
Sync format Separate H & V sync at TTL/5V levels.
2.2.6.
HDMI & DVI Inputs
HDMI 1.3 with or without HDCP, 36-bit video compatible.
DVI-D input with or without HDCP
Signal formats -video
484i and 576i (SD) in double-rate formats (1440 pixels per line), 480p, 576p (ED), 720p, 1080i at 50,
59.94 & 60Hz, 1080p at 24, 25, 30, 50, 59.94 & 60Hz.
Signal formats –computer
DOS, VGA –WUXGA up to 165MHz pixel clock
2.2.7.
Audio Output
HQView-4xx features an S/PDIF coaxial digital audio outputting HDMI audio.
2.2.8.
Display Output
Two output connectors are provided which are useable simultaneously, provided the input signal is not
HDCP encrypted. When the input signal has HDCP encryption, the DVI-D output connector will carry a
similarly HDCP encrypted signal and the VGA connector may be disabled. When an HDCP encrypted
signal is input, but the display device does not support HDCP, the output image will turn black
and a message indicating HDCP Signal will come up to indicate this.
One is a DVI-D output and the other is a VGA style output. Both conform to normal VESA standards for
connectors and pinouts for these signal types. The DVI-D connector will support HDMI 1.3 with 36-bit
video and HD audio formats when connected to a suitable HDMI 1.3 receiver.
©Calibre UK Limited Issue 1.41 08 August 2011, W: www.calibreuk.com
HQVIEW-4XX CONTROL
3.1.
Menu Tree
HQView-400S Menu Tree
1st Level 2nd Level 3rd Level 4th Level
©Calibre UK Limited Issue 1.41 08 August 2011, W: www.calibreuk.com
1st Level 2nd Level 3rd Level 4th Level
©Calibre UK Limited Issue 1.41 08 August 2011, W: www.calibreuk.com
1st Level 2nd Level 3rd Level 4th Level
©Calibre UK Limited Issue 1.41 08 August 2011, W: www.calibreuk.com
1st Level 2nd Level 3rd Level 4th Level
©Calibre UK Limited Issue 1.41 08 August 2011, W: www.calibreuk.com
HQView-410 as well as HQView-420 have a Multiple Unit Menu instead of the HQView-400 PiP Menu and they
feature embedded Warp.
HQView-410/420 can be rebooted in HQView-400S mode with PiP instead of Multiple Unit capability.
1st Level 2nd Level 3rd Level 4th Level
©Calibre UK Limited Issue 1.41 08 August 2011, W: www.calibreuk.com
HQView-420 has an additional Discrete Warp Map Item compared to HQView-410
1st Level 2nd Level 3rd Level 4th Level
HQView-400DC is a specialized version of HQView-400S targeted for the digital cinema market. It includes
embedded warp.
1st Level 2nd Level 3rd Level 4th Level
©Calibre UK Limited Issue 1.41 08 August 2011, W: www.calibreuk.com
3.2.
Introduction
The front panel has keys for OSD menu navigation, input channel selection and often used functions.
OSD navigation is through two direction keys and a Menu/Enter key.
1 –Standby key: When applying power to the unit it starts up. This is indicated by the green On LED
flashing. Once the unit is operational, the On LED is permanently on. By pressing the Standby Key, the
unit is put into standby mode. This is indicated by the red Standby LED being permanently on. The red
Keylocked LED indicates a keypad locking condition issued through the OSD menu. If a key on the front
panel is now pressed an OSD message comes up and displays the multiple key press to be applied to
unlock the front panel keys.
2 –Input channel selection keys: All input channels can be directly selected. The active channel is
indicated by the red LED above the corresponding channel key being on.
3 –PiP or AutoZoom key: A HQView-400 has a key to directly activate the PiP mode. The green LED is
switched on when in PiP mode. HQView-410 and 420 have a key to directly activate the AutoZoom
mode instead. The green LED is switched on when in AutoZoom mode.
4 –OSD navigational keys: With the Menu key the OSD menu is activated. The up/down keys are used
for OSD menu navigation. To exit the OSD menu or any submenu press the up and down key
simultaneously or navigate to the Exit item and press the menu key. To access a submenu navigate to it
and press the menu key. To apply a change go to the menu item, press the menu key and make a
parameter change with the up/down key. Confirm the change by pressing the Menu key. This will also
bring you back to the submenu.
5 –Direct function keys: Contrast (gain), Black (offset/brightness), Color (saturation) and Hue can be
altered directly from the front panel.
With the following multiple key presses further functions can be applied:
Keypad unlock: Menu/Up/Down
Set output mode to VGA: Menu/Contrast up/Contrast down
Mode reset: Menu/Black up/Black down
Factory reset: Color up/Color down/Hue up/Hue down
A factory reset can also be applied when pressing the factory reset key combination at power up.
The back panel features all input and output connectors, communication ports and the power supply
connector.
1 –SD/HD-SDI input 2 –Composite Video 1 (RCA) and S-Video input
3 –Composite Video 2 (BNC) 4 –Digital audio output
5 –HDMI input 6 –DVI-D and VGA input
7 –YPbPr / RGB(S) video input 8 –DVI-D and VGA output
9 –USB port 10 –TCP/IP port
11 –RS232 port 12 –Power supply connector
1
2
3
4
5
1
2
3
4
5
6
7
8
9
10
11
12
©Calibre UK Limited Issue 1.41 08 August 2011, W: www.calibreuk.com
3.3.
Main Menu
The main menu lists the input channel select item, 6 sub menus, and a menu item for automatic setup
of VGA modes. The 6 sub menus are Output, Color, Geometry, PiP (HQView-400S) or Multiple Unit
(HQView-410 and 420), Enhancement and System.
On each menu page an Exit menu item is available to leave the menu or submenu. Some adjustments
are not applicable to all signal types or operating modes, in which case those non-applicable functions
will be ghosted and are not accessible via the menus.
All menus have a top status line and a bottom line indicating the firmware revision number. In the status
line the currently selected input channel is indicated and the detected mode is identified. The firmware
revision number displays the revision number of the bootloader behind BL, the revision number of the
firmware behind FW and whether it is a 400S, 410, 420 type HQView unit.
To set up your HQView-4xx it is recommended that you follow this procedure:
Choose the correct output mode and parameters to suit your screen or projector.
Select the correct input signal.
Set the input levels and features appropriately to optimize the appearance of your image.
Set any other parameters to suit your application.
Note: All Input parameters are specific to your chosen input channel and input signal type, they are not
global to the unit. All Output parameters are global.
3.4.
Input
The list of available inputs can be scrolled through using the Up and Down keys. The new input is not
selected until the Menu key is pressed.
The list of inputs are: CVBS 1, CVBS 2, S-Video, Component, VGA, HD-SDI, HDMI and Test Pattern.
Test patterns can be generated by HQView-4xx without needing an input connected. When Test Pattern
is selected as the input, the required test pattern can be chosen with the menu navigation up/down keys
when the OSD menu is off.
©Calibre UK Limited Issue 1.41 08 August 2011, W: www.calibreuk.com
3.5. Output
This menu contains adjustments associated with setting up outputs from the unit. The items are
organized in two sub menus, Display Type and Gamma/Color/Crush. Use the up and down keys to
scroll to the required item and press the Menu key.
3.5.1. Display Type
Settings: Projector, LCD/Plasma
Select Projector if you need the blend and warp function. Set to LCD/Plasma if you do not need these
functions to be shown in the menu system. Note: For the HQView-4xx series this feature is of limited
use and only provides a compacted menu system. For the HQView-5xx series the LCD/Plasma mode
will make the Flicker Filter available in multiple unit configurations without blend or black-level uplift. The
HQView LED line has a LED setting which makes LED specific features available.
3.5.2. Output Mode
Settings: 640x480, 800x600, 1024x768, 1280x768, 1280x800, 1280x1024, 1360x768, 1366x768,
1400x1050, 1440x900, 1600x1200, 1680x1050, 1920x1200, 720p (1280x720), 1080p (1920x1080)
Set up the desired output resolution with output mode. The output mode setting should match the native
resolution of the imaging device to avoid double scaling.
3.5.3. Location
Settings: Front Tabletop, Front Ceiling, Rear Tabletop, Rear Ceiling
The image can be flipped to accommodate different projection scenarios as well as screens mounted
upside down.
3.5.4. Optimize for Display
Settings: DVI forced, Optimized, DVI/HDMI
Internally, the display interface processes data at a full ten bits per colour. A resolution of ten bits per
colour is provided for the VGA output. The colour depth on the DVI-D output is determined by the
supported standard of the attached monitor or device when set to DVI/HDMI. For DVI 1.0 and HDMI
1.1/1.2 devices it is 24 bit, for HDMI 1.3 compliant devices it is up to 36 bit.
DVI forced will output with 24 bit colour depth irrespective of the supported standard of the attached
monitor.
When the Optimized setting is enabled the output resolution is automatically set to the native screen
resolution of the attached display if the Aspect Ratio menu item was chosen to Scale or when no input is
detected. The colour depth is determined in the same way as when set to DVI/HDMI.
3.5.5. Frame Rate
Settings: 50Hz, 60Hz, Auto
In auto mode the output frame rate follows the input frame rate, i.e. when a 50Hz/60Hz video signal is
detected, the output is repeated at 50Hz/60Hz. When the input video signal has other than 50Hz or
60Hz (with margin) refresh rate, the output is set to 60Hz. Resolution and actual frame rate is shown in
the status lines of the OSD window under Output Format.
©Calibre UK Limited Issue 1.41 08 August 2011, W: www.calibreuk.com
3.5.6. I/O Lock
Settings: On, Off
If I/O Lock is switched off the output is run with a fixed refresh rate determined by the frame rate setting,
which deviates from the input refresh rate, even if both are nominally at the same rate. This causes
occasional frame dropping or repeat. If I/O Lock is on the output refresh rate is following the input
refresh rate. This is achieved by modulating the output clock and works if input and output refresh rate
are nominally at the same rate, e.g. when frame rate is set to 60Hz and the video input is also 60Hz. If
e.g. the video input rate is 50 Hz and the Frame rate is set to 60Hz, the output is in free run mode. The
status line of the OSD window under Sync Mode indicates if the output signal is locked to the input
signal (I/O Locked) or in free run mode (Free Run) .
3.5.7. Native Color Temp
Settings: 5500, 6500, 7500, 9300, 10000
Native Color Temp allows the user to select from pre-configured color temperatures to match the
display. If both Native Color Temp set here in the Output menu and Color Temp set in the Color menu
are set to the same value, no conversion is performed.
3.5.8. Output Gamma
Settings: 1.0 to 3.0 in steps of 0.1
Output gamma allows to re-gamma video signals with pre-configured gamma values to match the
display. Input gamma and output gamma both default to 2.2. If they are both set to the same value,
there is no effect on the image.
Note: If e.g. an adjustment to reduce the level of red in the image is required, select a higher number for
the (input) Color Temp in the Color menu, or a lower number for the Native Color Temp in the Output
menu.
©Calibre UK Limited Issue 1.41 08 August 2011, W: www.calibreuk.com
3.6. Colour
This menu contains adjustments associated with setting up inputs to the unit. Use the Up and Down
keys to scroll to the required item and press the Menu key.
3.6.1. Black-Level Offset
Settings: 0 IRE, 7.5 IRE
Used to select 7.5 IRE black level set-up adjustment. Should always be set to 7.5 IRE for HDMI video
inputs and should usually be off for analog video inputs.
3.6.2. Black-Level
Settings: -50 to 50 in steps of 1
Black level controls the offset applied to the video signal.
3.6.3. Contrast
Settings: -50 to 50 in steps of 1
Contrast controls the gain applied to the video signal.
3.6.4. Saturation
Settings: -50 to 50 in steps of 1
Control of video saturation, applies to all video inputs but not computer input signals or formats.
3.6.5. Hue
Settings: -50 to 50 in steps of 1
Control of video hue, applies to all video inputs but not computer input signals or formats.
3.6.6. RGB values
This is a user-defined color temperature setting whereby individual R,G,B gain and offset (bias) can be
set so as to accurately calibrate a particular input to the display device.
3.6.7. Colour Temp
Settings: 5500, 6500, 7500, 9300
Colour Temp allows the user to select from pre-configured colour temperatures to match the colour
temperature of the incoming signal. If both Colour Temp set here in the Colour menu and Native Colour
Temp set in the Output menu are set to the same value, no conversion is performed.
3.6.8. RGB values
This is a user-defined colour temperature setting whereby individual R,G,B gain and offset (bias) can be
set so as to accurately calibrate a particular input to the display device.
This manual suits for next models
3
Table of contents
