Callibri Smart Move User manual
Contents
About this guide.........................................................4
Symbols and abbreviations used in this guide........4
Safety information.....................................................5
Additional warnings for electrostimulation
usage..........................................................................6
Device information.....................................................8
Purpose of the device...............................................8
General information about Callibri............................9
Technical characteristics........................................11
Technical characteristics: power supply................12
Markings..................................................................12
Device operation......................................................14
External appearance of Callibri...............................14
Charging the battery................................................15
Caring for the device................................................16
Manufacturer`s warranty..........................................17
Troubleshooting.......................................................18
4
About this guide
The user guide describes the functions and
characteristics of the Callibri sensor/device in detail.
Safe operation of the device requires familiarity with
the contents of this guide.
Symbols and abbreviations used in this
guide
This user guide employs the following symbols:
Warning – situations which can cause harm
to you or those around you.
Attention – situations that may result in
damage to the device or other equipment.
Note – recommendations or additional
information.
OS – operating system
PC – personal computer/laptop
5
User guide
Safety information
The following precautions are necessary to avoid
potential harm to the user or damage to the device.
• Do not use a damaged charger or USB cable,
and do not use with loose or damaged
electrical sockets.
• Do not use excessive force when inserting the
USB cable into the device, as this can damage
the USB connector.
• Avoid kinking any of cables that are plugged
into the USB connector, as this can cause the
cables to break.
• Do not allow moisture or gel to enter the USB
connector, as this can lead to clogged or
oxidized electrode contacts and damage the
device. Such malfunctions are not covered by
warranty.
• Do not use the device during thunderstorms,
which increase the risk of electrical shock.
• Do not place the device inside or on top
of heating sources (such as microwaves,
stovetops or radiators). When severely
overheated the device may explode.
• The disposable electrodes should only be used
on healthy, undamaged skin.
6
Additional warnings for
electrostimulation usage
• Do not use disposable surface electrodes that
have dried out! This can cause burns on the
user’s skin!
• Do not perform stimulation in close proximity
to metallic objects (belts, clasps, jewelry, etc.)!
• Do not plug the charger into the device while it
is mounted on the user’s body!
The device should not be used in the following
circumstances:
• Electrical current intolerance on the part of the
user.
• Damage to the user’s skin (cuts, abrasions,
ulcers).
• User has a pacemaker, neurostimulator or any
other electronic implant.
• User has a heart condition, and has not
consulted a doctor before using Callibri.
• Serious circulation problems in the lower
extremities.
• Use only with caution if the user experiences
epileptic seizures. Use only with a doctor’s
permission!
It is forbidden to:
• Use the device near the head. Data do not exist
concerning the effects of stimulation on the
brain.
• Use the device to stimulate the throat. Possible
7
User guide
effects include severe muscle spasms and
airway obstruction.
• Undergo stimulation of the upper thorax,
which may interfere with the rhythm of the
heart.
It is not recommended to:
• Undergo stimulation for extended periods
(longer than 30 minutes).
• Use the device while pregnant.
• Do not attempt modification or repair of the
device. In case of malfunction, contact the
manufacturer.
• Extreme heat and cold may damage the
device, as well as reduce battery life and
power output.
• Do not apply excessive force to the USB
connector on the Callibri device.
• The device is intended for use in designated
healthcare facilities. For further instructions
on utilization, consult your local authorities.
8
Device information
Purpose of the device
The Callibri device is designed for use with Life/Health
Tracking software on mobile and desktop computers.
The device has two purposes:
• electrophysiological;
• electrostimulative.
Electrophysiological operation of the device allows the
recording of electromyography, electrocardiography,
electroencephalography and rheopulmonography
(respiratory movement) signals.
Electrostimulative operation provides
electrostimulation of muscles.
Both operations employ triaxial MEMS (gyroscope and
accelerometer) which enable the device to orient itself
in space.
The device has its own software development kit
(SDK). The SDK is intended for software developers
on Android, iOS, MacOS, Windows and Linux operating
systems.
These development tools facilitate easy creation of
Callibri-based apps for the following purposes:
• For electrophysiology:
-development of ‘smart clothing’;
- heart rhythm monitoring;
- monitoring personal exercise and training;
- medical applications (neurology, physical therapy,
gynecology, urology, etc.).
9
User guide
• For electrostimulation:
- EMS training in tness;
- restoring muscle tone to weakened muscles;
- pain reduction.
General information about Callibri
The Callibri sensor connects to an external device
(desktop computer, tablet or mobile phone) with
the help of Bluetooth Low Energy (BLE) wireless
technology. The quality and stability of this connection
depends in large part upon the operating environment
and proper procedure by the user.
To ensure a stable connection between Callibri and
the external device, follow these recommendations:
• Do not cover Callibri or the external device with
your body or other objects; preserve direct line of
sight between devices. This requirement is due
to the fact that Bluetooth Low Energy uses a 2.4
HZ radio frequency. At this frequency, radio waves
have difculty passing through obstacles.
• For use with desktop computers, use a high
quality BLE adapter (recommended model Asus
USB-BT400, product not included). It is also
recommended to bring the BLE adapter into close
proximity with Callibri using a USB extension cable
(product not included).
• While Callibri is in use, disconnect all other
Bluetooth devices – especially multimedia
(headsets, etc.) devices – to avoid reducing the
bandwidth available to Callibri. The fewer devices
connected via Bluetooth, the greater Callibri’s
10
ability to accurately transfer wireless data.
• Try to minimize the distance between Callibri and
the external device. The maximum connection
range is highly dependent on external factors, such
as the degree of interference from radio emitters
working on the same frequency as BLE (2.4 GHz).
Observe the effective range, beyond which stable
connection becomes impossible.
• Try to minimize the number of devices which are
emitting radio waves on the same frequency as
BLE (2.4 GHz) are are present in the same room as
Callibri, while also limiting the presence of powerful
radio emitters in general. It is recommended to
disable the WiFi functionality on devices device
to which Callibri is connected, as well as the local
WiFi network.
• Try to avoid placing Callibri in close proximity
to metallic objects. Metal is impermeable to
radio waves, and can cause distortions in BLE
transmitting channels.
11
User guide
Technical characteristics
Technical characteristics for electrophysiological use
Connection between
Callibri and external device
BLE version 4.0 or
later
Voltage range from 0 V to 0.2 V
Recorded signals EKG, EMG, EEG, angle,
velocity, acceleration
Detection of sensor’s
orientation in space yes
Input–Referred Noise
(measured with the inputs
shorted together)
no more than 12 μVpp
Duration of uninterrupted
use at least 6 hours
12
Connection between
Callibri and external device
BLE version 4.0 or
later
Recorded signals angle, velocity,
acceleration
Current amplitude of
stimulative impulse
from 1 to 100 mA in
increments of 1 mA
Frequency of stimulative
impulses
from 1 GHz to 200
GHz in increments of
1 GHz
Duration of stimulative
impulse
from 60 to 460 μs in
increments of 20 μs
Duration of uninterrupted
use at least 6 hours
Technical characteristics: power supply
Input parameters: 100–240 VAC, 50/60 Hz, 0.1–0.5 A
(or in accordance with your region).
Output parameters: 5V, DC (direct current) 1–2 A.
Technical characteristics for electrostimulative use
Markings
Labels and markings on the Callibri device contain the
following information:
• name of device;
• name or trademark of manufacturer;
• serial number;
• graphics and warning symbols.
13
User guide
Labels and marking on the packaging contain the
following information:
• name or trademark of manufacturer;
• name of device;
• graphics and warning symbols.
14
Device operation
External appearance of Callibri
LED indicators for electrophysiological use:
• LED indicators not illuminated –
Callibri is turned off.
• Left indicator glows green – Callibri is
powered on.
• Right indicator glows red – battery
charge is less than 5%.
• Right indicator blinks red – battery
charge is less than 1%.
Power button
Indicator 1
Indicator 2
Terminal for
attaching
electrode
Label
Terminal for
attaching
electrode
Micro USB
port
15
User guide
LED indicators for electrostimulative use:
• LED indicators not illuminated –
Callibri is turned off.
• Left indicator glows green – Callibri
is powered on and in standby mode/
pausing to trigger electrical impulses.
• Right indicator glows red – Stimulation
in progress.
• Right indicator blinks red – battery
charge is less than 1%.
LED indicators when charging battery:
• LED indicators not illuminated –
Callibri is turned off.
• Left indicator blinks green – battery is
charging.
• Left and right indicators glow green
and red – battery is fully charged.
Charging the battery
Before using Callibri, the battery must be charged.
• Only use chargers that meet all the technical
characteristics listed in this guide. The use
of improper chargers may cause the battery
to explode, or otherwise cause damage to the
device.
16
Additional power supply requirements for
electrostimulative use
• Charging Callibri through a USB connector in
a desktop computer is not recommended!
• In stimulation mode, a USB connector on a
desktop computer must not be used to charge
Callibri!
Caring for the device
• All parts of the device can be carefully
wiped clean with a moist toilette. Callibri’s
attachment band should be periodically
washed with soap and warm water.
• Do not expose the internal components of the
device to moisture!
17
User guide
Manufacturer`s warranty
Warrantied period of operation – 12 months.
Warrantied period of storage – 6 months from date of
production.
In the event that repair or correction of defects is
necessary during the warrantied period, the warranty
is extended by the amount of time for which the
device is not available for use due to the defect or
malfunction. If the device is replaced in its entirety,
the warranty period is renewed from the date of the
replacement.
Warranty repair of the device is carried out at the cost
of the seller/manufacturer. After expiration of the
warranty, the cost of repairs is borne by the purchaser
of the device.
If a warrantied device ceases to function due to
improper operation, then the cost of repairs is borne
by the purchaser.
18
Troubleshooting
Before contacting technical support, acquaint yourself
with the recommendations in the «General Information
about Callibri» section (page 9), or attempt the
following troubleshooting procedures:
Device does not turn on
Callibri does not power on because the battery is
fully depleted.
Connect the charger to the device.
：
FCC Warningÿ
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's
authority to operate the equipment.
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference
in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement.
The device can be used in portable exposure condition without restriction
Manufacture/distributor:
Callibri Inc.
Address: 205 E 42nd Street, 14th Floor
New York, NY 10017, US
Phone number: 1.646.725.1205
E-mail: [email protected]
Table of contents
