The mechanical shuer must be cocked between every exposure. WDS lens
panels featuring the Schneider® or Rodenstock® electronic shuer are avail-
able on request.
D. MOUNTING THE DIGITAL BACK
Please choose the SLW interface adapter corresponding to the interface mount
of your digital back. The digital back is mounted to the SLW adapter as it would
to corresponding medium format camera body (Hasselblad®-V, Mamiya® AFd,
Leaf® AFi, etc.). To synchronize the digital back with the mechanical/electronic
shuer please use the brand specic “synchro release cable”. For further op-
erang details please follow the instrucons of the manufacturer of the digital
back.
E. MOVEMENTS: SHIFT, RISE AND FALL
The Wide RS features horizontal as well as vercal (rise/fall) movement of the
rear standard. These movements can be used for perspecve control, image
displacement and stching of mulple exposures. This allows the user to take
full advantage of the large image circle of certain lenses. Both movements
shi the image plane, which allows the user to take mulple images within the
same focal plane, ideal for stching. Stching can be used to create panoramas
with the maximum viewing angle or to create higher resoluon les.
The horizontal shi is operated by drive knob located at the top of the camera.
From the opcal center posion the rear standard can be moved 20mm le
or 20mm right. The vercal shi (rise/fall) is operated by drive knob which is
located at the right hand side of the camera. From the opcal center posion
the rear standard can fall 25mm (shis the image up) or rise 15mm (shis the
image down).
Please note that above movements are the mechanically feasible movements,
which do not by default reect the opcal possibilies of all lenses. Each lens
has its own possibilies and limits.
F. MOVEMENTS AND SCALES
The horizontal movement can be followed and repeated viewing the scale (20)
on top of the main housing. The scale is divided into millimeters for your con-
venience. There are also movement indicators engraved on the back side of
the main housing which are always visible from behind the camera either un-
der or above the vercal moving plate, depending upon its posion.
The vercal movement can be followed and repeated viewing the scale on
right hand side of the main housing. The scale is divided into millimeters for
your convenience. There are also movement indicators engraved on the le
